Energies, Volume 11, Issue 2 (February 2018)

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Cover Story (view full-size image) Axial turbocharger turbines have, in recent years, become viable alternatives to radial turbines [...] Read more.
View options order results:
result details:
Displaying articles 1-215
Export citation of selected articles as:
Open AccessArticle Estimation of the Diesel Particulate Filter Soot Load Based on an Equivalent Circuit Model
Energies 2018, 11(2), 472; https://doi.org/10.3390/en11020472
Received: 31 January 2018 / Revised: 16 February 2018 / Accepted: 21 February 2018 / Published: 23 February 2018
PDF Full-text (1967 KB) | HTML Full-text | XML Full-text
Abstract
In order to estimate the diesel particulate filter (DPF) soot load and improve the accuracy of regeneration timing, a novel method based on an equivalent circuit model is proposed based on the electric-fluid analogy. This proposed method can reduce the impact of the
[...] Read more.
In order to estimate the diesel particulate filter (DPF) soot load and improve the accuracy of regeneration timing, a novel method based on an equivalent circuit model is proposed based on the electric-fluid analogy. This proposed method can reduce the impact of the engine transient operation on the soot load, accurately calculate the flow resistance, and improve the estimation accuracy of the soot load. Firstly, the least square method is used to identify the flow resistance based on the World Harmonized Transient Cycle (WHTC) test data, and the relationship between flow resistance, exhaust temperature and soot load is established. Secondly, the online estimation of the soot load is achieved by using the dual extended Kalman filter (DEKF). The results show that this method has good convergence and robustness with the maximal absolute error of 0.2 g/L at regeneration timing, which can meet engineering requirements. Additionally, this method can estimate the soot load under engine transient operating conditions and avoids a large number of experimental tests, extensive calibration and the analysis of complex chemical reactions required in traditional methods. Full article
Figures

Figure 1

Open AccessArticle Analysis of dc-Link Voltage Switching Ripple in Three-Phase PWM Inverters
Energies 2018, 11(2), 471; https://doi.org/10.3390/en11020471
Received: 6 February 2018 / Revised: 19 February 2018 / Accepted: 21 February 2018 / Published: 23 February 2018
PDF Full-text (6132 KB) | HTML Full-text | XML Full-text
Abstract
The three-phase voltage source inverter (VSI) is de facto standard in power conversion systems. To realize high power density systems, one of the items to be correctly addressed is the design and selection of the dc-link capacitor in relation to the voltage switching
[...] Read more.
The three-phase voltage source inverter (VSI) is de facto standard in power conversion systems. To realize high power density systems, one of the items to be correctly addressed is the design and selection of the dc-link capacitor in relation to the voltage switching ripple. In this paper, effective formulas for designing the dc-link capacitor as a function of the switching voltage ripple amplitude are obtained, considering the operating conditions such as the modulation index and the output current amplitude. The calculations are obtained considering the requirements and restrictions referring to the high (switching)-frequency dc-link voltage ripple component. Analyses have been performed considering the dc source impedance (non-ideal dc voltage source at the switching frequency) and a balanced load. Analytical expressions are derived for the dc-link voltage switching ripple amplitude and its maximum value over the fundamental period. Different values of modulation index and output phase angle have been considered and different diagrams are presented. Analytical results were validated both by simulations and comprehensive experimental tests. Full article
Figures

Figure 1

Open AccessArticle Analysis of Switching Transients during Energization in Large Offshore Wind Farms
Energies 2018, 11(2), 470; https://doi.org/10.3390/en11020470
Received: 24 January 2018 / Revised: 13 February 2018 / Accepted: 19 February 2018 / Published: 23 February 2018
Cited by 1 | PDF Full-text (4323 KB) | HTML Full-text | XML Full-text
Abstract
In order to study switching transients in an offshore wind farm (OWF) collector system, we employ modeling methods of the main components in OWFs, including vacuum circuit breakers (VCBs), submarine cables, and wind turbine transformers (WTTs). In particular, a high frequency (HF) VCB
[...] Read more.
In order to study switching transients in an offshore wind farm (OWF) collector system, we employ modeling methods of the main components in OWFs, including vacuum circuit breakers (VCBs), submarine cables, and wind turbine transformers (WTTs). In particular, a high frequency (HF) VCB model that reflects the prestrike characteristics of VCBs was developed. Moreover, a simplified experimental system of an OWF electric collection system was set up to verify the developed models, and a typical OWF medium voltage (MV) cable collection system was built in PSCAD/EMTDC based on the developed models. Finally, we investigated the influences of both the initial closing phase angle of VCBs and typical system operation scenarios on the amplitude and steepness of transient overvoltages (TOVs) at the high-voltage side of WTTs. Full article
Figures

