A Multi-Fork Z-Axis Quartz Micromachined Gyroscope

by
Lihui Feng
*,
Ke Zhao
,
Yunan Sun
,
Jianmin Cui
,
Fang Cui
and
Aiying Yang
School of Optoelectronics, Beijing Institute of Technology, Beijing 100081, China
*
Author to whom correspondence should be addressed.
Sensors 2013, 13(9), 12482-12496; https://doi.org/10.3390/s130912482
Submission received: 4 July 2013 / Revised: 19 August 2013 / Accepted: 11 September 2013 / Published: 17 September 2013
(This article belongs to the Special Issue Modeling, Testing and Reliability Issues in MEMS Engineering 2013)
Browse Figures
Versions Notes

Abstract

A novel multi-fork z-axis gyroscope is presented in this paper. Different from traditional quartz gyroscopes, the lateral electrodes of the sense beam can be arranged in simple patterns; as a result, the fabrication is simplified. High sensitivity is achieved by the multi-fork design. The working principles are introduced, while the finite element method (FEM) is used to simulate the modal and sensitivity. A quartz fork is fabricated, and a prototype is assembled. Impedance testing shows that the drive frequency and sense frequency are similar to the simulations, and the quality factor is approximately 10,000 in air. The scale factor is measured to be 18.134 mV/(°/s) and the nonlinearity is 0.40% in a full-scale input range of ±250 °/s.
Keywords: quartz micromachined gyroscope; multi-fork; coriolis force; anisotropic etching quartz micromachined gyroscope; multi-fork; coriolis force; anisotropic etching
