Sensors, Volume 17, Issue 8 (August 2017)

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Cover Story The Biomedical REAl-Time Health Evaluation (BREATHE) platform for real-time secure data [...] Read more.
View options order results:
result details:
Displaying articles 1-223
Export citation of selected articles as:

Editorial

Jump to: Research, Review, Other

Open AccessEditorial Recent Advancements towards Full-System Microfluidics
Sensors 2017, 17(8), 1707; doi:10.3390/s17081707
Received: 18 July 2017 / Revised: 22 July 2017 / Accepted: 22 July 2017 / Published: 25 July 2017
PDF Full-text (203 KB) | HTML Full-text | XML Full-text
Abstract
Microfluidics is quickly becoming a key technology in an expanding range of fields, such as medical sciences, biosensing, bioactuation, chemical synthesis, and more. This is helping its transformation from a promising R&D tool to commercially viable technology. Fuelling this expansion is the intensified
[...] Read more.
Microfluidics is quickly becoming a key technology in an expanding range of fields, such as medical sciences, biosensing, bioactuation, chemical synthesis, and more. This is helping its transformation from a promising R&D tool to commercially viable technology. Fuelling this expansion is the intensified focus on automation and enhanced functionality through integration of complex electrical control, mechanical properties, in situ sensing and flow control. Here we highlight recent contributions to the Sensors Special Issue series called “Microfluidics-Based Microsystem Integration Research” under the following categories: (i) Device fabrication to support complex functionality; (ii) New methods for flow control and mixing; (iii) Towards routine analysis and point of care applications; (iv) In situ characterization; and (v) Plug and play microfluidics. Full article
(This article belongs to the Special Issue Microfluidics-Based Microsystem Integration Research)
Open AccessEditorial Trusted and Secure Wireless Sensor Network Designs and Deployments
Sensors 2017, 17(8), 1787; doi:10.3390/s17081787
Received: 28 July 2017 / Revised: 2 August 2017 / Accepted: 2 August 2017 / Published: 4 August 2017
PDF Full-text (189 KB) | HTML Full-text | XML Full-text
(This article belongs to the Special Issue Trusted and Secure Wireless Sensor Network Designs and Deployments)

Research

Jump to: Editorial, Review, Other

Open AccessArticle An Automatic Multi-Target Independent Analysis Framework for Non-Planar Infrared-Visible Registration
Sensors 2017, 17(8), 1696; doi:10.3390/s17081696
Received: 12 June 2017 / Revised: 11 July 2017 / Accepted: 21 July 2017 / Published: 26 July 2017
PDF Full-text (3779 KB) | HTML Full-text | XML Full-text
Abstract
In this paper, we propose a novel automatic multi-target registration framework for non-planar infrared-visible videos. Previous approaches usually analyzed multiple targets together and then estimated a global homography for the whole scene, however, these cannot achieve precise multi-target registration when the scenes are
[...] Read more.
In this paper, we propose a novel automatic multi-target registration framework for non-planar infrared-visible videos. Previous approaches usually analyzed multiple targets together and then estimated a global homography for the whole scene, however, these cannot achieve precise multi-target registration when the scenes are non-planar. Our framework is devoted to solving the problem using feature matching and multi-target tracking. The key idea is to analyze and register each target independently. We present a fast and robust feature matching strategy, where only the features on the corresponding foreground pairs are matched. Besides, new reservoirs based on the Gaussian criterion are created for all targets, and a multi-target tracking method is adopted to determine the relationships between the reservoirs and foreground blobs. With the matches in the corresponding reservoir, the homography of each target is computed according to its moving state. We tested our framework on both public near-planar and non-planar datasets. The results demonstrate that the proposed framework outperforms the state-of-the-art global registration method and the manual global registration matrix in all tested datasets. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle A Novel Dual Separate Paths (DSP) Algorithm Providing Fault-Tolerant Communication for Wireless Sensor Networks
Sensors 2017, 17(8), 1699; doi:10.3390/s17081699
Received: 28 June 2017 / Revised: 20 July 2017 / Accepted: 21 July 2017 / Published: 25 July 2017
PDF Full-text (6721 KB) | HTML Full-text | XML Full-text
Abstract
Fault tolerance has long been a major concern for sensor communications in fault-tolerant cyber physical systems (CPSs). Network failure problems often occur in wireless sensor networks (WSNs) due to various factors such as the insufficient power of sensor nodes, the dislocation of sensor
[...] Read more.
Fault tolerance has long been a major concern for sensor communications in fault-tolerant cyber physical systems (CPSs). Network failure problems often occur in wireless sensor networks (WSNs) due to various factors such as the insufficient power of sensor nodes, the dislocation of sensor nodes, the unstable state of wireless links, and unpredictable environmental interference. Fault tolerance is thus one of the key requirements for data communications in WSN applications. This paper proposes a novel path redundancy-based algorithm, called dual separate paths (DSP), that provides fault-tolerant communication with the improvement of the network traffic performance for WSN applications, such as fault-tolerant CPSs. The proposed DSP algorithm establishes two separate paths between a source and a destination in a network based on the network topology information. These paths are node-disjoint paths and have optimal path distances. Unicast frames are delivered from the source to the destination in the network through the dual paths, providing fault-tolerant communication and reducing redundant unicast traffic for the network. The DSP algorithm can be applied to wired and wireless networks, such as WSNs, to provide seamless fault-tolerant communication for mission-critical and life-critical applications such as fault-tolerant CPSs. The analyzed and simulated results show that the DSP-based approach not only provides fault-tolerant communication, but also improves network traffic performance. For the case study in this paper, when the DSP algorithm was applied to high-availability seamless redundancy (HSR) networks, the proposed DSP-based approach reduced the network traffic by 80% to 88% compared with the standard HSR protocol, thus improving network traffic performance. Full article
Figures

Figure 1

Open AccessArticle High-Temporal-Resolution High-Spatial-Resolution Spaceborne SAR Based on Continuously Varying PRF
Sensors 2017, 17(8), 1700; doi:10.3390/s17081700
Received: 18 May 2017 / Revised: 7 July 2017 / Accepted: 21 July 2017 / Published: 25 July 2017
PDF Full-text (7105 KB) | HTML Full-text | XML Full-text
Abstract
Synthetic Aperture Radar (SAR) is a well-established and powerful imaging technique for acquiring high-spatial-resolution images of the Earth’s surface. With the development of beam steering techniques, sliding spotlight and staring spotlight modes have been employed to support high-spatial-resolution applications. In addition to this
[...] Read more.
Synthetic Aperture Radar (SAR) is a well-established and powerful imaging technique for acquiring high-spatial-resolution images of the Earth’s surface. With the development of beam steering techniques, sliding spotlight and staring spotlight modes have been employed to support high-spatial-resolution applications. In addition to this strengthened high-spatial-resolution and wide-swath capability, high-temporal-resolution (short repeat-observation interval) represents a key capability for numerous applications. However, conventional SAR systems are limited in that the same patch can only be illuminated for several seconds within a single pass. This paper considers a novel high-squint-angle system intended to acquire high-spatial-resolution spaceborne SAR images with repeat-observation intervals varying from tens of seconds to several minutes within a single pass. However, an exponentially increased range cell migration would arise and lead to a conflict between the receive window and ‘blind ranges’. An efficient data acquisition technique for high-temporal-resolution, high-spatial-resolution and high-squint-angle spaceborne SAR, in which the pulse repetition frequency (PRF) is continuously varied according to the changing slant range, is presented in this paper. This technique allows echo data to remain in the receive window instead of conflicting with the transmitted pulse or nadir echo. Considering the precision of hardware, a compromise and practical strategy is also proposed. Furthermore, a detailed performance analysis of range ambiguities is provided with respect to parameters of TerraSAR-X. For strong point-like targets, the range ambiguity of this technique would be better than that of uniform PRF technique. For this innovative technique, a resampling strategy and modified imaging algorithm have been developed to handle the non-uniformly sampled echo data. Simulations are performed to validate the efficiency of the proposed technique and the associated imaging algorithm. Full article
(This article belongs to the Section Remote Sensors)
Figures

Figure 1

Open AccessArticle In-Network Computation of the Optimal Weighting Matrix for Distributed Consensus on Wireless Sensor Networks
Sensors 2017, 17(8), 1702; doi:10.3390/s17081702
Received: 17 May 2017 / Revised: 3 July 2017 / Accepted: 21 July 2017 / Published: 25 July 2017
PDF Full-text (827 KB) | HTML Full-text | XML Full-text
Abstract
In a network, a distributed consensus algorithm is fully characterized by its weighting matrix. Although there exist numerical methods for obtaining the optimal weighting matrix, we have not found an in-network implementation of any of these methods that works for all network topologies.
[...] Read more.
In a network, a distributed consensus algorithm is fully characterized by its weighting matrix. Although there exist numerical methods for obtaining the optimal weighting matrix, we have not found an in-network implementation of any of these methods that works for all network topologies. In this paper, we propose an in-network algorithm for finding such an optimal weighting matrix. Full article
(This article belongs to the Special Issue Cognitive Radio Sensing and Sensor Networks)
Figures

Figure 1

Open AccessArticle Detection of Pseudomonas aeruginosa Metabolite Pyocyanin in Water and Saliva by Employing the SERS Technique
Sensors 2017, 17(8), 1704; doi:10.3390/s17081704
Received: 13 June 2017 / Revised: 19 July 2017 / Accepted: 20 July 2017 / Published: 25 July 2017
PDF Full-text (2735 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Pyocyanin (PYO) is a metabolite specific for Pseudomonas aeruginosa. In the case of immunocompromised patients, it is currently considered a biomarker for life-threating Pseudomonas infections. In the frame of this study it is shown, that PYO can be detected in aqueous solution
[...] Read more.
Pyocyanin (PYO) is a metabolite specific for Pseudomonas aeruginosa. In the case of immunocompromised patients, it is currently considered a biomarker for life-threating Pseudomonas infections. In the frame of this study it is shown, that PYO can be detected in aqueous solution by employing surface-enhanced Raman spectroscopy (SERS) combined with a microfluidic platform. The achieved limit of detection is 0.5 μM. This is ~2 orders of magnitude below the concentration of PYO found in clinical samples. Furthermore, as proof of principle, the SERS detection of PYO in the saliva of three volunteers was also investigated. This body fluid can be collected in a non-invasive manner and is highly chemically complex, making the detection of the target molecule challenging. Nevertheless, PYO was successfully detected in two saliva samples down to 10 μM and in one sample at a concentration of 25 μM. This indicates that the molecules present in saliva do not inhibit the efficient adsorption of PYO on the surface of the employed SERS active substrates. Full article
(This article belongs to the Special Issue Applications of Raman Spectroscopy in Biosensors)
Figures

Figure 1

Open AccessArticle Preliminary Assessment of Wind and Wave Retrieval from Chinese Gaofen-3 SAR Imagery
Sensors 2017, 17(8), 1705; doi:10.3390/s17081705
Received: 30 May 2017 / Revised: 13 July 2017 / Accepted: 18 July 2017 / Published: 25 July 2017
PDF Full-text (3978 KB) | HTML Full-text | XML Full-text
Abstract
The Chinese Gaofen-3 (GF-3) synthetic aperture radar (SAR) launched by the China Academy of Space Technology (CAST) has operated at C-band since September 2016. To date, we have collected 16/42 images in vertical-vertical (VV)/horizontal-horizontal (HH) polarization, covering the National Data Buoy Center (NDBC)
[...] Read more.
The Chinese Gaofen-3 (GF-3) synthetic aperture radar (SAR) launched by the China Academy of Space Technology (CAST) has operated at C-band since September 2016. To date, we have collected 16/42 images in vertical-vertical (VV)/horizontal-horizontal (HH) polarization, covering the National Data Buoy Center (NDBC) buoy measurements of the National Oceanic and Atmospheric Administration (NOAA) around U.S. western coastal waters. Wind speeds from NDBC in situ buoys are up to 15 m/s and buoy-measured significant wave height (SWH) has ranged from 0.5 m to 3 m. In this study, winds were retrieved using the geophysical model function (GMF) together with the polarization ratio (PR) model and waves were retrieved using a new empirical algorithm based on SAR cutoff wavelength in satellite flight direction, herein called CSAR_WAVE. Validation against buoy measurements shows a 1.4/1.9 m/s root mean square error (RMSE) of wind speed and a 24/23% scatter index (SI) of SWH for VV/HH polarization. In addition, wind and wave retrieval results from 166 GF-3 images were compared with the European Centre for Medium-Range Weather Forecasts (ECMWF) re-analysis winds, as well as the SWH from the WaveWatch-III model, respectively. Comparisons show a 2.0 m/s RMSE for wind speed with a 36% SI of SWH for VV-polarization and a 2.2 m/s RMSE for wind speed with a 37% SI of SWH for HH-polarization. Our work gives a preliminary assessment of the wind and wave retrieval results from GF-3 SAR images for the first time and will provide guidance for marine applications of GF-3 SAR. Full article
(This article belongs to the Special Issue First Experiences with Chinese Gaofen-3 SAR Sensor)
Figures

Figure 1

Open AccessArticle Grading of Chinese Cantonese Sausage Using Hyperspectral Imaging Combined with Chemometric Methods
Sensors 2017, 17(8), 1706; doi:10.3390/s17081706
Received: 9 June 2017 / Revised: 20 July 2017 / Accepted: 24 July 2017 / Published: 25 July 2017
PDF Full-text (3758 KB) | HTML Full-text | XML Full-text
Abstract
Fast and accurate grading of Chinese Cantonese sausage is an important concern for customers, organizations, and the industry. Hyperspectral imaging in the spectral range of 874–1734 nm, combined with chemometric methods, was applied to grade Chinese Cantonese sausage. Three grades of intact and
[...] Read more.
Fast and accurate grading of Chinese Cantonese sausage is an important concern for customers, organizations, and the industry. Hyperspectral imaging in the spectral range of 874–1734 nm, combined with chemometric methods, was applied to grade Chinese Cantonese sausage. Three grades of intact and sliced Cantonese sausages were studied, including the top, first, and second grades. Support vector machine (SVM) and random forests (RF) techniques were used to build two different models. Second derivative spectra and RF were applied to select optimal wavelengths. The optimal wavelengths were the same for intact and sliced sausages when selected from second derivative spectra, while the optimal wavelengths for intact and sliced sausages selected using RF were quite similar. The SVM and RF models, using full spectra and the optimal wavelengths, obtained acceptable results for intact and sliced sausages. Both models for intact sausages performed better than those for sliced sausages, with a classification accuracy of the calibration and prediction set of over 90%. The overall results indicated that hyperspectral imaging combined with chemometric methods could be used to grade Chinese Cantonese sausages, with intact sausages being better suited for grading. This study will help to develop fast and accurate online grading of Cantonese sausages, as well as other sausages. Full article
(This article belongs to the Special Issue Analysis of Multispectral and Hyperspectral Data)
Figures

