Search Results (11)

Deformation monitoring of Gas-Insulated Transmission Lines (GILs) is critical for the early detection of structural issues and for ensuring safe power transmission. In this study, we introduce a rapid monocular measurement method that leverages deep learning for real-time monitoring. A YOLOv10 model is developed for automatically identifying regions of interest (ROIs) that may exhibit deformations. Within these ROIs, grayscale data is used to dynamically set thresholds for FAST corner detection, while the Shi–Tomasi algorithm filters redundant corners to extract unique feature points for precise tracking. Subsequent subpixel refinement further enhances measurement accuracy. To correct image tilt, ArUco markers are employed for geometric correction and to compute a scaling factor based on their known edge lengths, thereby reducing errors caused by non-perpendicular camera angles. Simulated experiments validate our approach, demonstrating that combining refined ArUco marker coordinates with manually annotated features significantly improves detection accuracy. Our method achieves a mean absolute error of no more than 1.337 mm and a processing speed of approximately 0.024 s per frame, meeting the precision and efficiency requirements for GIL deformation monitoring. This integrated approach offers a robust solution for long-term, real-time monitoring of GIL deformations, with promising potential for practical applications in power transmission systems. Full article

The advanced Gas Insulated Switchgear/Gas Insulated Lines (GIS/GIL) transmission equipment serves as an essential physical infrastructure for establishing a new energy power system. An analysis spanning nearly a decade on faults arising from extra/ultra-high voltage discharges reveals that over 60% of such faults are attributed to the discharge of metal particles and dust. While existing technical means, such as ultra-high frequency and ultrasonic sensing, exhibit effectiveness in online monitoring of particles larger than sub-millimeter dimensions, the inherent randomness and elusive nature of micron-nano dust pose challenges for effective characterization through current technology. This elusive micron-nano dust, likely concealed as a latent threat, necessitates special attention due to its potential as a “safety killer”. To address the challenges associated with detecting micron-nano dust and comprehending its intricate mechanisms, this paper introduces a micron-nano dust adsorption experimental platform tailored for observation and practical application in GIS/GIL operations. The findings highlight that micron-nano dust’s adsorption state in the electric field predominantly involves agglomerative adsorption along the insulator surface and diffusive adsorption along the direction of the ground electrode. The pivotal factors influencing dust movement include the micron-nano dust’s initial position, mass, material composition, and applied voltage. Further elucidation emphasizes the potential of micron-nano dust as a concealed safety hazard. The study reveals specific physical phenomena during the adsorption process. Agglomerative adsorption results in micron-nano dust speckles forming on the epoxy resin insulator’s surface. With increasing voltage, these speckles undergo an “explosion”, forming an annular dust halo with deepening contours. This phenomenon, distinct from the initial adsorption, is considered a contributing factor to flashovers along the insulator’s surface. The physical mechanism behind flashovers triggered by micron-nano dust is uncovered, highlighting the formation of a localized short circuit area and intense electric field distortion constituted by dust speckles. These findings establish a theoretical foundation and technical support for enhancing the safe operational performance of AC and DC transmission pipelines’ insulation. Full article

Gas-insulated power transmission lines (GILs) can replace cables and overhead transmission lines, playing an important role in DC transmission systems. However, the influence of surface charge accumulation on insulation reliability cannot be ignored as the operational voltage of the DC GIL increases. In this paper, the measurement methods for the insulator surface potential are summarized, including, dust maps, the Pockels effect method, and the electrostatic probe method. Then, a typical surface charge inversion algorithm is introduced. The main influencing factors of surface charge accumulation are analyzed, such as the applied voltage, insulation gas, insulator shape, and temperature. The charge accumulation pathway is revealed. Furthermore, methods for inhibiting the accumulation of surface charges and promoting the dissipation of accumulated charges are introduced to reduce the surface charges on insulators. Finally, the development direction of DC GIL insulators is predicted. We anticipate that the online monitoring of surface charge distribution, clarifying the percentage of charge accumulation pathways, and optimizing the insulator casting process will be the research directions for the insulator surface charge topic in the future. This article provides a comprehensive understanding of the surface charges of GIL insulators and a reference for the insulation design of DC GILs. Full article

