Search Results (34)

This paper presents the design, optimization, and validation of a dual three-phase yokeless and segmented armature (YASA) axial flux permanent magnet (AFPM) machine for aerospace actuators. The proposed 12-slot, 10-pole topology employs segmented soft magnetic composite (SMC) stator teeth integrated into an additively manufactured aluminium holder, combining modularity, weight reduction, and improved thermal conduction. A multi-objective optimization process based on 3D finite element analysis (FEA) was applied to balance torque capability and losses. The manufacturable design achieved a peak torque of 28.3 Nm at 1400 rpm and a peak output power of 3.5 kW with an efficiency of 81.6%, while limiting short-circuit currents to 14 Arms. Transient structural simulations revealed that three-phase short circuits induce unbalanced axial forces, exciting rotor wobbling—a phenomenon not previously reported for YASA machines. A prototype was fabricated and tested, with static torque measurements deviating by 8.6% from FEA predictions. By contrast, line-to-line back-EMF and generator-mode power output exhibited larger discrepancies (up to 20%), attributed to the frequency-dependent permeability and localized eddy currents of the SMC stator material introduced during EDM machining. These results demonstrate both the feasibility and the limitations of YASA AFPM machines for aerospace applications. Full article

The use of additive manufacturing (AM) has seen increased utilization over the last decade, thanks to well-documented advantages such as lower startup costs, reduced wastage, and the ability to rapidly prototype. The poor surface finish of unprocessed AM components is one of the major drawbacks of this technology, with the research literature suggesting a measurable impact on flow characteristics and burner operability. For instance, surface roughness has been shown to potentially increase resistance to boundary layer flashback—an area of high concern, particularly when utilizing fuels with high hydrogen content. A more detailed understanding of the underlying thermophysical mechanisms is, therefore, required. Computational fluid dynamics can help elucidate the impact of these roughness effects by enabling detailed data interrogation in locations not easily accessible experimentally. In this study, roughness effects on a generic gas turbine swirler were numerically modeled using a low-y+ detached eddy simulation (DES) approach. Three DES models were investigated utilizing a smooth reference case and two rough cases, the latter employing a literature-based and novel equivalent sand-grain roughness (k_s) correlation developed for this work. Existing experimental isothermal and CH₄ data were used to validate the numerical simulations. Detailed investigations into the effects of roughness on flow characteristics, such as swirl number and recirculation zone position, were subsequently performed. The results show that literature-based k_s correlations are unsuitable for the current application. The novel correlation yields more promising outcomes, though its effectiveness depends on the chosen turbulence model. Moreover, it was demonstrated that, for identical k_s values, while trends remained consistent, the extent to which they manifested differed under reacting and isothermal conditions. Full article

This paper presents the development of a novel eddy current array (ECA) system for real-time, layer-by-layer quality control in powder bed fusion (PBF) additive manufacturing. The system is integrated into the recoater of a PBF machine to provide spatially resolved electrical conductivity imaging of the manufactured part. The system features an array of 40 inductive sensors spaced at 1 mm pitch and is capable of performing a full array readout every 0.192 mm at 100 mm/s recoater speed. Array scalability was achieved through the careful selection of the electromagnetic configuration, miniaturized and seamlessly integrated sensor elements, and the use of advanced mixed signal processing techniques. Experimental validation was performed on stainless steel 316L parts, successfully detecting metallic structures and confirming system performance in both laboratory and real-time PBF environments. The prototype achieved a signal-to-noise ratio (SNR) of 26.5 dB, discriminating metal from air and thus demonstrating its potential for improving PBF part design, process optimization, and defect detection. Full article