Figure 1

Open AccessArticle Miniaturisation of Pressure-Sensitive Paint Measurement Systems Using Low-Cost, Miniaturised Machine Vision Cameras
Sensors 2017, 17(8), 1708; doi:10.3390/s17081708
Received: 10 June 2017 / Revised: 10 July 2017 / Accepted: 20 July 2017 / Published: 25 July 2017
PDF Full-text (11569 KB) | HTML Full-text | XML Full-text
Abstract
Measurements of pressure-sensitive paint (PSP) have been performed using new or non-scientific imaging technology based on machine vision tools. Machine vision camera systems are typically used for automated inspection or process monitoring. Such devices offer the benefits of lower cost and reduced size
[...] Read more.
Measurements of pressure-sensitive paint (PSP) have been performed using new or non-scientific imaging technology based on machine vision tools. Machine vision camera systems are typically used for automated inspection or process monitoring. Such devices offer the benefits of lower cost and reduced size compared with typically scientific-grade cameras; however, their optical qualities and suitability have yet to be determined. This research intends to show relevant imaging characteristics and also show the applicability of such imaging technology for PSP. Details of camera performance are benchmarked and compared to standard scientific imaging equipment and subsequent PSP tests are conducted using a static calibration chamber. The findings demonstrate that machine vision technology can be used for PSP measurements, opening up the possibility of performing measurements on-board small-scale model such as those used for wind tunnel testing or measurements in confined spaces with limited optical access. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle Unambiguous Imaging of Static Scenes and Moving Targets with the First Chinese Dual-Channel Spaceborne SAR Sensor
Sensors 2017, 17(8), 1709; doi:10.3390/s17081709
Received: 17 June 2017 / Revised: 19 July 2017 / Accepted: 21 July 2017 / Published: 25 July 2017
PDF Full-text (6027 KB) | HTML Full-text | XML Full-text
Abstract
Multichannel synthetic aperture radar (SAR) is a breakthrough given the inherent limitation between high-resolution and wide-swath (HRWS) faced with conventional SAR. This paper aims to obtain unambiguous imaging of static scenes and moving targets with the first Chinese dual-channel spaceborne SAR sensor. We
[...] Read more.
Multichannel synthetic aperture radar (SAR) is a breakthrough given the inherent limitation between high-resolution and wide-swath (HRWS) faced with conventional SAR. This paper aims to obtain unambiguous imaging of static scenes and moving targets with the first Chinese dual-channel spaceborne SAR sensor. We propose an integrated imaging scheme with the dual-channel echoes. In the imaging scheme, the subspace-based error estimation algorithm is first applied to the spaceborne multichannel SAR system, followed by the reconstruction algorithm prior to imaging. The motion-adapted reconstruction algorithm for moving target imaging is initially achieved with the spaceborne multichannel SAR system. The results exhibit an effective suppression of azimuth ambiguities and false targets with the proposed process. This paper verifies the accuracy of the subspace-based channel error estimator and the feasibility of the motion-adapted reconstruction algorithm. The proposed imaging process has prospects for future HRWS SAR systems with more channels. Full article
(This article belongs to the Special Issue First Experiences with Chinese Gaofen-3 SAR Sensor)
Figures

Figure 1a

Open AccessArticle New Matching Method for Accelerometers in Gravity Gradiometer
Sensors 2017, 17(8), 1710; doi:10.3390/s17081710
Received: 11 June 2017 / Revised: 15 July 2017 / Accepted: 21 July 2017 / Published: 25 July 2017
PDF Full-text (4235 KB) | HTML Full-text | XML Full-text
Abstract
The gravity gradiometer is widely used in mineral prospecting, including in the exploration of mineral, oil and gas deposits. The mismatch of accelerometers adversely affects the measuring precision of rotating accelerometer-based gravity gradiometers. Several strategies have been investigated to address the imbalance of
[...] Read more.
The gravity gradiometer is widely used in mineral prospecting, including in the exploration of mineral, oil and gas deposits. The mismatch of accelerometers adversely affects the measuring precision of rotating accelerometer-based gravity gradiometers. Several strategies have been investigated to address the imbalance of accelerometers in gradiometers. These strategies, however, complicate gradiometer structures because feedback loops and re-designed accelerometers are needed in these strategies. In this paper, we present a novel matching method, which is based on a new configuration of accelerometers in a gravity gradiometer. In the new configuration, an angle was introduced between the measurement direction of the accelerometer and the spin direction. With the introduced angle, accelerometers could measure the centrifugal acceleration generated by the rotating disc. Matching was realized by updating the scale factors of the accelerometers with the help of centrifugal acceleration. Further simulation computations showed that after adopting the new matching method, signal-to-noise ratio improved from −41 dB to 22 dB. Compared with other matching methods, our method is more flexible and costs less. The matching accuracy of this new method is similar to that of other methods. Our method provides a new idea for matching methods in gravity gradiometer measurement. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle Complexation-Based Detection of Nickel(II) at a Graphene-Chelate Probe in the Presence of Cobalt and Zinc by Adsorptive Stripping Voltammetry
Sensors 2017, 17(8), 1711; doi:10.3390/s17081711
Received: 14 June 2017 / Revised: 1 July 2017 / Accepted: 3 July 2017 / Published: 25 July 2017
PDF Full-text (7823 KB) | HTML Full-text | XML Full-text
Abstract
The adsorptive stripping voltammetric detection of nickel and cobalt in water samples at metal film electrodes has been extensively studied. In this work, a novel, environmentally friendly, metal-free electrochemical probe was constructed for the ultra-trace determination of Ni2+ in water samples by
[...] Read more.
The adsorptive stripping voltammetric detection of nickel and cobalt in water samples at metal film electrodes has been extensively studied. In this work, a novel, environmentally friendly, metal-free electrochemical probe was constructed for the ultra-trace determination of Ni2+ in water samples by Adsorptive Cathodic Stripping Voltammetry (AdCSV). The electrochemical platform is based on the adsorptive accumulation of Ni2+ ions directly onto a glassy carbon electrode (GCE) modified with dimethylglyoxime (DMG) as chelating agent and a Nafion-graphene (NGr) nanocomposite to enhance electrode sensitivity. The nafion-graphene dimethylglyoxime modified glassy carbon electrode (NGr-DMG-GCE) shows superior detection capabilities as a result of the improved surface-area-to-volume ratio and enhanced electron transfer kinetics following the incorporation of single layer graphene, while limiting the toxic effects of the sensor by removal of the more common mercury, bismuth and lead films. Furthermore, for the first time the NGr-DMG-GCE, in the presence of common interfering metal ions of Co2+ and Zn2+ demonstrates good selectivity and preferential binding towards the detection of Ni2+ in water samples. Structural and morphological characterisation of the synthesised single layer graphene sheets was conducted by Raman spectrometry, HRTEM and HRSEM analysis. The instrumental parameters associated with the electrochemical response, including accumulation potential and accumulation time were investigated and optimised in addition to the influence of DMG and graphene concentrations. The NGr-DMG-GCE demonstrated well resolved, reproducible peaks, with RSD (%) below 5% and a detection limit of 1.5 µg L−1 for Ni2+ reduction at an accumulation time of 120 s., the prepared electrochemical sensor exhibited good detection and quantitation towards Ni2+ detection in tap water samples, well below 0.1 mg L−1 set by the WHO and EPA standards. This comparable to the South African drinking water guidelines of 0.15 mg L−1. Full article
(This article belongs to the Section Chemical Sensors)
Figures

Open AccessArticle Analysis of the Optimum Gain of a High-Pass L-Matching Network for Rectennas
Sensors 2017, 17(8), 1712; doi:10.3390/s17081712
Received: 8 April 2017 / Revised: 29 June 2017 / Accepted: 21 July 2017 / Published: 25 July 2017
PDF Full-text (3090 KB) | HTML Full-text | XML Full-text
Abstract
Rectennas, which mainly consist of an antenna, matching network, and rectifier, are used to harvest radiofrequency energy in order to power tiny sensor nodes, e.g., the nodes of the Internet of Things. This paper demonstrates for the first time, the existence of an
[...] Read more.
Rectennas, which mainly consist of an antenna, matching network, and rectifier, are used to harvest radiofrequency energy in order to power tiny sensor nodes, e.g., the nodes of the Internet of Things. This paper demonstrates for the first time, the existence of an optimum voltage gain for high-pass L-matching networks used in rectennas by deriving an analytical expression. The optimum gain is that which leads to maximum power efficiency of the rectenna. Here, apart from the L-matching network, a Schottky single-diode rectifier was used for the rectenna, which was optimized at 868 MHz for a power range from −30 dBm to −10 dBm. As the theoretical expression depends on parameters not very well-known a priori, an accurate search of the optimum gain for each power level was performed via simulations. Experimental results show remarkable power efficiencies ranging from 16% at −30 dBm to 55% at −10 dBm, which are for almost all the tested power levels the highest published in the literature for similar designs. Full article
(This article belongs to the Special Issue Autonomous Sensors)
Figures

Figure 1

Open AccessArticle Parameterized Pseudo-Localization for Accurate and Efficient Moving Targets Imaging in Synthetic Aperture Radar
Sensors 2017, 17(8), 1714; doi:10.3390/s17081714
Received: 7 June 2017 / Revised: 10 July 2017 / Accepted: 19 July 2017 / Published: 26 July 2017
PDF Full-text (1855 KB) | HTML Full-text | XML Full-text
Abstract
Accurate and efficient moving target imaging is an important challenge for targets recognition in current synthetic aperture radar (SAR) combined with a ground moving target indication (GMTI) system. As the key but unknown parameter, the Doppler rates are estimated conventionally by searching any
[...] Read more.
Accurate and efficient moving target imaging is an important challenge for targets recognition in current synthetic aperture radar (SAR) combined with a ground moving target indication (GMTI) system. As the key but unknown parameter, the Doppler rates are estimated conventionally by searching any possible values for moving targets imaging. However, this conventional estimation method suffers from low accuracy or low efficiency due to the searching procedure. Focusing on these, we present a method to efficiently image the moving targets without the Doppler rate by Doppler delayed interferometry, and the imaged localization, which is parameterized pseudo-localization, is used to estimate the Doppler rate. In order to improve the estimation accuracy, an improved method based on the Newton method of approximation is proposed by exploiting the unused amplitude information. Compared with the conventional methods, the proposed improved method capable of high accuracy and low computation complexity simultaneously can meet the accurate and efficient requirements in the practical applications. Comparison simulations and real data processing results demonstrate the effectiveness of the proposed methods. Full article
(This article belongs to the Section Remote Sensors)
Figures

Figure 1

Open AccessArticle Pulsed Polarization-Based NOx Sensors of YSZ Films Produced by the Aerosol Deposition Method and by Screen-Printing
Sensors 2017, 17(8), 1715; doi:10.3390/s17081715
Received: 3 July 2017 / Revised: 20 July 2017 / Accepted: 22 July 2017 / Published: 26 July 2017
PDF Full-text (7496 KB) | HTML Full-text | XML Full-text
Abstract
The pulsed polarization technique on solid electrolytes is based on alternating potential pulses interrupted by self-discharge pauses. Since even small concentrations of nitrogen oxides (NOx) in the ppm range significantly change the polarization and discharge behavior, pulsed polarization sensors are well
[...] Read more.
The pulsed polarization technique on solid electrolytes is based on alternating potential pulses interrupted by self-discharge pauses. Since even small concentrations of nitrogen oxides (NOx) in the ppm range significantly change the polarization and discharge behavior, pulsed polarization sensors are well suited to measure low amounts of NOx. In contrast to all previous investigations, planar pulsed polarization sensors were built using an electrolyte thick film and platinum interdigital electrodes on alumina substrates. Two different sensor layouts were investigated, the first with buried Pt electrodes under the electrolyte and the second one with conventional overlying Pt electrodes. Electrolyte thick films were either formed by aerosol deposition or by screen-printing, therefore exhibiting a dense or porous microstructure, respectively. For screen-printed electrolytes, the influence of the electrolyte resistance on the NOx sensing ability was investigated as well. Sensors with buried electrodes showed little to no response even at higher NOx concentrations, in good agreement with the intended sensor mechanism. Electrolyte films with overlying electrodes, however, allowed the quantitative detection of NOx. In particular, aerosol deposited electrolytes exhibited high sensitivities with a sensor output signal ΔU of 50 mV and 75 mV for 3 ppm of NO and NO2, respectively. For screen-printed electrolytes, a clear trend indicated a decrease in sensitivity with increased electrolyte resistance. Full article
(This article belongs to the Section Chemical Sensors)
Figures

Figure 1

Open AccessArticle A Disposable Amperometric Sensor Based on High-Performance PEDOT:PSS/Ionic Liquid Nanocomposite Thin Film-Modified Screen-Printed Electrode for the Analysis of Catechol in Natural Water Samples
Sensors 2017, 17(8), 1716; doi:10.3390/s17081716
Received: 8 June 2017 / Revised: 12 July 2017 / Accepted: 13 July 2017 / Published: 26 July 2017
PDF Full-text (2459 KB) | HTML Full-text | XML Full-text
Abstract
A conducting polymer-based composite material of poly(3,4-ethylenedioxythiophene) (PEDOT): poly(4-styrenesulfonate) (PSS) doped with different percentages of a room temperature ionic liquid (IL), 1-ethyl-3-methylimidazolium tetrafluoroborate ([EMIM][BF4]), was prepared and a very small amount of the composite (2.0 µL) was drop-coated on the working
[...] Read more.
A conducting polymer-based composite material of poly(3,4-ethylenedioxythiophene) (PEDOT): poly(4-styrenesulfonate) (PSS) doped with different percentages of a room temperature ionic liquid (IL), 1-ethyl-3-methylimidazolium tetrafluoroborate ([EMIM][BF4]), was prepared and a very small amount of the composite (2.0 µL) was drop-coated on the working area of a screen-printed carbon electrode (SPCE). The SPCE, modified with PEDOT:PSS/IL composite thin-film, was characterized by cyclic voltammetry (CV), electrochemical impedance spectroscopy (EIS), scanning electron microscopy (SEM), profilometry and sessile contact angle measurements. The prepared PEDOT:PSS/IL composite thin-film exhibited a nano-porous microstructure and was found to be highly stable and conductive with enhanced electrocatalytic properties towards catechol, a priority pollutant. The linear working range for catechol was found to be 0.1 µM–330.0 µM with a sensitivity of 18.2 mA·mM·cm−2 and a calculated limit of detection (based on 3× the baseline noise) of 23.7 µM. When the PEDOT:PSS/IL/SPCE sensor was used in conjunction with amperometry in stirred solution for the analysis of natural water samples, the precision values obtained on spiked samples (20.0 µM catechol added) (n = 3) were 0.18% and 0.32%, respectively, with recovery values that were well over 99.0%. Full article
(This article belongs to the Special Issue Screen-Printed Electrodes)
Figures

Figure 1

Open AccessArticle Exploiting Concurrent Wake-Up Transmissions Using Beat Frequencies
Sensors 2017, 17(8), 1717; doi:10.3390/s17081717
Received: 20 April 2017 / Revised: 12 July 2017 / Accepted: 18 July 2017 / Published: 26 July 2017
PDF Full-text (2001 KB) | HTML Full-text | XML Full-text
Abstract
Wake-up receivers are the natural choice for wireless sensor networks because of their ultra-low power consumption and their ability to provide communications on demand. A downside of ultra-low power wake-up receivers is their low sensitivity caused by the passive demodulation of the carrier
[...] Read more.
Wake-up receivers are the natural choice for wireless sensor networks because of their ultra-low power consumption and their ability to provide communications on demand. A downside of ultra-low power wake-up receivers is their low sensitivity caused by the passive demodulation of the carrier signal. In this article, we present a novel communication scheme by exploiting purposefully-interfering out-of-tune signals of two or more wireless sensor nodes, which produce the wake-up signal as the beat frequency of superposed carriers. Additionally, we introduce a communication algorithm and a flooding protocol based on this approach. Our experiments show that our approach increases the received signal strength up to 3 dB, improving communication robustness and reliability. Furthermore, we demonstrate the feasibility of our newly-developed protocols by means of an outdoor experiment and an indoor setup consisting of several nodes. The flooding algorithm achieves almost a 100% wake-up rate in less than 20 ms. Full article
(This article belongs to the Section Sensor Networks)
Figures

