Review

Senescence-Associated Vacuoles, a Specific Lytic Compartment for Degradation of Chloroplast Proteins?

Instituto de Fisiología Vegetal (INFIVE, CONICET-UNLP), cc327, La Plata 1900, Argentina
*
Author to whom correspondence should be addressed.
Plants 2014, 3(4), 498-512; https://doi.org/10.3390/plants3040498
Submission received: 19 July 2014 / Revised: 14 September 2014 / Accepted: 15 September 2014 / Published: 11 November 2014
(This article belongs to the Special Issue Plant Vacuole)

Abstract

:
Degradation of chloroplasts and chloroplast components is a distinctive feature of leaf senescence. In spite of its importance in the nutrient economy of plants, knowledge about the mechanism(s) involved in the breakdown of chloroplast proteins is incomplete. A novel class of vacuoles, “senescence-associated vacuoles” (SAVs), characterized by intense proteolytic activity appear during senescence in chloroplast-containing cells of leaves. Since SAVs contain some chloroplast proteins, they are candidate organelles to participate in chloroplast breakdown. In this review we discuss the characteristics of SAVs, and their possible involvement in the degradation of Rubisco, the most abundant chloroplast protein. Finally, SAVs are compared with other extra-plastidial protein degradation pathways operating in senescing leaves.

1. An Overview of Leaf Senescence

Senescence is typically described as a highly organized process characterized by degradation of macromolecules and cellular structures, ultimately leading to cell, organ and/or plant death [1,2]. Typically, the progression of senescence is assessed through parameters related to the loss of chloroplast integrity (e.g., chlorophyll and protein content) and functioning (e.g., photosynthesis, potential quantum yield of photosystem II). This reflects that the breakdown of chloroplasts is an important process during leaf senescence, and integral to the role of senescence in nutrient redistribution [3,4,5]. Leaves constitute an important store of nutrients, particularly nitrogen, which are mostly held in the photosynthetic apparatus [6]. Within leaves, most N resides in chloroplasts [6]. The degradation of photosynthetic proteins during senescence releases large amounts of N in a readily remobilizable form (i.e., amino acids), therefore senescence represents a salvage mechanism to recycle chloroplast nitrogen to actively growing organs of the plant (e.g., seeds) or to N reserves in the bark of deciduous trees [3,4,5]. In cereals, up to 80% of N harvested in the grains may come from senescence-associated redistribution of leaf protein N [6]. Given the importance of the breakdown of chloroplast proteins in the nitrogen budget of leaves, crops, and, eventually, global nutrient cycles [7], it is not surprising that senescence-associated changes in other organelles or cell compartments have received much less attention [8,9,10].

2. Chloroplast Degradation in Senescing Leaf Cells

Although the main focus of this review is on Senescence-Associated Vacuoles, given their presumed role in chloroplast protein degradation, a brief summary of breakdown processes taking place in senescing leaves seems warranted to provide a context of the developmental scenario where these vacuoles occur. During senescence, massive breakdown of chloroplasts results in the almost complete disappearance of recognizable plastids at late stages of senescence [11,12]. Many studies on chloroplast ultrastructure have documented extensive disorganization of the thylakoid membranes, with a decrease in grana stacking and dilation of thylakoids [11,13]. As thylakoids break down, osmiophillic globuli (plastoglobuli) containing products of membrane degradation appear, reaching relatively large numbers in severely deteriorated chloroplasts [11,12,13]. Eventually, chloroplast structure becomes completely disrupted at late stages of senescence [11]. The ultrastructural changes described above are the consequence of wide-range macromolecule degradation processes. Ultrastructural changes in thylakoids parallel the degradation of photosystem proteins [12,13,14], thylakoid galactolipids [12,15] and loss of chlorophylls [12,16,17], which result in impaired photosynthetic electron transport [13,18]. The stromal proteins of plastids, including Rubisco and other components of the C3 photosynthetic pathway [12,15], glutamine sunthetase II [19], and even sulfur assimilating enzymes [20] are also degraded, and their breakdown may start even before changes in the photochemical apparatus (e.g., chlorophyll loss) can be detected. The relative onset and rate of degradation of stromal vs. thylakoid proteins and chlorophyll may vary (e.g., [21]), which may help adjust the remaining photosynthetic capacity of a leaf in the course of senescence to environmental conditions (e.g., irradiance). This highlights the possibility that different proteolytic mechanisms are responsible for the fate of these different photosynthetic proteins.
The degradation of the membrane-bound proteins of photosystem II has been well studied in the context of the repair cycle following photoinhibition of PSII [22,23,24,25,26] and acclimation of the light-harvesting antenna to increased irradiance [27,28,29]. There is evidence that chloroplast proteases of the Deg and FtsH families are involved in the degradation of photodamaged D1 protein [22,23,24,25,26], and because photoinhibition persists during senescence [30], this mechanism might account for D1 breakdown in senescing chloroplasts. The light-harvesting proteins of PSII are degraded during acclimation to high irradiance, possibly through the operation of a metalloprotease [27,28]. In vitro experiments implicated FtsH6 in the degradation of the light-harvesting Lhcb2 protein [29], however, this could not be substantiated in vivo [31].
In many species, stromal protein degradation is apparently responsible for the marked decrease in photosynthetic activity during senescence, but, perhaps more important, Rubisco also constitutes the single most important source of remobilizable nitrogen in leaves of most species. Thus, understanding chloroplast protein and, particularly Rubisco, degradation, holds the promise of extending photosynthetic capacity or providing a handle to manipulate nutrient redistribution. Unfortunately, data linking a particular protease or a proteolytic pathway to the breakdown of stromal chloroplast proteins is often only correlative, or otherwise inconclusive.
In spite of the intense search for within-the-chloroplast degradation of Rubisco and other stromal proteins, there is still no convincing evidence to implicate chloroplast proteases in Rubisco degradation (reviewed in [14,32]). Moreover, recent findings showing Rubisco and other chloroplast proteins in vesicular structures outside the plastid (i.e., Rubisco-Containing Bodies and Senescence-Associated Vacuoles [33,34,35]) supports the idea that plastidial degradation of Rubisco may be a minor proteolytic pathway for the breakdown of chloroplast stromal proteins in senescing leaves, whereas extra-plastidial pathways may be more important. These extra-plastidial pathways will be discussed in detail below.

