Spontaneous and Chemically Induced Genome Doubling and Polyploidization in Vegetable Crops

Abstract

Plant ploidy manipulation is often required for breeding purposes. However, there is no comprehensive review covering genome doubling in vegetable crops despite the abundance of data for a large number of vegetable species. Similar to other species, genome doubling is required in vegetable crops to obtain doubled haploids (DHs). It is also utilized for the production of polyploids to overcome interspecific hybrid sterility and improve agricultural traits. Spontaneous haploid genome duplication (SHGD) occurs in many Apiaceae, Brassicaceae, Cucurbitaceae, and Solanaceae crops, allowing for the laborious treatment with antimitotic agents to be bypassed. SHGD mechanisms are not fully understood, but existing data suggest that SHGD can occur via nuclear fusion, endoreduplication, or other mechanisms during microspore or ovule early embryogenic development. Other studies show that SHGD can occur at later developmental stages during extended plant growth in vitro or ex vitro, possibly due to the presence of phytohormones in the medium and/or diploid cell competitive advantage. For unresponsive accessions and species with rare SHGD, such as onion (Allium cepa L.) and beet cultivars (Beta vulgaris subsp. vulgaris L.), antimitotic agent treatment has to be applied. Antimitotic agent application efficiency depends on the treatment conditions, especially the agent concentration and exposure time. Also, plant developmental stage is critical for agent accessibility and plant survival. The existing methods can be used to further improve genome doubling methodology for major vegetable crops and other species.

1. Introduction

Plant breeding aims to improve cultivar yield and valuable compound abundance, for instance, sugar, antioxidant, and essential oil content. Another important goal of breeding is developing cultivars resistant to diseases, pests, and abiotic stressors, such as extreme temperature, salinity, and drought. Genome doubling is one of the tools required to speed up breeding process and increase genetic diversity. It is required for doubled haploid (DH) production. It is also utilized for doubling genome in interspecific hybrids and obtaining polyploids with improved agricultural traits. The methods of chromosome doubling are covered in many reviews for cereal and industrial, medicinal, and ornamental crops, but vegetable crops have not been discussed extensively so far [1,2,3,4,5,6,7,8].

Conventional breeding requires self-pollination for multiple generations, which makes this method extremely time-consuming. Many species have severe inbreeding depression [9] or self-incompatibility [10], which additionally complicates the generation of pure lines.

DH technologies allow for the production of fully homozygous pure lines in one generation, which immensely accelerates breeding. DH lines are produced when haploid cells, microspores, or ovules are stimulated to switch toward a sporophytic developmental route. The resulting haploid regenerants need to double their genome to become diploid plants with two identical copies of genetic material [11,12]. SHGD induction or doubling with antimitotic agents are required for the successful inclusion of regenerant plants in a breeding program because haploid plants are sterile or have low seed productivity [5]. Similarly, if mixoploids or polyploids are generated, they can be of limited value for breeding. Therefore, SHGD induction methods or antimitotic treatment protocols are crucial for DH technology’s successful implementation. Detailed reviews provide protocol development guidelines for haploid genome doubling in many species [4,5,6]. However, there is no comprehensive review covering genome doubling in vegetable crops.

Vegetables play a crucial role in human nutrition, providing dietary fibers, vitamins, minerals, and other essential nutrients [13,14,15]. DH technologies are being developed and improved to facilitate vegetable crop breeding. Vegetable crops are less responsive to DH technologies compared to cereals and rapeseed (Brassica napus L.). Therefore, a lot of data on doubled haploids, including the putative mechanisms of SHGD, were obtained in cereals and rapeseed [6]. Recently, a large degree of progress was made in the development of DH technologies for vegetables [15]. However, problems with the induction of embryogenic growth in many vegetable crops, especially Solanaceae, and the limited SHGD, especially in Amaranthaceae and Amaryllidaceae, limited the production of sufficient numbers of DH plants for breeding programs [9,16,17].

Another problem faced by breeders is introducing new valuable traits. Polyploidization produces varieties with new characteristics that could not be achieved by other means. This method is exploited in ornamental crops [1,7,8], medicinal plants [1,2], and industrial crops [3] because polyploids often have increased plant size and vigor, improved decorative traits, or increased secondary metabolite synthesis. Polyploidization is used for vegetable breeding to improve agricultural traits as well. One of the commercial successes of this method is seedless watermelon hybrids produced from diploid and tetraploid parent lines [18]. Genome doubling is also applied to overcome interspecific hybrid sterility [19]. Broadening the genetic diversity of breeding material can be achieved via hybridization with related species. This method is commonly used to introduce disease, herbicide, and abiotic stress resistance, as well as cytoplasmic sterility genes and other traits from other species. However, the obtained hybrids are often sterile, but genome duplication with antimitotic compounds can restore fertility.

SHGD and colchicine treatments exert stress on the genome of treated plants. The skim sequencing of wheat (Triticum aestivum L.) showed that various chromosomal aberrations, including deletions, duplications, and aneuploidy, can happen due to genomic shock during DH production [20]. These alterations can affect plant fitness and agronomic performance. In addition, DNA methylation patterns change as a result of spontaneous and artificial doubling. Most differential DNA methylation occurred at random sites [21]. Colchicine treatment changed the expression of genes involved in hormone signal transduction, metabolism, cytoskeleton control, and others [22]. More studies are needed to identify how long these changes last and what their consequences are. Possibly, the development of less-stressful protocols of spontaneous and artificial genome doubling will be beneficial.

