The dynamic loads affecting earth-retaining structures may increase in seismically active regions. Therefore, studying the soil–structure interaction among the soil, shoring systems, and adjacent structures is crucial. However, there is limited research on this important topic. This study investigates the seismic performance of a deep braced excavation and a nearby 10-story building in sandy soil formation. The main focus of this study is the consideration of the influence of varying foundation depths of adjacent structures on the seismic response of the shoring system and the performance of the shoring system and adjacent structure under different earthquake records. PLAXIS 2D software (Version 22.02) was used to carry out the numerical analysis. Sandy soil was modeled using the Hardening Soil with small-strain stiffness model (HS-small). Back analysis of observation data extracted from a real case study of a deep braced excavation in the central district of Kaohsiung City, adjacent to the O₇ Station on the Orange Line of the Kaohsiung MRT system in Taiwan, was used to validate the numerical analysis. Beyond model validation, a parametric study was conducted to address the effect of the foundation level of the building adjacent to the excavation on both the seismic behavior of the shoring system and the structure itself, using the Loma-Prieta (1989) earthquake record. The parametric study was further extended to assess the responses of the shoring system and the adjacent structure under the influence of the earthquake records of Loma-Prieta (1989), Northridge (1994), and El-Centro (1940). The results show that the maximum lateral displacement of the diaphragm wall occurred at the top of the wall in all studied cases. The maximum dynamic bending moment in the retaining structure was more than three times the static one on average. In contrast, the dynamic shear force was more than 2.85 times the static one on average. In addition, the dynamic axial force of the first and second struts was 1.38 and 3.17 times the static forces, respectively. The results also reveal large differences in the behavior of the shoring system and the adjacent structure between the different earthquake records. Full article

Relying on an engineering case, this study establishes an analysis model using PLAXIS 3D and GeoStudio, and compares and analyzes the slope deformation and internal force of the supporting structure with different slope grades and different platform widths at the same height. The results show that the greatest displacement manifests in the lower segments of the slope, which is 12.99 mm, and the maximum anchoring force manifests in the mid-level and lower segments of the slope, which is 288.1 kN. A close correlation is observed between the simulated horizontal displacement of the slope, the maximum axial force of the anchor cable, and the corresponding field measurement results, indicating that the model parameters are satisfactory and that the resulting calculations are reliable. In consideration of the comprehensive stability of the slope, the stability coefficient increased by approximately 1.42% with two-stage slope support and by about 3.48% with four-stage slope support. The axial force of anchor cables was reduced by around 9.5% under two-stage grading, while four-stage grading decreased the maximum axial force of the middle–lower anchors by nearly 27%. The distance between the entrance and exit of the overall sliding surface and the slope surface also decreases with the increase in slope grading and platform width. This study systematically evaluates the combined effects of slope grading, platform width, and frame prestressed anchors. When site conditions permit, slope grading should be prioritized over simply widening the platform, as grading more effectively enhances slope stability and reduces anchor cable loads. Full article

Shaft deflection degrades roller alignment and intensifies stress concentration/edge effects at roller-ends and raceway edges, ultimately compromising service performance of tapered roller bearings (TRBs). Therefore, a dynamic model was developed for a TRB subjected to a deflected shaft in which Johnson’s load–deformation relationship was applied to reflect non-uniform cross-sectional structures of the tapered rollers and raceways, viscous damping was integrated into the roller/cage interaction, and friction actions at the raceways and flange areas were treated separately. Then, moment load and angular misalignment of the tapered roller were analyzed under various shaft deflection and operating conditions. Results indicate that tilt angle remains orders of magnitude smaller than skew angle. Shaft deflection amplifies both skew and tilt, and the influence level is proportional to the bearing size. Centrifugal effect primarily affects skew motion, whereas gyroscopic effect mainly influences tilt motion. Axial forces exert greater influence on roller skew than tilt. The flange typically constrains roller skew, whereas both raceways may induce bidirectional tilt/skew motion. Full article

Special-shaped concrete-filled steel tube (CFST) frames can be embedded in partition walls to improve space utilization, but their frame-level seismic behavior across joint types remains under-documented. This study examines six two-story, single-bay frames with cruciform, T-, and L-shaped CFST columns and three joint configurations: external hoops with vertical ribs, fully bolted joints, and fully bolted joints with replaceable flange plates. Low-cycle reversed loading tests were combined with validated ABAQUS and OpenSees models to interpret mechanisms and conduct parametric analyses. All frames exhibited stable spindle-shaped hysteresis with minor pinching; equivalent viscous damping reached 0.13–0.25, ductility coefficients 3.03–3.69, and drift angles 0.088–0.126 rad. Hooped-and-ribbed joints showed the highest capacity and energy dissipation, while replaceable joints localized damage for rapid repair. Parametric results revealed that increasing the steel grade and steel ratio (≈5–20%) improved seismic indices more effectively than raising the concrete strength. Recommended design windows include axial load ratio < 0.4–0.5, slenderness ≤ 30, stiffness ratio ≈ 0.36, and flexural-capacity ratio ≈ 1.0. These findings provide symmetry-based, repair-oriented guidance for transportation buildings requiring rapid post-earthquake recovery. Full article