3. Involvement of the Central Vacuole

Several reports have suggested that protein degradation in senescing leaves might occur within the central vacuole [36,37,38]. This is consistent with the fact that the central vacuole is an acidic compartment with high endopeptidase and carboxipeptidase activity [39,40], and that a number of senescence-associated proteases localize to the central vacuole [41,42,43], supporting its potential involvement in chloroplast protein degradation.
There are reports that provided microscopic evidence for the engulfment of entire plastids within the central vacuole [44,45,46], whereas other studies failed to confirm these observations (e.g., [47]). Although the available evidence suggests that engulfment of whole chloroplasts may be a relatively infrequent phenomenon, this does not rule out the involvement of the central vacuole. There is an early report on the late accumulation of amino acids (presumably arising from protein degradation) in the central vacuole of senescing leaf cells [48], and more recently Ono et al. [49] showed the accumulation of GFP in the central vacuoles of Arabidopsis plants expressing Rubisco-GFP. This implies that the central vacuole may participate in chloroplast protein degradation, either by accomplishing the complete degradation of proteins to their constituent amino acids, or part of this process. In any event, the operation of the entire or partial breakdown of chloroplast proteins in the central vacuole would require transport mechanisms between both organelles.

4. Senescence-Associated Vacuoles: Contents, Characteristics, Markers

In recent years evidence has accumulated showing the co-existence of different classes of vacuoles in the same cells. For example, primary and secondary vacuoles can be detected in aleurone layer cells [50], whereas functionally specialized CAM-associated and sodium storage vacuoles co-exist in mesophyll cells of Mesembryanthemum [51]. In general, the occurrence of two different vacuole types in the same cell, although clearly not universal, is possible under certain physiological or developmental transitions [52]. This is the case in senescing leaf cells, where in addition to the central vacuole, there are smaller vacuoles, absent from non-senescing leaves, and therefore termed “senescence-associated vacuoles” (SAVs) [53]. SAVs have been detected in soybean, Arabidopsis and tobacco [35,53,54]. The number of SAVs increases dramatically as senescence progresses, reaching relatively large numbers (40–60 SAVs per cell in a 1 µm thick optical section) during the period when chloroplast protein loss is most intense [35,55]. Further strengthening the association of SAVs with senescence, the number of SAVs per cell section increases when senescence is accelerated by ethylene, and, conversely, SAVs are almost non-detectable in leaves treated with cytokinins [35,54]. It is noteworthy that SAVs are detected in chloroplast-containing cells, i.e., mesophyll, and, to a lesser extent in guard cells, but they seem to be absent from the rest of the epidermis [53].
SAVs contain vacuolar H+ pyrophosphatase in their limiting membrane, are acidic, and display no organized internal structure [53], which justifies their assignment as a novel class of vacuoles. However, there are a number of features distinguishing SAVs from the central vacuole. As mentioned before, SAVs are smaller (0.5–0.8 µm in diameter). Furthermore, SAVs are more acidic than the central vacuole. Direct measurements with the pH sensor probe Lysosensor Yellow/Blue shows SAVs to have a lumenal pH around 5.2, whereas the pH of the central vacuole is approximately 6.0 [53]. SAVs membranes also lack the γ-TIP aquaporin, which is diagnostic of the central vacuole and may be important for internal equilibration of water [40].
