The rapid development of the Internet of Things (IoT) has imposed increasingly stringent power consumption requirements on receiver design. Unlike phase-locked loops (PLLs), free-running oscillators eliminate power-hungry loop circuitry. However, the inherent frequency offset of free-running oscillators introduces uncertainty in the intermediate frequency (IF), preventing the receiver from aligning with the desired channel. To address this, we present a reconfigurable channel receiver employing a free-running oscillator and frequency estimation for low-power IoT applications. The proposed receiver first captures a specific preamble sequence corresponding to the desired channel through multiple parallel sub-channels implemented in the digital baseband (DBB), which collectively cover the expected IF frequency range. The desired IF frequency is estimated using the proposed preamble-based frequency estimation (PBFE) algorithm. After frequency estimation, the receiver switches to a single-channel mode and tunes its passband center frequency to the estimated IF frequency, enabling high-sensitivity data reception. Measurement results demonstrate that the PBFE algorithm achieves reliable frequency estimation with a minimum IF signal-to-noise ratio (SNR) of 2 dB and an estimation error below 22 kHz. In single-channel mode, with a residual frequency offset of 30 kHz, an 8-point energy accumulation decoding scheme achieves a bit error rate (BER) of 10⁻³ at an IF SNR of 5.2 dB. Compared with the case of the original 50 kHz IF frequency offset, the required SNR is improved by 4.1 dB. Full article

Among wireless communication technologies underlying Internet of Things (IoT)-based smart buildings, IQRF (Intelligent Connectivity Using Radio Frequency) technology is a promising candidate due to its low power consumption, cost-effectiveness, and wide coverage. However, effectively modeling the propagation characteristics of IQRF in complex indoor environments for simple and accurate network deployment remains challenging, as architectural elements like walls and corners cause substantial signal attenuation and unpredictable propagation behavior. This study investigates the applicability of a site-specific modeling approach, originally developed for urban street canyons, to characterize peer-to-peer (P2P) IQRF links operating at 868 MHz in typical indoor scenarios, including line-of-sight (LoS), one-turn, and two-turn non-line-of-sight (NLoS) configurations. The received signal powers are compared with well-known empirical models, including international telecommunication union radio communication sector (ITU-R) P.1238-9 and WINNER II, and ray-tracing simulations. The results show that while ITU-R P.1238-9 achieves lower prediction error under LoS conditions with a root mean square error (RMSE) of 5.694 dB, the site-specific approach achieves substantially higher accuracy in NLoS scenarios, maintaining RMSE values below 3.9 dB for one- and two-turn links. Furthermore, ray-tracing simulations exhibited notably larger deviations, with RMSE values ranging from 7.522 dB to 16.267 dB and lower correlation with measurements. These results demonstrate the potential of site-specific modeling to provide practical, computationally efficient, and accurate insights for IQRF network deployment planning in smart building environments. Full article

Road transport in the European Union is responsible for approximately 60% of PM10 emissions and 45% of PM2.5 emissions. Acoustic agglomeration is researched to be the most effective after-treatment method to control particle pollution. Recent experimental research suggests that at a frequency of around 20 kHz and a sound pressure level of 140 dB, particles can be agglomerated. The kinetic energy of the particles is influenced by the presence of acoustics, and this enhances the collision efficiency between the particles. These collided fine particles increase in size and can be easily filtered through conventional filters. Additionally, clean burning biofuels produce comparatively fewer particles; hence RME is used for experiments along with its two blends of isopropanol (RME95I5 and RME90I10). The results are then compared to those of standard diesel fuel. With an increase in load, an average reduction of 20% in fine particles is observed along with an increase in large-sized particles. The aggregation of smaller particles is observed in a range of 0–50% in almost all tested conditions. With the increase in isopropanol from 5 to 10%, oxygen content in the fuel increased by 7%, a 1% reduction in carbon and a 2% reduction in C/H ratio is observed which led to a 6 and 9% reduction in particle emissions at 60 Nm and 90 Nm, respectively. At higher loads, D100, RME95I5 and RME90I10 recorded an agglomeration of 10%, 111% and 189%, respectively. Similar results are observed for the tendency for agglomeration at lower loads. Full article

