Appl. Mech., Volume 5, Issue 2 (June 2024) – 8 articles

Metal material additive manufacturing (MEAM) has risen in interest in the last five years as an alternative to powder bed processes. MEAM is promising for generating shelled components with defined infill structures, making it very interesting for lightweight engineering. Atomic Diffusion Additive Manufacturing (ADAM) is a filament-based MEAM process patented by Markforged Inc. that provides a closed process chain from preprocessing to the final sintering of printed green parts. This study focuses on Inconel 625, which is of high interest in the aerospace industry, and assesses its dimensional accuracy and tensile properties regarding different print orientations and solid, triangular, and gyroid infill structures. The results showed that neither the dimensional accuracy nor the sintering shrinkage was significantly influenced by the printing orientation or the infill structure. In the context of lightweight engineering, the infill structures proved beneficial, especially within the elastic region. Generally, triangular infill patterns resulted in higher stiffness, while gyroids led to more ductile specimens. A mass-related evaluation of tensile testing elucidates that with the aid of the infill structures, weight savings of 40% resulted in mechanical performance decreasing by only 20% on average, proving its high potential for lightweight design. Full article

The present study evaluates the ratcheting response of notched cylindrical samples made of 1045 steel alloy subjected to asymmetric loading cycles using the kinematic hardening framework, coupled with Neuber’s rule. Test samples with V-shaped and semi-circular edge notches were first heat-treated under different conditions, resulting in various material hardness values at the notch root region. Local ratcheting at the notch root of samples was found to be highly dependent on the notch shape and the heat treatment conditions. HT1 samples with a lower hardness of 12 RC at the notch region possessed higher values of ratcheting, while ratcheting at the notched region for HT2 samples with 40 RC dropped to half of that in HT1 samples. The higher hardness of 50 RC at the notch edge of HT3 samples promoted the initial yield strength and the yield surface through the kinematic hardening rule with a larger translation into the deviatoric stress space as compared with samples HT1 and HT2 with 12 and 40 RC, respectively. The local ratcheting strain in sample HT1, with semi-circular notches ($K_t=1$.65) at a stress ratio ($S_{max}/S_{ult}$) of 0.965, remained below 1.80% during the first hundred loading cycles. The local ratcheting decreased to 1.2% for sample HT2 and further dropped to 0.9% for sample HT3. The yield surfaces were translated consistent with the magnitude and direction of the backstress increments, as the applied loading excursion exceeded the elastic limit. Through the use of the Ahmadzadeh–Varvani (A–V) hardening rule, the predicted ratcheting values at notch roots were found to be larger in magnitudes as compared with those of experimental data, while the predicted local ratcheting through the Chaboche (CH) hardening rule fell below the experimental data. Results consistently showed that as sample hardness increased, the local ratcheting at notch roots decreased. Full article

This research delves into the design, modeling, and finite element impact analysis of the segmented sandwich composite armor system subjected to impact loading, considering different parameters such as materials to be used, armor height, and armor design configuration. Initial studies were performed to select the ideal model that will provide the best impact resistance at the least weight and with minimal fabrication requirements. Material type, thickness, and overall model configuration were defined during the initial model development period. Once the final design was defined, finite element analysis was performed using 2017 ABAQUS software to observe the performance of the model and to validate the efficiency of the chosen armor. Based on the results from the material selection and thickness validation, the optimal design with the best impact resistance was noted as 1.2 mm thick rectangular segmented silicon carbide tiles, serving as the top layer that covers the three-level gradient core composed of a titanium metal honeycomb frame filled with silicon carbide inserts, and finally a 2 mm thick glass epoxy composite layer made from four laminas in a 0/45/90/-45-degree configuration serving as the last layer of the armor. Full article

This study outlines a comprehensive strategy for designing and implementing robust controllers tailored for intelligent structures. This study presents a robust control-based structural identification technique that uses the input/output data of the system to construct a state-space mode and frequency domain. To reduce vibrations, a robust controller is created using the control Simulink model. The identification and robust control of smart structures using Simulink involve a combination of system identification techniques and control design within the MATLAB Simulink environment. The key challenge is dealing with uncertainties and variations in system dynamics. Robust control methods have been employed to suppress the vibrations during dynamic disturbances. These methods are important for mechanical systems operating under stochastic loading conditions. Full article

