Search Results (834)

Search Parameters:
Keywords = axial displacement

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
26 pages, 46031 KB
Article
Cross-Scale Modeling of CFRP Stacking Sequence in Filament-Wound Composite Pressure Vessels: In-Plane and Inter-Layer Homogenization Analysis
by Ziqi Wang, Ji Shi, Xiaodong Zhao, Hui Li, Huiming Shen, Jianguo Liang and Jun Feng
Materials 2025, 18(19), 4612; https://doi.org/10.3390/ma18194612 (registering DOI) - 5 Oct 2025
Viewed by 113
Abstract
Composite pressure vessels have attracted significant attention in recent years owing to their lightweight characteristics and superior mechanical performance. However, analyzing composite layers remains challenging due to complex filament-winding (FW) pattern structures and the associated high computational costs. This study introduces a homogenization [...] Read more.
Composite pressure vessels have attracted significant attention in recent years owing to their lightweight characteristics and superior mechanical performance. However, analyzing composite layers remains challenging due to complex filament-winding (FW) pattern structures and the associated high computational costs. This study introduces a homogenization method to achieve cross-scale modeling of carbon fiber-reinforced plastic (CFRP) layers, accounting for both lay-up sequence and in-plane FW diamond-shaped form. The stacking sequence in an FW Type IV composite pressure vessel is numerically investigated through ply modeling and cross-scale homogenization. The composite tank structure, featuring a polyamide PA66 liner, is designed for a working pressure of 70 MPa and comprises 12 helical winding layers and 17 hoop winding layers. An FW cross-undulation representative volume element (RVE) is developed based on actual in-plane mesostructures, suggesting an equivalent laminate RVE effective elastic modulus. Furthermore, six different lay-up sequences are numerically compared using ply models and fully and partially homogenized models. The structural displacements in both radial and axial directions are validated across all modeling approaches. The partial homogenization method successfully captures the detailed fiber-direction stress distribution in the innermost two hoop or helical layers. By applying the Hashin tensile failure criterion, the burst pressure of the composite tank is evaluated, revealing 7.56% deviation between the partial homogenization model and the ply model. Fatigue life analysis of the Type IV composite pressure vessel is conducted using ABAQUS® coupled with FE-SAFE, incorporating an S-N curve for polyamide PA66. The results indicate that the fatigue cycles of the liner exhibit only 0.28% variation across different stacking sequences, demonstrating that homogenization has a negligible impact on liner lifecycle predictions. The proposed cross-scale modeling framework offers an effective approach for multiscale simulation of FW composite pressure vessels, balancing computational efficiency with accuracy. Full article
Show Figures

Figure 1

25 pages, 6701 KB
Article
Experimental Study on Bearing Characteristics of Pile-Anchor Foundations for Floating Offshore Wind Turbines Under Inclined Loading
by Yuxuan Wang, Pingyu Liu, Bo Liu, Jiaqing Shu, Huiyuan Deng, Mingxing Zhu, Xiaojuan Li, Jie Chen and Haoran Ouyang
J. Mar. Sci. Eng. 2025, 13(10), 1890; https://doi.org/10.3390/jmse13101890 - 2 Oct 2025
Viewed by 203
Abstract
Pile-anchor foundations, serving as one of the anchoring solutions to ensure the safety and stability of floating offshore wind turbines, are primarily subjected to inclined loading induced by anchor chain forces, resulting in significantly different bearing behavior compared to conventional vertically loaded pile [...] Read more.
Pile-anchor foundations, serving as one of the anchoring solutions to ensure the safety and stability of floating offshore wind turbines, are primarily subjected to inclined loading induced by anchor chain forces, resulting in significantly different bearing behavior compared to conventional vertically loaded pile foundations. However, experimental research on the inclined pullout performance of anchor piles remains insufficient. To address this gap, this study employs a self-developed servo-controlled loading system to investigate the pullout bearing characteristics of anchor piles in dry and saturated sand, considering factors such as pullout angle and loading point depth. The research results show that from the load–displacement curve of the model pile, it can be found that with the increase in displacement, the load it bears first gradually increases to the peak, then decreases, and then gradually stabilizes. The loading angle has a significant impact on the bearing performance of pile-anchor foundations. As the loading angle increases, the failure mode shows pullout failure. When the loading angle increases from 30° to 60°, the bearing performance of the pile foundation decreases by approximately 63%. When the depth of the loading point increases from 0.22 times the pile length to 0.78 times the pile length, the diagonal anchor tensile bearing capacity of the model pile increases by approximately 45%. When the depth of the loading point is the same, the distribution patterns of bending moment and shear force are basically similar. However, the smaller the loading angle, the larger the value. This is because the horizontal load component plays a dominant role. The compression of the piles above and below the loading point, as well as the bending moment, shear force and axial force under saturated sand conditions, are similar to those in dry sand, but their values are reduced by about 50%. It can be seen that the soil conditions have an influence on the bearing characteristics of pile foundations. Full article
(This article belongs to the Section Coastal Engineering)
Show Figures

