Search Results (373)

Search Parameters:
Keywords = phonon scattering

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
18 pages, 3724 KB
Article
Stability and Thermophysical Property Enhancement of MoS2-Based Water Nanofluids Using Cationic CTAB and Anionic SLS Surfactants
by Sanae Bayou, Chaouki El Moujahid, Hammadi El Farissi, Claudia Roman, Oumaima Ettalibi and Tarik Chafik
ChemEngineering 2025, 9(6), 123; https://doi.org/10.3390/chemengineering9060123 - 6 Nov 2025
Viewed by 222
Abstract
In this study, molybdenum disulfide (MoS2)-based water nanofluids were prepared and stabilized using two surfactants with opposite charges: the cationic cetyltrimethylammonium bromide (CTAB) and the anionic sodium lauryl sulfate (SLS). Different MoS2:surfactant ratios (1:1, 1:2, and 1:3) were examined [...] Read more.
In this study, molybdenum disulfide (MoS2)-based water nanofluids were prepared and stabilized using two surfactants with opposite charges: the cationic cetyltrimethylammonium bromide (CTAB) and the anionic sodium lauryl sulfate (SLS). Different MoS2:surfactant ratios (1:1, 1:2, and 1:3) were examined to identify the optimal formulation ensuring stable dispersion. Stability was evaluated through dynamic light scattering (DLS), zeta potential, and UV–Vis spectroscopy analyses. The results showed that the MoS2:SLS (1:3) nanofluid achieved the highest stability, characterized by a zeta potential of −38 mV and a mean particle size of approximately 290 nm. Thermophysical properties were then investigated for nanoparticle concentrations of 0.05, 0.1, and 0.2 wt%. The 0.1 wt% nanofluid exhibited the best performance, showing a thermal conductivity enhancement of about 49% and an increased specific heat capacity compared with pure water. This improvement is attributed to uniform nanoparticle dispersion and enhanced phonon transport. Overall, the results demonstrate that the anionic SLS surfactant at a 1:3 ratio effectively enhances the stability as well as the thermal performance of MoS2–water nanofluids, making them promising candidates for thermal management and energy systems applications. Full article
(This article belongs to the Topic Advanced Materials in Chemical Engineering)
Show Figures

Figure 1

13 pages, 1853 KB
Article
Non-Destructive Evaluation of Damage and Electricity Characteristics in 4H-SiC Induced by Ion Irradiation via Raman Spectroscopy
by Hui Dai, Zhiyan Hou, Xinqing Han, Jiacheng Liang, Anxin Jiao, Zhixian Wei, Chen Wu, Ke Sun, Yong Liu and Xuelin Wang
Materials 2025, 18(21), 5057; https://doi.org/10.3390/ma18215057 - 6 Nov 2025
Viewed by 213
Abstract
To optimize the design of silicon carbide (SiC) devices for applications in space and nuclear environments, this work introduces varying degrees of lattice damage into SiC through controlled irradiation conditions, with Raman spectroscopy revealing its damage evolution behavior and quantitatively characterizing the increasing [...] Read more.
To optimize the design of silicon carbide (SiC) devices for applications in space and nuclear environments, this work introduces varying degrees of lattice damage into SiC through controlled irradiation conditions, with Raman spectroscopy revealing its damage evolution behavior and quantitatively characterizing the increasing trend of disorder with irradiation fluences. Fine analysis of the A1(LO) phonon mode demonstrates that proliferation of irradiation-induced acceptor centers and accumulation of scattering defects lead to significant attenuation of carrier concentration and mobility (cross-verified by Hall effect measurements), thereby causing degradation in electrical conductivity of SiC. Subsequent electrical testing confirms an orders-of-magnitude reduction in conductivity, establishing a quantitative correlation model with total disorder quantified by the DI/DS model. The non-destructive Raman technique enables simultaneous acquisition of material damage characteristics and quantitative electrical performance degradation, providing a predictive framework for the evolution of electrical behavior for SiC under irradiation damage, with significant implications for optimizing irradiation-hardened device designs. Full article
(This article belongs to the Section Advanced Materials Characterization)
Show Figures

