The Application of Fluorescence In Situ Hybridization in the Prescreening of Veronica Hybrids

by
Hye-Wan Park
1,
Samantha Serafin Sevilleno
1,
My Khanh Tran Thi Ha
2,
Raisa Aone Cabahug-Braza
3,
Ji-Hun Yi
4,
Ki-Byung Lim
5,
Wonwoo Cho
4,* and
Yoon-Jung Hwang
1,3,*
1
Department of Convergence Science, Sahmyook University, Seoul 01795, Republic of Korea
2
Institute for Global Health Innovations, Duy Tan University, Danang 550000, Vietnam
3
Plant Genetics and Breeding Institute, Sahmyook University, Seoul 01795, Republic of Korea
4
Division of Garden and Plant Resources, Korea National Arboretum, Pocheon 11186, Republic of Korea
5
Department of Horticultural Science, Kyungpook National University, Daegu 41566, Republic of Korea
*
Authors to whom correspondence should be addressed.
Plants 2024, 13(9), 1264; https://doi.org/10.3390/plants13091264
Submission received: 25 March 2024 / Revised: 22 April 2024 / Accepted: 29 April 2024 / Published: 1 May 2024
(This article belongs to the Section Plant Genetics, Genomics and Biotechnology)
Browse Figures
Versions Notes

Abstract

:
Fluorescence in situ hybridization (FISH), a molecular cytogenetic technique that enables the visualization and identification of specific DNA sequences within chromosomes, has emerged as a pivotal tool in plant breeding programs, particularly in the case of Veronica species. Veronica, a genus with a complex reproductive system, often poses challenges in accurately identifying hybrids because of its tendency to hybridize, which leads to intricate genetic variation. This study focused on the use of FISH as a prescreening method to identify true hybrids in Veronica breeding programs. FISH analysis was first performed on the parents to identify their 45S and 5S rDNA signals, along with their respective chromosome numbers. The signals were then compared with those of the twenty progenies with reference to their supposed parents. Five true hybrids, seven self-pollinated progenies, and eight false hybrids were identified through FISH. The findings highlight the significance of FISH as a screening method that contributes significantly to the efficiency of Veronica breeding programs by ensuring the preservation of desired genetic traits and minimizing the inadvertent inclusion of misidentified hybrids. To conclude, this study underscores the vital role of FISH in enhancing the precision and success of breeding programs and opens new avenues for improved breeding strategies and crop development.

1. Introduction

Fluorescence in situ hybridization (FISH) is an important molecular cytogenetic tool widely used to distinguish complementary DNA sequences using fluorescently labeled probes [1,2]. Along with the chromosome karyotype, FISH data provide the basic information needed for successful crossbreeding, which includes ploidy level, species chromosome characteristics, and parental origin [3]. FISH analysis helps determine the ploidy level and detect aneuploidy, which are important factors affecting pollen fertility and crossing efficiency in roses [4]. Likewise, results from this technique make it easier to visually authenticate hybrids and help track the origins of specific chromosomes, as applied in lily breeding [5]. Owing to its efficient detection and accuracy, the use of FISH analysis for ornamental plants, which have high demand and ornamental significance, is invaluable.
Currently, interest in the use of Veronica species as indoor and landscape plants is at a peak. Veronica, a large genus of the Plantaginaceae family with over 450 species, is highly adaptable to various ecological conditions and horticulturally valued for its prolonged flowering and easy maintenance. Their long flowering period varies from spring to fall, and they come in a wide array of colors, including white, pink, purple, and blue [6,7]. Between 2018 and 2019, there was an eight-fold increase in the average trading volume of Veronica flowers and an almost 50% increase in its unit price [8]. Owing to its desirable ornamental characteristics and increased market demand, an increasing number of studies have been conducted on its classification, morphology, propagation, and breeding [9,10,11].
Several domestic and wild Veronica species have been used as parents for plant breeding programs for Veronica species with desirable characteristics. In Korea, certain native taxa have been evaluated for their growth and flowering characteristics and have at least 40 to over 110 spikes per plant with minute florets ranging from 7 to 10 mm in diameter [11]. Because Veronica is self-compatible, many progenies are produced in one crossing and have a mixture of inbred, false, and true hybrids; thus, self-pollination is a possibility and inevitable [12,13]. A similar situation was observed in closely comparable spiked flowers of Plantago species [14].
Although there are traditional screening methods, such as direct investigation using gross morphological or physical characteristics, there are some cases where these methods may not be sufficient, as hybrids may resemble both parents [15]. In breeding programs, successful interspecific hybridization has been screened using traditional approaches coupled with high-throughput methods such as flow cytometry [16] and single-nucleotide polymorphism markers [17]. However, despite their advantages, these methods can only provide limited information for visibly identifying chromosome structure and organization. An alternative screening method that provides essential information for interspecific hybrids is the use of molecular cytogenetic tools such as karyotyping and FISH [18].
FISH is a well-established molecular cytogenetic technique that primarily focuses on chromosomal-level phylogeny investigation [19]. FISH not only locates a target sequence but also enables qualitative and quantitative analysis by employing labeled nucleic acid probes in conjunction with chromosomes, interphase nuclei, or DNA fibers [20]. This technique has found extensive applications in the identification of specific chromosomal regions and analysis of their composition, spatial positioning, and dynamic changes in chromatin during the cell cycle [19,20,21]. Moreover, FISH has been widely employed to elucidate the physical map, structure, and evolution of the genome and study interspecies relationships [3,5,20]. Ribosomal DNA (rDNA), comprised of 45S and 5S, has been shown to be the most widely used markers, which present a high copy number and are tandemly arranged with different chromosomal distributions [21,22].
FISH analysis was conducted to determine the cytogenetic features of native Korean Veronica taxa, including the chromosome number and rDNA distribution patterns [23]. To date, FISH data have been used to cytogenetically characterize wild species and cultivars to support evolutionary and phylogenetic studies of Veronica spp. [13,24]. We hypothesized that the identification of true hybrids might be based on rDNA distribution patterns that are accurately and visibly identifiable in chromosome spreads. By determining the 5S and 45S loci of the parents and progenies, we were able to differentiate true hybrids from self-pollination and false offspring produced via breeding programs. Only a limited number of studies have used rDNA-FISH analysis as a screening method; hence, we conducted this study.