Figure 1

23 pages, 7674 KB
Article
Lateral Impact Performance of Cold-Formed Steel L-Shaped Built-Up Columns
by Mengyao Li, Jinshan Sun, Yi Hu, Liqiang Jiang, Shizhong Zhou, Guangwei Dai and Ning Wu
Materials 2025, 18(19), 4548; https://doi.org/10.3390/ma18194548 - 30 Sep 2025
Viewed by 291
Abstract
Blasts, vehicle collisions, and other unexpected incidents may cause lateral impacts on building structures, which threaten their safety. This paper investigates the impact resistance of cold-formed steel (CFS) L-shaped built-up columns (LBC). Firstly, a finite element model (FEM) was established and validated through [...] Read more.
Blasts, vehicle collisions, and other unexpected incidents may cause lateral impacts on building structures, which threaten their safety. This paper investigates the impact resistance of cold-formed steel (CFS) L-shaped built-up columns (LBC). Firstly, a finite element model (FEM) was established and validated through experiments conducted by the authors. Then, a parametric analysis was conducted to quantify the effects of axial compression ratio, impact velocity, and dimensions on the impact response. The results indicated that: (1) The peak lateral impact force of the specimens presented a significant nonlinear trend with increasing axial compression ratio, and an optimal axial compression ratio was found as about 0.3. (2) Higher impact velocity intensified both force and displacement responses of the specimens, and both lateral impact peak force and maximum displacement increased significantly with the impact velocity. When the impact velocity rose from 3.13 m/s to 6.26 m/s, the peak force and maximum displacement increased by an average of 38.2% and 96.5%, respectively. (3) Increasing the cross-sectional dimensions and steel thickness, and reducing screw spacing, could significantly enhance the impact resistance and deformation capacity of the specimens. This study reveals the failure mechanism of such members and the laws of parameter influence, which can be used for impact design of CFS-LBC. Full article
(This article belongs to the Special Issue Advances in Sustainable Construction Materials, Third Edition)
Show Figures

