Smart transformers (STs), which are power electronic-based transformers with control and communication capabilities, facilitate managing future distribution grids with distributed generators (DGs) and battery energy storage systems (BESSs). This paper presents a current-fed quadruple active-bridge (CF-QAB) DC–DC converters-based cascaded H-bridge (CHB) ST architecture in which it is easy to coordinate the system-level power transmission and distribution. Compared with the QAB/DAB + Boost baseline, this topology achieves a reduction of approximately 20% in device count. For the core component of the proposed ST architecture, the operation principles are illustrated and the small-signal model is derived. Based on that, the control system obtained by using the individual channel design method is proposed to decouple the highly coupled LV and BESS DC ports, which significantly simplify the control system structure and design process. The experimental results are shown to validate the effectiveness of the proposed DC–DC converter and associated control system. Full article

Aiming at the challenges of design complexity and parameter adjustment difficulties in existing distributed controllers, a novel power flow sensitivity-based distributed cooperative control approach is proposed for voltage regulation and power sharing in droop-controlled DC distribution networks (DCDNs). Firstly, based on the power flow model of droop-controlled DCDNs, a comprehensive sensitivity model is established that correlates bus voltages, voltage source converter (VSC) loading rates, and VSC reference power adjustments. Leveraging the sensitivity model, a discrete-time linear state-space model is developed for DCDNs, using all VSC reference power as control variables, along with the weighted sum of the voltage deviation at the VSC connection point and the loading rate deviation of adjacent VSCs as state variables. A distributed consensus controller is then designed to alleviate the communication burden. The feedback gain design problem is formulated as an unconstrained multi-objective optimization model, which simultaneously enhances dynamic response speed, suppresses overshoot and oscillation, and ensures stability. The model can be efficiently solved by global optimization algorithms such as the genetic algorithm, and the feedback gains can be designed in a systematic and principled manner. The simulation results on a typical four-terminal DCDN under large power disturbances demonstrate that the proposed distributed control method achieves rapid voltage recovery and converter load sharing under a sparse communication network. The design complexity and parameter adjustment difficulties are greatly reduced without losing the control performance. Full article

Large-scale integration of distributed energy resources (DERs) into distribution networks causes topological-operational situations with multidirectional power flows. One of the main components of distribution networks is the power transformer, which does not have the capabilities for real-time control of distribution network parameters with DERs. The use of solid-state transformers (SSTs) for connecting medium-voltage (MV) and low-voltage (LV) distribution networks of both alternating and direct current has great potential for constructing new distribution networks and enhancing the existing ones. Electricity losses in distribution networks can be reduced through the establishment of MV and LV DC networks. In hybrid AC-DC distribution networks, the SSTs can be especially effective, ensuring compensation for voltage dips, fluctuations, and interruptions; regulation of voltage, current, frequency, and power factor in LV networks; and reduction in the levels of harmonic current and voltage due to the presence of power electronic converters (PECs) and capacitors in the DC link. To control the operating parameters of hybrid distribution networks with solid-state transformers, it is crucial to develop and implement advanced control systems (CSs). The purpose of this review is a comprehensive analysis of the features of the creation of CSs SSTs when they are used in hybrid distribution networks with DERs to identify the most effective principles and methods for managing SSTs of different designs, which will accelerate the development and implementation of CSs. This review focuses on the design principles and control strategies for SSTs, guided by their architecture and intended functionality. The architecture of the solid-state transformer control system is presented with a detailed description of the main stages of control. In addition, the features of the SST CS operating under various topologies and operating conditions of distribution networks are examined. Full article

Capacitor voltage imbalance among submodules in energy storage modular multilevel converters (MMCs) can lead to current distortion, power oscillations, and even system instability. Traditional voltage control strategies, inherited from non-storage MMCs, offer limited regulation capabilities and are insufficient to address the complex balancing requirements across phases, arms, and submodules in distributed Energy-Storage MMCs (ES-MMC). This paper proposes a self-synchronized common-mode current strategy to achieve capacitor voltage rebalancing in Carrier Phase-Shifted PWM (CPS-PWM) modulated ES-MMCs. The proposed method establishes both phase-level and arm-level power rebalancing pathways by utilizing the common-mode current in the upper and lower arms. Specifically, the DC component of the common-mode current is employed to regulate common-mode power between the arms, while the fundamental-frequency component, through its interaction with the fundamental modulation voltage, is used to adjust differential-mode power. By coordinating these two power components within each phase, the method enables effective capacitor voltage rebalancing among submodules in the presence of power imbalance caused by a nonuniform distributed energy storage converter. A comprehensive analysis of differential- and common-mode voltage regulation under CPS-PWM is presented. The corresponding control algorithm is developed to inject adaptive common-mode voltage based on capacitor voltage deviations, thereby inducing self-synchronized balancing currents. Simulation and experimental results verify that the proposed strategy significantly improves power distribution uniformity and reduces capacitor voltage deviations under various load and disturbance conditions. Full article

