Search Results (61)

Achieving a uniform thickness and defect-free production in the flat die extrusion of polymer sheets and films is a major challenge. Dies are designed for one extrusion scenario, for a polymer grade with specified rheological behavior, and for a given throughput rate. The extrusion of different polymer grades and at different flow rates requires trial-and-error procedures. This study investigated the application of machine learning (ML) to provide guidance for the extrusion of sheets and films with a reduced thickness, non-uniformities, and without defects. A dataset of 200 cases was generated using computer simulation software for flat die extrusion. The dataset encompassed variations in die geometry by varying the gap under a restrictor, polymer rheological and thermophysical properties, and processing conditions, including throughput rate and temperatures. The dataset was used to train and evaluate the following three powerful machine learning (ML) algorithms: Random Forest (RF), XGBoost, and Support Vector Regression (SVR). The ML models were trained to predict thickness variations, pressure drops, and the lowest wall shear rate (targets). Using the SHapley Additive exPlanations (SHAP) analysis provided valuable insights into the influence of input features, highlighting the critical roles of polymer rheology, throughput rate, and the gap beneath the restrictor in determining targets. This ML-based methodology has the potential to reduce or even eliminate the use of trial and error procedures. Full article

In the V-bending of sheet metals using a pair of plastic punch and die manufactured by a 3D printer, the effects of two different dimensions designed with the same tool geometry on the deformation behaviors of the punch, die, and sheet were evaluated. The deformation behavior and strain distribution of the punch, die, and sheet were analyzed using a digital image correlation method. Sheets from pure aluminum to ultra-high-strength steel were bent using the two tools with different spans; one was designed on the assumption of tool steel material, and the other was designed on the assumption of plastic material. In both tools, the large compressive strain appeared around the center of the punch tip and on the corners of the die. The tools with a long span for the plastic material gave a lower bending force and small deformation of the plastic tools. The angle difference between a bent sheet at the bottom dead center and a tool was smaller for the tools with the long span, although the springback in the bent sheet appeared. It was found that the design method on the assumption of the plastic material is effective for the V-bending plastic tools. Full article

This study develops an analytical model for the plastic bending of anisotropic sheet materials, incorporating strain-hardening effects. The model, experimentally validated with aluminum alloy samples and digital image correlation, accurately predicts stress–strain distributions, bending moments, and thinning behavior in the bending processes. The results reveal that while plastic anisotropy significantly increases the strain intensity, enhancing it by up to 15% on the inner surface relative to the outer under identical bending radius, it does not affect the position of the neutral layer. Strain hardening, on the other hand, raises the bending moment by approximately 12% and contributes to material thinning, which can reach 3% at smaller bend radii. Furthermore, quantitative analysis shows that decreasing the bend radius intensifies the strain, impacting the final geometry of the workpiece. These findings provide valuable insights for optimizing die design and material selection in forming processes involving anisotropic materials, enabling engineers to more precisely control the force requirements and product dimensions in applications where accurate bending characteristics are critical. Full article

To meet the in-orbit construction needs of super-large spacecraft for ultra-long rod structures, this paper proposes an innovative on-orbit roll forming method for polyetheretherketone (PEEK)-based rod stock. This method ingeniously integrates temperature gradient control into a continuous deformation surface cavity design to achieve an efficient forming of resin rod components. A parametric model of the forming die cavity was established based on the comprehensive bending and downhill methods, and the boundary conditions for the temperature distribution gradient within the cavity were determined. Through the simulation and analysis of the PEEK rod curling and stitching forming process, the influence of the cavity configuration parameters on the forming load was determined. By constructing a test platform for the roll forming characteristics of resin rod components, the effects of different forming methods, stitching temperatures, and feed rates on forming quality and load were verified, and the main factors affecting the width of the welding zone, the roundness of the rod, and the straightness of the weld were analyzed. Experimental results show that the proposed continuous roll forming scheme can achieve an efficient and continuous forming of resin rod structures. When the length of the member is processed to 300 mm, at a formed rod diameter of 20 mm, by employing a cavity deformation zone length of 210 mm, a cavity clearance of 0.1 mm, a sheet width of 61 mm, a feed rate of 1 mm/s, and a sealing zone temperature setting of 335 °C, optimal rod forming quality can be achieved, characterized by a straightness error of 0.0133 ± 0.005 mm and a roundness error of 0.19 ± 0.07 mm. The proposal of this scheme provides a reliable basis for the continuous manufacturing of rod structures in the on-orbit construction of large space structures in terms of both the scheme and the parameter selection. Full article