A distinctive feature of SAVs is their high peptidase activity. When senescing leaf cells are incubated in the presence of a fluorescent probe (R6502) for peptidase activity, most of the fluorescence resulting from hydrolysis of the probe is detected in SAVs [35,53,54]. Since R6502 has been reported to detect cysteine type proteases with high efficiency [55] we surmised that SAVs peptidase activity was mostly due to cysteine-proteases [53], which was later confirmed by the observation that in vivo peptidase activity in SAVs is almost completely abolished by pre-incubation with the diagnostic cysteine protease inhibitor E-64 [54] (Figure 1). Likewise, subcellular fractionation combined with the use of an activity-based probe for cysteine proteases, DCG-04 [56,57] detected a large part of the cysteine protease activity of senescing cells in a fraction enriched in SAVs [54]. Up-regulation of cysteine protease genes is a common observation in many transcriptomic studies of leaf senescence in several plant species (reviewed in [14]), which suggests that SAVs contain some of the senescence up-regulated proteases of the cell. In line with this, the senescence-specific cysteine protease SAG12 appears to be located preferentially in SAVs [53,54] (Figure 2), confirming fluorescent (R6502) and activity-based probe (DCG04) results about the prevalence of cysteine proteases in these lytic vacuoles. The localization of a SAG12-GFP fusion in SAVs is quite significant in view of the strict senescence-associated expression of SAG12 [58,59,60], and this makes SAG12-GFP a convenient and specific marker for SAVs. Consistent with this, increased expression of SAG12 parallels the accumulation of SAVs during senescence of tobacco leaves [54]. SAG12 may account for part of the proteolytic activity of SAVs, but it is clearly not required for SAVs biogenesis [53].
Summing up, the available evidence suggests that at least two types of vacuoles co-exist in senescing mesophyll cells, the central vacuole, and a large number of smaller, senescence-associated vacuoles loaded with high peptidase activity.
Figure 1. In vivo inhibition of cysteine protease activity of SAVs with the specific inhibitor E-64. Cells were isolated from senescing (3 days) tobacco leaves, and treated for 2 h with E-64 (100 µM, E through H), or left in buffer as controls (A through D). Cells were later stained with R6502, a probe for protease activity that becomes brightly fluorescent upon cleavage (C and G) and Lysotracker Red, an acidotropic marker for acid organelles (B and F). Panels A and E show chlorophyll autofluorescence, whereas panels D and H show a merged image of Chl, Lysotracker Red and R6502. Co-localization between Lysotracker Red and R6502 is pseudocolored white. Bars represent 5 µm. Redrawn from [54].
Figure 1. In vivo inhibition of cysteine protease activity of SAVs with the specific inhibitor E-64. Cells were isolated from senescing (3 days) tobacco leaves, and treated for 2 h with E-64 (100 µM, E through H), or left in buffer as controls (A through D). Cells were later stained with R6502, a probe for protease activity that becomes brightly fluorescent upon cleavage (C and G) and Lysotracker Red, an acidotropic marker for acid organelles (B and F). Panels A and E show chlorophyll autofluorescence, whereas panels D and H show a merged image of Chl, Lysotracker Red and R6502. Co-localization between Lysotracker Red and R6502 is pseudocolored white. Bars represent 5 µm. Redrawn from [54].
Plants 03 00498 g001
Figure 2. SAG12-GFP localization in senescing Arabidopsis leaves. Confocal images through the mesophyll of a senescing leaf from a SAG12-GFP transgenic plant incubated with the acidotropic dye Neutral Red. (A) Chlorophyll fluorescence (excitation 633 nm/emission > 650 nm), (B) SAG12-GFP (excitation 488 nm/ emission 505–550 nm), (C) Neutral Red (excitation 543 nm/emission 550–605 nm). Note that the GFP signal colocalizes with the fluorescence from Neutral Red, indicating that SAG12-GFP is located inside SAVs. Scale bar = 10 µm. Redrawn from [53].
Figure 2. SAG12-GFP localization in senescing Arabidopsis leaves. Confocal images through the mesophyll of a senescing leaf from a SAG12-GFP transgenic plant incubated with the acidotropic dye Neutral Red. (A) Chlorophyll fluorescence (excitation 633 nm/emission > 650 nm), (B) SAG12-GFP (excitation 488 nm/ emission 505–550 nm), (C) Neutral Red (excitation 543 nm/emission 550–605 nm). Note that the GFP signal colocalizes with the fluorescence from Neutral Red, indicating that SAG12-GFP is located inside SAVs. Scale bar = 10 µm. Redrawn from [53].
Plants 03 00498 g002