Figure 1

16 pages, 2645 KB
Article
Enhanced Superconductivity near the Pressure-Tuned Quantum Critical Point of Charge-Density-Wave Order in Cu1-δTe (δ = 0.016)
by Kwang-Tak Kim, Yeahan Sur, Ingyu Choi, Zifan Wang, Sangjin Kim, Dilip Bhoi, Duck Young Kim and Kee Hoon Kim
Materials 2025, 18(21), 5042; https://doi.org/10.3390/ma18215042 - 5 Nov 2025
Viewed by 281
Abstract
We have investigated the evolution of CDW states and structural phases in a Cu-deficient Cu1-δTe (δ = 0.016) by employing high-pressure experiments and first-principles calculations. Raman scattering results reveal that the vulcanite structure at ambient pressure starts to change into the [...] Read more.
We have investigated the evolution of CDW states and structural phases in a Cu-deficient Cu1-δTe (δ = 0.016) by employing high-pressure experiments and first-principles calculations. Raman scattering results reveal that the vulcanite structure at ambient pressure starts to change into the Cu-deficient rickardite (r-CuTe) structure from 6.7 GPa, which then becomes fully stabilized above 8.3 GPa. Resistivity data show that TCDW1 (≈333 K) is systematically suppressed under high pressure, reaching zero at 5.9 GPa. In the pressure range of 5.2–8.2 GPa, a sharp resistivity drop due to superconductivity occurs at the onset temperature TC = ~2.0–3.2 K. The maximum TC = 3.2 K achieved at 5.6 GPa is clearly higher than that of CuTe (2.3 K), suggesting the importance of charge fluctuation in the vicinity of CDW suppression. At 7.5 GPa, another resistivity anomaly appears due to the emergence of a second CDW (CDW2) ordering at TCDW2 = ~176 K, which exhibits a gradual increase to ~203 K with pressure increase up to 11.3 GPa. First-principles calculations on the Cu-deficient Cu11Te12 with the r-CuTe structure show that including on-site Coulomb repulsion is essential for incurring an unstable phonon mode relevant for stabilizing the CDW2 order. These results point out the important role of charge fluctuation in optimizing the pressure-induced superconductivity and that of Coulomb interaction in creating the competing CDW order in the Cu-deficient CuTe system. Full article
(This article belongs to the Section Materials Physics)
Show Figures

Figure 1

13 pages, 1918 KB
Article
Low-Frequency Phonon Scattering in Wurtzite Cadmium Sulfide: An Off- and Near-Resonance Raman Spectroscopy Study
by Carlos Israel Medel Ruiz, Roger Chiu, Jesús Ricardo Sevilla Escoboza, Jesús Castañeda Contreras, Francisco Gerardo Peña Lecona and Jesús Muñoz Maciel
Solids 2025, 6(4), 61; https://doi.org/10.3390/solids6040061 - 4 Nov 2025
Viewed by 284
Abstract
Phonons, the quantized lattice vibrations, are fundamental for a wide range of phenomena in condensed matter systems. In particular, low-frequency phonons significantly influence electrical conductivity, thermal transport, and the optical properties of solid-state materials. Although there is considerable literature on cadmium sulfide (CdS) [...] Read more.
Phonons, the quantized lattice vibrations, are fundamental for a wide range of phenomena in condensed matter systems. In particular, low-frequency phonons significantly influence electrical conductivity, thermal transport, and the optical properties of solid-state materials. Although there is considerable literature on cadmium sulfide (CdS) phonons—studied, for example, using resonance Raman spectroscopy—up-to-date information on the low-frequency phonons of this important semiconductor is still lacking. In this study, Raman spectroscopy under off- and near-resonance conditions is employed to investigate the low-frequency phonon in wurtzite CdS single crystals. Under off-resonance conditions, the spectrum exhibits multiple low-intensity peaks, which were analyzed through curve fitting. In contrast, the near-resonance spectrum shows an intense, broad band that was deconvoluted into its constituent components, including an antiresonance feature that was mathematically modeled for the first time in CdS. The results demonstrate that Raman scattering intensity in both regimes provides valuable insights into the low-frequency phonon modes of CdS. These findings enhance our understanding of the material’s vibrational properties and may facilitate the development of more efficient CdS-based optoelectronic devices. Full article
Show Figures