Given the climate change observed in the past few decades, sustainable development and the use of renewable energy sources are urgent. In this scenario, hydrogen production through electrolyzers is a promising renewable source and energy vector because of its ultralow greenhouse emissions and high energy content. Hydrogen can be used in a variety of applications, from transportation to electricity generation, contributing to the diversification of the energy matrix. In this context, this paper presents an autonomous isolated DC microgrid system for generating and storing electrical energy to be exclusively used for feeding an electrolyzer hydrogen production plant, which has been retrofitted for green hydrogen production. Experimental verification was performed at Itaipu Parquetec, which consists of an alkaline electrolysis unit directly integrated with a battery energy storage system and renewable sources (e.g., photovoltaic and wind) by using an isolated DC microgrid concept based on DC/DC and AC/DC converters. Experimental results revealed that the new electrolyzer DC microgrid increases the system’s overall efficiency in comparison to the legacy thyristor-based power supply system by 26%, and it autonomously controls the energy supply to the electrolyzer under optimized conditions with an extremely low output current ripple. Another advantage of the proposed DC microgrid is its ability to properly manage the startup and shutdown process of the electrolyzer plant under power generation outages. This paper is the result of activities carried out under the R&D project of ANEEL program No. PD-10381-0221/2021, entitled “Multiport DC-DC Converter and IoT System for Intelligent Energy Management”, which was conducted in partnership with CTG-Brazil. Full article

High penetration of Inverter-Based Resources (IBRs) into the power grid could diminish the rotational inertia offered by a traditional power system and thus impact frequency stability. Several techniques are adopted to provide virtual inertial support to the grid for a short duration in the presence of IBRs. This paper uses the combined inertia support of a Dual Active Bridge (DAB) and a Voltage Source Converter (VSC)-fed Electric Vehicle Fast Charging System (EVFCS) is used to provide virtual inertia support to the grid. The Voltage Source Converter is designed to provide DC bus voltage regulation. Coordinated control of DAB converters and VSCs for mitigating frequency oscillations using cascaded droop-integrated Proportional Integral (PI) controllers is proposed. An aggregated low-frequency model of a DAB converter is considered in this work. The inertia of the DC link capacitor of the VSCs and battery is sequentially extracted to offer grid frequency support. In this work, the single droop control, dual droop control, grid-forming and Augmented Frequency Support (AFS) modes are explored to provide virtual inertia support to the grid. Full article

This article introduces a quadratic boost converter topology that has a low input current ripple compared to other quadratic boost traditional topologies. The proposed converter is inspired by the LCL filter; one of the inductors in the traditional converter is split into two inductors and a capacitor. The proposed converter has more components than its previous version, but two of its inductors are equivalent to the second inductor in the traditional quadratic boost, providing a non-increase in the size while reducing the switching ripple at the input current. These findings suggest that the proposed design is a viable alternative for applications where a quadratic gain is required while a small input current ripple is desirable. A comparative evaluation with a design showed the proposed converter reduced 20% in the stored energy of inductors and still has a reduction of more than 40% in the input current ripple. Simulation and experimental results are provided to demonstrate the principle of the proposition. Full article