Background: The annular ligament is a key secondary stabilizer of the elbow, but its biomechanical behavior during forearm rotation has not been objectively quantified. This study aimed to assess interindividual variability in annular ligament tension, validate prior arthroscopic observations, and explore associations with chondral lesions in the lateral elbow compartment. Methods: In this cross-sectional anatomical study, 25 cadaveric upper limbs were analyzed following standardized dissection, preserving ligamentous and muscular integrity. Ligament displacement was measured using a custom mechanical apparatus and high-precision digital micrometer in neutral, 60° pronation, and 60° supination positions under axial tractions of 1, 2, and 3 kg. Ulnar length and presence of chondral lesions were also recorded. Results: Maximal ligament displacement occurred in supination in 80% of specimens (mean: 1.23 mm at 3 kg; range: 0.30–2.87 mm), indicating considerable interindividual variation. Significant displacement differences were observed between all forearm positions across load levels (p < 0.001). Chondral lesions were identified in three specimens with marked ligament laxity and reduced radial head coverage. Conclusions: This study provides the first objective evidence of annular ligament tension variability during forearm rotation. Ligament laxity may contribute to lateral elbow instability and cartilage degeneration, supporting the ligament’s role as a secondary stabilizer. Full article

This study investigates the structural performance of bolted T-joints in steel elements exposed to elevated temperatures, with a focus on the influence of fire-resistant coatings. A total of 36 T-joint specimens were tested under four different temperature levels (300 °C, 450 °C, 600 °C, and 900 °C), incorporating three IPE section sizes and three fire-resistant paint thicknesses (200 µm, 400 µm, and 600 µm). The experimental program aimed to evaluate the combined effects of temperature, cross-sectional geometry, and coating thickness on the axial load-bearing capacity and deformation characteristics of T-joints. To examine the influence of web geometry, T-sections were designed in accordance with Eurocode 3, and the flange-to-web thickness ratios (tf/tw) were varied between 1.52 and 1.58. Results showed that applying 200 µm and 400 µm coatings at 300 °C and 450 °C improved the axial load capacity by approximately 10% and 20%, respectively, compared to uncoated specimens. However, effective fire protection at higher temperatures (600 °C and 900 °C) required a minimum coating thickness exceeding 400 µm. Finite Element Models developed using ABAQUS (2017) were designed to predict post-fire load–displacement behavior, stiffness degradation, and failure modes. Predictions were validated against experimental results, with deviations ranging from 0.97% to 9.73% for maximum load and 1.18% to 42.13% for energy dissipation, confirming the model’s reliability in simulating the thermo-mechanical response of steel joints under fire exposure. Full article

The traditional research methods of the notch frequency phenomenon are mainly discussed by experimental observation or the semi-analytical finite element method. In this paper, the notch frequency characteristics of ultrasonic guided waves are simulated by the general finite element method. Firstly, the theoretical dispersion curve of the longitudinal mode in the axially loaded rod is derived by the acoustic elasticity theory, and the finite element simulation is carried out by ABAQUS/Explicit 6.14 to simulate the wave propagation in the seven-wire steel strand. In order to verify the model, laboratory experiments are carried out on three types of prestressed steel strands with diameters of 12.7 mm, 15.2 mm, and 17.8 mm, respectively. Each specimen is gradually loaded from 50 kN to 110 kN in increments of 30 kN. At each loading level, the ultrasonic signal is obtained, and the corresponding notch frequency is extracted from the spectrum. The experimental results confirm the accuracy of the model, and the maximum deviation between the predicted notch frequency and the measured value is 3%. The results show that the proposed method provides a robust and non-destructive means for structural health monitoring in civil engineering applications, and has the potential to be more widely used in complex waveguide structures. Full article

This work presents an experimental study of the effect of blade count on the flow field and the radiated noise in a low-speed axial fan with a rotating shroud. A two-component Laser Doppler Velocimetry (LDV) system and Particle Image Velocimetry (PIV) instrumentation have been employed to investigate the flow in the gap region and in front of the rotor blades. Additionally, the fan has been installed in a hemi-anechoic chamber and far-field acoustic measurements have been taken with a microphone mounted on-axis upstream of the rotor to show changes in the spectral features of the radiated noise. The tested rotor is a variable-geometry one that has allowed for studying rotor configurations with different numbers of blades of the same chord and shape, i.e., of the same geometry but different solidity. Rotor pressure rise and flow rate are average quantities that have a relevant effect on the leakage flow. Keeping them fixed while varying solidity allows us to highlight the local effects of circumferential pressure non-uniformity caused by differing blade loading. The results show that, at low solidity, the flow leaving the gap is mainly directed radially outward and follows a longer path before being ingested by the rotor, thus losing strength due to mixing with the main flow. As solidity increases, the flow becomes less radial and is more rapidly ingested by the rotor. In all cases, the sound pressure level spectrum shows marked subharmonic humps and peaks originating from the interaction between the leakage flow and rotor. The departure of such peaks from the blade passing frequency increases with the solidity, while the associated energy increases up to seven blades and then decreases. Full article