5. Involvement of SAVs in Chloroplast Protein Degradation

Their high peptidase activity and their occurrence in chloroplast-containing cells (i.e., mesophyll and guard cells), led us to speculate that the breakdown of chloroplast proteins during senescence might partially occur in SAVs. Two lines of evidence point to the relocation of some chloroplast proteins to SAVs in senescing leaf cells. First, in a transgenic line of tobacco expressing GFP fused to the recA transit peptide for targeting to plastids, GFP fluorescence is restricted to the chloroplasts in mature leaves [35,61], while in senescing cells, in addition to the presence of GFP in chloroplasts, also SAVs (detected by their staining with the acidotropic marker Lysotracker Red) contain GFP (Figure 3) [35]. This suggests that some chloroplast proteins relocalize to SAVs in the course of senescence. A second evidence for the presence of chloroplast proteins in SAVs comes from subcellular fractionation and isolation of a SAVs-enriched fraction. The large subunit of Rubisco and glutamine synthetase II were readily detected in isolated SAVs confirming the relocation of chloroplast proteins to SAVs during senescence. The finding of the large subunit of Rubisco is significant, not only because this is the most abundant protein in C3 plants, but also because the large subunit is chloroplast-encoded and synthesized within the plastid, therefore the most likely explanation for its presence in SAVs is relocation. The lack of characteristic PSII proteins, such as D1 and Lhcb in this SAVs-enriched fraction indicates also that the presence of Rubisco is not due to contamination, and, perhaps more important, that PSII proteins are degraded by a different proteolytic pathway.
Since SAVs contain high peptidase activity, it is not surprising that isolated SAVs can degrade the chloroplast proteins (e.g., Rubisco) contained within them in autodigestion experiments [35,54]. About 25% of Rubisco contained in SAVs is lost in 4 h of incubation, and this moderate rate of degradation possibly explains why chloroplast-targeted GFP is relatively stable in SAVs, allowing for its detection through confocal microscopy [35,54]. The loss of Rubisco in autodigestion experiments is reduced to a large extent by addition of cysteine protease inhibitors, whereas serine protease inhibitors are largely ineffective [35,54]. Thus, in vitro proteolytic activity of SAVs seems to be due to cysteine proteases, which is consistent with all the observations indicating that cysteine proteases are an important component of SAVs. Correlative evidence suggests that Rubisco degradation by SAVs cysteine proteases also occurs in vivo. Incubation of wheat leaf segments [62] and tobacco leaf disks [54] with an inhibitor of cysteine proteases (E64) reduces the degradation of chloroplast proteins, including Rubisco. This correlates with severe inhibition of the cysteine protease activity of SAVs [54]. Although a direct genetic approach to test whether chloroplast proteins are degraded in SAVs is still lacking, the presence of chloroplast proteins in SAVs and the decreased protein degradation by treatments that block SAVs proteolytic activity lend support to the idea that SAVs may be part of a proteolytic pathway(s) involved in breakdown of the stromal proteins of chloroplasts in senescing leaves.
Figure 3. Z-stack (consecutive 1 µm thick optical slices) covering a depth of 4 µm in a mesophyll cell of a senescing tobacco leaf expressing GFP targeted to the plastid [61]. As an example, SAV detected in the middle planes (second or third optical slices) are indicated with white arrows (one SAV with LysoTracker Red and GFP and Chl fluorescence) or white arrowheads (two SAVs with LysoTracker Red, and GFP fluorescence). Empty arrows/arrowheads show fainter signals above or below the focal plane of selected SAVs. Note that most SAVs, stained by Lysotracker Red, also contain GFP, and that almost all GFP located outside chloroplasts is found in SAVs. Scale bar: 5 µm. Redrawn from [35].
Figure 3. Z-stack (consecutive 1 µm thick optical slices) covering a depth of 4 µm in a mesophyll cell of a senescing tobacco leaf expressing GFP targeted to the plastid [61]. As an example, SAV detected in the middle planes (second or third optical slices) are indicated with white arrows (one SAV with LysoTracker Red and GFP and Chl fluorescence) or white arrowheads (two SAVs with LysoTracker Red, and GFP fluorescence). Empty arrows/arrowheads show fainter signals above or below the focal plane of selected SAVs. Note that most SAVs, stained by Lysotracker Red, also contain GFP, and that almost all GFP located outside chloroplasts is found in SAVs. Scale bar: 5 µm. Redrawn from [35].
Plants 03 00498 g003

7. Future Directions

The available evidence indicates that Senescence-Associated Vacuoles are lytic compartments possibly involved in the degradation of chloroplast proteins during senescence. There are a number of questions that still need to be resolved, and these include, among others, (1) the biogenesis of SAVs, (2) the identification of SAVs proteases responsible for protein degradation, (3) an assessment of the quantitative importance of SAVs in chloroplast protein breakdown and (4) a detailed study of the interrelations between SAVs and other extraplastidial chloroplast degradation pathways. Undoubtedly, identifying molecular targets to impair SAVs biogenesis and/or function will be critical to facilitate progress in the understanding of this novel cellular structure.

Acknowledgments

Funding from CONICET (PIP 487) and ANPCYT (PICT 2012-1862, PICT 061), Argentina, is gratefully acknowledged.