Figure 1

Open AccessArticle A PSO-Optimized Fuzzy Logic Control-Based Charging Method for Individual Household Battery Storage Systems within a Community
Energies 2018, 11(2), 469; https://doi.org/10.3390/en11020469
Received: 24 January 2018 / Revised: 13 February 2018 / Accepted: 16 February 2018 / Published: 23 February 2018
PDF Full-text (7150 KB) | HTML Full-text | XML Full-text
Abstract
Self-consumption of household photovoltaic (PV) storage systems has become profitable for residential owners under the trends of limited feed-in power and decreasing PV feed-in tariffs. For individual PV-storage systems, the challenge mainly lies in managing surplus generation of battery and grid power flow,
[...] Read more.
Self-consumption of household photovoltaic (PV) storage systems has become profitable for residential owners under the trends of limited feed-in power and decreasing PV feed-in tariffs. For individual PV-storage systems, the challenge mainly lies in managing surplus generation of battery and grid power flow, ideally without relying on error-prone forecasts for both generation and consumption. Considering the large variation in power profiles of different houses in a neighborhood, the strategy is also supposed to be beneficial and applicable for the entire community. In this study, an adaptable battery charging control strategy is designed in order to obtain minimum costs for houses without any meteorological or load forecasts. Based on fuzzy logic control (FLC), battery state-of-charge (SOC) and the variation of SOC (∆SOC) are taken as input variables to dynamically determine output charging power with minimum costs. The proposed FLC-based algorithm benefits from the charging battery as much as possible during the daytime, and meanwhile properly preserves the capacity at midday when there is high possibility of curtailment loss. In addition, due to distinct power profiles in each individual house, input membership functions of FLC are improved by particle swarm optimization (PSO) to achieve better overall performance. A neighborhood with 74 houses in Germany is set up as a scenario for comparison to prior studies. Without forecasts of generation and consumption power, the proposed method leads to minimum costs in 98.6% of houses in the community, and attains the lowest average expenses for a single house each year. Full article
(This article belongs to the Section Electrical Power and Energy System)
Figures

Figure 1

Open AccessArticle Multi-Rate and Parallel Electromagnetic Transient Simulation Considering Nonlinear Characteristics of a Power System
Energies 2018, 11(2), 468; https://doi.org/10.3390/en11020468
Received: 27 November 2017 / Revised: 24 January 2018 / Accepted: 31 January 2018 / Published: 23 February 2018
PDF Full-text (3074 KB) | HTML Full-text | XML Full-text
Abstract
The electromagnetic transient simulation of a power system with nonlinear characteristics is very time-consuming due to numerous inversion calculations of the admittance matrix. To speed up the simulation of the power system with nonlinear characteristics, a multi-rate and parallel electromagnetic transient simulation method
[...] Read more.
The electromagnetic transient simulation of a power system with nonlinear characteristics is very time-consuming due to numerous inversion calculations of the admittance matrix. To speed up the simulation of the power system with nonlinear characteristics, a multi-rate and parallel electromagnetic transient simulation method is proposed. Firstly, a Multi-Area Thevenin Equivalents (MATE)-based parallel algorithm considering nonlinear characteristics of the power system is proposed. This method guarantees the admittance matrix is constant by considering changing branches as link current without dividing the subnet again. Secondly, considering the differences of the time constant of the AC/DC subnet, different simulation steps are used for these subnets. The Lagrange interpolation method is used for calculating the Thevenin voltage of the AC subnet in non-synchronous time. Calculation methods of the DC subnet Thevenin voltage is proposed by considering the simulation results during the entire large simulation step. Finally, the simulation process is optimized for improving the simulation efficiency further. The simulation results show that the proposed method could greatly improve the simulation efficiency without losing simulation accuracy too much compared with the traditional method. Full article
Figures

