Search Results (79)

Ageing building stock, shrinking budgets, and inspector shortages hinder timely façade safety inspections. This research develops an automated damage detection and risk prioritization system for aging concrete structures. Five YOLOv11 variants were trained on 130,838 high-resolution images from 25 Seoul districts to detect three critical damage types: cracks, exposed rebar, and spalling. The proposed framework integrates YOLOv11 detection with a novel Damage Criticality Index (DCI) that transforms five visual-spatial cues—area, multiplicity, confidence, density, and spread—into continuous severity scores, subsequently categorized into low, medium, and high risk via K-means clustering. YOLOv11x achieved 0.78 mAP@0.5 at 101 FPS, enabling real-time processing suitable for field deployment. Field trials confirmed robust detection and consistent risk ranking in both uncluttered and cluttered urban environments, substantially reducing inspection time and minimizing missed defects compared to conventional manual methods. The framework provides scalable, data-driven support for city-wide monitoring and transparent, risk-prioritized maintenance of aging infrastructure. Full article

Aggregate masonry buildings in historic urban centers constitute tangible testimony of collective identity and historical continuity. They encompass both simple terraced configurations and more intricate clusters, which are inherently vulnerable to earthquake-induced damage, due to their typological features and the transformations that occurred in the course of time. Strategies aimed at the protection and valorization of such typical architectural heritage should be based on the recognition of their peculiarities, so that the intangible values embedded within the historic fabric can be preserved. A simplified approach able to identify the effect of facade layout on the vulnerability of terraced buildings was validated on a historical center struck by the Central Italy earthquake. It is based on the evaluation of vulnerability factors derived by the application of a multi-level procedure on a large scale, which integrates data on typological and structural aspects, as well as on the condition state and previous interventions. In the center in question, the evidence of prevalent shear damage in the continuous frontage of the buildings facing the main street suggested the in-depth analysis of the facade’s characteristics, and its relationship with the main direction of the seismic swarm. Starting from a preliminary abacus of twelve vulnerability factors, 16 archetypes of facades at increasing vulnerability defined by a combination of the most significant geometrical features of building aggregates were identified. These virtual models encompass typical features that can be found in similar buildings in different contexts, thus enabling preventive actions based on parametric assessment. Full article

The conservation of 19th-century heritage shophouses in Peunayong, Banda Aceh, illustrates a global challenge where material deterioration, structural decline, and weak governance intersect. Previous studies often examined these dimensions separately—focusing on architectural authenticity, structural safety, or heritage policy—but rarely in an integrated manner. This study addresses that gap by combining facade condition surveys, non-destructive structural testing, and policy analysis to evaluate the state and future of Peunayong’s historic shophouses. Fieldwork on 45 buildings employed visual documentation, interviews, questionnaires, and Schmidt Hammer and Ultrasonic Pulse Velocity (UPV) tests. The visual observation was measured using a Likert scale. Results show that 62.3% of shophouses experienced severe facade damage, primarily due to unregulated renovations erasing historical features. Windows, ornaments, and fascia boards were among the most degraded. Structural tests revealed that while some shophouses retained safe load-bearing capacity, others showed critical weaknesses below safety thresholds. Policy analysis highlighted an implementation deficit: despite recognition of Peunayong in urban spatial plans, the buildings remain unregistered as cultural heritage, leaving them unprotected and subject to uncontrolled alterations. Currently, 55.6% retain original facade features, while 44.4% have been modified. By framing conservation as a triple crisis of authenticity loss, structural vulnerability, and policy failure, this study contributes methodological and empirical insights to heritage debates, advocating for enforceable regulations, technical monitoring, and community-supported conservation. Full article

The acceleration of global urbanization has caused severe damage to, and even the disappearance of, traditional villages, significantly reducing the diversity of cultural landscapes. To effectively preserve and transmit the cultural landscape characteristics of traditional villages, this study adopts the “landscape gene” theory and proposes a traditional village landscape gene perception evaluation method combining game theory-based weight assignment and the cloud model. Using Huangtutang Village in Wuxi, China, as a case study, the study follows the framework and paradigm of “identification-translation-perception evaluation-preservation inheritance” to identify, translate, map, and comprehensively evaluate its landscape genes. Finally, targeted strategies for the preservation and development of Huangtutang Village are proposed based on the evaluation results. The results indicate that residents and tourists generally perceive the landscape genes of Huangtutang Village as “Satisfied,” with perception levels ranking from high to low as follows: environmental pattern, cultural characteristics, architectural character, and spatial layout characteristics. Perceptions of traffic location, street texture, building form, roof form, facade features, folk tales, and historical and cultural context were relatively low, showing lower “expectation values.” The findings provide valuable references for the preservation and development of Huangtutang Village and other traditional villages. The proposed traditional village landscape gene perception evaluation model advances the development of landscape gene theory, effectively supplements existing methods for traditional village preservation and sustainable development, and demonstrates broad applicability. Full article

