Search Results (61)

Variability across different calibration laboratories can impact the consistency of ocean color data; this study addresses that challenge through a coordinated comparison of spectral irradiance and radiance calibrations. As part of the Fiducial Reference Measurements for Satellite Ocean Color (FRM4SOC) Phase 2 project, the metrological consistency across six international laboratories was tested in the years 2022–2023. Each participant determined the responsivity for four transfer radiometers using their own SI-traceable radiometric standards and calibration procedures. This was among the first laboratory comparisons for Ocean Color Radiometry (OCR) using hyperspectral radiometers. The main objective was to verify that the instrument manufacturers and research laboratories can fulfill the updated International Ocean Color Coordination Group (IOCCG) protocols to perform SI traceable calibrations with an uncertainty of 1% (k = 1) for irradiance and slightly more for radiance. The comparison revealed biases among participants and provided an overview of the calibration capabilities of OCRs. The differences between the participants varied from ±1 … 2% up to ±5%. Biases due to different measurement conditions were corrected by the Pilot. Furthermore, biases due to traceability and different conditions revealed several data handling errors. However, after uniform data processing, the metrological compatibility between the participants was reached within ±3%. Full article

We present a gradient boosting framework for reconstructing hyperspectral signatures in the visible spectrum (400–700 nm) of satellite-based ocean scenes from limited multispectral inputs. Hyperspectral data is composed of many, typically greater than 100, narrow wavelength bands across the electromagnetic spectrum. While hyperspectral data can offer reflectance values at every nanometer, multispectral sensors typically provide only 3 to 11 discrete bands, undersampling the visible color space. Our approach is applied to remote sensing reflectance ($R_{rs}$) measurements from a set of ocean color sensors, including Suomi-National Polar-orbiting Partnership (SNPP) Visible Infrared Imaging Radiometer Suite (VIIRS), the Ocean and Land Colour Instrument (OLCI), Hyperspectral Imager for the Coastal Ocean (HICO), and NASA’s Plankton, Aerosol, Cloud, Ocean Ecosystem Ocean Color Instrument (PACE OCI), as well as in situ $R_{rs}$ data from National Oceanic and Atmospheric Administration (NOAA) calibration and validation cruises. By leveraging these datasets, we demonstrate the feasibility of transforming low-spectral-resolution imagery into high-fidelity hyperspectral products. This capability is particularly valuable given the increasing availability of low-cost platforms equipped with RGB or multispectral imaging systems. Our results underscore the potential of hyperspectral enhancement for advancing ocean color monitoring and enabling broader access to high-resolution spectral data for scientific and environmental applications. Full article

The chlorophyll-a (Chl-a) concentration, a critical parameter for characterizing marine primary productivity and ecological health, plays a vital role in providing ecological environment monitoring and climate change assessment while serving as a core retrieval product in ocean color remote sensing. Currently, more than ten ocean color satellites operate globally, including China’s HY-1C, HY-1D and HY-1E satellites. However, significant spatial data gaps exist in Chl-a concentration retrieval from satellites because of cloud cover, sun-glint, and limitation of sensor swath. This study aimed to systematically enhance the spatiotemporal integrity of ocean monitoring data through multisource data merging and reconstruction techniques. We integrated Chl-a concentration datasets from four major sensor types—Moderate Resolution Imaging Spectroradiometer (MODIS), Visible Infrared Imaging Radiometer Suite (VIIRS), Ocean and Land Color Instrument (OLCI), and Chinese Ocean Color and Temperature Scanner (COCTS)—and quantitatively evaluated their global coverage performance under different payload combinations. The key findings revealed that single-sensor 4-day continuous observation achieved effective coverage levels ranging from only 10.45–26.1%, while multi-sensor merging substantially increased coverage, namely, homogeneous payload merging provided 25.7% coverage for two MODIS satellites, 41.1% coverage for three VIIRS satellites, 24.8% coverage for two OLCI satellites, and 37.1% coverage for three COCTS satellites, with 10-payload merging increasing the coverage rate to 55.4%. Employing the Data Interpolating Empirical Orthogonal Functions (DINEOFS) algorithm, we successfully reconstructed data for China’s ocean color satellites. Validation against VIIRS reconstructions indicated high consistency (a mean relative error of 26% and a linear correlation coefficient of 0.93), whereas self-verification yielded a mean relative error of 27% and a linear correlation coefficient of 0.90. Case studies in Chinese offshore and adjacent waters, waters east of Mindanao Island and north of New Guinea, demonstrated the successful reconstruction of spatiotemporal Chl-a dynamics. The results demonstrated that China’s HY-1C, HY-1D, and HY-1E satellites enable daily global-scale Chl-a reconstruction. Full article