The results of experimental and numerical studies of plastic forming of sheets made of the difficult-to-deform Hastelloy X, a nickel-based alloy with a thickness of 1 mm, using layered elastomeric punches and steel dies, are presented in this publication. The elastomeric punches were characterized by hardness in the range of 50–90 Shore A, while the dies were made of 90MnCrV8 steel with a hardness of over 60 HRC. The principle of operating the stamping die was based on the Guerin method. The finite-element-based numerical modeling of the forming process for various configurations of polyurethane inserts was also carried out. The results obtained from numerical modeling were confirmed by the results of experimental tests. The drawpieces obtained through sheet forming were subjected to geometry tests using optical 3D scanning. The results confirmed that in the case of forming difficult-to-deform Hastelloy X, Ni-based alloy sheets, the hardness of the polyurethane inserts significantly affected the geometric quality of the obtained drawpieces. Significant nonuniform sheet metal deformations were also found, which may pose a problem in the process of designing forming tools and the technology of the plastic forming of Hastelloy X, Ni-based alloy sheets. Full article

In this paper, a near-net discrete clamp motion path control (SF-CMPC)-based stretch-forming method is proposed as a solution for the low-cost high-quality machining of highly curved surfaces. In this approach, the clamps are discretized, the motion paths are designed to control deformation distribution and avoid forming defects, the stretch-forming transition zone can be effectively reduced, the material utilization rate can be increased, and the near-net formation of large surfaces can be achieved. To investigate this method’s feasibility, the conventional stretch-forming (SF-C) and SF-CMPC processes are numerically analyzed. The results indicate that, upon increasing the transition zone length via SF-CMPC, the maximum thickness reduction and strain value are reduced by 0.010 mm and 0.0249, respectively, with the dependence of the forming quality on the transition zone length being significantly reduced compared to SF-C. In the formation of surfaces with large curvatures, SF-CMPC’s crack risk is lower than SF-C’s crack risk, with better adaptability. Through controlling the contact process with a die, the sheet metals’ constraint state is improved, the transverse compressive strain can be effectively reduced via friction, and the wrinkling defects can be suppressed. A stretch-forming experiment was carried out on a spherical surface, using self-developed equipment. The feasibility of achieving surfaces’ near-net stretch forming by controlling the clamps’ motion paths was hereby proven. Full article

In order to understand the formability of as-received tempered commercial pure titanium grade 2 foils (CP Ti Gr2) with a thickness of 38 µm, a series of micro limited dome height (µ-LDH) tests were conducted in quasi-static speed (0.01 mm/s) at room temperature without the use of a lubricant. A technique developed at NIU was also used to create micro-circular grids (ϕ50 μm) on the as-received material. The forming limit curve (FLC) of the CP Ti Gr2 foils was obtained through the proposed µ-LDH test. For having mechanical properties of the CP Ti Gr2 foils for LS-Dyna FEA (Finite Element Analysis) simulations, a series of tensile tests in three directions were also conducted at room temperature with the same speed. The obtained FLC has been validated using a micro deep drawing case study in which both FEA simulations and experiments were conducted and compared. It has been proven in this study that the FLC obtained using the proposed µ-LDH test can be used for an extremely thin sheet-metal-forming process by the automotive, aerospace, medical, energy, and electronic industries, etc., right away for product design, forming process development, tool and die designs, and simulations, etc. Full article