Genome doubling is an indispensable tool for a multitude of applications in plant breeding. In this review, we discuss SHGD incidence and mechanisms, as well as antimitotic treatment protocols for different vegetable crops. Emphasis was placed on the most recent papers and literature sources that provided well-described and statistically tested data with controls and a large number of tested plants. Very limited data were available for some species; therefore, any available information was analyzed for them. The critical treatment information was unified (concentrations in g/L, doubling rate in %) and summarized in a table (Table 1).

2. Spontaneous Genome Doubling

The term “spontaneous doubling” is used to differentiate from doubling induced by chemical treatment. SHGD is extremely advantageous for DH production as it allows for the laborious and costly genome doubling with antimitotic compounds to be omitted.

2.1. Spontaneous Haploid Genome Doubling in Vegetable Crops

SHGD occurs at different frequencies in different species. Moreover, it can vary greatly within a species between different cultivars. For instance, in cereal crops, the percentage of doubling in barley (Hordeum vulgare L.) is up to 87% [23], in rice (Oryza sativa L.) it is up to 72% [24], in wheat (T. aestivum L.) it is up to 50% [25], and in maize (Zea mays L.) genotypes it is up to 0–21.4% [26,27].

SHGD can be documented in vegetable crop plants generated by DH technologies (Figure 1). For the Amaranthaceae vegetable crop red beet (Beta vulgaris subsp. vulgaris L.), the SHGD rate varied in different studies. Some authors observed no incidence of SHGD [28], while others obtained up to 70% diploid plants [29] or tetraploid regenerants [30]. The close relative of red beet, sugar beet (B. vulgaris subsp. vulgaris (var. saccharifera)), had gynogenic regenerants with a haploid chromosome set, but the root tips had endopolyploid cells [31]. In another study, a 10% SHGD rate was observed for sugar beet [32].

For the Amaryllidaceae family, SHGD was reported in onion (Allium cepa L.) during gynogenesis in vitro, but the doubling efficiency was relatively low. When a large number of regenerants (about 100) were obtained, the doubling efficiency could be more accurately assessed, and it was determined to be about 10% [33,34,35].Various SHGD rates were reported in the Apiaceae family. In some studies, no doubling occurred, as reported by Hu et al., who showed that among 18 carrot (Daucus carota L.) plants obtained from the embryoids and calli, 16 plants were haploid (2n = 9), and the other 2 plants were aneuploids (2n = 10 and 11) [36]. In another study, regenerants obtained in a culture of isolated microspores had an SHGD rate ranging from 17.5% to 63.6% depending on carrot accession [37]. A total of 90% of carrot regenerants obtained from another culture were diploid [38]. The flow cytometric analysis of carrot plants obtained in an in vitro culture of unfertilized ovules in carrot showed that 97.7% of the regenerants were diploid [39].

About 50% of the dill (Anethum graveolens L.), caraway (Carum carvi L.), carrot (D. carota L.), fennel (Foeniculum vulgare Mill.), lovage (Levisticum officinale Koch.), and parsnip (Pastinaca sativa L.) regenerants obtained from microspore culture spontaneously doubled their genome. However, regenerant images and ploidy evaluation [40].

SHGD is widely observed in the Brassicaceae family. For instance, besides haploid plants, mixoploid, diploid, and tetraploid cabbage (Brassica oleracea var. capitata L.) regenerants produced from microspores can be observed as assessed by flow cytometry, guard cell chloroplast, and chromosome counting (Figure 1). SHGD occurred in 0–76.9% of cabbage (Brassica oleracea var. capitata L.) regenerants, in 52.2–100% of broccoli (B. oleracea var. italica L.) [41], in 50–70% plants of different B. rapa L. accessions [42,43,44,45], and in more than 60% of rapeseed (B. napus L.) regenerants [46].

In Cucurbitaceae species, for instance, in a summer squash (Cucurbita pepo L.) ovary/ovule culture, most regenerants doubled their genome. Although, occasional haploid, mixoploid, or polyploid regenerants were observed as well [47]. In styrian oil pumpkin (Cucurbita pepo ssp. pepo var. styriaca), most plants were also diploid, with rare occurrences of n, 3n, and 4n plants [48].

Solanaceae crops also demonstrate genome doubling in DH regenerants, although the doubling rate often differs greatly not only between different species but also within the same species between different genotypes or even between different plants within the same genotype [49]. The frequency of SHGD in bell pepper (Capsicum annuum L.) plants was 14%–51% [50], 14.3–65.8% [51], 30–55% [52,53], 32.6% [54], 33% [55], and 65% [56]. In hot pepper (C. annuum L.), the SHGD rate was 16.3% [57]. In Indonesian hot pepper (C. annuum L.), spontaneous doubling was 14–33% in four accessions and 47% and 51% in the other two pepper accessions [50]. The analysis of cayenne pepper (C. frutescens L.) regenerants showed that about 40% of plants were diploids and 8% were mixoploids [58]. Interspecific hybrids, C. frutescens × C. annuum and C. frutescens × C. chinense had a lower haploid embryoid regeneration rate compared to C. annuum, but the SHGD was 50% and 80%, respectively [49]. In the genus Physalis, a high level of spontaneous diploidization (up to 72%) was observed in tomatillo (Physalis ixocarpa Brot.) (2n = 2x = 24) [10,59]. At the same time, for the tetraploid species cape gooseberry (Physalis peruviana L.) (2n = 4x = 48), a fairly low doubling level was documented (28%), and antimitotic treatment was required to double the genome in haploid regenerants [60].

