Search Results (16)

Direct methanol fuel cells (DMFCs) offer significant advantages including high energy density and rapid refueling, making them promising power sources for portable electronic products. However, their practical application, particularly in passive systems, is hindered by critical mass transport limitations: water flooding in the cathode and CO₂ bubble blockage in the anode. Herein, a novel dual-gradient patterned wettability current collector (CC) was designed to alleviate this mass transport impedance. The design uniquely integrates wedge-shaped gradients with surface energy gradients to create a unified, self-driven mechanism for efficient water and CO₂ bubble transport at both electrodes. A mathematical model was developed to quantitatively evaluate the effects of the dual-gradient structure. The results confirm that water removal is enhanced when the cathode current collector features a hydrophobic periphery with a dual-gradient patterned wettability interior on the gas-diffusion-layer side and a fully hydrophilic air-side surface, whereas an inverted pattern facilitates anode CO₂ removal. Optimal fabrication parameters on 316 L stainless steel were established by investigating laser scanning conditions and low-surface-energy agent concentrations. The experimental results show that the passive DMFCs incorporating the optimized current collectors delivered marked performance improvements. At 1 mol·L⁻¹ methanol, the novel anode and cathode current collectors increased peak power density by 15.6% and 14.5%, respectively. Electrochemical impedance spectroscopy revealed a 31.4% and 31.9% reduction in mass transfer resistance of the cell with novel anode and cathode current collectors, respectively, confirming improved gas–liquid self-driven efficiency. Furthermore, the new cells exhibited substantially enhanced long-term stability over 18 h of continuous discharge, attributed to the robust wettability achieved via laser–silane modification. Overall, these findings suggest that the proposed dual-gradient wettability design is a promising method for improving internal mass transport, potentially supporting the development of more robust passive DMFCs. Full article

This study employs hydrophobic modification of the current collector to optimize cathode water management and enhance the performance of passive DMFCs. The surface of the cathode current collector was hydrophobized by polytetrafluoroethylene (PTFE) coating and titanium dioxide/polydimethylsiloxane (PDMS) composite coating. The experimental results showed that the surface hydrophobic treatment significantly improved the cell performance at low methanol concentration and marginally improved the cell performance at high methanol concentration. Among them, the DMFC with bilayer TiO₂/PDMS hydrophobic-treated cathode current collector with a contact angle of 153.2° showed the best performance, which achieved superhydrophobicity and led to a peak power density that was 27.25% higher compared to the DMFC with an untreated current collector. With the gradient-based hydrophobic treatment for the cathode current collector, the best performance was achieved when double-layer TiO₂/PDMS was used on the MEA side and PTFE coating on the air side. Full article

With the global shift in energy structure and the advancement of the “double carbon” strategy, methanol has gained attention as a clean low-carbon fuel in the engine sector. However, the corrosion–wear coupling failure caused by acidic byproducts, such as methanoic acid and formaldehyde, generated during combustion severely limits the durability of methanol engines. In this study, we employed a systematic approach combining the construction of a corrosion liquid concentration gradient experiment with a full-load and full-speed bench test to elucidate the synergistic corrosion–wear mechanism of core friction pairs (cylinder liner, piston, and piston ring) in methanol-fueled engines. The experiment employed corrosion-resistant gray cast iron (CRGCI), high chromium cast iron (HCCI), and nodular cast iron (NCI) cylinder liners, along with F38MnVS steel and ZL109 aluminum alloy pistons. Piston rings with DLC, PVD, and CKS coatings were also tested. Corrosion kinetic analysis was conducted in a formaldehyde/methanoic acid gradient corrosion solution, with a concentration range of 0.5–2.5% for formaldehyde and 0.01–0.10% for methanoic acid, simulating the combustion products of methanol. The results showed that the corrosion depth of CRGCI was the lowest in low-concentration corrosion solutions, measuring 0.042 and 0.055 μm. The presence of microalloyed Cr/Sn/Cu within its pearlite matrix, along with the directional distribution of flake graphite, effectively inhibited the micro-cell effect. In high-concentration corrosion solutions (#3), HCCI reduced the corrosion depth by 60.7%, resulting in a measurement of 0.232 μm, attributed to the dynamic reconstruction of the Cr₂O₃-Fe₂O₃ composite passive film. Conversely, galvanic action between spherical graphite and the surrounding matrix caused significant corrosion in NCI, with a depth reaching 1.241 μm. The DLC piston coating obstructed the permeation pathway of formate ions due to its amorphous carbon structure. In corrosion solution #3, the recorded weight loss was 0.982 mg, which accounted for only 11.7% of the weight loss observed with the CKS piston coating. Following a 1500 h bench test, the combination of the HCCI cylinder liner and DLC-coated piston ring significantly reduced the wear depth. The average wear amounts at the top and bottom dead centers were 5.537 and 1.337 μm, respectively, representing a reduction of 67.7% compared with CRGCI, where the wear amounts were 17.152 and 4.244 μm. This research confirmed that the HCCI ferrite–Cr carbide matrix eliminated electrochemical heterogeneity, while the DLC piston coating inhibited abrasive wear. Together, these components reduced the wear amount at the top dead center on the push side by 80.1%. Furthermore, mismatches between the thermal expansion coefficients of the F38MnVS steel piston (12–14 × 10⁻⁶/°C) and gray cast iron (11 × 10⁻⁶/°C) resulted in a tolerance exceeding 0.105 mm in the cylinder fitting gap after 3500 h of testing. Notably, the combination of a HCCI matrix and DLC coating successfully maintained the gap within the required range of 50–95 μm. Full article

