This study details the modelling and simulation analyses performed on a mathematically modelled permanent magnet-assisted synchronous reluctance motor (PMa-SynRM) driven by a field-oriented controlled (FOC) voltage source inverter (VSI) coupled with a half-bridge bidirectional buck-boost DC/DC converter for two-wheeler electric vehicle (EV) applications. The 5 kW, 1500 rpm PMa-SynRM employed here has a shorter response time and is also naturally lighter and cost-effective, making it suitable for two-wheeler EVs. Field-oriented control simplifies the control strategy for PMa-SynRM by decoupling torque and flux, effectively matching the behaviour of a DC motor. A half-bridge buck-boost converter is a DC-DC converter capable of bidirectional power flow, stepping up and down voltages. This makes it ideal for both motoring and regenerative braking in electric vehicles. The buck-boost converter with its controller effectively adjusts the inverter and battery voltage for efficient power flow during motoring and maximum power recovery during regenerating braking. The developed model aims at demonstrating forward and reverse motoring, as well as forward and reverse braking to validate the four-quadrant torque-speed characteristics of two-wheeler EVs. The proposed model attains less than 2% torque ripple and less than 1% speed ripple, respectively. Further, the current ripples are minimised to reduce losses and to improve efficiency. The work presented in this paper implements a PMa-SynRM-based drive system for EVs, a technology which is in the exploratory stage and not commercially widespread. This adds novelty to the proposed work. A MATLAB Simulink environment was used for modelling and simulation. Full article

To improve the speed regulation performance of permanent magnet synchronous motor (PMSM) drive systems, a composite control strategy consisting of an improved sliding mode controller (ISMC) and an adaptive Luenberger load torque observer (ALLTO) is proposed. The ISMC is constructed based on a novel sliding mode reaching law (NSMRL). The proposed NSMRL overcomes the slow convergence and chattering problems of conventional reaching laws by introducing system state variables and a nonlinear adaptive function, ensuring rapid convergence with reduced chattering. In parallel, the ALLTO is developed to estimate and compensate load disturbances in real time, where its bandwidth is adaptively adjusted according to the speed error to achieve fast response and high estimation accuracy without degrading steady-state performance. Experimental results demonstrate that the proposed control scheme significantly improves the dynamic response and disturbance rejection capability of PMSM drive systems. Full article

To address the deteriorated control performance of permanent magnet synchronous motor (PMSM) drive systems for new energy vehicles (NEVs) under complex conditions caused by multi-source disturbances (internal parameter perturbations and external load mutations), this paper proposes an improved terminal integral sliding mode control (ITISMC-ADERL) strategy integrating a piecewise adaptive terminal integral sliding mode surface and an ADERL. The proposed sliding mode surface adopts interval-adaptive switching between high- and low-order power terms, completely eliminating singularity and integral saturation defects of traditional terminal sliding mode control while ensuring fast convergence, and achieving an optimal structural balance between convergence speed and chattering suppression. The state-dependent ADERL leverages the synergy of error-sliding variable coupled dynamic gain adjustment and variable exponential power compensation, realizing dual-mode adaptive switching of “strong driving for fast approaching far from the sliding surface, weak gain for smooth regulation near the sliding surface”, which significantly improves control accuracy and anti-disturbance robustness. The finite-time convergence of the closed-loop system is rigorously proved via Lyapunov stability theory. Full-operating-condition comparative tests on a TMS320F28379D DSP platform show that the proposed strategy outperforms SMC-ERL, ISMC-ERL and ITISMC-ERL in all test scenarios (no-load startup, acceleration/deceleration, sudden load changes, flux linkage perturbation), meeting the requirements of high-performance NEV drive systems and possessing important engineering application potential. Full article

In order to reduce the influence of external radial disturbances on the control accuracy and stability of the vehicle magnetic suspension flywheel battery system during driving, and to further enhance the system’s disturbance rejection ability, this paper designs a control method based on the Accelerated Engineering Fastest Controller (AEFC) and the improved differential optimization algorithm. A mathematical model of the flywheel battery system is established, and the AEFC scheme with engineering disturbance rejection is adopted in the control loop. The improved differential optimization algorithm is used to obtain the optimal control parameters of AEFC, and a multi-criteria optimization function combining tracking error and smoothness is established. The overall control scheme effectively integrates the characteristics of rapid tracking, interference suppression, and rapid parameter adjustment. The experimental results show that compared with the Engineering Fastest Controller (EFC), in the vehicle turning process, the AEFC controller can reduce the offset by 28% during vehicle driving, and compared with the traditional PID control, it can reduce the offset by 41.94%. In the process of vehicle uphill and speed change, the control effect of AEFC also has a significant improvement. Full article