Figure 1

25 pages, 11496 KB
Article
Axial Force Analysis and Geometric Nonlinear Beam-Spring Finite Element Calculation of Micro Anti-Slide Piles
by Guoping Lei, Dongmei Yuan, Zexiong Wu and Feifan Liu
Buildings 2025, 15(19), 3498; https://doi.org/10.3390/buildings15193498 - 28 Sep 2025
Viewed by 151
Abstract
This study investigates the development of axial force in micro anti-slide piles under soil movement during slope stabilization. Axial force arises from two primary mechanisms: axial soil displacement (zs) and pile kinematics. The former plays a dominant role, producing either [...] Read more.
This study investigates the development of axial force in micro anti-slide piles under soil movement during slope stabilization. Axial force arises from two primary mechanisms: axial soil displacement (zs) and pile kinematics. The former plays a dominant role, producing either tensile or compressive axial force depending on the direction of zs, while the kinematically induced component remains consistently tensile. A sliding angle of α=5° represents an approximate transition point where these two effects balance each other. Furthermore, the two mechanisms exhibit distinct mobilization behaviors: zs-induced axial force mobilizes earlier than both bending moment and shear force, whereas kinematically induced axial force mobilizes significantly later. The study reveals two distinct pile–soil interaction mechanisms depending on proximity to the slip surface: away from the slip surface, axial soil resistance is governed by rigid cross-section translation, whereas near the slip surface, rotation-dominated displacement accompanied by soil–pile separation introduces significant complexity in predicting both the magnitude and direction of axial friction. A hyperbolic formulation was adopted to model both the lateral soil resistance relative to lateral pile–soil displacement (p-y behavior) and the axial frictional resistance relative to axial pile–soil displacement (t-z behavior). Soil resistance equations were derived to explicitly incorporate the effects of cross-sectional rotation and pile–soil separation. A novel beam-spring finite element method (BSFEM) that incorporates both geometric and material nonlinearities of the pile behavior was developed, using a soil displacement-driven solution algorithm. Validation against both numerical simulations and field monitoring data from an engineering application demonstrates the model’s effectiveness in capturing the distribution and evolution of axial deformation and axial force in micropiles under varying soil movement conditions. Full article
Show Figures

Figure 1

17 pages, 17502 KB
Article
Multiscale Compressive Failure Analysis of Wrinkled Laminates Based on Multiaxial Damage Model
by Jian Shi, Guang Yang, Nan Sun, Jie Zheng, Jingjing Qian, Wenjia Wang and Kun Song
Materials 2025, 18(19), 4503; https://doi.org/10.3390/ma18194503 - 27 Sep 2025
Viewed by 225
Abstract
The waviness defect, a common manufacturing flaw in composite structures, can significantly impact the mechanical performance. This study investigates the effects of wrinkles on the ultimate load and failure modes of two Carbon Fiber Reinforced Composite (CFRC) laminates through compressive experiments and simulation [...] Read more.
The waviness defect, a common manufacturing flaw in composite structures, can significantly impact the mechanical performance. This study investigates the effects of wrinkles on the ultimate load and failure modes of two Carbon Fiber Reinforced Composite (CFRC) laminates through compressive experiments and simulation analyses. The laminates have stacking sequences of [0]10S and [45/0/−45/90/45/0/−45/0/45/0]S. Each laminate includes four different waviness ratios (the ratio of wrinkle amplitude to laminate thickness) of 0%, 10%, 20% and 30%. In the simulation, a novel multiaxial progressive damage model is implemented via the user material (UMAT) subroutine to predict the compressive failure behavior of wrinkled composite laminates. This multiscale analysis framework innovatively features a 7 × 7 generalized method of cells coupled with stress-based multiaxial Hashin failure criteria to accurately analyze the impact of wrinkle defects on structural performance and efficiently transfer macro-microscopic damage variables. When any microscopic subcell within the representative unit cell (RUC) satisfies a failure criterion, its stiffness matrix is reduced to a nominal value, and the corresponding failure modes are tracked through state variables. When more than 50% fiber subcells fail in the fiber direction or more than 50% matrix subcells fail in the transverse or thickness direction, it indicates that the RUC has experienced the corresponding failure modes, which are the tensile or compressive failure of fibers, matrix, or delamination in the three axial directions. This multiscale model accurately predicted the load–displacement curves and failure modes of wrinkled composites under compressive load, showing good agreement with experimental results. The analysis results indicate that wrinkle defects can reduce the ultimate load-carrying capacity and promote local buckling deformation at the wrinkled region, leading to changes in damage distribution and failure modes. Full article
Show Figures