This paper presents the design of a 140 GHz vector-sum phase shifter in a 28 nm CMOS process. Two variable-gain amplifiers—Gilbert cell and current-steering amplifiers—are investigated and compared. The Gilbert cell-based phase shifter controls the tail current source in a common-source amplifier. However, this configuration exhibits insufficient gain at D-band frequencies. To address this issue, we designed a current-steering variable-gain amplifier in cascode form to improve the gain performance. I/Q signals are generated by Marchand baluns and Lange couplers, and a 13-bit digital-to-analog converter enables fine bias control. Simulation results show that the current-steering phase shifter achieves up to a 4.4 dB higher gain than the Gilbert cell-based phase shifter, with an RMS gain error below 1.3 dB and an RMS phase error below 4.8° across 129–144 GHz. Full article

This paper presents a simplified matching network using coupled transmission lines (CTLs) for broadband power amplifiers. The proposed structure consists of a CTL with an electrical length shorter than $\lambda$/4 and a single shunt component, exhibiting excellent frequency characteristics across a wide bandwidth at both the input and load networks of the transistor. The reactance variation of the non-Foster elements in the equivalent circuit of the CTL with respect to frequency was analyzed, and the external reactive components were accordingly optimized to extend the bandwidth of the matching network. The proposed network was applied to the input and load networks of a GaN HEMT-based power amplifier. It was designed to maintain required performances over a wide frequency range of 1.9–4.9 GHz, covering both LTE and sub-6 GHz 5G bands, thereby achieving a fractional bandwidth (FBW) of 88.2%. The CTLs were fabricated on a two-layer printed-circuit board (PCB), and the additional shunt components were designed using surface-mount devices (SMDs). The overall power-amplifier module occupied a small area of 40 × 35 mm². Using the continuous-wave (CW) signal, the proposed power amplifier exhibited a power gain of 10–14.8 dB and a drain efficiency (DE) of 47.5–60% at a saturated output power of 7.1–9.3 W across the entire operating frequency band. Using a 5G New Radio (NR) signal with a 100 MHz bandwidth and a peak-to-average power ratio (PAPR) of 7.8 dB, the amplifier achieved an average output power of 30 dBm, a DE of 20–27.5%, and an adjacent-channel leakage power ratio (ACLR) better than −30 dBc. Full article

This letter presents a high-gain frequency-controlled beam-scanning antenna specifically designed for through-wall radar (TWR) applications in the W band. The antenna leverages the leaky-wave radiation generated by spoof surface plasmon polaritons (SSPPs) propagating on sinusoidally modulated reactance surfaces (SMRS). Periodically arranged quasi-H-shaped metallic cells are employed to achieve beam scanning. The integration of a flared structure at the apex of the designed SSPP antenna results in a significant gain enhancement, yielding an approximate increase of 10 dB. From 92.8 to 97.6 GHz, the antenna exhibits a reflection coefficient of |S11| < −10 dB, provides a high scanning rate of 4.05°/%, and achieves a realized gain of 20.9 dBi. This design eliminates the necessity for mechanical rotators and phase shifters that are typical in traditional TWR systems, significantly reducing system complexity and cost. A vehicle-mounted W-band TWR system was developed, integrating the designed SSPP antenna and employing linear frequency modulation technology to emit millimeter-wave signals for electronic scanning detection. With an economical and efficient design approach, testing has demonstrated that the system can perform through-wall imaging at a distance of 10 m, both in stationary and in motion conditions. Full article

Implantable technologies targeting the cerebral cortex and deeper brain structures are increasingly utilised in human–machine interfacing, advanced neuroprosthetics, and clinical interventions for neurological conditions. These systems require highly efficient and low-power methods for exchanging information between the implant and external electronics. Traditional approaches often rely on inductively coupled data transfer (ic-DT), where the same coils used for wireless power are modulated for communication. Other designs use high-frequency antenna-based radio systems, typically operating in the 401–406 MHz MedRadio band or the 2.4 GHz ISM band. A promising alternative is intrabody communication (IBC), which leverages the bioelectrical characteristics of body tissue to enable signal propagation. This work presents a theoretical investigation into two schemes—inductive coupling and galvanically coupled IBC (gc-IBC)—as applied to cortical data links, considering frequencies from 1 to 10 MHz and implant depths of up to 7 cm. We propose a hybrid solution where gc-IBC supports data transmission and inductive coupling facilitates wireless power delivery. Our findings indicate that gc-IBC can accommodate wider bandwidths than ic-DT and offers significantly reduced path loss, approximately 20 dB lower than those of conventional RF-based antenna systems. Full article

