Early SOC balancing techniques primarily centered on simple hardware circuit designs. Passive balancing circuits utilize resistors to consume energy, aiming to balance the SOC among batteries; however, this approach leads to considerable energy wastage. As research progresses, active balancing circuits have garnered widespread attention. Successively, active balancing circuits utilizing capacitors, inductors, and transformers have been proposed, enhancing balancing efficiency to some extent. Nevertheless, challenges persist, including energy wastage during transfers between non-adjacent batteries and the complexity of circuit designs. In recent years, SOC balancing methods based on software algorithms have gained popularity. For instance, intelligent control algorithms are being integrated into battery management systems to optimize control strategies for SOC balancing. However, these methods may encounter issues such as high algorithmic complexity and stringent hardware requirements in practical applications. This paper proposes a fast state-of-charge (SOC) balance control strategy that incorporates a weighting factor within a modular battery energy storage system architecture. The modular distributed battery system consists of battery power modules (BPMs) connected in series, with each BPM comprising a battery cell and a bidirectional buck–boost DC-DC converter. By controlling the output voltage of each BPM, SOC balance can be achieved while ensuring stable regulation of the DC bus voltage without the need for external equalization circuits. Building on these BPMs, a sliding mode control strategy with adaptive acceleration coefficient weighting factors is designed to increase the output voltage difference of each BPM, thereby reducing the balancing time. Simulation and experimental results demonstrate that the proposed control strategy effectively increases the output voltage difference among the BPMs, facilitating SOC balance in a short time. Full article

This paper describes active battery balancing based on a bidirectional buck converter, a flyback converter, and battery cells by using the proposed chain-loop comparison strategy. The role of the bidirectional buck converter is to charge/discharge the battery pack. During the charging period, the converter is in buck mode, and its output is controlled by constant current/voltage; during the discharging period, the converter is in boost mode, and its output is controlled by constant voltage. The role of the flyback converter is voltage equalization of the battery pack, and its output is controlled by constant current. A chain-loop comparison strategy is used to control battery voltage equalization. In this work, three equalization modes, namely, charging balance, discharging balance, and static balance, were considered. The voltage difference between the maximum and minimum is 0.007 V after a balancing time of 19.75 min, 0.005 V after a balancing time of 24 min, and 0.007 V after a balancing time of 20 min for charging balance, discharging balance, and static balance, respectively. Full article

Traditional fuel vehicles are currently still the main means of transportation when people travel. It brings convenience to their travels, but it also causes energy shortages and environmental pollution. With the development of science and technology and the popularization of green environmental protection, electric vehicles have gradually entered people’s lives, greatly alleviating these problems. As a power supply device for electric vehicles, the performance of batteries directly affects various indicators of vehicles. Due to their long lifespan and high energy density, lithium-ion batteries are now the preferred source of power for electric vehicles. However, due to various factors in the manufacturing and operation of lithium-ion batteries, there are often differences among individual cells. The power balance and performance of a battery pack are closely related. Thus, battery equalization is an important standard for a battery management system to work normally, and it is also one of the various battery management application problems. This paper reviews battery equalization systems and various active equalization circuits and summarizes the working principle and research progress of each active equalization circuit. Then, various active equalization circuits are analyzed and compared, and dynamic equalization for a second-life battery is introduced to enrich this review of equalization technology. Finally, the above contents are summarized and prospected. In order to obtain the best outcomes, different equalization circuits need to be chosen for various situations. Full article

In order to address the energy imbalance issue of a series-connected lithium-iron battery pack, this paper proposes an active equalization method based on a reduced-order solving strategy for the Hanoi Tower problem. The proposed scheme utilizes a combined structure of a switching-network circuit and a bidirectional Cuk converter and leverages an ultracapacitor cell as the energy-transfer carrier. Simulation and comparison demonstrate that the exchange of unbalanced energy within the battery pack can be achieved. The proposed approach can effectively achieve various balancing modes such as cell-to-cell, cell-to-string, string-to-cell, and string-to-string with a relatively fast balancing speed. Full article

Assessing the performance of active balancing methods poses a significant challenge due to the time required to replicate the equalization of various balancing techniques under identical initial cell conditions. Conventional circuit simulation methods, designed for high-frequency switching behavior, impose a considerable computational burden when applied to the long-term equalization of battery cells. To address this challenge, this paper presents an efficient performance evaluation method employing an average equivalent model of the equalizers. By representing the charge transfer mechanism inherent to the equalization process, the proposed approach is compatible with the most widely used switched-energy-tank equalizers. The validity of this method is confirmed through simulation and experimental results. In the case of four series-connected battery cells, our proposed approach can assess the performance of a three-hour equalization process in just one minute of execution time. The use cases in the paper highlight the practical feasibility of the AM in facilitating performance comparisons of SET-Es under various initial conditions. Full article