Figure 1

Open AccessArticle Effects of Ambient Temperature and Relative Humidity on Subsurface Defect Detection in Concrete Structures by Active Thermal Imaging
Sensors 2017, 17(8), 1718; doi:10.3390/s17081718
Received: 27 June 2017 / Revised: 18 July 2017 / Accepted: 25 July 2017 / Published: 26 July 2017
PDF Full-text (9542 KB) | HTML Full-text | XML Full-text
Abstract
Active thermal imaging is an effective nondestructive technique in the structural health monitoring field, especially for concrete structures not exposed directly to the sun. However, the impact of meteorological factors on the testing results is considerable and should be studied in detail. In
[...] Read more.
Active thermal imaging is an effective nondestructive technique in the structural health monitoring field, especially for concrete structures not exposed directly to the sun. However, the impact of meteorological factors on the testing results is considerable and should be studied in detail. In this study, the impulse thermography technique with halogen lamps heat sources is used to detect defects in concrete structural components that are not exposed directly to sunlight and not significantly affected by the wind, such as interior bridge box-girders and buildings. To consider the effect of environment, ambient temperature and relative humidity, these factors are investigated in twelve cases of testing on a concrete slab in the laboratory, to minimize the influence of wind. The results showed that the absolute contrast between the defective and sound areas becomes more apparent with an increase of ambient temperature, and it increases at a faster rate with large and shallow delaminations than small and deep delaminations. In addition, the absolute contrast of delamination near the surface might be greater under a highly humid atmosphere. This study indicated that the results obtained from the active thermography technique will be more apparent if the inspection is conducted on a day with high ambient temperature and humidity. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle Multi-Robot Interfaces and Operator Situational Awareness: Study of the Impact of Immersion and Prediction
Sensors 2017, 17(8), 1720; doi:10.3390/s17081720
Received: 31 May 2017 / Revised: 18 July 2017 / Accepted: 19 July 2017 / Published: 27 July 2017
PDF Full-text (9579 KB) | HTML Full-text | XML Full-text
Abstract
Multi-robot missions are a challenge for operators in terms of workload and situational awareness. These operators have to receive data from the robots, extract information, understand the situation properly, make decisions, generate the adequate commands, and send them to the robots. The consequences
[...] Read more.
Multi-robot missions are a challenge for operators in terms of workload and situational awareness. These operators have to receive data from the robots, extract information, understand the situation properly, make decisions, generate the adequate commands, and send them to the robots. The consequences of excessive workload and lack of awareness can vary from inefficiencies to accidents. This work focuses on the study of future operator interfaces of multi-robot systems, taking into account relevant issues such as multimodal interactions, immersive devices, predictive capabilities and adaptive displays. Specifically, four interfaces have been designed and developed: a conventional, a predictive conventional, a virtual reality and a predictive virtual reality interface. The four interfaces have been validated by the performance of twenty-four operators that supervised eight multi-robot missions of fire surveillance and extinguishing. The results of the workload and situational awareness tests show that virtual reality improves the situational awareness without increasing the workload of operators, whereas the effects of predictive components are not significant and depend on their implementation. Full article
(This article belongs to the Special Issue Context Aware Environments and Applications)
Figures

Figure 1

Open AccessArticle Seamline Determination Based on PKGC Segmentation for Remote Sensing Image Mosaicking
Sensors 2017, 17(8), 1721; doi:10.3390/s17081721
Received: 12 June 2017 / Revised: 14 July 2017 / Accepted: 24 July 2017 / Published: 27 July 2017
PDF Full-text (19035 KB) | HTML Full-text | XML Full-text
Abstract
This paper presents a novel method of seamline determination for remote sensing image mosaicking. A two-level optimization strategy is applied to determine the seamline. Object-level optimization is executed firstly. Background regions (BRs) and obvious regions (ORs) are extracted based on the results of
[...] Read more.
This paper presents a novel method of seamline determination for remote sensing image mosaicking. A two-level optimization strategy is applied to determine the seamline. Object-level optimization is executed firstly. Background regions (BRs) and obvious regions (ORs) are extracted based on the results of parametric kernel graph cuts (PKGC) segmentation. The global cost map which consists of color difference, a multi-scale morphological gradient (MSMG) constraint, and texture difference is weighted by BRs. Finally, the seamline is determined in the weighted cost from the start point to the end point. Dijkstra’s shortest path algorithm is adopted for pixel-level optimization to determine the positions of seamline. Meanwhile, a new seamline optimization strategy is proposed for image mosaicking with multi-image overlapping regions. The experimental results show the better performance than the conventional method based on mean-shift segmentation. Seamlines based on the proposed method bypass the obvious objects and take less time in execution. This new method is efficient and superior for seamline determination in remote sensing image mosaicking. Full article
(This article belongs to the Special Issue UAV or Drones for Remote Sensing Applications)
Figures

Figure 1

Open AccessArticle Establishment of a Site-Specific Tropospheric Model Based on Ground Meteorological Parameters over the China Region
Sensors 2017, 17(8), 1722; doi:10.3390/s17081722
Received: 11 May 2017 / Revised: 24 July 2017 / Accepted: 25 July 2017 / Published: 27 July 2017
PDF Full-text (2883 KB) | HTML Full-text | XML Full-text
Abstract
China is a country of vast territory with complicated geographical environment and climate conditions. With the rapid progress of the Chinese BeiDou satellite navigation system (BDS); more accurate tropospheric models must be applied to improve the accuracy of navigation and positioning. Based on
[...] Read more.
China is a country of vast territory with complicated geographical environment and climate conditions. With the rapid progress of the Chinese BeiDou satellite navigation system (BDS); more accurate tropospheric models must be applied to improve the accuracy of navigation and positioning. Based on the formula of the Saastamoinen and Callahan models; this study develops two single-site tropospheric models (named SAAS_S and CH_S models) for the Chinese region using radiosonde data from 2005 to 2012. We assess the two single-site tropospheric models with radiosonde data for 2013 and zenith tropospheric delay (ZTD) data from four International GNSS Service (IGS) stations and compare them to the results of the Saastamoinen and Callahan models. The experimental results show that: the mean accuracy of the SAAS_S model (bias: 0.19 cm; RMS: 3.19 cm) at all radiosonde stations is superior to those of the Saastamoinen (bias: 0.62 cm; RMS: 3.62 cm) and CH_S (bias: −0.05 cm; RMS: 3.38 cm) models. In most Chinese regions; the RMS values of the SAAS_S and CH_S models are about 0.51~2.12 cm smaller than those of their corresponding source models. The SAAS_S model exhibits a clear improvement in the accuracy over the Saastamoinen model in low latitude regions. When the SAAS_S model is replaced by the SAAS model in the positioning of GNSS; the mean accuracy of vertical direction in the China region can be improved by 1.12~1.55 cm and the accuracy of vertical direction in low latitude areas can be improved by 1.33~7.63 cm. The residuals of the SAAS_S model are closer to a normal distribution compared to those of the Saastamoinen model. Single-site tropospheric models based on the short period of the most recent data (for example 2 years) can also achieve a satisfactory accuracy. The average performance of the SAAS_S model (bias: 0.83 cm; RMS: 3.24 cm) at four IGS stations is superior to that of the Saastamoinen (bias: −0.86 cm; RMS: 3.59 cm) and CH_S (bias: 0.45 cm; RMS: 3.38 cm) models. Full article
Figures

Figure 1

Open AccessArticle Optimization of Detection Accuracy of Closed-Loop Optical Voltage Sensors Based on Pockels Effect
Sensors 2017, 17(8), 1723; doi:10.3390/s17081723
Received: 19 May 2017 / Revised: 19 July 2017 / Accepted: 25 July 2017 / Published: 27 July 2017
PDF Full-text (3396 KB) | HTML Full-text | XML Full-text
Abstract
The influence of optical parameters on the performance of closed-loop optical voltage sensors (OVSs) based on Pockels effect is analyzed and a control algorithm is proposed to suppress the nonlinearity caused by the unideal parameters of optical devices for optimizing the detection precision
[...] Read more.
The influence of optical parameters on the performance of closed-loop optical voltage sensors (OVSs) based on Pockels effect is analyzed and a control algorithm is proposed to suppress the nonlinearity caused by the unideal parameters of optical devices for optimizing the detection precision of OVSs. First, a quantified model of the feedback phase demonstrates how the optical parameters of optical devices (including light source, polarizer, 45° fusion point, Faraday rotator and half-wave plate) result in the nonlinearity of closed-loop OVSs. Then, the parameter indexes of different optical devices are put forward to instruct the manufacturing process of the optical system. Furthermore, a closed-loop control algorithm is investigated to improve the measurement accuracy of nonlinear OVSs considering the unideal parameters. The experiment results indicate that additional bias caused by undesirable optical parameters is obviously decreased so that the measurement accuracy of OVSs satisfies the demand of IEC60044-3 for 0.1 level measurement accuracy, which verifies the effectiveness and correctness of the methods for suppressing the impact of unideal optical parameters on OVSs. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle Evaluation of Shifted Excitation Raman Difference Spectroscopy and Comparison to Computational Background Correction Methods Applied to Biochemical Raman Spectra
Sensors 2017, 17(8), 1724; doi:10.3390/s17081724
Received: 26 June 2017 / Revised: 18 July 2017 / Accepted: 20 July 2017 / Published: 27 July 2017
PDF Full-text (3179 KB) | HTML Full-text | XML Full-text
Abstract
Raman spectroscopy provides label-free biochemical information from tissue samples without complicated sample preparation. The clinical capability of Raman spectroscopy has been demonstrated in a wide range of in vitro and in vivo applications. However, a challenge for in vivo applications is the simultaneous
[...] Read more.
Raman spectroscopy provides label-free biochemical information from tissue samples without complicated sample preparation. The clinical capability of Raman spectroscopy has been demonstrated in a wide range of in vitro and in vivo applications. However, a challenge for in vivo applications is the simultaneous excitation of auto-fluorescence in the majority of tissues of interest, such as liver, bladder, brain, and others. Raman bands are then superimposed on a fluorescence background, which can be several orders of magnitude larger than the Raman signal. To eliminate the disturbing fluorescence background, several approaches are available. Among instrumentational methods shifted excitation Raman difference spectroscopy (SERDS) has been widely applied and studied. Similarly, computational techniques, for instance extended multiplicative scatter correction (EMSC), have also been employed to remove undesired background contributions. Here, we present a theoretical and experimental evaluation and comparison of fluorescence background removal approaches for Raman spectra based on SERDS and EMSC. Full article
(This article belongs to the Special Issue Applications of Raman Spectroscopy in Biosensors)
Figures

Figure 1

Open AccessArticle Curvature and Temperature Measurement Based on a Few-Mode PCF Formed M-Z-I and an Embedded FBG
Sensors 2017, 17(8), 1725; doi:10.3390/s17081725
Received: 17 June 2017 / Revised: 15 July 2017 / Accepted: 24 July 2017 / Published: 27 July 2017
PDF Full-text (9073 KB) | HTML Full-text | XML Full-text
Abstract
We have experimentally demonstrated an optical fiber Mach-Zehnder interferometer (MZI) structure formed by a few-mode photonic crystal fiber (PCF) for curvature measurement and inscribed a fiber Bragg grating (FBG) in the PCF for the purpose of simultaneously measuring temperature. The structure consists of
[...] Read more.
We have experimentally demonstrated an optical fiber Mach-Zehnder interferometer (MZI) structure formed by a few-mode photonic crystal fiber (PCF) for curvature measurement and inscribed a fiber Bragg grating (FBG) in the PCF for the purpose of simultaneously measuring temperature. The structure consists of a PCF sandwiched between two multi-mode fibers (MMFs). Bending experimental results show that the proposed sensor has a sensitivity of −1.03 nm/m−1 at a curvature range from 10 m−1 to 22.4 m−1, and the curvature sensitivity of the embedded FBG was −0.003 nm/m−1. Temperature response experimental results showed that the MZI’s wavelength, λa, has a sensitivity of 60.3 pm/°C, and the FBG’s Bragg wavelength, λb, has sensitivity of 9.2 pm/°C in the temperature range of 8 to 100 °C. As such, it can be used for simultaneous measurement of curvature and temperature over ranges of 10 m−1 to 22.4 m−1 and 8 °C to 100 °C, respectively. The results show that the embedded FBG can be a good indicator to compensate the varying ambient temperature during a curvature measurement. Full article
(This article belongs to the Special Issue Optical Fiber Sensors 2017)
Figures

Figure 1

Open AccessArticle IoT Service Clustering for Dynamic Service Matchmaking
Sensors 2017, 17(8), 1727; doi:10.3390/s17081727
Received: 30 June 2017 / Revised: 20 July 2017 / Accepted: 27 July 2017 / Published: 27 July 2017
PDF Full-text (3292 KB) | HTML Full-text | XML Full-text
Abstract
As the adoption of service-oriented paradigms in the IoT (Internet of Things) environment, real-world devices will open their capabilities through service interfaces, which enable other functional entities to interact with them. In an IoT application, it is indispensable to find suitable services for
[...] Read more.
As the adoption of service-oriented paradigms in the IoT (Internet of Things) environment, real-world devices will open their capabilities through service interfaces, which enable other functional entities to interact with them. In an IoT application, it is indispensable to find suitable services for satisfying users’ requirements or replacing the unavailable services. However, from the perspective of performance, it is inappropriate to find desired services from the service repository online directly. Instead, clustering services offline according to their similarity and matchmaking or discovering service online in limited clusters is necessary. This paper proposes a multidimensional model-based approach to measure the similarity between IoT services. Then, density-peaks-based clustering is employed to gather similar services together according to the result of similarity measurement. Based on the service clustering, the algorithms of dynamic service matchmaking, discovery, and replacement will be performed efficiently. Evaluating experiments are conducted to validate the performance of proposed approaches, and the results are promising. Full article
Figures

