The paper presents experimental results for a modified pulsed plasma thruster (PPT) with solid propellant, using a coaxial anode–cathode design. Graphite from pencil leads served as propellant, and a tungsten trigger electrode was tested to reduce carbonization effects. Experiments were performed in a vacuum chamber at 0.001 Pa, employing diagnostics such as discharge current/voltage recording, power measurement, ballistic pendulum, time-of-flight (TOF) method, and a Faraday cup. Current and voltage waveforms matched an oscillatory RLC circuit with variable plasma channel resistance. Key discharge parameters were measured, including current pulse duration/amplitude and plasma channel formation/decay dynamics. Impulse bit values, obtained with a ballistic pendulum, reached up to 8.5 μN·s. Increasing trigger capacitor capacitance reduced thrust due to unstable “pre-plasma” formation and partial pre-discharge energy loss. Using TOF and Faraday cup diagnostics, plasma front velocity, ion current amplitude, current density, and ion concentration were determined. Tungsten electrodes produced lower charged particle concentrations than graphite but offered better adhesion resistance, minimal carbonization, and stable long-term performance. The findings support optimizing trigger electrode materials and PPT operating modes to extend lifetime and stabilize thrust output. Full article

Beam diagnostics are essential tools for monitoring the performance of charged particle beams and the safe operation of particle accelerators. The performance of an accelerator is determined by evaluating the properties of beam particles, such as energy, charge, spatial, and temporal density distributions, which require very specific instruments. Faraday Cups (FCs) have emerged as important beam diagnostic devices because of their ability to accurately measure the beam charge and, in some cases, the charge distribution, which can be subsequently used to reconstruct transverse beam profiles. This paper aims to provide a detailed review of FCs, their principles, and their design challenges. FCs have applications in various scientific disciplines that include the measurement of beam current/intensity in particle accelerators, in addition to those for mass spectrometry, beam profiles/total beam currents for broad ion beams, thermonuclear fusion, and antimatter experiments. This review also covers and discusses the versatility of FCs in various scientific disciplines, along with showcasing the technological advancements that include improved collector materials, novel designs, enhanced measurement techniques, and developments in electronics and data acquisition (D.A.Q). A summary of the challenges faced while working with the FCs, such as sensitivity, calibration, and potential errors, is included in this review. Full article

Background: This study aims to present the feasibility of developing a synchrotron-based proton ultra-high dose rate (UHDR) pencil beam scanning (PBS) system. Methods: The RF extraction power in the synchrotron system was increased to generate 142.4 MeV pulsed proton beams for UHDR irradiation at ~100 nA beam current. The charge per spill was measured using a Faraday cup. The spill length and microscopic time structure of each spill was measured with a 2D strip transmission ion chamber. The measured UHDR beam fluence was used to derive the spot dwell time for pencil beam scanning. Absolute dose distributions at various depths and spot spacings were measured using Gafchromic films in a solid-water phantom. Results: For proton UHDR beams at 142.4 MeV, the maximum charge per spill is 4.96 ± 0.10 nC with a maximum spill length of 50 ms. This translates to an average beam current of approximately 100 nA during each spill. Using a 2 × 2 spot delivery pattern, the delivered dose per spill at 5 cm and 13.5 cm depth is 36.3 Gy (726.3 Gy/s) and 56.2 Gy (1124.0 Gy/s), respectively. Conclusions: The synchrotron-based proton therapy system has the capability to deliver pulsed proton UHDR PBS beams. The maximum deliverable dose and field size per pulse are limited by the spill length and extraction charge. Full article

The Dual-beam ion irradiation facility for Fusion materials (DiFU) has been developed and installed at the Ruđer Bošković Institute with the purpose to perform irradiation of samples of fusion materials by one or two ion beams. Ion beams are delivered to the DiFU chamber by a 6 MV EN Tandem Van de Graaff and a 1 MV HVE Tandetron accelerator, enabling irradiation of areas up to 30 × 30 mm². The sample holder enables the three-dimensional positioning of samples that can be irradiated while being heated, cooled, or kept at room temperature. Ion fluxes are measured indirectly by the insertion of two large Faraday cups. Besides, the ion flux is monitored continuously by two sets of horizontal and vertical slits, which, in turn, define the limits of the irradiation area on the sample. Sample temperature and conditions during irradiation are additionally monitored by a set of thermocouples, an IR camera, and a video camera. Particular care is dedicated to the mitigation of carbon contamination during ion irradiation. Full article