The processing of pure copper (Cu) has been a challenge for laser-based additive manufacturing for many years since copper powders have a high reflectivity of up to 83% of electromagnetic radiation at a wavelength of 1070 nm. In this study, Cu particles were coated with sub-micrometer tungsten (W) particles to increase the laser beam absorptivity. The coated powders were processed by powder bed fusion-laser beam for metals (PBF-LB/M) with a conventional laser system of <300 watts laser power and a wavelength of 1070 nm. Two different powder manufacturing routes were developed. The first manufacturing route was gas atomization combined with a milling process by a planetary mill. The second manufacturing method was gas atomization with particle co-injection, where a separate W particle jet was sprayed into the atomized Cu jet. As part of the investigations, an extensive characterization of powder and additively manufactured test specimens was carried out. The specimens of Cu/W powders manufactured by the milling process have shown superior results. The laser absorptivity of the Cu/W powder was increased from 22.5% (pure Cu powder) to up to 71.6% for powders with 3 vol% W. In addition, a relative density of test specimens up to 98.2% (optically) and 95.6% (Archimedes) was reached. Furthermore, thermal conductivity was measured by laser flash analysis (LFA) and thermo-optical measurement (TOM). By using eddy current measurement, the electrical conductivity was analyzed. In comparison to the Cu reference, a thermal conductivity of 88.9% and an electrical conductivity of 85.8% were determined. Moreover, the Vickers hardness was measured. The effect of porosity on conductivity properties and hardness was investigated and showed a linear correlation. Finally, a demonstrator was built in which a wall thickness of down to 200 µm was achieved. This demonstrates that the Cu/W composite can be used for heat exchangers, heat sinks, and coils. Full article

Pore and crack formation in parts produced by additive manufacturing (AM) processes, such as laser powder bed fusion, is one of the issues associated with AM technology. Surface and subsurface cracks and pores are induced during the printing process, undermining the printed part durability. In-situ detection of defects will enable the real-time or intermittent control of the process, resulting in higher product quality. In this paper, a new eddy current-based probe design is proposed to detect these defects in parts with various defects that mimic pores and cracks in additively manufactured parts. Electromagnetic finite element analyses were carried out to optimize the probe geometry, followed by fabricating a prototype. Artificial defects were seeded in stainless steel plates to assess the feasibility of detecting various flaws with different widths and lengths. The smallest defect detected had a 0.17 mm radius for blind holes and a 0.43 mm notch with a 5 mm length. All the defects were 0.5 mm from the surface, and the probe was placed on the back surface of the defects. The surface roughness of the tested samples was less than 2 µm. The results show promise for detecting defects, indicating a potential application in AM. Full article

The detection of defects in aluminium alloys using eddy current testing (ECT) can be restricted by higher electrical conductivity. Considering the occurrence of discontinuities during the selective laser melting (SLM) process, checking the ability of the ECT method for the mentioned purpose could bring simple and fast material identification. The research described here is focused on the application of three ECT probes with different frequency ranges (0.3–100 kHz overall) for the identification of artificial defects in SLM aluminium alloy AlSi10Mg. Standard penetration depth for the mentioned frequency range and identification abilities of used probes expressed through lift-off diagrams precede the main part of the research. Experimental specimens were designed in four groups to check the signal sensitivity to variations in the size and depth of cavities. The signal behavior was evaluated according to notch-type and hole-type artificial defects’ presence on the surface of the material and spherical cavities in subsurface layers, filled and unfilled by unmolten powder. The maximal penetration depth of the identified defect, the smallest detectable notch-type and hole-type artificial defect, the main characteristics of signal curves based on defect properties and circumstances for distinguishing between the application of measurement regime were stated. These conclusions represent baselines for the creation of ECT methodology for the defectoscopy of evaluated material. Full article

Additive Manufacturing (AM) Direct Laser Fabrication (DLF) of Ti-5Al-5V-5Mo-3Cr (Ti5553) is being developed as a method for producing aircraft components. The additive manufacturing process can produce flaws near the surface, such as porosity and material voids, which act as stress raisers, leading to potential component failure. Eddy current testing was investigated to detect flaws on or near the surface of DLF Ti5553 bar samples. For this application, the objective was to develop an eddy current probe capable of detecting flaws 500 µm in diameter, located 1 mm below the component’s surface. Two initial sets of coil parameters were chosen: The first, based on successful experiments that demonstrated detection of a near surface flaw in Ti5553 using a transmit-receive array probe, and the second, derived from simulation by Finite Element Method (FEM). An optimized transmit receive coil design, based on the FEM simulations, was constructed. The probe was evaluated on Ti5553 samples containing sub-surface voids of the target size, as well as samples with side-drilled holes and samples with holes drilled from the opposing inspection surface. The probe was able to effectively detect 80% of the sub-surface voids. Limitations included the probe’s inability to detect sub-surface voids near sample edges and a sensitivity to surface roughness, which produces local changes in lift-off. Multifrequency mixing improved signal-to-noise ratio when surface roughness was present on average by 22%. A probe based on that described in this paper could benefit quality assurance of additively manufactured aircraft components. Full article