Graphical abstract

14 pages, 2479 KB
Article
Comparison of Quantum Transition Characteristics of Group II–VI (ZnO), Group III–V (GaN) Compound Semiconductors, and Intrinsic (Si) Semiconductors in Response to Externally Applied Energy
by Herie Park and Su-Ho Lee
Materials 2025, 18(20), 4709; https://doi.org/10.3390/ma18204709 - 14 Oct 2025
Viewed by 451
Abstract
In this paper, we study the line-shape (LS), which indicates the amount of absorbed energy, and the line-width (LW), which indicates the scattering factor, according to the vibrational direction of the externally applied energy in the electron–phonon potential interaction system of representative semiconductor [...] Read more.
In this paper, we study the line-shape (LS), which indicates the amount of absorbed energy, and the line-width (LW), which indicates the scattering factor, according to the vibrational direction of the externally applied energy in the electron–phonon potential interaction system of representative semiconductor bonding types, group II–VI (ZnO) and group III–V (GaN) bonded compound semiconductors and pure group IV (Si) bonded semiconductors. One of the two systems receives the externally applied energy of right-handed circular polarization vibration, and the other receives the externally applied energy of left-handed circular polarization vibration. To analyze the quantum transport, we first employ quantum transport theory (QTR) for an electron system confined within a square-well potential, where the projected Liouville equation is addressed using the balanced-average projection method. In analyzing quantum transitions, phonon emission is linked to the transition line-width (LW), whereas phonon absorption is evaluated through the transition line-shape (LS), highlighting its sensitivity to temperature and magnetic field variations. As a result of analyzing the line-width (LW), which is a quantum scattering coefficient, and the line-shape (LS), which represents the absorbed power, the absorbed power and scattering coefficient were higher for the left circularly polarized vibration under the influence of the external magnetic field. In contrast, the right polarization produced smaller values. In addition, the scattering coefficient (LW) and the absorbed power according to the bonding type of the semiconductor were the largest in Si, a group IV bonded semiconductor, followed by group III–V (GaN) and group II–VI (ZnO) bonded semiconductors. Full article
(This article belongs to the Special Issue Feature Papers in Materials Physics (2nd Edition))
Show Figures

