Search Results (19)

Road accidents could result in severe or fatal neck injuries. A few surrogate necks are available to develop and test neck protectors as countermeasures, but each has its own limitations. The objective of this study was to develop a surrogate neck compatible with the Hybrid III dummy, focused on tunable flexural stiffness and integrated angular sensors for kinematic feedback during impact tests. The neck features six 3D-printed surrogate vertebral bodies interconnected by rubber surrogate discs, providing a baseline flexibility to the surrogate fundamental spinal units. An adjustable inner cable and elastic elements hooked on the sides of vertebral elements allow to increase the flexural stiffness of the surrogate and to simulate the asymmetric behavior of the human neck. Neck flexural angles and axial compression are measured using a novel system made of wires, pulleys, and rotary potentiometers embedded in the neck base. A motion capture system and a load cell were used to determine the bending and torsional stiffness of the neck and to calibrate the sensors. Results showed that the neck flexural stiffness can be tuned between 3.29 and 5.76 Nm/rad. Torsional stiffness was 1.01 Nm/rad and compression stiffness can be tuned from 39 to 193 N/mm. Sensor flexural angles were compared with motion capture angles, showing an RMSE error of 1.35° during static testing and of 3° during dynamic testing. The developed neck could be a viable tool for investigating neck braces from a kinematic and kinetic perspective due to its inbuilt sensing ability and its tunable stiffness. Full article

In freeform surface grid structures, quadrilateral meshes offer high visual transparency and simple joint connections, but their structural stability is relatively limited. To enhance stability, designers often introduce additional structural elements along the diagonals of the quadrilateral mesh, forming double-layer quadrilateral grid systems such as cable-braced gridshells. However, current design methodologies do not support the simultaneous optimization of both layers. As a result, the two layers are often designed independently in practical applications, leading to complex joint detailing that compromises construction efficiency, architectural aesthetics, and overall structural performance. To address these challenges, this study presents a weighted multi-objective geometry optimization framework based on a Guided-Projection algorithm. The proposed method integrates half-edge data structure and multiple geometric and structural constraints, enabling the simultaneous optimization of quadrilateral mesh planarity (i.e., panels lying on flat planes) and the orthogonality (i.e., angles approaching 90°) of diagonal cable layouts. Through multiple case studies, the method demonstrates significant improvements in panel planarity and cable orthogonality. The results also highlight the algorithm’s rapid convergence and high computational efficiency. Finite element analysis further validates the structural benefits of the optimized configurations, including reduced peak axial forces in cables, more uniform cable force distribution, and enhanced overall stiffness and buckling resistance. In conclusion, the method improves structural stability, constructability, and design efficiency, offering a practical tool for optimizing freeform cable-braced gridshells. Full article

Effectively preventing hanger bending damage during the configuration transformation of the spatial main cables in suspension bridges is a critical challenge, particularly under the influence of construction errors. This study proposes an active fault-tolerant control method that integrates real-time data feedback, tolerance interval inversion technology, and a suspended lateral bracing (SLB) system to mitigate the risk of hanger bending damage in real time. The method establishes a dynamic inversion mechanism, utilizing data feedback, constraint function reconstruction, and secondary optimization to compensate for construction errors. This ensures that hangers remain undamaged throughout the transformation process. Construction errors are quantified as intervals, with the lower bound of the reliability interval used to account for extreme disturbances. This transforms the inversion process into a multi-objective optimization problem constrained by the worst reliability conditions. By integrating finite element analysis (FEA), reliability analysis, surrogate modeling, and interval analysis, the proposed approach establishes a direct relationship between design variables and the lower bound of the reliability interval. Case study results demonstrate that the proposed method not only ensures structural performance and hanger safety, but also significantly enhances the constructability of the configuration transformation. Additionally, it provides a larger fault tolerance margin, thereby improving the overall efficiency and safety of the construction process. Full article