Tomato (Solanum lycopersicum L.) is one of the most recalcitrant crops for DH technologies. Unlike most other members of the Solanaceae family, tomato is unresponsive to all the existing DH methods available in the literature. Therefore, it is difficult to make conclusions about SHGD for tomato. The largest number of plants was obtained in the work of Zagorska et al., 2003, who analyzed ploidy in 700 androgenic regenerants. They concluded that 21,5% were haploid, 11.3% were diploid, and the rest were mixoploid [61].

Diploid plants obtained from the anther or ovule cultures can originate from surrounding somatic tissues. In addition, some regenerant plants can come from unreduced gametes that formed via meiotic restitution [62]. Therefore, regenerant origin has to be validated by molecular markers to select only true DHs. The reported SHGD rate may be affected by the erroneous inclusion of plants obtained via the abovementioned mechanisms.

A large number of vegetable species described above undergo spontaneous genome doubling. However, some accessions have an insufficient SHGD rate, and some species, including onion and beet, are recalcitrant to spontaneous doubling induction. Despite the challenges of the DH technologies in vegetable crops, doubled DH lines are included in breeding programs. Examples of the successful use of spontaneously doubled DH lines include the F1 hybrid of cabbage ‘Nataly’, kohlrabi ‘Dobryniya’, sweet pepper ‘Mila’, ‘Nataly’ and ‘Gusar’, pumkin ‘Vega’, and a carrot variety ‘Sonata’ [63].

2.2. SHGD Mechanisms

A list of factors influence spontaneous doubling induction, including genetic factors and microspore or anther temperature stress treatments. In cereal crops, mannitol or 2-hydroxynicotinic acid can also be used as a stress treatment [62]. In addition, spontaneous doubling can occur after a long-term regenerant subculturing in vitro or ex vitro.

Four possible mechanisms of genome doubling were proposed: nuclear fusion, endoreduplication, C-mitosis, and endomitosis [6,27,62]. Endoreduplication is a process when one or several rounds of DNA replication happen without mitosis. It is widely observed in angiosperms at different stages of development [64]. One of the critiques to this plausible mechanism is that endoreduplication is generally seen as a terminal stage of cell differentiation served to obtain higher metabolic competences and/or cell size, which differs from the processes observed in developing haploids [27].

The nuclear fusion of two haploid nuclei is another possible mechanism. Nuclear fusion was experimentally documented in a barley microspore culture (H. vulgare L.) by live cell imaging [65]. More studies in different taxa are needed to further confirm this mechanism’s applicability for SHGD.

Endomitosis happens when mitotic stages occur inside the nuclear membrane without spindle formation and daughter cell separation. However, endomitosis is rarely observed in angiosperms. C-mitosis is an artificially aborted cell division via the disruption of mitotic spindle by colchicine or other antimitotic agents [27,62], which is discussed in Section 2 of this review.

Besides haploid and doubled haploid plants, triploid and polyploid regenerants can often be observed in many crops, including Brassica species, C. annuum L., D. carota L. [4], and C. pepo L. [47,48]. Possibly, triploid plants can form due to the fusion of diploid and haploid nuclei. Tetraploid and higher ploidy plants are likely to result from more than one round of doubling [6]. As it was mentioned before, different cultivars can have a big difference in the incidence of SHGD. The genetic mechanisms that make some cultivars more prone to SHGD are not clear, but the research conducted on maize showed one major and a few minor QTLs that are associated with spontaneous genome doubling. The possible candidate gene associated with the reported QTLs is the absence of the first division (afd1) gene that affects the first meiotic division, resulting in a single equational division. Another candidate is the formin-like protein 5 that affects actin cytoskeleton [66]. Studies of other species, including vegetable cultivars, are required for the elucidation of the genetic mechanisms controlling SHGD. The development of SHGD-associated markers would simplify the introgression of this valuable trait into elite germplasm and increase DH production efficiency.

2.3. SHGD Timing during Development

Spontaneous genome doubling can occur at different stages of microspore development [6,62]. The applied stress pretreatment leads to cytoskeleton perturbation. It disrupts mitotic spindle or cell wall formation that results in SHGD. It was demonstrated that to obtain the best results, the stress treatment has to be applied specifically at late uninucleate to early binucleate stages. Microspores isolated at early uninucleate stages predominantly resulted in haploid regenerants, while the binucleate microspores produced more doubled haploid and polyploid regenerants [6]. Stress application at later stages can increase the incidence of triploid and polyploid regenerants [62].