China is taking initiative in energy transition to cope with the long-term controversy of its enormous energy consumption, aiming to use less carbon. Wind power, especially offshore wind energy, has become a prevailing alternative due to its low carbon emissions, renewability, competitiveness, and operation security. The layout of a transmission channel is a key consideration in marine project implementation. This paper investigates the technical characteristics, application status, and viable advantages of a conventional AC transmission, voltage source converter-based high-voltage direct current (VSC-HVDC) transmission, gas-insulated line (GIL) transmission, and hybrid HVDC transmission. A component-resolved evaluation model was proposed to estimate the costs to be incurred of four electrical transmission options for offshore wind power along the coast of Eastern China, with technical feasibility and economical considerations. Cost comparisons and component sensitivity analyses were developed with different transmission distances and capacities. Results suggest HVAC transmission and VSC-HVDC are the preferable solutions for present offshore wind farm development in Eastern China, and the economic potential of the hybrid HVDC makes it feasible for future deployment. Some conclusions can be applied in disparate regions across the globe. Full article

Gas insulated transmission lines (GILs) are used in electrical systems mainly for power transmission and High Voltage substation interconnection. In this paper, we focus on the development of complex numerical tools for the optimization of gas insulated HVDC components by the estimation of realistic electric field distribution and the voltage holding of the designed geometry. In particular, the paper aims at describing the correct modelling approach suitable to study high voltage components in DC, considering the nonlinear behaviour characterizing the electrical conductivity of solid and gas insulators. The simulated field distribution is then adopted to estimate the voltage holding of the dielectric gas, with a convenient engineering technique, based on the streamer criterion. These two tools are integrated in an automatic optimization package developed in COMSOL^® and MATLAB^®, with the purpose of adjusting the critical geometry features, suffering from excessive electrical stress and possibly giving rise to electrical breakdown, in order to guide the designer towards a robust solution. Full article

This work presents a novel diagnostic method to localize Partial Discharges (PDs) inside Medium Voltage (MV) and High Voltage (HV) equipment. The method is well suited for that equipment presenting a bounded domain with fixed Boundary Conditions (BCs) such as Oil-Filled Power Transformers (OFPTs), Air Insulated Switchgears (AISs), Gas Insulated Switchgears (GISs) or Gas Insulated Transmission Lines (GILs). It is based on Electromagnetic (EM) measurements which are used to reconstruct the EM field produced by the PD and localize the PD itself. The reconstruction and localization tasks are based on the eigenfunctions series expansion method which intrinsically accounts for the physical information of the propagation phenomenon. This fact makes the proposed diagnostic method very robust and accurate even in real and complex scenarios. The promising experimental results, obtained in two different test cases, confirmed the ability and powerfulness of the proposed PD localization method. Full article

Gas-insulated lines (GILs) have been increasingly used as high-current busducts for high-power transmission. Temperature is one of the most important factors affecting the performance and ampacity of GILs. In this paper, an analytical method was proposed to determine the temperature of a three-phase high-current busduct in the form of a single pole GIL. First, power losses in the phase conductors and enclosures were determined analytically with the skin, and proximity effects were taken into account. The determined power losses were used as heat sources in thermal analysis. Considering the natural convection and radiation heat transfer effects, the heat balance equations on the surface of the phase conductors and the screens were established, respectively. Subsequently, the temperature of the phase conductors and the enclosures were determined. The validation of the proposed method was carried out using the finite element method and laboratory measurements. Full article