Weight reduction strategies are essential for the transportation sector to reduce greenhouse gas emissions or extend the range of electric vehicles. In the field of lightweight assembly strategies, multi-material design offers great potential. Joining materials typically used in the automotive sector, such as aluminum and steel, brings challenges as conventional processes such as fusion welding are unsuitable. Therefore, new technologies can extend the design options. In previous studies, a mechanical interlocking between cold-rolled surface structures with undercuts on a steel sheet and die-cast aluminum was presented. This method has now been extended to double-sided structures for more complex applications with a joint on both sheet surfaces. Numerical simulations and validation experiments were performed to investigate the manufacturing of the double-sided structures. Furthermore, the influence of the alignment of the upper and lower structures in relation to each other on the resulting structural geometry and the rolling forces were analyzed. More advantageous geometric parameters, e.g., 24% larger undercuts, and approx. 24.1% lower forming forces at 20% height reduction were observed for a shifted alignment. However, significantly higher wear of the structured rollers occurred in the corresponding experiments. Full article

Sheet metal forming processes are widely used in applications such as those in the automotive or aerospace industries. Among them, punching is of great interest due to its high productivity and low operating cost. However, it is necessary to optimize these processes and adjust their parameters, such as clearance, shear force or tool geometry, to obtain the best finishes and minimize crack generation. Thus, the main objective of this research work is to optimize the punching process to achieve parts that do not require subsequent processes, such as deburring, by controlling the properties of the starting materials and with the help of tools such as design of experiments and simulations. In the present study, tensile tests were performed on three steels with different compositions and three sample geometries. The information obtained from these tests has allowed us to determine the parameters of the Johnson–Cook damage criteria. Moreover, punching was performed on real parts and compared with simulations to analyze the percentage of burnish surface. The results obtained show that the methodology used was correct and that it can be extrapolated to other types of die-cutting processes by reducing the percentage of surface fractures and predicting the appearance of cracks. Furthermore, it was observed that clearance has a greater influence than processing speed, while the minimum percentage of the burnish area was observed for the minimum values of clearance. Full article

It is currently a challenge to accurately predict the deformation and fracture behavior of metal parts in automobile crashes. Many studies have shown that the deformation and fracture behavior of materials are significantly affected by the stress state during automobile crashes with complex stress state characteristics. In order to further promote the application of die-cast magnesium alloys in automobiles, it is particularly important to study the material deformation and fracture behavior of die-cast magnesium alloys. In this paper, the mechanical properties of the AM60B die-cast magnesium alloy sheet under four stress states (shear, tension, R10 notch tension, and cupping) were designed and tested. Based on the von Mises isotropic constitutive model and Swift weighted Hockett–Sherby hardening model, the plastic constitutive model of die-cast magnesium alloy was established. Based on the plastic model and the fracture model (JC, MMC, and DIEM) considering the influence of three stress states, the deformation and fracture behavior of the AM60B die-cast magnesium alloy front-end members in three-point bending were predicted by experiments and finite element simulation. The experimental results show that the deformation mode and loading–displacement curve trend of the AM60B die-cast magnesium alloy front members are the same, the crack initiation point and crack initiation time are the same, and the crack shape is similar. The results show that the complex stress state constitutive model parameters and the DIEM fracture model obtained in this paper can accurately predict the deformation and fracture failure behavior of the AM60B die-cast magnesium alloy sheet. Full article

A new manufacturing process has been developed that involves drawing circular sheets of thin metal through a conical die to create square cups. This technique produces deep square cups with a height-to-punch-side length ratio of approximately 2, as well as high dimensional accuracy and a nearly uniform height. The study investigated how various factors, including the sheet material properties and process geometric parameters, affect the limiting drawing ratio (LDR). The researchers used finite element analysis to determine the optimal die design for achieving a high LDR and found that the proposed technique is advantageous for producing long square cups with high dimensional accuracy. Full article

