Search Results (42)

This review paper deals with Triply Periodic Minimal Surfaces (TPMS) and lattice structures as a new generation of heat exchangers. Especially, their manufacturing is becoming feasible with technological progress. While some intricate structures are fabricated, challenges persist concerning manufacturing limitations, cost-effectiveness, and performance under transient operating conditions. Studies reported that these complex geometries, such as diamond, gyroid, and hexagonal lattices, outperform traditional finned and porous materials in thermal management, particularly under forced and turbulent convection regimes. However, TPMS necessitates the optimization of geometric parameters such as cell size, porosity, and topology stretching. The complex geometries enhance uniform heat exchange and reduce thermal boundary layers. Moreover, the integration of high thermal conductivity materials (e.g., aluminum and silver) and advanced coolants (including nanofluids and ethylene glycol mixtures) further improves performance. However, the drawback of complex geometries, confirmed by both numerical and experimental investigations, is the critical trade-off between heat transfer performance and pressure drop. The potential of TPMS-based heatsinks transpires as a trend for next-generation thermal management systems, besides identifying key directions for future research, including design optimization, Multiphysics modeling, and practical implementation. Full article

This study numerically and experimentally investigated the maximum heat transfer rate of the evaporator in loop heat pipes (LHPs) using a pore network simulation that considers the vapor–liquid interface within the evaporator wick under high heat flux conditions. The numerical model was validated with previous results. Based on the validated model, the boundary conditions were modified to consider high heat flux conditions. Also, a porous medium approach was applied to predict the working fluid flow in multiscale wicks, which were fabricated by sintering micro-sized SAC305 particles onto conventional screen mesh wicks. The effective pore radius and permeability of multiscale wicks were experimentally measured using the rate-of-rise method. Using the modified numerical model and experimental results, a parametric study was conducted on sintered weight fraction (SWF), fin ratio, and wick thickness to evaluate their effects on the maximum heat transfer rate of the LHP evaporator. As a result, the maximum heat transfer rate increased with higher SWF and thicker wicks due to improved capillary performance and greater vapor growth space, while a higher fin ratio reduced the maximum heat transfer rate by decreasing the vapor groove area. Under optimal conditions, a maximum heat flux of 800 W/cm² was achieved. Full article

This study compares the heat transfer and pressure drop of three cell structures, namely Kelvin cells (KCs), ellipsoidal Kelvin cells (EKCs), and body-centered cubic (BCC) structures, at the cell scale in order to identify the superior configuration. Then, we conducted numerical simulations on the heat exchangers based on porous media, and evaluate their comprehensive performance. It is shown that KCs have a superior heat transfer. Their volumetric heat transfer coefficient (h_V) is more than 50% higher than that of EKCs and more than 100% higher than that of BCC structures. EKCs exhibit a lower pressure drop. In the heat exchanger performance optimization study, the Kelvin structure demonstrated significant heat transfer characteristics. Simulation data show that the heat transfer performance at the hot end of the Kelvin heat exchanger (KCHE) is enhanced by more than 40% compared to the conventional plate-fin structure (FHE), but its flow channel pressure drop characteristics show a significant nonlinear increase. It is noteworthy that the improved Kelvin heat exchanger (EKCHE), optimized by introducing elliptic cell topology, maintains heat transfer while keeping the pressure loss increase within 1.22 times that of the conventional structure. The evaluation of the heat transfer and pressure drop characteristics is consistent for both scales. In addition, the EKC configuration exhibits a superior overall heat transfer capacity. To summarize, this work proposes a systematic numerical framework encompassing cell unit screening through heat exchanger design, offering valuable guidance for the structured development and analysis of porous media heat exchangers in relevant engineering domains. Full article

