Standards describing the test procedures recommended to investigate the shielding effectiveness of enclosures have two major issues: they generally prescribe the assessment of the electromagnetic field of empty cavities, and they do not deal with very small enclosures. However, the dimensions of some very common shielded apparatus are smaller than those considered in the standards and the electromagnetic field distribution inside the shielded structure is strongly affected by the enclosure content. In this paper, both issues have been investigated for two components commonly used in medium voltage/low voltage (MV/LV) substations: a mini personal computer used to store, process, and transmit relevant data on the status of the electric network, with these aspects being essential in smart grids, and an electronic relay which is ubiquitous in MV/LV substations. Both components are partially contained in a metallic enclosure which provides a certain amount of electromagnetic shielding against external interferences. It is observed that an electrostatic discharge may cause a failure and/or a loss of data, requiring an improvement of shielding characteristics or a wise choice of the positions where the most sensitive devices are installed inside the enclosure. Since the dimensions of very small enclosures, fully occupied by their internal components, do not allow for the insertion of sensors inside the protected volume, numerical analysis is considered as the only way for the appraisal of the effects induced by a typical source of interference, such as an electrostatic discharge. Full article

Electrification of the transport sector introduces operational issues in the electricity distribution network, such as excessive voltage deviation, substation overloading, and adverse power quality impacts on other network loads. These concerns are expected to grow as electrification expands to incorporate heavy vehicles such as trucks and buses due to their greater energy requirements and higher charging loads. Two strategies are proposed to support medium- and heavy-duty chargers which address their high power demand and mitigate power quality disturbances and the overloading of substations. The first is a dedicated feeder connected at the secondary of the substation directly to the charging station which aims to reduce the impact of high load on other customers. The second is the addition of a dedicated substation that solely provides power for charging stations in major corridors, alleviating stress on existing zone substations. Hosting capacity is measured using a voltage deviation index, describing the deviation in line voltage, which should experience a sag of no more than 6% of the nominal voltage, and a substation charging capacity index, describing the available capacity of each zone substation as a ratio of its total power capacity. Verification of the proposed strategies was performed on an MV-LV distribution network representative of an industrial Australian town with heavy-vehicle charging. Results showed that the network could handle ten 250 kW chargers, which was tripled to 35 with a dedicated feeder. The dedicated feeder alternatively allowed up to 10 megawatt-scale chargers, which was again tripled when a dedicated substation was introduced. Full article

Care about the environment is one of the key issues faced by engineers. Among the solutions conducive for reducing CO₂ and NO_x emissions from road transport is the introduction of electric cars. At the same time, it requires taking care of the infrastructure enabling the charging of electric vehicles in large as well small towns. Since December 2021, an amendment to the Act on Electromobility and Alternative Fuels has been forced in Poland. It introduced the obligation to design and construct buildings in a way that allows the installation of charging stations for electric vehicles. The article proposes a technical criterion for selecting a substation to connect an EV charging station. The criterion was based on the maximum apparent power determined from the transformer’s annual load profile. The transformer profiles were developed using data from the advanced metering infrastructure system with which MV/LV substations are equipped. Thirty-eight of the fifty-five stations were selected for analysis due to insufficient measurement data. In addition to the technical criterion, a social and economic criterion was used to select the location of electric vehicle charging stations. Full article

This article presents an original methodology to determine the optimal level of reactive energy transmission to low-voltage consumers supplied from MV/LV substations that guarantees the lowest total costs of reactive energy transmission through the DSO network and its generation in receiving installations within the reactive power compensation process. The average value of the optimal factor tgφ to be maintained by customers depends on the efficiency of the network, the characteristics of the load, and the market costs of energy losses due to the transmission of reactive energy through the network that are covered by the DSO and the costs of reactive energy generation in receiving installations. The results presented for real MV/LV substations operating in the Polish distribution network demonstrate the application of annual measurements of active and reactive energy consumed and generated registered by AMI systems to calculate the optimal reactive power compensation level. They can be applied to verify the permissible levels of reactive energy compensation applied by the DSOs until now within the yearly tariffs for customers. Full article