Gas pipelines are a critical means of transportation in industrial production. To detect gas pipeline leaks, ultrasonic transducers with specific center frequencies and high sensitivity are required. This paper proposes a novel air-coupled ultrasonic transducer design based on a horn-type matching layer and a bending-mode type of piezoelectric material, specifically tailored for gas leak detection scenarios. The transducer design is optimized by the finite element method, focusing on the basic components of the piezoelectric bimorph, the horn and the supporting tube. First, the influence of various dimensional parameters of the piezoelectric bimorph on the bending vibration mode was analyzed. Then, the effects of the other two components, the horn and the supporting tube, on the piezoelectric bimorph vibration mode were investigated. A parametric scan on the dimensions of these components was conducted to optimize the transducer’s output. Finally, ultrasonic transducers using PMN-PT and PZT were fabricated and tested. The results show that the sensitivity of those transducers surpasses that of similar commercial transducers, especially the PMN-PT one with a center frequency of 40 kHz and a peak receiving sensitivity of −51.1 dB. This transducer, benefiting from the high-performance piezoelectric material and the bending vibration mode, proves to be a promising candidate for high-precision leak detection in gas pipelines. Full article

The Laser Doppler Vibrometer (LDV) is widely used in precision vibration measurement due to its non-contact nature and high accuracy. However, when measuring non-cooperative targets, the internal stray light in the LDV interferes with the target’s return light, creating competition with the reference light, a phenomenon known as interference competition. This issue is particularly prominent in integrated transceiver LDV systems, where the backscattered light from the lens can be comparable in intensity to the target’s return light, significantly degrading phase extraction accuracy and limiting the LDV’s applicability. To address this challenge, this paper proposes a noise suppression algorithm based on the In-phase and Quadrature (IQ) demodulation. The algorithm uses the power spectrum within each frame’s relevant frequency band as an evaluation metric and employs the Three-point Probe Extremum Localization (3P-PEL) method to estimate the amplitude and phase of the stray light interference with the reference light in real time. This enables the accurate extraction of the interference signal between the measurement light and the reference light. Both simulations and experiments validate the effectiveness of the proposed method. The simulation results demonstrate that when the stray-to-measurement power ratio is below 0.25, the proposed algorithm can suppress spurious signals induced by multi-beam interference by more than 25 dB, while experimental results show it can reduce such signals below the LDV’s noise floor in various motion scenarios. The proposed algorithm holds potential applications in laser interferometry and effectively enhances LDV measurement accuracy. Full article

The transportation of large murals with significant historical and cultural value presents a considerable challenge due to their high susceptibility to damage caused by mechanical vibrations. This article presents a study on the design, implementation, and evaluation of an advanced wire rope isolator system, complemented by vibration sensors equipped with indicator lights for real-time monitoring. The research focuses on the case study of the relocation of Diego Rivera’s mural “Pan American Unity” from the City College of San Francisco to the San Francisco Museum of Modern Art (SFMOMA). The study observed a reduction in vibration transmission to the mural panels, achieving vibration attenuation of up to −20 dB in the critical 10–30 Hz frequency band during transportation. It was also found that the implementation of real-time monitoring with indicator lights alerted operators and conservators to critical vibration levels, enabling immediate intervention. Full article

Traditional zero-compensation techniques employed to improve sub-sampling phase-locked loop (SSPLL) stability often exacerbate spur degradation or incur excessive area overhead, rendering them unsuitable for high-resolution image sensor applications. This paper proposes a novel SSPLL based on capacitor multiplication technology. This capacitor multiplication technology employs dual charge pumps (CP1 and CP2) in a coordinated operational scheme where their charge/discharge states are inversely synchronized. The effective capacitance of the loop filter is thereby amplified without expanding the physical layout area dedicated to capacitive components. Meanwhile, the continued use of zero-compensation technology ensures the stability of the SSPLL. The proposed SSPLL is designed and verified in a 55 nm CMOS process. At a 1.2 GHz output frequency, simulation results show a spot phase noise of −131.5 dBc/Hz at 1 MHz offset, accompanied by an integrated RMS jitter of 549 fs across the 10 kHz to 40 MHz spectrum, spurs suppressed to −51.3 dB, while maintaining a power efficiency of 3.81 mW and a compact layout area of 0.064 mm². All the above results show that by introducing the novel dual-CP charge multiplication technology, the SSPLL can achieve low jitter and low power consumption performance while reducing the layout area, providing a new technical approach for its application in high-resolution image sensors. Full article

