High-voltage DC (HVDC) power supplies are essential for several advanced applications, including medical imaging, aerospace systems, and additive manufacturing. Traditional HVDC supplies often suffer from performance limitations due to high transformer turn ratios, which increased stray capacitance and degraded inverter performance. This paper proposes a novel two-stage HVDC power supply architecture that addresses these challenges by combining a Z-source converter with a full-bridge inverter, both enabled by high-performance Silicon Carbide (SiC) devices. The first stage boosts the rectified line voltage to 2 kV using a Z-source topology and inverts it at high frequency, while the second stage employs a high-voltage, high-frequency (HVHF) transformer and a voltage doubler to achieve a regulated 10 kV DC output. Simulation results using PLECS and experimental validation demonstrate the effectiveness of the proposed design in minimizing the reflected capacitance, enabling constant-frequency operation at the boundary of continuous conduction mode for improved efficiency, and providing high power density and compactness. This approach offers a promising solution for high-efficiency, high-voltage applications. Full article

A triple active bridge (TAB) converter used for simultaneous fast charging of two dissimilar EVs can exhibit significant circulating power under asymmetric port voltages and power levels. This internal power exchange increases losses and current stress and limits the effectiveness of conventional magnetic design optimization. This paper develops a generalized five-variable phase-shift model of the TAB and formulates explicit zero-circulating-power conditions that characterize non-circulating operating points in asymmetric dual-EV charging. Based on this formulation, a decoupled control law is synthesized that assigns the five phase-shift variables to suppress circulating power while independently regulating the power delivered to each EV port over a wide operating range, without requiring specialized transformer or leakage-inductance design. Results from representative dynamic dual-EV charging scenarios demonstrate 15% reduction in RMS current stress compared with conventional phase-shift control. Full article

The intermittent nature of renewable power sources, nonlinear load effects, and harmonic distortions induced by power electronic converters complicate the maintenance of high energy quality in microgrid-connected hybrid renewable power systems. In a range of operating conditions, conventional strategies-including fractional-order proportional-integral (FOPI) controllers-frequently prove ineffective in delivering both robust harmonic mitigation and expeditious dynamic response. To surmount these constraints, the present paper puts forth an intelligent control solution that is predicated on a fractional-order fuzzy logic (FOFL). The FOFL is integrated into a multi-converter HRPS, comprising a photovoltaic generator, a lithium-ion battery power storage system, and a wind turbine equipped with a permanent magnet synchronous generator. A multifunctional voltage source inverter has been developed to control these parts, which are interfaced via a common DC bus. Through the implementation of MATLAB 2021 simulation studies, the efficacy of the suggested algorithm is verified and evaluated in comparison to the FOPI. The findings indicate that the FOFL enhances system efficacy by minimizing harmonic distortion, improving energy quality, and achieving a faster dynamic response under various circumstances. In the context of grid-connected microgrid environments, the FOFL has been demonstrated to offer superior overall energy management, robustness, and adaptability when compared to other evaluated strategies. Full article

To address fault-period DC-link overvoltage, the reduction in grid-side active-power regulation margin caused by reactive-current-priority operation, and the double-frequency current fluctuation induced by negative-sequence components under asymmetrical grid faults in a flywheel-assisted permanent-magnet direct-drive wind power system, this paper proposes a coordinated low-voltage ride-through (LVRT) strategy based on DC-link-voltage-threshold partitioning. According to the DC-link voltage level, the operating process is divided into a normal regulation region, a grid-side saturation region, and a flywheel activation region, thereby enabling coordinated regulation between grid-side reactive-current support and flywheel-side active-power absorption. To improve transient smoothness, an anti-windup mechanism together with a bumpless transfer scheme is incorporated into the coordinated control process to suppress integrator saturation and mitigate mode-transition disturbances. In addition, a grid-side proportional–integral–vector resonant controller (PI-VRC) is introduced to improve the suppression of double-frequency current fluctuation under asymmetrical faults and enhance converter capacity utilization. Simulation results show that the proposed strategy can effectively restrain fault-period DC-link voltage rise, improve three-phase current symmetry and grid power quality, and strengthen transient reactive-power support, thereby enhancing the asymmetrical-fault LVRT capability of the system. Full article