A magnetically insulated transmission line (MITL) is an inevitable choice for ultra-high power density energy transmissions. Its working process is complex, with an obvious influence on the working process of electron beam diodes and other load devices. The power coupling process of an electron beam diode driven by an MITL is a difficult problem in pulse power applications. No research is available on the electron beam characteristics of its anode. In this paper, a fast time response full absorption Faraday cup was developed. An intense electron beam measurement waveform showing the multi-stage characteristics was obtained through measurements using the Faraday cup absorber as the anode of the electron beam diode. The stage characteristics of the beam were in good agreement with the vacuum transmission, magnetic insulation formation, and multi-stage process of the stable magnetic insulation. The beam intensity corresponded with the conduction current of the cathode. It was obviously smaller than the current of the anode. The results reflected the influence of the different processes of the magnetic insulation on the transmission line on the beam waveforms in the diode area and provided a reference for the power transmission of the power device and the load system design. Full article

Purpose: The electron linac ElectronFlash installed at Institut Curie (Orsay, France) is entirely dedicated to FLASH irradiation for radiobiological and pre-clinical studies. The system was designed to deliver an ultra-high-dose rate per pulse (UHDR) (above ${10}^6$ Gy/s) and a very high average dose rate at different energies and pulse durations. A campaign of tests and measurements was performed to obtain a full reliable characterizations of the electron beam and of the delivered dose, which are necessary to the radiobiological experiments. Methods: A Faraday cup was used to measure the electron charges in a single RF pulse. The percentage depth dose (PDD) and the transverse dose profiles, at the energies of 5 MeV and 7 MeV, were evaluated employing Gafchromic films EBT-XD for two Poly-methylmethacrylate (PMMA) applicators with irradiation sizes of 30 mm and 120 mm, normally used for in vivo and in vitro experiments, respectively. The results were compared with Monte Carlo (MC) simulations. Results: The measurements were performed during a period of a few months in which the experimental set up was adapted and tuned in order to characterize the electron beam parameters and the values of delivered doses before the radiobiological experiments. The measurements showed that the dose parameters, obtained at the energy of 5 MeV and 7 MeV with different applicators, fulfill the FLASH regime, with a maximum value of an average dose rate of 4750 Gy/s, a maximum dose per pulse of 19 Gy and an instantaneous dose rate up to 4.75 $\times {10}^6$ Gy/s. By means of the PMMA applicators, a very good flatness of the dose profiles was obtained at the cost of a reduced total current. The flatness of the large field is reliable and reproducible in radiobiological experiments. The measured PDD and dose profiles are in good agreement with Monte Carlo simulations with more than $95\%$ of the gamma-index under the thresholds of 3 mm/$3\%$. Conclusions: The results show that the system can provide UHDR pulses totally satisfying the FLASH requirements with very good performances in terms of beam profile flatness for any size of the fields. The monitoring of electron beams and the measurement of the dose parameters played an important role in the in vivo and in vitro irradiation experiments performed at the Institut Curie laboratory. Full article

Electrostatically coated abrasives have drawn vast attention in many industrial applications. Therefore, influence of humidity on the electrical properties of α-SiC and α-Al₂O₃ abrasive powders with three μm-range particle sizes are here investigated using electrostatic charge and DC resistivity analysis. From the three particle size ranges used, 15–16 μm, 60–63 μm and 153–156 μm, the intermediate one (60–63 μm) is found to be associated with the highest charge values, measured using a double Faraday cup method, as well as the highest resistivity for both materials. However, comparing SiC and Al₂O₃ powders, the latter ones present about twice larger charges in dry and normal humidity states accompanied by several orders of magnitude larger resistivity. Under humid conditions all the powders reveal diminishing charge and resistivity values. Full article

