This study quantifies shear and flexural stiffnesses and their changes over time to support structural health monitoring of in-service bridge superstructures across four girder types: reinforced concrete (RC) beams, prestressed concrete (PSC) girders, steel girders, and ultra-high-performance concrete (UHPC) sections, using field ambient vibration testing. A total of 20 bridges across Georgia and Iowa are assessed, involving over 100 hours of on-site data collection and traffic control strategies. Results show that field-measured natural frequencies differ from theoretical predictions by average of 30–35% for RC, and 20–25% for PSC, 15–25% for steel and 2% for UHPC, reflecting the complexity of in situ structural dynamics and challenges in estimating material properties. Site-placed RC beams showed stiffness reduction due to deterioration, whereas prefabricated PSC girders maintained consistent stiffness with predictable variations. UHPC sections exhibited the highest stiffness, reflecting superior performance. Steel girders matched theoretical values, but a span-level test revealed that deck damage can reduce frequencies undetected by localized measurements. Importantly, vibration-based measurements revealed reductions in structural stiffness that were not apparent through conventional visual inspection, particularly in RC beams. The research significance of this work lies in establishing a portfolio-based framework that enables cross-comparison of stiffness behavior across multiple girder types, providing a scalable and field-validated approach for system-level bridge health monitoring and serving as a quantitative metric to support bridge inspections and decision-making. Full article

The growing use of weathering steel in bridge engineering has highlighted the increasing impact of fatigue damage caused by the combined effects of welding residual stress and vehicular loading. This study investigates the fatigue performance of Q500qENH weathering steel bridge decks by proposing a coupled analysis method for residual stress and fatigue crack growth, utilizing collaborative simulations with Abaqus 2023 and Franc3D 7.0. An interaction model integrating welding-induced residual stress fields and dynamic vehicular loads is developed to systematically examine crack propagation patterns in critical regions, including the weld toes of the top plate and the weld seams of the U-ribs. The results indicate that the crack propagation rate at the top plate weld toe exhibits the most rapid progression, reaching the critical dimension (two-thirds of plate thickness) at 6.98 million cycles, establishing this location as the most vulnerable failure point. Residual stresses significantly amplify the stress amplitude under tension–compression cyclic loading, with life degradation effects showing 48.9% greater severity compared to pure tensile stress conditions. Furthermore, parametric analysis demonstrates that increasing the top plate thickness to 16 mm effectively retards crack propagation, while wheel load pressures exceeding 1.0 MPa induce nonlinear acceleration of life deterioration. Based on these findings, engineering countermeasures including welding defect control, optimized top plate thickness (≥16 mm), and wheel load pressure limitation (≤1.0 MPa) are proposed, providing theoretical support for fatigue-resistant design and maintenance of weathering steel bridge decks. Full article

High-pier partially cable-stayed bridges, with their significant pier heights and relatively low structural stiffness and stability, experience pronounced vehicle–bridge coupling effects during vehicle transit, influencing their dynamic response and safety. This study developed a co-simulation analysis program using easy language and ANSYS to investigate the dynamic behavior of a prestressed concrete five-tower partially cable-stayed bridge under vehicle–bridge interaction, considering factors such as vehicle speed, bridge deck grade, and cable force. The research findings indicate that a reduction in bridge deck grade leads to increases in peak dynamic responses and impact factors, with the dynamic amplification factor showing a deteriorating trend across all cross-sections. Structural responses fluctuate with vehicle speed and exhibit sensitivity to speed variations, with the maximum response observed at a speed of 80 km/h. Adjusting cable forces can reduce the impact factor: a 5% change in cable tension causes the mid-span impact factor to drop sharply from 0.38 to 0.04, a substantial decrease of 89.5%. The structural system can exert an impact on the impact factor by as much as several times: while the dynamic displacement and bending moment of the fixed system are smaller than those of the continuous beam system, its impact factor is as high as 4.22 times that of the continuous beam system. Additionally, dynamic responses are closely related to the position of the fixed bearing, with responses near the fixed bearing being reduced. Notably, the maximum impact factors of critical sections all exceed the 0.05 limit specified in the code for this type of bridge, with values of 0.54 at the mid-span, 0.91 at the pier top, and 0.43 at the tower top anchor zone. This indicates that the provisions regarding dynamic amplification factors in the current code are inappropriate for such bridges. The difference in impact factors between bridge components can reach 2.12 times, this indicates that specific impact factors should be assigned to individual components to achieve an optimal balance between safety and economic performance. Full article