This paper presents an adaptive nonlinear control and state observation framework for energy management in standalone photovoltaic (PV) systems integrated with battery energy storage. A unified nonlinear dynamic model is developed to describe the interactions between the PV generator, the DC/DC buck converter, and the lithium-ion battery. Based on this model, a multi-mode control strategy is designed to ensure efficient and safe operation under varying environmental and loading conditions. The proposed scheme incorporates maximum power point tracking (MPPT) to maximize photovoltaic energy extraction, along with constant current (CC) and constant voltage (CV) charging modes to guarantee battery safety and longevity. To address uncertainties and unmeasured states, an adaptive nonlinear observer is developed for real-time estimation of the battery open-circuit voltage and state of charge. The observer design is supported by Lyapunov-based stability analysis, ensuring boundedness and convergence of the estimation error in the presence of modeling uncertainties and external disturbances. An energy management algorithm is further introduced to coordinate the transition between operating modes according to the estimated system states and battery constraints. The effectiveness and robustness of the proposed control and observation strategy are validated through detailed simulations in MATLAB/Simulink under varying solar irradiance conditions. The results demonstrate accurate maximum power tracking, reliable state estimation, and safe battery charging performance, highlighting the potential of the proposed approach for advanced autonomous PV–battery systems. Full article

The dual-active-bridge (DAB) converter is the core component of the DC micro-grid system; it has the advantages of topological structure symmetry, high efficiency, and high-power density. Model predictive control (MPC) is often employed to improve the dynamic response characteristics of the system, but its strong parameter dependence is a key factor limiting the development of MPC. Therefore, a model-free predictive control (MFPC) method combining an ultra-local model with model predictive control is proposed to solve the problem of strong dependence of traditional MPC on system model parameters. Firstly, establish the ultra-local mathematical model of the DAB converter. The system’s lumped disturbances are identified using the residual prediction method and substituted into the discrete model of the system at the next time step to achieve model-free prediction. Secondly, a minimum back-flow power constraint is added to the cost function to improve the steady-state performance of the converter. Thirdly, in the extended phase shift modulation, the Lagrange multiplier method (LMM) is proposed to reduce the current stress, ultimately achieving the collaborative optimization of the comprehensive performance of the DAB. Finally, a simulation model is built using MATLAB/Simulink, and compared with traditional control methods, the voltage ripple has been reduced by 51.3%, 89.1%, and 85.1%, respectively; the current stress significantly decreases both when the output voltage reference value changes and when the load resistance changes abruptly, and both can basically achieve zero back-flow power operation. The validity and superiority of the proposed strategy have been verified. Full article

To address the insufficient frequency-support capability, the difficulty of multi-terminal power coordination, and the constraints on DC-voltage fluctuations in flexible DC transmission systems under weak-grid interconnection, this paper conducts a simulation-based control strategy study. First, based on the coupling relationship between AC frequency and DC voltage, an inertia-enhanced grid-forming/VSG control method is proposed, enabling converter stations to use DC-link capacitor energy to provide transient frequency support during the initial stage of a disturbance. Second, for multi-terminal flexible DC systems, an adaptive U-P-f dual-droop distributed control strategy is designed to coordinate unbalanced power sharing among multiple converter stations and to limit the DC-voltage deviation generated during frequency support. In this paper, a hybrid half-bridge/full-bridge MMC is adopted as a fixed-converter simulation platform, rather than being treated as an object of systematic topology optimization. Finally, a four-terminal MMC-HVDC simulation model is established in MATLAB/Simulink, and the proposed control strategy is evaluated under weak-grid step-load disturbances, different short-circuit-ratio conditions, and continuous pseudo-random load disturbance scenarios. Simulation results show that, under the tested operating conditions, the proposed method can reduce the maximum frequency deviation, suppress DC-voltage fluctuations, and improve the power-sharing process among multi-terminal converter stations compared with conventional VSG control and fixed-droop control. Full article

