Silicon-based Micro/Nanofabrication for Biomedical Applications

A special issue of Micromachines (ISSN 2072-666X).

Deadline for manuscript submissions: closed (3 May 2018) | Viewed by 17829

Special Issue Editor

Department of Electronics and Computer Engineering, The Hong Kong University of Science & Technology, Kowloon, Hong Kong, China
Interests: bio-micro(nano)fluidics; bioelectronics; biomedical engineering (BME); biomedical microelectromechanical systems (BioMEMS); biosensors
Special Issues, Collections and Topics in MDPI journals

Special Issue Information

Dear Colleagues,

Silicon-based micro/nanofabrication is an advanced technology that emerged out of the miniaturization of electronics (microelectronics) and monolithic large-scale integration, and have yielded microchips with complex functionalities. This technology has also been instrumental for the subsequent miniaturization of sensors and actuators into integrated compact systems (also known as micromachines or microelectromechanical systems, MEMS), with applications ranging from consumer electronics to automative and biomedical fields. Biomedical applications of MEMS (BioMEMS) have led to various microdevices, including medical implants (e.g., silicon neural probes, artificial retinas) and analytical devices for prognosis and diagnostics. The latter has led to the rise of micro/nanofluidics, a field that is mainly concerned with the processing and delivery of a minute amount of sample to biosensors. Along this journey, silicon has gone from being a purely electronic material to a structural and mechanical one. Despite the competition faced from various other materials (glass, polymer, paper) for reasons of cost and material properties, silicon offers a unique combination of scaling, precision, performance, and reliability, which is unmatched, and yet can be detrimental for applications like cancer and medical implants. We dedicate this Special Issue to silicon-based micro/nanofabrication for biomedical applications and invite contributions on this topic.