This study introduces a sensorless control approach for permanent magnet synchronous motors (PMSMs) that employs an Improved Non-Singular Fast Terminal Sliding Mode Controller (IMNFTSMC) and an Improved Non-Singular Fast Terminal Sliding Mode Observer (IMNFTSMO). The IMNFTSMC employs a novel hybrid reaching law and a continuous piecewise square root switching function to achieve faster convergence and effective chattering reduction over the conventional Sliding Mode Controller (SMC). This design successfully replaces two critical components: the discontinuous constant velocity term (a key component of the traditional SMC reaching law that is a primary source of control chattering in PMSM torque regulation) and the high-gain exponential term (which tends to induce overshoot during transient speed adjustments and degrade steady-state control precision). In the IMNFTSMO, a hybrid approach combining linear and non-singular terminal sliding modes eliminates phase lag associated with low-pass filtering in traditional sliding mode observers, improving rotor position and speed estimation accuracy. Stability of both IMNFTSMC and IMNFTSMO is rigorously proven using Lyapunov stability theory.Validation through extensive simulations and hardware experiments, including challenging zero-speed start, speed stepping, and load disturbance tests, confirms the proposed strategy provides improved dynamic response, effective anti-disturbance capability, and high accuracy for rotor position and speed estimation compared to established benchmark methods, demonstrating its feasibility for mid-to-low speed sensorless PMSM drives. Full article

Permanent magnet synchronous motors (PMSM) are widely favored in industry for their high efficiency, compact size, and robust performance. This study employs a model-based PID control approach for speed regulation of PMSM. In contrast to traditional PID approaches, this method addresses the inherent nonlinearity of PMSM systems and tunes PID coefficients dynamically for fast multi-input and multi-output (MIMO) operations. Traditional PID controllers typically assume linear motor dynamics and determine a single set of coefficients, often through trial and error. However, the nonlinear dynamics of motor drives and variations in motor parameters often lead to instability, limiting the effectiveness of conventional PID controllers. The proposed auto-tuning PID controller adjusts its coefficients in real-time based on the system’s operational state. This method has been implemented in both simulation and experimental setups, with real-time execution facilitated by dSPACE DS1104. A comparative analysis with conventional PI control demonstrates the enhanced stability and adaptability of the proposed approach. Full article

The permanent magnet synchronous motor (PMSM) is extensively utilized in the power drive systems of Cyber–Physical Systems (CPSs). In scenarios where control signals are subjected to malicious attacks within the network, ensuring that the PMSM achieves its designated speed within a specified timeframe serves as a critical metric for evaluating the efficacy of security control strategies in networked systems. To address practical challenges arising from updates to controlled objects at the physical layer and limitations of control layer algorithms—wherein convergence time for system trajectory tracking errors (TTEors) may extend indefinitely—we have developed a novel resilient control algorithm with predefined-time convergence (PreTC) tailored for uncertain PMSMs susceptible to cyber threats. Firstly, we introduce an innovative Lyapunov stability criterion characterized by an adjustable gain reaching law alongside PreTC. Following this, we design an SMS (SMS) that incorporates PreTC and employ an extreme learning machine (ELM) to facilitate real-time identification of both physical layer models and malicious cyber-attacks. A sliding-mode adaptive resilient controller devoid of explicit physical model information is proposed for CPSs, with Lyapunov stability theory substantiating the system’s predefined-time (PDT) stability. This significantly enhances resilience against malicious cyber-attacks and other uncertainties. Finally, comparative simulations involving four distinct resilient control algorithms demonstrate that our proposed algorithm not only guarantees predetermined convergence times but also exhibits robust resistance to cyber-attacks, parameter perturbations, and external disturbances—notably achieving a motor speed tracking error accuracy of 0.008. These findings validate the superior robustness and effectiveness of our control algorithm against malicious cyber threats. Full article

