The crane installation on the deck of a yacht redistributes the stress field and affects the local structural integrity and performance. The safe operation of the yacht is associated with the optimal placement of the crane on the deck and the proper local structural reinforcement. Here, the structural analysis of the bow part of a yacht made of composite materials is studied, considering the retrofit installation of a crane, in three different cases of reinforcing the deck: (a) without any reinforcement, (b) with a T-type reinforcement, and finally, (c) with a longitudinal beam. The T-type connects the longitudinal bulkhead and the deck, reinforced locally with overlamination skin and adhesive-filler. The longitudinal beam works as a local longitudinal stiffener attached to the deck and connects the second, third, and fourth transverse frames. The structural analysis is performed using the finite element method following the classification societies’ rules. The local reinforcements are made from the same composite materials as the unreinforced deck. The maximum deformations, the principal stresses, and the safety factors following Tsai-Wu and Hashin criteria are calculated and compared for the three different cases. The T-type and longitudinal reinforcements reduce deck stresses by 33%, with longitudinal reinforcement reducing deck deformation by 17%. Composite failure analysis shows the structure was near failure, and the reinforcements enhance safety; T-type is better for multiaxial loads (Tsai-Wu), and longitudinal is superior for micromechanical failure (Hashin). By considering the structural performance and safety aspects, designers and engineers can make optimal decisions regarding yacht crane installation and proper reinforcement, leading to safer and more efficient structures. Full article

Considering the different structural strength requirements of different parts of fiberglass yachts, carbon fiber/glass fiber hybrid reinforcement can be applied to the skins of sandwich panels in special areas. This paper designs and prepares 12 foam sandwich panel samples composed of pure carbon fiber, a carbon fiber/glass fiber hybrid, pure glass fiber skin, and PVC and SAN foam sandwich, with reference to the layup structure of the outer panel of a fiberglass yacht. Through a comparative analysis of low-speed impact experiments, edge compression experiments, and short beam three-point bending experiments, we seek the optimal carbon fiber/glass fiber hybrid layup design scheme for local structures to guide production. The results show that a reasonable hybrid carbon fiber layup in fiberglass skin can effectively reduce the low-speed impact damage of the sandwich structure, reduce edge compression damage, and improve the bending and compression resistance of sandwich structure. The impact resistance, compression resistance, and shear resistance of the SAN sandwich structure are stronger than the PVC sandwich structure. The carbon fiber/glass fiber hybrid SAN foam sandwich structure can be used for the local structural reinforcement of special parts such as the bow, side, and main deck of fiberglass yachts. Full article