An electron cyclotron resonance (ECR) ion source (ECRIS) can generate an available amount of multicharged ions, thus it is not limited for use in the field of accelerator science, but also in medical/biological fields, such as for heavy ion beam cancer treatment and ion engines. The processes of generating multicharged ions are mainly sequential collisions of a direct ionization process by electrons, and have good ion confinement characteristics. By utilizing this confinement property, we have synthesized iron-encapsulated fullerenes, which are supramolecular and can be expected to have various high functions. Fullerenes and iron ions are vaporized from pure solid materials and introduced into the ECRIS together with the support gas. We investigated conditions under which fullerene ions do not dissociate and iron ions are generated so that both can coexist. Generated ions are extracted from the ECRIS and separated by mass/charge with a dipole magnet, and detected with a Faraday cup. This measurement system is characterized by a wide dynamic range. The charge-state distribution (CSD) of ion currents was measured to investigate the optimum conditions for supramolecular synthesis. As a result, a significant spectrum suggesting the possibility of iron-encapsulated fullerenes was obtained. This paper describes the details of these experimental results. Full article

Turbulent cascade transferring the free energy contained within the large scale fluctuations of the magnetic field, velocity and density into the smaller ones is probably one of the most important mechanisms responsible for heating of the solar corona and solar wind, thus the turbulent behavior of these quantities is intensively studied. The temperature is also highly fluctuating quantity but its variations are studied only rarely. There are probably two reasons, first the temperature is tensor and, second, an experimental determination of temperature variations requires knowledge of the full velocity distribution with an appropriate time resolution but such measurements are scarce. To overcome this problem, the Bright Monitor of the Solar Wind (BMSW) on board Spektr-R used the Maxwellian approximation and provided the thermal velocity with a 32 ms resolution, investigating factors influencing the temperature power spectral density shape. We discuss the question whether the temperature spectra determined from Faraday cups are real or apparent and analyze mutual relations of power spectral densities of parameters like the density, parallel and perpendicular components of the velocity and magnetic field fluctuations. Finally, we compare their spectral slopes with the slopes of the thermal velocity in both inertial and kinetic ranges and their evolution in course of solar wind expansion. Full article

A Faraday cup (FC) is an instrument dedicated to current measurement in beams, jets and plasmas. It consists of a set of polarized electrodes mounted in such a way plasma sheath effect can be neglected, yielding accurate and reliable results. A FC is composed of three main parts, namely a collector or cup, which collects the current, a collimator, which defines the collection area and can contribute to limit electrons from entering the cup and a housing which protects the instrument from perturbation caused by the surrounding medium. In this paper, we provide experimental results of the effect of the collimator upon the measured ion current within the beam of a low-power Hall thruster. Different collimator materials, aperture diameters and polarization voltages are studied to determine the optimum design. Minimum dimension as well as appropriate materials are given as a conclusion in the case of low-power Hall thruster beam investigation. Full article

The 100 W-class ISCT100-v2 Hall Thruster (HT) has been characterized in terms of far-field plume properties. By means of a Faraday Cup and a Retarding Potential Analyzer, both the ion current density and the ion energy distribution function have been measured over a 180 ${}^{\circ }$ circular arc for different operating points. Measurements are compared to far-field plume characterizations performed with higher power Hall thrusters. The ion current density profiles remain unchanged whatever the HT input power, although an asymptotic limit is observed in the core of the plume at high discharge voltages and anode mass flow rates. In like manner, the ion energy distribution functions reveal that most of the beam energy is concentrated in the core of the plume $[-{40}^{\circ };{40}^{\circ }]$ . Moreover, the fraction of low energy ion populations increases at large angles, owing to charge exchange and elastic collisions. Distinct plume regions are identified; they remain similar to the one described for high-power HTs. An efficiency analysis is also performed in terms of current utilization, mass utilization, and voltage utilization. The anode efficiency appears to be essentially affected by a low voltage utilization, the latter originating from the large surface-to-volume ratio inherent to low-power HTs. Experimental results also show that the background pressure clearly affects the plume structure and content. Full article