Author Contributions

Cristian Carrión supplied unpublished data and revised the manuscript, Dana Martínez, María Lorenza Costa and Juan José Guiamet wrote different sections of this manuscript and revised the final version.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. Noodén, L.D.; Guiamet, J.J.; John, I. Whole plant senescence. In Plant Cell Death Processes; Noodén, L.D., Ed.; Academic Press: San Diego, CA, USA, 2004; pp. 227–244. [Google Scholar]
  2. Li, P.O.; Kim, H.J.; Nam, H.G. Leaf senescence. Annu. Rev. Plant. Biol. 2007, 58, 115–136. [Google Scholar]
  3. Masclaux-Daubresse, C.; Reisdorf-Cren, M.; Orsel, M. Leaf nitrogen remobilisation for plant development and grain filling. Plant Biol. 2008, 10, 23–36. [Google Scholar] [CrossRef] [PubMed]
  4. Mae, T. Leaf senescence and nitrogen metabolism. In Plant Cell Death Processes; Noodén, L.D., Ed.; Academic Press: San Diego, CA, USA, 2004; pp. 157–168. [Google Scholar]
  5. Killingbeck, K.T. Nutrient resorption. In Plant Cell Death Processes; Noodén, L.D., Ed.; Academic Press: San Diego, CA, USA, 2004; pp. 215–226. [Google Scholar]
  6. Peoples, M.B.; Dalling, M.J. The interplay between proteolysis and amino acid metabolism during senescence and nitrogen reallocation. In Senescence and Aging in Plants; Noodén, L.D., Leopold, A.C., Eds.; Academic Press: San Diego, CA, USA, 1988; pp. 181–217. [Google Scholar]
  7. Vergutz, L.; Manzoni, S.; Portorato, A.; Ferreira Novais, R.; Jackson, M.B. Global resorption efficiencies and concentrations of carbon and nutrients in leaves of terrestrial plants. Ecol. Monogr. 2012, 82, 205–220. [Google Scholar] [CrossRef]
  8. Martínez, D.E.; Guiamet, J.J. Senescence-related changes in the leaf apoplast. J. Plant Growth Regul. 2014, 33, 44–55. [Google Scholar] [CrossRef]
  9. Del Río, L.A.; Pastori, G.M.; Palma, J.M.; Sandalio, L.M.; Sevilla, F.; Corpas, F.J.; Jiménez, A.; López-Huerta, E.; Hernández, J.A. The activated oxygen role of peroxisomes in senescence. Plant Physiol. 1998, 116, 1195–1200. [Google Scholar] [CrossRef] [PubMed]
  10. Keech, O.; Pesquet, E.; Ahad, A.; Askne, A.; Nordvall, D.; Vodnala, S.M.; Tuominen, H.; Hurry, V.; Dizengremel, P.; Gardeström, P. The different fates of mitochondria and chloroplasts during dark-induced senescence in Arabidopsis leaves. Plant Cell Environ. 2007, 30, 1523–1534. [Google Scholar] [CrossRef] [PubMed]
  11. Guiamét, J.J.; Luquez, V.M. Leaf senescence and related processes. In Crops: Growth, Quality, and Biotechnology; Dris, R., Ed.; WFL Publisher: Helsinki, Finland, 2005; pp. 1238–1253. [Google Scholar]
  12. Krupinska, K. Fate and activities of plastids during leaf senescence. In The Structure and Function of Plastids; Wise, R.R., Hoober, J.K., Eds.; Springer: Dordrecht, The Netherlands, 2007; pp. 433–449. [Google Scholar]
  13. Gepstein, S. Photosynthesis. In Senescence and Aging in Plants; Noodén, L.D., Leopold, A.C., Eds.; Academic Press: San Diego, CA, USA, 1988; pp. 85–109. [Google Scholar]
  14. Costa, M.L.; Martínez, D.E.; Gomez, F.M.; Carrión, C.; Guiamét, J.J. Chloroplast protein degradation: Involvement of senescence-associated vacuoles. In Advances in Photosynthesis and Respiration Series; Biswal, B., Krupinska, K., Biswal, U.C., Eds.; Springer Science + Business Media: Dordrecht, The Netherlands, 2013; pp. 417–433. [Google Scholar]
  15. Meir, S.; Philosoph-Hadas, S. Metabolism of polar lipids during senescence of watercress leaves. Plant Physiol. Biochem. 1995, 33, 241–249. [Google Scholar]
  16. Ougham, H.; Hörtensteiner, S.; Armstead, I.; Donninson, I.; King, I.; Thomas, H.; Mur, L. The control of chlorophyll catabolism and the status of yellowing as a biomarker of leaf senescence. Plant Biol. 2008, 10, 4–14. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  17. Hörtensteiner, S.; Kräutler, B. Chlorophyll breakdown in higher plants. Biochim. Biophys. Acta 2011, 1807, 977–988. [Google Scholar] [CrossRef]
  18. Krupinska, K.; Humbeck, K. Photosynthesis and chloroplast breakdown. In Plant Cell Death Processes; Noodén, L.D., Ed.; Academic Press: San Diego, CA, USA, 2004; pp. 169–187. [Google Scholar]