Figure 1

Open AccessArticle Experimental Determination of Gas Relative Permeability Considering Slippage Effect in a Tight Formation
Energies 2018, 11(2), 467; https://doi.org/10.3390/en11020467
Received: 1 February 2018 / Revised: 17 February 2018 / Accepted: 19 February 2018 / Published: 23 February 2018
PDF Full-text (8295 KB) | HTML Full-text | XML Full-text
Abstract
In this paper, the gas relative permeability considering slippage effect has been experimentally examined under various experimental conditions (i.e., ambient, high confining pressure, and high temperature). Experimentally, Klinkenberg permeabilities of 12 core samples have been measured by using steady-state flow experiment. It has
[...] Read more.
In this paper, the gas relative permeability considering slippage effect has been experimentally examined under various experimental conditions (i.e., ambient, high confining pressure, and high temperature). Experimentally, Klinkenberg permeabilities of 12 core samples have been measured by using steady-state flow experiment. It has been found that the Klinkenberg permeability is independent of the experimental temperature and dramatically decreases as confining pressure is increasing. Furthermore, linear correlations have been newly developed between the Klinkenberg permeability and the gas-measured permeability under various conditions. Subsequently, the developed correlations are correspondingly applied to calibrate the gas relative permeability. It has been found that the gas relative permeability can be overestimated without consideration of the slippage effect, i.e., Klinkenberg effect. In addition, the newly developed correlations have been applied to analyze the sensitivity of gas–water relative permeability to gas-measured permeability, confining pressure, and temperature. It is demonstrated that mobile water greatly alleviates the gas relative permeability in comparison to irreducible water. Although an increased confining pressure simultaneously reduces the effective water phase and gas phase permeability, the gas relative permeability increases and the water relative permeability decreases as the confining pressure increases. It is attributed to the fact that the effective water phase permeability is more sensitive to the confining pressure. Given an elevated experimental temperature, the gas relative permeability is reduced while the water relative permeability is enhanced, implying the significance of temperature effect on gas–water relative permeability measurements. Full article
Figures

Figure 1

Open AccessArticle Composite Reliability Evaluation of Load Demand Side Management and Dynamic Thermal Rating Systems
Energies 2018, 11(2), 466; https://doi.org/10.3390/en11020466
Received: 23 January 2018 / Revised: 9 February 2018 / Accepted: 9 February 2018 / Published: 23 February 2018
Cited by 1 | PDF Full-text (3149 KB) | HTML Full-text | XML Full-text
Abstract
Electric power utilities across the globe are facing higher demand for electricity than ever before, while juggling to balance environmental conservation with transmission corridor expansions. Demand side management (DSM) and dynamic thermal rating systems (DTR) play an important role in alleviating some of
[...] Read more.
Electric power utilities across the globe are facing higher demand for electricity than ever before, while juggling to balance environmental conservation with transmission corridor expansions. Demand side management (DSM) and dynamic thermal rating systems (DTR) play an important role in alleviating some of the challenges faced by electric power utilities. In this paper, various DSM measures are explored and their interactions with the application of the DTR system in the transmission network are examined. The proposed modelling of DSM in this paper implements load shifting on load demand curves from the system, bus and load sector levels. The correlation effects of line ratings are considered in the DTR system modelling as the weather that influences line ratings is also correlated. The modelling of the line ratings was performed using the time series method, the auto regressive moving average (ARMA) model. Both the DSM and the DTR systems were implemented on the modified IEEE reliability test network. The modification was achieved by developing a load model starting from the perspective of the load sectors at each bus and a new collective hourly load curve for the system was obtained by combining the loads at all buses. Finally, the results in this paper elucidate the interaction of DSM and DTR systems. Full article
(This article belongs to the Section Electrical Power and Energy System)
Figures

Figure 1

Open AccessArticle PV Hosting Capacity Dependence on Harmonic Voltage Distortion in Low-Voltage Grids: Model Validation with Experimental Data
Energies 2018, 11(2), 465; https://doi.org/10.3390/en11020465
Received: 29 January 2018 / Revised: 15 February 2018 / Accepted: 19 February 2018 / Published: 23 February 2018
PDF Full-text (2409 KB) | HTML Full-text | XML Full-text
Abstract
This paper introduces a brief analysis on hosting capacity and related concepts as applied to distribution network systems. Furthermore, it addresses the applicability of hosting capacity study methodologies to harmonic voltage distortion caused by photovoltaic panels (PV) connected at a low-voltage (LV) side
[...] Read more.
This paper introduces a brief analysis on hosting capacity and related concepts as applied to distribution network systems. Furthermore, it addresses the applicability of hosting capacity study methodologies to harmonic voltage distortion caused by photovoltaic panels (PV) connected at a low-voltage (LV) side of a university campus grid. The analysis of the penetration of new distributed generation technologies, such as PV panels, in the distribution grid of the campus was carried out via measurement processes, and later by computer simulations analyzing a new concept of the hosting capacity approach in relation to voltage harmonics distortion. The voltage rise due to harmonic injection is analyzed and discussed with the aim of validating the discussed model and also putting forward recommendations for connecting PV generation across other network systems. Full article
(This article belongs to the Special Issue Distributed and Renewable Power Generation)
Figures

