Search Results (5)

A simple self-decoupling approach using only a shorting pin is proposed to effectively reduce mutual coupling in multiple-input multiple-output patch antennas. By loading a shorting pin along the polarization direction on one side of the patch antenna, the equivalent inductance of the corresponding source is altered, thereby changing the initial phase of the slot source. This modification, in conjunction with the path effect, creates a mutual coupling null by counteracting the electric fields at the adjacent patch’s feeding position, achieving a reduced mutual coupling level. The simplicity of this decoupling method enables flexibility in practical applications, facilitating adaptation to diverse packaging environments and substrates. Furthermore, the proposed method effectively suppresses mutual coupling between adjacent and non-adjacent elements in multi-element linear arrays, as well as between elements arranged along E-planes and H-planes in planar arrays. To validate the effectiveness of this self-decoupling technique, a two-element decoupled antenna was fabricated and measured. Experimental results demonstrate a decrease in mutual coupling from −22 dB to below −40 dB across the effective frequency range of 4.809 GHz to 4.984 GHz. Full article

As the number of devices using wireless communications increases, the amount of usable radio frequency spectrum becomes increasingly congested. As a result, the need for robust, adaptive communications to improve spectral efficiency and ensure reliable communication in the presence of interference is apparent. One solution is using beamforming techniques on digital phased-array receivers to maximize the energy in a desired direction and steer nulls to remove interference; however, traditional phased-array beamforming techniques used for interference removal rely on perfect calibration between antenna elements and precise knowledge of the array configuration. Consequently, if the exact array configuration is not known (unknown or imperfect assumption of element locations, unknown mutual coupling between elements, etc.), these traditional beamforming techniques are not viable, so a beamforming approach with relaxed requirements (blind beamforming) is required. This paper proposes a novel blind beamforming approach to address complex narrowband interference in spectrally congested environments where the precise array configuration is unknown. The resulting process is shown to suppress numerous interference sources, all without any knowledge of the primary signal of interest. The results are validated through wireless laboratory experimentation conducted with a two-element array, verifying that the proposed beamforming approach achieves a similar performance to the theoretical performance bound of receiving packets in additive white Gaussian noise (AWGN) with no interference present. Full article

In this paper, we consider the gain-phase error calibration problem for uniform linear arrays (ULAs). Based on the adaptive antenna nulling technique, a new gain-phase error pre-calibration method is proposed, requiring only one calibration source with known direction of arrival (DOA). In the proposed method, a ULA with M array elements is divided into $M-1$ sub-arrays, and the gain-phase error of each sub-array can be uniquely extracted one by one. Furthermore, in order to obtain the accurate gain-phase error in each sub-array, we formulate an errors-in-variables (EIV) model and present a weighted total least-squares (WTLS) algorithm by exploiting the structure of the received data on sub-arrays. In addition, the solution to the proposed WTLS algorithm is exactly analyzed in the statistical sense, and the spatial location of the calibration source is also discussed. Simulation results demonstrate the efficiency and feasibility of our proposed method in both large-scale and small-scale ULAs and the superiority to some state-of-the-art gain-phase error calibration approaches. Full article

Space–time waveform-encoding (STWE) SAR can receive echoes from multiple sub-swaths simultaneously with a single receive window. The echoes overlap each other in the time domain. To separate the echoes from different directions, traditional schemes adapt single-null steering techniques for digital receive beam patterns. However, the problems of spaceborne DBF-SAR, in practice, such as null extension loss, terrain undulation, elevation angle of arrival extension, and spaceborne antenna beam control, make the conventional scheme unable to effectively separate the echoes from different sub-swaths, which overlap each other in the time domain.A novel multi-null constrained echo separation scheme is proposed to overcome the shortcomings of the conventional scheme. The proposed algorithm can flexibly adjust the width of the notch to track the time-varying pulse extension angle with less resource consumption. Moreover, the hardware implementation details of the corresponding real-time processing architecture are discussed. The two-dimensional simulation results indicate that the proposed scheme can effectively improve the performance of echo separation. The effectiveness of the proposed method is verified by raw data processing instance of an X-band 16-channel DBF-SAR airborne system. Full article

When jammers move rapidly or an antenna platform travels at high speed, interference signals may move out of the null width in the array beampattern. Consequently, the interference suppression performance can be significantly degraded. To solve this problem, both the null broadening technique and robust adaptive beamforming are considered in this paper. A novel null broadening beamforming method based on reconstruction of the interference-plus-noise covariance (INC) matrix is proposed, in order to broaden the null width and offset the motion of the interfering signals. In the moving case, a single interference signal can have multiple directions of arrival, which is equivalent to the existence of multiple interference sources. In the reconstruction of the INC matrix, several virtual interference sources are set up around each of the actual jammers, such that the nulls can be broadened. Based on the reconstructed INC and signal-plus-noise covariance (SNC) matrices, the steering vector of the desired signal can be obtained by solving a new convex optimization problem. Simulation results show that the proposed beamformer can effectively broaden the null width and deepen the null depth, and its performance in interference cancellation is robust against fast-moving jammers or array platform motion. Furthermore, the null depth can be controlled by adjusting the power parameters in the reconstruction process and, if the direction of interference motion is known, the virtual interference sources can be set to achieve better performance. Full article