Fins are extended surfaces designed to increase heat dissipation from hot sources to their surroundings. Heat transfer is improved by utilising fins of different geometrical shapes. Fins are extensively used in automobile parts, solar panels, electrical equipment, computer CPUs, refrigeration systems, and superheaters. Motivated by these applications, this study investigates the incorporation of magnetic fields and porosity into a convective–radiative triangular fin to enhance heat transfer performance. The shooting technique is applied to study thermal profile and efficiency of the fin. It is found that the magnetic number (Hartmann number), porosity, convective, and radiative parameters reduce the thermal profile, while the Peclet number and ambient temperature increase it. Moreover, the efficiency increases with an increase in the magnetic number, porosity, convective, and radiative parameters, whereas it declines with an increase in the Peclet number and ambient temperature. Increasing the magnetic number from $0.1$ to $0.7$ leads to a $4\%$ reduction in the temperature profile. Similarly, raising the porosity parameter within the same range results in an approximate $3\%$ decrease in the thermal profile. An increase in the convective parameter from $0.1$ to $0.7$ causes about an $8\%$ decline in the thermal profile, while an elevation in the radiative parameter within the same range reduces it by approximately $2\%$. In contrast, enhancing the Peclet number from $0.1$ to $0.7$ increases the thermal profile by nearly $2\%$, and a rise in the ambient temperature within this range leads to an approximate $4\%$ enhancement in the thermal profile. Magnetised triangular fins are observed to have higher thermal transfer ability and efficiency than non-magnetised triangular fins. It is found that the incorporation of a magnetic field into a triangular fin, in conjunction with the porosity, improves the performance and efficiency of the triangular fin. Full article

In this work, a novel type of shell and helically coiled heat exchangers (SHCHEXs) that are used extensively in numerous applications has been numerically and experimentally studied. A low-cost and easily applicable design for enhancing the heat exchange rate in a shell and helically coiled heat exchanger has been developed within the scope of this study. In this context, a SHCHEX has been developed with an internal guiding pipe and spirally formed fins with the purpose of leading the fluid in the cold loop over the coil where hot fluid flows inside it. Numerical simulations were carried out in this study for determining how the new changes including nonporous and porous spiral fins affected heat transfer in the system. In the experimental part of the current research, a heat exchanger with a guiding pipe and nonporous spiral fins has been fabricated and its thermal behavior tested at various conditions utilizing water and MnFe₂O₄-ZnFe₂O₄/water hybrid-type nanofluid. Both numerical and experimental findings of this research exhibited positive effects of using new modifications including spiral fin integration. Overall findings of this work clearly exhibited a significant effect of the spiral fin medication and MnFe₂O₄-ZnFe₂O₄/water-hybrid magnetic nanofluid utilization on the thermal performance improvement in the heat exchanger. Experimentally determined findings showed that using MnFe₂O₄-ZnFe₂O₄/water in the hot loop of the SHCHEX improved the heat transfer coefficient of the heat exchanger by an average ratio of 16.2%. In addition, mean variation between the experimentally obtained exit temperature and numerically achieved one was 3.9%. Full article

Vibrational double diffusion has gained increasing attention in recent studies due to its role in enhancing mixing, disrupting thermal boundary layers, and stabilizing convection structures, especially in nanofluids and porous media. This study focuses on the case of two-phase nanofluid flow in the presence of vibrational effects. The flow domain is a fined chamber that is filled with a non-Darcy porous medium. Two concentration formulations are proposed for the species concentration and nanoparticle concentration. The thermal radiation is in both the x- and y-directions, while the flow domain is considered to be inclined. The solution technique depends on an effective finite volume method. The periodic behaviors of the stream function, Nusselt numbers, and Sherwood numbers against the progressing time are presented and interpreted. From the major results, a significant reduction in harmonic behaviors of the stream function is obtained as the lengths of the fins are raised while the gradients of the temperature and concentration are improved. Also, a higher rate of heat and mass transfer is obtained when the vibration frequency is raised. Furthermore, for fixed values of the Rayleigh number and vibration frequency (Ra = 10⁴, σ = 500), the heat transfer coefficient improves by 27.2% as the fin length increases from 0.1 to 0.25. Full article

The enhancement of the thermal and thermo-hydraulic performance of a semi-circular solar air collector (SCSAC) is numerically investigated using porous semi-circular obstacles made of metal foam with and without longitudinal porous Y-shaped fins. Two 10 and 40 PPI porous material samples are examined. Three-dimensional models are built to simulate the performance of SCSAC: model (I) with clear air passage; model (II) with only metal foam obstacles, and model (III) with metal foam obstacles as well as porous Y-fins. COMSOL Multiphysics software version 6.2 based on finite element methodology is employed. A conjugate heat transfer with a (k-ε) turbulence model is selected to simulate both heat transfer and fluid flow across the entire computational domain. However, only the local thermal non-equilibrium (LTNE) model of heat transfer is applied in the porous regions. The findings demonstrated that adding metal foam as the novel proposed configuration particularity of model (III) may enhance the thermal efficiency by about 30%, and the outlet air temperature may rise to 7% compared to other models. Also, the performance evaluation factor of this model is greater than one in all cases. Additionally, the thermal enhancement is accomplished by occupying only 5% of the air passage volume, thereby including an associated pressure drop of minimal magnitude. Full article