Figure 1a

Open AccessArticle Cupula-Inspired Hyaluronic Acid-Based Hydrogel Encapsulation to Form Biomimetic MEMS Flow Sensors
Sensors 2017, 17(8), 1728; doi:10.3390/s17081728
Received: 29 May 2017 / Revised: 13 July 2017 / Accepted: 21 July 2017 / Published: 28 July 2017
PDF Full-text (9245 KB) | HTML Full-text | XML Full-text
Abstract
Blind cavefishes are known to detect objects through hydrodynamic vision enabled by arrays of biological flow sensors called neuromasts. This work demonstrates the development of a MEMS artificial neuromast sensor that features a 3D polymer hair cell that extends into the ambient flow.
[...] Read more.
Blind cavefishes are known to detect objects through hydrodynamic vision enabled by arrays of biological flow sensors called neuromasts. This work demonstrates the development of a MEMS artificial neuromast sensor that features a 3D polymer hair cell that extends into the ambient flow. The hair cell is monolithically fabricated at the center of a 2 μm thick silicon membrane that is photo-patterned with a full-bridge bias circuit. Ambient flow variations exert a drag force on the hair cell, which causes a displacement of the sensing membrane. This in turn leads to the resistance imbalance in the bridge circuit generating a voltage output. Inspired by the biological neuromast, a biomimetic synthetic hydrogel cupula is incorporated on the hair cell. The morphology, swelling behavior, porosity and mechanical properties of the hyaluronic acid hydrogel are characterized through rheology and nanoindentation techniques. The sensitivity enhancement in the sensor output due to the material and mechanical contributions of the micro-porous hydrogel cupula is investigated through experiments. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle An Ensemble Deep Convolutional Neural Network Model with Improved D-S Evidence Fusion for Bearing Fault Diagnosis
Sensors 2017, 17(8), 1729; doi:10.3390/s17081729
Received: 11 June 2017 / Revised: 22 July 2017 / Accepted: 25 July 2017 / Published: 28 July 2017
PDF Full-text (6213 KB) | HTML Full-text | XML Full-text
Abstract
Intelligent machine health monitoring and fault diagnosis are becoming increasingly important for modern manufacturing industries. Current fault diagnosis approaches mostly depend on expert-designed features for building prediction models. In this paper, we proposed IDSCNN, a novel bearing fault diagnosis algorithm based on ensemble
[...] Read more.
Intelligent machine health monitoring and fault diagnosis are becoming increasingly important for modern manufacturing industries. Current fault diagnosis approaches mostly depend on expert-designed features for building prediction models. In this paper, we proposed IDSCNN, a novel bearing fault diagnosis algorithm based on ensemble deep convolutional neural networks and an improved Dempster–Shafer theory based evidence fusion. The convolutional neural networks take the root mean square (RMS) maps from the FFT (Fast Fourier Transformation) features of the vibration signals from two sensors as inputs. The improved D-S evidence theory is implemented via distance matrix from evidences and modified Gini Index. Extensive evaluations of the IDSCNN on the Case Western Reserve Dataset showed that our IDSCNN algorithm can achieve better fault diagnosis performance than existing machine learning methods by fusing complementary or conflicting evidences from different models and sensors and adapting to different load conditions. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle Portable Multispectral Colorimeter for Metallic Ion Detection and Classification
Sensors 2017, 17(8), 1730; doi:10.3390/s17081730
Received: 12 June 2017 / Revised: 20 July 2017 / Accepted: 25 July 2017 / Published: 28 July 2017
PDF Full-text (5022 KB) | HTML Full-text | XML Full-text
Abstract
This work deals with a portable device system applied to detect and classify different metallic ions as proposed and developed, aiming its application for hydrological monitoring systems such as rivers, lakes and groundwater. Considering the system features, a portable colorimetric system was developed
[...] Read more.
This work deals with a portable device system applied to detect and classify different metallic ions as proposed and developed, aiming its application for hydrological monitoring systems such as rivers, lakes and groundwater. Considering the system features, a portable colorimetric system was developed by using a multispectral optoelectronic sensor. All the technology of quantification and classification of metallic ions using optoelectronic multispectral sensors was fully integrated in the embedded hardware FPGA ( Field Programmable Gate Array) technology and software based on virtual instrumentation (NI LabView®). The system draws on an indicative colorimeter by using the chromogen reagent of 1-(2-pyridylazo)-2-naphthol (PAN). The results obtained with the signal processing and pattern analysis using the method of the linear discriminant analysis, allows excellent results during detection and classification of Pb(II), Cd(II), Zn(II), Cu(II), Fe(III) and Ni(II) ions, with almost the same level of performance as for those obtained from the Ultravioled and visible (UV-VIS) spectrophotometers of high spectral resolution. Full article
(This article belongs to the Special Issue Fluorescent Probes and Sensors)
Figures

Figure 1

Open AccessArticle Determination of the State of Strain of Large Floating Covers Using Unmanned Aerial Vehicle (UAV) Aided Photogrammetry
Sensors 2017, 17(8), 1731; doi:10.3390/s17081731
Received: 8 June 2017 / Revised: 10 July 2017 / Accepted: 26 July 2017 / Published: 28 July 2017
PDF Full-text (23295 KB) | HTML Full-text | XML Full-text
Abstract
Floating covers used in waste water treatment plants are one of the many structures formed with membrane materials. These structures are usually large and can spread over an area measuring 470 m × 170 m. The aim of this paper is to describe
[...] Read more.
Floating covers used in waste water treatment plants are one of the many structures formed with membrane materials. These structures are usually large and can spread over an area measuring 470 m × 170 m. The aim of this paper is to describe recent work to develop an innovative and effective approach for structural health monitoring (SHM) of such large membrane-like infrastructure. This paper will propose a potentially cost-effective non-contact approach for full-field strain and stress mapping using an unmanned aerial vehicle (UAV) mounted with a digital camera and a global positioning system (GPS) tracker. The aim is to use the images acquired by the UAV to define the geometry of the floating cover using photogrammetry. In this manner, any changes in the geometry of the floating cover due to forces acting beneath resulting from its deployment and usage can be determined. The time-scale for these changes is in terms of weeks and months. The change in the geometry can be implemented as input conditions to a finite element model (FEM) for stress prediction. This will facilitate the determination of the state of distress of the floating cover. This paper investigates the possibility of using data recorded from a UAV to predict the strain level and assess the health of such structures. An investigation was first conducted on a laboratory sized membrane structure instrumented with strain gauges for comparison against strains, which were computed from 3D scans of the membrane geometry. Upon validating the technique in the laboratory, it was applied to a more realistic scenario: an outdoor test membrane structure and capable UAV were constructed to see if the shape of the membrane could be computed. The membrane displacements were then used to calculate the membrane stress and strain, state demonstrating a new way to perform structural health monitoring on membrane structures. Full article
(This article belongs to the Special Issue Sensors for Deformation Monitoring of Large Civil Infrastructures)
Figures

Figure 1

Open AccessArticle A Long-Distance RF-Powered Sensor Node with Adaptive Power Management for IoT Applications
Sensors 2017, 17(8), 1732; doi:10.3390/s17081732
Received: 30 June 2017 / Revised: 23 July 2017 / Accepted: 26 July 2017 / Published: 28 July 2017
PDF Full-text (10956 KB) | HTML Full-text | XML Full-text
Abstract
We present a self-sustained battery-less multi-sensor platform with RF harvesting capability down to −17 dBm and implementing a standard DASH7 wireless communication interface. The node operates at distances up to 17 m from a 2 W UHF carrier. RF power transfer allows operation
[...] Read more.
We present a self-sustained battery-less multi-sensor platform with RF harvesting capability down to −17 dBm and implementing a standard DASH7 wireless communication interface. The node operates at distances up to 17 m from a 2 W UHF carrier. RF power transfer allows operation when common energy scavenging sources (e.g., sun, heat, etc.) are not available, while the DASH7 communication protocol makes it fully compatible with a standard IoT infrastructure. An optimized energy-harvesting module has been designed, including a rectifying antenna (rectenna) and an integrated nano-power DC/DC converter performing maximum-power-point-tracking (MPPT). A nonlinear/electromagnetic co-design procedure is adopted to design the rectenna, which is optimized to operate at ultra-low power levels. An ultra-low power microcontroller controls on-board sensors and wireless protocol, to adapt the power consumption to the available detected power by changing wake-up policies. As a result, adaptive behavior can be observed in the designed platform, to the extent that the transmission data rate is dynamically determined by RF power. Among the novel features of the system, we highlight the use of nano-power energy harvesting, the implementation of specific hardware/software wake-up policies, optimized algorithms for best sampling rate implementation, and adaptive behavior by the node based on the power received. Full article
(This article belongs to the Special Issue Wireless Rechargeable Sensor Networks)
Figures

Figure 1

Open AccessArticle Load Identification for a Cantilever Beam Based on Fiber Bragg Grating Sensors
Sensors 2017, 17(8), 1733; doi:10.3390/s17081733
Received: 20 June 2017 / Revised: 23 July 2017 / Accepted: 25 July 2017 / Published: 28 July 2017
PDF Full-text (3284 KB) | HTML Full-text | XML Full-text
Abstract
Load identification plays an important role in structural health monitoring, which aims at preventing structural failures. In order to identify load for linear systems and nonlinear systems, this paper presents methods to identify load for a cantilever beam based on dynamic strain measurement
[...] Read more.
Load identification plays an important role in structural health monitoring, which aims at preventing structural failures. In order to identify load for linear systems and nonlinear systems, this paper presents methods to identify load for a cantilever beam based on dynamic strain measurement by Fiber Bragg Grating (FBG) sensors. For linear systems, the proposed inverse method consists of Kalman filter with no load terms and a linear estimator. For nonlinear systems, the proposed inverse method consists of cubature Kalman filter (CKF) with no load terms and a nonlinear estimator. In the process of load identification, the state equations of the beam structures are constructed by using the finite element method (FEM). Kalman filter or CKF is used to suppress noise. The residual innovation sequences, gain matrix, and innovation covariance generated by Kalman filter or CKF are used to identify a load. To prove the effectiveness of the proposed method, numerical simulations and experiments of the beam structures are employed and the results show that the method has an excellent performance. Full article
(This article belongs to the Special Issue Fiber Bragg Grating Based Sensors)
Figures

Figure 1

Open AccessArticle A Novel Detection Method for Underwater Moving Targets by Measuring Their ELF Emissions with Inductive Sensors
Sensors 2017, 17(8), 1734; doi:10.3390/s17081734
Received: 21 June 2017 / Revised: 23 July 2017 / Accepted: 25 July 2017 / Published: 28 July 2017
PDF Full-text (4783 KB) | HTML Full-text | XML Full-text
Abstract
In this article, we propose a novel detection method for underwater moving targets by detecting their extremely low frequency (ELF) emissions with inductive sensors. The ELF field source of the targets is modeled by a horizontal electric dipole at distances more than several
[...] Read more.
In this article, we propose a novel detection method for underwater moving targets by detecting their extremely low frequency (ELF) emissions with inductive sensors. The ELF field source of the targets is modeled by a horizontal electric dipole at distances more than several times of the targets’ length. The formulas for the fields produced in air are derived with a three-layer model (air, seawater and seafloor) and are evaluated with a complementary numerical integration technique. A proof of concept measurement is presented. The ELF emissions from a surface ship were detected by inductive electronic and magnetic sensors as the ship was leaving a harbor. ELF signals are of substantial strength and have typical characteristic of harmonic line spectrum, and the fundamental frequency has a direct relationship with the ship’s speed. Due to the high sensitivity and low noise level of our sensors, it is capable of resolving weak ELF signals at long distance. In our experiment, a detection distance of 1300 m from the surface ship above the sea surface was realized, which shows that this method would be an appealing complement to the usual acoustic detection and magnetic anomaly detection capability. Full article
(This article belongs to the Special Issue Marine Sensing)
Figures

Figure 1

Open AccessArticle Automated Water Quality Survey and Evaluation Using an IoT Platform with Mobile Sensor Nodes
Sensors 2017, 17(8), 1735; doi:10.3390/s17081735
Received: 31 May 2017 / Revised: 19 July 2017 / Accepted: 24 July 2017 / Published: 28 July 2017
PDF Full-text (17812 KB) | HTML Full-text | XML Full-text
Abstract
An Internet of Things (IoT) platform with capabilities of sensing, data processing, and wireless communication has been deployed to support remote aquatic environmental monitoring. In this paper, the design and development of an IoT platform with multiple Mobile Sensor Nodes (MSN) for the
[...] Read more.
An Internet of Things (IoT) platform with capabilities of sensing, data processing, and wireless communication has been deployed to support remote aquatic environmental monitoring. In this paper, the design and development of an IoT platform with multiple Mobile Sensor Nodes (MSN) for the spatiotemporal quality evaluation of surface water is presented. A survey planner is proposed to distribute the Sampling Locations of Interest (SLoIs) over the study area and generate paths for MSNs to visit the SLoIs, given the limited energy and time budgets. The SLoIs are chosen based on a cellular decomposition that is composed of uniform hexagonal cells. They are visited by the MSNs along a path ring generated by a planning approach that uses a spanning tree. For quality evaluation, an Online Water Quality Index (OLWQI) is developed to interpret the large quantities of online measurements. The index formulations are modified by a state-of-the-art index, the CCME WQI, which has been developed by the Canadian Council of Ministers of Environment (CCME) for off-line indexing. The proposed index has demonstrated effective and reliable performance in online indexing a large volume of measurements of water quality parameters. The IoT platform is deployed in the field, and its performance is demonstrated and discussed in this paper. Full article
(This article belongs to the Special Issue State-of-the-Art Sensors Technology in Canada 2017)
Figures

Figure 1

Open AccessArticle Real-Time Electrical Bioimpedance Characterization of Neointimal Tissue for Stent Applications
Sensors 2017, 17(8), 1737; doi:10.3390/s17081737
Received: 19 May 2017 / Revised: 17 July 2017 / Accepted: 25 July 2017 / Published: 28 July 2017
PDF Full-text (4857 KB) | HTML Full-text | XML Full-text
Abstract
To follow up the restenosis in arteries stented during an angioplasty is an important current clinical problem. A new approach to monitor the growth of neointimal tissue inside the stent is proposed on the basis of electrical impedance spectroscopy (EIS) sensors and the
[...] Read more.
To follow up the restenosis in arteries stented during an angioplasty is an important current clinical problem. A new approach to monitor the growth of neointimal tissue inside the stent is proposed on the basis of electrical impedance spectroscopy (EIS) sensors and the oscillation-based test (OBT) circuit technique. A mathematical model was developed to analytically describe the histological composition of the neointima, employing its conductivity and permittivity data. The bioimpedance model was validated against a finite element analysis (FEA) using COMSOL Multiphysics software. A satisfactory correlation between the analytical model and FEA simulation was achieved in most cases, detecting some deviations introduced by the thin “double layer” that separates the neointima and the blood. It is hereby shown how to apply conformal transformations to obtain bioimpedance electrical models for stack-layered tissues over coplanar electrodes. Particularly, this can be applied to characterize the neointima in real-time. This technique is either suitable as a main mechanism for restenosis follow-up or it can be combined with proposed intelligent stents for blood pressure measurements to auto-calibrate the sensibility loss caused by the adherence of the tissue on the micro-electro-mechanical sensors (MEMSs). Full article
(This article belongs to the Section Biosensors)
Figures

Figure 1

Open AccessArticle Simultaneous Indoor Tracking and Activity Recognition Using Pyroelectric Infrared Sensors
Sensors 2017, 17(8), 1738; doi:10.3390/s17081738
Received: 20 June 2017 / Revised: 19 July 2017 / Accepted: 25 July 2017 / Published: 29 July 2017
PDF Full-text (4228 KB) | HTML Full-text | XML Full-text
Abstract
Indoor human tracking and activity recognition are fundamental yet coherent problems for ambient assistive living. In this paper, we propose a method to address these two critical issues simultaneously. We construct a wireless sensor network (WSN), and the sensor nodes within WSN consist
[...] Read more.
Indoor human tracking and activity recognition are fundamental yet coherent problems for ambient assistive living. In this paper, we propose a method to address these two critical issues simultaneously. We construct a wireless sensor network (WSN), and the sensor nodes within WSN consist of pyroelectric infrared (PIR) sensor arrays. To capture the tempo-spatial information of the human target, the field of view (FOV) of each PIR sensor is modulated by masks. A modified partial filter algorithm is utilized to decode the location of the human target. To exploit the synergy between the location and activity, we design a two-layer random forest (RF) classifier. The initial activity recognition result of the first layer is refined by the second layer RF by incorporating various effective features. We conducted experiments in a mock apartment. The mean localization error of our system is about 0.85 m. For five kinds of daily activities, the mean accuracy for 10-fold cross-validation is above 92%. The encouraging results indicate the effectiveness of our system. Full article
Figures