This study investigates the application of soft magnetic composite (SMC) materials in alternator core manufacturing for bladeless wind turbines operating under the principle of vortex-induced vibration (VIV), employing additive manufacturing (AM) technologies. Through a comparative analysis of alternator prototypes featuring air, SMC, and iron cores, the investigation aims to evaluate the performance of SMC materials as an alternative to the most commonly used material (iron) in VIV BWT, by assessing damping, resonance frequency, magnetic hysteresis, and energy generation. Results indicate that while alternators with iron cores exhibit superior energy generation (peaking at 3830 mV and an RMS voltage of 1019 mV), those with SMC cores offer a promising compromise with a peak voltage of 1150 mV and RMS voltage of 316 mV, mitigating eddy current losses attributed to magnetic hysteresis. Notably, SMC cores achieve a damping rate of 60%, compared to 67% for air cores and 59% for iron cores, showcasing their potential to enhance the efficiency and sustainability of bladeless wind turbines (BWTs). Furthermore, the adaptability of AM in optimizing designs and accommodating intricate shapes presents significant advantages for future advancements. This study underscores the pivotal role of innovative materials and manufacturing processes in driving progress towards more efficient and sustainable renewable energy solutions. Full article

Additively manufactured soft-magnetic components are inherently bulky leading to significant eddy current losses when applied to electrical machines. Prior works have addressed this issue by implementing structures based on the Hilbert space-filling curve which include eddy current suppressing gaps, thereby reducing the fill factor of the soft-magnetic component. The present research aims at investigating a number of space-filling curves in addition to sheets in order to find the optimal eddy current suppressing structure from an electromagnetic point of view. By means of both analysis and finite-element simulation, it was shown that sheets are superior at minimizing eddy current losses while space-filling curves excel at maximizing the fill factor. Full article

In recent years, infrared thermographic (IRT) technology has experienced notable advancements and found widespread applications in various fields, such as renewable industry, electronic industry, construction, aviation, and healthcare. IRT technology is used for defect detection due to its non-contact, efficient, and high-resolution methods, which enhance product quality and reliability. This review offers an overview of active IRT principles. It comprehensively examines four categories based on the type of heat sources employed: pulsed thermography (PT), lock-in thermography (LT), ultrasonically stimulated vibration thermography (UVT), and eddy current thermography (ECT). Furthermore, the review explores the application of IRT imaging in the renewable energy sector, with a specific focus on the photovoltaic (PV) industry. The integration of IRT imaging and deep learning techniques presents an efficient and highly accurate solution for detecting defects in PV panels, playing a critical role in monitoring and maintaining PV energy systems. In addition, the application of infrared thermal imaging technology in electronic industry is reviewed. In the development and manufacturing of electronic products, IRT imaging is used to assess the performance and thermal characteristics of circuit boards. It aids in detecting potential material and manufacturing defects, ensuring product quality. Furthermore, the research discusses algorithmic detection for PV panels, the excitation sources used in electronic industry inspections, and infrared wavelengths. Finally, the review analyzes the advantages and challenges of IRT imaging concerning excitation sources, the PV industry, the electronics industry, and artificial intelligence (AI). It provides insights into critical issues requiring attention in future research endeavors. Full article

Residual stress occurs in the materials after different methods of processing due to the application of pressure and/or thermal gradient. The occurrence of residual stresses can be observed in both subtractive and additive-manufactured (AM) materials and objects. However, pressure residual stresses are considered, in some cases, to have a positive effect; there are applications where the neutral stress state is required. As there is a lack of standards describing the heat treatment of AM materials, there is a need for experimental research in this field. The objective of this article is to determine the heat treatment thermal regime to achieve close to zero stress state in the subsurface layer of additively manufactured AM316L stainless steel. The presented objective leads to the long-term goal of neutral etalons for eddy current residual stress testing preparation. A semi-product intended for the experiment was prepared using the Selective Laser Melting (SLM) process and subsequently cut, using Abrasive Water Jet (AWJ) technology, into experimental specimens, which were consequently heat-treated in combination with four temperatures and three holding times. Residual stresses were measured using X-ray diffraction (XRD), and microstructure variations were observed and examined. A combination of higher temperature and longer duration of heat treatment caused more significant stress relaxation, and the original stress state of the material influenced a degree of this relaxation. The microstructure formed of cellular grains changed slightly in the form of grain growth with randomly occurring unmolten powder particles, porosity, and inclusion precipitation. Full article

