This section provides the literature selection criteria (LSC) and the papers that have been collected to review the literature from all the databases. The literature selection criteria (LSC) section shows how we selected related papers based on the selection criteria, after collecting the articles from the databases. Looking at papers published between 2010 and November 2020, this research has explored several electronic databases, such as Institute of Electrical and Electronics Engineers (IEEE) Xplore, PubMed, National Center for Biotechnology Information (NCBI), Springer, Google Scholar, and Elsevier. Based on the selected articles, the literature review is provided in detail below.
Literature Selection Criteria
The advantage of selection criteria is that it is possible to work according to a plan, especially when downloading the papers. According to the time duration set, articles can be searched, and fake journals can be skipped. In terms of search criteria, the research paper must be a conference paper or journal article, and it must use a machine-learning-based model or program intended solely for cervical cancer prediction. In addition, the following conditions must be met:
Purposes must be included in the research paper.
The time frame being surveyed is from 2010 to 30 November 2021. It is important to analyse the previous studies’ insights
We do not include any research work that has not yet been printed, or is not peer reviewed.
In [
14], the authors conducted a survey-based study on cervical cancer detection, including performance analysis to determine the accuracy of various distinctive types of architecture in an artificial neural network (ANN), where the ANN was used for identifying cancerous, normal, and abnormal cells. The authors of [
15] used cervigram images to illustrate a method of screening cervical cancer with the oriented local histogram technique (OLHT), which can increase edges, and the dual-tree complex wavelet transform (DT-CWT), which can help achieve multi-resolution images. Using a UCI data repository and six machine learning (ML) classifiers, ref. [
16] proposed a model that can predict the exact level of cervix infection. Data pre-processing was carried out with physician verification to extract some features and to perform validation. To complete the study, 10-fold cross-validation is utilized to assess the performance of the suggested model. Another key study was published in [
16], which used machine learning classifiers (SVM, QUEST, C&R tree, and MLP). The investigation examined distinct metrics such as accuracy, sensitivity, specificity, and area under the curve (AUC). The QUEST parameters were 95.55%, 90.48%, 100%, and 95.20%, respectively. This research proposed a federated learning method for machinery malfunction diagnostics to address the data island problem. Each participant’s model training is implemented on a local level, and a self-supervised learning scheme is provided to improve learning performance [
17].
Five different machine learning algorithms are used by [
18], including random forest, KNN, C5.0, SVM, and RPart. After finishing the training and evaluating the performance of all of the classifiers (C5.0, RF, RPART, SVM, and KNN), the best options in terms of accuracy were investigated, showing values of 97%, 96.9%, 96%, 88%, and 88%. Machine learning (ML) algorithms such as decision tree, random forest, and logistic regression were used in conjunction with the voting model. In [
19], cervical cancer was detected using a dataset containing four target parameters (biopsy, cytology, Schiller, and Hinselmann), as well as 32 risk factors, collected from the University of California (UCI). Machine learning (ML) algorithms were applied, including the the decision tree and decision jungle approaches. The study observed that the decision tree algorithm showed a higher value (98.5%). In another study using the Microsoft Azure ML tool, an appropriate data mining technique was developed from the boosted decision tree, decision forest, and decision jungle algorithms to detect cervical cancer [
20]. The models’ performances were measured in terms of accuracy, area under the receiver operating characteristic (AUROC) curve, specificity, and sensitivity, with 10-fold cross-validation applied to the outputs to improve the decision tree algorithm’s performance, reaching a value of 97.8% on the AUROC curve. The authors of [
21] presented a survey-based study on cervical cancer prevention from the perspective of women in Bug, IRI, and Mayuge in Eastern Uganda, using a questionnaire to collect data from 900 women aged 25 to 49 years. After measuring and scoring the women’s knowledge and statements about cervical cancer treatment, the data was analyzed using Stata 12.0 software. After doing bivariate and multivariate analysis, the authors discovered that 794 women, or roughly 88.2%, had heard of the condition. A majority of 557 women (70.2%) acquired their information from the radio, while a minority of 120 women (15.1%) got their information from health care organizations.