Marine vessels rely heavily on propeller shaft systems to adjust the engine torque and propeller thrust. However, these systems are subjected to various dynamic excitations during operation, such as transverse, longitudinal, and torsional excitations. These excitations can arise from factors like non-uniform stern flow fields, misaligned components, and the whirling motion of the shafts, which can affect the integrity and reliability of the vehicle. To analyze the dynamic response of the propulsion shaft system and ensure its reliability, numerical/analytical models are currently in practice. The finite element method (FEM) is a popular choice, but uncertainties in bearings and connectors stiffness lead to inaccuracies in the Finite Element model, resulting in significant differences between the experimental and theoretical models. This paper proposes the response surface optimization (RSO) technique to estimate unknown bearing stiffness in the propulsion shaft system. The experimental model of the propeller shaft system is constructed using steady-state response with step sine excitation. The RSO technique is then used to update the natural frequencies and vibration amplitude of the FE (Finite Element) model. The updated model shows less than a 10% difference in natural frequencies and vibration amplitude compared to the experimental model, demonstrating that the proposed technique is an efficient tool for marine shaft dynamic analysis. Full article

Current trends show that wind turbines are growing in size to meet a rising demand for renewable energy generation, and their upscaled rotors have inherently become more flexible to maintain a proportionally lighter design. This is because larger rotors must be less massive relative to their diameter to minimize the levelized cost of energy (LCOE), which means that blades that are notably less stiff are produced as a result. These structural changes to blades are often reflected in their compromised aeroelastic stability and amplified deformation during operation, which has the potential to decrease the blade’s expected lifetime and the performance of the machine overall. Variations in blade flexibility are also known to influence vortex-wake structures downstream of the turbine, causing patterns of velocity deficit to evolve in ways that affect the performance of other turbines in the farm. This research explores how the increased flexibility of modern utility-scale wind turbine blades influences rotor aeroelastic behavior and interactions with farm flow. High-fidelity simulations of Sandia National Laboratories’ (SNL) National Rotor Testbed (NRT) wind turbine are presented. Flexible variations of the NRT baseline blade are simulated in a variety of realistic operational conditions typically expected at the SNL’s SWiFT facility in Lubbock, Texas. Solutions are then compared to investigate how specific changes to the structural properties of the NRT baseline blade’s design and construction can influence its aeroelastic response at the rotor and the evolution of the turbine’s wake. Full article

A new moment-resisting mass timber connection was designed based on the principles of force equilibrium in applied mechanics. The connection configuration utilizing two mechanically fastened threaded steel rods embedded into the end of a glulam beam section was experimentally investigated in this study. A gradually increasing transverse load was applied to the free end of a cantilevered beam, causing a bending moment on the beam-end connection until failure. Four different connection configurations were examined, each replicated twice to verify results. The beam connection parameters investigated were rod anchorage length (200 and 250 mm) and square washer size (38.1 and 50.8 mm). Test results show that increasing the washer size increased the connection bending strength by increments more significantly than those due to increasing the rod anchorage length. However, the connection configurations with the smaller-size washer, which failed mainly due to wood crushing under the washer, had higher ductility ratios than those with the larger-size washer, which failed due to steel rod yielding. In a real-life scenario, a structural element such as a glulam beam is usually loaded to approximately 50% to 70% of its design capacity, considering a reasonable margin of safety. The study estimates a maximum possible bending moment utilization factor for the strongest connection configuration that ranged between 34% and 48% compared to the maximum moment resistance of a supported glulam beam spanning an average length of 4.0 m to 6.0 m (a common span length in framed timber buildings) and has a cross-section size same as the one utilized in this study. This utilization factor is quite large for a timber connection, and thus, confirms a considerable moment-resisting capability of the new configuration developed in this study. Full article

A variety of hollow microneedle (HMN) designs has emerged for minimally invasive therapies and monitoring systems. In this study, a design change limiting the indentation depth of the (3D) printed custom microneedle assembly (circular array of five conical frusta with and without a stopper, aspect ratio = 1.875) fabricated using stereolithography has been experimentally validated and modeled in silico. The micro-indentation profiles generated in confined compression on 1 mm ± 0.073 mm alginate films enabled the generation of a Prony series, where displacement ranged from 100 to 250 µm. These constants were used as intrinsic properties simulating experimental ramp/release profiles. Puncture occurred on two distinct hydrogel formulations at the design depth of 150 µm and indentation rate of 0.1 mm/s characterized by a peak force of 3.5 N (H = 31 kPa) and 8.3 N (H = 36.5 kPa), respectively. Experimental and theoretical alignments for peak force trends were obtained when the printing resolution was simulated. Higher puncture force and uniformity inferred by the stopper was confirmed via microscopy and profilometry. Meanwhile, poroviscoelasticity characterization is required to distinguish mass loss vs. redistribution post-indentation through pycnometry. Results from this paper highlight the feasibility of insertion-depth control within the epidermis thickness for the first time in solid HMN literature. Full article