One of the main challenges faced by DC microgrid (DCMG) is their low inertia, which leads to rapid and significant voltage fluctuations during load or generation changes. These fluctuations can negatively impact sensitive loads and protection devices. Previous studies have addressed this by enabling battery converters to mimic the behavior of synchronous generators (SGs), but this approach becomes ineffective when the converters or batteries reach their current or energy limits, leading to a loss of inertia and potential system instability. In interconnected multi-microgrid (MMG) systems, the presence of multiple batteries offers the potential to enhance system inertia, provided there is a coordinated control strategy. This research introduces a hierarchical control method that combines decentralized and centralized approaches. Decentralized control allows individual converters to emulate SG behavior, while the centralized control uses Internet of Things (IoT) technology to enable real-time coordination among all Energy Storage Units (ESUs). This coordination improves inertia across the DCMMG system, enhances energy management, and strengthens overall system stability. IoT integration ensures real-time data exchange, monitoring, and collaborative decision-making. The proposed scheme is validated through MATLAB simulations, with results confirming its effectiveness in improving inertial response and supporting the integration of renewable energy sources within DCMMGs. Full article

Light-emitting diodes (LEDs) have gained widespread adoption as solid-state lighting sources due to their compact size, long operational lifetime, high brightness, and mechanical robustness. This paper presents the development and implementation of an isolated AC-DC LED electronic lighting driver circuit that integrates a modified flyback converter with a lossless snubber circuit, along with inherent power factor correction (PFC). The proposed design operates the transformer’s magnetizing inductor in the discontinuous conduction mode (DCM), thereby naturally achieving PFC without the need for complex control circuitry. Furthermore, the circuit is capable of recycling the energy stored in the transformer’s leakage inductance, improving overall efficiency. The input current harmonics are shown to comply with the IEC 61000-3-2 Class C standard. A 72 W (36 V/2 A) prototype has been constructed and tested under a 110 V AC input. Experimental results confirm the effectiveness of the proposed design, achieving a power factor of 0.9816, a total harmonic distortion (THD) of 12.094%, an output voltage ripple factor of 9.7%, and an output current ripple factor of 11.22%. These results validate the performance and practical viability of the proposed LED driver architecture. Full article

The electrification of automotive powertrains has accelerated research efforts in the modeling, control, and monitoring of electric drive systems, where reliability, safety, and efficiency are key enablers for mass adoption. Despite a large corpus of literature addressing individual aspects of electric drives, current surveys remain fragmented, typically focusing on either multiphysics modeling of machines and converters, or advanced control algorithms, or diagnostic and prognostic frameworks. This review provides a comprehensive perspective that systematically integrates these domains, establishing direct connections between high-fidelity models, control design, and monitoring architectures. Starting from the fundamental components of the automotive power drive system, the paper reviews state-of-the-art strategies for synchronous motor modeling, inverter and DC/DC converter design, and advanced control schemes, before presenting monitoring techniques that span model-based residual generation, AI-driven fault classification, and hybrid approaches. Particular emphasis is given to the interplay between functional safety (ISO 26262), computational feasibility on embedded platforms, and the need for explainable and certifiable monitoring frameworks. By aligning modeling, control, and monitoring perspectives within a unified narrative, this review identifies the methodological gaps that hinder cross-domain integration and outlines pathways toward digital-twin-enabled prognostics and health management of automotive electric drives. Full article

This paper presents a robust and computationally efficient fault classification framework for wind energy conversion systems (WECS), built upon a Robust Random Vector Functional Link Network (Robust-RVFLN) and validated through real-time simulations on a Real-Time Digital Simulator (RTDS). Unlike existing studies that depend on high-dimensional feature extraction or purely data-driven deep learning models, our approach leverages a compact set of five statistically significant and physically interpretable features derived from rotor torque, phase current, DC-link voltage, and dq-axis current components. This reduced feature set ensures both high discriminative power and low computational overhead, enabling effective deployment in resource-constrained edge devices and large-scale wind farms. A synthesized dataset representing seven representative fault scenarios—including converter, generator, gearbox, and grid faults—was employed to evaluate the model. Comparative analysis shows that the Robust-RVFLN consistently outperforms conventional classifiers (SVM, ELM) and deep models (CNN, LSTM), delivering accuracy rates of up to 99.85% for grid-side line-to-ground faults and 99.81% for generator faults. Beyond accuracy, evaluation metrics such as precision, recall, and F1-score further validate its robustness under transient operating conditions. By uniting interpretability, scalability, and real-time performance, the proposed framework addresses critical challenges in condition monitoring and predictive maintenance, offering a practical and transferable solution for next-generation renewable energy infrastructures. Full article