Figure 1

Open AccessArticle Modulation Strategy of a 3 × 5 Modular Multilevel Matrix Converter
Energies 2018, 11(2), 464; https://doi.org/10.3390/en11020464
Received: 2 January 2018 / Revised: 8 February 2018 / Accepted: 9 February 2018 / Published: 23 February 2018
PDF Full-text (6957 KB) | HTML Full-text | XML Full-text
Abstract
In this paper, a modulation strategy of a 3 × 5 modular multilevel matrix converter (M3C) is proposed. The circuit of 3 × 5 M3C is firstly introduced. Then, operation rules of 3 × 5 M3C are illustrated, and a connection pattern of
[...] Read more.
In this paper, a modulation strategy of a 3 × 5 modular multilevel matrix converter (M3C) is proposed. The circuit of 3 × 5 M3C is firstly introduced. Then, operation rules of 3 × 5 M3C are illustrated, and a connection pattern of branches is determined based on these rules. Different voltage states in the input and output side can be achieved by different connection patterns. These voltage states are represented in the form of vector. It is hard to synthesize five-phase output with the three-level synthesis method. Therefore, the five-level synthesis method is adopted in this paper; i.e., is the branch states have been increased. Ten effective vectors and a zero vector are selected based on the five-level synthesis method. With this modulation strategy, we achieve output line-to-line voltages that are in line with the trend of a sine wave. The segment division and duty cycle calculation are very simple, and the modulation strategy can be implemented easily. The simulation model of 3 × 5 M3C is constructed based on Matlab/Simulink, and the corresponding experimental platform is set up. The results of simulation and experiment show that the proposed method is reasonable and correct. Full article
Figures

Figure 1

Open AccessArticle A Comprehensive Energy Analysis and Related Carbon Footprint of Dairy Farms, Part 2: Investigation and Modeling of Indirect Energy Requirements
Energies 2018, 11(2), 463; https://doi.org/10.3390/en11020463
Received: 22 December 2017 / Revised: 8 February 2018 / Accepted: 13 February 2018 / Published: 22 February 2018
PDF Full-text (1508 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Dairy cattle farms are continuously developing more intensive systems of management, which require higher utilization of durable and non-durable inputs. These inputs are responsible for significant direct and indirect fossil energy requirements, which are related to remarkable emissions of CO2. This
[...] Read more.
Dairy cattle farms are continuously developing more intensive systems of management, which require higher utilization of durable and non-durable inputs. These inputs are responsible for significant direct and indirect fossil energy requirements, which are related to remarkable emissions of CO2. This study focused on investigating the indirect energy requirements of 285 conventional dairy farms and the related carbon footprint. A detailed analysis of the indirect energy inputs related to farm buildings, machinery and agricultural inputs was carried out. A partial life cycle assessment approach was carried out to evaluate indirect energy inputs and the carbon footprint of farms over a period of one harvest year. The investigation highlights the importance and the weight related to the use of agricultural inputs, which represent more than 80% of the total indirect energy requirements. Moreover, the analyses carried out underline that the assumption of similarity in terms of requirements of indirect energy and related carbon emissions among dairy farms is incorrect especially when observing different farm sizes and milk production levels. Moreover, a mathematical model to estimate the indirect energy requirements of dairy farms has been developed in order to provide an instrument allowing researchers to assess the energy incorporated into farm machinery, agricultural inputs and buildings. Combining the results of this two-part series, the total energy demand (expressed in GJ per farm) results in being mostly due to agricultural inputs and fuel consumption, which have the largest share of the annual requirements for each milk yield class. Direct and indirect energy requirements increased, going from small sized farms to larger ones, from 1302–5109 GJ·y−1, respectively. However, the related carbon dioxide emissions expressed per 100 kg of milk showed a negative trend going from class <5000 to >9000 kg of milk yield, where larger farms were able to emit 48% less carbon dioxide than small herd size farm (43 vs. 82 kg CO2-eq per 100 kg Fat- and Protein-Corrected Milk (FPCM)). Decreasing direct and indirect energy requirements allowed reducing the anthropogenic gas emissions to the environment, reducing the energy costs for dairy farms and improving the efficient utilization of natural resources. Full article
Figures