Figure 1

15 pages, 3057 KB
Case Report
Rack-and-Pinion Displacement of an Intramedullary Pin During Minimally Invasive Plate–Rod Osteosynthesis of the Canine Femur—A Case Report
by Daniel J. Wills, Max J. Lloyd, Kristy L. Hospes and William R. Walsh
Animals 2025, 15(19), 2777; https://doi.org/10.3390/ani15192777 - 23 Sep 2025
Viewed by 361
Abstract
We present a case of unexpected proximal displacement of an intramedullary pin (IMP) during plate–rod repair of a femoral fracture caused by minimally invasive plate osteosynthesis (MIPO), requiring immediate revision. Implant retrieval analysis and ex vivo modelling were performed to characterise the technique [...] Read more.
We present a case of unexpected proximal displacement of an intramedullary pin (IMP) during plate–rod repair of a femoral fracture caused by minimally invasive plate osteosynthesis (MIPO), requiring immediate revision. Implant retrieval analysis and ex vivo modelling were performed to characterise the technique failure mode. The case details are reported. Implant retrieval analysis consisted of stereo zoom microscopic examination of the retrieved IMP. Wear patterns formed by conflict with a 2.8 mm, two-fluted surgical drill bit and a 3.5 mm AO locking screw were replicated using a simple paper impression model. The mechanism of pin movement was replicated in a benchtop laminated polyurethane foam block model, and wear patterns produced during drilling and screw insertion were characterised using stereo zoom. The wear pattern visible on the retrieved IMP suggested axial displacement caused by a rack-and-pinion-like mechanism, enacted by contact with either the drill bit or locking screws during placement of the repair construct. Significant axial displacement of the IMP due to conflict with screws during construct placement is possible during the placement of plate–rod fixation. Surgeons should confirm implant positioning if implant conflict is recognised intra-operatively. Full article
(This article belongs to the Special Issue Advanced Management of Small Animal Fractures)
Show Figures

Figure 1

19 pages, 6922 KB
Article
Mechanical Insertion Force and Electrical Contact Resistance of By-Pass Switches with Axially Canted Coil Springs
by Chao Zhang, Ming Li, Wanbin Ren and Jian Liu
Machines 2025, 13(9), 878; https://doi.org/10.3390/machines13090878 - 21 Sep 2025
Viewed by 397
Abstract
By-pass switches play a crucial role in high-power electrical equipment, where reliable mechanical insertion and stable electrical contact are essential for safety and performance. However, few computational models have been developed to characterize the coupled mechanical–electrical behavior of by-pass switches with axially canted [...] Read more.
By-pass switches play a crucial role in high-power electrical equipment, where reliable mechanical insertion and stable electrical contact are essential for safety and performance. However, few computational models have been developed to characterize the coupled mechanical–electrical behavior of by-pass switches with axially canted coil springs, which limits the understanding of their structural parameter effects. Motivated by this gap, this work investigates the mechanical insertion force and electrical contact resistance of by-pass switches with axially canted coil spring by combining analytical modeling and finite element simulation. The variations in mechanical insertion force, contact force and associated contact resistance as functions of the insertion displacement are presented. The total electrical contact resistance could comprise three components of resistance, that is, constriction resistance between multiple turns of coil spring wires and pin, constriction resistance between multiple turns of coil spring wires and V-shape groove, and the bulk resistance. The effects of structure feature parameters (including turns, spring wire diameter, inclination angle of axially canted coil spring wire, cylindrical pin chamfer radius and V-shape groove angle) are evaluated. Subsequently, the associated empirical formulas are established to guide the design of by-pass switches with axially canted coil springs. Full article
(This article belongs to the Section Machine Design and Theory)
Show Figures