Cable conduits are crucial for urban power transmission and distribution systems. However, current conduit robots are often large and susceptible to tilting issues, which hampers the effective and intelligent inspection of these conduits. Therefore, there is an urgent need to develop a smaller-sized conduit inspection robot to address these challenges. Based on an in-depth analysis of the characteristics of the cable conduit working environment and the associated functional requirements, this study successfully developed a small-scale urban cable conduit inspection robot prototype. This development was grounded in relevant design theories, simulation analyses, and experimental tests. The test results demonstrate that the robot’s bracing module effectively prevents tilting within the conduit. Additionally, the detection module enables comprehensive 360-degree conduit inspections, and the vacuuming module meets the negative pressure requirements for efficient absorption of dust and foreign matter. The robot has met the expected design goals, effectively enhanced the automation of the cable conduit construction process, and improved the quality control of cable laying. Full article

In order to improve the force performance of traditional anti-buckling energy dissipation bracing with excessive non-recoverable deformation caused by strong seismic action, this paper presents a prestress-braced frame structure system with shape memory alloy (SMA) and investigates its deformation characteristics under a horizontal load. Firstly, this paper establishes a theoretical analysis model by analyzing the geometric relationship between the deformation of SMA cables and inter-story displacement based on the internal force balance equation. The model is used to solve the anti-lateral displacement stiffness of the SMA cable-supported frame structure and to derive a reasonable formula for calculating the initial prestress and cross-sectional area of SMA cables. Then, the mechanical behavior of the SMA cable-supported frame structure system under an equivalent horizontal load is simulated using ABAQUS software and compared with the calculated results of conventional tie-supported and non-dissipative-supported frame structures. The results show that the force performance of the frame structure system determined by the SMA cable design method proposed in this paper is significantly improved under the horizontal load. Furthermore, it can ensure a certain ductility requirement of the frame structure system, which verifies the effectiveness of the design method of the SMA cable frame structure system proposed in this paper. Full article

This paper takes the deep foundation pit project of Lanzhou Hospital of Traditional Chinese Medicine as the background. The design and construction of the foundation pit is relatively difficult due to the complex environment around the pit, the dense surrounding buildings, the complex underground soil layer and the influence of groundwater on the pit. In order to detect problems in the construction process, the pit was monitored in real time through an automated monitoring system for the whole process of excavation and backfilling of the pit. The analysis of the actual monitoring data shows that: (i) the support scheme of bored pile + prestressed anchor cable support combined with concrete corner bracing can meet the design of this type of foundation pit without causing disturbance to the surrounding buildings; (ii) combined with the actual case of the influence of groundwater on the excavation process of the foundation pit, it proves that the real-time measurement by the robot can timely detect the safety hazards caused by external factors during the construction process of the foundation pit. The project is a very important one for deep pits and complex pits. This project provides a good reference case for deep foundation pits and foundation pit projects in complex environments. Full article

Typically, the upper part of the roof a gymnasium building is a radial inverted triangular truss structure, and the lower part is a cable structure. They are connected by vertical braces to form a self-balancing structural system. The whole roof is supported by a complex, spatial, prestressed structure comprising tilted Y-shaped laced columns. Such structures rely on the integrity of the form and the application of prestress to achieve the best performance; it is in an extremely unstable state during construction. In order to study the mechanical behavior of the structure in this process, finite element software was used to analyze the cumulative slip of the structure and the construction process of cable tension, and the simulation values were compared to the actual monitoring values. The stress and deformation of the structure in different construction stages were investigated, and a reasonable structural unloading scheme was put forward. The study results showed that the stiffness of the long-span space truss suspended dome structure gradually increased with the structural integrity during construction, and the vertical deformation decreased from 25.4 mm to 19.26 mm with the construction process. The location and magnitude of the structure’s maximum internal force and maximum stress varied greatly compared to the static analysis when considering the construction process effects. Hence, conducting a construction process analysis is necessary. The construction technology of symmetrical rotating cumulative slip proposed in this paper has the advantages of a short construction duration, safe and stable construction process, etc., providing technical references for similar engineering constructions. Full article