Spontaneous chromosome doubling can occur at later developmental stages as well. Yuan et al. reported that the long-term subculturing of cabbage or broccoli haploids on MS-2 medium with 0.1 mg/L NAA and 0.2 mg/L 6-BAP led to a gradual increase in the number of plants with a doubled chromosome set. After one or more years in tissue culture, most of the cabbage or broccoli haploids turned into DHs or mixoploid plants [41]. Similar results were observed in haploid pepper (C. annuum L.) plants grown ex vitro for 6 years. The plants were rejuvenated by cutting off the shoots and allowing young shoots to regrow. The authors reported that out of 12 plants, 1 plant had all diploid shoots, 7 plants had both haploid and diploid shoots, 2 plants remained haploid, and 2 plants died [67]. For plants that change their ploidy after long-term growth in vitro or ex vitro, it can be speculated that spontaneous endoreduplication or doubling via other mechanisms can happen in some cells. Subsequently, doubled haploid cells could outcompete haploid cells. However, this hypothesis requires experimental testing. Possibly, culture media hormones can affect the doubling rate. For instance, auxins are involved in the transition from the mitotic cycle to endoreduplication [68]. For instance, it was shown that NAA caused genome duplication in sugar beet [69]. 2,4-D is also known to increase plant ploidy, as shown, for example, in an orchid tissue culture [70]. The cucumber embryogenic callus established from immature embryos on media supplemented with 6-BAP, NAA, and 2,4-D regenerated not only into diploid (57%) but also tetraploid (18%), octoploid (4%), and mixoploid (2n/4n—4% and 4n/8n—17%) regenerants, as tested by flow cytometry [71].

Currently, the SHGD mechanisms are not fully understood. More research is needed to definitively demonstrate how SHGD occurs and what molecular mechanisms underlie these processes. Understanding the mechanisms of spontaneous doubling can vastly improve the genome doubling rate and the efficiency of DH technology.

3. Chemically Induced Genome Doubling Protocols

When SHGD does not occur or happens at a low frequency, genome doubling can be induced with antimitotic compounds. Currently, a number of antimitotic agents are used to induce genome duplication, including a natural alkaloid colchicine (C22H25NO6) and herbicides, such as trifluralin (C13H16F3N3O4), oryzalin (C12H18N4O6S), pronamide (C12H11Cl2NO), and amiprofosmethyl (APM) (C11H17N2O4PS). Alcohol n-butanol (C4H9OH) is also utilized as an antimitotic agent. The listed antimitotic compounds have a similar mechanism of action. They perturb the microtubule cytoskeleton that prevents mitotic spindle formation and chromosome separation. As a result, the cell receives a doubled chromosome set [4,72,73].

The antimitotic compound choice, concentration and treatment time, supplementary compounds, and the explants used for treatment are critical for successful genome doubling. Different approaches for chemically induced genome doubling are covered below.

3.1. Antimitotic Agent Choice

Colchicine is one of the most widely used antimitotic agents (Table 1). Colchicine is typically applied at concentrations of 0.05 to 5 g/L, but in some cases, it may be outside this range. For example, Gurel S. et al. (2021) treated sugar beet (B. vulgaris subsp. vulgaris (var. saccharifera)) with 20 g/L colchicine, while Vasilchenko et al. (2018) used it at a 4000 times smaller concentration (0.005 g/L) on the same crop [16,74]. Hence, the antimitotic agent should be tested in a wide range of concentrations to determine the most effective and cost-efficient treatment protocol. Colchicine must be handled with caution with the use of protective clothing and gloves due to its toxicity [75]. In addition, colchicine is a light-sensitive compound; therefore, it has to be used under limited or no light conditions [76]. For instance, plant apices with applied cotton balls soaked in colchicine should be covered with foil to prevent colchicine degradation.

Trifluralin is another common substance used to increase the ploidy level. It is a pre-emergence herbicide that prevents seed germination. Trifluralin has low acute toxicity, but it has been classified as a group C, possible human carcinogen [77]. Similar to colchicine, it has to be protected from light due to its light sensitivity [72]. Trifluralin is typically used at 3.35 × 10⁻⁴ [78] to a 0.1 g/L concentration. However, concentrations close to 0.1 g/L or above have led to plantlet death [79,80]. Trifluralin was successfully used in a list of species, including onion (A. cepa L.) [81], rapeseed (B. napus L.) [78,82], sugar beet (B. vulgaris subsp. vulgaris (var. saccharifera)) [79,83], rice (O. sativa L.) [5], maize (Z. mays L.) [84], and others (Table 1).

Oryzalin is used to increase ploidy in many horticultural and ornamental species. For genome doubling purposes, oryzalin is used at concentrations ranging from 4 × 10⁻⁴ [79] to 0.1 g/L. Similar to trifluralin, high oryzalin concentrations (0.1 g/L or above) are also detrimental for plant survival [79,85]. Oryzalin was tested in rapeseed (B. napus L.) [82], sugar beet (B. vulgaris subsp. vulgaris (var. saccharifera)) [79], onion (A. cepa L.) [34,81,86], maize (Z. mays L.) [84], and other species (Table 1).

Amiprofos-methyl (APM) is an antimitotic agent that destroys mitotic spindle or induces multipolar spindle division [4]. Successful genome doubling using APM was reported for a list of species, including rapeseed (B. napus L.) [82], wheat (T. aestivum L.) [87], and maize (Z. mays L.) [84,88,89]. For vegetable crops, it shows promising results in onion (A. cepa L.) [81,86,90,91,92,93].

