Prosthesis, Volume 3, Issue 4 (December 2021) – 14 articles

This article describes the design of complete removable prostheses following the Slavicek philosophy, which involves the integration between condylographic data and an individual cephalometric study of the patient. The electronic condylograph is a device that records the mandibular movements made by the patient. This case report shows how condylography data are useful not only in the individual articulator setting, but also for diagnostic completion and for planning a functional prosthetic rehabilitation. Full article

A partial removable denture is a device that allows the patient to recover from a partial edentulism. This case report describes the realization of a chrome–cobalt partial removable denture by using two different realization methods: (1) analogic framework and (2) hybrid framework. This allowed us to compare the stability, retention as well as clasp quality of both the products and to highlight their respective advantages, disadvantages, and limitations. Full article

(1) Background: This paper presents a conceptual design for an anthropomorphic replacement hand made of silicone that integrates a sensory feedback system. In combination with a motorized orthosis, it allows performing movements and registering information on the flexion and the pressure of the fingers. (2) Methods: To create the replacement hand, a three-dimensional (3D) scanner was used to scan the hand of the test person. With computer-aided design (CAD), a mold was created from the hand, then 3D-printed. Bending and force sensors were attached to the mold before silicone casting to implement the sensory feedback system. To achieve a functional and anthropomorphic appearance of the replacement hand, a material analysis was carried out. In two different test series, the properties of the used silicones were analyzed regarding their mechanical properties and the manufacturing process. (3) Results: Individual fingers and an entire hand with integrated sensors were realized, which demonstrated in several tests that sensory feedback in such an anthropomorphic replacement hand can be realized. Nevertheless, the choice of silicone material remains an open challenge, as there is a trade-off between the hardness of the material and the maximum mechanical force of the orthosis. (4) Conclusion: Apart from manufacturing-related issues, it is possible to cost-effectively create a personalized, anthropomorphic replacement hand, including sensory feedback, by using 3D scanning and 3D printing techniques. Full article

The aim of this study was to evaluate the efficacy of activated irrigants (EDTA e NaOCL) during the cleansing of root walls, of the smear layer, of the debris, and gutta-percha after the preparation of the restorative space. Twenty single and multi-rooted (n = 20) have been collected. All samples were prepared by the same operator, using Nickel-titanium rotating instruments (Mtwo) through the Simultaneous Shaping Technique. The continuous-wave of condensation technique of obturation was used. To all specimens, the restorative space has been made, leaving 5 mm of apical gutta-percha, and postoperative periapical X-rays were performed. The samples were randomly divided into two groups: Group (A): cleansing of the root walls with ultrasonic activation of the irrigants (NEWTRON P5 XS; Satelec Acteon); Group (B): radicular walls wash without ultrasonic activation of endodontic irrigants (NaOCl 5.25% and EDTA 17%). Both dental sample groups were cut longitudinally with a low-speed saw (Isomet); the samples were observed by using a scanning electron microscope (Jeol, Jsm-6060LV) in order to evaluate: (1) the amount of debris/smear layer; (2) the mount of obstruction of dentinal tubules found in the two groups; and (3) evaluation of the presence of gutta-percha. Then, the other five samples each group (with and without ultrasonic activation) were prepared following the same protocol. Then, a universal bonding system (G-Praemio Bond, GC) and a layer of a flowable resin composite (Gaenial Flow, GC) were light-cured and used on top of the prepared root canal walls. The samples were cut in two pieces along the long axis of the root. Then, half sample teeth were kept in an acidic solution (37% HCl) for 48 h in order to completely dissolve dental structures and to have a direct view of resin tags formation under SEM. The other half was prepared to observe the adhesive interface under SEM. The amount of debris was not satisfactory in 9 out of 10 cases in Group B, while in Group A, which has been treated with ultrasounds, the result was either good or great in most of the samples. For the sample group treated with ultrasound, the tubules were evaluated as perfectly clean in 9 out of 10 cases, instead, the results are unsatisfactory for 9 out of 10 cases of group B not treated with ultrasound. Differences between Group A and B were statistically significant. With respect to the presence of debris and tubules obstruction treatment with ultrasonic activation, it offers with no doubt better results. When ultrasonic activation is used in combination with endodontic irrigants, a clean dentin substrate is be obtained for the adhesion of restorative materials, but in order to confirm the findings of this study, further in vivo trials are needed. Full article

Obtaining a good socket fit is an iterative process dependent on the skill and experience of the prosthetist creating it and requires individualisation based on the size and shape. There is no standard measurement system used to aid prosthetic socket creation despite the severe impacts on physical health and quality of life if one is ill fitting. Pressure sensors embedded in a prosthetic socket were used to collect data at the socket–residuum interface. To choose an interpolation method, the sensor array was simplified to a 2D grid with a border for extrapolation and tested using previously collected walking test pressure data. Four multivariable interpolation methods were evaluated to create a colour map of the pressure data. Radial basis function interpolation was chosen, as it produced a clear image with a graduated interpolation between data points, and was used to create a colour map across the surface of a 3D prosthetic socket model. For the model to be accessible to clinical audiences, a desktop application was created using PyQt to view the model. The application allowed for connection to the sensors via Bluetooth, with the pressure data updating on the 3D model in real time. Clinician feedback on the application showed the potential for a clinical product; however, further development informed by feedback from rehabilitation clinicians and prosthesis users is required. Full article