Figure 1

16 pages, 2244 KB
Article
Biomechanical Analysis of Fixation Strength in Unstable Intertrochanteric Femoral Fracture Models Based on the Caput–Collum–Diaphyseal Angle of Cephalomedullary Nails and Position of Lag Screws
by Yong-Cheol Yoon, Sung-Jae Lee and Hyung Keun Song
J. Clin. Med. 2025, 14(18), 6495; https://doi.org/10.3390/jcm14186495 - 15 Sep 2025
Viewed by 405
Abstract
Background/Objectives: The combined effect of femoral neck–shaft angle and lag screw position on unstable intertrochanteric fracture fixation has not been well established. This biomechanical study evaluated the effects of two caput–collum–diaphyseal (CCD) angles and two lag screw positions on construct stability. Methods: Twenty-four [...] Read more.
Background/Objectives: The combined effect of femoral neck–shaft angle and lag screw position on unstable intertrochanteric fracture fixation has not been well established. This biomechanical study evaluated the effects of two caput–collum–diaphyseal (CCD) angles and two lag screw positions on construct stability. Methods: Twenty-four synthetic femurs with identical AO/OTA 31-A2.2 fracture gaps (2 mm) were fixed using cephalomedullary nails with CCD angles of either 125° or 130°, each with a central or inferior (calcar) lag screw (n = 6/group). Constructs were tested in a single-leg stance under preloading, cyclic loading (75–750 N, 10,000 cycles, and 2 Hz), and axial loading to failure. Lag screw migration was measured radiographically, and femoral head rotation was recorded using a three-dimensional coordinate-measuring device. Stiffness, failure load, and rotations were compared using the Kruskal–Wallis and Bonferroni post hoc tests. Results: The 125° inferior configuration showed the highest stiffness (188 ± 15 N/mm, p = 0.038) and failure load (1350 ± 97 N, p = 0.047), with the least screw migration (0.54 ± 0.11 mm, p = 0.003), significantly outperforming the 125° central and 130° central constructs. However, it exhibited greater varus collapse (2.25 ± 0.27°, p = 0.013) and axial rotation (~20–30% higher than others, p = 0.025). Screw position had a stronger effect on stability than the CCD angle, although the 130° inferior construct showed slightly less varus deformation. Conclusions: An inferior calcar-guided lag screw improves fixation strength and stiffness in unstable intertrochanteric fractures, particularly in those with a 125° nail. However, this configuration increases varus and rotational displacement, warranting adjunct measures to enhance rotational control in clinical applications. Full article
(This article belongs to the Section Orthopedics)
Show Figures

Figure 1

38 pages, 15055 KB
Article
Towards a Generative Frame System of Ancient Chinese Timber Architecture: Structural Generation and Optimization of “Column Reduction” and “Column Relocation”
by Tonghao Liu, Binyue Zhang and Yamin Zhao
Buildings 2025, 15(18), 3329; https://doi.org/10.3390/buildings15183329 - 15 Sep 2025
Viewed by 516
Abstract
In traditional Chinese timber architecture, “column reduction” (Jian Zhu Zao) and “column relocation” (Yi Zhu Zao) enhances spatial continuity, yet often produces bending-dominated, material-intensive frames. This study develops a generative frame system that encodes raised beam logic into a parametric line-model workflow and [...] Read more.
In traditional Chinese timber architecture, “column reduction” (Jian Zhu Zao) and “column relocation” (Yi Zhu Zao) enhances spatial continuity, yet often produces bending-dominated, material-intensive frames. This study develops a generative frame system that encodes raised beam logic into a parametric line-model workflow and couples it with simulation-based optimization. Informed by case analysis, the tool implements three lateral strategies—ridge-support revision, insertion of inclined members, and inclination of originally horizontal members—and one longitudinal strategy—longitudinal truss formation—whose use is governed by a user-defined historical authenticity parameter. Structural responses were evaluated using Karamba3D, and cross-section sizing was searched using Wallacei under gravity-dominant loading. The results indicate clearer load paths, greater axial-force participation, and reduced bending, yielding lower maximum displacements at comparable self-weight; moreover, the performance ranking aligns with the calibrated authenticity loss schedule, suggesting that the authenticity controller also acts as a practical proxy for expected stiffness gains. The framework improves design and modeling efficiency while offering quantitative decision support for culturally sensitive conservation and imitation design. Limitations include line-model idealization, simplified timber and joint behavior, gravity-only loading, and a modest historical corpus. The approach is extensible to other traditional systems via parameter and rule adaptation. Full article
(This article belongs to the Section Architectural Design, Urban Science, and Real Estate)
Show Figures