Figure 1

18 pages, 2751 KB
Article
Assessment of the Influence of Chemical Composition, Atomic Distribution, and Grain Boundaries on Heat Transfer in Refractory High-Entropy Alloys Hf–Nb–Ta–Zr Based on Atomistic Simulation
by Rita I. Babicheva, Arseny M. Kazakov and Elena A. Korznikova
Crystals 2025, 15(10), 880; https://doi.org/10.3390/cryst15100880 - 13 Oct 2025
Viewed by 337
Abstract
This work investigates the influence of chemical composition, grain boundary (GB) type, and atomic distribution on the thermal conductivity of Hf–Nb–Ta–Zr refractory high-entropy alloys (RHEAs) via atomistic simulations. Three compositions—equiatomic HfNbTaZr (M1), Hf10Nb40Ta10Zr40 (M2), and Hf [...] Read more.
This work investigates the influence of chemical composition, grain boundary (GB) type, and atomic distribution on the thermal conductivity of Hf–Nb–Ta–Zr refractory high-entropy alloys (RHEAs) via atomistic simulations. Three compositions—equiatomic HfNbTaZr (M1), Hf10Nb40Ta10Zr40 (M2), and Hf40Nb10Ta40Zr10 (M3)—were studied in single-crystalline and bicrystalline models containing Σ3 or Σ5 GBs. The effect of chemical short-range order (SRO) and GB segregation was probed by comparing results for non-relaxed structures with those obtained for corresponding materials relaxed using combined Monte Carlo/molecular dynamics (MC/MD) simulation. Material relaxation is accompanied by the formation of coherent nanoclusters (NbTa in M1, Nb or Zr in M2, Hf or Ta in M3) and Hf/Zr segregation to GBs. In single crystals, SRO reduces thermal conductivity by up to ~2.7% (e.g., from 3.66 to 3.56 W/m·K in M1), which is explained by the phonon scattering effect from matrix–cluster interfaces, densely distributed in the structures. In contrast, in certain bicrystals, the combined effects of GB healing and intragranular cluster coarsening lead to a 6.9% increase in thermal conductivity (from 4.59 to 4.93 W/m·K), despite the presence of high-energy Σ5 GBs. These results demonstrate that the interplay between SRO, GB segregation, and microstructural evolution governs phonon transport in RHEAs, revealing a counterintuitive pathway to enhance thermal conductivity through controlled atomic redistribution. Full article
(This article belongs to the Section Crystalline Metals and Alloys)
Show Figures

Figure 1

29 pages, 2358 KB
Review
Research Progress on the Preparation and Properties of Graphene–Copper Composites
by Wenjie Liu, Xingyu Zhao, Hongliang Li and Yi Ding
Metals 2025, 15(10), 1117; https://doi.org/10.3390/met15101117 - 8 Oct 2025
Viewed by 954
Abstract
The persistent conflict between strength and electrical conductivity in copper-based materials presents a fundamental limitation for next-generation high-performance applications. Graphene, with its unique two-dimensional architecture and exceptional intrinsic characteristics, has become a promising reinforcement phase for copper matrices. This comprehensive review synthesizes recent [...] Read more.
The persistent conflict between strength and electrical conductivity in copper-based materials presents a fundamental limitation for next-generation high-performance applications. Graphene, with its unique two-dimensional architecture and exceptional intrinsic characteristics, has become a promising reinforcement phase for copper matrices. This comprehensive review synthesizes recent advancements in graphene–copper composites (CGCs), focusing particularly on structural design innovations and scalable manufacturing approaches such as powder metallurgy, molecular-level mixing, electrochemical deposition, and chemical vapor deposition. The analysis examines pathways for optimizing key properties—including mechanical strength, thermal conduction, and electrical performance—while investigating the fundamental reinforcement mechanisms and charge/heat transport phenomena. Special consideration is given to how graphene morphology, concentration, structural quality, interfacial chemistry, and processing conditions collectively determine composite behavior. Significant emphasis is placed on interface engineering strategies, graphene alignment, consolidation control, and defect management to minimize electron and phonon scattering while improving stress transfer efficiency. The review concludes by proposing research directions to resolve the strength–conductivity paradox and broaden practical implementation domains, thereby offering both methodological frameworks and theoretical foundations to support the industrial adoption of high-performance CGCs. Full article
(This article belongs to the Special Issue Study on the Preparation and Properties of Metal Functional Materials)
Show Figures

