New Materials and Designs for Soft Actuators

Special Issue Editors
Special Issue Information
Keywords
Published Papers

A special issue of Actuators (ISSN 2076-0825).

Deadline for manuscript submissions: closed (31 March 2019) | Viewed by 78550

Share This Special Issue

Special Issue Editor

Dr. Aslan Miriyev

E-Mail Website
Guest Editor

Physical AI (PAI) Laboratory, Department of Mechanical Engineering, Ben-Gurion University of the Negev, Be'er Sheva, Israel
Interests: physical AI (PAI); material intelligence; soft-material robotics; bio-hybrid robotics; soft actuation; bio-hybrid actuation; soft and structural functional composites; multi-material systems; advanced manufacturing; 3D printing
Special Issues, Collections and Topics in MDPI journals

Special Issue Information

Dear Colleagues,

Soft Robotics aims to overcome one of the most significant barriers in robotics—the lack of adaptivity to the environment—by introducing soft materials that would render robots more compliant. Akin to biological organisms, such robots would be capable of soft-bodied locomotion and dexterity, necessitating the development of novel, soft actuators. The most widely known, and even successfully-commercialized soft actuation systems, presently in use, are based on inflating/deflating elastomeric chambers of various designs with fluids using compressors and pipes. The non-compliant components of these actuation systems limit miniaturization, thus introducing constraints into robotic design. This has prompted a novel research vector aimed at developing material systems for soft actuation, in particular those integrating sensing capabilities for centralized computer control of robotic motion. The goal of this exciting endeavor is replacing existing pneumatic and hydraulic soft actuators with electrically-activated functional material systems.

The synthesis and fabrication of novel actuator-sensor material systems is a technological prerequisite for engineering bio-inspired compliant robots. In the development of these critical technologies, particular attention is devoted to stimuli-responsive composite and multifunctional material systems with graded compliance and integrated flexible electronics. Such actuator–sensor materials may allow common modular design, in which nuts and bolts are used to assemble robots, to be replaced by a single-step autonomous fabrication. In addition, new actuator designs, along with advanced manufacturing methods, will further enhance the actuation performance by maximizing the actuation stress and strain. Folding, origami, fabric-embedded and 4D-robot designs may pave the way for miniaturization and multi-dimensional controlled actuation on demand.

The current Special Issue of Actuators provides insight into the latest scientific advances in the development and manufacturing of new materials for soft actuators, and their designs, aimed at improving soft actuation performance.

The following topics are of particular interest:

Materials

Stimuli-responsive elastomer composites
Multifunctional material systems for soft actuation and actuation-sensing
Materials with functionally-graded compliance
Electrically-driven soft actuators
Soft-material robots
Soft-hard actuators
Soft actuator-sensor material systems
Liquid metal alloys for soft actuation, sensing and actuation control
Fabric-involving actuation (including wearables)

Related fabrication and processing methods:

3D- and 4D-printing techniques
Single-step fabrication of actuator-sensor systems
Micro- and nano-fabrication
Microfluidics

Design and manufacturing:

Performance-leveraging soft actuator design
“Bolts-and-nuts-free” soft actuator design and manufacturing
Bio-inspired soft actuator design
Soft artificial muscles
Origami-based design and manufacturing
Smart folding design and manufacturing
Fabric-involving actuator design and manufacturing

New! Artificial Intelligence (AI) and Computational Simulation of Soft Materials Towards Implementation in Soft Actuation

Understanding the properties and performance of soft functional materials for implementation in Soft Actuation using computer simulations and/or AI, including, but not limited to:

Materials

Relation between structure and function in soft materials (micro- and macro-levels)
Nonlinear behavior of soft materials for actuation
Elastic/viscoelastic behavior
Wave propagation in soft matter
Deformation of soft matter under various actuation stimuli
Mechanical properties of soft material systems
Simulation of composite material behavior
Simulation of manufacturing methods (including 3D-printing)

Design

Design of soft actuators
Material design for soft actuation
Evolutionary robotics and design automation
Forward and inverse kinematics in design of soft actuators
CAD in design of soft actuators
Design optimization

AI in Soft Actuation
Using AI for performance prediction and control of soft actuators

I welcome you to submit your research manuscripts to this Special Issue.

Sincerely,
Dr. Aslan Miriyev
Guest Editor

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Actuators is an international peer-reviewed open access monthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2400 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

Soft actuators
Soft-hard actuators
Soft artificial muscles
Soft actuator-sensors
Advanced manufacturing of soft actuators
3D-Printing of soft actuators
Soft actuator design
Bio-inspired design
Folding, origami, 4D-robots
Fabric-embedded soft actuators

Published Papers (9 papers)

Download All Papers

Editorial

Jump to: Research

13 pages, 789 KiB