This study investigates the robustness of steel moment-resisting frames (MRFs) under column loss scenarios, both in undamaged and post-seismic conditions. In this context, robustness is defined as the ability of a damaged structure to prevent progressive collapse following an earthquake. A parametric investigation was conducted on 48 three-dimensional MRF configurations, varying key design and geometric parameters such as the number of storeys, span length, and design load combinations. Nonlinear dynamic analyses were performed using realistic ground motions and column loss scenarios defined by UFC guidelines. The effects of pre-existing seismic damage, façade claddings, and joint typologies were explicitly accounted for using validated component-based modelling approaches. The results indicate that long-span, low-rise frames are more vulnerable to collapse initiation due to higher plastic demands, while higher-rise frames benefit from load redistribution through their increased redundancy. In detail, long-span, low-rise frames experience roughly ten times higher displacement demands than their short-span counterparts, and post-seismic damage has limited influence, yielding rotational demands within 5–10% of the undamaged case. The Reserve Displacement Ductility (RDR) ranges from approximately 6.3 for low-rise, long-span frames to 21.5 for high-rise frames, highlighting the significant role of geometry in post-seismic robustness. The post-seismic damage was found to have a limited influence on the dynamic displacement and rotational demands, suggesting that the robustness of steel MRFs after a moderate earthquake is largely comparable to that of the initially undamaged structure. These findings support the development of more accurate design and retrofit provisions for seismic and multi-hazard scenarios. Full article

Bell towers, due to their slender geometry and structural configuration, are among the buildings most susceptible to deterioration from weathering and seismic events. These aspects influence the structural assessment of these historic towers, which is essential for their conservation and maintenance. The “Carmine Maggiore” bell tower in Naples (Italy) has been an important and prominent landmark of the city for centuries. It is square in plan and 72 m high. Over time, it suffered extensive damage and was severely damaged by the earthquake of 1456. Reconstruction began in the first decade of the 17th century and the original design was modified, adding two stories and changing the shape of the plan to octagonal. In the centuries that followed, the structure was damaged again and further interventions were carried out, adding tie-rods and replacing damaged elements. Today, the bell tower has very elaborate façades with mouldings and decorations, so that the supporting structure appears to be covered with plaster, stucco, and stone elements. This paper describes the results of FEM analyses of the bell tower, obtained from models with different levels of complexity to evaluate the influence of stone cladding elements on the seismic behaviour. In particular, the difference in the IS safety indices, calculated as the ratio of capacity to demand, exceeds 15%, due to the mechanical consistency of the cladding elements, which contribute significantly to both stiffness and strength. Full article

The Façade Opening Rate (FOR) reflects a building’s capacity to withstand seismic loads, serving as a crucial foundation for seismic risk assessment and management. However, FOR data are often outdated or nonexistent in rural areas, which are particularly vulnerable to earthquake damage. This paper proposes a practical framework for estimating FORs from real-scene 3D models derived from UAV photogrammetry. The framework begins by extracting individual buildings from 3D models using annotated roof outlines. The known edges of the roof outline are then utilized to sample and generate orthogonally projected front-view images for each building façade, enabling undistorted area measurements. Next, a modified convolutional neural network is employed to automatically extract opening areas (windows and doors) from the front-view façade images. To enhance the accuracy of opening area extraction, a vanishing point correction method is applied to open-source street-view samples, aligning their style with the front-view images and leveraging street-view-labeled samples. Finally, the FOR is estimated for each building by extracting the façade wall area through simple spatial analysis. Results on two test datasets show that the proposed method achieves high accuracy in FOR estimation. Regarding the mean relative error (MRE), a critical evaluation metric which measures the relative difference between the estimated FOR and its ground truth, the proposed method outperforms the closest baseline by 5%. Moreover, on the façade images we generated, the MRE of our method was improve by 1% and 2% compared to state-of-the-art segmentation methods. These results demonstrate the effectiveness of our framework in accurately estimating FORs and highlight its potential for improving seismic risk assessment in rural areas. Full article