Figure 1

23 pages, 5282 KB
Article
Bilayer TMDs for Future FETs: Carrier Dynamics and Device Implications
by Shoaib Mansoori, Edward Chen and Massimo Fischetti
Nanomaterials 2025, 15(19), 1526; https://doi.org/10.3390/nano15191526 - 5 Oct 2025
Viewed by 528
Abstract
Bilayer transition metal dichalcogenides (TMDs) are promising materials for next-generation field-effect transistors (FETs) due to their atomically thin structure and favorable transport properties. In this study, we employ density functional theory (DFT) to compute the electronic band structures and phonon dispersions of bilayer [...] Read more.
Bilayer transition metal dichalcogenides (TMDs) are promising materials for next-generation field-effect transistors (FETs) due to their atomically thin structure and favorable transport properties. In this study, we employ density functional theory (DFT) to compute the electronic band structures and phonon dispersions of bilayer WS2, WSe2, and MoS2, and the electron-phonon scattering rates using the EPW (electron-phonon Wannier) method. Carrier transport is then investigated within a semiclassical full-band Monte Carlo framework, explicitly including intrinsic electron-phonon scattering, dielectric screening, scattering with hybrid plasmon–phonon interface excitations (IPPs), and scattering with ionized impurities. Freestanding bilayers exhibit the highest mobilities, with hole mobilities reaching 2300 cm2/V·s in WS2 and 1300 cm2/V·s in WSe2. Using hBN as the top gate dielectric preserves or slightly enhances mobility, whereas HfO2 significantly reduces transport due to stronger IPP and remote phonon scattering. Device-level simulations of double-gate FETs indicate that series resistance strongly limits performance, with optimized WSe2 pFETs achieving ON currents of 820 A/m, and a 10% enhancement when hBN replaces HfO2. These results show the direct impact of first-principles electronic structure and scattering physics on device-level transport, underscoring the importance of material properties and the dielectric environment in bilayer TMDs. Full article
(This article belongs to the Special Issue First Principles Study of Two-Dimensional Materials)
Show Figures

Figure 1

13 pages, 3165 KB
Article
Thermal Conductivity of Suspended Graphene at High Temperature Based on Raman Spectroscopy
by Junyi Wang, Zhiyu Guo, Zhilong Shang and Fang Luo
Nanomaterials 2025, 15(19), 1520; https://doi.org/10.3390/nano15191520 - 5 Oct 2025
Viewed by 530
Abstract
With the development of technology, many fields have put forward higher requirements for the thermal conductivity of materials in high-temperature environments, for instance, in fields such as heat dissipation of electronic devices, high-temperature sensors, and thermal management. As a potential high-performance thermal management [...] Read more.
With the development of technology, many fields have put forward higher requirements for the thermal conductivity of materials in high-temperature environments, for instance, in fields such as heat dissipation of electronic devices, high-temperature sensors, and thermal management. As a potential high-performance thermal management material, studying the thermal conductivity of graphene at high temperatures is of great significance for expanding its application range. In this study, high-quality suspended graphene was prepared through PDMS dry transfer, which can effectively avoid the binding and influence of the substrate. Based on the calculation model of the thermal conductivity of suspended graphene, the model was modified accordingly by measuring the attenuation coefficient of laser power. Combined with the temperature variation coefficient of suspended graphene measured experimentally and the influence of laser power on the Raman characteristic peak positions of graphene, the thermal conductance of suspended graphene with different layers under high-temperature conditions was calculated. It is conducive to a further in-depth understanding of the phonon scattering mechanism and heat conduction process of graphene at high temperatures. Full article
(This article belongs to the Section 2D and Carbon Nanomaterials)
Show Figures