To meet the load voltage and power requirements for various specific needs, a typical lithium–ion battery (LIB) pack consists of different parallel and series combinations of individual cells in modules, which can go as high as tens of series and parallel connections in each module, reaching hundreds and even thousands of cells at high voltage (HV) levels. The inhomogeneity among the cells and modules results in voltage imbalances during operation and reduces the overall system efficiency. In this work, a robust and flexible active balancing topology is presented. It can not only mitigate the charge imbalance within a module, i.e., intramodular equalization, but also help to balance the state of charge (SoC) level of the modules in a high voltage pack, i.e., intermodular equalization, which is an often-overlooked topic. The proposed concept was proven by experimental verification on parallel and series configurations of cells in realistically sized modules and practical battery management system (BMS) hardware, when the LIB was both idle and under load. Full article

The article is devoted to solving the problem of charge equalization of multi-element batteries with rated voltage up to 1000 V, operating in dynamic modes with different charge and discharge depths. This article proposes a method of balancing the voltages of power battery elements. The essence of the proposed method is to form a reference signal equivalent to the reference voltage of the battery element for the current state of charge. The novelty of the method presented in this article, in comparison with relevant existing techniques, lies in active control over the balancing circuit proportional to real cell voltage deviation from the reference value. The proposed method can be used both for passive balancing techniques based on ballast resistors, and for circuits made on electromagnetic energy redistribution systems between galvanic cells. A number of Simulink models were developed to determine the electrical parameters of active and passive balancing circuits. Performance and accuracy study of balancing a multi-element battery in charge and discharge modes was conducted by Simulink models. It was established that, compared to classical methods, the proposed balancing method enhances the accuracy by 1.43 times and improves dynamic indices of the balancing process at any state of charge of batteries. The proposed balancing method is a perspective for energy storage systems based on multi-element batteries for power supply nodes of high-power loads with pulsed and repeated short-term operation modes. Full article

Electric vehicles (EVs) are becoming increasingly popular due to their low emissions, energy efficiency, and reduced reliance on fossil fuels. One of the most critical components in an EV is the energy storage and management system, which requires compactness, lightweight, high efficiency, and superior build quality. Active cell equalization circuits such as those used in battery management systems (BMS) have been developed to balance the voltage and state of charge (SoC) of individual cells, ensuring the safety and reliability of the energy storage system. The use of these types of equalization circuits offers several benefits including improved battery performance, extended battery life, and enhanced safety, which are essential for the successful adoption of EVs. This paper provides a comprehensive overview of the research works related to active cell equalization circuits. This review highlights the important aspects, advantages and disadvantages, and specifications. Full article

The investigation of electric vehicle technologies has increased significantly in the last few years. These vehicles can substantially reduce the environmental impact of the transportation sector. In electric cars, the battery is a crucial element. The batteries are made up of several stacked cells to meet the requirements of the propulsion system. Battery equalizer circuits take active measures to ensure that a particular variable is kept inside an allowable range in all cells. Inductor-based equalizers are very popular since the equalization current is controlled. This paper proposes a single-inductor architecture with a reduced number of components. The proposed topology can transfer energy from adjacent cell-to-cell or adjacent string-to-string. This paper analyzes the operation of the converter, its design, and the design of the controller. Furthermore, a comparison of the proposed equalizer with other inductor-based schemes was made considering the component count, stress on devices, equalization time, driver complexity, and other parameters. The theoretical efficiency of the proposed equalizer obtained was 84.9%, which is competitive with other literature solutions. The impact of battery size on the number of circuit components was also analyzed. Finally, simulation results in open load and changes of current through the battery conditions were performed to validate the theoretical analysis. Full article

The equalization technique is a key technique in the secondary utilization of retired batteries. In this paper, a double-layer equalization method is proposed, which combines the reconfigurable topology with the converter active equalization method. The inner layer uses the reconfigurable topology to have a balanced set of battery cells. Thanks to isolating the lowest SOC (state of charge) cell in the battery group, the energy transfer loss among cells is avoided. In addition, this topology can reduce cost and control complexity and the number of components. In the outer layer, a Buck–Boost converter is added for each battery group, and the outputs of the converters are connected in series. The output voltage of the converter varies as the SOC of the group varies while the total output voltage is stable. In order to validate the proposed method, an equalization circuit consisting of 12 battery cells is built on Matlab/Simulink. Simulation results show that the proposed method can effectively balance the battery pack and maintain a stable output voltage. Compared to the conventional active equalization method, the proposed method has significantly improved the equalization efficiency. Full article

The energy flow is step-by-step among Lithium-ion-battery when an equalizer based on the buck-boost converter is adopted, resulting in a long energy transmission path and low equalization efficiency. First, a Lithium-ion-battery equalizer based on the dual active half-bridge is studied in this paper. Second, the key parameters of the energy flow between cells in the same group and cells in different groups in the equalizer are analyzed. Third, a phase shift control strategy is put forward according to the analysis results. The equalizer with the proposed control strategy not only can realize the energy flow between cells in the same group and different groups but also work at high frequency. Therefore, the transformer can be designed to be small in size and light in weight, greatly reducing the volume and weight of the equalizer. A prototype of the dual active half-bridge equalizer with four lithium batteries was managed. The experimental results show that the proposed Lithium-ion-battery equalizer based on phase shift control has good equalization performances. Full article