2. Results

To determine the true hybrids, FISH analysis was first performed on the parents to identify their 45S and 5S rDNA signals, along with their respective chromosome numbers. The signals were then compared with those of the 20 progenies with reference to their supposed parents. The FISH results for the parents as well as the results of crossing studies producing true, self-pollinated, and false hybrids are presented in Table 1.

2.1. Parents

There were nine parents of the screened progenies, of which five were native Korean species (Figure 1A) and four were cultivars (Figure 1B). All Korean native species as well as one cultivar, Veronica spicata f. nana ‘Blauteppich’, showed diploid complements 2n = 34, while the other three cultivars were tetraploids with 2n = 68 (Figure 1). FISH analysis revealed that diploid species and cultivars possessed a pair of 5S rDNA loci, whereas tetraploid parents possessed two pairs of 5S rDNA loci. In contrast, a variable number of 45S rDNA loci were observed in these species and cultivars. Four pairs of 45S rDNA loci were identified in Veronica nakaiana Ohwi. Veronica dahurica Steven and Veronica pusanensis Y. N. Lee possessed five pairs of 45S rDNA loci, whereas Veronica pyrethrina Nakai, Veronica kiusiana var. glabrifolia, and V. spicata f. nana ‘Blauteppich’ had six pairs. The tetraploid cultivars, Veronica spicata ‘Ulster Blue Dwarf’, and Veronica ‘Veronica Blue’, as well as Veronica longifolia ‘Blue Shades’, were observed to have nine and fourteen pairs of 45S rDNA loci, respectively.

2.2. True Hybrids

The results of the hybridization studies, which produced five true hybrids, are shown in Figure 2. The parents used for crossing were all diploid, with one pair of 5S rDNA loci and either five or six pairs of 45S rDNA loci (Figure 2). The results showed that all five progenies had diploid complements with 2n = 34, similar to their parents. A pair of 5S rDNA loci and 11 45S rDNA FISH signals was detected in all hybrids. The FISH signals of 5S and 45S rDNA in the chromosomal complement corresponded to the average number of rDNA signals in both parents. The female parents of Ve-31, Ve-86, and Ve-88 possessed six pairs of 45S rDNA loci, whereas the male parents had five pairs of 45S rDNA loci. In contrast, Ve-55-1 and Ve 57-1 whose female parent is V. pusanensis Y. N. Lee, contain five pairs of 45S rDNA loci, while the male parents both have six pairs of 45S rDNA FISH signals. All progenies had the expected number of eleven 45S rDNA sites.

2.3. Self-Pollinated Progenies

The seven crossing studies that resulted in the self-pollinated Veronica species are shown in Figure 3. All self-pollinated progenies were diploids (2n = 34), possessing one pair of 5S rDNA loci, except for Ve-153, which was tetraploid (2n = 68) with two pairs of 5S rDNA loci (Figure 3). Ve-48 and Ve-56, whose female parent was V. pusanensis Y. N. Lee, possessed five pairs of 45S rDNA loci. Ve-59-2 and Ve-65-2, with V. dahurica Steven as their female parent, also had five pairs of 45S rDNA loci. Ve-77 had a similar number as its parents, with six pairs of 45S rDNA loci. Ve-91 had four pairs of 45S rDNA loci, similar to its female parent, V. nakaiana Ohwi. Nine pairs of 45S rDNA signals were detected in Ve-153, similar to its female parent, V. ‘Ulster Blue Dwarf’.

2.4. False Hybrids

Eight false hybrids were produced in crossing studies, as shown in Figure 4. Progenies are hypothesized to be false hybrids when their chromosome number or rDNA loci is different from the average chromosome number and rDNA loci of both parents or different from the corresponding number of chromosomes or rDNA loci in one of their parents. All progenies were diploid (2n = 34), except for Ve-65-1 and Ve-109, which were tetraploid (2n = 68) (Figure 4). All diploid progenies possessed one pair of 5S rDNA loci, whereas tetraploid progenies had two pairs of 5S rDNA loci. The number of 45S rDNA sequences varied among the progenies. Ve-87, whose supposed parents were similar to the true hybrid Ve-88, was observed to have 16 45S rDNA sites in contrast to the 11 FISH signals found in Ve-88. Eight pairs of 45S hybridization signals were detected in Ve-75, with the same parent as the self-pollinated progeny, Ve-77, which possessed only six pairs of 45S rDNA signals. Ve-65-1 and Ve-65-2 (self-pollinated progeny) had the same parents; however, the former was found to be tetraploid with ten pairs of 45S rDNA loci compared to the latter, which was diploid with only five pairs of 45S rDNA loci. Ve-131 and Ve-132 had the same parents but possessed different 45S rDNA loci at 16 and 15, respectively. Ve-38 and Ve-109, which resulted from a supposed cross-hybridization between a diploid and a tetraploid parent, did not possess the expected triploid chromosome number but were diploid and tetraploid, respectively, and had different 45S rDNA signals in contrast with their supposed parents.