Figure 1

11 pages, 3471 KB
Article
Annular Ligament Instability in Lateral Elbow Pathology: Objective Confirmation Through a Cadaveric Study
by Daniel Berlanga de Mingo, Guillem Paz Ramírez, Arnau Moreno Garcia, Maria Tibau Alberdi, Diana Noriego Muñoz, Miguel Pérez Abad, Giacomo Rossettini, Jorge Hugo Villafañe, César Abellán Miralles, Montserrat del Valle Jou, Àngel Ferreres Claramunt and Alfonso Rodríguez Baeza
Muscles 2025, 4(3), 39; https://doi.org/10.3390/muscles4030039 - 15 Sep 2025
Viewed by 319
Abstract
Background: The annular ligament is a key secondary stabilizer of the elbow, but its biomechanical behavior during forearm rotation has not been objectively quantified. This study aimed to assess interindividual variability in annular ligament tension, validate prior arthroscopic observations, and explore associations with [...] Read more.
Background: The annular ligament is a key secondary stabilizer of the elbow, but its biomechanical behavior during forearm rotation has not been objectively quantified. This study aimed to assess interindividual variability in annular ligament tension, validate prior arthroscopic observations, and explore associations with chondral lesions in the lateral elbow compartment. Methods: In this cross-sectional anatomical study, 25 cadaveric upper limbs were analyzed following standardized dissection, preserving ligamentous and muscular integrity. Ligament displacement was measured using a custom mechanical apparatus and high-precision digital micrometer in neutral, 60° pronation, and 60° supination positions under axial tractions of 1, 2, and 3 kg. Ulnar length and presence of chondral lesions were also recorded. Results: Maximal ligament displacement occurred in supination in 80% of specimens (mean: 1.23 mm at 3 kg; range: 0.30–2.87 mm), indicating considerable interindividual variation. Significant displacement differences were observed between all forearm positions across load levels (p < 0.001). Chondral lesions were identified in three specimens with marked ligament laxity and reduced radial head coverage. Conclusions: This study provides the first objective evidence of annular ligament tension variability during forearm rotation. Ligament laxity may contribute to lateral elbow instability and cartilage degeneration, supporting the ligament’s role as a secondary stabilizer. Full article
Show Figures

Figure 1

19 pages, 5840 KB
Article
Research on Energy Localization and Vibration Suppression of Axially Functionally Graded Porous Beams
by Qiuhua Wang, Rongjiang Tang, Sai Zhang, Kefang Cai, Wenwen Wang and Xuekang Zhang
Materials 2025, 18(18), 4306; https://doi.org/10.3390/ma18184306 - 14 Sep 2025
Viewed by 423
Abstract
Functionally graded porous beam (FGPB) structures are widely used in engineering due to their light weight, high strength, and vibration-damping performance. However, their energy localization and vibration suppression characteristics remain largely unexplored. To address this gap, this study proposes an axially functionally graded [...] Read more.
Functionally graded porous beam (FGPB) structures are widely used in engineering due to their light weight, high strength, and vibration-damping performance. However, their energy localization and vibration suppression characteristics remain largely unexplored. To address this gap, this study proposes an axially functionally graded porous beam (AFGPB) structure capable of achieving energy localization and suppressing vibration transmission. A semi-analytical model is first developed within the Rayleigh–Ritz framework, using Gaussian functions as basis functions to accurately represent the displacement field. The accuracy of the model is validated by comparing its vibration characteristics with those obtained using the finite element method (FEM). Subsequently, the vibration behavior of double-AFGPB with simply supported boundary constraints is investigated. A series of numerical results are presented in this study to analyze the influence of porosity parameters on the energy localization effect and vibration suppression performance. Results reveal that the porosity power-law index N and truncation coefficient δ play key roles in energy localization and vibration suppression performance. When N ≥ 4, the energy localization effect and the vibration attenuation of the double-AFGPB become more pronounced with increasing N and decreasing δ, particularly in the low-frequency range. Full article
(This article belongs to the Special Issue Research on Vibration of Composite Structures)
Show Figures