The use of herbicide pronamide is limited to a small number of studies. In maize, 0.0026 g/L pronamide resulted in about a 60% doubling rate [84]. In sugar beet and fodder beet, 0.004 g/L pronamide induced 2% doubling [79]. Rapeseed treatment with pronamide increased the number of plants with doubled genome (52%) compared to untreated control (36.4%), but it was less effective than colchicine treatment (69.6%) [94] (Table 1).

N-butanol is a primary 4-carbon alcohol that induces cortical microtubule depolymerization [95,96]. A drastic increase in the microspore embryogenesis rate after n-butanol treatment was observed in wheat (T. aestivum L.) [97] and certain barley cultivars (Hordeum vulgare L.) [98]. N-butanol has some positive effect on embryogenesis in maize (Z. mays L.) [95,99,100] and pepper (C. annuum L.) [101]. A further improvement in the n-butanol treatment regimen and testing of this compound in other species is still needed.

The efficacy of an antimitotic agent treatment critically depends on a number of factors that determine the toxic effect of the antimitotic compound, as well as the duplication and the aberrant ploidy rate. The agent concentration, supplementary components, the application method, and other contributing factors are discussed below.

Table 1. Vegetable crop and sugar beet (Beta vulgaris L.) genome doubling approaches.

The Crop	Ploidy before Treatment	The Best Doubling Efficiency	Application Method	Antimitotic Agent	Treatment Time	Growth Conditions after Treatment	Practical Results	References
Amaranthaceae
Sugar beet (Beta vulgaris)	n	–	Seedlings with 3–7 leaves	5 g/L colchicine	5 min 2 times	MS, 10 g/L sucrose, 6.5 g/L Gelrite, 0.002 g/L kinetin	–	[16]
	n	91.3%	Microclones	0.0005 g/L colchicine	48 h	MS, GA, 6-BAP, kinetin—0.0002 g/L each	Selection of new lines with sterile cytoplasm (confirmed by PCR and RFLP analysis). Four lines were selected for breeding purposes (the plant qualities are not described)	[74]
	n	29.1%	Shoots higher than 1 cm with roots removed	0.05, 0.1, 0.15 or 0.5 g/L colchicine	12, 24, 36 or 48 h	MS, 0.001 g/L 6-BAP, solid or liquid media	–	[83]
		20.7%		0.017, 0.0034 or 0.005 g/L trifluralin
	n	4.7% (0.03 g/L)	Ovules. Antimitotic agent with 1.5% DMSO	0–0.09 g/L APM	5 h	Liquid culture medium	–	[79]
		2.8% (0.00035 g/L)		0–0.1 g/L oryzalin
		2.0% (0.003 g/L)		0–0.1 g/L pronamid
		2.0% (0.003 g/L)		0–0.1 g/L trifluralin
	n	60% (4 g/L, 2.5 h)	Ovules after 7 days in culture	4–60 g/L colchicine	0.08—5 h	Induction medium	–	[102]
	n	64% (0.046 g/L APM, 5 h)	Ovules after 10 days culture	0.006, 0.046, 0.092 g/L APM + 15 g/L DMSO in liquid induction medium	2, 5, 18 h	Culture medium	–	[103]
	n	19%	Roots of regenerant plants	3 g/L colchicine	24 h	Plants were planted in soil	Three lines that exceeded diploid control for yield and sugar concentration were produced (for instance, BTS 40 DH line—377.7 g and 19.4%, control diploid—204.2 g and 18.4% root weight and sugar content, respectively)	[104]
	n	8.4% 2n, 3.4% 4n, 1.1% 8n, 33% mixoploids	Meristem of plants at the 6–8-leaf stage	1 g/L colchicine with 20 g/L DMSO	72 h	–	–	[105]
Amaryllidaceae
Garlic (A. sativum)	2n	–	Basal plates in liquid B5 with 20 g/L DMSO and colchicine	2.5–7.5 g/L colchicine	36–72 h	B5, 0.0008 g/L 2iP, 0.0001 g/L NAA	4n plants leaves had 3 times larger area. Allicin content increased by 30%	[106]
Onion (Allium cepa)	n	–	Basal explant in MSO (MS based) medium with colchicine	0.4 g/L colchicine	48 h	½ BDS, 30 g/L glucose and 7.0 g/L agar, pH 6.0	–	[9]
	n	36.7%	Embryos in medium with APM	0.015 g/L APM	48 h	½ BDS, 30 g/L glucose, 7.0 g/L agar, pH 6.0	–	[93]
	n	36%	Intact or cut longitudinally into halves basal explants in BDS medium with antimitotic agents	0.003; 0.006; 0.009 g/L APM	72 h	½ BDS or M4, 30 g/L glucose and 0 or 7.0 g/L agar, pH 6.0	Fertility/fecundity recovered in some genotypes, but not others. Lines with uniform bulb shapes were produced	[90]
		40–46% 2n, 18–30% mixoploids (0.2–0.4 g/L colchicine in liquid medium, 48 h		0.01–0.4 g/L colchicine	24, 48, 72 h