The Ateneo Sueco del Socorro, built in 1927 in Sueca, Spain, is a prime example of the 20th-century architectural transformation, using reinforced concrete. Designed by architect Juan Guardiola, it reflects the Art Deco style, incorporating ornamental elements from Eastern civilizations. The building’s structure includes masonry walls, concrete columns, and vaulted ceilings. The building displayed a high level of damage due to the oxidation and corrosion of the reinforcements that compose the façade, which led to the definition of the most appropriate study and intervention methodology, applying contemporary tests for reinforced concrete. The original project’s structural design reflects the construction methods of its time, with sculptural elements using Fallas modeling techniques, resulting in various concrete and mortar types. After the façade presented a pathological condition in the early 21st century that made its restoration urgent, a study methodology was followed with current tests to accurately determine the lesions, their degree of damage, and compatible materials for restoration. Corrosion on the façade is mainly triggered by carbonation and the depassivation of reinforcements, exacerbated by environmental issues like moisture retention and oxygen permeability. Repairs should use compatible pre-mixed mortars, with surface inhibitors recommended to extend the lifespan of reinforcements. Full article

ETICS is a popular external wall insulation system, which is not without possible defects and damages. A frequent cause, direct or indirect, of damage to buildings is the impact of water (moisture). This article presents, among others, the results of tests of the moisture content of ETICS layers, the water absorption and capillary absorption of the render by means of the Karsten tube method, numerical thermo-moisture simulations, and tests of interlayer adhesion, in sample residential buildings. Mass moisture content testing of the wall substrate showed acceptable moisture levels (1–4%m) within masonry walls made of silicate blocks, as well as locally elevated moisture levels (4–8%m) in the case of reinforced concrete walls. Moisture testing of the insulation samples showed a predominantly dry condition, and testing of the reinforcement layer showed an acceptable level of moisture. Severe moisture was found in the sample taken in the ground-floor zone at the interface between mineral wool and EPS-P insulation underneath the reinforced layer. Capillary water absorption tests helped classify silicone render as an impermeable and surface hydrophobic coating. Tests of the water absorption of the facade plaster showed that the value declared by the manufacturer (<0.5 kg/m²) was mostly met (not in the ground-floor zone). The simulation calculations gave information that there was no continuous increase in condensation during the assumed analysis time (the influence of interstitial condensation on the observed anomalies was excluded). The tests carried out indicated the occurrence of numerous errors in the implementation of insulation works affecting the moisture content and durability of external partitions. Full article

Multimodal image data have found widespread applications in visual-based building façade damage detection in recent years, offering comprehensive inspection of façade surfaces with the assistance of drones and infrared thermography. However, the comprehensive integration of such complementary data has been hindered by low levels of automation due to the absence of properly developed methods, resulting in high cost and low efficiency. Thus, this paper proposes an automatic end-to-end building façade damage detection method by integrating multimodal image registration, infrared–visible image fusion (IVIF), and damage segmentation. An infrared and visible image dataset consisting of 1761 pairs encompassing 4 main types of façade damage has been constructed for processing and training. A novel infrared–visible image registration method using main orientation assignment for feature point extraction is developed, reaching a high RMSE of 14.35 to align the multimodal images. Then, a deep learning-based infrared–visible image fusion (IVIF) network is trained to preserve damage characteristics between the modalities. For damage detection, a relatively high mean average precision (mAP) result of 85.4% is achieved by comparing four instance segmentation models, affirming the effective utilization of IVIF results. Full article

A swimming pool in Corrales de Buelna (Cantabria) was demolished in March 2017 due to the loss of mechanical performance of the laminated timber structure. The relevant deterioration was caused by rotting of the wood and corrosion of the metal connecting elements. The structure featured a barrel vault with five large tri-articulated arches enclosed on the sides by inclined facades formed by toral rafters and purlins. The corresponding diagnostic process involved data collection and structural assessments to verify the structure’s bearing capacity and serviceability. Data collection was carried out in December 2015 and consisted of a thermal camera inspection to determine the points of moisture accumulation and sampling openings, conduct environmental and wood hygrothermal measurements, and measure cross-sectional losses and deformations of the structural elements. Verification of the load-bearing capacity was carried out using matrix calculation structure software for both the original and deteriorated structure. The diagnosis indicated that the damage was caused by leaks in the joints of the aluminum composite roof panels and by the insufficient load-bearing capacity of the structure. The severity of the damage compromised the mechanical strength and stability of the building, leading to a recommendation that the use of the facilities be immediately discontinued. The degree of deterioration left the structure unrecoverable, making it very difficult to apply reinforcement measures. These factors led to the structure’s demolition to prevent its collapse. Full article