Figure 1

Open AccessArticle Fuzzy Logic-Based Perturb and Observe Algorithm with Variable Step of a Reference Voltage for Solar Permanent Magnet Synchronous Motor Drive System Fed by Direct-Connected Photovoltaic Array
Energies 2018, 11(2), 462; https://doi.org/10.3390/en11020462
Received: 17 January 2018 / Revised: 14 February 2018 / Accepted: 14 February 2018 / Published: 22 February 2018
PDF Full-text (2462 KB) | HTML Full-text | XML Full-text
Abstract
Photovoltaic pumping is considered to be the most used application amongst other photovoltaic energy applications in isolated sites. This technology is developing with a slow progression to allow the photovoltaic system to operate at its maximum power. This work introduces the modified algorithm
[...] Read more.
Photovoltaic pumping is considered to be the most used application amongst other photovoltaic energy applications in isolated sites. This technology is developing with a slow progression to allow the photovoltaic system to operate at its maximum power. This work introduces the modified algorithm which is a perturb and observe (P&O) type to overcome the limitations of the conventional P&O algorithm and increase its global performance in abrupt weather condition changes. The most significant conventional P&O algorithm restriction is the difficulty faced when choosing the variable step of the reference voltage value, a good compromise between the swift dynamic response and the stability in the steady state. To adjust the step reference voltage according to the location of the operating point of the maximum power point (MPP), a fuzzy logic controller (FLC) block adapted to the P&O algorithm is used. This allows the improvement of the tracking pace and the steady state oscillation elimination. The suggested method was evaluated by simulation using MATLAB/SimPowerSystems blocks and compared to the classical P&O under different irradiation levels. The results obtained show the effectiveness of the technique proposed and its capacity for the practical and efficient tracking of maximum power. Full article
Figures

Figure 1

Open AccessArticle A Steady-State Analysis Method for Modular Multilevel Converters Connected to Permanent Magnet Synchronous Generator-Based Wind Energy Conversion Systems
Energies 2018, 11(2), 461; https://doi.org/10.3390/en11020461
Received: 23 January 2018 / Revised: 10 February 2018 / Accepted: 20 February 2018 / Published: 22 February 2018
Cited by 1 | PDF Full-text (13279 KB) | HTML Full-text | XML Full-text
Abstract
Modular multilevel converters (MMCs) have shown great potential in the area of multi-megawatt wind energy conversion system (WECS) based on permanent magnet synchronous generators (PMSGs). However, the studies in this area are few, and most of them refer to the MMC used in
[...] Read more.
Modular multilevel converters (MMCs) have shown great potential in the area of multi-megawatt wind energy conversion system (WECS) based on permanent magnet synchronous generators (PMSGs). However, the studies in this area are few, and most of them refer to the MMC used in high-voltage direct current (HVDC) systems, and hence the characteristics of the PMSG are not considered. This paper proposes a steady-state analysis method for MMCs connected to a PMSG-based WECS. In the proposed method, only the wind speed (operating condition) is required as input, and all the electrical quantities in the MMC, including the amplitudes, phase angles and their harmonics, can be calculated step by step. The analysis method is built on the proposed d-q frame mathematical model. Interactions of electrical quantities between the MMC and PMSG are comprehensively considered. Moreover, a new way to calculate the average switching functions are adopted in order to improve the accuracy of the analysis method. Applications of the proposed method are also presented, which includes the characteristic analysis of capacitor voltage ripples and the capacitor sizing. Finally, the accuracy of the method and the correctness of the analysis are verified by simulations and experiments. Full article
(This article belongs to the Section Electrical Power and Energy System)
Figures

Graphical abstract

Open AccessFeature PaperArticle Estimation of Effective Diffusion Coefficient of O2 in Ash Layer in Underground Coal Gasification by Thermogravimetric Apparatus
Energies 2018, 11(2), 460; https://doi.org/10.3390/en11020460
Received: 28 January 2018 / Revised: 14 February 2018 / Accepted: 14 February 2018 / Published: 22 February 2018
Cited by 1 | PDF Full-text (5051 KB) | HTML Full-text | XML Full-text
Abstract
Underground coal gasification (UCG) proceeds generally in the presence of an ash layer on coal (or char) surface. The ash layer increases the mass transfer resistance of O2 to the gasification surface, which may become the limiting step of whole process. This
[...] Read more.
Underground coal gasification (UCG) proceeds generally in the presence of an ash layer on coal (or char) surface. The ash layer increases the mass transfer resistance of O2 to the gasification surface, which may become the limiting step of whole process. This paper studies O2 diffusion in ash layer formed on cylindrical char samples using a specially designed one-dimension setup in a thermogravimetric apparatus (TGA). The effective internal diffusion coefficient (De) is found to increase with an increase in ash layer thickness, due to an increase in median pore diameter. Methods are established to correlate De with operating conditions and to estimate the role of internal diffusion resistance in overall mass transfer resistance. Full article
(This article belongs to the Special Issue Biomass Chars: Elaboration, Characterization and Applications Ⅱ)
Figures