Patients with unrepaired cleft palate defects still exist within remote rural areas. The prosthodontic rehabilitation of an adult edentulous cleft patient could be very demanding for treating maxillofacial prosthodontist, since most of them are edentulous, challenging the retention and the stability of the maxillary prosthesis. It is therefore highly important that cleft palate patients seek dental and prosthodontic care as early in their life as possible. In this report, an unusual case of a patient self-obturated cleft palate defect is presented. The patient’s self-made prosthesis was replaced by an appropriately fabricated pharyngeal obturator prosthesis in order to improve speech and swallowing. Full article

Medical devices are highly regulated to ensure safety and efficacy of the products and minimize the risk of harm to users and patients. However, the broader impacts of these devices on the environment have scarcely been questioned until recently. The United Kingdom National Health Service intends to achieve a “net zero” emissions service by 2040 and has identified specific targets to achieve through this process. However, medical device manufacturers do not see sufficient incentives to invest in reducing greenhouse gas emissions unless enforced by legislation. Furthermore, there is little evidence on the legislation required to reduce emissions from medical devices. This study addresses the relationship of medical device regulations and the environmental impact of the devices throughout their lifecycle. A scoping review was conducted on academic literature on the topic, followed by a critical review of the current medical device regulations and associated guidelines in the United Kingdom. The challenges to regulating environmental impact of medical devices were identified under seven themes. These challenges were contextualized with the National Health Service target of achieving zero emissions by 2040. The review indicates that current guidelines support single-use disposal of devices and equipment as the best approach to prevent pathogen transmission and landfilling and incineration are the most used waste management strategies. Manufacturers need to be guided and educated on reducing their emissions while ensuring the development of safe and effective devices. Full article

Removable partial dentures (RPD) are still a valid alternative for the restoration of missing teeth. Additionally, implant-supported removable partial dentures (ISRPD) represent a valid alternative as it allows to avoid the use of clasps and increase stability. The objective of this study was to evaluate through an OHIP-14 questionnaire the level of satisfaction and quality of life (QoL) of patients treated before RPD and then with ISRPD. Twenty patients were rehabilitated with traditional RPDs, and after one year the prosthesis was modified into ISRPD, by inserting an implant and a ball or locator attachment. At the end of both phases, patients completed the Oral Health Impact Profile (OHIP-14) questionnaire. The collected data were statistically analyzed through the Wilcoxon U test, as overall OHIP score and difference between treatments. The mean of the OHIP summary (range from 0 to 56) in the RPD Group was 20.95 (±5.27). In the ISRPD Group it was 13.95 (±3.91), with a statistically significant difference (p < 0.05) between the two Groups. The same findings were highlighted for the differences between groups in every domain question. Patients showed significant improvements after rehabilitation in all areas of investigation, stating how the transformation of a removable prosthesis into an implant-supported one can improve patients’ QoL with benefits in chewing ability, aesthetics and self-satisfaction. Full article

The wear behaviour and chemical composition of orthodontic components influence the mechanical characteristics of a fixed orthodontic treatment. The purpose of this paper is to evaluate the surface alterations of different types of brackets (aesthetic, metallic, and conventional self-ligating) and archwires (superelastic and thermal) subjected to wear tests through optical microscopy and, subsequently, to identify the chemical elements of accessories by X-ray fluorescence. The cycles (5000 for each bracket and 10,000 for each wire) of the tribological test were carried out in dry conditions inside a machine that allows alternating sliding. The results of the study highlighted different wear behaviours even within the same type of brackets and archwires. The monocrystalline sapphire brackets maintain their aesthetic properties despite traces of wear inside the slots and contain minimal amounts of nickel. Superelastic NiTi archwires have a better overall rating than thermal wires, as they do not show significant surface wear alterations. Full article

The objective was to compare the repeatability between dental faculty, whose clinical practice was primarily restorative dentistry, and final year dental students in categorizing the inherent translucency of images selected at random using either a 3- or 7-point scale (translucent to opaque). Digital images of anterior dentition were randomly selected based on inherent translucency. Thirty images (five were repeated) were randomized and categorized by 20 dental students and 20 faculty on their inherent translucency. Statistical analysis was performed using an F test for analysis of variance at 95% confidence interval. A covariance parameter estimate (CPE) was accomplished to compare the inter-rater variability of the dental faculty and dental students. Statistically, more variability occurred between Slides (CPE of 0.185 (p = 0.001)) and between Subject and Slide (CPE of 0.122 (p = 0.0002)) than within subjects (CPE of 0.021 (p = 0.083)). Viewing repeat Slides, Students (CPE = 0.16) were more consistent (p < 0.05) than faculty (CPE = 1.8) using the 3- point scale, while the CPE was the same (CPE = 0.669) using 7-point scale. Dental students and faculty were consistent using the 7-point scale to judge repeat slides, while dental students in this limited pilot study were more consistent when viewing a repeat slide using the 3-point scale. Full article