	n	32.8% (0.4 g/L)	Whole basal explants	0.3–0.4 g/L colchicine	–	MSO, 30 g/L sucrose	Fertility/fecundity recovery	[86]
		15.8% (0.03 g/L)		0.017–0.051 g/L oryzalin
		25% (0.03 g/L, 0.045 g)		0.015–0.045 g/L APM
	n	100% (0.25 g/L, 48 h)	in vitro plants	0.25 or 0.5 g/L colchicine	24 and 48 h	½ MS, 40 g/L sucrose, 7.5 g/L agar, pH 5.8	–	[92]
		57.7% (0.015 g/L 48 h)		0.015–0.06 g/L APM
	n	46% (0.01 g/L, 72 h)	Root tips, shoot apex	0.01; 0.1 g/L colchicine	24 and 72 h	M3 medium	–	[91]
	n	up to 65.7% (1 g/L)	in vitro plants	0.25–5 g/L colchicine	24 h	MS	–	[34]
		up to 57.1% (0.0175 g/L)		0.0035–0.07 g/L oryzalin
	n	44%	Two-month-old haploid plants on BDS basic medium with colchicine	0.015 g/L colchicine	72 h	The plants were grown in peat blocks	–	[107]
	n	47.1% 2n, 29,4% 29,4% another ploidy (0.017 g/L 72 h)	Gynogenic embryos were plated on the media with antimitotic agents in the dark	0.0017 g/L; 0.017 g/L trifluralin in acetone	24 and 72 h	Medium R1: ½ BDS, 30 g/L glucose and 7.0 g/L agar, pH 6.0; medium R2: BDS, 40 g/L sucrose, 7.0 g/L agar, pH 6.0	–	[81]
		47.1% 2n, 8.8% other ploidy (24 h)		0.012 g/L oryzalin in acetone
		34.8% 2n, 17.4% other ploidy (72 h)		0.015 g/L APM in methanol
		35.3% 2n, 5.9% other ploidy (0.05 g/L 72 h)		0.001 g/L; 0.05 g/L colchicine with 20 g/L DMSO
	n	Up to 38% 2n (0.015 g/L, liquid media, 24 h)	Embryos in liquid or solid media with APM	0.008 g/L; 0.015 g/L APM	24 and 72 h	½ BDS, 15 g/L glucose	–	[108]
Onion (A. fistulosum × A. cepa)	2n	51.4% 4n (10 g/L)	Callus in liquid BDS on a shaker at 60 rpm	5–20 g/L colchicine	36–72 h	solid BDS medium with 8 g/L agar	Five 4n, likely amphidiploid plants were obtained and adapted to field conditions for future breeding	[109]
Onion (A. cepa × A. vavilovii, A. cepa × A. nutans, A. cepa × A. schoenoprasum)	3n *	–	Meristems in vitro	0.01 g/L colchicine	–	–	An increased vegetative mass (no quantitative data) and resistance to downy mildew was observed in interspecific hybrids	[110]
Persian shallot (A. hirtifolium)	2n	died after treatment	Basal plates in liquid MS with 10 g/L DMSO and antimitotic agent on a shaker at 100 rpm	3–7 g/L colchicine	24–48 h	MS, 30 g/L sucrose, 8 g/L agar, 0.001 g/L 6-BAP, 0.0005 g/L NAA	Increased total phenolic compound and allicin content by 27 and 15%, respectively [111]	[111]
		died after treatment		0.01–0.04 g/L oryzalin	4–8 h
		35% 4n (5 g/L, 36 h); 31.82% mixoploids (3 g/L, 36 h)	Basal plates on solid MS with 8 g/L agar with antimitotic agents	3–7 g/L colchicine	24–48 h
		45.45% 4n (0.01 g/L, 8 h); 16.9% mixoploids (0.04 g/L)		0.01–0.04 g/L oryzalin	4–8 h
Apiaceae
Ajowan (Trachyspermum ammi)	2n	11.53% 4n (0.5 g/L, 24 h)	Seeds	0.24–0.5 g/L colchicine	6–48 h	liquid MS	Thymol in essential oil increased by 39% in 4n plants. The increase was observed in plant organ sizes with the largest difference in plant height (over 2 times)	[112]
American wild carrot (Daucus pusillus)	n	–	Cut umbrellas before flowering in the green bud phase	1 g/L colchicine with 20 g/L DMSO	20 h	MSm, 0.0002 g/L 2,4-D, 6–8 g/L agar	–	[110]
Caraway (Carum carvi)	n	–	Root system of in vitro plants	0.4 g/L colchicine with 10 drops/L DMSO	24 h	Containers with soil, plants were covered to maintain high humidity	–	[113]
Carrot (Daucus carota L.)	n	–	Microspores	0.5 g/L colchicine	24 h	B5, 0.0001 g/L 2,4-D, 0.0001 g/L NAA, 100 g/L sucrose	–	[114]
Carrot (D. carota L.)	n	–	Microspores	0.5 g/L colchicine	48 h	NLN, 0.0001 g/L 2,4-D, 0.0001 g/L NAA, 130 g/L sucrose	–	[115]
Fennel (Foeniculum vulgare), Dill (Anethum graveolens)	n	–	Root system and crowns	3.4 g/L colchicine	1.5 h	Containers with soil, plants were covered to maintain high humidity	–	[116]
Parsley (Petroselinum crispum L.)	2n	about 30% (0.5, 24 h)	Seeds ex vitro on a rotary shaker at 120 rpm	0.25, 0.5, 1, 2 g/L colchicine	8–48 h	Seeds were planted in pots with soil mixture	Plant height is increased by 42% and leaf length is increased by 64% in 4n plants	[117]
		100% (1 g/L, 24 h)	Plant nodes in vitro on a rotary shaker at 120 rpm			MS with 0.001 g/L 2,4-D
Brassicaceae