Battery systems are one of the most important components for the development of flexible energy storage for future applications. These comprise energy storage in both the mobility sector and stationary applications. To ensure the safe operation of multiple battery cells connected in series and parallel in a battery pack, it is essential to implement state of charge (SOC) equalization strategies. Generally, two fundamentally different approaches can be distinguished. On the one hand, these are passive approaches for SOC equalization that are based on including additional Ohmic resistors in a battery back over which equalization currents flow as long as the correspondingly connected cells have different voltages. Despite the simple implementation of such equalization circuits, they have a major drawback, namely wasting stored energy to perform the SOC equalization. This waste of energy goes along with Ohmic heat production, which leads to the necessity of additional cooling for batteries with large power densities. On the other hand, active SOC equalization approaches have been investigated, which allow for an independent charging of the individual cells. Especially, this latter approach has big potential to be more energy efficient. In addition, the potential for a reduction of Ohmic heat production may contribute to extending the lifetime of battery cells. To perform the individual charging of battery cells in an energetically optimal manner, this paper provides a comparison of closed-form optimization approaches on the basis of Pontryagin’s maximum principle and approaches for reinforcement learning. Especially, their accuracy and applicability for the implementation of optimal online cell charging strategies are investigated. Full article

This paper presents a hybrid equalization (EQ) topology of lithium-ion batteries (LIB). Currently, LIBs are widely used for electric mobility due to their characteristics of high energy density and multiple recharge cycles. In an electric vehicle (EV), these batteries are connected in series and/or parallel until the engine reaches the voltage and energy capacity required. For LIBs to operate safely, a battery management system (BMS) is required. This system monitors and controls voltage, current, and temperature parameters. Among the various functions of a BMS, voltage equalization is of paramount importance for the safety and useful life of LIBs. There are two main voltage equalization techniques: passive and active. Passive equalization dissipates energy, and active equalization transfers energy between the LIBs. The passive has the advantage of being simple to implement; however, it has a longer equalization time and energy loss. Active is complex to implement but has fast equalization time and lower energy loss. This paper proposes the combination of these two techniques to implement simultaneously to control a pack of LIBs, equalizing voltage between stacks and at the cell level. For this purpose, a pack of LIBs was simulated with sixty-four cells connected in series and divided into eight stacks with eight battery cells each. The rated voltage of each cell is 3.7 V, with a capacity of 106 Ah. The total pack has a voltage of 236.8 V and 25 kW. Some LIBs were fitted with different SOC values to simulate an imbalance between cells. In the simulations, different topologies were evaluated: passive and active topology at the cell level and combined active and passive equalization at the pack level. Results are compared as a response time and state of charge (SOC) level. In addition, equalization topologies are applied in an EV model with the FTP75 conduction cycle. In this way, it is possible to evaluate the autonomy of each equalization technique simulated in this work. The hybrid topology active at the stack level and passive at the module level showed promising results in equalization time and autonomy compared with a purely active or passive equalization technique. This combination is a solution to achieve low EQ time and satisfactory SOC when compared to a strictly active or passive EQ. Full article

Batteries are widely used in our lives, but the inevitable inconsistencies in series-connected battery packs will seriously impact their energy utilization, cycle life and even jeopardize their safety in use. This paper proposes a balancing topology structure combining Buck-Boost circuit and switch array to reduce this inconsistency. This structure can realize multi-cell-to-multi-cell (MC2MC) battery balancing by controlling the switch array and having a fast balancing speed, easy expansion and few magnetic components. Then, the operation principle of the proposed balancing topology is analyzed, and the simulation model is verified. In addition, the effects of switching frequency and voltage difference on the equalization effect are further analyzed. The results show that the higher the switching frequency, the lower the time efficiency, but the higher the energy efficiency. The voltage difference significantly impacts the duty cycle, so it is absolutely necessary to introduce a variable duty cycle in the multi-cell-to-multi-cell equalization. Finally, eight series batteries are selected for simulation verification. The simulation results show that, compared with any-cell-to-any-cell (AC2AC) equalization, the time efficiency of multi-cell-to-multi-cell equalization is improved considerably, the energy efficiency is improved slightly, and the variance of the completed equalization is reduced, demonstrating the excellent performance of multi-cell-to-multi-cell equalization. Full article

In order to reduce the time and improve the balancing speed of traditional single-layer inductive equalization circuits, this paper proposes an active equalization control strategy with double-layer inductors for series-connected battery packs, based on an accurate state-of-charge (SOC) estimation. By selecting the inductor as the intermediate energy storage element, the SOC of the single lithium-ion battery (LIB) cell is calculated by using a particle filter (PF) algorithm. Meanwhile, according to the deviation in SOC among the batteries, stop parameters are introduced to achieve the design and optimization of the equalization strategy. Finally, the relationship between the equalization current and the control signal period is derived to fulfill the equalization. The experimental results show that, compared with the traditional single-layer inductive equalization topology, the proposed equalization control topology can shorten the equalization time by at least 15.6%. More importantly, this equalization scheme overcomes the disadvantage of the long energy transfer path of traditional inductive equalization, which helps to improve the equalization speed and the inconsistency of the battery pack. Full article