  19. Kamachi, K.; Yamaya, T.; Hayakawa, T.; Mae, T.; Ojima, K. Changes in cytosolic glutamine synthetase polypeptide and its mRNA in a leaf blade of rice plants during natural senescence. Plant Physiol. 1992, 98, 1323–1329. [Google Scholar] [CrossRef]
  20. Schmutz, D.; Wyss, H.-R.; Brunold, C. Activity of sulfate-assimilating enzymes in primary leaves of Phaseolus vulgaris L. during dark-induced senescence. Z. Pflanzenphysiol. 1983, 110, 211–219. [Google Scholar] [CrossRef]
  21. Hidema, J.; Makino, A.; Mae, T.; Ojima, K. Photosynthetic characteristics of rice leaves aged under different irradiances from full expansion through senescence. Plant Physiol. 1991, 97, 1287–1293. [Google Scholar] [CrossRef] [PubMed]
  22. Zaltsman, A.; Ori, N.; Adam, Z. Two types of FtsH subunits are required for chloroplast biogenesis and Photosystem II repair in Arabidopsis. Plant Cell 2005, 17, 2782–2790. [Google Scholar] [CrossRef] [PubMed]
  23. Kapri-Pardes, E.; Naveh, L.; Adam, Z. The thylakoid lumen protease DegP1 is involved in the repair of photosystem II from photoinhibition in Arabidopsis. Plant Cell 2007, 19, 1039–1047. [Google Scholar] [CrossRef]
  24. Sun, X.; Peng, L.; Guo, J.; Chi, W.; Ma, J.; Lu, C.; Zhang, L. Formation of Deg5 and Deg8 complexes and their involvement in the degradation of photodamaged Photosystem II reaction center D1 protein in Arabidopsis. Plant Cell 2007, 19, 1347–1361. [Google Scholar] [CrossRef]
  25. Kato, Y.; Miura, E.; Ido, K.; Ifuku, K.; Sakamoto, W. The variegated mutants lacking chloroplastic FtsHs are defective in D1 degradation and accumulate reactive oxygen species. Plant Physiol. 2009, 151, 1790–1801. [Google Scholar]
  26. Sun, X.; Fu, T.; Chen, N.; Guo, J.; Ma, J.; Zou, M.; Lu, C.; Zhang, L. The stromal chloroplast Deg7 protease participates in the repair of photosystem II after photoinhibition in Arabidopsis. Plant Physiol. 2010, 152, 1263–1273. [Google Scholar] [CrossRef] [PubMed]
  27. Yang, D.-H.; Webster, J.; Adam, Z.; Lindahl, M.; Andersson, B. Induction of acclimative proteolysis of the light-harvesting chlorophyll a/b protein of photosystem II in response to elevated light intensities. Plant Physiol. 1998, 118, 827–834. [Google Scholar] [CrossRef]
  28. Zelisko, A.; Jackowski, G. Senescence-dependent degradation of Lhcb3 is mediated by a thylakoid membrane-bound protease. J. Plant Physiol. 2004, 161, 1157–1170. [Google Scholar] [CrossRef]
  29. Zelisko, A.; García-Lorenzo, M.; Jackowski, G.; Jansson, S.; Funk, C. AtFtsH6 is involved in the degradation of the light-harvesting complex II during high-light acclimation and senescence. Proc. Natl. Acad. Sci. USA 2005, 102, 13690–13704. [Google Scholar] [CrossRef]
  30. Guiamét, J.J.; Tyystjärvi, E.; Tyystjärvi, T.; John, I.; Kairavuo, M.; Pichersky, P.; Noodén, L.D. Photoinhibition and loss of photosystem II reaction center proteins during senescence of soybean leaves. Enhancement of photoinhibition by the “stay-green” mutation cytG. Physiol. Plant 2002, 115, 468–478. [Google Scholar] [CrossRef]
  31. Wagner, R.; Aigner, H.; Pruzinská, A.; Jänkänpää, H.J.; Jansson, S.; Funk, C. Fitness analysis of Arabidopsis thaliana mutants depleted of FtsH metalloproteases and characterization of three FtsH6 deletion mutants exposed to high light stress, senescence and chilling. New Phytol. 2011, 191, 449–458. [Google Scholar] [CrossRef]
  32. Martínez, D.E.; Costa, M.; Guiamet, J.J. Senescence associated degradation of chloroplast proteins inside and outside the organelle. Plant Biol. 2008, 10, 15–22. [Google Scholar] [CrossRef] [PubMed]
  33. Chiba, A.; Ishida, H.; Nishizawa, N.K.; Makino, A.; Mae, T. Exclusion of ribulose-1,5-bisphosphate carboxylase/oxygenase from chloroplasts by specific bodies in naturally senescing leaves of wheat. Plant Cell Physiol. 2003, 44, 914–921. [Google Scholar] [CrossRef] [PubMed]
  34. Ishida, H.; Yoshimoto, K.; Izumi, M.; Reisen, D.; Yano, Y.; Makino, A.; Ohsumi, Y.; Hanson, M.R.; Mae, T. Mobilization of rubisco and stroma-localized fluorescent proteins of chloroplast to the vacuole by an ATG gene-dependent autophagic process. Plant Physiol. 2008, 148, 142–155. [Google Scholar] [CrossRef] [PubMed]
