Search Results (15)

Beyond supporting ultra-high-capacity data transmission, metropolitan and access networks are expected to enable real-time infrastructure monitoring, driving the emergence of integrated sensing and communication (ISAC). Distributed acoustic sensing (DAS) has proven to be well-suited to urban sensing application requirements, yet its seamless integration into ISAC remains challenging—conventional high-peak-power sensing pulses in DAS induce nonlinear crosstalk in communication channels. DAS inherently suffers from interference fading due to single-frequency laser sources, which limits sensitivity. Here, we propose an ISAC architecture based on an electro-optic (EO) comb and a 7-core fiber, achieving nonlinearity-suppressed self-homodyne transmission and fading-suppressed DAS. Unmodulated comb lines and sensing pulses are polarization-multiplexed into orthogonal polarization states within the central core to minimize nonlinear crosstalk while delivering local oscillators (LOs) for wavelength division multiplexing (WDM) coherent transmission within six outer cores—achieving 10.56 Tbit/s capacity. In addition to supporting WDM transmission, the EO comb’s wavelength diversity is also exploited to enhance DAS performance. Specifically, a dual-pulse probe loaded onto four comb lines yields a 6 dB signal-to-noise ratio gain and a 64% reduction in fading occurrences, achieving a sensitivity of 1.72 $p\epsilon /\sqrt{\mathrm{Hz}}$ with 8 m spatial resolution. Moreover, our system supports simultaneous multi-wavelength backscatter detection in sensing and simplified digital signal processing in self-homodyne communication, reducing receiver complexity and cost. Our work presents a scalable, energy-efficient ISAC framework that unifies high-capacity communication with high-sensitivity sensing, providing a blueprint for future intelligent optical networks. Full article

The spatial response of rectangular pulse heterodyne phase-sensitive optical time-domain reflectometry ($\varphi$-OTDR) to an acoustic event is characterized by a windowing function rather than a point-like sensitivity. This effect degrades the system’s spatial resolution and introduces systematic errors in array signal processing. This work presents modeling analysis and a mitigation strategy for this fundamental limitation. The spatial windowing effect is modeled as a point spread function (PSF) derived from physical mechanisms and system parameters, including the pulse width, gauge length, and intra-pulse intensity dynamics. The PSF model is validated against measurements under near-ideal conditions using a fiber-coupled tuning fork. A Wiener filter-based deconvolution method is utilized to invert the windowed spatial response towards a point-like response. The effectiveness of this inversion is demonstrated through enhanced spatial resolution and accurate reconstruction of two-dimensional wavefront geometry. Furthermore, the impact of this effect on array signal processing is quantitatively evaluated. The results demonstrate that the proposed method effectively suppresses systematic errors in wavefield analysis, and specifically enhances the accuracy and confidence of steered response power—phase transform (SRP-PHAT) spatial spectrum estimation. This study provides a systematic framework for understanding, quantifying, and inverting the spatial response in $\varphi$-OTDR, enabling accurate and interpretable acoustic field sensing. Full article

This paper presents hardware-efficient phase demodulation schemes for FPGA-based digital phase-sensitive optical time-domain reflectometry ($\varphi$-OTDR) receivers. We first derive a signal model for the heterodyne $\varphi$-OTDR frontend, then propose and analyze three demodulation methods: (1) a baseband reconstruction approach via zero-IF downconversion, (2) an analytic signal generation technique using the Hilbert transform (HT), and (3) a wavelet transform (WT)-based alternative for analytic signal extraction. Algorithm-hardware co-design implementations are detailed for both RFSoC and conventional FPGA platforms, with resource utilization comparisons. Additionally, we introduce an incremental DC-rejected phase unwrapper (IDRPU) algorithm to jointly address phase unwrapping and DC drift removal, minimizing computational overhead while avoiding numerical overflow. Experiments on simulated and real-world $\varphi$-OTDR data show that the HT method matches the performance of zero-IF demodulation with simpler hardware and lower resource usage, while the WT method offers enhanced robustness against fading noise (3.35–22.47 dB SNR improvement in fading conditions), albeit with slightly ambiguous event boundaries and higher hardware utilization. These findings provide actionable insights for demodulator design in distributed acoustic sensing (DAS) applications and advance the development of single-chip DAS systems. Full article