The bridge deck is more vulnerable to deterioration than other structural components. This is due to its direct exposure to environmental factors such as vehicular loads, chloride ingress, and freeze–thaw cycles. The resulting accelerated degradation often results in a serviceability life that is shorter than the intended design life. However, the absence of standardized condition assessment methods coupled with clear definitions of remaining service life has limited the establishment of rational guidelines for repair and strengthening. In a bid to address this lack, this study focuses on PSC-I type bridges in South Korea, utilizing long-term field inspection data to analyze environmental, structural, and material factors—including reinforcement corrosion, chloride diffusion, and freeze–thaw actions. Environmental zoning was applied based on regional conditions, while structural zoning was performed according to load characteristics, thereby allowing the classification of deck regions into moment zones and cantilever sections. Machine learning models were employed to identify dominant deterioration mechanisms, with the validity of the zoning classification being evaluated via model accuracy and SHAP value analysis. Additionally, a regression-based approach was proposed to estimate the remaining service life of the bridge deck for each corrosion phase, thereby providing a quantitative framework for durability assessment and maintenance planning. Full article

This paper outlines a structural qualification process to assess the use of newly developed high-modulus (HM) glass fiber-reinforced polymer (GFRP) bars with headed ends in the joint between concrete bridge barriers and decks. The main goals of the study are to evaluate the structural performance of GFRP-reinforced TL-5 barrier–deck systems under transverse loading and to determine the pullout capacity of GFRP anchorage systems for both new construction and retrofit applications. The research is divided into two phases. In the first phase, six full-scale Test-Level 5 (TL-5) barrier wall–deck specimens, divided into three systems, were constructed and tested up to failure. The first system used headed-end GFRP bars to connect the barrier wall to a non-deformable thick deck slab. The second system was similar to the first but had a deck slab overhang for improved anchorage. The third system utilized postinstalled GFRP bars in a non-deformable thick deck slab, bonded with a commercial epoxy adhesive as a solution for deteriorated barrier replacement. The second phase involves an experimental program to evaluate the pullout strength of the GFRP bar anchorage in normal-strength concrete. The experimental results from the tested specimens were then compared to the factored applied moments in existing literature based on traffic loads in the Canadian Highway Bridge Design Code. Experimental results confirmed that GFRP-reinforced TL-5 barrier–deck systems exceeded factored design moments, with capacity-to-demand ratios above 1.38 (above 1.17 with the inclusion of an environmental reduction factor of 0.85). A 195 mm embedment length proved sufficient for both pre- and postinstalled bars. Headed-end GFRP bars improved pullout strength compared to straight-end bars, especially when bonded. Failure modes occurred at high loads, demonstrating structural integrity. Postinstalled bars bonded with epoxy performed comparably to preinstalled bars. A design equation for the barrier resistance due to a diagonal concrete crack at the barrier–deck corner was developed and validated using experimental findings. This equation offers a conservative and safe design approach for evaluating barrier–deck anchorage. Full article