3. Discussion

In plant breeding programs, new experimental hybrids are produced by crossing two parent crops. In many plant species such as lilies [25], crossbreeding is a fundamental breeding strategy in which hybrid affinity is crucial for success. The production of false hybrids is a frequent outcome of hybridization, making it difficult to determine the authenticity of the hybrid [26]. Following cross-hybridization, distinguishing true hybrids is not only vital in developing a breeding program but also essential in enhancing hybrid varieties. However, current approaches to hybrid identification, whether through morphological or molecular means, are both laborious and costly and require specialized knowledge, skills, and specific laboratory equipment [27].
Since the number of chromosomes and karyotypes of a species or cultivar is generally stable, the conventional cytogenetic method of karyotype analysis has been useful in rapidly classifying plant species and verifying alien disomic addition lines in breeding through the identification of some basic cytological parameters [28,29,30]. However, it cannot distinguish individual chromosomes with similar morphology, size, and parental origin from a pair of chromosomes, such as Veronica species with small and similarly sized chromosomes [6]. FISH, which maps repetitive or single-copy sequences on the chromosomes, serves as an important tool in plant cytogenetics. 5S and 45S rDNA, which are highly conserved tandem repeat sequences, are generally used as cytogenetic markers for routine FISH analyses of plant species [31,32,33]. These genetic markers display variability in both intraspecific and interspecific hybrids, as indicated by differences in the intensity, number, and location of hybridization signals [34]. Hybrids can be confirmed cytogenetically based on chromosomal traits using in situ hybridization techniques at the earliest growth stage. FISH is instrumental in detecting hybrids with probes employed as markers to determine the number and position of rRNA genes on chromosomes [35].
In Veronica progenies screened as true hybrids, the FISH signals of 5S and 45S rDNA in their chromosome complements were the average for both parents. FISH has also been utilized to validate hybridization status and investigate genetic diversity in progenies or developed hybrids in other important horticultural plants, such as sweet potato [36], Passiflora [37], and Thinopyrum elongatum [38]. The first attempt to use FISH with 25S rDNA as a probe proved to be sufficient for hybrid status verification in some Lilium hybrids [35]. In a study by Wang et al. [5], Asiatic hybrid lilies with different ploidy levels were crossbred. Consequently, FISH analysis was successfully conducted on the offspring using 45S rDNA as a probe to visually confirm the authenticity of the hybrid and trace the origins of specific chromosomes. In addition, FISH karyotype analyses using 5S and 45S rDNA probes in xBrassicaraphanus line BB#5, a hybrid of Brassica rapa and Raphanus sativus, showed a combined rDNA pattern for the two parental species [33]. In first-generation (F1) hybrids, the 45S rDNA loci inherited from each parent are often conserved and undergo differential transcriptional silencing [39,40,41].
FISH analyses of Veronica hybrids screened as self-pollinated showed similar chromosome numbers as the female parents, as well as their 5S and 45S rDNA FISH signals. Ve-56 had parents similar to the true hybrid Ve-57-1; however, the number of 45S rDNA sites detected was not the expected average of both parents but was comparable to that of the female parent, V. pusanensis Y. N. Lee, and Ve-48. Hybridization between the tetraploid V. ‘Ulster Blue Dwarf’ and the diploid V. kiusiana var. glabrifolia resulted in a tetraploid progeny (Ve-153) with rDNA signals similar to those of the female parent instead of the expected triploid hybrid with 2n = 51. Ve-59-2 and Ve-65-2 had similar numbers of hybridization signals as their female parent, V. dahurica Steven. Ve-91, a cross-hybridization between V. nakaiana Ohwi and V. spicata f. nana ‘Blauteppich’, had eight 45S rDNA FISH signals similar to those of its female parent. Some Veronica species, such as Veronica cymbalaria Bodard and Veronica persica Poir, have automatic self-crossing abilities [42]. Furthermore, V. spicata subspecies were described as self-compatible, protogynous, and entomophilous species, and were found to be self-pollinated when grown in strict isolation [43]. Veronica is self-compatible; thus, self-pollination during cross-hybridization is possible [12,13]. In tomatoes, less hybridization occurs because of the large number of self-pollinating plants [44].
False hybrids may arise from misclassification or misidentification of parent plants. Eight false or misidentified hybrids were classified using rDNA-FISH analysis, three of which had parents similar to the identified true and self-pollinated Veronica species; however, their chromosomal characteristics were different. The 45S rDNA signal distribution of these hybrids did not correspond to the average rDNA loci of both parents or at least to the rDNA loci similar to one of their parents, thus characterizing them as false hybrids.
In interspecific hybrid breeding programs, a reliable method for identifying parental species and verifying true hybrids is necessary to ensure the production of desired materials and achieve the expected genetic gains [45]. FISH using 5S and 45S rDNA probes in metaphase chromosomes, as confirmed in this study, allows for a quick and clear determination of the genomic composition of hybrid plants [46,47], making it a suitable tool to identify hybrids in breeding programs and to analyze the genomes of the genus Veronica.

4. Materials and Methods

4.1. Plant Materials

Young roots were harvested from the plant materials of the Korean Veronica wild species and the cultivars that served as parents (Table 2).
Similarly, twenty (20) progenies (Table 3) were obtained from the Useful Plant Resources Center of the Korea National Arboretum, Republic of Korea.

4.2. Chromosome Preparation

Modified fixation and chromosome preparation were performed following the methods described by Ha et al. [23]. Properly cleaned and washed harvested root tips were treated with 2 mM 8-hydroxyquinoline for 5 h at 18 °C. Carnoy’s solution (3:1, acetic acid: ethanol, v/v) was used to fix the roots overnight at 25 °C. The root tips were then transferred to a 70% ethanol solution at 4 °C to preserve the materials.
The fixed root tips were placed in distilled water prior to enzyme mixture (1% cellulose, cytohelicase, and pectolyase) treatment at 37 °C for 90 min. The enzyme-treated roots were transferred to a 1.5 mL tube containing Carnoy’s solution and vortexed for 20 s. Homogenized root meristems were placed on ice for 5 min and centrifuged at 13,000 rpm to collect the pellets. The supernatant was discarded, and the pellet was immediately resuspended in an acetic acid–ethanol (9:1) solution. The final suspension was pipetted on an 80 °C pre-warmed glass slide in a humid chamber and air-dried at room temperature.