  35. Martínez, D.E.; Costa, M.L.; Gomez, F.M.; Otegui, M.S.; Guiamet, J.J. “Senescence-associated vacuoles” are involved in the degradation of chloroplast proteins in tobacco leaves. Plant J. 2008, 56, 196–206. [Google Scholar] [CrossRef] [PubMed]
  36. Lin, W.; Wittenbach, V.A. Subcellular localization of proteases in wheat and corn mesophyll protoplasts. Plant Physiol. 1981, 67, 969–972. [Google Scholar] [CrossRef]
  37. Wittenbah, V.A.; Lin, W.; Herbert, R.H. Vacuolar localization of proteases and degradation of chloroplasts in mesophyll protoplasts from senescing primary wheat leaves. Plant Physiol. 1982, 69, 98–102. [Google Scholar] [CrossRef]
  38. Srivalli, B.; Bharti, S.; Kanna-Chopra, R. Vacuole cysteine proteases and ribulose-1,5-bisphosphate carboxylase/oxygenase degradation during monocarpic senescence in cowpea leaves. Photosynthetica 2001, 39, 87–93. [Google Scholar] [CrossRef]
  39. De Deepesh, N. Plant Cell Vacuoles. An Introduction; CSIRO Publishing: Collingwood, Australia, 2000; pp. 1–304. [Google Scholar]
  40. Müntz, K. Protein dynamics and proteolysis in plant vacuoles. J. Exp. Bot. 2007, 58, 2391–2407. [Google Scholar] [CrossRef]
  41. Hensel, L.L.; Grbic, V.; Baumgarten, D.A.; Bleecker, A.B. Developmental and age-related processes that influence the longevity and senescence of photosynthetic tissues in Arabidopsis. Plant Cell 1993, 5, 553–564. [Google Scholar] [CrossRef] [PubMed]
  42. Drake, R.; John, I.; Farrell, A.; Cooper, W.; Schuch, W.; Grierson, D. Isolation and analysis of cDNAs encoding tomato cysteine proteases expressed during leaf senescence. Plant Mol. Biol. 1996, 30, 755–767. [Google Scholar] [CrossRef] [PubMed]
  43. Martínez, D.E.; Bartoli, C.G.; Grbic, V.; Guiamet, J.J. Vacuolar cysteine proteases of wheat (Triticum aestivum L.) are common to leaf senescence induced by different factors. J. Exp. Bot. 2007, 58, 1099–1107. [Google Scholar] [CrossRef] [PubMed]
  44. Minimikawa, T.; Toyooka, K.; Okamoto, T.; Hara-Nishimura, I.; Nishimura, M. Degradation of ribulose-bisphosphate carboxylase by vacuolar enzymes of senescing French bean leaves: Immunocytochemical and ultrastructural observations. Protoplasma 2001, 218, 144–153. [Google Scholar]
  45. Niwa, Y.; Kato, T.; Tabata, S.; Seki, M.; Kobayashi, M.; Shinozaki, K.; Moriyasu, Y. Disposal of chloroplasts with abnormal function into the vacuole in Arabidopsis thaliana cotyledon cells. Protoplasma 2004, 223, 229–232. [Google Scholar]
  46. Wada, S.; Ishida, H.; Izumi, M.; Yoshimoto, K.; Ohsumi, Y.; Mae, T.; Makino, A. Autophagy plays a role in chloroplast degradation during senescence in individually darkened leaves. Plant Physiol. 2009, 149, 885–893. [Google Scholar]
  47. Evans, M.; Rus, A.M.; Belanger, E.M.; Kimoto, M.; Brusslan, J.A. Dismantling of Arabidopsis thaliana mesophyll cell chloroplasts during natural leaf senescence. Plant Biol. 2010, 12, 1–12. [Google Scholar]
  48. Matile, P. The vacuole and cell senescence. Adv. Bot. Res. 1997, 25, 87–112. [Google Scholar]
  49. Ono, Y.; Wada, S.; Izumi, M.; Makino, A.; Ishida, H. Evidence for contribution of autophagy to Rubisco degradation during leaf senescence in Arabidopsis thaliana. Plant Cell Environ. 2013, 36, 1147–1159. [Google Scholar] [CrossRef]
  50. Swanson, S.J.; Bethke, P.C.; Jones, R.L. Barley aleurone cells contain two types of vacuoles: Characterization of lytic organelles by means of fluorescent probes. Plant Cell 1998, 10, 685–698. [Google Scholar] [PubMed]
  51. Epimashko, S.; Meckel, T.; Fischer-Schliebs, E.; Lüttge, U.; Thiel, G. Two functional different vacuoles for static and dynamic purposes in one plant mesophyll leaf cell. Plant J. 2004, 37, 294–300. [Google Scholar]
  52. Frigerio, L.; Hinz, G.; Robinson, D.G. Multiple vacuoles in plant cells: Rule or exception? Traffic 2008, 9, 1564–1570. [Google Scholar] [CrossRef]
  53. Otegui, M.; Noh, Y.-S.; Martínez, D.; Vila-Petroff, M.; Staehelin, A.; Amasino, R.; Guiamet, J.J. Senescence-associated vacuoles with intense proteolytic activity develop in senescing leaves of Arabidopsis and soybean. Plant J. 2005, 41, 831–844. [Google Scholar] [CrossRef]