Figure 1

Open AccessArticle Nanometric Integrated Temperature and Thermal Sensors in CMOS-SOI Technology
Sensors 2017, 17(8), 1739; doi:10.3390/s17081739
Received: 6 July 2017 / Revised: 26 July 2017 / Accepted: 27 July 2017 / Published: 29 July 2017
PDF Full-text (3016 KB) | HTML Full-text | XML Full-text
Abstract
This paper reviews and compares the thermal and noise characterization of CMOS (complementary metal-oxide-semiconductor) SOI (Silicon on insulator) transistors and lateral diodes used as temperature and thermal sensors. DC analysis of the measured sensors and the experimental results in a broad (300 K
[...] Read more.
This paper reviews and compares the thermal and noise characterization of CMOS (complementary metal-oxide-semiconductor) SOI (Silicon on insulator) transistors and lateral diodes used as temperature and thermal sensors. DC analysis of the measured sensors and the experimental results in a broad (300 K up to 550 K) temperature range are presented. It is shown that both sensors require small chip area, have low power consumption, and exhibit linearity and high sensitivity over the entire temperature range. However, the diode’s sensitivity to temperature variations in CMOS-SOI technology is highly dependent on the diode’s perimeter; hence, a careful calibration for each fabrication process is needed. In contrast, the short thermal time constant of the electrons in the transistor’s channel enables measuring the instantaneous heating of the channel and to determine the local true temperature of the transistor. This allows accurate “on-line” temperature sensing while no additional calibration is needed. In addition, the noise measurements indicate that the diode’s small area and perimeter causes a high 1/f noise in all measured bias currents. This is a severe drawback for the sensor accuracy when using the sensor as a thermal sensor; hence, CMOS-SOI transistors are a better choice for temperature sensing. Full article
(This article belongs to the Special Issue Integrated Sensors)
Figures

Figure 1

Open AccessArticle Flexible Mixed-Potential-Type (MPT) NO2 Sensor Based on An Ultra-Thin Ceramic Film
Sensors 2017, 17(8), 1740; doi:10.3390/s17081740
Received: 23 June 2017 / Revised: 24 July 2017 / Accepted: 26 July 2017 / Published: 29 July 2017
PDF Full-text (7675 KB) | HTML Full-text | XML Full-text
Abstract
A novel flexible mixed-potential-type (MPT) sensor was designed and fabricated for NO2 detection from 0 to 500 ppm at 200 °C. An ultra-thin Y2O3-doped ZrO2 (YSZ) ceramic film 20 µm thick was sandwiched between a heating electrode
[...] Read more.
A novel flexible mixed-potential-type (MPT) sensor was designed and fabricated for NO2 detection from 0 to 500 ppm at 200 °C. An ultra-thin Y2O3-doped ZrO2 (YSZ) ceramic film 20 µm thick was sandwiched between a heating electrode and reference/sensing electrodes. The heating electrode was fabricated by a conventional lift-off process, while the porous reference and the sensing electrodes were fabricated by a two-step patterning method using shadow masks. The sensor’s sensitivity is achieved as 58.4 mV/decade at the working temperature of 200 °C, as well as a detection limit of 26.7 ppm and small response time of less than 10 s at 200 ppm. Additionally, the flexible MPT sensor demonstrates superior mechanical stability after bending over 50 times due to the mechanical stability of the YSZ ceramic film. This simply structured, but highly reliable flexible MPT NO2 sensor may lead to wide application in the automobile industry for vehicle emission systems to reduce NO2 emissions and improve fuel efficiency. Full article
(This article belongs to the Section Chemical Sensors)
Figures

Figure 1

Open AccessArticle Position, Orientation and Velocity Detection of Unmanned Underwater Vehicles (UUVs) Using an Optical Detector Array
Sensors 2017, 17(8), 1741; doi:10.3390/s17081741
Received: 30 June 2017 / Revised: 26 July 2017 / Accepted: 27 July 2017 / Published: 29 July 2017
PDF Full-text (5754 KB) | HTML Full-text | XML Full-text
Abstract
This paper presents a proof-of-concept optical detector array sensor system to be used in Unmanned Underwater Vehicle (UUV) navigation. The performance of the developed optical detector array was evaluated for its capability to estimate the position, orientation and forward velocity of UUVs with
[...] Read more.
This paper presents a proof-of-concept optical detector array sensor system to be used in Unmanned Underwater Vehicle (UUV) navigation. The performance of the developed optical detector array was evaluated for its capability to estimate the position, orientation and forward velocity of UUVs with respect to a light source fixed in underwater. The evaluations were conducted through Monte Carlo simulations and empirical tests under a variety of motion configurations. Monte Carlo simulations also evaluated the system total propagated uncertainty (TPU) by taking into account variations in the water column turbidity, temperature and hardware noise that may degrade the system performance. Empirical tests were conducted to estimate UUV position and velocity during its navigation to a light beacon. Monte Carlo simulation and empirical results support the use of the detector array system for optics based position feedback for UUV positioning applications. Full article
(This article belongs to the Special Issue Marine Sensing)
Figures

Figure 1

Open AccessArticle A Solar Position Sensor Based on Image Vision
Sensors 2017, 17(8), 1742; doi:10.3390/s17081742
Received: 26 June 2017 / Revised: 23 July 2017 / Accepted: 26 July 2017 / Published: 29 July 2017
PDF Full-text (6378 KB) | HTML Full-text | XML Full-text
Abstract
Solar collector technologies operate with better performance when the Sun beam direction is normal to the capturing surface, and for that to happen despite the relative movement of the Sun, solar tracking systems are used, therefore, there are rules and standards that need
[...] Read more.
Solar collector technologies operate with better performance when the Sun beam direction is normal to the capturing surface, and for that to happen despite the relative movement of the Sun, solar tracking systems are used, therefore, there are rules and standards that need minimum accuracy for these tracking systems to be used in solar collectors’ evaluation. Obtaining accuracy is not an easy job, hence in this document the design, construction and characterization of a sensor based on a visual system that finds the relative azimuth error and height of the solar surface of interest, is presented. With these characteristics, the sensor can be used as a reference in control systems and their evaluation. The proposed sensor is based on a microcontroller with a real-time clock, inertial measurement sensors, geolocation and a vision sensor, that obtains the angle of incidence from the sunrays’ direction as well as the tilt and sensor position. The sensor’s characterization proved how a measurement of a focus error or a Sun position can be made, with an accuracy of 0.0426° and an uncertainty of 0.986%, which can be modified to reach an accuracy under 0.01°. The validation of this sensor was determined showing the focus error on one of the best commercial solar tracking systems, a Kipp & Zonen SOLYS 2. To conclude, the solar tracking sensor based on a vision system meets the Sun detection requirements and components that meet the accuracy conditions to be used in solar tracking systems and their evaluation or, as a tracking and orientation tool, on photovoltaic installations and solar collectors. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle Olive Actual “on Year” Yield Forecast Tool Based on the Tree Canopy Geometry Using UAS Imagery
Sensors 2017, 17(8), 1743; doi:10.3390/s17081743
Received: 2 June 2017 / Revised: 25 July 2017 / Accepted: 26 July 2017 / Published: 30 July 2017
PDF Full-text (2747 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Olive has a notable importance in countries of Mediterranean basin and its profitability depends on several factors such as actual yield, production cost or product price. Actual “on year” Yield (AY) is production (kg tree−1) in “on years”, and this research
[...] Read more.
Olive has a notable importance in countries of Mediterranean basin and its profitability depends on several factors such as actual yield, production cost or product price. Actual “on year” Yield (AY) is production (kg tree−1) in “on years”, and this research attempts to relate it with geometrical parameters of the tree canopy. Regression equation to forecast AY based on manual canopy volume was determined based on data acquired from different orchard categories and cultivars during different harvesting seasons in southern Spain. Orthoimages were acquired with unmanned aerial systems (UAS) imagery calculating individual crown for relating to canopy volume and AY. Yield levels did not vary between orchard categories; however, it did between irrigated orchards (7000–17,000 kg ha−1) and rainfed ones (4000–7000 kg ha−1). After that, manual canopy volume was related with the individual crown area of trees that were calculated by orthoimages acquired with UAS imagery. Finally, AY was forecasted using both manual canopy volume and individual tree crown area as main factors for olive productivity. AY forecast only by using individual crown area made it possible to get a simple and cheap forecast tool for a wide range of olive orchards. Finally, the acquired information was introduced in a thematic map describing spatial AY variability obtained from orthoimage analysis that may be a powerful tool for farmers, insurance systems, market forecasts or to detect agronomical problems. Full article
(This article belongs to the Special Issue UAV or Drones for Remote Sensing Applications)
Figures

Figure 1

Open AccessArticle Crowd Sensing-Enabling Security Service Recommendation for Social Fog Computing Systems
Sensors 2017, 17(8), 1744; doi:10.3390/s17081744
Received: 29 April 2017 / Revised: 9 July 2017 / Accepted: 24 July 2017 / Published: 30 July 2017
PDF Full-text (2195 KB) | HTML Full-text | XML Full-text
Abstract
Fog computing, shifting intelligence and resources from the remote cloud to edge networks, has the potential of providing low-latency for the communication from sensing data sources to users. For the objects from the Internet of Things (IoT) to the cloud, it is a
[...] Read more.
Fog computing, shifting intelligence and resources from the remote cloud to edge networks, has the potential of providing low-latency for the communication from sensing data sources to users. For the objects from the Internet of Things (IoT) to the cloud, it is a new trend that the objects establish social-like relationships with each other, which efficiently brings the benefits of developed sociality to a complex environment. As fog service become more sophisticated, it will become more convenient for fog users to share their own services, resources, and data via social networks. Meanwhile, the efficient social organization can enable more flexible, secure, and collaborative networking. Aforementioned advantages make the social network a potential architecture for fog computing systems. In this paper, we design an architecture for social fog computing, in which the services of fog are provisioned based on “friend” relationships. To the best of our knowledge, this is the first attempt at an organized fog computing system-based social model. Meanwhile, social networking enhances the complexity and security risks of fog computing services, creating difficulties of security service recommendations in social fog computing. To address this, we propose a novel crowd sensing-enabling security service provisioning method to recommend security services accurately in social fog computing systems. Simulation results show the feasibilities and efficiency of the crowd sensing-enabling security service recommendation method for social fog computing systems. Full article
(This article belongs to the Special Issue Security and Privacy Challenges in Emerging Fog Computing)
Figures

Figure 1

Open AccessArticle Sparse Representation Based Frequency Detection and Uncertainty Reduction in Blade Tip Timing Measurement for Multi-Mode Blade Vibration Monitoring
Sensors 2017, 17(8), 1745; doi:10.3390/s17081745
Received: 21 June 2017 / Revised: 26 July 2017 / Accepted: 26 July 2017 / Published: 30 July 2017
PDF Full-text (7303 KB) | HTML Full-text | XML Full-text
Abstract
The accurate monitoring of blade vibration under operating conditions is essential in turbo-machinery testing. Blade tip timing (BTT) is a promising non-contact technique for the measurement of blade vibrations. However, the BTT sampling data are inherently under-sampled and contaminated with several measurement uncertainties.
[...] Read more.
The accurate monitoring of blade vibration under operating conditions is essential in turbo-machinery testing. Blade tip timing (BTT) is a promising non-contact technique for the measurement of blade vibrations. However, the BTT sampling data are inherently under-sampled and contaminated with several measurement uncertainties. How to recover frequency spectra of blade vibrations though processing these under-sampled biased signals is a bottleneck problem. A novel method of BTT signal processing for alleviating measurement uncertainties in recovery of multi-mode blade vibration frequency spectrum is proposed in this paper. The method can be divided into four phases. First, a single measurement vector model is built by exploiting that the blade vibration signals are sparse in frequency spectra. Secondly, the uniqueness of the nonnegative sparse solution is studied to achieve the vibration frequency spectrum. Thirdly, typical sources of BTT measurement uncertainties are quantitatively analyzed. Finally, an improved vibration frequency spectra recovery method is proposed to get a guaranteed level of sparse solution when measurement results are biased. Simulations and experiments are performed to prove the feasibility of the proposed method. The most outstanding advantage is that this method can prevent the recovered multi-mode vibration spectra from being affected by BTT measurement uncertainties without increasing the probe number. Full article
Figures

Figure 1

Open AccessArticle Assessment of Chlorophyll-a Algorithms Considering Different Trophic Statuses and Optimal Bands
Sensors 2017, 17(8), 1746; doi:10.3390/s17081746
Received: 13 June 2017 / Revised: 17 July 2017 / Accepted: 26 July 2017 / Published: 31 July 2017
PDF Full-text (4975 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Numerous algorithms have been proposed to retrieve chlorophyll-a concentrations in Case 2 waters; however, the retrieval accuracy is far from satisfactory. In this research, seven algorithms are assessed with different band combinations of multispectral and hyperspectral bands using linear (LN), quadratic polynomial
[...] Read more.
Numerous algorithms have been proposed to retrieve chlorophyll-a concentrations in Case 2 waters; however, the retrieval accuracy is far from satisfactory. In this research, seven algorithms are assessed with different band combinations of multispectral and hyperspectral bands using linear (LN), quadratic polynomial (QP) and power (PW) regression approaches, resulting in altogether 43 algorithmic combinations. These algorithms are evaluated by using simulated and measured datasets to understand the strengths and limitations of these algorithms. Two simulated datasets comprising 500,000 reflectance spectra each, both based on wide ranges of inherent optical properties (IOPs), are generated for the calibration and validation stages. Results reveal that the regression approach (i.e., LN, QP, and PW) has more influence on the simulated dataset than on the measured one. The algorithms that incorporated linear regression provide the highest retrieval accuracy for the simulated dataset. Results from simulated datasets reveal that the 3-band (3b) algorithm that incorporate 665-nm and 680-nm bands and band tuning selection approach outperformed other algorithms with root mean square error (RMSE) of 15.87 mg·m−3, 16.25 mg·m−3, and 19.05 mg·m−3, respectively. The spatial distribution of the best performing algorithms, for various combinations of chlorophyll-a (Chla) and non-algal particles (NAP) concentrations, show that the 3b_tuning_QP and 3b_680_QP outperform other algorithms in terms of minimum RMSE frequency of 33.19% and 60.52%, respectively. However, the two algorithms failed to accurately retrieve Chla for many combinations of Chla and NAP, particularly for low Chla and NAP concentrations. In addition, the spatial distribution emphasizes that no single algorithm can provide outstanding accuracy for Chla retrieval and that multi-algorithms should be included to reduce the error. Comparing the results of the measured and simulated datasets reveal that the algorithms that incorporate the 665-nm band outperform other algorithms for measured dataset (RMSE = 36.84 mg·m−3), while algorithms that incorporate the band tuning approach provide the highest retrieval accuracy for the simulated dataset (RMSE = 25.05 mg·m−3). Full article
(This article belongs to the Special Issue Analysis of Multispectral and Hyperspectral Data)
Figures