Broccoli (Brassica oleracea var. italica)	n	50% (2 g/L, 6 h), 66.7% (1 g/L, 12 h)	In vitro seedling roots were trimmed to 1–2 cm length and immersed in colchicine	0.5, 1, 2, 4 g/L colchicine with 20 g/L DMSO	6–12 h	Containers with soil, plants were covered to maintain high humidity	Genome doubling recovered fertility (fertile DH and partially fertile mixoploids), high colchicine toxicity for broccoli was shown (from 50 (1 g/L, 6 h) to 100% (4 g/L, 9–12 h)	[41]
White cabbage (B. oleracea var. capitata L.)		50% (2 g/L, 9 h)			3–12 h
B. oleracea × leaf mustard B. juncea	2n ***	Best results for 1.5, 2 g/L	Rooted ex vitro cuttings axillary meristems were soaked in colchicine solution and covered with foil	0.5, 1, 1.5, 2, 2.5 g/L colchicine	Two treatments/day for 3 days	–	Genome doubling recovered fertility (7–84% pollen fertility), an increased main stem thickness and leaf size, more compact inflorescences, different leaf texture and margins compared to ABC hybrids and parents (no quantitative data)	[118]
Chinese cabbage (B. rapa) × white cabbage (B. oleracea), rapeseed (B. napus)/leaf mustard (B. juncea) × Chinese cabbage (B. rapa)	2n **	–	Plantlets in vitro	1 g/L colchicine	4 h	Plants were planted in coco-peat	The white cabbage with orange/yellow inner leaves (no quantitative data) and Chinese cabbage with an increased anthocyanin content (increased from 0 to 4.7 mg/g)	[119]
Cucurbitaceae
Cucumber (Cucumis sativus)	n	–	Cuttings with 2 axillary buds in E20H8 medium with colchicine	0.2 g/L colchicine	48 h	–	Genome doubling recovered fertility. A 40–80% mortality rate from colchicine treatment.	[120]
Cucumber (C. sativus)	n	24%	Haploid plants were on CBM basic medium with colchicine	0.2 g/L colchicine	96 h	The roots were rinsed in water. Then, the plants were grown in peat blocks	–	[107]
Melon (Cucumis melo)	n	–	The main apical stem	colchicine	2 h	–	–	[121]
Pumpkin (Cucurbita pepo)	n	–	Plantlets on a shaker at 120 rpm	5 g/L colchicine	12 h	–	–	[122]
			Apical shoot	10 g/L colchicine	3 1 h treatments per day
Watermelon (Citrullus lanatus)	2n	Over 60% (colchicine, ethalfluralin, oryzalin at the highest concentration, 9 days)	Shoot buds of in vitro plants in MS with antimitotics on a shaker	0.2, 0.4, 0.6, 0,8 g/L colchicine. Ethalfluralin, oryzalin, cobex, amex (25, 50, 75, 100 µM/L)	3, 6, 9 days	MS, 30 g/L sucrose, 7 g/L agar with 0.00225 g/L 6-BAP	–	[123]
	2n	–	Seedlings were immersed in colchicine aqueous solution	2 g/L colchicine	6 days	–	4n rootstocks are more tolerant to salt stress (minor withering at 300 mM NaCl, no quantitative data) due to lower Na+ /K+ ratio, higher photosynthetic capacity, antioxidant enzyme activity, and osmoregulatory gene expression	[124]
Solanaceae
African nightshade (Solanum nigrum ssp. villosum)	2n ****	about 10% (0.1 g/L)	Ex vitro seedlings at cotyledonary stage were sprayed with colchicine solution and covered with polyethylene sheets	0.1, 0.5, 2.5 g/L colchicine in 1 mL DMSO and 0.1 mL Tween-20	7 d, sprayed once a day	–	–	[125]
Cape gooseberry (Physalis peruviana)	n ****	over 60% (2 g/L, 2 h)	Excised axillary buds were immersed in colchicine solution in the dark	2, 4, 6 g/L colchicine with 20 g/L DMSO	2 h, 4 h, 6 h	MS, 0.1 mg/ L IBA	Recovery of fertility and seed production	[60]
Chili (C. annuum); Ancho chili × habanero chili (C. annuum × C. chinense)	n	–	Seedlings in vitro/ex vitro. Each seedling was immersed to the base of the stem in a bottle with colchicine solution	5 g/L colchicine	8 h	Pots with sterile substrate	Maintainers of cytoplasmic male sterility resistant to Phytophthora capsici Leo. and to the geminiviruses PepGMV and PHYVV were obtained	[126]
Chili (C. annuum)	2n	–	Seedlings at the 4-leaf stage	3 g/L colchicine	9 or 12 h for 2 days or 8 h for 3 days	–	4n plants exhibit gigas characters when compared to the 8n (leaf area 1.8 times larger; fruit diameter 2.7 times larger; flower diameter 1.6 times larger), except for the anthers, which are large, thick, sometimes deformed and coalesce with the corolla in the 8n plants. 8n plants were less vigorous.	[127]
Eggplant (Solanum melongena)	n	–	Plants in vitro	5–10 g/L colchicine	2 h (5 g/L); 1 h (10 g/L)	–	–	[17]