This article adds to the emergent body of research that examines the potential of 6G as a platform that can combine wired and wireless sensing modalities. We apply vision transformers (ViTs) in a distributed fiber-optic sensing system to evaluate road traffic parameters in smart cities. Convolutional neural networks (CNNs) are also assessed for benchmarking. The experimental setup is based on a direct-detection phase-sensitive optical time-domain reflectometer ($\varphi$-OTDR) implemented using a narrow linewidth source. The monitored fibers are buried on the university campus, creating a smart city environment. Backscattered traces are consolidated into space–time matrices, illustrating traffic patterns and enabling analysis through image processing algorithms. The ground truth is established by traffic parameters obtained by processing video camera images monitoring the same street using the YOLOv8 model. The results indicate that ViTs outperform CNNs for estimating the number of vehicles and the mean vehicle speed. While a ViT necessitates a significantly larger number of parameters, its complexity is similar to that of a CNN when considering multiply–accumulate operations and random access memory usage. The processed dataset has been made publicly available for benchmarking. Full article

Distributed Acoustic Sensing (DAS) has emerged as a groundbreaking technology in seismology, transforming fiber-optic cables into dense, cost-effective seismic monitoring arrays. DAS makes use of Rayleigh backscattering to detect and measure dynamic strain and vibrations over extended distances. It can operate using both pre-existing telecommunication networks and specially designed fibers. This review explores the principles of DAS, including Coherent Optical Time Domain Reflectometry (COTDR) and Phase-Sensitive OTDR (ϕ-OTDR), and discusses the role of optoelectronic interrogators in data acquisition. It examines recent advancements in fiber design, such as helically wound and engineered fibers, which improve DAS sensitivity, spatial resolution, and the signal-to-noise ratio (SNR). Additionally, innovations in deployment techniques include cemented borehole cables, flexible liners, and weighted surface coupling to further enhance mechanical coupling and data accuracy. This review also demonstrated the applications of DAS across earthquake detection, microseismic monitoring, reservoir characterization and monitoring, carbon storage sites, geothermal reservoirs, marine environments, and urban infrastructure surveillance. The study highlighted several challenges of DAS, including directional sensitivity limitations, vast data volumes, and calibration inconsistencies. It also addressed solutions to these problems, such as advances in signal processing, noise suppression techniques, and machine learning integration, which have improved real-time analysis and data interpretability, enabling DAS to compete with traditional seismic networks. Additionally, modeling approaches such as full waveform inversion and forward simulations provide valuable insights into subsurface dynamics and fracture monitoring. This review highlights DAS’s potential to revolutionize seismic monitoring through its scalability, cost-efficiency, and adaptability to diverse applications while identifying future research directions to address its limitations and expand its capabilities. Full article

In this paper, we propose and demonstrate a damage detection technique based on the automatic classification of the Lamb wave signals acquired on a metallic plate. In the reported experiments, Lamb waves are excited in an aluminum plate through a piezoelectric transducer glued onto the monitored structure. The response of the monitored structure is detected through a high-resolution phase-sensitive optical time-domain reflectometer (ϕ-OTDR). The presence and location of a small perturbation, induced by placing a lumped mass of 5 g on the plate, are determined by processing the optical fiber sensor data through support vector machine (SVM) classifiers trained with experimental data. The results show that the proposed method takes full advantage of the multipoint sensing nature of the ϕ-OTDR technology, resulting in accurate damage detection and localization. Full article