The continuous reduction in critical dimensions and the escalating demands for higher throughput are driving motion platforms to operate under increasingly complex conditions, including multi-axis coupling, structural nonlinearities, and time-varying operational scenarios. These complexities make the trade-offs among precision, speed, and robustness increasingly challenging. Traditional Proportional–Integral–Derivative (PID) controllers, which rely on empirical tuning methods, suffer from prolonged trial-and-error cycles and limited transferability, and consequently struggle to maintain optimal performance under these complex working conditions. This paper proposes an adaptive β–Proximal Policy Optimization with Random Network Distillation (β-PPO-RND) parameter optimization within the Prescribed Performance Control (PPC) framework. The adaptive coefficient β is updated based on the temporal change in reward difference, which is clipped and smoothly mapped to a preset range using a hyperbolic tangent function. This mechanism dynamically balances intrinsic and extrinsic rewards—encouraging broader exploration in the early stage and emphasizing performance optimization in the later stage. Experimental validation on a Permanent Magnet Linear Synchronous Motor (PMLSM) platform confirms the effectiveness of the proposed approach. It eliminates the need for manual tuning and enables real-time controller parameter adjustment within the PPC framework, achieving high-precision trajectory tracking and a significant reduction in steady-state error. Experimental results show that the proposed method achieves MAE = 0.135 and RMSE = 0.154, representing approximately 70% reductions compared to the conventional PID controller. Full article

This paper proposes an enhanced Model Predictive Direct Speed Control (MPDSC) framework for Permanent Magnet Synchronous Motor (PMSM) drives, integrating duty ratio optimization and load torque disturbance compensation to significantly improve both transient and steady-state performance. Traditional finite-control-set MPC strategies, which apply a single voltage vector per sampling interval, often suffer from steady-state ripples, elevated total harmonic distortion (THD), and high computational complexity due to exhaustive switching evaluations. The proposed approach addresses these limitations through a novel dual-stage cost function structure: the first cost function optimizes dynamic response via predictive control of speed error, while the second adaptively minimizes torque ripple and harmonic distortion by adjusting the active–zero voltage vector duty ratio without the need for manual weight tuning. Robustness against time-varying disturbances is further enhanced by integrating a real-time load torque observer into the control loop. The scheme is validated through both MATLAB/Simulink R2020a simulations and real-time experimental testing on a dSPACE 1202 rapid control prototyping platform across small- and large-scale PMSM configurations. Experimental results confirm that the proposed controller achieves a transient speed deviation of just 0.004%, a steady-state ripple of 0.01 rpm, and torque ripple as low as 0.0124 Nm, with THD reduced to approximately 5.5%. The duty ratio-based predictive modulation ensures faster settling time, improved current quality, and greater immunity to load torque disturbances compared to recent duty-ratio MPC implementations. These findings highlight the proposed DR-MPDSC as a computationally efficient and experimentally validated solution for next-generation PMSM drive systems in automotive and industrial domains. Full article

Aiming at the control performance degradation of permanent magnet synchronous motor (PMSM) drive systems caused by uncertainties of internal and external disturbances, a robust control algorithm integrating an improved fast terminal sliding mode (IFTSM) surface with a novel adaptive reaching law (NARL) is proposed. A dynamic model of PMSM with disturbances is established, and an improved fast terminal sliding mode surface is designed. By introducing nonlinear terms and error derivative feedback mechanisms, the finite-time rapid convergence of system states is achieved, while solving the singularity problem of traditional terminal sliding mode control. Combined with the novel adaptive reaching law strategy, a state-dependent gain adjustment function is used to dynamically optimize the balance between reaching speed and chattering, enhancing the smoothness of the system′s dynamic response. Through the synergy of the finite-time convergence characteristic of the improved sliding mode surface and the novel adaptive reaching law, the proposed algorithm significantly enhances the system′s anti-interference capability against load mutations and parameter time variations. Experiment results demonstrate that under complex working conditions, the algorithm achieves superior speed tracking accuracy and current stability, providing a control solution with strong anti-interference capability and fast response for PMSM speed control systems. Full article

Time-varying lumped disturbance and measurement noise are primary obstacles that restrict the control performance of permanent magnet synchronous motor (PMSM) drives. To tackle these obstacles, an adaptive nonsingular terminal sliding mode (ANTSM) algorithm is combined with augmented recursive sliding mode observer (ARSMO) for PMSM speed regulation system in this paper. Generally, conventional nonsingular terminal sliding mode (NTSM) controller adopts a fixed and conservative control gain to suppress the time-varying disturbance, which will lead to unsatisfactory steady-state performance. Without requiring any information of the time-varying disturbance in advance, a novel barrier function adaptive algorithm is utilized to adjust the gain of NTSM controller online according to the amplitude of disturbance. In addition, the ARSMO is emoloyed to estimate the total disturbance and motor speed simultaneously, thereby alleviating the negative impact of measurement noise and excessive control gain. Comprehensive experimental results verify that the proposed enhanced ANTSM strategy can optimize the dynamic performance of PMSM system without sacrificing its steady-state performance. Full article