		25% more compared to SHGD	Plant axillary buds ex vitro	5 g/L colchicine in lanolin paste	48 h
	n	50–70%	Remove the apical and axillary buds from plantlets. Apply colchicine to secondary axillary buds in the dark	5 g/L colchicine in lanolin paste	48 h	Greenhouse conditions; remove shoots produced by untreated buds	–	[128]
	n	35%	2–3 leaf plantlets on ½ MS with colchicine	0.6 g/L colchicine	72 h	The plants were grown in peat blocks	–	[107]
	n	100%	Colchicine solution was applied to axillary buds with a piece of cotton in the dark	5 g/L	2 h	–	–	[129]
				10 g/L colchicine	1 h
	n	–	Plantlets in vitro	5 g/L	2 h	Hormone-free medium R	–	[130]
	n	–	Plantlets roots in vitro/ex vitro	0.1 g/L colchicine	4 h	The plants were acclimated and transferred to the greenhouse	–	[131]
Paprika (C. annuum)	n	95% on average	In vitro plantlets at 2–3-leaf stage in plain V3 medium with colchicine	10 g/L colchicine	1 h	Plastic pots containing 1:1 mixture of non-sterilized peat and sandy soil mix	–	[107,132]
Pepper (C. annuum)	n	50–95%	In vitro plantlets in V3 medium with colchicine	0.05–0.4 g/L colchicine	96–144 h	–	–	[133]
Pepper (C. annuum)	n	up to 100%	Axillary buds of ex vitro plants were covered with cotton soaked in colchicine and wrapped with foil	5 g/L colchicine	12 h	Colchicine applications were continued until chromosome doubling was achieved	–	[134]
Pepper (C. annuum)	n	–	Axillary buds of ex vitro plants were covered with a piece of cotton soaked in colchicine in the dark	0.5 g/L colchicine	2 h	–	–	[135]
Pepper (C. annuum)	n	57.6% and 47.3% 33% SHGD	Anthers	3 g/L colchicine	30 days	MS with supplements	Addition of colchicine to culture medium resulted with positive effects on viability of embryo, regeneration, and growth into full developed plantlets; haploid plants are smaller, plant viability, in vitro regeneration, development, and growth is lower compared to diploid donor plants	[55]
Pepper (C. annuum)	n	25–27% 2n, 29–55% mixoploids	The apical shoot fragment with 2–3 leaves in vitro	0.2, 0.4 g/L g/L colchicine	6–9 days	MSm, 30 g/L sucrose, 8 g/L agar, pH 5.8	Four weeks after the second colchicine treatment the growth disorder was observed, which proved to be directly proportional to the time of explant incubation on the colchicine-containing MS medium; after six days of colchicine treatment, 38% of the plants regenerated, and after nine days, their number decreased to 33%	[136]
Spice and bell pepper (C. annuum)	n	75%	4–6 leaf stage in vitro plantlets	3 g/L colchicine with 1.5 g/L DMSO	3 h	The roots were rinsed in water. Then, the plants were grown in peat blocks	–	[137]
F2 hybrids C. annuum L. (cv. Zdorovie) × C. chinense Jacq; BC2 of C. annuum L. (cv. Zdorovie) × C. chinense Jacq × cv. Zdorovie × cv. Zdorovie	n/2n	-	Apical meristem ex vitro plants	5 g/L colchicine with Tween-20 (1 drop/100 mL)	-	Plants were covered with polyethylene film to reduce evaporation	Fast generation of homozygous lines combining C. annuum L. and C. chinense Jacq traits. 17.5% were fertile and set seeds; fruit mass was 3 times larger than in C. chinense	[138]
Bell pepper, capia, charleston, and green types (C. annuum)	n	-	Ex vitro plants	5 g/L colchicine	2 h	Self-pollination was performed in at least 3–4 flowers. Three or four fruits were harvested from each self-pollinated plant, and their seeds were removed. Then, the seeds were labeled and packed.	Three homozygote pure lines with agronomically valuable traits, including Me1, Me3, N and Me7 nematode resistance genes, were obtained. Also, one homozygote pure line containing Me1 was found	[139]
Tomatillo (Physalis ixocarpa)	n	50% 2n, 50% 4n	Excised apical axillary buds from in vitro regenerants were inoculated on MS medium with colchicine	0.5, 1 g/L colchicine	2–6 days	MSD medium	–	[59]

Notes: * A. cepa 2n = 2x = 16; A. vavilovii, A. nutans, A. schoenoprasum are natural tetraploids 2n = 4x = 32. ** B. rapa 2n = 2x = 20, B. oleracea 2n = 2x = 18, B. napus 2n = 2x = 38, B. juncea 2n = 2x = 36. *** B. oleracea 2n = 2x = 18, B. juncea 2n = 2x = 36. **** the species is a natural tetraploid 2n = 4x: S. nigrum ssp. villosum 2n = 4x = 48; Physalis peruviana L. 2n = 4x = 48.