To solve the problem of low-frequency aerodynamic noise control of Helmholtz resonators (HR) due to the frequency shift and amplitude reduction in acoustic attenuation caused by increasing fluid flow, the lossless regulation mechanism of the dynamic acoustic mass of a novel embedded-neck Helmholtz resonator (ENHR) metasurface is revealed through finite element simulation and wind tunnel experiments. Firstly, the flow–acoustic coupling aerodynamic simulation model based on the ducted silencer system is established. Then, the physical mechanism of lossless regulation of the dynamic acoustic mass for low-frequency aerodynamic noise reduction under incident fluid flow is studied specifically. Finally, a sub-wavelength and larger broadband ENHR metasurface comprising ten parallel cells is designed, in which an average transmission loss (TL) of 18.7 dB within 70–200 Hz with a Mach number (Ma) of 0.05 is achieved. The lossless regulation mechanism of dynamic acoustic mass with metasurface design would have an extensive potential application value in controlling low-frequency aerodynamic noise. Full article

This study presents a lightweight metasurface microwave absorption filter (MMAF) designed for low-frequency stealth applications in the L-band. The metasurface is optimized using a genetic algorithm to achieve broadband absorption at subwavelength thickness. The fabricated MMAF consists of a glass fiber-reinforced plastic layer, a metasurface layer, and a dielectric layer with a size of 30 × 30 cm². It maintains a reflection coefficient below −10 dB in the frequency range of 1.01–1.78 GHz. Experiments using small MMAFs measuring 15 × 15 cm² confirmed stable performance after composite molding. In addition, the results from small MMAFs configured in a 2 × 2 array were similar to those of the 30 × 30 cm² structure. These results highlight the potential of the MMAF for scalable deployment on curved or segmented surfaces, expanding its applicability to various stealth platforms. Full article

In this paper, a 3D-printed S-Band corrugated horn antenna with X-Band radar cross section (RCS) reduction is investigated. This work demonstrates effective RCS reduction at the X-band through the application of the phase cancellation principle. Specifically, the corrugated horn antenna is partitioned into eight identical sections, with three discrete height offsets introduced between them. The reflection phase cancellation, which can be attained through the path difference introduced by a designed height step among different regions, leads directly to a consequent suppression of scattered waves. The proposed low-RCS corrugated horn antenna is monolithically fabricated using stereolithography appearance (SLA) 3D printing technology, followed by a surface metallization process. The measured results demonstrate that the proposed antenna operates over the frequency band of 2.34–3.3 GHz in the S-band with good impedance matching, exhibiting a peak gain of 11.7 dB. Furthermore, the monostatic RCS of the antenna under normal incidence for both x- and y-polarizations exhibits a significant reduction of over 10 dB within the frequency range of 8.7–12.0 GHz and 8.2–12.0 GHz, respectively. This indicates that effective stealth performance is achieved across the majority of the X-band. The proposed design integrates exceptional out-of-band RCS reduction, low cost, light weight, and high efficiency, making it a promising candidate for radar stealth system applications. Full article

In comparison to internal combustion engines, which usually have low frequency, broadband excitations, in electric vehicles, tonal excitations from the electric drivetrain are noticeable and disturbing. As the acoustic and structural dynamic behavior, often referred to as noise, vibration, and harshness (NVH), strongly influences customers’ quality perceptions, optimizing it is a key challenge in development. This study investigates the influence of static rotor–stator eccentricity on the NVH behavior of an electric drivetrain using a transient elastic multibody simulation (eMBS) model incorporating non-linear gear meshing, bearing contact, and electromagnetic forces. The analysis identifies the 36th order excitation of the electric machine as the dominant source, leading to a maximum total acceleration level of 152 dB. Two specific excitation directions were found to reduce this amplitude most effectively. However, varying the amount of static eccentricity in these directions resulted in only minor vibration reductions (<1.5 dB). The findings indicate that the symmetric mode shapes of the cylindrical housing govern the response, indicating that addressing the excitability of housing modes by developing asymmetric housing designs could offer a more effective approach for NVH optimizations of electric drivetrains. Full article
