A Design of High-Efficiency: Vertical Accumulation Modulators Based on Silicon Photonics
Abstract
:1. Introduction
2. Principles and Methods
2.1. Principles
2.2. Methods
3. Results
3.1. Dielectric Layer Thickness
3.2. Doping Concentration
3.3. Modulator Geometric Factors
4. Discussion
Gate Material | Oxide | VπL (V·cm) | Loss (dB/cm) | α· VπL (dB·V) | Result Type |
---|---|---|---|---|---|
ITO [23] | Al2O3 | 0.052 | >1500 | >80 | Experimental |
ITO [24] | Al2O3 | 0.095 | 16,000 | 152 | Experimental |
InGaAsP [25] | Al2O3 | 0.047 | 4.6 | <1 | Experimental |
InP [26] | SiO2/Al2O3 | 0.54 | 2.3 | 1.24 | Experimental |
Poly-Si [7] | SiO2 | 1.8 | >30 | >48 | Experimental |
Poly-Si [29] | SiO2 | 0.886 | >18 | >16 | Numerical |
Poly-Si [9] | SiO2 | 0.2 | 65 | 13 | Experimental |
(This work) Poly-si | ZrO2 | 0.16 | 50 | 8.24 | Numerical |