The performance of electrodes is the most critical factor determining the output characteristics of high-temperature proton exchange membrane fuel cells (HT-PEMFCs), and the electrode structure directly determines the strength of mass transfer and electrochemical reactions. Therefore, exploring the mechanism of increasing the specific surface area of electrodes is crucial for the design of electrode structures. In this paper, the electrochemical characteristics and mass transport of an HT-PEMFC are investigated based on a three-dimensional single-channel model, and a mathematical model of the fin structure on the electrode surface is established to make comparisons with calculations. The results indicate that the oxygen mole concentration decreases with an increase in fin density. Meanwhile, the fuel cell reaches optimal performance at a low operating voltage and in high fin density conditions. In addition, the output performance of the PEMFC increases with the aspect ratio. Finally, the potential distribution of the simulation results coincides with the theoretical model, and the mechanism of electrode polarization on the performance of fin geometry can significantly support the interpretation of kinetic characteristics obtained from simulations. The research result contributes to the efficient design and preparation of future electrode structures of HT-PEMFCs. Full article

The triply periodic minimal surface (TPMS) is receiving much interest among researchers. The advantage of using this TPMS structure is the ability to design a structure based on engineering need. In the present context, experimental measurement was conducted and compared with numerical models using a foam porous medium and TPMS porous structure, leading to an accurate calibration of the model. A porous medium, metal foam, was heated experimentally at the bottom, and forced convection was investigated for different heating conditions. Then, the porous foam was replaced with a TPMS, and the experiment was repeated under similar conditions. The experimental data were compared with the numerical model using COMSOL software. Besides the model’s accuracy, the TPMS showed a uniform heating condition contrary to the metal foam case. At a later stage, the numerical model was used to investigate the importance of flow direction (two flow directions) in cooling hot surfaces. The first flow was parallel to the hot surface, and the second perpendicular to the hot surface. The TPMS structure was located on the top of the hot surface and acted as a fin in both cases. The Nusselt number exceeded 80 in the presence of the TPMS. As the porosity of the TPMS decreases below 0.7, a more considerable pressure drop is observed. The performance evaluation criterion was found to be greater than 70 when the porosity of the TPMS structure was 0.8. Full article

Thermal effects of adsorption and desorption, leading to temperature fluctuations and losses of adsorption storage systems capacity in the processes of gas charging and discharging, are the main obstacle to the wide practical application of adsorbed natural gas (ANG) technology. This work presents a numerical simulation of heat and mass transfer processes under various cyclic operation modes of a full-scale adsorption storage tank with various thermal control systems. The high-density monolithic adsorbent KS-HAM, obtained on the basis of industrial activated carbon KS-HA, was used as the adsorption material. The phase composition, surface morphology, and porous structure of the sorbents were studied. The adsorption of methane on the KS-HA adsorbent was measured. It is shown that increasing the duration of charging leads to obtaining additional capacity of the ANG system; however, the final efficiency and benefit at the end of the charging–discharging cycle are determined by the efficiency of the thermal control system and the gas-discharging mode. It has been shown that the presence of a finned thermal control system allows for charging the adsorption storage tank 3–8 times faster and provides an 8–24% greater amount of gas discharged at the discharging stage compared to the ANG system without fins. Full article

Solar collectors represent an attractive green technology for water heating, where sunlight is efficiently absorbed by a selective coating and the generated heat is transferred to water. In this work, the improvement and scale-up of an electrodeposited black nickel selective coating with a modified silica (MS) film deposited by spray pyrolysis are reported. The MS material was prepared by the sol–gel method using tetraethyl orthosilicate with the addition of n-propyl triethoxysilane to obtain a porous film with an adequate refractive index and enhanced flexibility. The reflectance of electrodeposited selective coatings was characterized with and without the MS film and compared to a commercially available coating of black paint. The MS film increased the solar absorptance from 89% to 93% while maintaining a much lower thermal emittance than the painted coating. The reflectance of the MS film remained unchanged after prolonged thermal treatment at 200 °C (200 h). The fabrication process was scaled up to 193 cm × 12 cm copper fins, which were incorporated in commercial-size flat-plate solar collectors. Three complete collectors of an area of 1.7 m² were fabricated and their performance was evaluated under outdoor conditions. The results show that the electrodeposited selective coating with the MS film outperformed both the commercial black paint system and the system without the modified silica film. Full article