In satellite altimetry calibration, the atmosphere’s integrated water vapor content has been customarily derived through the Global Navigation Satellite Systems (GNSS), principally over land where the satellite radiometer is not operational. Progressively, several alternative methods have emerged to estimate this wet troposphere component with ground instruments, alternative satellite sensors, and global models. For any ground calibration facility, integration of various approaches is required to arrive at an optimum value of a calibration constituent and in accordance with the strategy of Fiducial Reference Measurements (FRM). In this work, different estimation methods and instruments are evaluated for wet troposphere delays, especially when transponder and corner reflectors are employed at the Permanent Facility for Altimetry Calibration of the European Space Agency. Evaluation includes, first, ground instruments with microwave radiometers and radiosondes; second, satellite sensors with the Ocean Land Color Instrument (OLCI) and the Sea Land Surface Temperature Radiometer (SLSTR) of the Copernicus Sentinel-3 altimeter, as well as the TROPOMI spectrometer on the Sentinel-5P satellite; and finally with global atmospheric models, such as the European Center for Medium-Range Weather Forecasts. Along these lines, multi-sensor and redundant values for the troposphere delays are thus integrated and used for the calibration of Sentinel-6 MF and Sentinel-3A/B satellite altimeters. All in all, the integrated water vapor value of the troposphere is estimated with an FRM uncertainty of ±15 mm. In the absence of GNSS stations, it is recommended that the OLCI and SLSTR measurements be used for determining tropospheric delays in daylight and night operations, respectively. Ground microwave radiometers can also be used to retrieve tropospheric data with high temporal resolution and accuracy, provided that they are properly installed and calibrated and operated with site-specific parameters. Finally, the synergy of ground radiometers with instruments on board other Copernicus satellites should be further investigated to ensure redundancy and diversity of the produced values for the integrated water vapor. Full article

The multi-band atmospheric correction algorithms, now referred to as remote sensing reflectance (R_rs) algorithms, have been implemented on a NASA computing facility for global remote sensing of ocean color and atmospheric aerosol parameters from data acquired with several satellite instruments, including the Visible Infrared Imaging Radiometer Suite (VIIRS) on board the Suomi spacecraft platform. These algorithms are based on the 2-band version of the SeaWiFS (Sea-Viewing Wide Field-of-View Sensor) algorithm. The bands centered near 0.75 and 0.865 μm are used for atmospheric corrections. In order to obtain high-quality R_rs values over Case 1 waters (deep clear ocean waters), strict masking criteria are implemented inside these algorithms to mask out thin clouds and very turbid water pixels. As a result, R_rs values are often not retrieved over bright Case 2 waters. Through our analysis of VIIRS data, we have found that spatial features of bright Case 2 waters are observed in VIIRS visible band images contaminated by thin cirrus clouds. In this article, we describe methods of combining cirrus and aerosol corrections to improve spatial coverage in R_rs retrievals over Case 2 waters. One method is to remove cirrus cloud effects using our previously developed operational VIIRS cirrus reflectance algorithm and then to perform atmospheric corrections with our updated version of the spectrum-matching algorithm, which uses shortwave IR (SWIR) bands above 1 μm for retrieving atmospheric aerosol parameters and extrapolates the aerosol parameters to the visible region to retrieve water-leaving reflectances of VIIRS visible bands. Another method is to remove the cirrus effect first and then make empirical atmospheric and sun glint corrections for water-leaving reflectance retrievals. The two methods produce comparable retrieved results, but the second method is about 20 times faster than the spectrum-matching method. We compare our retrieved results with those obtained from the NASA VIIRS R_rs algorithm. We will show that the assumption of zero water-leaving reflectance for the VIIRS band centered at 0.75 μm (M6) over Case 2 waters with the NASA R_rs algorithm can sometimes result in slight underestimates of water-leaving reflectances of visible bands over Case 2 waters, where the M6 band water-leaving reflectances are actually not equal to zero. We will also show conclusively that the assumption of thin cirrus clouds as ‘white’ aerosols during atmospheric correction processes results in overestimates of aerosol optical thicknesses and underestimates of aerosol Ångström coefficients. Full article