This paper experimentally investigates the fretting fatigue behavior of metal additive-manufactured Ti-6Al-4V alloy specimens fabricated using the selective laser melting (SLM) method, focusing on damage characterization and fatigue life assessment. Based on the ASTM E466 standard, the test components were manufactured using metal 3D printing technology. Fretting fatigue tests were conducted under varying axial stress levels and contact loads, followed by microscopic examinations using scanning electron microscopy (SEM) to analyze damage mechanisms. A fretting map was developed based on SEM observations, providing insights into damage evolution under different loading conditions. These findings contribute to a better understanding of the relationship between fretting fatigue parameters and failure mechanisms. The developed fretting map and experimental observations provide a foundation for further studies aimed at enhancing the fretting fatigue life assessment of standard specimens for different test parameters. Finally, this paper includes design-oriented evaluation frameworks that can guide engineers in integrating AM components into safety-critical systems under fretting fatigue conditions. Full article

Based on the G85 high-fill subgrade project in east Gansu Province, this study conducts one-dimensional compression tests in the laboratory on both disturbed and in situ-compacted loess. Through the combination of the test results of remolded soil, compaction standards for each layer of the subgrade fill are established, and quality inspections of the compacted subgrade are performed. The experimental results demonstrate that the compression deformation of remolded loess exhibits a positive correlation with compaction degree and a negative correlation with moisture content. Under constant compaction degree conditions, axial pressure and deformation follow a linear relationship, whereas under fixed conditions, the relationship adheres to a quadratic trend. Specimen void ratios show minimal variation within the 25–100 kPa stress range but undergo significant reduction between 100 and 400 kPa. Under an axial compressive load of 100–200 kPa, the compression coefficient at a height of 10 m within the subgrade ranges from 0.163 to 0.171 MPa⁻¹. At a height of 6 m, it ranges from 0.177 to 0.183 MPa⁻¹, and at 1 m, from 0.183 to 0.186 MPa⁻¹. These values indicate that the compaction quality throughout the subgrade corresponds to a low compressibility level. However, the compaction quality near the slopes on both sides is slightly lower than that along the centerline of the subgrade. Overall, the compaction quality meets the required standards. Full article

Current research primarily focuses on using CFRP materials to strengthen small or medium-sized test specimens. To address this, our study employed ABAQUS software to analyze the axial compression behavior of large-scale reinforced concrete (RC) columns strengthened with prestressed carbon fiber reinforced polymer (CFRP) sheets. We conducted comparative analyses on key parameters: the prestress level applied to the CFRP, the width of CFRP strips, the spacing between strips, the confinement ratio, and the overall load–displacement curves of the columns. The results demonstrate that applying prestress significantly improves the efficiency of stress transfer in the CFRP sheet, effectively mitigating the stress lag phenomenon common in traditional CFRP strengthening, leading to a substantially enhanced strengthening effect. The CFRP wrapping method critically impacts performance: increasing the confinement ratio enhanced ultimate load capacity by 21.8–59.9%; reducing the strip spacing increased capacity by 21.8–50.4%; and widening the strips boosted capacity by 38.7–58%. Although full wrapping achieved the highest capacity increase (up to 73.2%), it also incurred significantly higher costs. To ensure the required strengthening effect while optimizing economic efficiency and CFRP material utilization, the strip wrapping technique is recommended. For designing optimal reinforcement, priority should be given to optimizing the confinement ratio first, followed by adjusting strip width and spacing. Proper optimization of these parameters significantly enhances the strengthened member’s ultimate load capacity, ductility, and energy dissipation capacity. This study enriches the theoretical foundation for prestressed CFRP strengthening and provides an essential basis for rationally selecting prestress levels and layout parameters in engineering practice, thereby aiding the efficient design of strengthening projects for structures like bridges, with significant engineering and scientific value. Full article