This study details the modelling and simulation analyses performed on a mathematically modelled permanent magnet-assisted synchronous reluctance motor (PMa-SynRM) driven by a field-oriented controlled (FOC) voltage source inverter (VSI) coupled with a half-bridge bidirectional buck-boost DC/DC converter for two-wheeler electric vehicle (EV) applications. The 5 kW, 1500 rpm PMa-SynRM employed here has a shorter response time and is also naturally lighter and cost-effective, making it suitable for two-wheeler EVs. Field-oriented control simplifies the control strategy for PMa-SynRM by decoupling torque and flux, effectively matching the behaviour of a DC motor. A half-bridge buck-boost converter is a DC-DC converter capable of bidirectional power flow, stepping up and down voltages. This makes it ideal for both motoring and regenerative braking in electric vehicles. The buck-boost converter with its controller effectively adjusts the inverter and battery voltage for efficient power flow during motoring and maximum power recovery during regenerating braking. The developed model aims at demonstrating forward and reverse motoring, as well as forward and reverse braking to validate the four-quadrant torque-speed characteristics of two-wheeler EVs. The proposed model attains less than 2% torque ripple and less than 1% speed ripple, respectively. Further, the current ripples are minimised to reduce losses and to improve efficiency. The work presented in this paper implements a PMa-SynRM-based drive system for EVs, a technology which is in the exploratory stage and not commercially widespread. This adds novelty to the proposed work. A MATLAB Simulink environment was used for modelling and simulation. Full article

Although secondary control of direct current (DC) microgrids has been widely studied, traditional static current sharing may still cause severe voltage sag under large-signal constant power load (CPL) steps, and many distributed schemes rely on global topology information while showing limited transient disturbance rejection. To address these issues, this paper proposes an observer-assisted, stability-margin-driven prescribed-time distributed secondary control strategy for islanded DC microgrids. A dynamic CPL risk evaluation function updates current-sharing ratios according to converter operating margins, while a distributed prescribed-time observer estimates disturbance envelopes and alleviates high-frequency chattering. Local adaptive gains remove the explicit dependence of controller tuning on global Laplacian eigenvalue information. MATLAB R2024a-based numerical studies show that, under a 6000 W CPL stress scenario, the proposed method limits the maximum voltage drop to 3.37 V, compared with 24.60 V for the conventional virtual current derivative (VCD) method. Under heterogeneous line impedances and a non-ideal digital benchmark, the proposed method yields a normalized current-sharing error of 0.72%, whereas the VCD method exhibits milder voltage transients. These results support the algorithmic effectiveness and numerical robustness of the proposed strategy within the adopted validation environment. Full article