The Visible Infrared Imaging Radiometer Suite (VIIRS) onboard the National Oceanic and Atmospheric Administration-20 (NOAA-20) satellite was launched on 18 November 2017. The on-orbit calibration of the NOAA-20 VIIRS visible and near-infrared (VisNIR) bands has been very stable over time. However, NOAA-20 operational M1 (a dual gain band with a center wavelength of 0.41 µm) sensor data records (SDR) have exhibited persistent scene-dependent striping over clear-sky ocean (high gain, low radiance) since the beginning of the mission, different from other VisNIR bands. This paper studies the root causes of the striping in the operational NOAA-20 M1 SDRs. Two potential factors were analyzed: (1) polarization effect-induced striping over clear-sky ocean and (2) imperfect on-orbit radiometric calibration-induced striping. NOAA-20 M1 is more sensitive to the polarized lights compared to other NOAA-20 short-wavelength bands and the similar bands on the Suomi NPP and NOAA-21 VIIRS, with detector and scan angle-dependent polarization sensitivity up to ~6.4%. The VIIRS M1 top of atmosphere radiance is dominated by Rayleigh scattering over clear-sky ocean and can be up to ~70% polarized. In this study, the impact of the polarization effect on M1 striping was investigated using radiative transfer simulation and a polarization correction method similar to that developed by the NOAA ocean color team. Our results indicate that the prelaunch-measured polarization sensitivity and the polarization correction method work well and can effectively reduce striping over clear-sky ocean scenes by up to ~2% at near nadir zones. Moreover, no significant change in NOAA-20 M1 polarization sensitivity was observed based on the data analyzed in this study. After the correction of the polarization effect, residual M1 striping over clear-sky ocean suggests that there exists half-angle mirror (HAM)-side and detector-dependent striping, which may be caused by on-orbit radiometric calibration errors. HAM-side and detector-dependent striping correction factors were analyzed using deep convective cloud (DCC) observations (low gain, high radiances) and verified over the homogeneous Libya-4 desert site (low gain, mid-level radiance); neither are significantly affected by the polarization effect. The imperfect on-orbit radiometric calibration-induced striping in the NOAA operational M1 SDR has been relatively stable over time. After the correction of the polarization effect, the DCC-based striping correction factors can further reduce striping over clear-sky ocean scenes by ~0.5%. The polarization correction method used in this study is only effective over clear-sky ocean scenes that are dominated by the Rayleigh scattering radiance. The DCC-based striping correction factors work well at all radiance levels; therefore, they can be deployed operationally to improve the quality of NOAA-20 M1 SDRs. Full article

The study explores the feasibility of adapting the EOStat crop monitoring system, originally designed for monitoring crop growth conditions in Poland, to fulfill the requirements of a similar system in Ukraine. The system utilizes satellite data and agrometeorological information provided by the Copernicus program, which offers these resources free of charge. To predict crop yields, the system uses several factors, such as vegetation condition indices obtained from Sentinel-3 Ocean and Land Color Instrument (OLCI) optical and Sea and Land Surface Temperature Radiometer (SLSTR). It also incorporates climate information, including air temperature, total precipitation, surface radiation, and soil moisture. To identify the best predictors for each administrative unit, the study utilizes a recursive feature elimination method and employs the Extreme Gradient Boosting regressor, a machine learning algorithm, to forecast crop yields. The analysis indicates a noticeable decrease in crop losses in 2022 in certain regions of Ukraine, compared to the previous year (2021) and the 5-year average (2017–2021), specifically for winter crops and maize. Considering the reduction in yield, it is estimated that the decline in production of winter crops in 2022 was up to 20%, while for maize, it was up to 50% compared to the decline in production. Full article