  54. Carrión, C.A.; Costa, M.L.; Martínez, D.E.; Mohr, C.; Humbeck, K.; Guiamet, J.J. In vivo inhibition of cysteine proteases provides evidence for the involvement of “senescence-associated vacuoles” in chloroplast protein degradation during dark-induced senescence of tobacco leaves. J. Exp. Bot. 2013, 64, 4967–4980. [Google Scholar] [CrossRef]
  55. Peptidase substrates. Available online: http://www.lifetechnologies.com/ar/es/home/references/molecular-probes-the-handbook/enzyme-substrates/detecting-peptidases-and-proteases.html#head1 (accessed on 7 October 2014).
  56. Greenbaum, D.; Medzihradsky, K.; Burlingame, A.; Bogyo, M. Epoxide electrophiles as activity-dependent cysteine protease profiling and discovery tools. Chem. Biol. 2000, 7, 569–581. [Google Scholar] [CrossRef] [PubMed]
  57. Van der Hoorn, R.A.L.; Leeuwenbergh, M.A.; Bogyo, M.; Joosten, M.H.A.; Peck, S.C. Activity profiling of papain-like cystein proteases in plants. Plant Physiol. 2004, 135, 1170–1178. [Google Scholar] [CrossRef] [PubMed]
  58. Lohman, K.N.; Gan, S.; John, L.M.; Amasino, R.M. Molecular analysis of natural leaf senescence in Arabidopsis thaliana. Physiol. Plant. 1994, 92, 322–328. [Google Scholar] [CrossRef]
  59. Noh, Y.-S.; Amasino, R.M. Identification of a promoter region responsible for the senescence-specific expression of SAG12. Plant Mol. Biol. 1999, 41, 181–194. [Google Scholar] [CrossRef]
  60. Grbic, V. SAG2 and SAG12 protein expression in senescing Arabidopsis plants. Physiol. Plant. 2003, 119, 1–7. [Google Scholar]
  61. Köhler, R.H.; Cao, J.; Zipfel, W.R.; Webb, W.W.; Hanson, M.R. Exchange of protein molecules through connections between higher plant plastids. Science 1997, 276, 2039–2042. [Google Scholar] [CrossRef] [PubMed]
  62. Thoenen, M.; Herrmann, B.; Feller, U. Senescence in wheat leaves: Is a cysteine endopeptidase involved in the degradation of the large subunit of Rubisco? Acta Physiol. Plant. 2007, 29, 339–350. [Google Scholar]
  63. Carrión, C.A.; Instituto de Fisiología Vegetal (INFIVE, CONICET-UNLP), La Plata, Argentina. Unpublished data. 2013.
  64. Tamura, K.; Shimada, T.; Ono, E.; Tanaka, Y.; Nagatani, A.; Higashi, S.-I.; Watanabe, M.; Nishimura, M.; Hara-Nishimura, I. Why green fluorescent fusion proteins have not been observed in the vacuoles of higher plants. Plant J. 2003, 35, 545–555. [Google Scholar] [CrossRef]
  65. Dettmer, J.; Hong-Hemesdorf, A.; Stierhof, Y.-D.; Schumacher, K. Vacuolar H+-ATPase activity is required for endocytic and secretory trafficking in Arabidopsis. Plant Cell 2006, 18, 715–730. [Google Scholar] [CrossRef]
  66. Doelling, J.H.; Walker, J.M.; Friedman, E.M.; Thompson, A.R.; Vierstra, R.D. The APG8/12-activating enzyme APG7 is required for proper nutrient recycling and senescence in Arabidopsis thaliana. J. Biol. Chem. 2002, 277, 33105–33114. [Google Scholar] [CrossRef]
  67. Thompson, A.R.; Doelling, J.H.; Suttangkakul, A.; Vierstra, R.D. Autophagic nutrient recycling in Arabidopsis directed by the ATG8 and ATG12 conjugation pathways. Plant Physiol. 2005, 138, 2097–2110. [Google Scholar] [CrossRef]
  68. Liu, Y.; Bassham, D.C. Autophagy: Pathways for self-eating in plant cells. Ann. Rev. Plant Biol. 2012, 63, 215–237. [Google Scholar] [CrossRef]
  69. Lee, T.A.; Vande Wetering, S.W.; Bruslan, J.A. Stromal protein degradation is incomplete in Arabidopsis thaliana autophagy mutants undergoing natural senescence. BMC Res. Notes 2013, 6, 17. [Google Scholar] [CrossRef] [PubMed]
  70. Guiboileau, A.; Avila-Ospina, L.; Yoshimoto, K.; Soulay, F.; Azzopardi, M.; Marmagne, M.; Lothier, J.; Masclaux-Daubresse, C. Physiological and metabolic consequences of autophagy deficiency for the management of nitrogen and protein resources in Arabidopsis leaves depending on nitrate availability. New Phytol. 2013, 199, 683–694. [Google Scholar]
  71. Yoshimoto, K.; Jikumaru, Y.; Kamiya, Y.; Kusano, M.; Consonni, C.; Panstruga, R.; Ohsuni, Y.; Shirasu, K. Autophagy negatively regulates cell death by controlling NPR1-dependent salicylic acid signaling during senescence and the innate immune response in Arabidopsis. Plant Cell 2009, 21, 2914–2927. [Google Scholar] [CrossRef]