Bridges are assets in every society, and their deterioration can have severe economic, social, and environmental consequences. Therefore, implementing effective asset management strategies is crucial to ensure bridge infrastructure’s long-term performance and safety. Roadmaps can serve as valuable tools for bridge asset managers, helping bridge engineers make informed decisions that enhance bridge safety while maintaining controlled life cycle costs. Although some bridge asset management roadmaps exist, such as the one published by the United States Federal Highway Administration (FHWA), there is a lack of structured research roadmaps that are both region-specific and adaptable as guiding frameworks for similar studies. For instance, the FHWA roadmap cannot be universally applied across diverse regional contexts. This study addresses this critical gap by developing a research roadmap tailored to Idaho, USA. The roadmap was developed using a three-phase methodological approach: (1) a comprehensive analysis of past and ongoing Department of Transportation (DOT)-funded research projects over the last five years, (2) a nationwide survey of DOT funding and research practices, and (3) a detailed assessment of Idaho Transportation Department (ITD) deficiently rated bridge inventory, including individual element condition states. In the first phase, three filtering stages were implemented to identify the top 25 state projects. A literature review was conducted for each project to provide ITD’s Technical Advisory Committee (TAC) members with insights into research undertaken by various state DOTs. Moreover, in the second phase, approximately six questionnaires were designed and distributed to other state DOTs. These questionnaires primarily covered topics related to bridge research priorities and funding allocation. In the final phase, a condition state analysis was conducted using data-driven methods. Key findings from this three-phase methodological approach highlight that ultra-high-performance concrete (UHPC), bridge deck preservation, and maintenance strategies are high-priority research areas across many DOTs. Furthermore, according to the DOT responses, funding is most commonly allocated to projects related to superstructure and deck elements. Finally, ITD found that the most deficient elements in Idaho bridges are reinforced concrete abutments, reinforced concrete pile caps and footings, reinforced concrete pier walls, and movable bearing systems. These findings were integrated with insights from ITD’s TAC to generate a prioritized list of 23 high-impact research topics aligned with Idaho’s specific needs and priorities. From this list, the top six topics were selected for further investigation. By adopting this strategic approach, ITD aims to enhance the efficiency and effectiveness of its bridge-related research efforts, ultimately contributing to safer and more resilient transportation infrastructure. This paper could be a helpful resource for other DOTs seeking a systematic approach to addressing their bridge research needs. Full article

Ground Penetrating Radar (GPR) is widely used for assessing the deterioration of concrete bridge decks. GPR surveys generate large amounts of data in the form of B-scan images, which display rebar traces as hyperbolas. Accurate analysis of the GPR scans relies on the effective extraction of rebar locations and amplitudes. This paper presents two automated rebar detection algorithms based on Convolutional Neural Network (CNN) machine learning techniques. Two models are proposed: CNN-1 and CNN-2. CNN-1 was trained on raw GPR images to identify hyperbolas, while CNN-2 model used both raw and migrated GPR images for enhanced analysis. The models were evaluated using GPR data collected from three bridges with different overlay types. Performance was assessed through the visual comparison of the generated bridge amplitude maps against ground-truth data, as well as precision, recall, and F1-score metrics. The results demonstrate that CNN-2 outperforms CNN-1 in terms of accuracy and efficiency for rebar detection. Full article

Orthotropic Steel Bridge Decks (OSBDs) are often used in long-span bridges due to their high performance and ease of installation. However, issues such as fatigue cracking and the deterioration of asphalt overlays due to their local stiffness inefficiency necessitate innovative solutions. Orthotropic Steel–Ultra-High-Performance Concrete Composite Bridge Decks (OS-UHPC-CBDs) have enhanced OSBD performance; however, they have disadvantages such as a heavier weight and high initial cost requirements. In this study, an Orthotropic Steel–Lightweight Ultra-High-Performance Concrete Composite Bridge Deck (OS-LUHPC-CBD) is proposed as a solution that integrates a novel Lightweight Ultra-High-Performance Concrete (LUHPC) with a high-strength Q425 steel deck and trapezoidal ribs. A comprehensive experimental investigation, including full-scale four-point bending tests, was undertaken to evaluate the flexural behavior of the proposed OS-LUHPC-CBD compared to the OS-UHPC-CBD. The experimental results show that the proposed OS-LUHPC-CBD has equivalent flexural capacity and improved ductility compared to the OS-UHPC-CBD. This study found the proposed OS-LUHPC-CBD to be a promising solution for application in long-span bridges with an 8.4% lighter weight and a 6.8% lower cost, and with the same ease of construction as OS-UHPC-CBDs. A finite element model with a strong correlation was developed and validated through the experimental results. Based on this, a parametric study was undertaken on the effect of the key geometric design parameters on the flexural capacity of the OS-LUHPC-CBD. Full article