This study proposes a current control strategy to enhance the control stability of an interior permanent magnet synchronous motor (IPMSM) under transient conditions, such as rapid acceleration or deceleration in electric vehicle (EV) applications. Conventional current control methods provide optimal steady-state current references corresponding to torque commands using a lookup table (LUT)-based approach. However, during transitions between these reference points, particularly in the field-weakening region at high speeds, the voltage limit may be exceeded. When the voltage limit is exceeded, unstable overmodulation states may occur, degrading stability and resulting in overshoot of the inverter input current. Although ramp generators are commonly employed to interpolate between current references, a fixed ramp slope may fail to ensure a sufficient voltage margin during rapid transients. In this study, a method is proposed to dynamically adjust the rate of change of the d-axis current reference in real time based on the difference between the inverter output voltage and its voltage limit. By enabling timely field-weakening before rapid changes in speed or q-axis current, the proposed strategy maintains control stability within the voltage limit. The effectiveness of the proposed method was verified through simulations based on real vehicle driving profiles and dynamometer experiments using a 38 kW class IPMSM for a hybrid electric vehicle (HEV), demonstrating reduced input DC current overshoot, improved voltage stability, and enhanced torque tracking performance under high-speed transient conditions. Full article

Conventional model-free control (MFC) is widely used in motor drives due to its simplicity and model independence, yet its performance suffers from imperfect disturbance estimation and input gain mismatch. To address these issues, this paper proposes an adaptive enhanced model-free speed control (AEMFSC) scheme based on an ultra-local model for permanent magnet synchronous motor (PMSM) drives. First, by integrating a nonlinear disturbance observer (NDOB) and a PD control law into the generalized model-free controller, an enhanced model-free speed controller (EMFSC) was developed to ensure closed-loop stability. Compared with a conventional MFSC, the proposed method eliminated steady-state errors, reduced the speed overshoot, and achieved faster settling with improved disturbance rejection. Second, to address the performance degradation induced by input gain $\alpha$ mismatch during time-varying load conditions, we developed an online parameter identification method for real-time $\alpha$ estimation. This adaptive mechanism enabled automatic controller parameter adjustment, which significantly enhanced the transient tracking performance of the PMSM drive. Furthermore, an algebraic-framework-based high-precision identification technique is proposed to optimize the initial $\alpha$ selection, which effectively reduces the parameter tuning effort. Simulation and experimental results demonstrated that the proposed AEMFSC significantly enhanced the PMSM’s robustness against load torque variations and parameter uncertainties. Full article

A novel brushless power feedback permanent magnet adjustable speed drive (BLPF-PMASD) is developed for the energy-saving of a large power electrical machine drive system in this paper. It can transfer the slip power between the input and output shafts to a stator and then transmit it back to the power grid, achieving higher drive efficiency and stability. First, the topology feature, operation principle, and power feedback mechanism of the proposed drive are clearly illustrated. Second, a multi-objective optimization design method suitable for all working conditions is proposed to provide an effective design means for this type of adjustable speed drive with power feedback. Finally, the electromagnetic performance of the optimized drive is analyzed by using the finite element method (FEM) to demonstrate the effectiveness and superiority of the proposed drive. Full article

In this paper, an axial flux electromagnetic energy harvester driven by a Stirling engine (AFEEH-SE) is presented for recovering waste heat above 200 °C. A gamma-type Stirling engine with a slider-crank drive mechanism serves as the power unit to convert thermal energy into rotational mechanical energy. The harvester comprises a rotating magnet array and a stationary coil array. Finite element simulations were conducted to analyze and compare the voltage output under different magnet and coil parameter configurations. Subsequently, a prototype utilizing mineral oil combustion as the heat source was designed, achieving a rotational speed of 950 rpm under open-circuit conditions. Through systematic adjustments to the magnet and coil parameters, the optimal performance configuration was determined to maximize the output power of the harvester. Under this optimized configuration, the AFEEH-SE achieved an effective power output of 57.13 mW, capable of charging a 2.2 mF capacitor to 28 V in 49 s. This study demonstrates the feasibility of the AFEEH-SE in practical applications and provides a solid foundation for the future field of waste heat recovery. Full article