On 18 December 2023, a 6.2-magnitude earthquake struck Jishishan, affecting multiple counties and cities in Gansu and Qinghai Provinces. The seismic intensity of the meizoseismal area was VIII, resulting in extensive structural damage and building collapses. A damage assessment was conducted of the epicenter and surrounding high-intensity zones. To understand the typical structures and characteristics of the buildings that were damaged in these high-intensity zones, this study summarizes the characteristics of the damage to typical rural houses, compares the damage of the rural houses across different sites, and analyzes the causes behind these variations. The findings of the study indicate the following: (1) Timber and some brick–timber structures, due to their age, insufficient material strength, and lack of adequate connections between parts of the building, primarily experienced severe damage or total collapse, characterized by through-wall cracks, partial collapses, or complete collapses. (2) Brick–concrete structures predominantly suffered moderate to severe damage due to factors such as improper layout, uneven façades, and inadequate or incomplete seismic measures. The observed damage included significant wall cracks and extensive damage to two-story buildings. (3) Frame structures, mainly used for public facilities like schools, hospitals, and health centers, exhibited strong integrity and excellent seismic performance, resulting in minimal to no damage, with damage largely confined to non-load-bearing components. (4) The amplification effects of seismic waves in thick loess basin areas, slope sites, and the hanging wall effect of faults exacerbated structural damage to rural houses located in certain villages within the high-intensity areas. The results of this study can serve as a reference for post-disaster reconstruction and seismic retrofitting of buildings and contribute positively to enhancing the disaster resilience of rural housing. Full article

The difficulty in identifying collapsed houses and damaged structures in synthetic aperture radar (SAR) images after natural disasters represents a significant challenge in the monitoring of urban structural deformation using SAR. SAR image simulation was conducted on a three-dimensional model of a typical wooden building in Japan to analyze the scattering mechanism of the structure in collapsed and uncollapsed states. Based on the physical properties of the buildings, a correlation was established between the simulated SAR image feature signals and the geometric structures of the buildings. The findings indicate that SAR scattering is more uniform for uncollapsed structures, which is predominantly influenced by their geometry. At low incidence angles, single reflections were the predominant phenomenon, whereas at high incidence angles, multiple reflections became more prevalent. The uncollapsed building’s facade formed a dihedral angle, exhibiting bright lines in the SAR image. Multiple reflections occurred at the edges of the building and floor junctions. These findings follow the theoretical predictions. In the case of the collapsed buildings, multiple reflections occurred with greater frequency, and irregular scattering was observed. Notwithstanding the augmented scattering pathways, some walls nevertheless manifested single reflections. The collapsed structures demonstrated a reduced sensitivity to alterations in the angle of incidence. Full article

Evaluating the seismic vulnerability of facades of historic masonry buildings is essential not only for their significant historical and heritage value, but also to evaluate the safety of this type of construction. This work applies a simplified methodology to assess the seismic vulnerability of the facade of masonry buildings in the historic center of Morelia, Michoacán, México. The historic center of Morelia was declared a World Cultural Heritage Site by UNESCO in 1991. On the facades, there is ornamentation with sculptural and vegetal decorative elements. The methodology involved conducting visual inspections to identify the location, type of structure, construction materials, doors, windows, balconies, cornices, ironwork, pediments, niches, and sculptures, among other characteristic elements of colonial architecture. The seismic demands were determined specifically for the city’s historic center based on a recent seismic hazard assessment of Morelia. Based on the methodology and the compiled database, characterized vulnerability indices were defined for the different damage scenarios that buildings may present. Results indicate that earthquakes with intensities greater than VIII on the Modified Mercalli scale risk collapsing heritage masonry buildings’ facades. Full article

The emergence of pathological manifestations on facades persists globally, with recurring failures occurring often due to repeated construction details or design decisions. This study selected a building with a recurring architectural design and evaluated the stain pattern on its facade using a UAV with an infrared thermal camera. The results showed that advanced technology offers a non-invasive and efficient approach for comprehensive inspections, enabling early detection and targeted interventions to preserve architectural assets without requiring ancillary infrastructure or risking workers at height. The precise identification of damage clarified the real causes of the observed pathological manifestations. Capturing the images allowed accurate inspection, revealing hollow and damp spots not visible to the human eye. Novel results highlight patterns in the appearance of dirt on facades, related to water flow that could have been redirected through proper geometric element execution. The presented inspection methodology, staining standards, and construction details can be easily applied to any building, regardless of location. Sills, drip pans, and flashings must have drip cuts, adequate inclination, and projections to prevent building degradation. Full article