Figure 1

Open AccessArticle Real-Time Genetic Algorithms-Based MPPT: Study and Comparison (Theoretical an Experimental) with Conventional Methods
Energies 2018, 11(2), 459; https://doi.org/10.3390/en11020459
Received: 9 January 2018 / Revised: 19 February 2018 / Accepted: 20 February 2018 / Published: 22 February 2018
PDF Full-text (16671 KB) | HTML Full-text | XML Full-text
Abstract
Maximum Power Point Tracking (MPPT) methods are used in photovoltaic (PV) systems to continually maximize the PV array output power, which strongly depends on both solar radiation and cell temperature. The PV power oscillations around the maximum power point (MPP) resulting from the
[...] Read more.
Maximum Power Point Tracking (MPPT) methods are used in photovoltaic (PV) systems to continually maximize the PV array output power, which strongly depends on both solar radiation and cell temperature. The PV power oscillations around the maximum power point (MPP) resulting from the conventional methods and complexity of the non-conventional ones are convincing reasons to look for novel MPPT methods. This paper deals with simple Genetic Algorithms (GAs) based MPPT method in order to improve the convergence, rapidity, and accuracy of the PV system. The proposed method can also efficiently track the global MPP, which is very useful for partial shading. At first, a review of the algorithm is given, followed with many test examples; then, a comparison by means Matlab/Simulink© (R2009b) is conducted between the proposed MPPT and, the popular Perturb and Observe (PO) and Incremental Conductance (IC) techniques. The results show clearly the superiority of the proposed controller. Indeed, with the proposed algorithm, oscillations around the MPP are dramatically minimized, a better stability is observed and increase in the output power efficiency is obtained. All these results are experimentally validated by a test bench developed at LIAS laboratory (Poitiers University, Poitiers, France) using real PV panels and a PV emulator which allows one to define a profile insolation model. In addition, the proposed method permits one to perform the test of linearity between the optimal current I mp (current at maximum power) and the short-circuit current I sc , and between the optimal voltage V mp and open-circuit voltage V oc , so the current and voltage factors can be easily obtained with our algorithm. Full article
Figures

Figure 1

Open AccessArticle Selective Harmonic Elimination in a Wide Modulation Range Using Modified Newton–Raphson and Pattern Generation Methods for a Multilevel Inverter
Energies 2018, 11(2), 458; https://doi.org/10.3390/en11020458
Received: 19 January 2018 / Revised: 5 February 2018 / Accepted: 11 February 2018 / Published: 22 February 2018
Cited by 1 | PDF Full-text (6681 KB) | HTML Full-text | XML Full-text
Abstract
Considering the aim of having low switching losses, especially in medium-voltage and high-power converters, the pre-programmed pulse width modulation technique is very useful because the generated harmonic content can be known in advance and optimized. Among the different low switching frequency techniques, the
[...] Read more.
Considering the aim of having low switching losses, especially in medium-voltage and high-power converters, the pre-programmed pulse width modulation technique is very useful because the generated harmonic content can be known in advance and optimized. Among the different low switching frequency techniques, the Selective Harmonics Elimination (SHE) modulation method is most suitable because of its direct control over the harmonic spectrum. This paper proposes a method for obtaining multiple solutions for selectively eliminating specific harmonics in a wide range of modulation indices by using modified Newton–Raphson (NR) and pattern generation techniques. The different pattern generation and synthesis approach provide more degrees of freedom and a way to operate the converter in a wide range of modulation. The modified Newton–Raphson technique is not complex and ensures fast convergence on a solution. Moreover, multiple solutions are obtained by keeping a very small increase in the modulation index. In the previous methods, solutions were not obtainable at all modulation indices. In this paper, only exact solutions to the low-order harmonics elimination for Cascaded H-bridge inverter are reported for all modulation indices. Analytical and simulation results prove the robustness and correctness of the technique proposed in this paper. Full article
Figures

Figure 1