In this paper, the use of a phase-sensitive optical time-domain reflectometry (ϕ-OTDR) sensor for the detection of the Lamb waves excited by a piezoelectric transducer in an aluminum plate, is investigated. The system is shown to detect and resolve the Lamb wave in distinct regions of the plate, opening the possibility of realizing structural health monitoring (SHM) and damage detection using a single optical fiber attached to the structure. The system also reveals the variations in the Lamb wave resulting from a change in the load conditions of the plate. The same optical fiber used to detect the Lamb waves has also been employed to realize distributed strain measurements using a Brillouin scattering system. The method can be potentially used to replace conventional SHM sensors such as strain gauges and PZT transducers, with the advantage of offering several sensing points using a single fiber. Full article

We demonstrate the use of a graded-index perfluorinated optical fiber (GI-POF) for distributed static and dynamic strain measurements based on Rayleigh scattering. The system is based on an amplitude-based phase-sensitive Optical Time-Domain Reflectometry (ϕ-OTDR) configuration, operated at the unconventional wavelength of 850 nm. Static strain measurements have been carried out at a spatial resolution of 4 m and for a strain up to 3.5% by exploiting the increase of the backscatter Rayleigh coefficient consequent to the application of a tensile strain, while vibration/acoustic measurements have been demonstrated for a sampling frequency up to 833 Hz by exploiting the vibration-induced changes in the backscatter Rayleigh intensity time-domain traces arising from coherent interference within the pulse. The reported tests demonstrate that polymer optical fibers can be used for cost-effective multiparameter sensing. Full article

The distributed long-range sensing system, using the standard telecommunication single-mode optical fiber for the distributed sensing of mechanical vibrations, is described. Various events generating vibrations, such as a walking or running person, moving car, train, and many other vibration sources, can be detected, localized, and classified. The sensor is based on phase-sensitive optical time-domain reflectometry (ϕ-OTDR). Related sensing system components were designed and constructed, and the system was tested both in the laboratory and in the real deployment, with an 88 km telecom optical link, and the results are presented in this paper. A two-fiber sensor unit, with a double-sensing range was also designed, and its scheme is described. The unit was constructed and the initial measurement results are presented. Full article

We present a new pipeline integrity surveillance system for long gas pipeline threat detection and classification. The system is based on distributed acoustic sensing with phase-sensitive optical time domain reflectometry ($\varphi$-OTDR) and pattern recognition for event classification. The proposal incorporates a multi-position approach in a Gaussian Mixture Model (GMM)-based pattern classification system which operates in a real-field scenario with a thorough experimental procedure. The objective is exploiting the availability of vibration-related data at positions nearby the one actually producing the main disturbance to improve the robustness of the trained models. The system integrates two classification tasks: (1) machine + activity identification, which identifies the machine that is working over the pipeline along with the activity being carried out, and (2) threat detection, which aims to detect suspicious threats for the pipeline integrity (independently of the activity being carried out). For the machine + activity identification mode, the multi-position approach for model training obtains better performance than the previously presented single-position approach for activities that show consistent behavior and high energy (between 6% and 11% absolute) with an overall increase of 3% absolute in the classification accuracy. For the threat detection mode, the proposed approach gets an 8% absolute reduction in the false alarm rate with an overall increase of 4.5% absolute in the classification accuracy. Full article

Until recently, the amount of solar irradiance reaching the Earth surface was considered to be a steady value over the years. However, there is increasing observational evidence showing that this quantity undergoes substantial variations over time, which need to be addressed in different scenarios ranging from climate change to solar energy applications. With the growing interest in developing solar energy technology with enhanced efficiency and optimized management, the monitoring of solar irradiance at the ground level is now considered to be a fundamental input in the pursuit of that goal. Here, we propose the first fiber-based distributed sensor able of monitoring ground solar irradiance in real time, with meter scale spatial resolutions over distances of several tens of kilometers (up to 100 km). The technique is based on an optical fiber reflectometry technique (CP-ϕOTDR), which enables real time and long-range high-sensitivity bolometric measurements of solar radiance with a single optical fiber cable and a single interrogator unit. The method is explained and analyzed theoretically. A validation of the method is proposed using a solar simulator irradiating standard optical fibers, where we demonstrate the ability to detect and quantify solar irradiance with less than a 0.1 W/m² resolution. Full article