The method of making parts through additive manufacturing (AM) is becoming more and more widespread due to the possibility of the direct manufacturing of components with complex geometries. However, the technology’s capacity is limited by the appearance of micro-cracks/discontinuities during the layer-by-layer thermal process. The ultrasonic (US) method is often applied to detect and estimate the location and size of discontinuities in the metallic parts obtained by AM as well as to identify local deterioration in structures. The Ti6Al4V (Ti64) alloy prepared by AM needed to acquire a high-quality densification if remarkable mechanical properties were to be pursued. Ultrasonic instruments employ a different type of scanning for the studied samples, resulting in extremely detailed images comparable to X-rays. Automated non-destructive testing with special algorithms is widely used in the industry today. In general, this means that there is a trend towards automation and data sharing in various technological and production sectors, including the use of intelligent systems at the initial stage of production that can exclude defective construction materials, prevent the spread of defective products, and identify the causes of certain instances of damage. Placing the non-destructive testing on a completely new basis will create the possibility for a broader analysis of the primary data and thus will contribute to the improvement of both inspection reliability and consistency of the results. The paper aims to present the C-scan method, using ultrasonic images in amplitude or time-of-flight to emphasize discontinuities of Ti64 samples realized by laser powder-bed fusion (L-PBF) technology. The analysis of US maps offers the possibility of information correlation, mainly as to flaws in certain areas, as well as distribution of a specific flaw in the volume of the sample (flaws and pores). Final users can import C-scan results as ASCII files for further processing and comparison with other methods of analysis (e.g., non-linear elastic wave spectroscopy (NEWS), multi-frequency eddy current, and computer tomography), leading to specific results. The precision of the flight time measurement ensures the possibility of estimating the types of discontinuities, including volumetric ones, offering immediate results of the inspection. In situ monitoring allows the detection, characterization, and prediction of defects, which is suitable for robotics. Detailing the level of discontinuities at a certain location is extremely valuable for making maintenance and management decisions. Full article

This paper presents a review of the main advantages and challenges of Additive Manufacturing (AM) applied in the production of soft magnetic components for electrical machines. Firstly, a general introduction about additive manufacturing is made, considering all of its possibilities of application, then the authors focused on the electrical machine application field, in particular the AM of soft ferromagnetic materials. The soft ferromagnetic materials are fundamental for the production of electrical machines, and currently, there are more and more requests for designed ad hoc geometries, which can be difficult to produce with conventional manufacturing technologies. With this purpose, AM can be used to produce the desired geometries. Full article

Magnetic levitation and additive manufacturing (AM) are two fields of significant interest in academic research. The use of non-contact forces for magnetic levitation techniques provides opportunities for adoption within the AM environment. The key goal of this article is to experimentally validate the implementation of a magnetic levitation system for Laser-Directed Energy Deposition via Powder Feeding (LDED-PF) Additive Manufacturing applications. Through simulations (conducted in ANSYS Maxwell) and experimental implementation, the levitation system’s stability is tested under a variety of different conditions. The experimental implementation highlights the feasibility of a magnetic levitation system for LDED-PF applications. The levitation system developed is capable of the suspension of non-magnetic materials. The system is also able to maintain stable levitation for extended periods of time. The incorporation of the levitation system into the AM environment may result in an increased maneuverability of non-clamped structures for AM deposition operations. Full article

The production of parts by additive manufacturing is an important issue for the reduction in manufacturing costs and the creation of complex geometries. Optical inspection is often implemented in the machines during the manufacturing process in order to monitor the possible generated defects. However, it is also crucial to test the quality of the manufactured parts after their fabrication and monitor their health throughout their industrial lifetime. Therefore structural health monitoring (SHM) methods need to be studied or designed. In this paper, the eddy current method is used to control fabricated parts, as this technique is adapted to detect surface and shallow defects in conductive materials. Using simulations with the CIVA non-destructive testing software package, several sensors and their parameters were tested in order to determine the most optimal ones: a separate transmitter/receiver sensor and an isotropic sensor were finally designed. The comparison of these sensors’ efficiency was made on the detection of notches and engraved letters based on simulation and experimental tests on parts fabricated by laser powder bed fusion (L-PBF) in order to determine the optimal sensor. The various tests showed that the isotropic sensor is the optimal one for the detection and characterization of defects. Full article