In this communication, we present an innovative approach leveraging advanced Machine Learning (ML) and Artificial Intelligence (AI) techniques, specifically the Non-Negative Matrix Factorization (NMF) method, to analyze downward and upward light spectra collected by Hyperspectral Ocean Color Radiometer (HyperOCR, HOCR) sensors in the water column. Our work focuses on the development of a robust and efficient tool for unraveling the structure and activities of natural microbial assemblages in the ocean. By applying the NMF method to HyperOCR data, we successfully extracted five spectral signatures, representing unique patterns in the data. These signatures were instrumental in predicting the abundances of various microbial components, including bacteria, heterotrophic nanoflagellates, and picoeukaryotes, showcasing the potential of ML and AI in advancing oceanographic studies. To validate these methods, the study area included a shallow coastal area under the influence of freshwater inflow and an open offshore area with a depth of 100 m. The study sites in coastal and offshore waters (Kaštela Bay and Stončica Vis, respectively) had significantly different hydrographic and microbiological characteristics. Kaštela Bay had lower temperatures and salinity than the site on Vis. We have demonstrated prediction of the structure of the microbial community through application of different AI and ML methods with specific HOCR sensors. Full article

Utilizing in situ measurement data to assess satellite-derived long-term ocean color products under different observational conditions is crucial for ensuring data quality and integrity. In this study, we conducted an extensive evaluation and analysis of Visible Infrared Imaging Radiometer Suite (VIIRS) remote sensing reflectance (Rrs) products using long-term OC-CCI in situ data from 2012 to 2021. Our research findings indicate that, well beyond its designed operational lifespan, the root mean square difference accuracy of VIIRS Rrs products across most spectral bands remains superior to 0.002 (sr⁻¹). However, VIIRS Rrs products in shorter wavelength bands (e.g., at 412 nm) have exhibited significantly lower accuracy and a long-term bias in recent years. The annual precision of VIIRS Rrs products demonstrated a declining trend, particularly in coastal or eutrophic waters. This degradation in accuracy highlights the imperative for continuous monitoring of VIIRS performance and further advancements in the atmospheric correction algorithm, especially to address satellite records at high solar zenith angles (SZAs) and observation zenith angles (OZAs). Our analysis indicates that, in observation environments with high SZAs (greater than 70°), the accuracy of VIIRS Rrs products has declined by nearly 50% compared to typical solar zenith angle observation conditions. To address the challenge of declining accuracy under large observation geometries, we introduced the neural network atmospheric correction model (NN-V). Developed based on meticulously curated VIIRS products, the NN-V model exhibits outstanding performance in handling VIIRS data in conditions of extensive observation geometries. During the winter season in high-latitude marine regions, the NN-V model demonstrates a remarkable enhancement in ocean color product coverage, achieving an increase of nearly 20 times compared to traditional methods. Full article

Haiyang-1D (HY-1D) is the second operational satellite in China’s Haiyang-1 series of satellites, carrying the Chinese Ocean Color and Temperature Scanner (COCTS) to provide ocean color and temperature observations. The radiometric calibration is a prerequisite to guarantee the quality of the satellite observations and the derived products, and the radiometric calibration of the thermal emissive bands of HY-1D/COCTS can effectively improve the accuracy of sea surface temperature (SST) derived from the thermal infrared data. In this paper, a study on the regional cross-calibration of the COCTS thermal emissive bands is conducted for high-accuracy SST observations in the South China Sea. The Visible Infrared Imaging Radiometer Suite (VIIRS) on board the NOAA-20 satellite launched by the National Oceanic and Atmospheric Administration (NOAA) is selected as the calibration reference sensor, and a double-difference cross-calibration method is used for HY-1D/COCTS thermal infrared brightness temperature (BT) evaluation. The results show that the bias of the 11 µm and 12 µm thermal emissive bands of COCTS and VIIRS in the South China Sea are 0.101 K and 0.892 K, respectively, and the differences in BTs between the two sensors show temperature dependence. The cross-calibration coefficients are obtained and used to correct the BT of the COCTS thermal emissive bands. The bias of the BT of the 11 µm and 12 µm bands of COCTS are about 0.01 K after cross-calibration. To further validate the results, COCTS post-calibration data were examined using the NOAA-20 Cross-track Infrared Sounder (CrIS) data as a third-party source. The BT is calculated with the spectral response functions of the COCTS thermal emissive bands using the convolution calculation of the CrIS hyperspectral region observations. The comparison shows a small bias between the post-calibration COCTS thermal emissive band observations and CrIS, which is consistent with the comparison between VIIRS and CrIS. The accuracy of the post-calibration COCTS thermal emissive band BT data in the South China Sea has been significantly improved. Full article

