Open AccessArticle
Int. J. Mol. Sci. 2013, 14(11), 21319-21327; doi:10.3390/ijms141121319

Enhanced Solar Cell Conversion Efficiency Using Birefringent Liquid Crystal Polymer Homeotropic Films from Reactive Mesogens

Institute of Electro-Optical Engineering, Chang Gung University, Kweisan, Taoyuan 333, Taiwan
*
Author to whom correspondence should be addressed.
Received: 12 September 2013 / Revised: 12 October 2013 / Accepted: 17 October 2013 / Published: 25 October 2013
View Full-Text   |   Download PDF [621 KB, uploaded 19 June 2014]   |

Abstract

Novel birefringent liquid crystal polymer homeotropic films have been coated on semiconductor solar cells to improve the effective incident sunlight angles. The liquid crystal polymer precursor, based on reactive mesogens, is fluidic and flows like liquid. It would distribute uniformly on the solar cell sample surface by any traditional coating technique. The birefringence for light, due to the liquid crystal retardation properties, manipulated the optical length and the deflection of incident light, thus allowed an increase in the energy conversion efficiency. The expensive sunlight tracking systems could be avoided. The processing parameters can be tuned such as different mesogen concentrations and plate speeds of spin-coating. The results showed that the solar cell conversion efficiency was improved from 14.56% to 14.85% at an incident sunlight angle of 15°. It was further improved from 13.40% to 13.81% when the angle was 30°. The interesting angular dependency on solar cell efficiency enhancement has been evaluated. View Full-Text
Keywords: liquid crystal polymer; energy conversion efficiency; reflectivity liquid crystal polymer; energy conversion efficiency; reflectivity
This is an open access article distributed under the Creative Commons Attribution License (CC BY 3.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Wu, G.; Hsieh, L.-H.; Chien, H.-W. Enhanced Solar Cell Conversion Efficiency Using Birefringent Liquid Crystal Polymer Homeotropic Films from Reactive Mesogens. Int. J. Mol. Sci. 2013, 14, 21319-21327.