The paper presents the numerical and experimental results of research aimed at determining the influence of hardness in the range of 50–90 Shore A of layered tools composed of elastomeric materials on the possibility of forming Inconel 625 nickel-based alloy sheets. A stamping die composed of 90MnCrV8 steel (hardness 60HRC) was designed for forming embosses in drawpieces, ensuring various stress states on the cross-section of the formed element. The principle of operating the stamping die was based on the Guerin method. The finite-element-based numerical modelling of the forming process for various configurations of polyurethane inserts was also carried out. The drawpieces obtained through sheet forming were subjected to geometry tests using optical 3D scanning. The results confirmed that, in the case of forming difficult-to-deform Inconel 625 Ni-based alloy sheets, the hardness of the polyurethane inserts significantly affected the geometric quality of the obtained drawpieces. The assumptions determined in numerical simulations were verified in experimental studies. Based on the test results, it was concluded that the selection of polyurethane hardness should be determined by the shape of the formed element. Significant nonuniform sheet metal deformations were also found, which may pose a problem in the process of designing forming tools and the technology of the plastic forming of Inconel 625 Ni-based alloy sheets. Full article

The use of coat-hanger dies is prevalent in the plastic film and sheet extrusion industry. The product quality and the power of the extrusion machine depend on the uniformities of the fluid velocity at the exit and the pressure drop. Die manufacturers face the challenge of producing coat-hanger dies that can extrude materials uniformly and with a minimal pressure drop. Previous studies have analyzed the die outlet’s flow homogeneity and pressure drop using various numerical simulations. However, the combination of the scheme programming language together with the Adjoint Method of Optimization has yet to be attempted. The adjoint optimization method has been demonstrated to be beneficial in addressing issues related to shape optimization problems and it may also be beneficial in optimizing the design of dies used in polymer melt extrusion. In this study, the proposed innovations involve incorporating both the Scheme programming language and Adjoint solver to examine and optimize the coat hanger’s flow homogeneity and pressure drop. Before optimization, the outlet velocity was almost 10 times higher at the die center than at the edges but after optimization, it became more uniform. The proposed optimized coat-hanger die geometry results in more uniform melt flow as demonstrated by the velocity contour plot and the outlet velocity graph in the die slit area, reducing the deviation value from 0.097 to 0.015. Additionally, the mass flux variance across the die outlet decreased by 71.6% from 0.015069 kg m⁻² s⁻¹ to 0.004281 kg m⁻² s⁻¹. Therefore, using this method reduces the amount of time wasted on trial and error or other optimization techniques that may be limited by design constraints. Full article

Hot deformation and in-die quenching of aluminum components for the automotive industry is a cost and energy efficient technique that has been developed and thoroughly evaluated in recent years. The performance of this process is considered higher when compared to traditional cold metal forming due to shorter process times, low-cost machinery, and a high level of structural integrity in fabricated parts. The work presented in this paper provides several approaches for the formability of age hardenable 6xxx alloy sheets when forming at different temperatures. Warm tensile testing and formability cup testing were carried out to investigate the alloy formability at different temperatures. The results indicate that the formability of candidate alloys is not significantly affected by deformation temperatures or conditions, which provides great freedom when designing an automated production process with high productivity and minimal environmental impact. The candidate alloy can be deep drawn without severe thinning at the whole temperature range, from room temperature (RT) to solutionizing temperature. Full article

Reducing the weight of parts through lightweight designs impacts CO₂ emissions, especially in the automotive and transportation sectors, which have significant fuel and electric energy consumption. Using multi-material design approaches, specific material properties can be combined to achieve effective lightweighting. Commonly used metals include aluminum, which is known for its high specific strength, and steel, which is valued for its strength and structural integrity. However, joining aluminum and steel presents challenges given their different thermophysical properties and the potential formation of brittle intermetallic phases, making common joining techniques like fusion welding unsuitable. In this study, a hybrid casting process for the production of a complex workpiece from dissimilar materials was investigated. Aluminum was die-cast around a steel sheet insert. Surface structures with undercuts on the steel sheet were applied through modified cold rolling, allowing molten aluminum to flow into the channels and interlock during solidification. It was found that elevated temperatures of the melt and tool were beneficial for the interlocking, resulting in a 30% increase in compound strength. Furthermore, a reduction in both the piston position at the changeover point, between the pre-filling and cavity filling, and the melt velocity at the gate reduced the compound’s strength by 41% and 30%. Up- and downstream processes did not show any significant influence on the conducted experiments. Based on this, two main detrimental effects were observed: pre-solidification of the aluminum melt and gas entrapment. Full article