To address the key problems of low-frequency oscillation and insufficient regulation accuracy at the Point of Common Coupling (PCC) in hydro–wind–photovoltaic hybrid systems, which are caused by the randomness of wind and photovoltaic output, the water-hammer effect of hydropower units, and multi-source power coupling, a joint control strategy based on Fractional-Order Proportional Integral Derivative (FOPID) and Co-evolutionary Multi-objective Particle Swarm Optimization (CMOPSO) is proposed. First, a small-signal transfer function model of the system covering photovoltaic inverters, doubly fed induction generators (DFIGs), hydropower units and voltage-source converter-based high-voltage direct current (VSC-HVDC) converter stations is established to accurately characterize the water-hammer effect and multi-source dynamic coupling characteristics. Second, a Caputo-type FOPID controller is designed. Compared with traditional integer-order controllers with limited tuning flexibility, the FOPID controller utilizes its five degrees of freedom to address specific multi-source coupling challenges. This precisely compensates for the non-minimum phase lag caused by the water-hammer effect in hydropower units via the fractional derivative link, and effectively smooths the impact of stochastic wind–solar fluctuations on PCC voltage through the memory characteristics of the fractional integral link. This multi-parameter regulation mechanism prevents a trade-off between response speed and overshoot suppression, achieving effective decoupling of complex multi-source dynamic interactions. Third, a dual-objective optimization framework with the Integral of Time-weighted Absolute Error (ITAE) and Oscillatory Disturbance Risk Index (ODRI) as the objectives is constructed. The multi-population co-evolution mechanism of the CMOPSO algorithm is adopted to solve the Pareto-optimal solution set, realizing the coordinated optimization of dynamic response accuracy and oscillation instability risk. Finally, comparative simulations are carried out on the Simulink platform with traditional PI/FOPI controllers and optimization algorithms such as Multi-objective Particle Swarm Optimization based on the Decomposition/Simple Indicator-Based Evolutionary Algorithm (MPSOD/SIBEA). The results show that the proposed strategy can effectively suppress low-frequency oscillations in the range of 0~30 Hz. Compared with the traditional PI controller, the PCC voltage overshoot is reduced by more than 40%, the oscillation decay time is shortened by 33%, the ITAE and ODRI indices are decreased by 12.58% and 2.47%, respectively, and the stability of DC bus voltage is significantly improved. Its robustness and comprehensive control performance are superior to existing methods, providing an efficient and stable control scheme for power electronics-dominated complex new energy grid-connected systems. Full article

Grid-forming converters, with their voltage-source characteristics, can independently provide voltage support and thus have become a critical supporting technology for new-type power systems. However, they suffer from overcurrent risks and insufficient voltage support capability during grid faults. To overcome these shortcomings, this paper proposes an adaptive transient-voltage support strategy for grid-forming PMSG wind turbines based on DC capacitor-voltage synchronization. First, the inertia synchronization and autonomous-voltage support mechanisms of such grid-forming wind turbines are analyzed. Second, based on power-flow equations and the grid-forming topology, key factors affecting the grid-connected voltage during faults are identified, and an adaptive voltage-support strategy using fuzzy control is developed. Finally, a grid-forming wind power system is modeled on the PSCAD/EMTDC platform, where the proposed strategy raises the minimum PCC voltage to 0.62 p.u. and increases reactive power injection by 0.13 p.u. under a 70% deep sag, successfully fulfilling low-voltage ride-through requirements. Full article

Current-source DC links and their associated power converters require continuous conduction mode (CCM), necessitating specialized switching device configurations. These topologies have gained significant attention due to the increasing adoption of current-mode power distribution systems. The operation of a current-source DC-DC converter relies on temporary magnetic energy storage, typically regulated using established switch-mode power conversion techniques. For a stable current step up or step down the use of the tapped inductor concept can provide an ultimate stable solution for current adjustment and the proposed concept is now developed on a step-down current source DC-DC power converter for the first time to reveal in the power electronics field. The use of tapping concept is similar to a coupled inductor and this allows flexible current modification. In this article, this concept is extended to a family of Tapped inductor current-based DC-DC together with soft-switching to reduce the loss of the switching devices. The key advantage is that it can offer a wide range of current conversions with high efficiency. The theoretical and experimental analysis of the proposed converter family is presented. An experimental prototype of the converter was built and tested, operating with a switching frequency of 100 kHz and accommodating input currents ranging from 1 A to 10 A. The converter achieved current conversion ratios of 0.8, 0.67 and 0.57 times the input current, with an output power range of 1 W to 314 W. The maximum efficiency of 88% was achieved at an output power of 314 W. The high efficiency and wide current conversion range of this current-based converter make it suitable for a variety of applications such as current driving LED systems, photovoltaic (PV) system current source control, and constant current fast charging systems for electric vehicles (EVs). Full article