The objective of this study is to analyze bridge deck condition deterioration and evaluate the impact of concrete sealer and salt usage on deck condition and life-cycle cost. To achieve this goal, machine learning models were built to predict the evolution of bridge deck rating. The deck maintenance history shows that the average bridge age at deck overlay and deck replacement is around 25 and 50 years, respectively. Deck overlay can improve deck condition from an average rating of 6.3 to 7.1, and deck replacement can efficiently recover deck condition from an average rating of 5.3 to 8.5. The effect of concrete sealer on bridge deck condition is only observable at the stage before the first overlay, indicating that concrete sealer may not be effective over the long term. More usages of prewet salt and salt brine in anti-icing result in slightly higher deck condition ratings, while more dry salt in deicing presents slightly lower deck condition ratings, indicating the benefits of salt brine over dry salt. When concrete sealer is applied every 2 or 4 years, it can help extend the service life of the bridge deck by around 1~2 years. If concrete sealer is applied every 12 years, a 6% reduction in life cycle cost could be achieved. Full article

Transportation infrastructure such as concrete pavements, parapets, barriers, and bridge decks in cold regions are usually exposed to a heavy amount of deicing chemicals during the winter for ice and snow control. Various deicer salts can physically and chemically react with concrete and result in damage and deterioration. Currently, Idaho uses four different types of deicers during the winter: salt brine, mag bud converse, freeze guard plus, and mag chloride. The most often utilized substance is salt brine, which is created by dissolving rock salt at a concentration of 23.3%. Eight concrete mixtures for paving and structural purposes were made and put through a battery of durability tests. Following batching, measurements were made of the unit weight, entrained air, slump, and super air meter (SAM) fresh characteristics. Rapid freeze–thaw (F-T) cycle experiments, deicing scaling tests, and surface electrical resistivity testing were used to test and assess all mixes. Tests with mag bud converse, freeze guard plus mag chloride, and acid-soluble chloride were conducted following an extended period of soaking in salt brine. Two different structural mixtures were suggested as a result of the severe scaling observed in the structural mixtures lacking supplemental cementitious materials (SCMs) and the moderate scaling observed in the other combinations. The correlated values of the SAM number with the spacing factor have been shown that mixture with no SCMs has a spacing factor of 0.24, which is higher than the recommended value of 0.2 and concentrations of acid soluble chloride over the threshold limit were discernible. In addition, the highest weight of calcium hydroxide using the TGA test was observed. For all examined mixes, the residual elastic moduli after 300 cycles varied between 76.0 and 83.3 percent of the initial moduli. Mixture M5 displayed the lowest percentage of initial E (76.0 percent), while mixtures M1 and M2 showed the highest percentage of residual E (83.3 and 80.0 percent, respectively) among the evaluated combinations. There were no significant variations in the percentage of maintained stiffness between the combinations. As a result, it was difficult to identify distinct patterns about how the air content or SAM number affected the mixture’s durability. Class C coal fly ash and silica fume were present in the suggested mixtures, which were assessed using the same testing matrix as the original mixtures. Because of their exceptional durability against large concentrations of chemical deicers, the main findings suggest altering the concrete compositions to incorporate SCMs in a ternary form. Full article

Thousands of multi-span, simply supported beam bridges with short or medium spans have been built in China. They often suffer from problems of cracks in the link slabs over piers, and the deterioration and damage of deck expansion joints at abutments. To address these problems, one approach is to retrofit them by converting the simply supported box beams into continuous structures over the piers and jointless bridges over the abutments. This paper discusses the design methodology and details for retrofitting the Jinpu Bridge in Zhangzhou, Fujian, China, from a simply supported bridge into a semi-integral bridge, in which semi-fixed dowel joints are used to connect the superstructure and the substructure, including piers and abutments. Simultaneously, the finite element software is used to calculate the internal forces and displacements of the structure. The analysis reveals an 11.1% reduction in the maximum positive moment at the midspan of the main beam in the semi-integral bridge compared to the simply supported bridge. However, the shear forces at the interior pier increase by 6.4%. According to the response spectrum analysis, the maximum longitudinal displacement of the semi-integral bridge’s main beam is 11.6 mm, reduced by 80.1% compared to the simply supported bridge under a dead load and earthquake effects. The maximum bending moment and shear force on the pier of the semi-integral bridge are 984.7 kN·m and 312.6 kN, respectively, both below their ultimate bearing capacities. The maximum displacement at the top of the pier is 7.7 mm, which is below the allowable 52.4 mm displacement. The calculated results conform to the design requirements specified by the code. Full article