Open AccessArticle Imaging of Subsurface Corrosion Using Gradient-Field Pulsed Eddy Current Probes with Uniform Field Excitation
Sensors 2017, 17(8), 1747; doi:10.3390/s17081747
Received: 28 June 2017 / Revised: 19 July 2017 / Accepted: 27 July 2017 / Published: 31 July 2017
PDF Full-text (3534 KB) | HTML Full-text | XML Full-text
Abstract
A corrosive environment leaves in-service conductive structures prone to subsurface corrosion which poses a severe threat to the structural integrity. It is indispensable to detect and quantitatively evaluate subsurface corrosion via non-destructive evaluation techniques. Although the gradient-field pulsed eddy current technique (GPEC) has
[...] Read more.
A corrosive environment leaves in-service conductive structures prone to subsurface corrosion which poses a severe threat to the structural integrity. It is indispensable to detect and quantitatively evaluate subsurface corrosion via non-destructive evaluation techniques. Although the gradient-field pulsed eddy current technique (GPEC) has been found to be superior in the evaluation of corrosion in conductors, it suffers from a technical drawback resulting from the non-uniform field excited by the conventional pancake coil. In light of this, a new GPEC probe with uniform field excitation for the imaging of subsurface corrosion is proposed in this paper. The excited uniform field makes the GPEC signal correspond only to the field perturbation due to the presence of subsurface corrosion, which benefits the corrosion profiling and sizing. A 3D analytical model of GPEC is established to analyze the characteristics of the uniform field induced within a conductor. Following this, experiments regarding the imaging of subsurface corrosion via GPEC have been carried out. It has been found from the results that the proposed GPEC probe with uniform field excitation not only applies to the imaging of subsurface corrosion in conductive structures, but provides high-sensitivity imaging results regarding the corrosion profile and opening size. Full article
(This article belongs to the Special Issue Intelligent Sensing Technologies for Nondestructive Evaluation)
Figures

Figure 1

Open AccessArticle A Framework to Improve Energy Efficient Behaviour at Home through Activity and Context Monitoring
Sensors 2017, 17(8), 1749; doi:10.3390/s17081749
Received: 12 June 2017 / Revised: 22 July 2017 / Accepted: 25 July 2017 / Published: 31 July 2017
PDF Full-text (3125 KB) | HTML Full-text | XML Full-text
Abstract
Real-time Localization Systems have been postulated as one of the most appropriated technologies for the development of applications that provide customized services. These systems provide us with the ability to locate and trace users and, among other features, they help identify behavioural patterns
[...] Read more.
Real-time Localization Systems have been postulated as one of the most appropriated technologies for the development of applications that provide customized services. These systems provide us with the ability to locate and trace users and, among other features, they help identify behavioural patterns and habits. Moreover, the implementation of policies that will foster energy saving in homes is a complex task that involves the use of this type of systems. Although there are multiple proposals in this area, the implementation of frameworks that combine technologies and use Social Computing to influence user behaviour have not yet reached any significant savings in terms of energy. In this work, the CAFCLA framework (Context-Aware Framework for Collaborative Learning Applications) is used to develop a recommendation system for home users. The proposed system integrates a Real-Time Localization System and Wireless Sensor Networks, making it possible to develop applications that work under the umbrella of Social Computing. The implementation of an experimental use case aided efficient energy use, achieving savings of 17%. Moreover, the conducted case study pointed to the possibility of attaining good energy consumption habits in the long term. This can be done thanks to the system’s real time and historical localization, tracking and contextual data, based on which customized recommendations are generated. Full article
Figures

Figure 1

Open AccessArticle A Miniaturized QEPAS Trace Gas Sensor with a 3D-Printed Acoustic Detection Module
Sensors 2017, 17(8), 1750; doi:10.3390/s17081750
Received: 8 July 2017 / Revised: 23 July 2017 / Accepted: 28 July 2017 / Published: 31 July 2017
PDF Full-text (8257 KB) | HTML Full-text | XML Full-text
Abstract
A 3D printing technique was introduced to a quartz-enhanced photoacoustic spectroscopy (QEPAS) sensor and is reported for the first time. The acoustic detection module (ADM) was designed and fabricated using the 3D printing technique and the ADM volume was compressed significantly. Furthermore, a
[...] Read more.
A 3D printing technique was introduced to a quartz-enhanced photoacoustic spectroscopy (QEPAS) sensor and is reported for the first time. The acoustic detection module (ADM) was designed and fabricated using the 3D printing technique and the ADM volume was compressed significantly. Furthermore, a small grin lens was used for laser focusing and facilitated the beam adjustment in the 3D-printed ADM. A quartz tuning fork (QTF) with a low resonance frequency of 30.72 kHz was used as the acoustic wave transducer and acetylene (C2H2) was chosen as the analyte. The reported miniaturized QEPAS trace gas sensor is useful in actual sensor applications. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle A Method to Reduce Non-Nominal Troposphere Error
Sensors 2017, 17(8), 1751; doi:10.3390/s17081751
Received: 13 June 2017 / Revised: 27 July 2017 / Accepted: 27 July 2017 / Published: 31 July 2017
PDF Full-text (8713 KB) | HTML Full-text | XML Full-text
Abstract
Under abnormal troposphere, Ground-Based Augmentation System (GBAS) is unable to eliminate troposphere delay, resulting in non-nominal troposphere error. This paper analyzes the troposphere meteorological data of eight International GNSS Monitoring Assessment System (iGMAS) stations and 10 International GNSS Service (IGS) stations in China
[...] Read more.
Under abnormal troposphere, Ground-Based Augmentation System (GBAS) is unable to eliminate troposphere delay, resulting in non-nominal troposphere error. This paper analyzes the troposphere meteorological data of eight International GNSS Monitoring Assessment System (iGMAS) stations and 10 International GNSS Service (IGS) stations in China and records the most serious conditions during 2015 and 2016. Simulations show that the average increase in Vertical Protection Level (VPL) of all visible satellites under non-nominal troposphere is 2.32 m and that more satellites increase the VPL. To improve GBAS integrity, this paper proposes a satellite selection method to reduce the non-nominal troposphere error. First, the number of satellites in the optimal subset is determined to be 16 based on the relationship among VPL, non-nominal troposphere error and satellite geometry. Second, the distributions of the optimal satellites are determined. Finally, optimal satellites are selected in different elevation ranges. Results show that the average VPL increase caused by non-nominal troposphere error is 1.15 m using the proposed method. Compared with the brute method and greedy method, the running rate of the proposed method is improved by 390.91% and 111.65%, respectively. In summary, the proposed method balances the satellite geometry and non-nominal troposphere error while minimizing the VPL and improving the running rate. Full article
(This article belongs to the Section Remote Sensors)
Figures

Figure 1

Open AccessArticle Development of Wearable Sheet-Type Shear Force Sensor and Measurement System that is Insusceptible to Temperature and Pressure
Sensors 2017, 17(8), 1752; doi:10.3390/s17081752
Received: 27 June 2017 / Revised: 28 July 2017 / Accepted: 28 July 2017 / Published: 31 July 2017
PDF Full-text (17726 KB) | HTML Full-text | XML Full-text
Abstract
A sheet-type shear force sensor and a measurement system for the sensor were developed. The sensor has an original structure where a liquid electrolyte is filled in a space composed of two electrode-patterned polymer films and an elastic rubber ring. When a shear
[...] Read more.
A sheet-type shear force sensor and a measurement system for the sensor were developed. The sensor has an original structure where a liquid electrolyte is filled in a space composed of two electrode-patterned polymer films and an elastic rubber ring. When a shear force is applied on the surface of the sensor, the two electrode-patterned films mutually move so that the distance between the internal electrodes of the sensor changes, resulting in current increase or decrease between the electrodes. Therefore, the shear force can be calculated by monitoring the current between the electrodes. Moreover, it is possible to measure two-dimensional shear force given that the sensor has multiple electrodes. The diameter and thickness of the sensor head were 10 mm and 0.7 mm, respectively. Additionally, we also developed a measurement system that drives the sensor, corrects the baseline of the raw sensor output, displays data, and stores data as a computer file. Though the raw sensor output was considerably affected by the surrounding temperature, the influence of temperature was drastically decreased by introducing a simple arithmetical calculation. Moreover, the influence of pressure simultaneously decreased after the same calculation process. A demonstrative measurement using the sensor revealed the practical usefulness for on-site monitoring. Full article
(This article belongs to the Special Issue Flexible Electronics and Sensors)
Figures

Figure 1

Open AccessArticle Practical Considerations before Installing Ground-Based Geodetic Infrastructure for Integrated InSAR and cGNSS Monitoring of Vertical Land Motion
Sensors 2017, 17(8), 1753; doi:10.3390/s17081753
Received: 18 June 2017 / Revised: 27 July 2017 / Accepted: 29 July 2017 / Published: 31 July 2017
PDF Full-text (8244 KB) | HTML Full-text | XML Full-text
Abstract
Continuously operating Global Navigation Satellite Systems (cGNSS) can be used to convert relative values of vertical land motion (VLM) derived from Interferometric Synthetic Aperture Radar (InSAR) to absolute values in a global or regional reference frame. Artificial trihedral corner reflectors (CRs) provide high-intensity
[...] Read more.
Continuously operating Global Navigation Satellite Systems (cGNSS) can be used to convert relative values of vertical land motion (VLM) derived from Interferometric Synthetic Aperture Radar (InSAR) to absolute values in a global or regional reference frame. Artificial trihedral corner reflectors (CRs) provide high-intensity and temporally stable reflections in SAR time series imagery, more so than naturally occurring permanent scatterers. Therefore, it is logical to co-locate CRs with cGNSS as ground-based geodetic infrastructure for the integrated monitoring of VLM. We describe the practical considerations for such co-locations using four case-study examples from Perth, Australia. After basic initial considerations such as land access, sky visibility and security, temporary test deployments of co-located CRs with cGNSS should be analysed together to determine site suitability. Signal to clutter ratios from SAR imagery are used to determine potential sites for placement of the CR. A significant concern is whether the co-location of a deliberately designed reflecting object generates unwanted multipath (reflected signals) in the cGNSS data. To mitigate against this, we located CRs >30 m from the cGNSS with no inter-visibility. Daily RMS values of the zero-difference ionosphere-free carrier-phase residuals, and ellipsoidal heights from static precise point positioning GNSS processing at each co-located site were then used to ascertain that the CR did not generate unwanted cGNSS multipath. These steps form a set of recommendations for the installation of such geodetic ground-infrastructure, which may be of use to others wishing to establish integrated InSAR-cGNSS monitoring of VLM elsewhere. Full article
(This article belongs to the Section Remote Sensors)
Figures

Figure 1

Open AccessArticle Identification and Quantification of Celery Allergens Using Fiber Optic Surface Plasmon Resonance PCR
Sensors 2017, 17(8), 1754; doi:10.3390/s17081754
Received: 6 July 2017 / Revised: 19 July 2017 / Accepted: 20 July 2017 / Published: 31 July 2017
PDF Full-text (1272 KB) | HTML Full-text | XML Full-text
Abstract
Abstract: Accurate identification and quantification of allergens is key in healthcare, biotechnology and food quality and safety. Celery (Apium graveolens) is one of the most important elicitors of food allergic reactions in Europe. Currently, the golden standards to identify, quantify
[...] Read more.
Abstract: Accurate identification and quantification of allergens is key in healthcare, biotechnology and food quality and safety. Celery (Apium graveolens) is one of the most important elicitors of food allergic reactions in Europe. Currently, the golden standards to identify, quantify and discriminate celery in a biological sample are immunoassays and two-step molecular detection assays in which quantitative PCR (qPCR) is followed by a high-resolution melting analysis (HRM). In order to provide a DNA-based, rapid and simple detection method suitable for one-step quantification, a fiber optic PCR melting assay (FO-PCR-MA) was developed to determine different concentrations of celery DNA (1 pM–0.1 fM). The presented method is based on the hybridization and melting of DNA-coated gold nanoparticles to the FO sensor surface in the presence of the target gene (mannitol dehydrogenase, Mtd). The concept was not only able to reveal the presence of celery DNA, but also allowed for the cycle-to-cycle quantification of the target sequence through melting analysis. Furthermore, the developed bioassay was benchmarked against qPCR followed by HRM, showing excellent agreement (R2 = 0.96). In conclusion, this innovative and sensitive diagnostic test could further improve food quality control and thus have a large impact on allergen induced healthcare problems. Full article
(This article belongs to the Special Issue Surface Plasmon Resonance Sensing)
Figures

Figure 1

Open AccessArticle Context- and Template-Based Compression for Efficient Management of Data Models in Resource-Constrained Systems
Sensors 2017, 17(8), 1755; doi:10.3390/s17081755
Received: 22 June 2017 / Revised: 19 July 2017 / Accepted: 27 July 2017 / Published: 1 August 2017
PDF Full-text (714 KB) | HTML Full-text | XML Full-text
Abstract
The Cyber Physical Systems (CPS) paradigm is based on the deployment of interconnected heterogeneous devices and systems, so interoperability is at the heart of any CPS architecture design. In this sense, the adoption of standard and generic data formats for data representation and
[...] Read more.
The Cyber Physical Systems (CPS) paradigm is based on the deployment of interconnected heterogeneous devices and systems, so interoperability is at the heart of any CPS architecture design. In this sense, the adoption of standard and generic data formats for data representation and communication, e.g., XML or JSON, effectively addresses the interoperability problem among heterogeneous systems. Nevertheless, the verbosity of those standard data formats usually demands system resources that might suppose an overload for the resource-constrained devices that are typically deployed in CPS. In this work we present Context- and Template-based Compression (CTC), a data compression approach targeted to resource-constrained devices, which allows reducing the resources needed to transmit, store and process data models. Additionally, we provide a benchmark evaluation and comparison with current implementations of the Efficient XML Interchange (EXI) processor, which is promoted by the World Wide Web Consortium (W3C), and it is the most prominent XML compression mechanism nowadays. Interestingly, the results from the evaluation show that CTC outperforms EXI implementations in terms of memory usage and speed, keeping similar compression rates. As a conclusion, CTC is shown to be a good candidate for managing standard data model representation formats in CPS composed of resource-constrained devices. Full article
Figures

Figure 1

Open AccessArticle Highly Sensitive Hot-Wire Anemometry Based on Macro-Sized Double-Walled Carbon Nanotube Strands
Sensors 2017, 17(8), 1756; doi:10.3390/s17081756
Received: 8 June 2017 / Revised: 24 July 2017 / Accepted: 27 July 2017 / Published: 1 August 2017
PDF Full-text (2384 KB) | HTML Full-text | XML Full-text
Abstract
This paper presents a highly sensitive flow-rate sensor with carbon nanotubes (CNTs) as sensing elements. The sensor uses micro-size centimeters long double-walled CNT (DWCNT) strands as hot-wires to sense fluid velocity. In the theoretical analysis, the sensitivity of the sensor is demonstrated to
[...] Read more.
This paper presents a highly sensitive flow-rate sensor with carbon nanotubes (CNTs) as sensing elements. The sensor uses micro-size centimeters long double-walled CNT (DWCNT) strands as hot-wires to sense fluid velocity. In the theoretical analysis, the sensitivity of the sensor is demonstrated to be positively related to the ratio of its surface. We assemble the flow sensor by suspending the DWCNT strand directly on two tungsten prongs and dripping a small amount of silver glue onto each contact between the DWCNT and the prongs. The DWCNT exhibits a positive TCR of 1980 ppm/K. The self-heating effect on the DWCNT was observed while constant current was applied between the two prongs. This sensor can evidently respond to flow rate, and requires only several milliwatts to operate. We have, thus far, demonstrated that the CNT-based flow sensor has better sensitivity than the Pt-coated DWCNT sensor. Full article
(This article belongs to the Special Issue MEMS and Nano-Sensors)
Figures