This paper proposes an innovative control strategy for DC-DC LLC resonant converters, which is based on Reinforcement Learning (RL), specifically utilizing the Tabular Q-Learning algorithm. The presented approach is designed to overcome the limitations of traditional model-based linear controllers and offers two distinct advantages. First, the model-free nature of the algorithm ensures superior robustness: the agent learns the optimal control policy through direct interaction with the converter, implicitly compensating for non-linearities, component tolerances, and parameter drifts caused by aging or thermal stress, without requiring a priori knowledge of the mathematical model. Second, unlike Deep Reinforcement Learning (DRL) techniques, which demand high processing power, the tabular approach guarantees a fast, deterministic execution, which makes the proposed technique highly suitable for implementation on standard microcontrollers in low-cost edge applications. Validation through PLECS simulations demonstrates the controller’s ability to maintain tight voltage regulation even under severe dynamic variations of the input voltage and load. Full article

To address the computational complexity and cumbersome matrix assembly inherent in the Space-Wavenumber Mixed-Domain Method based on the Finite-Element Method (SWMDM-FEM) for three-dimensional (3D) Direct Current (DC) resistivity simulations, we propose an enhanced numerical approach. This approach utilizes two-dimensional (2D) Fourier transform technology to convert the 3D resistivity problem into a one-dimensional (1D) problem within the space-wavenumber mixed domain, which is then solved using the finite-difference method (FDM). By integrating the efficiency of Fourier transform with the simplicity of FDM, this method significantly enhances the efficiency of 3D numerical simulations in DC-resistivity methods. The accuracy of our algorithm is first validated using a spherical anomalous model, followed by testing with a model combining a low-resistivity cuboid and a high-resistivity sphere, demonstrating the method’s superior computational efficiency over the SWMDM-FEM. Subsequently, the proposed algorithm in this paper was tested using a cubic anomaly model. The number of iterations of the algorithm required to achieve the preset convergence accuracy was focused on and counted under different resistivity differences between the anomalous body and the background medium, different total grid numbers in the computational region, and different burial depths of the anomalous body so as to verify that the proposed algorithm has good convergence performance. At the same time, the test results show that under the premise of meeting the preset accuracy requirements, the number of iterations when the algorithm converges is only related to the resistivity difference between the anomalous body and the background medium, and has no correlation with the total number of grid divisions and the burial depth of the anomalous body. Finally, the E-SCAN method was used to carry out three-dimensional observation on the composite model, and the electromagnetic response characteristics of the anomalies were systematically analyzed. It is found that the position of the power supply point significantly impacts the observational outcomes. The E-SCAN method shows higher resolution in terms of identifying low-resistivity bodies but has limited capability in recognizing high-resistivity bodies. These findings provide a strategic workflow for practical geophysical exploration: rapid anomaly delineation using the E-SCAN method followed by high-precision 3D inversion. Full article

Cascaded H-bridge converters are the prevalent option for classic energy storage converters due to their excellent battery integration and current sharing capabilities. However, this scheme requires numerous IGBT switchings and exhibits high losses in low-voltage, high-power applications due to high current flowing through the batteries. Furthermore, the limited DC voltage regulation capability makes it difficult to obtain sufficient DC voltage for modulation when the battery is continuously discharging, resulting in shortened continuous discharge duration. To address these issues, this paper proposes a novel energy storage converter based on controllable DC buses. The proposed controllable DC bus consists of cascaded half-bridges and a bidirectional DC converter, where the former topology is designed to preserve voltage and current balancing between batteries, as well as boost the DC voltage—thereby reducing the current flowing through the batteries and minimizing losses. The latter topology is implemented to maintain DC bus voltage during battery discharge, thereby increasing the continuous operating time of the proposed energy storage converter. Moreover, the control and modulation of the proposed controllable DC bus have been optimized, and its effectiveness and performance are verified through simulation results. Full article