Low-voltage (LV) network assets, although they do not play a significant role in reliability indices compared to medium-voltage (MV) assets like the transformer and switchgears, are required to be designed in a way that would mitigate the risk of sporadic failures, hence incurring an R&M cost. LV assets like LV cables, distribution panels, molded-case circuit breakers (MCCBs), and miniature circuit breakers (MCBs) generally do not have a planned maintenance (PM) schedule and are procured based on the run-to-failure concept in view of the huge volume. These assets are exposed to the harshest of environmental and operation conditions. Hence, it is imperative that we take the necessary measures during the design stage such that they are able to cater to their stringent duties, which include frequent short circuits, exposure to the environment, and thermal overloads. It is also important to periodically review the product design based on site feedback and product performance to re-calibrate the product and its associated processes. Through this technical paper, several case studies are presented wherein special terminal connectors with shear bolts were designed to mitigate the thermal hotspot issues causing frequent fire and failures—i.e., vertical fuse switch disconnectors (VFSDs) and miniature circuit breaker (MCBs). A case study on condition monitoring through a substation inspection schedule is also presented, through which potential failures were averted in time. The observations and measurements are mapped in an SAP system for trend analysis. With the adoption of effective product and process design, AEML has reduced asset failures. Full article

This paper focuses on the evaluation of the electric shock hazard accompanying earth faults in a non-effectively earthed medium-voltage (MV) electrical power network. This hazard depends on the duration and value of the fault current. While the fault current depends on several factors, the most important is the neutral point earthing method. The value of the fault current affects the earthing-electrode voltage value, being the basis for the assessment of electric shock hazard in MV/LV substations. The earthing-electrode voltage is also influenced by the resistance of the substation earthing, which in practice is random. Therefore, an original statistical evaluation method for assessing the electric shock hazard has been developed and presented in this paper. It is based on a statistical model of the MV/LV substation earthing resistance, worked out on the basis of experiments and measurements in real electrical power networks. This method can be used for the determination of statistical distributions of earthing-conductor voltages in real electrical power networks, and on this basis, the MV/LV substations with rates of electric shock hazard that are too high can be indicated. This also makes it possible to determine the longest permissible fault current interruption times or the highest permissible earthing resistances for specific substations. This method is also applicable when selecting the neutral point earthing method. The developed method was used in all of the above proposed areas by performing calculations on a model of a real 15 kV network with the neutral point earthed by a resistor. This analysis proves the practicability of the method both at the stage of designing power networks, and when a change in the neutral point earthing method in existing networks is being considered. Particularly valuable is also the statistical model of an earthing electrode resistance, developed on the basis of measurements in 2408 MV/LV substations, which may also be applicable in the future studies. Full article

The reliability of systems and components is a fundamental need for the efficient development of a smart distribution grid. In fact, the presence of a fault in one component of the grid could potentially lead to a service interruption and loss of profit. Since faults cannot be avoided, the introduction of a diagnostic scheme could predict the fault of a component in order to carry out predictive maintenance. In this framework, this paper proposes a novel Fault Detection and Isolation (FDI) scheme for AC/DC converters in MV/LV substations. In order to improve the reliability of the FDI procedure, the system architecture includes also an Instrument Fault Detection and Isolation section for identifying faults that could occur on the instruments and sensors involved in the monitoring process of the AC/DC converter. The proposed architecture is scalable, easily upgradable, and uses cost-effective sensors. Tests, carried out on a real test site, have demonstrated the efficacy of the proposal showing very good IFDI diagnostic performance for the 12 types of faults tested. Furthermore, as the FDI diagnostic performance regards, it shows a detection rate close to 100%. Full article

Connecting a large number of distributed sources to the medium and low voltage grid poses many problems. The most important of these are the voltage changes inside the network, what can be observed when the power flow from these sources towards the HV/MV (High Voltage/Medium Voltage) transformer station. In particular, if the power consumption in nodes of the MV network is small and the distance between the place of installation of the source and the substation is large, increases and changes in voltage may be dangerous for the insulation of the network and burdensome for the consumers connected to it. The solution most frequently used to control voltage increases is the appropriate setting of the controller that affects the on-load tap changer of the MV/HV or even MV/LV (Medium Voltage/Low Voltage) transformer. It is also possible to regulate the reactive power of the sources and, of course, to limit their generated active power (curtailment of generation). The development of energy storage technology has made it possible to introduce consumers into the network, whose power can be controlled in a wide range. The article proposes the concept of an innovative voltage control system in the MV network, whose output values are three groups of parameters: HV/MV transformer ratio, reactive power of sources and active power of consumers connected in generation nodes. In the technological sense, it has been assumed that the loads are installations of electrolyzers used to produce “green hydrogen”, according to the P2G (Power to Gas) formula. The tests consisting in the execution of several hundred calculation cycles for the IEEE 37 test network, using the Monte Carlo simulation, have shown that the subordination of the hydrogen production process to the objectives of voltage control in the MV network clearly contributes to stabilizing its value, while meeting the technological requirements. The control variables of the proposed control system are the result of the optimization algorithm described in the article, the function of which is the quality of network voltage. Full article