Medical device regulations are dynamic, as they need to cover an ever changing landscape. In Europe this has led to a new set of regulations (both for Medical Devices and In Vitro Diagnostics), which replaced the old rules. This study is interested in how the complexity of these medical regulations changed over time and if additional time-based metrics can be associated with any of the complexity metrics. Complexity is defined in terms of readability of the text and it is computed using established linguistic measures, as well as Halstead complexity scores. It was shown that the regulatory complexity of new EU medical device regulations was higher than their predecessors, especially when Halstead complexity measures were considered. The complexity metrics obtained for the new regulations were subsequently associated with the time it took to consider these regulations. Only very weak Pearson’s correlation coefficients were found between the complexity scores and the obtained response times for the new regulations. This could indicate that there are issues with how complexity is perceived by those that need to apply these regulations. Taking the complexity of regulations into account can greatly help with the development of more user friendly regulations. The results from the data-driven methods that are applied in this research indicate that governments could benefit from focusing on making regulations more accessible and utilitarian. This would improve the stakeholder adherence and facilitate effective implementation. This work also highlighted the need to develop more suitable methods to analyse regulatory text to further inform the wider research community. Full article

The purpose of this study is to numerically analyze a 3D model of an implant under fatigue loads. A bone and a V shape implant were modeled using SolidWorks2008 software. In order to obtain an exact model, the bone was assumed as a linear orthotropic material. Mechanical loads were applied in terms of fastening torque to the abutment and mastication force applied at the top of the crown. The abutment was tightened into the implant by applying a 35 N.cm torque causing tensile stress within the abutment screw as a preload that is harmful not only for the fatigue life of the abutment, but also for the stability of the implant-abutment interface. A 700 N force at an angle of 30 degrees to the vertical direction was applied to the crown. The mechanical analysis results showed that the abutment is the critical component of the implant system in terms of fatigue failure. This is due to the fact that the tensile preloads originated from the fastening torque. The results were presented in terms of fatigue life in the abutment. Fatigue life of the abutment and implant were calculated based on the Goodman, Soderberg, Smith–Watson–Topper (SWT), and Marrow theories. According to the results of the fatigue life prediction, abutment screws may fail after about 3 × 10⁵ cycles. The predicted results by the Goodman theory are at a very good accordance with the clinical data. Full article

Functional, comfortable prosthetic limbs depend on personalised sockets, currently designed using an iterative, expert-led process, which can be expensive and inconvenient. Computer-aided design and manufacturing (CAD/CAM) offers enhanced repeatability, but far more use could be made from clinicians’ extensive digital design records. Knowledge-based socket design using smart templates could collate successful design features and tailor them to a new patient. Based on 67 residual limb scans and corresponding sockets, this paper develops a method of objectively analysing personalised design approaches by expert prosthetists, using machine learning: principal component analysis (PCA) to extract key categories in anatomic and surgical variation, and k-means clustering to identify local ‘rectification’ design features. Rectification patterns representing Total Surface Bearing and Patella Tendon Bearing design philosophies are identified automatically by PCA, which reveals trends in socket design choice for different limb shapes that match clinical guidelines. Expert design practice is quantified by measuring the size of local rectifications identified by k-means clustering. Implementing smart templates based on these trends requires clinical assessment by prosthetists and does not substitute training. This study provides methods for population-based socket design analysis, and example data, which will support developments in CAD/CAM clinical practice and accuracy of biomechanics research. Full article

Implants fracture is a rare but possible complication that leads to implants failure after prostheses delivery. Mechanical properties play a key role in the failure of dental implant systems. The aim of this narrative review was to evaluate the existing evidence in identifying etiology risk factors for implants fracture. The focused question was to evaluate whether there was any possible factors influencing the fracture of dental implants. A literature search of papers written in English, published from 1967 to July 2021, and reporting incidence of implants fracture in human with at least 15 participants (and one year of follow-up) was conducted using PubMed database including MeSH and free text terms and filters. Selected manuscripts were analyzed and discussed. The outcomes were the incidence of implants failure due to a fracture and the associated risk factors. A total of 96 articles were initially selected, but only eight articles were included according to the search criteria (two systematic reviews and six retrospective evaluation). Incidence of implants fracture ranged from 0.2 to 2.3%, with a mean value of 0.52%. Poor implant planning, including implant design and diameter, and occlusal overloading, were the most common variables associated with implants fracture. Implant removal is the only possible treatment and hence prevention, including stability of the marginal bone loss, is mandatory. Full article