China’s marine satellite infrared radiometer SST remote sensing observations began relatively late. Thus, it is essential to evaluate and correct the SST observation data of the Ocean Color and Temperature Scanner (COCTS) onboard the China HY-1C satellite in the Southeast Asia seas. We conducted a quality assessment and correction work on the SST of the China COCTS/HY-1C in Southeast Asian seas based on multisource satellite SST data and temperature data measured by Argo buoys. The accuracy evaluation results of the COCTS SST indicated that the bias, Std, and RMSE of the daytime SST data for HY-1C were −0.73 °C, 1.38 °C, and 1.56 °C, respectively, while the bias, Std, and RMSE of the nighttime SST data were −0.95 °C, 1.57 °C, and 1.83 °C, respectively. The COCTS SST accuracy was significantly lower than that of other infrared radiometers. The effect of the COCTS SST zonal correction was most significant, with the Std and RMSE approaching 1 °C. After correction, the RMSE of the daytime SST and nighttime SST data decreased by 32.52% and 42.04%, respectively. Full article

In August 2020, during the 80th cruise of the R/V “Akademik Mstislav Keldysh”, the chlorophyll a concentration (Chl-a) and spectral coefficients of light absorption by phytoplankton pigments, non-algal particles (NAP) and colored dissolved organic matter (CDOM) were measured in the Norwegian Sea, the Barents Sea and the adjacent area of the Arctic Ocean. It was shown that the spatial distribution of the three light-absorbing components in the explored Arctic region was non-homogenous. It was revealed that CDOM contributed largely to the total non-water light absorption (a_tot(λ) = a_ph(λ) + a_NAP(λ) + a_CDOM(λ)) in the blue spectral range in the Arctic Ocean and the Barents Sea. The fraction of NAP in the total non-water absorption was low (less than 20%). The depth of the euphotic zone depended on a_tot(λ) in the surface water layer, which was described by a power equation. The Arctic Ocean, the Norwegian Sea and the Barents Sea did not differ in the Chl-a-specific light absorption coefficients of phytoplankton. In the blue maximum of phytoplankton absorption spectra, Chl-a-specific light absorption coefficients of phytoplankton in the upper mixed layer (UML) were higher than those below the UML. Relationships between phytoplankton absorption coefficients and Chl-a were derived by least squares fitting to power functions for the whole visible domain with a 1 nm interval. The OCI, OC3 and GIOP algorithms were validated using a database of co-located results (day-to-day) of in situ measurements (n = 63) and the ocean color scanner data: the Moderate Resolution Imaging Spectroradiometer (MODIS) onboard the Terra (EOS AM) and Aqua (EOS PM) satellites, the Visible and Infrared Imager/Radiometer Suite (VIIRS) onboard the Suomi National Polar-orbiting Partnership (S-NPP) and JPSS-1 satellites (also known as NOAA-20), and the Ocean and the Land Color Imager (OLCI) onboard the Sentinel-3A and Sentinel-3B satellites. The comparison showed that despite the technological progress in optical scanners and the algorithms refinement, the considered standard products (chlor_a, chl_ocx, aph_443, adg_443) carried little information about inherent optical properties in Arctic waters. Based on the statistic metrics (Bias, MdAD, MAE and RMSE), it was concluded that refinement of the algorithm for retrieval of water bio-optical properties based on remote sensing data was required for the Arctic region. Full article