Figure 1

13 pages, 2571 KB
Article
Operando NRVS on LiFePO4 Battery with 57Fe Phonon DOS
by Alexey Rulev, Nobumoto Nagasawa, Haobo Li, Hongxin Wang, Stephen P. Cramer, Qianli Chen, Yoshitaka Yoda and Artur Braun
Crystals 2025, 15(10), 841; https://doi.org/10.3390/cryst15100841 - 27 Sep 2025
Viewed by 640
Abstract
The vibration properties of materials play a role in their conduction of electric charges. Ionic conductors such as electrodes and solid electrolytes are also relevant in this respect. The vibration properties are typically assessed with infrared and Raman spectroscopy, and inelastic neutron scattering, [...] Read more.
The vibration properties of materials play a role in their conduction of electric charges. Ionic conductors such as electrodes and solid electrolytes are also relevant in this respect. The vibration properties are typically assessed with infrared and Raman spectroscopy, and inelastic neutron scattering, which all allow for the derivation of the phonon density of states (PDOS) in part of a full portion of the Brioullin zone. Nuclear resonant vibration spectroscopy (NRVS) is a novel method that produces the element-specific PDOS from Mössbauer-active isotopes in a compound. We employed NRVS operando on a pouch cell battery containing a Li57FePO4 electrode, and thus could derive the PDOS of the 57Fe in the electrode during charging and discharging. The spectra reveal reversible vibrational changes associated with the two-phase conversion between LiFePO4 and FePO4, as well as signatures of metastable intermediate states. We demonstrate how the NRVS data can be used to tune the atomistic simulations to accurately reconstruct the full vibration structures of the battery materials in operando conditions. Unlike optical techniques, NRVS provides bulk-sensitive, element-specific access to the full phonon spectrum under realistic operando conditions. These results establish NRVS as a powerful method to probe lattice dynamics in working batteries and to advance the understanding of ion transport and phase transformation mechanisms in electrode materials. Full article
(This article belongs to the Section Materials for Energy Applications)
Show Figures

Figure 1

18 pages, 18416 KB
Article
Radiation-Induced Degradation Mechanisms in Silicon MEMS Under Coupled Thermal and Mechanical Fields
by Xian Guo, Deshou Yang, Jibiao Qiao, Hui Zhang, Tong Ye and Ning Wei
Processes 2025, 13(9), 2902; https://doi.org/10.3390/pr13092902 - 11 Sep 2025
Viewed by 3344
Abstract
Silicon-based MEMS devices are essential in extreme radiation environments but suffer progressive reliability degradation from irradiation-induced defects. Here, the generation, aggregation, and clustering of defects in single-crystal silicon were systematically investigated through molecular dynamics (MD) simulations via employing a hybrid Tersoff–ZBL potential that [...] Read more.
Silicon-based MEMS devices are essential in extreme radiation environments but suffer progressive reliability degradation from irradiation-induced defects. Here, the generation, aggregation, and clustering of defects in single-crystal silicon were systematically investigated through molecular dynamics (MD) simulations via employing a hybrid Tersoff–ZBL potential that was validated by nanoindentation and transmission electron microscopy. The influences of the primary knock-on atom energy, temperature, and pre-strain state on defect evolution were quantified in detail. Frenkel defects were found to cause a linear reduction in the Young’s modulus and a nonlinear decline in thermal conductivity via enhanced phonon scattering. To link atomic-scale damage with device-level performance, MD-predicted modulus degradation was incorporated into finite element (FE) models of a sensing diaphragm. The FE analysis revealed that modulus reductions result in nonlinear increases in deflection and stress concentration, potentially impairing sensing accuracy. This integrated MD–FE framework establishes a robust, physics-based approach for predicting and mitigating irradiation damage in silicon-based MEMS operating in extreme environments. Full article
(This article belongs to the Section Chemical Processes and Systems)
Show Figures