Hybrid cascaded multi-terminal HVDC systems represent a significant advancement in HVDC transmission technology. A notable real-world implementation of this concept is the bipolar hybrid cascaded multi-terminal high voltage direct current (MTDC) project in China, which successfully transmits hydropower from Baihetan to Jiangsu. This system combines MMCs for system support with LCCs for high-power transmission, offering both flexibility and efficiency in long-distance power delivery. This research explores the characteristics of main DC fault types in such systems, classifying faults based on sections and modes while analyzing their unique outcomes depending on DC fault locations. By focusing on the DC-side terminal behavior of the MMCs and LCCs, the main response processes to asymmetrical DC faults are investigated in detail. This study offers a detailed analysis of asymmetrical DC faults in bipolar HVDC systems, proposing a new classification based on fault characteristics such as current, voltage, active power, and reactive power. A supporting theoretical analysis is also presented. It identifies specific control demands needed for effective fault mitigation. PSCAD/EMTDC simulation results demonstrate that DC faults with similar characteristics can be consistently grouped into distinct categories by this new classification method. Each category is further linked to specific control demands, providing a strong basis for developing advanced protection strategies and practical solutions that enhance the stability and reliability of hybrid cascaded HVDC systems. Full article

This study presents a comparative analysis of efficiency and harmonic generation in Triple Active Bridge (TAB) converters under two operating configurations: Case I, with one input source and two loads, and Case II, with two input sources and one load. Two modulation strategies, Single-Phase Shift (SPS) and Dual-Phase Shift (DPS), are evaluated through frequency-domain modeling and simulations performed in MATLAB/Simulink. The analysis is complemented by experimental validation on a laboratory prototype. The results show that DPS reduces harmonic amplitudes, decreases conduction losses, and improves output waveform quality, leading to higher efficiency compared to SPS. Harmonic current spectra and total harmonic distortion (THD) are analyzed to quantify the impact of each modulation method. The findings highlight that DPS is more suitable for applications requiring stable power transfer and improved efficiency, such as renewable energy systems, electric vehicles, and multi-source DC microgrids. Full article

Within the modernizing energy infrastructure of today, the integration of renewable energy sources and direct current (DC)-powered technologies calls for the re-examination of traditional alternative current (AC) networks. Low-voltage DC (LVDC) grids offer an attractive way forward in reducing conversion losses and simplifying local power management. However, ensuring reliable operation depends on a thorough understanding of DC distortions—phenomena generated by power converters, source instability, and varying loads. Two complementary traceable measurement chains are presented in this article with the purpose of measuring the steady-state DC component and the amplitude and frequency of the distortions around the DC bus with low uncertainties. One chain is optimized for laboratory environments, with high effectiveness in a controlled setup, and the other one is designed as a flexible and easily transportable solution, ensuring efficient and accurate assessments of DC distortions for field applications. In addition to our hardware solutions fully characterized by the uncertainty budget, we present the measurement method used for assessing DC distortions after evaluating the limitations of conventional AC techniques. Both arrangements are set to measure voltages of up to 1000 V, currents of up to 30 A, and frequency components of up to 150–500 kHz, with an uncertainty varying from 0.01% to less than 1%. This level of accuracy in the measurements will allow us to draw reliable conclusions regarding the dynamic behavior of future LVDC grids. Full article

A radiation-hardened RCC (Ring Choke Converter) isolated power supply design is proposed, which provides an innovative solution to the challenge of providing stable power to the PWM controller in DC-DC converters under nuclear radiation environments. By optimizing circuit architecture and component selection, and incorporating transformer isolation and dynamic parameter compensation technology, the RCC maintains an 8.9 V output voltage after exposure to neutron irradiation of 3 × 10¹³ n/cm², significantly outperforming conventional designs with a failure threshold of 1 × 10¹³ n/cm². For the first time, the degradation mechanisms of VDMOS devices under neutron irradiation during switching operations are systematically revealed: a 32–36% reduction in threshold voltage (with the main power transistor dropping from 5 V to 3.4 V) and an increase in on-resistance. Based on these findings, a selection criterion for power transistors is established, enabling the power supply to achieve a 2 W output in extreme environments such as nuclear power plant monitoring and satellite systems. The results provide a comprehensive solution for radiation-hardened power electronics systems, covering device characteristic analysis to circuit optimization, with significant engineering application value. Full article