Figure 1

Open AccessArticle An Opto-Electronic Sensor for Detecting Soil Microarthropods and Estimating Their Size in Field Conditions
Sensors 2017, 17(8), 1757; doi:10.3390/s17081757
Received: 4 July 2017 / Revised: 24 July 2017 / Accepted: 24 July 2017 / Published: 1 August 2017
PDF Full-text (2525 KB) | HTML Full-text | XML Full-text
Abstract
Methods to estimate density of soil-dwelling arthropods efficiently, accurately and continuously are critical for investigating soil biological activity and evaluating soil management practices. Soil-dwelling arthropods are currently monitored manually. This method is invasive, and time- and labor-consuming. Here we describe an infrared opto-electronic
[...] Read more.
Methods to estimate density of soil-dwelling arthropods efficiently, accurately and continuously are critical for investigating soil biological activity and evaluating soil management practices. Soil-dwelling arthropods are currently monitored manually. This method is invasive, and time- and labor-consuming. Here we describe an infrared opto-electronic sensor for detection of soil microarthropods in the size range of 0.4–10 mm. The sensor is built in a novel microarthropod trap designed for field conditions. It allows automated, on-line, in situ detection and body length estimation of soil microarthropods. In the opto-electronic sensor the light source is an infrared LED. Two plano-convex optical lenses are placed along the virtual optical axis. One lens on the receiver side is placed between the observation space at 0.5–1 times its focal length from the sensor, and another emitter side lens is placed between the observation space and the light source in the same way. This paper describes the setup and operating mechanism of the sensor and the control unit, and through basic tests it demonstrates its potential in automated detection of soil microarthropods. The sensor may be used for monitoring activities, especially for remote observation activities in soil and insect ecology or pest control. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle Deformation Monitoring of Metro Tunnel with a New Ultrasonic-Based System
Sensors 2017, 17(8), 1758; doi:10.3390/s17081758
Received: 15 June 2017 / Revised: 19 July 2017 / Accepted: 22 July 2017 / Published: 1 August 2017
PDF Full-text (4554 KB) | HTML Full-text | XML Full-text
Abstract
With the rapid construction of metro tunnels in many metropolises, a fast and convenient solution to capture tunnel deformation is desired by civil engineers. This contribution reports an automatic and wireless tunnel deformation monitoring system using ultrasonic transducers. A processing algorithm of the
[...] Read more.
With the rapid construction of metro tunnels in many metropolises, a fast and convenient solution to capture tunnel deformation is desired by civil engineers. This contribution reports an automatic and wireless tunnel deformation monitoring system using ultrasonic transducers. A processing algorithm of the redundant ultrasonic information (RUI) approach is proposed to improve measurement accuracy. The feasibility of this tunnel deformation monitoring method is carefully examined with various probe angles, distances, and surrounding temperature variations. The results indicate that high accuracy can be achieved with different coefficients for various probe angles and sensor distances, as well as temperatures. In addition, a physical tunnel model was fabricated to verify the new processing algorithm of the RUI approach for a wireless tunnel deformation sensing system. The test results reveal that average measurement errors decreased from 7% to 3.75% using the RUI approach. Therefore, it can be concluded that the proposed approach is well suited to the automatic detection of critical conditions such as large deformation events in metro tunnels. Full article
(This article belongs to the Special Issue Sensors for Deformation Monitoring of Large Civil Infrastructures)
Figures

Figure 1

Open AccessArticle An Adaptive Impedance Matching Network with Closed Loop Control Algorithm for Inductive Wireless Power Transfer
Sensors 2017, 17(8), 1759; doi:10.3390/s17081759
Received: 15 June 2017 / Revised: 13 July 2017 / Accepted: 28 July 2017 / Published: 1 August 2017
PDF Full-text (8381 KB) | HTML Full-text | XML Full-text
Abstract
For an inductive wireless power transfer (IWPT) system, maintaining a reasonable power transfer efficiency and a stable output power are two most challenging design issues, especially when coil distance varies. To solve these issues, this paper presents a novel adaptive impedance matching network
[...] Read more.
For an inductive wireless power transfer (IWPT) system, maintaining a reasonable power transfer efficiency and a stable output power are two most challenging design issues, especially when coil distance varies. To solve these issues, this paper presents a novel adaptive impedance matching network (IMN) for IWPT system. In our adaptive IMN IWPT system, the IMN is automatically reconfigured to keep matching with the coils and to adjust the output power adapting to coil distance variation. A closed loop control algorithm is used to change the capacitors continually, which can compensate mismatches and adjust output power simultaneously. The proposed adaptive IMN IWPT system is working at 125 kHz for 2 W power delivered to load. Comparing with the series resonant IWPT system and fixed IMN IWPT system, the power transfer efficiency of our system increases up to 31.79% and 60% when the coupling coefficient varies in a large range from 0.05 to 0.8 for 2 W output power. Full article
(This article belongs to the Special Issue Wireless Rechargeable Sensor Networks)
Figures

Figure 1

Open AccessArticle A Chip for Estrogen Receptor Action: Detection of Biomarkers Released by MCF-7 Cells through Estrogenic and Anti-Estrogenic Effects
Sensors 2017, 17(8), 1760; doi:10.3390/s17081760
Received: 27 June 2017 / Revised: 26 July 2017 / Accepted: 28 July 2017 / Published: 1 August 2017
PDF Full-text (2655 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
The fluorescence-based multi-analyte chip platform for the analysis of estrogenic and anti-estrogenic substances is a new in vitro tool for the high throughput screening of environmental samples. In contrast to existing tools, the chip investigates the complex action of xenoestrogens in a human
[...] Read more.
The fluorescence-based multi-analyte chip platform for the analysis of estrogenic and anti-estrogenic substances is a new in vitro tool for the high throughput screening of environmental samples. In contrast to existing tools, the chip investigates the complex action of xenoestrogens in a human cell model by characterizing protein expression. It allows for the quantification of 10 proteins secreted by MCF-7 cells, representing various biological and pathological endpoints of endocrine action and distinguishing between estrogen- and anti-estrogen-dependent secretion of proteins. Distinct protein secretion patterns of the cancer cell line after exposure to known estrogen receptor agonists ß-estradiol, bisphenol A, genistein, and nonylphenol as well as antagonists fulvestrant and tamoxifen demonstrate the potential of the chip. Stimulation of cells with Interleukin-1ß shifts concentrations of low abundant biomarkers towards the working range of the chip. In the non-stimulated cell culture, Matrix Metalloproteinase 9 (MMP-9) and Vascular Endothelial Growth Factor (VEGF) show differences upon treatment with antagonists and agonists of the estrogen receptor. In stimulated MCF-7 cells challenged with receptor agonists secretion of Monocyte Chemoattractant Protein (MCP-1), Interleukin-6 (IL-6), Rantes, and Interleukin-8 (IL-8) significantly decreases. In parallel, the proliferating effect of endocrine-disrupting substances in MCF-7 cells is assessed in a proliferation assay based on resazurin. Using ethanol as a solvent for test substances increases the background of proliferation and secretion experiments, while using dimethyl sulfoxide (DMSO) does not show any adverse effects. The role of the selected biomarkers in different physiological processes such as cell development, reproduction, cancer, and metabolic syndrome makes the chip an excellent tool for either indicating endocrine-disrupting effects in food and environmental samples, or for screening the effect of xenoestrogens on a cellular and molecular level. Full article
(This article belongs to the Special Issue Sensors for Toxic and Pathogen Detection)
Figures

Open AccessArticle Optimization Techniques for Design Problems in Selected Areas in WSNs: A Tutorial
Sensors 2017, 17(8), 1761; doi:10.3390/s17081761
Received: 29 May 2017 / Revised: 10 July 2017 / Accepted: 21 July 2017 / Published: 1 August 2017
PDF Full-text (2211 KB) | HTML Full-text | XML Full-text
Abstract
This paper is intended to serve as an overview of, and mostly a tutorial to illustrate, the optimization techniques used in several different key design aspects that have been considered in the literature of wireless sensor networks (WSNs). It targets the researchers who
[...] Read more.
This paper is intended to serve as an overview of, and mostly a tutorial to illustrate, the optimization techniques used in several different key design aspects that have been considered in the literature of wireless sensor networks (WSNs). It targets the researchers who are new to the mathematical optimization tool, and wish to apply it to WSN design problems. We hence divide the paper into two main parts. One part is dedicated to introduce optimization theory and an overview on some of its techniques that could be helpful in design problem in WSNs. In the second part, we present a number of design aspects that we came across in the WSN literature in which mathematical optimization methods have been used in the design. For each design aspect, a key paper is selected, and for each we explain the formulation techniques and the solution methods implemented. We also provide in-depth analyses and assessments of the problem formulations, the corresponding solution techniques and experimental procedures in some of these papers. The analyses and assessments, which are provided in the form of comments, are meant to reflect the points that we believe should be taken into account when using optimization as a tool for design purposes. Full article
(This article belongs to the Section Sensor Networks)
Figures

Figure 1

Open AccessArticle Two Hop Adaptive Vector Based Quality Forwarding for Void Hole Avoidance in Underwater WSNs
Sensors 2017, 17(8), 1762; doi:10.3390/s17081762
Received: 21 May 2017 / Revised: 13 July 2017 / Accepted: 26 July 2017 / Published: 1 August 2017
PDF Full-text (533 KB) | HTML Full-text | XML Full-text
Abstract
Underwater wireless sensor networks (UWSNs) facilitate a wide range of aquatic applications in various domains. However, the harsh underwater environment poses challenges like low bandwidth, long propagation delay, high bit error rate, high deployment cost, irregular topological structure, etc. Node mobility and the
[...] Read more.
Underwater wireless sensor networks (UWSNs) facilitate a wide range of aquatic applications in various domains. However, the harsh underwater environment poses challenges like low bandwidth, long propagation delay, high bit error rate, high deployment cost, irregular topological structure, etc. Node mobility and the uneven distribution of sensor nodes create void holes in UWSNs. Void hole creation has become a critical issue in UWSNs, as it severely affects the network performance. Avoiding void hole creation benefits better coverage over an area, less energy consumption in the network and high throughput. For this purpose, minimization of void hole probability particularly in local sparse regions is focused on in this paper. The two-hop adaptive hop by hop vector-based forwarding (2hop-AHH-VBF) protocol aims to avoid the void hole with the help of two-hop neighbor node information. The other protocol, quality forwarding adaptive hop by hop vector-based forwarding (QF-AHH-VBF), selects an optimal forwarder based on the composite priority function. QF-AHH-VBF improves network good-put because of optimal forwarder selection. QF-AHH-VBF aims to reduce void hole probability by optimally selecting next hop forwarders. To attain better network performance, mathematical problem formulation based on linear programming is performed. Simulation results show that by opting these mechanisms, significant reduction in end-to-end delay and better throughput are achieved in the network. Full article
(This article belongs to the Special Issue Advances and Challenges in Underwater Sensor Networks)
Figures

Figure 1

Open AccessArticle Impedance Matching Antenna-Integrated High-Efficiency Energy Harvesting Circuit
Sensors 2017, 17(8), 1763; doi:10.3390/s17081763
Received: 21 July 2017 / Revised: 27 July 2017 / Accepted: 29 July 2017 / Published: 1 August 2017
PDF Full-text (6346 KB) | HTML Full-text | XML Full-text
Abstract
This paper describes the design of a high-efficiency energy harvesting circuit with an integrated antenna. The circuit is composed of series resonance and boost rectifier circuits for converting radio frequency power into boosted direct current (DC) voltage. The measured output DC voltage is
[...] Read more.
This paper describes the design of a high-efficiency energy harvesting circuit with an integrated antenna. The circuit is composed of series resonance and boost rectifier circuits for converting radio frequency power into boosted direct current (DC) voltage. The measured output DC voltage is 5.67 V for an input of 100 mV at 900 MHz. Antenna input impedance matching is optimized for greater efficiency and miniaturization. The measured efficiency of this antenna-integrated energy harvester is 60% for −4.85 dBm input power and a load resistance equal to 20 kΩ at 905 MHz. Full article
(This article belongs to the Special Issue Wireless Rechargeable Sensor Networks)
Figures

Figure 1

Open AccessArticle Optimization of a VOC Sensor with a Bilayered Diaphragm Using FBAR as Strain Sensing Elements
Sensors 2017, 17(8), 1764; doi:10.3390/s17081764
Received: 5 July 2017 / Revised: 29 July 2017 / Accepted: 1 August 2017 / Published: 1 August 2017
PDF Full-text (2206 KB) | HTML Full-text | XML Full-text
Abstract
Film bulk acoustic resonators (FBARs) are widely applied in mass bio-sensing and pressure sensors, owing to their extreme sensitivity and integration ability, and ability to miniaturize circuits. A volatile organic compound (VOC) sensor with a polymer-coated diaphragm, using FBARs as a strain sensing
[...] Read more.
Film bulk acoustic resonators (FBARs) are widely applied in mass bio-sensing and pressure sensors, owing to their extreme sensitivity and integration ability, and ability to miniaturize circuits. A volatile organic compound (VOC) sensor with a polymer-coated diaphragm, using FBARs as a strain sensing element is proposed and optimized. This vapor sensor is based on organic vapor-induced changes of mechanical deformation of the micro-diaphragm. The four FBARs are located at the edge of the bi-layer diaphragm comprising silicon nitride and silicon oxide for strain extraction. In this work, the strain distribution of the FBAR area under vapor loads is obtained using the finite element analysis (FEA) and the response frequency changes of the FBARs under vapor loads are obtained based on both the first-principle methods to deduce the elastic coefficient variation of aluminum nitride film in FBARs under the bending stresses and the Mason equivalent circuit model of the sensor using ADS software. Finally, optimizations are performed on both the bilayered diaphragm structure and sensing film. The diaphragm with a 0.7 μm silicon nitride layer and a 0.5 μm silicon oxide layer are considered to be the optimized design. The optimal coverage area of the sensing film for the diaphragm is around 0.8. Full article
(This article belongs to the Section Chemical Sensors)
Figures