Due to the ever-increasing demand for electricity in the one hand and the environmental constraints to use clean energy on the other hand, the global production of energy from remote renewable sources, particularly from large hydropower plants and offshore wind farms and their connection to the grid are expected to grow significantly in the future. Consequently, the demand to carry this electric power by high voltage direct current (HVDC) technology will increase too. The most suitable HVDC power transmission technology to deliver large amounts of power, exceeding a capacity of 5 GW per bipolar system over long distances with lower losses is by using compact HVDC gas insulated transmission lines (DC GIL) and gas insulated switchgears (DC GIS) with rated voltage (maximum continuous operating voltage) of ±550 kV and 5000 A which are presently under development worldwide. Among the critical challenges for the development of these HVDC gas insulated systems, there are the epoxy cast resin insulators that are used to separate gas compartments also called spacers. Indeed, thorough research studies have been and still being carried out to well understand and clarify the electrical insulation characteristics of HVDC spacers using mainly cylindrical samples and small insulator models, where useful results have been obtained and proposed for implementation in real compact gas insulated systems. However, few practical investigations have been undertaken on real size spacers (product scale) to verify such research outcomes and validate the reliability of the spacers to collect experiences or for commercial use. This paper reviews the current achievements of real size HVDC spacers development. It describes the basic electric field calculation and spacers design, the verification of the insulation performance and validation testing. It gives today’s commercially available compact HVDC GIS/GIL and finally it presents the envisaged future research and development. Full article

The Gas-insulated Line (GIL) is a technical equipment that allows power transmission underground at high voltage level. The UHV GIL-overhead hybrid transmission line is an essential way for power transmission in complicated landscapes. Because of the distributed capacitance of the UHV transmission line and the difference of the structure and the electrical parameters between GIL and overhead transmission line, the distance protection based on uniform lumped parameters cannot be applied to this hybrid transmission line directly. In order to overcome the shortcomings, this paper studies and proposes a new principle of distance protection for the UHV GIL-overhead hybrid transmission line based on frequency domain lossless transmission line equation, with the distributed capacitance accounted. Then, the paper presents a setting scheme for this distance protection with the hybrid line parameters considered. Finally, tests are carried out on the Power Systems Computer Aided Design (PSCAD) platform, and the accuracy and reliability of the distance protection method proposed are verified by simulation results. Full article

Gas insulated transmission lines (GILs) are being used in electrical systems regarding power transmission and substation interconnection. However, operational complexities of conventional schemes, such as structural rigidity, corrosion protection, gas leakage in case of seismic vibrations, larger bending radius and jointing complexities which restrain their application perspectives, could be curtailed by developing a flexible GIL. In this research paper, a new pliable scheme of gas insulated transmission line is proposed. Further, COMSOL Multiphysics^® (version 5.1, COMSOL Inc., Stockholm, Sweden) based electrostatic assay and practically performed high voltage tests-based dielectric analysis is performed for the proposed scheme. Electrostatic appraisal is comprised of field utilization based electrostatic stress analysis. In addition, dimensional optimization of pliable GIL regarding enclosure and pitch sizes in relation to electrostatic stresses and field utilization is also performed. Regarding dielectric perusal, experimental setup has been developed for standard lightning impulse and disruptive discharge tests in order to investigate the synergistic dielectric characteristics of proposed flexible post insulators for pliable GIL. Experimental and simulation appraisal unveil that the proposed scheme exhibits almost analogous electrostatic and dielectric behavior in comparison to the conventional GIL scheme and could simplify the operational intricacies associated with conventional scheme. The proposed modifications could eliminate the requirement of trench development, corrosion protection and acceleration dampers, along with a significant reduction in required land area at bends, due to a smaller bending radius which will ultimately result in substantial cost reduction. Full article

The gas-insulated line (GIL) is one technical solution to allow the transmission of electricity underground at a high voltage level, yet its equivalent model is quite complicated. Based on an examination of the geometrical structure of the GIL and the way the metallic enclosure is grounded, this paper analyzed the electromagnetic and electrostatic coupling among the inner conductors and the metallic enclosures of the three phases. Then, the paper proposes a modeling method for the widely-used short-distance GIL based on the PI-model (the model consisting of two lumped admittance at each terminal and a lumped impedance in between). The GIL parameters were later simplified with the coupling effect of the metallic enclosure considered, and a simplified PI-model was produced. Finally, the proposed PI-model and its simplified version were built on the Power Systems Computer Aided Design (PSCAD) platform, and their effectiveness verified by simulation results. Full article