With the continuous development of urbanization and the rapid development of science and technology, the requirements for foundation pit engineering are getting higher and higher. Foundation pit engineering is gradually developing in the direction of larger area and deeper excavation. In engineering examples, the combined supporting structure of a pile–brace and pile–anchor for foundation pits is widely used, while the engineering examples supported by a pile–anchor–brace supporting system are less frequently used. Based on a super-large deep foundation pit project in Yancheng City, Jiangsu Province, China, according to the surrounding environmental conditions, the foundation pit support scheme, and on-site construction situation, the design and on-site monitoring of the pile–anchor–brace supporting system were introduced and analyzed. The results show that: (1) the deformation of the pile–anchor–brace supporting system shows an obvious spatial effect, and the horizontal displacement of the pile and soil of the long side direction is greater than the short side direction; (2) in the initial state, the deep horizontal displacement of the soil is in the form of a ‘cantilever’, but in the later stage it changed to the form of a ‘drum belly’, and both the brace and anchor cable can limit the displacement of the soil effectively; (3) the axial force of the brace develops rapidly in the initial stage, but its development tends to be gentle after the completion of the first anchor cable construction. Through on-site monitoring, it was found that the axial force of the ring brace was larger than that of the corner brace, which was larger than the opposite brace; and (4) the development trend of the axial force for the two rows of anchor cables is quite different. The average axial force of the first row of anchor cables is greater than the second row of anchor cables, and the development trend of the first row of anchor cables is steep first and then gentle, while the change trend of the second row of anchor cables is just the opposite. Full article

The key to evaluating the health status of cable-stayed bridges lies in the accuracy of cable force measurement. When measuring the cable force using the conventional frequency method, the clearance between the bracing cable and the protective tube is typically disregarded. Moreover, due to their large size, existing vibration sensors are difficult to install into protective tubes for steel strand-type bracing cables to measure the cable force. To address the above difficulties, a type of thin rod vibration sensor only 5 mm in diameter was designed based on the high sensitivity of Fiber Bragg grating (FBG), and high-throughput data processing software for engineering calculation (EC) was self-developed. Then, the recognition principle of the thin rod vibration sensor was theoretically analyzed and a step-by-step tension test was carried out. The results demonstrated that the relative error of the cable force measured by the thin rod vibration sensor within 12.865 Hz was less than 5% and the sensitivity reached 28.7 pm/Hz, indicating its high measurement precision. Upon subsequent application of the thin rod vibration sensor to a monitoring test in the field, the relative error of the fundamental frequency between artificial and natural excitations was less than 4%. In addition, the error relative to both the theoretical frequency and the third-party sampling frequency was less than 5%, further verifying the accuracy and applicability for monitoring the cable force of bridges under natural excitation. Compared with the traditional cantilever FBG sensor, the improved sensor with supporting data processing software has the advantages of small cross-section, high reliability, and good sensitivity. The research results can provide a reference for the subsequent accurate measurement of cable force and the development of a supporting sensor data processing system. Full article

As cables are the most critical components of pre-stressed steel structures, accurate identification of the cable force is necessary. This paper established a vibration equation of a multi-brace strut cable, which ignores the influence of sagging and changes in the cable force during the vibration. The form of cable vibration was also developed based on the vibration theory of cables. The analytical solutions of cable vibration equations under different boundary conditions were derived by studying the vibration models of single-span cables. The cable vibration under arbitrary boundary conditions was discussed. Additionally, based on the multi-span cable element vibration theory, the theoretical model of multi-span cable vibration and a cable force calculation method were proposed. A realization principle and an algorithm of the multi-frequency fitting method were proposed to calculate and identify the cable force. Further, the accuracy of the cable force calculated by the proposed method was verified based on a multi-span cable model test and two practical project experiments. The results show that the cable force was calculated with a relative error of 8%. Finally, a cable safety monitoring system was developed and established. Full article