Figure 1

Open AccessArticle Sensitivity and Frequency-Response Improvement of a Thermal Convection–Based Accelerometer
Sensors 2017, 17(8), 1765; doi:10.3390/s17081765
Received: 26 June 2017 / Revised: 23 July 2017 / Accepted: 28 July 2017 / Published: 2 August 2017
PDF Full-text (3192 KB) | HTML Full-text | XML Full-text
Abstract
This paper presents a thermal convection–based sensor fabricated using simple microelectromechanical systems (MEMS)-based processes. This sensor can be applied to both acceleration and inclination measurements without modifying the structure. Because the operating mechanism of the accelerometer is the thermal convection of a gas
[...] Read more.
This paper presents a thermal convection–based sensor fabricated using simple microelectromechanical systems (MEMS)-based processes. This sensor can be applied to both acceleration and inclination measurements without modifying the structure. Because the operating mechanism of the accelerometer is the thermal convection of a gas medium, a simple model is proposed and developed in which the performance of the thermal convection–based accelerometer is closely associated with the Grashof number, Gr and the Prandtl number, Pr. This paper discusses the experiments that were performed by varying several parameters such as the heating power, cavity size, gas media, and air pressure. The experimental results demonstrate that an increase in the heating power, pressure, and cavity size leads to an increase in the accelerometer sensitivity. However, an increase in the pressure and/or cavity size results in a decrease in the frequency bandwidth. This paper also discusses the fact that a working-gas medium with a large thermal diffusivity and small kinematic viscosity can widen the frequency bandwidth and increase the sensitivity, respectively. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle An Acquisition Scheme Based on a Matched Filter for Novel Communication and Navigation Fusion Signals
Sensors 2017, 17(8), 1766; doi:10.3390/s17081766
Received: 20 June 2017 / Revised: 21 July 2017 / Accepted: 28 July 2017 / Published: 2 August 2017
PDF Full-text (4440 KB) | HTML Full-text | XML Full-text
Abstract
In order to enhance the positioning capability of terrestrial networks, a novel communication and navigation fusion signal is proposed. The novel signal multiplexes the communication and navigation signal in the same frequency band, and the navigation system is superimposed on the original communication
[...] Read more.
In order to enhance the positioning capability of terrestrial networks, a novel communication and navigation fusion signal is proposed. The novel signal multiplexes the communication and navigation signal in the same frequency band, and the navigation system is superimposed on the original communication system. However, the application of pseudorandom noise (PRN) sequences in the navigation system is limited by the communication clock period. Taking the application of PRN sequences limited by the clock period as objects, the present study analyzes truncated PRN (TPRN) sequences. PRN sequences with a TPRN sequence as the navigation signal can overcome the communication system clock period limitation. Then, a matched filter algorithm with double detection (MFADD) is proposed to acquire the novel signal. The matched filter method is applied to the proposed algorithm to determine the start code phase of TPRN. Monte Carlo simulations and real data tests demonstrate the effectiveness of the proposed algorithm for the designed signal. Full article
Figures

Figure 1

Open AccessArticle Integrating Optimal Heterogeneous Sensor Deployment and Operation Strategies for Dynamic Origin-Destination Demand Estimation
Sensors 2017, 17(8), 1767; doi:10.3390/s17081767
Received: 5 June 2017 / Revised: 25 July 2017 / Accepted: 29 July 2017 / Published: 2 August 2017
PDF Full-text (1023 KB) | HTML Full-text | XML Full-text
Abstract
Most existing network sensor location problem (NSLP) models are designed to identify the number of sensors with fixed costs and installation locations, and sensors are assumed to be installed permanently. However, sometimes sensors are carried by individuals to collect traffic data measurements manually
[...] Read more.
Most existing network sensor location problem (NSLP) models are designed to identify the number of sensors with fixed costs and installation locations, and sensors are assumed to be installed permanently. However, sometimes sensors are carried by individuals to collect traffic data measurements manually at fixed locations. Hence, their duration of operation for which traffic data measurements are collected is limited, and their costs are not fixed as they are correlated with the duration of operation. This paper proposes a NSLP model that integrates optimal heterogeneous sensor deployment and operation strategies for the dynamic O-D demand estimates under budget constraints. The deployment strategy consists of the numbers of link and node sensors and their installation locations. The operation strategy includes sensors’ start time and duration of operation, which has not been addressed in previous studies. An algorithm is developed to solve the proposed model. Numerical experiments performed on a network from a part of Chennai, India show that the proposed model can identify the optimal heterogeneous sensor deployment and operation strategies with the maximum dynamic O-D demand estimation accuracy. Full article
(This article belongs to the Section Sensor Networks)
Figures

Figure 1

Open AccessArticle A Magnetic-Balanced Inductive Link for the Simultaneous Uplink Data and Power Telemetry
Sensors 2017, 17(8), 1768; doi:10.3390/s17081768
Received: 12 July 2017 / Revised: 30 July 2017 / Accepted: 30 July 2017 / Published: 2 August 2017
PDF Full-text (2487 KB) | HTML Full-text | XML Full-text
Abstract
When using the conventional two-coil inductive link for the simultaneous wireless power and data transmissions in implantable biomedical sensor devices, the strong power carrier could overwhelm the uplink data signal and even saturate the external uplink receiver. To address this problem, we propose
[...] Read more.
When using the conventional two-coil inductive link for the simultaneous wireless power and data transmissions in implantable biomedical sensor devices, the strong power carrier could overwhelm the uplink data signal and even saturate the external uplink receiver. To address this problem, we propose a new magnetic-balanced inductive link for our implantable glaucoma treatment device. In this inductive link, an extra coil is specially added for the uplink receiving. The strong power carrier interference is minimized to approach zero by balanced canceling of the magnetic field of the external power coil. The implant coil is shared by the wireless power harvesting and the uplink data transmitting. Two carriers (i.e., 2-MHz power carrier and 500-kHz uplink carrier) are used for the wireless power transmission and the uplink data transmission separately. In the experiments, the prototype of this link achieves as high as 65.72 dB improvement of the signal-to-interference ratio (SIR) compared with the conventional two-coil inductive link. Benefiting from the significant improvement of SIR, the implant transmitter costs only 0.2 mW of power carrying 50 kbps of binary phase shift keying data and gets a bit error rate of 1 × 10 7 , even though the coupling coefficient is as low as 0.005. At the same time, 5 mW is delivered to the load with maximum power transfer efficiency of 58.8%. This magnetic-balanced inductive link is useful for small-sized biomedical sensor devices, which require transmitting data and power simultaneously under ultra-weak coupling. Full article
Figures

Figure 1

Open AccessArticle A Simple and Inexpensive Electrochemical Assay for the Identification of Nitrogen Containing Explosives in the Field
Sensors 2017, 17(8), 1769; doi:10.3390/s17081769
Received: 11 July 2017 / Revised: 27 July 2017 / Accepted: 31 July 2017 / Published: 2 August 2017
PDF Full-text (5009 KB) | HTML Full-text | XML Full-text
Abstract
We report a simple and inexpensive electrochemical assay using a custom built hand-held potentiostat for the identification of explosives. The assay is based on a wipe test and is specifically designed for use in the field. The prototype instrument designed to run the
[...] Read more.
We report a simple and inexpensive electrochemical assay using a custom built hand-held potentiostat for the identification of explosives. The assay is based on a wipe test and is specifically designed for use in the field. The prototype instrument designed to run the assay is capable of performing time-resolved electrochemical measurements including cyclic square wave voltammetry using an embedded microcontroller with parts costing roughly $250 USD. We generated an example library of cyclic square wave voltammograms of 12 compounds including 10 nitroaromatics, a nitramine (RDX), and a nitrate ester (nitroglycine), and designed a simple discrimination algorithm based on this library data for identification. Full article
(This article belongs to the Section Chemical Sensors)
Figures

Figure 1

Open AccessArticle Hybrid Structure Multichannel All-Fiber Current Sensor
Sensors 2017, 17(8), 1770; doi:10.3390/s17081770
Received: 21 June 2017 / Revised: 27 July 2017 / Accepted: 28 July 2017 / Published: 2 August 2017
PDF Full-text (3075 KB) | HTML Full-text | XML Full-text
Abstract
We have experimentally developed a hybrid-structure multi-channel all-fiber current sensor with ordinary silica fiber using fiber loop architecture. According to the rationale of time division multiplexing, the sensor combines parallel and serial structures. The purpose of the hybrid-structure multi-channel all-fiber current sensor is
[...] Read more.
We have experimentally developed a hybrid-structure multi-channel all-fiber current sensor with ordinary silica fiber using fiber loop architecture. According to the rationale of time division multiplexing, the sensor combines parallel and serial structures. The purpose of the hybrid-structure multi-channel all-fiber current sensor is to get more information from the different measured points simultaneously. In addition, the hybrid-structure fiber current sensor exhibited a good linear response for each channel. A three-channel experiment was performed in the study and showed that the system could detect different current positions. Each channel could individually detect the current and needed a separate calibration system. Furthermore, the three channels will not affect each other. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle Barrier Coverage for 3D Camera Sensor Networks
Sensors 2017, 17(8), 1771; doi:10.3390/s17081771
Received: 18 June 2017 / Revised: 18 July 2017 / Accepted: 25 July 2017 / Published: 3 August 2017
PDF Full-text (5961 KB) | HTML Full-text | XML Full-text
Abstract
Barrier coverage, an important research area with respect to camera sensor networks, consists of a number of camera sensors to detect intruders that pass through the barrier area. Existing works on barrier coverage such as local face-view barrier coverage and full-view barrier coverage
[...] Read more.
Barrier coverage, an important research area with respect to camera sensor networks, consists of a number of camera sensors to detect intruders that pass through the barrier area. Existing works on barrier coverage such as local face-view barrier coverage and full-view barrier coverage typically assume that each intruder is considered as a point. However, the crucial feature (e.g., size) of the intruder should be taken into account in the real-world applications. In this paper, we propose a realistic resolution criterion based on a three-dimensional (3D) sensing model of a camera sensor for capturing the intruder’s face. Based on the new resolution criterion, we study the barrier coverage of a feasible deployment strategy in camera sensor networks. Performance results demonstrate that our barrier coverage with more practical considerations is capable of providing a desirable surveillance level. Moreover, compared with local face-view barrier coverage and full-view barrier coverage, our barrier coverage is more reasonable and closer to reality. To the best of our knowledge, our work is the first to propose barrier coverage for 3D camera sensor networks. Full article
(This article belongs to the Section Sensor Networks)
Figures

Figure 1

Open AccessArticle Hyperspectral and Radar Airborne Imagery over Controlled Release of Oil at Sea
Sensors 2017, 17(8), 1772; doi:10.3390/s17081772
Received: 28 June 2017 / Revised: 21 July 2017 / Accepted: 25 July 2017 / Published: 2 August 2017
PDF Full-text (17220 KB) | HTML Full-text | XML Full-text
Abstract
Remote sensing techniques are commonly used by Oil and Gas companies to monitor hydrocarbon on the ocean surface. The interest lies not only in exploration but also in the monitoring of the maritime environment. Occurrence of natural seeps on the sea surface is
[...] Read more.
Remote sensing techniques are commonly used by Oil and Gas companies to monitor hydrocarbon on the ocean surface. The interest lies not only in exploration but also in the monitoring of the maritime environment. Occurrence of natural seeps on the sea surface is a key indicator of the presence of mature source rock in the subsurface. These natural seeps, as well as the oil slicks, are commonly detected using radar sensors but the addition of optical imagery can deliver extra information such as thickness and composition of the detected oil, which is critical for both exploration purposes and efficient cleanup operations. Today, state-of-the-art approaches combine multiple data collected by optical and radar sensors embedded on-board different airborne and spaceborne platforms, to ensure wide spatial coverage and high frequency revisit time. Multi-wavelength imaging system may create a breakthrough in remote sensing applications, but it requires adapted processing techniques that need to be developed. To explore performances offered by multi-wavelength radar and optical sensors for oil slick monitoring, remote sensing data have been collected by SETHI (Système Expérimental de Télédection Hyperfréquence Imageur), the airborne system developed by ONERA (the French Aerospace Lab), during an oil spill cleanup exercise carried out in 2015 in the North Sea, Europe. The uniqueness of this dataset lies in its high spatial resolution, low noise level and quasi-simultaneous acquisitions of different part of the EM spectrum. Specific processing techniques have been developed to extract meaningful information associated with oil-covered sea surface. Analysis of this unique and rich dataset demonstrates that remote sensing imagery, collected in both optical and microwave domains, allows estimating slick surface properties such as the age of the emulsion released at sea, the spatial abundance of oil and the relative concentration of hydrocarbons remaining on the sea surface. Full article
(This article belongs to the Special Issue Sensors for Oil Applications)
Figures

Figure 1

Open AccessArticle Full-Duplex Cooperative Sensing for Spectrum-Heterogeneous Cognitive Radio Networks
Sensors 2017, 17(8), 1773; doi:10.3390/s17081773
Received: 10 July 2017 / Revised: 28 July 2017 / Accepted: 31 July 2017 / Published: 2 August 2017
PDF Full-text (1778 KB) | HTML Full-text | XML Full-text
Abstract
In cognitive radio networks (CRNs), spectrum sensing is critical for guaranteeing that the opportunistic spectrum access by secondary users (SUs) will not interrupt legitimate primary users (PUs). The application of full-duplex radio to spectrum sensing enables SU to carry out sensing and transmission
[...] Read more.
In cognitive radio networks (CRNs), spectrum sensing is critical for guaranteeing that the opportunistic spectrum access by secondary users (SUs) will not interrupt legitimate primary users (PUs). The application of full-duplex radio to spectrum sensing enables SU to carry out sensing and transmission simultaneously, improving both spectrum awareness and CRN throughput. However, the issue of spectrum sensing with full-duplex radios deployed in heterogeneous environments, where SUs may observe different spectrum activities, has not been addressed. In this paper, we give a first look into this problem and develop a light-weight cooperative sensing framework called PaCoSIF, which involves only a pairwise SU transmitter (SU-Tx) and its receiver (SU-Rx) in cooperation. A dedicated control channel is not required for pairwise cooperative sensing with instantaneous feedback (PaCoSIF) because sensing results are collected and fused via the reverse channel provided by full-duplex radios. We present a detailed protocol description to illustrate how PaCoSIF works. However, it is a challenge to optimize the sensing performance of PaCoSIF since the two sensors suffer from spectrum heterogeneity and different kinds of interference. Our goal is to minimize the false alarm rate of PaCoSIF given the bound on the missed detection rate by adaptively adjusting the detection threshold of each sensor. We derive an expression for the optimal threshold using the Lagrange method and propose a fast binary-searching algorithm to solve it numerically. Simulations show that, with perfect signal-to-interference-and-noise-ratio (SINR) information, PaCoSIF could decrease the false alarm rate and boost CRN throughput significantly against conventional cooperative sensing when SUs are deployed in spectrum-heterogeneous environments. Finally, the impact of SINR error upon the performance of PaCoSIF is evaluated via extensive simulations. Full article
(This article belongs to the Special Issue Cognitive Radio Sensing and Sensor Networks)
Figures

Figure 1

Open AccessArticle Parametric Optimization of Lateral NIPIN Phototransistors for Flexible Image Sensors
Sensors 2017, 17(8), 1774; doi:10.3390/s17081774
Received: 29 June 2017 / Revised: 28 July 2017 / Accepted: 29 July 2017 / Published: 2 August 2017
PDF Full-text (2407 KB) | HTML Full-text | XML Full-text
Abstract
Curved image sensors, which are a key component in bio-inspired imaging systems, have been widely studied because they can improve an imaging system in various aspects such as low optical aberrations, small-form, and simple optics configuration. Many methods and materials to realize a
[...] Read more.
Curved image sensors, which are a key component in bio-inspired imaging systems, have been widely studied because they can improve an imaging system in various aspects such as low optical aberrations, small-form, and simple optics configuration. Many methods and materials to realize a curvilinear imager have been proposed to address the drawbacks of conventional imaging/optical systems. However, there have been few theoretical studies in terms of electronics on the use of a lateral photodetector as a flexible image sensor. In this paper, we demonstrate the applicability of a Si-based lateral phototransistor as the pixel of a high-efficiency curved photodetector by conducting various electrical simulations with technology computer aided design (TCAD). The single phototransistor is analyzed with different device parameters: the thickness of the active cell, doping concentration, and structure geometry. This work presents a method to improve the external quantum efficiency (EQE), linear dynamic range (LDR), and mechanical stability of the phototransistor. We also evaluated the dark current in a matrix form of phototransistors to estimate the feasibility of the device as a flexible image sensor. Moreover, we fabricated and demonstrated an array of phototransistors based on our study. The theoretical study and design guidelines of a lateral phototransistor create new opportunities in flexible image sensors. Full article
(This article belongs to the Special Issue Flexible Electronics and Sensors)