This paper focuses on studying the phenomenon of harmonic distortion propagation through distribution networks. This phenomenon is governed by a combination of factors involving the nature of harmonic loads and their dynamic interaction, the influence of background voltage distortion, and harmonic impedance values. The objective of the proposed research includes evaluation of the network response at different nodes to harmonic current injections via utilizing a time-synchronized distributed measurement system. The study is performed in a fully controlled and flexible test network with three medium voltage/low voltage (MV/LV) distribution substations and several managed LV harmonic sources, namely PV inverter, single-phase EV charger and emulated harmonic load with reference current injections. A selection of the results is analyzed and interpretation of the observed phenomena is given with implications that synchronized harmonic measurements can be considered as potential powerful instruments for analyzing power quality disturbances. Full article

With the continuous increase in the number and relevance of electric transmission lines and distribution networks, there is a higher exposure to the magnetic fields generated by them, leading to more cases of human electrosensitivity, which greatly necessitates the design and development of magnetic field mitigation procedures and, at the same time, the need to minimize both performance degradation and deterioration in the efficiency as well. During the last four decades, fruitful results have been reported about extremely low frequency magnetic field mitigation, giving a wide variety of solutions. This survey paper aims to give a comprehensive overview of cost-effective optimization techniques destined to magnetic field mitigation in power systems, with particular attention to the results reported in the last decade. Full article

Narrowband powerline communication (NB-PLC) systems represent a key step for the real development of smart grids’ applications in the medium voltage (MV) and low voltage (LV) networks. This article sums up the results of a complete experimental measurement campaign aimed at investigating the low voltage NB-PLC channel in the frequency range from 9 to 500 kHz in various sites (i.e., rural, urban etc.) located in France. The noise features in time-frequency representation are studied at five different sites between the transformer substation and the smart electricity meter. The main contribution of this study consists in estimating the theoretical channel capacity which constitutes a major interest for the users and actors of the electrical system. The channel capacity calculation shows reliable results in the US Federal Communications Commission (FCC) band (a few Mbits/s). The quality of the communication in the FCC band enables to integrate new smart grids’ applications and services based on the existing NB-PLC communication for advanced metering infrastructure (AMI). Full article

A key issue in Low Voltage(LV) distribution systems is to identify strategies for the optimal management and control in the presence of Distributed Energy Resources (DERs). To reduce the number of variables to be monitored and controlled, virtual levels of aggregation, called Virtual Microgrids (VMs), are introduced and identified by using new models of the distribution system. To this aim, this paper, revisiting and improving the approach outlined in a conference paper, presents a sensitivity-based model of an LV distribution system, supplied by a Medium/Low Voltage (MV/LV) substation and composed by several feeders, which is suitable for the optimal management and control of the grid and for VM definition. The main features of the proposed method are: it evaluates the sensitivity coefficients in a closed form; it provides an overview of the sensitivity of the network to the variations of each DER connected to the grid; and it presents a limited computational burden. A comparison of the proposed method with both the exact load flow solutions and a perturb-and-observe method is discussed in a case study. Finally, the method is used to evaluate the impact of the DERs on the nodal voltages of the network. Full article

Electric Vehicles (EVs) have seen significant growth in sales recently and it is not clear how power systems will support the charging of a great number of vehicles. This paper proposes a methodology which allows the aggregated EV charging demand to be determined. The methodology applied to obtain the model is based on an agent-based approach to calculate the EV charging demand in a certain area. This model simulates each EV driver to consider its EV model characteristics, mobility needs, and charging processes required to reach its destination. This methodology also permits to consider social and economic variables. Furthermore, the model is stochastic, in order to consider the random pattern of some variables. The model is applied to Barcelona’s (Spain) mobility pattern and uses the 37-node IEEE test feeder adapted to common distribution grid characteristics from Barcelona. The corresponding grid impact is analyzed in terms of voltage drop and four charging strategies are compared. The case study indicates that the variability in scenarios without control is relevant, but not in scenarios with control. Moreover, the voltages do not reach the minimum voltage allowed, but the MV/LV substations could exceed their capacities. Finally, it is determined that all EVs can charge during the valley without any negative effect on the distribution grid. In conclusion, it is determined that the methodology presented allows the EV charging demand to be calculated, considering different variables, to obtain better accuracy in the results. Full article