The authors of [
22] analyzed various machine learning approaches used from 2006 to 2017 to diagnose cervical cancer. In this research, a comparison was made using existing relevant works based on cervical cancer medical data, to determine the benefits and drawbacks of different approaches. Most studies had used unbalanced medical image datasets. The survey also mentioned employing deep learning to predict cervical cancer. Furthermore, the goal of [
23] was to see how well the Cox proportional hazard regression model and the deep learning neural network model predicted survival in cervical cancer patients. A dataset from the University of California, Irvine, was used in the study [
23], which included age, number of pregnancies, contraceptive use, smoking habits, and chronological records of sexually transmitted infections (STDs). The study’s essential purpose was to use Hinslemann screening methods to predict cervical cancer. With 10-fold validation, a data mining strategy was used with the boosted decision tree, decision forest, and decision jungle approaches. Moreover, on the AUROC (area under receiver operating characteristic) curve, the boosted decision tree method achieved a forecast precision of 98%. The best example of using electronic health record (EHR) data to predict cervical cancer is [
24]. Four machine learning classifiers were used to predict cancer. The random forest algorithm produced the best results, with an AUC (area under the curve) of 0.97 one day before diagnosis, up from 0.70 a year before diagnosis. The primary purpose of [
25] was to create a method that can anticipate the early effects of radiation on bone metastases in cervical cancer patients. The researchers employed class imbalance learning (CIL) in data mining to tackle the challenge of an imbalanced dataset. To deal with the issue of imbalanced data categorization, many models, such as ant-miner, RIPPER, Ridor, PART, ADTree, C4.5, ELM, and weighted ELM, with the synthetic minority over-sampling approach (SMOTE) were used. The study aimed to assist in the early detection of cervical cancer. The study showed the use of machine learning in defining a data validation mechanism to improve the performance of cervical cancer prediction. The study also suggested genetic assistance as an optional strategy to enhance the validity of the prediction. Additionally, [
26] has presented a method based on machine learning approaches for identifying cardiac disease. Classification algorithms were used to construct the system. The model suggested a conditional mutual information feature selection method to overcome the feature selection problem. Feature selection methods are utilized to improve classification accuracy and shorten the time it takes to develop a classification system.
Furthermore, the fundamental purpose of [
27] was to examine how big data analytics and machine-learning-based approaches may be used for diabetes. The results demonstrate that the proposed machine-learning-based system might score as high as 86% on the diagnostic accuracy of DL. Health specialists and other stakeholders collaborated to create classification models that would assist in diabetes prediction and the design of prevention measures. Based on the findings, the authors review the literature on machine models and propose an intelligent framework for diabetes prediction. Anther study has been conducted [
28] where a methodology for heart disease was developed using the UCI repository dataset and healthcare monitors to estimate the public’s risk of heart disease. In addition, classification algorithms were employed to classify patient data to detect cardiac disease, such as doosted decision tree and decision forest. The classification was performed using data from the benchmark dataset during the training phase. At the testing stage, accurate patient data was used to determine whether illness existed. The results demonstrate that the proposed model based on machine learning could score as high as 92% on the diagnostic accuracy of DL. Comparative analysis of existing research are provided in
Table 1.
Based on the above review, it can be stated that several traditional algorithms have been used to predict cervical cancer; still, the models do not achieve a satisfactory level, because the selection of important features is the most crucial part of machine learning, and the authors have not specified how the chosen features were selected. In addition, just using traditional deep learning algorithms does not indicate that a model is suitable for practical implementation in the healthcare sector; rather, model customization is required to remove the overfitting and make it faster for a clinical application. Nonetheless, this research has come up with an effective solution. Various state-of-the-art techniques are used in this study to take this research to a satisfactory level and assist doctors in diagnosing cervical disease.