A pulse-width multiplexing method for reducing the nuisance-alarm rate of a phase-sensitive optical time-domain reflectometer ( $\varphi$ -OTDR) is described. In this method, light pulses of different pulse-widths are injected into the sensing fiber; the data acquired at different pulse-widths are regarded as the outputs of different sensors; and these data are then processed by a multisensor data fusion algorithm. In laboratory tests with a sensing fiber on a vibrating table, the effects of pulse-width on the signal-to-noise ratio (SNR) of the $\varphi$ -OTDR data are observed. Furthermore, by utilizing the SNR as the feature in a feature-layer algorithm based on Dempster–Shafer evidential theory, a four-pulse-width multiplexing $\varphi$ -OTDR system is constructed, and the nuisance-alarm rate is reduced by about 70%. These experimental results show that the proposed method has great potential for perimeter protection, since the nuisance-alarm rate is significantly reduced by using a simple configuration. Full article

There is an increasing interest in researchers and companies on the combination of Distributed Acoustic Sensing (DAS) and a Pattern Recognition System (PRS) to detect and classify potentially dangerous events that occur in areas above fiber optic cables deployed along active pipelines, aiming to construct pipeline surveillance systems. This paper presents a review of the literature in what respect to machine learning techniques applied to pipeline surveillance systems based on DAS+PRS (although its scope can also be extended to any other environment in which DAS+PRS strategies are to be used). To do so, we describe the fundamentals of the machine learning approaches when applied to DAS systems, and also do a detailed literature review of the main contributions on this topic. Additionally, this paper addresses the most common issues related to real field deployment and evaluation of DAS+PRS for pipeline threat monitoring, and intends to provide useful insights and recommendations in what respect to the design of such systems. The literature review concludes that a real field deployment of a PRS based on DAS technology is still a challenging area of research, far from being fully solved. Full article

Distributed vibration sensing based on phase-sensitive optical time domain reflectometry ( $\varphi$ -OTDR) is being widely used in several applications. However, one of the main challenges in coherent detection-based $\varphi$ -OTDR systems is the fading noise, which impacts the detection performance. In addition, typical signal averaging and differentiating techniques are not suitable for detecting high frequency events. This paper presents a new approach for reducing the effect of fading noise in fiber optic distributed acoustic vibration sensing systems without any impact on the frequency response of the detection system. The method is based on temporal adaptive processing of $\varphi$ -OTDR signals. The fundamental theory underlying the algorithm, which is based on signal-to-noise ratio (SNR) maximization, is presented, and the efficacy of our algorithm is demonstrated with laboratory experiments and field tests. With the proposed digital processing technique, the results show that more than 10 dB of SNR values can be achieved without any reduction in the system bandwidth and without using additional optical amplifier stages in the hardware. We believe that our proposed adaptive processing approach can be effectively used to develop fiber optic-based distributed acoustic vibration sensing systems. Full article

This paper presents a novel surveillance system aimed at the detection and classification of threats in the vicinity of a long gas pipeline. The sensing system is based on phase-sensitive optical time domain reflectometry (ϕ-OTDR) technology for signal acquisition and pattern recognition strategies for threat identification. The proposal incorporates contextual information at the feature level and applies a system combination strategy for pattern classification. The contextual information at the feature level is based on the tandem approach (using feature representations produced by discriminatively-trained multi-layer perceptrons) by employing feature vectors that spread different temporal contexts. The system combination strategy is based on a posterior combination of likelihoods computed from different pattern classification processes. The system operates in two different modes: (1) machine + activity identification, which recognizes the activity being carried out by a certain machine, and (2) threat detection, aimed at detecting threats no matter what the real activity being conducted is. In comparison with a previous system based on the same rigorous experimental setup, the results show that the system combination from the contextual feature information improves the results for each individual class in both operational modes, as well as the overall classification accuracy, with statistically-significant improvements. Full article