Figure 1

13 pages, 4343 KB
Article
Impact of Four-Phonon Scattering on Thermal Transport and Thermoelectric Performance of Penta-XP2 (X = Pd, Pt) Monolayers
by Yangshun Lan, Yueyu Zhang, Honggang Zhang, Ping Wang, Ning Wang, Yangjun Yan, Xiaoting Zha, Changchun Ding, Yuzhi Li, Chuanfu Li, Yunjun Gu and Qifeng Chen
Nanomaterials 2025, 15(18), 1396; https://doi.org/10.3390/nano15181396 - 11 Sep 2025
Viewed by 525
Abstract
Accurately understanding and modulating thermal and thermoelectric transport in penta-XP2 (X = Pd, Pt) monolayers is crucial for their applications in nanoelectronics and energy conversion. We systematically investigate the thermal conductivity and thermoelectric properties of penta-XP2 monolayers through first-principles calculations, incorporating [...] Read more.
Accurately understanding and modulating thermal and thermoelectric transport in penta-XP2 (X = Pd, Pt) monolayers is crucial for their applications in nanoelectronics and energy conversion. We systematically investigate the thermal conductivity and thermoelectric properties of penta-XP2 monolayers through first-principles calculations, incorporating four-phonon (4ph) scattering and electron–phonon interaction (EPI) effects. The 4ph scattering, particularly Umklapp and redistribution processes, markedly suppresses lattice thermal conductivity by generating substantial thermal resistance and disrupting phonon population distributions. At 300 K, the lattice thermal conductivity is reduced to 0.87 W/mK (80% reduction) for penta-PdP2 and 1.64 W/mK (79% reduction) for penta-PtP2 compared to three-phonon-only scattering. Combining this with EPI-optimized electronic transport yields enhanced thermoelectric figures of merit (ZT), increasing from 0.21 to 0.86 for penta-PdP2 and from 0.11 to 0.34 for penta-PtP2, alongside a broadened optimal carrier concentration range. These findings highlight momentum-conserving 4ph scattering as a key mechanism for phonon transport modulation and thermoelectric efficiency improvement in penta-XP2 materials, providing theoretical guidance for designing high-performance nanoscale thermal management and energy conversion devices. Full article
Show Figures

Figure 1

18 pages, 1627 KB
Article
First-Principles Study of Strain Engineering Regulation of SnSe Thermoelectric Properties
by Haoru Zhang, Songqing Zhao, Yuhong Xia, Xinyue Zhang, Lulu Zhou and Zhenqing Yang
Materials 2025, 18(17), 4219; https://doi.org/10.3390/ma18174219 - 8 Sep 2025
Viewed by 880
Abstract
To study the effect of strain engineering on the thermoelectric properties of SnSe, we combined first-principles calculation and Boltzmann transport theory to study the effect of −4% to 4% strain on SnSe thermoelectric properties. Compressive strain enhances the maximum power factor (PF [...] Read more.
To study the effect of strain engineering on the thermoelectric properties of SnSe, we combined first-principles calculation and Boltzmann transport theory to study the effect of −4% to 4% strain on SnSe thermoelectric properties. Compressive strain enhances the maximum power factor (PFmax) of p-type SnSe from 2.3 to 4.3 mW·m−1·K−2. Specifically, under a −3% compressive strain, the thermoelectric figure of merit (ZT) experiences a 50% enhancement, increasing from 0.18 to 0.27. Conversely, for n-type, tensile strain leads to a 26% rise in the PFₘₐₓ, from 53.6 to 67.6 mW·m−1·K−2. Notably, the 4% tensile strain increased the ZT value of n-type SnSe by 123% from 0.66 to 1.47. Importantly, tensile strain effectively reduces lattice thermal conductivity through enhanced phonon scattering, synergistically improving ZT with the enhanced power factor. The results show that strain can effectively improve the thermoelectric properties of SnSe, and that n-type SnSe has great potential in thermoelectric materials. Full article
(This article belongs to the Section Materials Simulation and Design)
Show Figures