Direct methanol fuel cells (DMFCs) typically operate in passive mode, where methanol is distributed across the membrane electrode assembly through natural diffusion. Usual methanol concentrations range from 1% to 5% by weight (wt.%), although this can vary depending on the specific configuration and application. In this work, the effect of an additional pumping system to supply the methanol has been analyzed by varying the methanol flow rate within the pump’s range. To this end, a parametric experimental study was carried out to study the influence of temperature (25–40 °C), concentration (0.15–6 wt.% methanol in water), and the flow rate of methanol (1.12–8.65 g/s) on the performance of a single mini-direct methanol fuel cell (DMFC) operating in semi-passive mode with a passive cathode and an active anode. Open circuit voltage, maximum power density, and cell efficiency were analyzed. To this purpose, open circuit voltage and current–voltage curves were measured in different experimental conditions. Results indicate that temperature is the most decisive parameter to increase DMFC performance. For all methanol concentrations and flow rates, performance improves with higher operating temperatures. However, the impact of the concentration and flow rate depends on the other parameters. The operating optimal concentration was 1% wt. At this concentration, a maximum power of 14.2 mW was achieved at 40 °C with a methanol flow of 7.6 g/s. Under these same conditions, the cell also reached its maximum efficiency of 23%. The results show that switching from passive to semi-passive mode generally increases open-circuit voltage and maximum power, thus improving fuel cell performance, likely due to the enhanced uniform distribution of the reactant in semi-passive mode. However, further increases in flow rate led to a decrease in performance, probably due to the methanol crossover effect. An optimal methanol flow rate is observed, depending on methanol flow temperature and concentration. Full article

Mini passive direct methanol fuel cells (mpDMFCs) appear to be a promising alternative for powering portable devices, since they use a liquid fuel, have a fast refuelling time, have a high efficiency and have a low environmental impact. However, some issues need to be solved before their commercialization, such as methanol crossover, short lifetime and high costs. The present work studies the effect of reducing the anode and cathode catalyst loading on the performance of a mpDMFC towards a reduction in the system costs and the characterization of the system losses. The undesirable losses that affect the fuel cell performance were identified and quantified using the electrochemical impedance spectroscopy (EIS) technique. Accordingly, a novel equivalent electric circuit (EEC) was proposed, accurately reproducing the mini pDMFC. In this work, a maximum power density of 7.07 mW cm⁻² was obtained, with a methanol concentration of 5 M, using 2 mg cm⁻² Pt-RuB and 4 mg cm⁻² PtB. The mpDMFC allowed the cell to work with high methanol concentrations and reduced anode catalyst loadings. Full article

In this work, an anode current collector with a scaled step-hole structure (called SF-type) and a cathode current collector with a perforated cross-tilt structure (called X-type) were designed and fabricated for application in passive direct methanol fuel cells (DMFCs). A whole-cell test showed that the combination of an anode SF-type current collector and cathode conventional current collector increased the optimal methanol concentration from 6 M to 8 M and the maximum power density to 5.40 mW cm⁻², which improved the cell performance by 51.6% compared to that of the conventional design under ambient testing conditions. The combination of the anode conventional current collector and cathode X-type current collector achieved a maximum power density of 5.65 mW cm⁻² with a 58.7% performance improvement, while the optimal methanol concentration was increased to 10 M. Furthermore, the combination of anode SF-type and cathode X-type obtained the highest power density at 6.22 mW cm⁻². Notably, the anode and cathode catalyst loadings used in this study were 2.0 mg cm⁻², which is lower than the commonly used loading, thus reducing the fuel cell cost. Full article