4.3. Fluorescence In Situ Hybridization

FISH was performed using the modified procedure described by Lim et al. [48]. Pre-labeled probes (PLOPs) of 5S and 45S rDNA sequences were used following the methods described by Waminal et al. [49]. The FISH hybridization mixture consists of 50% formamide, 10% dextran sulfate, 20× saline sodium citrate (SSC) buffer, 50 ng/μL of each PLOP, and nuclease-free water with a 40 μL total volume. The mixture was spread onto prepared chromosomal slides and denatured on a slide heater at 80 °C for 5 min. The slides were then incubated at room temperature in a humid chamber for 30 min. After hybridization, the slides were washed sequentially with 2× SSC at room temperature for 10 min, 0.1× SSC at 42 °C for 25 min, and 2× SSC at room temperature for 5 min and then dehydrated in a series of ethanol concentrations of 70%, 90%, and 100% at room temperature for 3 min each. The slides were counterstained with Vectashield (H-1000, Vector Laboratories, Newark, CA, USA) with 1 µg/mL−1 4′,6-diamidino-2-phenylindole (Roche, Indianapolis, IN, USA) and observed under a fluorescence microscope (Olympus BX53, Olympus, Tokyo, Japan) with a built-in CCD camera (CoolSNAP™ cf, Photometrics, Tucson, AZ, USA) using an oil lens (×100 magnification).

5. Conclusions

The study results demonstrated the effectiveness of FISH in distinguishing true hybrids from plants produced through other genetic mechanisms. These findings highlight the critical role of FISH as a rapid prescreening method that greatly enhances the efficiency of Veronica breeding programs by maintaining the desired genetic characteristics and reducing the inconvenience and consequences of incorporating misidentified hybrids.

Author Contributions

Conceptualization, Y.-J.H.; methodology, H.-W.P., S.S.S., M.K.T.T.H. and J.-H.Y.; formal analysis, H.-W.P., S.S.S. and Y.-J.H.; writing—original draft preparation, S.S.S. and R.A.C.-B.; writing—review and editing, S.S.S., R.A.C.-B., W.C., K.-B.L. and Y.-J.H.; supervision, Y.-J.H.; project administration, Y.-J.H. All authors have read and agreed to the published version of the manuscript.

Funding

This research was funded by the Korea National Arboretum grant number KNA1-5-1,-24-1.

Data Availability Statement

The data presented in this study are available within the article.

Acknowledgments

This study was conducted with the support of the project “Development of Breeding Models for Native Garden Plants in the New Climate Regime (Project No. KNA1-5-1,-24-1)” by the Korea National Arboretum.

Conflicts of Interest

The authors declare no conflicts of interest.