Here we present a machine-learning-based method for utilizing traditional ocean-viewing satellites to perform automated atmospheric correction of nanosatellite data. These sensor convolution techniques are required because nanosatellites do not usually possess the wavelength combinations required to atmospherically correct upwelling radiance data for oceanographic applications; however, nanosatellites do provide superior ground-viewing spatial resolution (~3 m). Coincident multispectral data from the Suomi National Polar-Orbiting Partnership Visible Infrared Imaging Radiometer Suite (Suomi NPP VIIRS; referred to herein as “VIIRS”) were used to remove atmospheric contamination at each of the nanosatellite’s visible wavelengths to yield an estimate of spectral water-leaving radiance [L_w(l)], which is the basis for surface ocean optical products. Machine learning (ML) algorithms (KNN, decision tree regressors) were applied to determine relationships between L_w and top-of-atmosphere (L_t)/Rayleigh (L_r) radiances within VIIRS training data, and then applied to test cases for (1) the Marine Optical Buoy (MOBY) in Hawaii and (2) the AErosol RObotic Network Ocean Color (AERONET-OC), Venice, Italy. For the test cases examined, ML-based methods appeared to improve statistical results when compared to alternative dark spectrum fitting (DSF) methods. The results suggest that ML-based sensor convolution techniques offer a viable path forward for the oceanographic application of nanosatellite data streams. Full article

The current operational multi-band atmospheric correction algorithms implemented by NASA and NOAA for global remote sensing of ocean color from VIIRS (Visible Infrared Imaging Radiometer Suite) data are mostly based on the 2-band version of the SeaWiFS (Sea-Viewing Wide Field-of-View Sensor) algorithm. These algorithms generally use two NIR bands, one centered near 0.75 μm and the other near 0.865 μm, and a band ratio method for deriving aerosol information. The algorithms work quite well over open ocean waters. However, water leaving reflectances over turbid coastal waters are frequently not derived. We describe here a spectrum-matching algorithm using shortwave IR (SWIR) bands above 1 μm for retrieving water leaving reflectances in the visible from VIIRS data. The SWIR bands centered near 1.24, 1.61, and 2.25 μm are used in a spectrum-matching process to obtain spectral aerosol information, which is subsequently extrapolated to the visible region for the derivation of water leaving reflectances of visible bands. We present retrieval results for four VIIRS scenes acquired over turbid waters. We demonstrate that the spatial coverages of our retrieving results can be improved significantly in comparison with those retrieved with the current NOAA operational algorithm. If our SWIR algorithm is implemented for operational data processing, the algorithm can potentially be complimentary to current NASA and NOAA VIIRS algorithms over turbid waters to increase spatial coverages. Full article

The Visible Infrared Imaging Radiometer Suite (VIIRS) instruments on-board the Suomi National Polar-orbiting Partnership (S-NPP) and Joint Polar Satellite System (JPSS) spacecrafts 1 and 2 provides calibrated sensor data record (SDR) reflectance, radiance, and brightness temperatures for use in environment data record (EDR) products. The SDRs and EDRs are used in weather forecasting models, weather imagery and climate applications such as ocean color, sea surface temperature and active fires. The VIIRS has 22 bands covering a spectral range 0.4–12.4 µm with resolutions of 375 m and 750 m for imaging and moderate bands respectively on four focal planes. The bands are stratified into three different types based on the source of energy sensed by the bands. The reflective solar bands (RSBs) detect sunlight reflected from the Earth, thermal emissive bands (TEBs) sense emitted energy from the Earth and the day/night band (DNB) detects both solar and lunar reflected energy from the Earth. The SDR calibration uses a combination of pre-launch testing and the solar diffuser (SD), on-board calibrator blackbody (OBCBB) and space view (SV) on-orbit calibrator sources. The pre-launch testing transfers the National Institute of Standards and Technology (NIST) traceable calibration to the SD, for the RSB, and the OBCBB, for the TEB. Post-launch, the on-board calibrators track the changes in instrument response and adjust the SDR product as necessary to maintain the calibration. This paper will discuss the pre-launch radiometric calibration portion of the SDR calibration for the RSBs that includes the dynamic range, detector noise, calibration coefficients and radiometric uncertainties for JPSS-2 VIIRS. Full article