A new chemical separation has been developed to isolate uranium (U) using two UTEVA columns to minimize iron and thorium interferences from high background area soil samples containing minerals like monazites and ilmenite. The separation method was successfully verified in some certified reference materials (CRMs), for example, JSd-2, JLk-1, JB-1 and JB-3. The same method was applied for purification of U in Fukushima soil samples affected by the Fukushima dai-ichi nuclear power station (FDNPS) accident. Precise and accurate measurement of ²³⁴U/²³⁸U and ²³⁵U/²³⁸U isotope ratios in chemically separated U were carried out using a multi-collector inductively coupled plasma mass spectrometer (MC-ICP-MS). In this mass spectrometric method, an array of two Faraday cups (10¹¹ Ω, 10¹² Ω resistor) and a Daly detector were simultaneously employed. The precision of U isotope ratios in an in-house standard was evaluated by replicate measurement. Relative standard deviation (RSD) of ²³⁴U/²³⁸U and ²³⁵U/²³⁸U were found to be 0.094% (2σ) and 0.590% (2σ), respectively. This method has been validated using a standard reference material SRM 4350B, sediment sample. The replicate measurements of ²³⁴U/²³⁸U in SRM shows 0.7% (RSD). This developed method is suitable for separation of U and its isotope ratio measurement in environmental samples. Full article

Precise tellurium (Te) isotope ratio measurement using mass spectrometry is a challenging task for many decades. In this paper, Te isotope ratio measurements using multi-collector inductively coupled plasma mass spectrometry (MC–ICP–MS) in terrestrial Te standards have been reported. Newly developed Faraday cup with 10¹² Ω resistor is used to measure low abundance ¹²⁰Te, whereas the 10¹¹ Ω resistor is used to measure other Te isotopes. The relative standard deviation obtained for Te isotope ratio measurement by Faraday cups of ¹²⁰Te/¹²⁸Te [0.002907(05)], ¹²²Te/¹²⁸Te [0.079646(10)], ¹²³Te/¹²⁸Te [0.027850(07)], ¹²⁵Te/¹²⁸Te [0.221988(09)], ¹²⁶Te/¹²⁸Te [0.592202(20)], and ¹³⁰Te/¹²⁸Te [1.076277(30)] were 0.140%, 0.014%, 0.026%, 0.005%, 0.004%, and 0.004%, respectively. The measured isotope ratio results are compared with previous results obtained by thermal ionization mass spectrometry (TIMS), negative thermal ionization mass spectrometry (N–TIMS), and MC–ICP–MS, showing an improvement in the precision about one order of magnitude for ¹²⁰Te/¹²⁸Te ratio. The present study shows better precision for Te isotope ratios compared to earlier studies. Full article

Low energy ion measurements in the vicinity of a comet have provided us with important information about the planet’s evolution. The calibration of instruments for thermal ions in the laboratory plays a crucial role when analysing data from in-situ measurements in space. A new low energy ion source based on carbon nanotube electron emitters was developed for calibrating the ion-mode of mass spectrometers or other ion detectors. The electron field emission (FE) properties of carbon nanotubes (CNTs) for H₂, He, Ar, O₂, and CO₂ gases were tested in the experiments. H₂, He, Ar, and CO₂ adsorbates could change the FE temporarily at pressures from10⁻⁶ Pa to10⁻⁴ Pa. The FE of CNT remains stable in Ar and increases in H₂, but degrades in He, O₂, and CO₂. All gas adsorbates lead to temporary degradation after working for prolonged periods. The ion current of the ion source is measured by using a Faraday cup and the sensitivity is derived from this measurement. The ion currents for the different gases were around 10 pA (corresponding to 200 ions/cm³ s) and an energy of ~28 eV could be observed. Full article

Accurate knowledge of the beam energy distribution is crucial for particle accelerators, compact medical cyclotrons for the production of radioisotopes in particular. For this purpose, a compact instrument was developed, based on a multi-leaf Faraday cup made of thin aluminum foils interleaved with plastic absorbers. The protons stopping in the aluminum foils produce a measurable current that is used to determine the range distribution of the proton beam. On the basis of the proton range distribution, the beam energy distribution is assessed by means of stopping-power Monte Carlo simulations. In this paper, we report on the design, construction, and testing of this apparatus, as well as on the first measurements performed with the IBA Cyclone 18-MeV medical cyclotron in operation at the Bern University Hospital. Full article