References

  1. Trask, B.J. Human cytogenetics: 46 chromosomes, 46 years and counting. Nat. Rev. Genet. 2002, 3, 769–778. [Google Scholar] [CrossRef]
  2. Speicher, M.R.; Carter, N.P. The new cytogenetics: Blurring the boundaries with molecular biology. Nat. Rev. Genet. 2005, 6, 782–792. [Google Scholar] [CrossRef] [PubMed]
  3. Hwang, Y.J.; Cabahug, R.A.; Mancia, F.H.; Lim, K.B. Molecular cytogenetics and its application to major flowering ornamental crops. Hort. Environ. Biotech. 2020, 61, 1–9. [Google Scholar] [CrossRef]
  4. Hwang, Y.J.; Song, C.M.; Kwon, M.K.; Kim, S.T.; Kim, W.H.; Han, Y.Y.; Han, T.H.; Lim, K.B. An increment of crossing efficiency with consideration of pollen viability analysis in rose. Flower Res. J. 2010, 18, 193–200. [Google Scholar]
  5. Wang, Q.; Wang, J.; Zhang, Y.; Zhang, Y.; Xu, S.; Lu, Y. The application of fluorescence in situ hybridization in different ploidy level cross-breeding of lily. PLoS ONE 2015, 10, e0126899. [Google Scholar] [CrossRef] [PubMed]
  6. Albach, D.C.; Martínez-Ortega, M.M.; Delgado, L.; Weiss-Schneeweiss, H.; Özgökce, F.; Fischer, M.A. Chromosome numbers in Veroniceae (Plantaginaceae): Review and several new counts. Ann. Mo. Bot. Gar. 2008, 95, 543–566. [Google Scholar] [CrossRef] [PubMed]
  7. Albach, D.C.; Meudt, H.M.; Oxelman, B. Piecing together the “new” Plantaginaceae. Am. J. Bot. 2005, 92, 297–315. [Google Scholar] [CrossRef] [PubMed]
  8. Oh, H.Y.; Shin, U.S.; Song, S.J.; Kim, J.H.; Kim, S.Y.; Suh, G.U. Growth and flowering characteristics of 20 Veronica species. Flower Res. J. 2019, 27, 308–317. [Google Scholar] [CrossRef]
  9. Albach, D.C.; Briggs, B.G. Phylogenetic analysis of Australian species of Veronica (V. section Labiatoides; Plantaginaceae). Aust. Syst. Bot. 2012, 25, 353–363. [Google Scholar] [CrossRef]
  10. Albach, D.C.; Chase, M.W. Incongruence in Veroniceae (Plantaginaceae): Evidence from two plastid and a nuclear ribosomal DNA region. Mol. Phylogenet. Evol. 2004, 32, 183–197. [Google Scholar] [CrossRef]
  11. Song, C.Y.; Moon, J.Y.; Kim, S.Y. Growth and flowering characteristics of Veronica native to Korea and their crossings. Acta Hortic. 2020, 129, 33–44. [Google Scholar] [CrossRef]
  12. Albach, D.C.; Greilhuber, J. Genome size variation and evolution in Veronica. Ann. Bot. 2004, 94, 897–911. [Google Scholar] [CrossRef] [PubMed]
  13. Müller, K.; Albach, D.C. Evolutionary rates in Veronica L. (Plantaginaceae): Disentangling the influence of life history and breeding system. J. Mol. Evol. 2010, 70, 44–56. [Google Scholar] [CrossRef] [PubMed]
  14. Sharma, N.; Koul, P.; Koul, A.K. Pollination biology of some species of genus Plantago L. Bot. J. Linn. Soc. 1993, 111, 129–138. [Google Scholar] [CrossRef]
  15. Britten, E.J. A proposed classification of screening methods for plant breeding programs. Euphytica 1960, 9, 293–303. [Google Scholar] [CrossRef]
  16. Väinölä, A. Polyploidization and early screening of Rhododendron hybrids. Euphytica 2000, 112, 239–244. [Google Scholar] [CrossRef]
  17. Stetter, M.G.; Zeitler, L.; Steinhaus, A.; Kroener, K.; Biljecki, M.; Schmid, K.J. Crossing methods and cultivation conditions for rapid production of segregating populations in three grain amaranth species. Front. Plant Sci. 2016, 7, 816. [Google Scholar] [CrossRef] [PubMed]
  18. Lakshmanan, P.S.; Van Laere, K.; Eeckhaut, T.; Van Huylenbroeck, J.; Van Bockstaele, E.; Khrustaleva, L. Karyotype analysis and visualization of 45S rRNA genes using fluorescence in situ hybridization in aroids (Araceae). Comp. Cytogenet. 2015, 9, 145–160. [Google Scholar] [PubMed]
  19. Van Laere, K.; Van Huylenbroeck, J.; Van Bockstaele, E. Karyotype analysis and physical mapping of 45S rRNA genes in Hydrangea species by fluorescence in situ hybridization. Plant Breed. 2008, 127, 301–307. [Google Scholar] [CrossRef]
  20. Schubert, I.; Fransz, P.F.; Fuchs, J.; de Jong, J.H. Chromosome painting in plants. Methods Cell Sci. 2001, 23, 57–69. [Google Scholar] [CrossRef]
  21. Leitch, I.J.; Heslop-Harrison, J.S. Physical mapping of the 18S–5.8 S–26S rRNA genes in barley by in situ hybridization. Genome 1992, 35, 1013–1018. [Google Scholar] [CrossRef]
  22. Heslop-Harrison, J.S. Comparative genome organization in plants: From sequence and markers to chromatin and chromosomes. Plant Cell 2000, 12, 617–635. [Google Scholar] [CrossRef] [PubMed]
  23. Ha, M.K.T.T.; Sevilleno, S.S.; Cabahug, R.A.M. Cytogenetic analysis and genome size estimation of Korean native Veronica taxa. Flower Res. J. 2022, 30, 41–52. [Google Scholar] [CrossRef]
  24. Garcia, S.; Kovařík, A.; Leitch, A.R.; Garnatje, T. Cytogenetic features of rRNA genes across land plants: Analysis of the Plant rDNA database. Plant J. 2017, 89, 1020–1030. [Google Scholar] [CrossRef] [PubMed]
  25. Ramzan, F.; Kim, H.T.; Shim, K.K.; Younis, A.; Choi, Y.H.; Hwang, Y.J.; Lim, K.B. Evaluation of F1 and BC1 hybrids of Lilium lancifolium × Asiatic hybrid ‘Chianti’ by morphological analysis and fluorescence in situ hybridization. J. Hortic. Sci. Biotechnol. 2018, 93, 614–624. [Google Scholar] [CrossRef]