Fuel cells have already demonstrated their potential for green energy generation. However, the low reaction performance becomes an obstacle in terms of large-scale commercial manufacturing. Accordingly, this work focuses on a new unique fabrication of three-dimensional pore hierarchy TiO₂-graphene aerogel (TiO₂-GA) supporting PtRu catalyst for anodic catalyst direct methanol fuel cell, which is facile, ecologically benign, and economical. In this work, a hydrothermal technique was used, followed by a freeze-drying technique and a microwave-assisted ethylene reduction technique. The structural properties of the studied materials were confirmed by UV/visible spectroscopy, XRD, Raman spectrum, FESEM TEM, and XPS. Based on existing structural advantages, the performance of PtRu/TiO₂-GA has been investigated on DMFC anode catalysts. Furthermore, electrocatalytic stability performance with the same loading (~20%) was compared to commercial PtRu/C. Experimental outcomes show that the TiO₂-GA support offered a significantly high surface area value of 68.44 m²g⁻¹, mass activity/specific activity (608.17 mAmg⁻¹/0.45 mA/cm²_PtRu) that is higher than commercial PtRu/C (79.11 mAmg⁻¹/0.19 mA/cm²_PtRu). In passive DMFC mode, PtRu/TiO₂-GA showed a maximum power density of 3.1 mW cm⁻², which is 2.6 times higher than that of the PtRu/C commercial electrocatalyst. This suggests that PtRu/TiO₂-GA has a promising possibility for methanol oxidation and may be used as an anodic element in DMFC. Full article

Direct methanol fuel cells (DMFCs) have attracted much attention due to their potential application as a power source for portable devices. Their simple construction and operation, associated with compact design, high energy density, and relatively high energy-conversion efficiency, give the DMFCs an advantage over other promising energy production technologies in terms of portability. Nowadays, research on DMFCs has received increased attention in both academics and industries. However, many challenges remain before these systems become commercial, including their costs and durability. As a key material with a high-value cost, noble metal catalysts for both the anode and cathode sides face several problems, which hinder the commercialisation of DMFCs. This paper provides a detailed comprehensive review of recent progress in the development of nanocatalysts (NCs) for the anode and cathode reactions of DMFCs, based on Platinum, Platinum-hybrid, and Platinum-free materials. Particular attention is devoted to the systematisation of published experimental results tested in DMFC devices since 2015, with an emphasis on passive DMFC systems. In addition, a dedicated section was created to include modelling/theoretical studies. Some open problems and remaining challenges are also highlighted in the final section. Full article

The effect of the Au coated printed circuit board (PCB) as a current collector on the performance of fuel cells is demonstrated. In this study, optimized pulse electroplating was introduced, which was found to be much more effective compared to the direct current (DC) plating for the PCB fabrication based on the passive area from the potentiodynamic polarization scan. Variable electrochemical parameters such as applied potential and frequency for the pulse electroplating method are controlled. Using the polarization tests, the corrosion behavior of the Au coated PCB layer was also observed. From these basic data, the coating methods and electrochemical parameters were systematically controlled to achieve efficient results for direct methanol fuel cells (DMFCs). The stability test for the cell operation indicates that the micro DMFC with the Au coated PCB substrate formed at a frequency of 10 Hz exhibited the highest stability and performance. As a result, the Au coated PCB substrate using pulse electroplating at 1.5 V and 1 kHz can be a promising current collector for portable DMFCs. Full article

A membrane electrode assembly (MEA) with a novel trilaminar-catalytic layered structure was designed and fabricated for a micro-direct methanol fuel cell (μ-DMFC). The trilaminar-catalytic layer comprises three porous layers. The medial layer has a lower porosity than the inner and outer layers. The simulation results predicted a lower water content and a higher oxygen concentration in the trilaminar-catalytic layer. The novel trilaminar-catalytic layer enhanced the back diffusion of water from the cathode to the anode, which reduces methanol crossover and improves oxygen mass transportation. The electrochemical results of the half-cell test indicate that the novel MEA has a greatly increased cathode polarization and a slightly increased anode polarization. Thus, this novel μ-DMFC structure has a higher power density and a longer discharging time, and hence may be used in portable systems. Full article