Graphical abstract

19 pages, 2810 KB
Article
Bismuth-Doped Indium Oxide as a Promising Thermoelectric Material
by Haitao Zhang, Bo Feng, Tongqiang Xiong, Wenzheng Li, Tong Tang, Ruolin Ruan, Peng Jin, Guopeng Zhou, Yang Zhang, Kewei Wang, Yin Zhong, Yonghong Chen and Xiaoqiong Zuo
Inorganics 2025, 13(9), 277; https://doi.org/10.3390/inorganics13090277 - 22 Aug 2025
Viewed by 693
Abstract
Bismuth (Bi)-doped indium oxide (In2O3) has emerged as a promising thermoelectric material due to its tunable electrical and thermal properties. This study investigates the effects of Bi-doping on the thermoelectric performance of In2O3, focusing on [...] Read more.
Bismuth (Bi)-doped indium oxide (In2O3) has emerged as a promising thermoelectric material due to its tunable electrical and thermal properties. This study investigates the effects of Bi-doping on the thermoelectric performance of In2O3, focusing on its electrical conductivity, band structure, carrier concentration, mobility, Seebeck coefficient, power factor, thermal conductivity, and overall thermoelectric figure of merit (ZT). The incorporation of Bi into the In2O3 lattice significantly enhances the material’s electrical conductivity, attributed to the increased carrier concentration resulting from Bi acting as an effective dopant. However, this doping also leads to a broadening of the bandgap, which influences the electronic transport properties. The Seebeck coefficient (absolute value) is observed to decrease with Bi-doping, a consequence of the elevated carrier concentration. Despite this reduction, the overall power factor improves due to the substantial increase in electrical conductivity. Furthermore, Bi-doping effectively reduces both the total thermal conductivity and the lattice thermal conductivity of In2O3. This reduction is primarily due to enhanced phonon scattering caused by the introduction of Bi atoms, which disrupt the lattice periodicity and introduce point defects. The combined improvement in electrical conductivity and reduction in thermal conductivity results in a significant enhancement of the thermoelectric figure of merit (ZT) with highest ZT value increased from 0.055 to 0.402 at 973 K. The optimized Bi-doped In2O3 samples demonstrate a ZT value that surpasses that of undoped In2O3, highlighting the potential of Bi-doping for advancing thermoelectric applications. This work provides a comprehensive understanding of the underlying mechanisms governing the thermoelectric properties of Bi-doped In2O3 and offers valuable insights into the design of high-performance thermoelectric materials for energy conversion technologies. Full article
(This article belongs to the Special Issue Advances in Thermoelectric Materials, 2nd Edition)
Show Figures

Figure 1

12 pages, 2376 KB
Article
Investigating Helium-Induced Thermal Conductivity Degradation in Fusion-Relevant Copper: A Molecular Dynamics Approach
by Xu Yu, Hanlong Wang and Hai Huang
Materials 2025, 18(15), 3702; https://doi.org/10.3390/ma18153702 - 6 Aug 2025
Viewed by 596
Abstract
Copper alloys are critical heat sink materials for fusion reactor divertors due to their high thermal conductivity (TC) and strength, yet their performance under extreme particle bombardment and heat fluxes in future tokamaks requires enhancement. While neutron-induced transmutation helium affects the properties of [...] Read more.
Copper alloys are critical heat sink materials for fusion reactor divertors due to their high thermal conductivity (TC) and strength, yet their performance under extreme particle bombardment and heat fluxes in future tokamaks requires enhancement. While neutron-induced transmutation helium affects the properties of copper, the atomistic mechanisms linking helium bubble size to thermal transport remain unclear. This study employs non-equilibrium molecular dynamics (NEMD) simulations to isolate the effect of bubble diameter (10, 20, 30, 40 Å) on TC in copper, maintaining a constant He-to-vacancy ratio of 2.5. Results demonstrate that larger bubbles significantly impair TC. This reduction correlates with increased Kapitza thermal resistance and pronounced lattice distortion from outward helium diffusion, intensifying phonon scattering. Phonon density of states (PDOS) analysis reveals diminished low-frequency peaks and an elevated high-frequency peak for bubbles >30 Å, confirming phonon confinement and localized vibrational modes. The PDOS overlap factor decreases with bubble size, directly linking microstructural evolution to thermal resistance. These findings elucidate the size-dependent mechanisms of helium bubble impacts on thermal transport in copper divertor materials. Full article
(This article belongs to the Special Issue Advances in Computation and Modeling of Materials Mechanics)
Show Figures

Figure 1