  26. Li, X.; Zheng, B.; Xu, W.; Ma, X.; Wang, S.; Qian, M.; Wu, H. Identification of F1 hybrid progenies in mango based on Fluorescent SSR markers. Horticulturae 2022, 8, 1122. [Google Scholar] [CrossRef]
  27. Sari, H.; Eker, T.; Sari, D.; Aksoy, M.; Bakır, M.; Dogdu, V.; Toker, C.; Canci, H. The Fastest and Most Reliable Identification of True Hybrids in the Genus Pisum L. Life 2023, 13, 2222. [Google Scholar] [CrossRef] [PubMed]
  28. Farshadfar, M. Chromosome location of ISSR markers and genes controlling seed germination under drought stress in wheat-barley disomic addition lines. Cell. Mol. Biol. 2020, 66, 101–108. [Google Scholar] [CrossRef] [PubMed]
  29. Guerra, M. Chromosome numbers in plant cytotaxonomy: Concepts and implications. Cytogenet. Genome Res. 2008, 120, 339–350. [Google Scholar] [CrossRef]
  30. Sun, W.; Sun, H.; Li, Z. Chromosome data mining and its application in plant diversity research. Plant Sci. J. 2019, 37, 260–269. [Google Scholar]
  31. Devi, J.; Ko, J.M.; Seo, B.B. FISH and GISH: Modern cytogenetic techniques. Indian J. Biotechnol. 2005, 4, 307–315. [Google Scholar]
  32. Waminal, N.E.; Kim, H.H. Dual-color FISH karyotype and rDNA distribution analyses on four Cucurbitaceae species. Hortic. Environ. Biotech. 2012, 53, 49–56. [Google Scholar] [CrossRef]
  33. Belandres, H.R.; Waminal, N.E.; Hwang, Y.J.; Park, B.S.; Lee, S.S.; Huh, J.H.; Kim, H.H. FISH karyotype and GISH meiotic pairing analyses of a stable intergeneric hybrid xBrassicoraphanus line BB#5. Korean J. Hortic. Sci. Technol. 2015, 33, 83–92. [Google Scholar]
  34. Younis, A.; Ramzan, F.; Hwang, Y.J.; Lim, K.B. FISH and GISH: Molecular cytogenetic tools and their applications in ornamental plants. Plant Cell Rep. 2015, 34, 1477–1488. [Google Scholar] [CrossRef] [PubMed]
  35. Marasek, A.; Hasterok, R.; Wiejacha, K.; Orlikowska, T. Determination by GISH and FISH of hybrid status in Lilium. Hereditas 2004, 140, 1–7. [Google Scholar] [CrossRef]
  36. Su, D.; Chen, L.; Sun, J.; Zhang, L.; Gao, R.; Li, Q.; Han, Y.; Li, Z. Comparative chromosomal localization of 45S and 5S rDNA sites in 76 purple-fleshed sweet potato cultivars. Plants 2020, 9, 865. [Google Scholar] [CrossRef]
  37. Silva, G.S.; Souza, M.M.; de Melo, C.A.; Urdampilleta, J.D.; Forni-Martins, E.R. Identification and characterization of karyotype in Passiflora hybrids using FISH and GISH. BMC Genet. 2018, 19, 26. [Google Scholar] [CrossRef] [PubMed]
  38. Li, D.; Li, T.; Wu, Y.; Zhang, X.; Zhu, W.; Wang, Y.; Zeng, J.; Xu, L.; Fan, X.; Sha, L.; et al. FISH-based markers enable identification of chromosomes derived from tetraploid Thinopyrum elongatum in hybrid lines. Front. Plant Sci. 2018, 9, 526. [Google Scholar] [CrossRef] [PubMed]
  39. Tucker, S.; Vitins, A.; Pikaard, C.S. Nucleolar dominance and ribosomal RNA gene silencing. Cur. Opin. Cell Biol. 2010, 22, 351–356. [Google Scholar] [CrossRef]
  40. Matyasek, R.; Dobesova, E.; Huska, D.; Ježková, I.; Soltis, P.S.; Soltis, D.E.; Kovařík, A. Interpopulation hybridization generates meiotically stable rDNA epigenetic variants in allotetraploid Tragopogon mirus. Plant J. 2016, 85, 362–377. [Google Scholar] [CrossRef]
  41. Volkov, R.A.; Panchuk, I.I.; Borisjuk, N.V. Evolutional dynamics of 45S and 5S ribosomal DNA in ancient allohexaploid Atropa belladonna. BMC Plant Biol. 2017, 17, 21. [Google Scholar] [CrossRef] [PubMed]
  42. Nishida, S.; Tamakoshi, N.; Takakura, K.I.; Watanabe, Y.; Kanaoka, M.M. Reproductive interference between alien species in Veronica. J. Plant Res. 2024, 137, 167–178. [Google Scholar] [CrossRef] [PubMed]
  43. Wilson, G.B.; Houston, L.; Whittington, W.J.; Humphries, R.N. Veronica spicata L. ssp. spicata and ssp. hybrida (L.) Gaudin (Pseudolysimachium spicatum (L.) Opiz). J. Ecol. 2000, 88, 890–909. [Google Scholar]
  44. Yu, D.; Gu, X.; Zhang, S.; Dong, S.; Miao, H.; Gebretsadik, K.; Bo, K. Molecular basis of heterosis and related breeding strategies reveal its importance in vegetable breeding. Hortic. Res. 2021, 1, 8. [Google Scholar] [CrossRef] [PubMed]
  45. Gros-Louis, M.C.; Bousquet, J.; Pâques, L.E.; Isabel, N. Species-diagnostic markers in Larix spp. based on RAPDs and nuclear, cpDNA, and mtDNA gene sequences, and their phylogenetic implications. Tree Genet. Genomes 2005, 1, 50–63. [Google Scholar] [CrossRef]
  46. Desel, C.; Jansen, R.; Dedong, G.; Schmidt, T. Painting of parental chromatin in beta hybrids by multi-colour fluorescent in situ hybridization. Ann. Bot. 2002, 89, 171–181. [Google Scholar] [CrossRef] [PubMed]
  47. Markova, M.; Lengerova, M.; Ziuvova, J.; Janousek, B.; Vyskot, B. Karyological analysis of an interspecific hybrid between the dioecious Silene latifolia and the hermaphroditic Silene viscose. Genome 2006, 49, 373–379. [Google Scholar] [CrossRef] [PubMed]
  48. Lim, K.B.; De Jong, H.; Yang, T.J.; Park, J.Y.; Kwon, S.J.; Kim, J.S.; Lim, M.H.; Kim, J.A.; Jin, M.; Jin, Y.-M.; et al. Characterization of rDNAs and tandem repeats in the heterochromatin of Brassica rapa. Mol. Cells 2005, 19, 436–444. [Google Scholar] [CrossRef]