Passive direct methanol fuel cells (pDMFCs) are promising devices to replace the conventional batteries in portable electronic devices, due to their higher energy densities, autonomies, and instant recharging. However, some challenges, such as their costs, efficiency, and durability, need to be overcome before their commercialization. Towards that, this work presents the effect of the anode diffusion layer (ADL) properties on the performance of a pDMFC using a membrane electrode assembly (MEA) with reduced loadings on both anode and cathode catalysts (3 mg/cm² Pt/Ru on the anode and 1.3 mg/cm² of Pt on the cathode). The pDMFC behavior was evaluated through polarization and electrochemical impedance spectroscopy measurements, which allow identifying and quantifying the different losses that affect these systems. The results showed better performances when a diffusion layer with a dual-layer structure was used using higher methanol concentrations. The maximum power density achieved was 3.00 mW/cm², using carbon cloth with a microporous layer, CC_MPL, as ADL, and a methanol concentration of 5 M. In this work, a tailored and low-cost MEA, using the materials available in the market, was proposed to achieve higher performances working under higher methanol concentrations. This work demonstrates that performing modifications on the fuel cell structure/design is an efficient way to achieve optimized performances. Full article

Platinum (Pt) and ruthenium (Ru) were sputtered on an electrolyte membrane and it was used as a membrane-electrode assembly for passive direct methanol fuel cells (DMFCs) operating with high concentration methanol solution (4 M). Thick (Pt of 300 nm and Ru of 150 nm) and thin (Pt of 150 nm and Ru of 75 nm) sputtered catalysts were prepared and their performance was first evaluated to find out the best sputtering conditions showing higher performance. Subsequently, four electrolyte membranes with different surface roughness were prepared to investigate its influence on the performance. As a result, the performance of the passive DMFC showed increasing tendency as the roughness is low, while the performance was decreased as the roughness was high, indicating there exists an optimal roughness of the electrolyte membrane. It was further investigated through morphological study through electron microscopy that such performance variation is attributed to the surface of sputtered Pt–Ru catalyst on the rough electrolyte membrane that adequate roughness induces the increase of reactive area while a too rough surface bears the poor contact of it with gas-diffusion layer. Full article

Methanol crossover (MCO) significantly affects the performance of a direct methanol fuel cell (DMFC). In order to reduce its effect, this study presents in-house carbon nanofiber webs (CNWs) used as a porous methanol barrier for MCO control in a passive DMFC. The CNW is made from polyacrylonitrile (PAN) by using electrospinning and heat treatment. The impacts of PAN concentration and carbonizing temperature on the material properties are considered. The concentration of PAN has a great effect on the micro structures of the CNWs since a higher concentration of PAN leads to a larger nanofiber diameter and lower porosity. A higher carbonizing temperature helps promote the sample conductivity. The use of CNWs has twofold effects on the cell performance. It helps significantly enhance the cell performance, especially at a low methanol concentration due to its balanced effect on reactant and product management. There is an increase in peak power density of up to 53.54% when the CNW is used, in contrast with the conventional DMFC at 2 mol/L. The dynamic and constant-load performances of the fuel cell based on CNWs are also investigated in this work. Full article

A dual-chamber anode structure is proposed in order to solve two performance problems of the conventional passive micro direct methanol fuel cell (μ-DMFC). One of the problems is the unstable performance during long time discharge. The second problem is the short operating time. In this structure, low concentration chamber is filled with methanol solution with appropriate concentration for the μ-DMFC. Pure methanol in high concentration chamber diffuses to the low concentration chamber to keep the concentration of methanol solution suitable for long-term discharge of μ-DMFC. In this study, a Nafion-Polytetrafluoroethylene (PTFE) composite membrane is inserted between the two chambers to conduct pure methanol. The experimental results during long-term discharge show that the stable operating time of passive μ-DMFC increases by nearly 2.3 times compared to a conventional one with the same volume. These results could be applied to real products. Full article

The direct methanol fuel cell (DMFC) adopts methanol solution as a fuel suitable for low power portable applications. A miniature, lightweight, passive air-breathing design is therefore desired. This paper presents a novel planar disc-type DMFC with multiple cells containing a novel developed lightweight current collector at both the anode and cathode sides. The present lightweight current collector adopts FR4 Glass/Epoxy as the substrate with the current collecting areas located at the corresponding membrane electrolyte assembly (MEA) areas. The current collecting areas are fabricated by sequentially coating a corrosion resistant layer and electrical conduction layer via the thermal evaporation technique. The anode current collector has carved flow channels for fuel transport and production. The cathode current collector has drilled holes for passive air breathing. In order to ensure feasibility in the present concept a 3-cell prototype DMFC module with lightweight disc type current collectors is designed and constructed. Experiments were conducted to measure the cell performance. The results show that the highest cell power output is 54.88 mW·cm⁻² and successfully demonstrate the feasibility of this novel design. Full article