Figure 1

20 pages, 4917 KB
Article
Innovative Seismic Strengthening of Reinforced Concrete Frames with U-Shaped Precast Concrete Wall Panels: Experimental Performance Assessment
by Sookyoung Ha
Buildings 2025, 15(18), 3273; https://doi.org/10.3390/buildings15183273 - 10 Sep 2025
Viewed by 281
Abstract
Many existing reinforced concrete (RC) frames with brick infill walls are vulnerable to earthquake damage, particularly when the walls contain window openings that reduce the lateral resistance. This study aims to examine the seismic performance of RC frames strengthened with U-shaped precast concrete [...] Read more.
Many existing reinforced concrete (RC) frames with brick infill walls are vulnerable to earthquake damage, particularly when the walls contain window openings that reduce the lateral resistance. This study aims to examine the seismic performance of RC frames strengthened with U-shaped precast concrete (PC) wall panels. In the proposed method, the window-containing brick infill walls within the RC frames are replaced with factory-fabricated U-shaped PC wall panels, thereby converting the infill into a strong and rigid structural element while preserving the openings. The panels are anchored to the RC frame using post-installed anchors inserted through predrilled holes, allowing for rapid and secure installation with minimal on-site work. To validate the method, five full-scale, one-bay, one-story RC frames were constructed and tested under reversed cyclic lateral loading. Three frames were strengthened with U-shaped PC wall panels of varying thicknesses and large openings. Displacement-controlled cycles following ACI 374.1-05 (R7.0) were applied, with three cycles at each drift ratio stage, and no axial load was applied to the columns. Compared with the reference specimen with a U-shaped brick wall, the strengthened frames exhibited up to 3.29 times higher lateral strength, 4.39 times higher initial stiffness, and 4.33 times greater energy dissipation capacity. These findings demonstrate that the proposed strengthening technique significantly enhances seismic resistance while maintaining the architectural openings, offering a practical and efficient solution for upgrading low-rise RC buildings. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

27 pages, 5221 KB
Article
Post-Fire Performance of Bolted Steel T-Joints with Varying Coating Thicknesses: Experimental and Finite Element Analysis
by Zeynep Yaman, Mahyar Maali, Elif Ağcakoca, Mohammad Saber Sadid, Abdulkadir Cüneyt Aydin and Hüsna Ekşi
Buildings 2025, 15(18), 3257; https://doi.org/10.3390/buildings15183257 - 9 Sep 2025
Viewed by 475
Abstract
This study investigates the structural performance of bolted T-joints in steel elements exposed to elevated temperatures, with a focus on the influence of fire-resistant coatings. A total of 36 T-joint specimens were tested under four different temperature levels (300 °C, 450 °C, 600 [...] Read more.
This study investigates the structural performance of bolted T-joints in steel elements exposed to elevated temperatures, with a focus on the influence of fire-resistant coatings. A total of 36 T-joint specimens were tested under four different temperature levels (300 °C, 450 °C, 600 °C, and 900 °C), incorporating three IPE section sizes and three fire-resistant paint thicknesses (200 µm, 400 µm, and 600 µm). The experimental program aimed to evaluate the combined effects of temperature, cross-sectional geometry, and coating thickness on the axial load-bearing capacity and deformation characteristics of T-joints. To examine the influence of web geometry, T-sections were designed in accordance with Eurocode 3, and the flange-to-web thickness ratios (tf/tw) were varied between 1.52 and 1.58. Results showed that applying 200 µm and 400 µm coatings at 300 °C and 450 °C improved the axial load capacity by approximately 10% and 20%, respectively, compared to uncoated specimens. However, effective fire protection at higher temperatures (600 °C and 900 °C) required a minimum coating thickness exceeding 400 µm. Finite Element Models developed using ABAQUS (2017) were designed to predict post-fire load–displacement behavior, stiffness degradation, and failure modes. Predictions were validated against experimental results, with deviations ranging from 0.97% to 9.73% for maximum load and 1.18% to 42.13% for energy dissipation, confirming the model’s reliability in simulating the thermo-mechanical response of steel joints under fire exposure. Full article
Show Figures