  49. Waminal, N.E.; Pellerin, R.J.; Kim, N.S.; Jayakodi, M.; Park, J.Y.; Yang, T.J.; Kim, H.H. Rapid and efficient FISH using pre-labeled oligomer probes. Sci. Rep. 2018, 8, 8224. [Google Scholar] [CrossRef]
Plants 13 01264 g001
Figure 1. Parent Veronica species. (A) Korean native species, namely: (1) V. pyrethrina Nakai; (2) V. dahurica Steven; (3) V. pusanensis Y. N. Lee; (4) V. kiusiana var. glabrifolia; (5) V. nakaiana Ohwi and (B) cultivars, namely: (1) V. spicata ‘Ulster Blue Dwarf’; (2) V. longifolia ‘Blue Shades’; (3) V. spicata f. nana ‘Blauteppich’; and (4) V. ‘Veronica Blue’. 5S and 45S rDNA signals are indicated by the green and red fluorescence, respectively. Scale bar = 10 µm, 400× magnification.
Figure 1. Parent Veronica species. (A) Korean native species, namely: (1) V. pyrethrina Nakai; (2) V. dahurica Steven; (3) V. pusanensis Y. N. Lee; (4) V. kiusiana var. glabrifolia; (5) V. nakaiana Ohwi and (B) cultivars, namely: (1) V. spicata ‘Ulster Blue Dwarf’; (2) V. longifolia ‘Blue Shades’; (3) V. spicata f. nana ‘Blauteppich’; and (4) V. ‘Veronica Blue’. 5S and 45S rDNA signals are indicated by the green and red fluorescence, respectively. Scale bar = 10 µm, 400× magnification.
Plants 13 01264 g001
Plants 13 01264 g002
Figure 2. Progenies screened as true hybrids: (1) Ve-31 (V. pyrethrina Nakai × V. pusanensis Y. N. Lee); (2) Ve-55-1 (V. pusanensis Y. N. Lee × V. pyrethrina Nakai); (3) Ve-57-1 (V. pusanensis Y. N. Lee × V. kiusiana var. glabrifolia); (4) Ve-86 (V. kiusiana var. glabrifolia × V. dahurica Steven); and (5) Ve-88 (V. kiusiana var. glabrifolia × V. pusanensis Y. N. Lee). 5S and 45S rDNA signals are indicated by the green and red fluorescence, respectively. Scale bar = 10 µm, 400× magnification.
Figure 2. Progenies screened as true hybrids: (1) Ve-31 (V. pyrethrina Nakai × V. pusanensis Y. N. Lee); (2) Ve-55-1 (V. pusanensis Y. N. Lee × V. pyrethrina Nakai); (3) Ve-57-1 (V. pusanensis Y. N. Lee × V. kiusiana var. glabrifolia); (4) Ve-86 (V. kiusiana var. glabrifolia × V. dahurica Steven); and (5) Ve-88 (V. kiusiana var. glabrifolia × V. pusanensis Y. N. Lee). 5S and 45S rDNA signals are indicated by the green and red fluorescence, respectively. Scale bar = 10 µm, 400× magnification.
Plants 13 01264 g002
Plants 13 01264 g003
Figure 3. Progenies screened as self-pollinated: (1) Ve-48 (V. pusanensis Y. N. Lee × V. longifolia ‘Blue Shades’); (2) Ve-56 (V. pusanensis Y. N. Lee × V. kiusiana var. glabrifolia (S2)); (3) Ve-59-2 (V. dahurica Steven × V. spicata f. nana ‘Blauteppich’); (4) Ve-65-2 (V. dahurica Steven × V. pyrethrina Nakai); (5) Ve-77 (V. kiusiana var. glabrifolia × V. spicata f. nana ‘Blauteppich’); (6) Ve-91 (V. nakaiana Ohwi × V. spicata f. nana ‘Blauteppich’); and (7) Ve-153 (V. spicata ‘Ulster Blue Dwarf’ × V. kiusiana var. glabrifolia). 5S and 45S rDNA signals are indicated by the green and red fluorescence, respectively. Scale bar = 10 µm, 400× magnification.
Figure 3. Progenies screened as self-pollinated: (1) Ve-48 (V. pusanensis Y. N. Lee × V. longifolia ‘Blue Shades’); (2) Ve-56 (V. pusanensis Y. N. Lee × V. kiusiana var. glabrifolia (S2)); (3) Ve-59-2 (V. dahurica Steven × V. spicata f. nana ‘Blauteppich’); (4) Ve-65-2 (V. dahurica Steven × V. pyrethrina Nakai); (5) Ve-77 (V. kiusiana var. glabrifolia × V. spicata f. nana ‘Blauteppich’); (6) Ve-91 (V. nakaiana Ohwi × V. spicata f. nana ‘Blauteppich’); and (7) Ve-153 (V. spicata ‘Ulster Blue Dwarf’ × V. kiusiana var. glabrifolia). 5S and 45S rDNA signals are indicated by the green and red fluorescence, respectively. Scale bar = 10 µm, 400× magnification.
Plants 13 01264 g003
Plants 13 01264 g004
Figure 4. Progenies screened as false hybrids: (1) Ve-33 (V. pyrethrina Nakai × V. spicata f. nana ‘Blauteppich’); (2) Ve-38 (V. pyrethrina Nakai × V. spicata ‘Ulster Blue Dwarf’); (3) Ve-65-1 (V. dahurica Steven × V. pyrethrina Nakai); (4) Ve-75 (V. kiusiana var. glabrifolia × V. spicata f. nana ‘Blauteppich; (5) Ve-87 (V. kiusiana var. glabrifolia × V. pusanensis Y. N. Lee); (6) Ve-109 (V. ‘Veronica Blue’ × V. kiusiana var. glabrifolia); (7) Ve-131 (V. spicata f. nana ‘Blauteppich’ × V. pyrethrina Nakai); and (8) Ve-132 (V. spicata f. nana ‘Blauteppich’ × V. pyrethrina Nakai). 5S and 45S rDNA signals are indicated by the green and red fluorescence, respectively. Scale bar = 10 µm, 400× magnification.
Figure 4. Progenies screened as false hybrids: (1) Ve-33 (V. pyrethrina Nakai × V. spicata f. nana ‘Blauteppich’); (2) Ve-38 (V. pyrethrina Nakai × V. spicata ‘Ulster Blue Dwarf’); (3) Ve-65-1 (V. dahurica Steven × V. pyrethrina Nakai); (4) Ve-75 (V. kiusiana var. glabrifolia × V. spicata f. nana ‘Blauteppich; (5) Ve-87 (V. kiusiana var. glabrifolia × V. pusanensis Y. N. Lee); (6) Ve-109 (V. ‘Veronica Blue’ × V. kiusiana var. glabrifolia); (7) Ve-131 (V. spicata f. nana ‘Blauteppich’ × V. pyrethrina Nakai); and (8) Ve-132 (V. spicata f. nana ‘Blauteppich’ × V. pyrethrina Nakai). 5S and 45S rDNA signals are indicated by the green and red fluorescence, respectively. Scale bar = 10 µm, 400× magnification.
Plants 13 01264 g004