This paper presents a novel type of hybrid self-centering braces incorporating tension-only superelastic NiTi shape memory alloy (SMA) cables and integrated viscoelastic dampers (VEDs). One of our reasons for proposing this new SMA-viscoelastic hybrid brace (SCVEB) is to provide enhanced energy-dissipation ability whilst promoting increased self-centering tendency compared with the existing SMA-based self-centering solutions, where upgrading behavior is mainly benefited from the participation of the VEDs. The configuration and the working principle, along with theoretical equations describing the mechanical behavior of the SCVEB, are described in detail firstly. Experimental verification of individual elements in this SCVEB system, namely the NiTi SMA cables and VEDs, was performed to obtain a basic understanding of their mechanical properties. A proof-of-concept SCVEB specimen was then manufactured, and its cyclic performance was further investigated. Followed by this, a system-level analysis on a series of steel frames equipped with or without SCVEB was conducted. The results showed that the SCVEB system exhibited a moderate damping ratio and a more efficient controlled behavior in terms of its post-event residual deformation and floor acceleration when compared with those of the non-SCVEB system. Full article

A suspended ceiling system (SCS) is one of the most fragile and non-structural elements during earthquakes. However, effective seismic protection technologies for enhancing the suspended ceiling system have not been developed other than the steel bracing system. An innovative passive vibration control system is proposed in this paper, which equipped a damper-employed pulley amplification mechanism into the indirect suspended ceiling system, named the pulley–damper ceiling system (PDCS). Theoretical formulation and the detailed information on the system were presented first. In addition, a new rotational damper composition consisting of a non-linear viscous damper was developed to follow the large wire-cable stroke. Six types of the full-scale ceiling specimens of a 15.6-square meter area with different configurations were constructed for the preliminary experiments to evaluate the seismic performance and feasibility of PDCS under simulated earthquake motions. The comparative results of the shake table test demonstrated that the application of PDCS is capable of controlling both displacement and acceleration of the ceiling panels. This study also presents the nonlinear time history analyses by modeling a wire-cable as an equivalent truss element to transmit the relative displacement of the ceiling system to the damper. The analytical model accurately simulated the dynamic behavior of PDCS. Full article

The application of pultruded glass fiber-reinforced polymer composites (PGFRPCs) as a replacement for conventional wooden cross-arms in transmission towers is relatively new. Although numerous studies have conducted creep tests on coupon-scale PGFRPC cross-arms, none had performed creep analyses on full-scale PGFRPC cross-arms under actual working load conditions. Thus, this work proposed to study the influence of an additional bracing system on the creep responses of PGFRPC cross-arms in a 132 kV transmission tower. The creep behaviors and responses of the main members in current and braced PGFRPC cross-arm designs were compared and evaluated in a transmission tower under actual working conditions. These PGFRPC cross-arms were subjected to actual working loads mimicking the actual weight of electrical cables and insulators for a duration of 1000 h. The cross-arms were installed on a custom test rig in an open area to simulate the actual environment of tropical climate conditions. Further creep analysis was performed by using Findley and Burger models on the basis of experimental data to link instantaneous and extended (transient and viscoelastic) creep strains. The addition of braced arms to the structure reduced the total strain of a cross-arm’s main member beams and improved elastic and viscous moduli. The addition of bracing arms improved the structural integrity and stiffness of the cross-arm structure. The findings of this study suggested that the use of a bracing system in cross-arm structures could prolong the structures’ service life and subsequently reduce maintenance effort and cost for long-term applications in transmission towers. Full article

Inerter-based vibration control systems have been developed rapidly in recent years. However, previous studies mainly focus on the development of new devices and parameter optimization strategies, while ignoring the improvements in the utilization efficiency of the inerter system that the bracing system and novel installation methods may bring. In this paper, a cross-layer installed cable-bracing inerter system (CICBIS) is proposed to improve the utilization efficiency of the inerter system, which can cross more layers and is suitable for shear-type multi-degree-of-freedom (MDOF) structures. A demand-based cable-bracing inerter system (CBIS) design method is developed. The mass enhancement and utilization efficiency improvement of the inerter system caused by the cross-layer installation are quantified through calculating the effective inerter-mass ratio of the CBIS-equipped MDOF structure. A 10-story benchmark structure is used to verify the control performance of the CICBIS and the design method. The analysis results show that the proposed design method can exert the cable-bracing system’s adjustability and the damping enhancement of the inerter system. The CICBIS can reduce the total apparent mass and damping coefficient requirements of the inerter systems without increasing the control force. It means that the proposed design method is effective, and the CICBIS has a high efficiency. Full article