Figure 1

18 pages, 4746 KB
Article
An Analytical Solution for Short Thin-Walled Beams with Monosymmetric Open Sections Subjected to Eccentric Axial Loading
by Branka Bužančić Primorac, Marko Vukasović, Radoslav Pavazza and Frane Vlak
Appl. Mech. 2025, 6(3), 68; https://doi.org/10.3390/applmech6030068 - 5 Sep 2025
Viewed by 539
Abstract
A simple analytic procedure for the linear static analysis of short thin-walled beams with monosymmetric open cross-sections subjected to eccentric axial loading is presented. Under eccentric compressive loading, the beam is subjected to compression/extension, to torsion with influence of shear with respect to [...] Read more.
A simple analytic procedure for the linear static analysis of short thin-walled beams with monosymmetric open cross-sections subjected to eccentric axial loading is presented. Under eccentric compressive loading, the beam is subjected to compression/extension, to torsion with influence of shear with respect to the principal pole and to bending with influence of shear in two principal planes. The approximate closed-form solutions for displacements consist of the general Vlasov’s solutions and additional displacements due to shear according to the theory of torsion with the influence of shear, as well as the theory of bending with the influence of shear. The internal forces and displacements for beams clamped at one end and simply supported on the other end, where eccentric loading is acting, are calculated using the method of initial parameters. The shear coefficients for the monosymmetric cross-sections introduced in these equations are provided. Solutions for normal stress and total displacements according to Vlasov’s general thin-walled beam theory, and those obtained with the proposed method taking shear influence into account, are compared with shell finite element solutions analyzing isotropic and orthotropic I-section beams. According to the results for normal stress relative differences, and Euclidean norm for displacements, it has been demonstrated that shear effects must be accounted for in the analysis of such structural problems. Full article
Show Figures

Figure 1

16 pages, 4056 KB
Article
Experimental Study on Compressive Behavior of CFRP-Confined Pre-Damaged Pinus sylvestris var. mongolia Composited Wooden Column
by Sheng Peng, Wei Lou, Yifan Qiao, Lanyu Liu, Huacheng Liu and Dongping Wu
Buildings 2025, 15(17), 3173; https://doi.org/10.3390/buildings15173173 - 3 Sep 2025
Viewed by 421
Abstract
In China, most of the ancient wooden structure mortise and tenon buildings, under the long-term upper load, have columns with surface surfaces that have varying degrees of damage, which need to be repaired and strengthened urgently, but the theory related to CFRP, mortise [...] Read more.
In China, most of the ancient wooden structure mortise and tenon buildings, under the long-term upper load, have columns with surface surfaces that have varying degrees of damage, which need to be repaired and strengthened urgently, but the theory related to CFRP, mortise size, and pre-damage simulation still needs to be deeply studied. To investigate the effects of CFRP reinforcement layers, cross-sectional area of concealed tenons as the projected area after installation, and tenon engagement length as the axial length after installation on the axial compressive mechanical properties of pre-damaged quad-segment spliced Pinus sylvestris var. mongolia composited wooden columns, axial compression failure tests were conducted on 10 specimens following pre-damage simulation and CFRP strengthening. The experimental program yielded comprehensive data, including observations, mechanical analyses, load-displacement curves, load-strain curves, ultimate load-bearing capacities, ductility coefficients, and stiffness values. The results demonstrate that with consistent tenon cross-sectional area and engagement length, increasing CFRP layers from 1 to 3 raises the ultimate bearing capacity from 472.3 kN to 620.3 kN and improves the ductility coefficient from 4.67 to 7.95, clearly indicating that CFRP reinforcement significantly enhances axial compressive performance while effectively mitigating brittle failure. When maintaining constant CFRP layers and tenon cross-sectional area, extending the tenon engagement length from 30 mm to 90 mm elevates the bearing capacity from 494.95 kN to 546.3 kN and boosts the ductility coefficient from 5.58 to 7.95. In contrast, with fixed CFRP layers and engagement length, expanding the tenon cross-sectional area from 360 mm2 to 810 mm2 produces only marginal bearing capacity improvement from 548.2 kN to 556.2 kN with ductility coefficients ranging between 4.67 and 5.56, conclusively revealing that tenon engagement length has substantially greater influence on mechanical properties than cross-sectional area. The optimal axial compressive performance configuration combines 3 CFRP layers, an 810 mm2 tenon cross-section, and a 90 mm engagement length. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1