Table 1. FISH analyses of parent Korean native Veronica species and cultivars, and the results of crossing studies producing true hybrids, self-pollinated Veronica species, and false Veronica hybrids.
Table 1. FISH analyses of parent Korean native Veronica species and cultivars, and the results of crossing studies producing true hybrids, self-pollinated Veronica species, and false Veronica hybrids.
Plant SampleSpecies/CultivarsChromosome Number (2n)FISH Signals
5S rDNA45S rDNA
ParentsVeronica pyrethrina Nakai34212
Veronica dahurica Steven34210
Veronica pusanensis Y. N. Lee34210
Veronica kiusiana var. glabrifolia34212
Veronica nakaiana Ohwi3428
Veronica spicata ‘Ulster Blue Dwarf’68418
Veronica longifolia ‘Blue Shades’68428
Veronica spicata f. nana ‘Blauteppich’34212
Veronica ‘Veronica Blue’68428
ClassificationCodeSupposed Parents (Mo × Fa)Chromosome Number (2n)FISH Signals
5S rDNA45S rDNA
True hybridsVe-31V. pyrethrina Nakai × V. pusanensis Y. N. Lee34211
Ve-55-1V. pusanensis Y. N. Lee × V. pyrethrina Nakai34211
Ve-57-1V. pusanensis Y. N. Lee × V. kiusiana var. glabrifolia34211
Ve-86V. kiusiana var. glabrifolia × V. dahurica Steven34211
Ve-88V. kiusiana var. glabrifolia × V. pusanensis Y. N. Lee34211
Self-pollinated progeniesVe-48V. pusanensis Y. N. Lee × V. longifolia ‘Blue Shades’34210
Ve-56V. pusanensis Y. N. Lee × V. kiusiana var. glabrifolia (S2)34210
Ve-59-2V. dahurica Steven × V. spicata f.nana ‘Blauteppich’34210
Ve-65-2V. dahurica Steven × V. pyrethrina Nakai34210
Ve-77V. kiusiana var. glabrifolia × V. spicata f. nana ‘Blauteppich’34212
Ve-91V. nakaiana Ohwi × V. spicata f. nana ‘Blauteppich’3428
Ve-153V. ‘Ulster Blue Dwarf’ × V. kiusiana var. glabrifolia68418
False hybridsVe-33V. pyrethrina Nakai × V. spicata f. nana ‘Blauteppich’34210
Ve-38V. pyrethrina Nakai × V. spicata ‘Ulster Blue Dwarf’34210
Ve-65-1V. dahurica Steven × V. pyrethrina Nakai68420
Ve-75V. kiusiana var. glabrifolia × V. spicata f. nana ‘Blauteppich’34216
Ve-87V. kiusiana var. glabrifolia × V. pusanensis Y. N. Lee34216
Ve-109V. ‘Veronica Blue’ × V. kiusiana var. glabrifolia68416
Ve-131V. spicata f. nana ‘Blauteppich’ × V. pyrethrina Nakai34216
Ve-132V. spicata f. nana ‘Blauteppich’ × V. pyrethrina Nakai34215
Table 2. Veronica taxa used as parents in the breeding program.
Table 2. Veronica taxa used as parents in the breeding program.
No. Veronica Taxa
Korean native species
1Veronica pyrethrina Nakai
2Veronica dahurica Steven
3Veronica pusanensis Y. N. Lee
4Veronica kiusiana var. glabrifolia
5Veronica nakaiana Ohwi
Cultivars
1Veronica spicata ‘Ulster Blue Dwarf’
2Veronica longifolia ‘Blue Shades’
3Veronica spicata f. nana ‘Blauteppich’
4Veronica ‘Veronica Blue’
Table 3. Progenies developed from cross breeding with their respective population code.
Table 3. Progenies developed from cross breeding with their respective population code.
No. CodeSupposed Parents (Mo × Fa)
1Ve-31 V. pyrethrina Nakai × V. pusanensis Y. N. Lee
2Ve-33V. pyrethrina Nakai ×V. spicata f. nana ‘Blauteppich’
3Ve-38V. pyrethrina Nakai × V. spicata ‘Ulster Blue Dwarf’
4Ve-48V. pusanensis Y. N. Lee × V. longifolia ‘Blue Shades’
5Ve-55-1V. pusanensis Y. N. Lee × V. pyrethrina Nakai
6Ve-56V. pusanensis Y. N. Lee × V. kiusiana var. glabrifolia (S2)
7Ve-57-1 V. pusanensis Y. N. Lee × V. kiusiana var. glabrifolia
8Ve-59-2V. dahurica Steven × V. spicata f. nana ‘Blauteppich’
9Ve-65-1V. dahurica Steven × V. pyrethrina Nakai
10Ve-65-2V. dahurica Steven × V. pyrethrina Nakai
11Ve-75V. kiusiana var. glabrifolia × V. spicata f. nana ‘Blauteppich’
12Ve-77V. kiusiana var. glabrifolia × V. spicata f. nana ‘Blauteppich’
13Ve-86 V. kiusiana var. glabrifolia × V. dahurica Steven
14Ve-87V. kiusiana var. glabrifolia × V. pusanensis Y. N. Lee
15Ve-88 V. kiusiana var. glabrifolia × V. pusanensis Y. N. Lee
16Ve-91V. nakaiana Ohwi × V. spicata f. nana ‘Blauteppich’
17Ve-109V. ‘Veronica Blue’ × V. kiusiana var. glabrifolia
18Ve-131V. spicata f. nana ‘Blauteppich’ × V. pyrethrina Nakai
19Ve-132V. spicata f. nana ‘Blauteppich’ × V. pyrethrina Nakai
20Ve-153 V. spicata ‘Ulster Blue Dwarf’ × V. kiusiana var. glabrifolia
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.

Share and Cite

MDPI and ACS Style

Park, H.-W.; Sevilleno, S.S.; Ha, M.K.T.T.; Cabahug-Braza, R.A.; Yi, J.-H.; Lim, K.-B.; Cho, W.; Hwang, Y.-J. The Application of Fluorescence In Situ Hybridization in the Prescreening of Veronica Hybrids. Plants 2024, 13, 1264. https://doi.org/10.3390/plants13091264

AMA Style

Park H-W, Sevilleno SS, Ha MKTT, Cabahug-Braza RA, Yi J-H, Lim K-B, Cho W, Hwang Y-J. The Application of Fluorescence In Situ Hybridization in the Prescreening of Veronica Hybrids. Plants. 2024; 13(9):1264. https://doi.org/10.3390/plants13091264

Chicago/Turabian Style

Park, Hye-Wan, Samantha Serafin Sevilleno, My Khanh Tran Thi Ha, Raisa Aone Cabahug-Braza, Ji-Hun Yi, Ki-Byung Lim, Wonwoo Cho, and Yoon-Jung Hwang. 2024. "The Application of Fluorescence In Situ Hybridization in the Prescreening of Veronica Hybrids" Plants 13, no. 9: 1264. https://doi.org/10.3390/plants13091264

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