A comprehensive 3D Multiphysics model was developed to simulate a plate fin heat exchanger designed for hydrogen liquefaction, incorporating an ortho-para hydrogen conversion catalyst in the hot fin channel. The model encompassed the 3D serrate fin structure, turbulent flow within the cold fin channel, and porous flow through the catalytic hot fin channel. Species transportation within the hot fin channel is coupled with ortho-para hydrogen conversion kinetics, while heat transfer mechanisms between the hot and cold fin channels are rigorously accounted for. Additionally, the state-of-the-art equation of state is employed to accurately describe the thermodynamic properties of ortho- and para-hydrogen within the model. Numerous operational parameters, including the gas hourly space velocity, cold gas velocity, ortho-para hydrogen conversion kinetics, and operating pressure, were systematically varied to identify the kinetic and heat transfer constraints during the heat exchanger operation. The findings revealed that the ortho-para hydrogen conversion kinetic parameter predominantly governs operations requiring high gas hourly space velocity, particularly in large-scale hydrogen liquefaction processes. Furthermore, a significant pressure drop within the catalytic filled channel was observed; however, operating at higher pressure mitigates this issue while mildly enhancing ortho-para hydrogen conversion kinetics. Full article

The utilization of phase change materials (PCMs) in solar water heating systems (SWHS) has undergone notable advancements, driven by a rising demand for systems delivering superior performance and efficiency. Extensive research suggests that enhancing heat transfer (HTE) in storage systems is crucial for achieving these improvements. This review employs a bibliometric analysis to track the evolution of HTE methods within this field. While current literature underscores the necessity for further exploration into hot water generation applications, several methodologies exhibit significant promise. Particularly, strategies such as fins, encapsulation, and porous media emerge as prominent HTE techniques, alongside nanofluids, which hold the potential for augmenting solar water heating systems. This review also identifies numerous unexplored techniques awaiting investigation, aiming to pave new paths in research and application within the field of hot water generation. It highlights methods that could be used independently or alongside predominantly used techniques. Full article

The porous-medium approximation (PM) approach is extensively employed in large-quantity grid simulations of heat exchangers, providing a time-saving approach in engineering applications. To further investigate the influence of different geometries on the implementation of the PM approach, we reviewed existing experimental conditions and performed numerical simulations on both straight fins and serrated fins. Equivalent flow and heat-transfer factors were obtained from the actual model, and computational errors in flow and heat transfer were compared between the actual model and its PM model counterpart. This exploration involved parameters such as aspect ratio (a*), specific surface area (A_sf), and porosity (γ) to evaluate the influence of various geometric structures on the PM approach. Whether in laminar or turbulent-flow regimes, when the aspect ratio a* of straight fins is 0.98, the flow error (${\delta }_f$) utilizing the PM approach exceeds 45%, while the error remains within 5% when a* is 0.05. Similarly, for serrated fins, the flow error peaks (${\delta }_f$ > 25%) at higher aspect ratios (a* = 0.61) with the PM method and reaches a minimum (${\delta }_f$ < 5%) at lower aspect ratios (a* = 0.19). Under the same Reynolds numbers (Re), employing the PM approach results in an increased heat-transfer error (${\delta }_h$)with rising porosity (γ) and decreasing specific surface area (A_sf), both of which remained under 10% within the range of this study. At lower aspect ratios (a*), the fin structure becomes more compact, resulting in a larger specific surface area (A_sf) and smaller porosity (γ). This promotes more uniform flow and heat transfer within the model, which is closer to the characteristics of PM. In summary, for straight fins at 0 < a* < 0.17 in the laminar regime (200 < Re < 1000) and in the turbulent regime (1200 < Re < 5000) and for serrated fins at 0 < a* < 0.28 in the laminar regime (400 < Re < 1000) or 0 < a* < 0.32, in the turbulent regime (2000 < Re < 5000), the flow and heat-transfer errors are less than 15%. Full article

Fins are utilized to considerably increase the surface area available for heat emission between a heat source and the surrounding fluid. In this study, radial annular fins are considered to investigate the rate of heat emission from the surface to the surroundings. The effects of a ternary nanofluid, magnetic field, permeable medium and thermal radiation are considered to formulate the nonlinear ordinary differential equation. The differential transformation method, one of the most efficient approaches, has been used to arrive at the analytical answer. Graphical analysis has been performed to show how nondimensional characteristics dominate the thermal gradient of the fin. The thickness and inner radius of a fin are crucial factors that impact the heat transmission rate. Based on the analysis, it can be concluded that a cost-effective annular rectangular fin can be achieved by maintaining a thickness of 0.1 cm and an inner radius of 0.2 cm. Full article