Traditional forecasting models for bridge conditions, such as ARIMA and Markov chains, often fail to adequately capture nonlinear and dynamic relationships among critical variables like age, traffic patterns, and environmental factors, leading to suboptimal maintenance decisions, increased long-term maintenance costs, and heightened safety risks. This study addresses these limitations by developing recurrent neural network (RNN) models utilizing Long Short-Term Memory (LSTM) and Gated Recurrent Unit (GRU) architectures with a TimeDistributed output layer. This novel approach enables accurate forecasting of the Bridge Health Index (BHI) and condition ratings for key components—deck, superstructure, and substructure—while effectively modeling temporal dependencies. Applied to bridge data from Georgia, USA, the regression models (BHI) achieved R² values exceeding 0.84, while the classification models (components condition ratings) demonstrated accuracy between 84.78% and 87.54%. By modeling complex temporal trends in bridge deterioration, our method processes time-dependent data from multiple bridges simultaneously, revealing intricate relationships that influence bridge performance within a state’s inventory. These results provide actionable insights for maintenance planning, optimized resource allocation, and reduced risks of unexpected failures. This research establishes a robust framework for bridge performance prediction, ensuring improved infrastructure safety and resilience amid aging assets and constrained maintenance budgets. Full article

The increased volume of heavy vehicles and use of de-icing agents on concrete bridge decks accelerates the deterioration of these structures. Therefore, the rapid replacement of these structures has attracted considerable attention, with prefabricated bridges being the preferred option. Conventionally, horizontal shear connections between girders and precast decks have incorporated rebar stirrup shear connectors. Although effective for initial construction, this method renders dismantling of aged decks complex, because rebar connectors are fully embedded within girders. This study introduced an embedded separable shear connector that minimizes deck-breaking and facilitates easy reinstallation by the simple separation of the deck from the girder. Horizontal shear and flexural tests on composite girders and comparisons with various design codes were conducted to evaluate this connector. The results of horizontal shear tests confirmed that securing sufficient embedment depth is necessary to prevent the pull-out failure of shear connectors. Additionally, prestressed concrete composite girder flexural tests with improved design verified that the detachable shear connectors exhibited an approximately 60% improvement in flexural performance compared with conventional reinforcement shear connectors. Full article

Bridges are generally acknowledged as one of the vital structures of transportation systems. Meanwhile, they are prone to time-variant damage and deterioration mechanisms over their life span. With that in mind, this research study aims to explore state-of-the-art work in relation to deterioration models and related critical factors of reinforced concrete bridges. Particularly, this study presents a mixed review methodology (scientometric and systematic) that reviews over 300 publications in Scopus and Web of Science databases over the period 1985–2023. The study scrutinized and categorized the wide spectrum of deterioration factors in reinforced concrete bridges with the help of deterioration models. Results manifested that implicating deterioration factors can be grouped into seven main clusters, namely chemical, material properties, design & construction, physical, operational, environmental, and force majeure. In addition, it is noted that hitherto, there has been a lack of sufficient research efforts on non-destructive evaluation-based deterioration models. Full article

Applying unmanned aerial vehicles (UAVs) and vision-based analysis methods to detect bridge surface damage significantly improves inspection efficiency, but the existing techniques have difficulty in accurately locating damage, making it difficult to use the results to assess a bridge’s degree of deterioration. Therefore, this study proposes a method to generate panoramic bridge surface images using multi-view images captured by UAVs, in order to automatically identify and locate damage. The main contributions are as follows: (1) We propose a UAV-based image-capturing method for various bridge sections to collect close-range, multi-angle, and overlapping images of the surface; (2) we propose a 3D reconstruction method based on multi-view images to reconstruct a textured bridge model, through which an ultra-high resolution panoramic unfolded image of the bridge surface can be obtained by projecting from multiple angles; (3) we applied the Swin Transformer to optimize the YOLOv8 network and improve the detection accuracy of small-scale damages based on the established bridge damage dataset and employed sliding window segmentation to detect damage in the ultra-high resolution panoramic image. The proposed method was applied to detect surface damage on a three-span concrete bridge. The results indicate that this method automatically generates panoramic images of the bridge bottom, deck, and sides with hundreds of millions of pixels and recognizes damage in the panoramas. In addition, the damage detection accuracy reached 98.7%, which is improved by 13.6% when compared with the original network. Full article