The impact mechanism of long-term creep in gas-containing coal on coal and gas outbursts has not been fully elucidated and remains insufficiently understood for the purpose of disaster engineering control. This investigation conducted triaxial creep experiments on raw coal specimens under controlled confining pressures, axial stresses, and gas pressures. Through systematic analysis of coal’s physical responses across different loading conditions, we developed and validated a novel creep damage constitutive model for gas-saturated coal through laboratory data calibration. The key findings reveal three characteristic creep regimes: (1) a decelerating phase dominates under low stress conditions, (2) progressive transitions to combined decelerating–steady-state creep with increasing stress, and (3) triphasic decelerating–steady–accelerating behavior at critical stress levels. Comparative analysis shows that gas-free specimens exhibit lower cumulative strain than the 0.5 MPa gas-saturated counterparts, with gas presence accelerating creep progression and reducing the time to failure. Measured creep rates demonstrate stress-dependent behavior: primary creep progresses at 0.002–0.011%/min, decaying exponentially to secondary creep rates below 0.001%/min. Steady-state creep rates follow a power law relationship when subject to deviatoric stress (R² = 0.96). Through the integration of Burgers viscoelastic model with the effective stress principle for porous media, we propose an enhanced constitutive model, incorporating gas adsorption-induced dilatational stresses. This advancement provides a theoretical foundation for predicting time-dependent deformation in deep coal reservoirs and informs monitoring strategies concerning gas-bearing strata stability. This study contributes to the theoretical understanding and engineering monitoring of creep behavior in deep coal rocks. Full article

This paper presents field investigations of a corrugated steel soil–steel arch structure with a span of 25.7 m and a rise of 9.0 m—currently the largest single-span structure of its kind in Europe. The structure, serving as a wildlife crossing along the DK16 expressway in northeastern Poland, was constructed using deep corrugated steel plates (500 mm× 237 mm) made from S315MC steel, without additional reinforcements such as stiffening ribs or geosynthetics. The study focused on monitoring the structural behavior during the critical backfilling phase. Displacements and strains were recorded using 34 electro-resistant strain gauges and a geodetic laser system at successive backfill levels, with particular attention to the loading stage at the crown. The measured results were compared with predictions based on the Swedish Design Method (SDM). The SDM equations did not accurately predict internal forces during backfilling. At the crown level, bending moments and axial forces were overestimated by approximately 69% and 152%, respectively. At the final backfill level, the SDM underestimated bending moments by 55% and overestimated axial forces by 90%. These findings highlight limitations of current design standards and emphasize the need for revised analytical models and long-term monitoring of large-span soil–steel structures. Full article

Lateritic soils in tropical regions feature cohesive textures and high specific resistance, driving up energy demands for tillage and harvesting machinery. However, current equipment designs lack discrete element models that account for soil moisture variations, and the microscopic effects of water content on lateritic soil deformation remain poorly understood. This study aims to calibrate and validate discrete element method (DEM) models of lateritic soil at varying moisture contents of 20.51%, 22.39%, 24.53%, 26.28%, and 28.04% by integrating the Hertz–Mindlin contact mechanics with bonding and JKR cohesion models. Key parameters in the simulations were calibrated through systematic experimentation. Using Plackett–Burman design, critical factors significantly affecting axial compressive force—including surface energy, normal bond stiffness, and tangential bond stiffness—were identified. Subsequently, Box–Behnken response surface methodology was employed to optimize these parameters by minimizing deviations between simulated and experimental maximum axial compressive forces under each moisture condition. The calibrated models demonstrated high fidelity, with average relative errors of 4.53%, 3.36%, 3.05%, 3.32%, and 7.60% for uniaxial compression simulations across the five moisture levels. Stress–strain analysis under axial loading revealed that at a given surface displacement, both fracture dimensions and stress transfer rates decreased progressively with increasing moisture content. These findings elucidate the moisture-dependent micromechanical behavior of lateritic soil and provide critical data support for DEM-based design optimization of soil-engaging agricultural implements in tropical environments. Full article

This paper presents a symmetry-driven broadband circularly polarized magnetoelectric dipole antenna with bandpass filtering response, where the principle of symmetry is strategically employed to enhance both radiation and filtering performance. The antenna’s circular polarization is achieved through a symmetrical arrangement of two orthogonally placed metallic ME dipoles combined with a phase delay line, creating balanced current distributions for optimal CP characteristics. The design further incorporates symmetrical parasitic elements—a pair of identical inverted L-shaped metallic structures placed perpendicular to the ground plane at −45° relative to the ME dipoles—which introduce an additional CP resonance through their mirror-symmetric configuration, thereby significantly broadening the axial ratio bandwidth. The filtering functionality is realized through a combination of symmetrical modifications: grid slots etched in the metallic ground plane and an open-circuited stub loaded on the microstrip feed line work in tandem to create two radiation nulls in the upper stopband, while the inherent symmetrical properties of the ME dipoles naturally produce a radiation null in the lower stopband. This comprehensive symmetry-based approach results in a well-balanced bandpass filtering response across a wide operating bandwidth. Experimental validation through prototype measurement confirms the effectiveness of the symmetric design with compact dimensions of 0.96${\lambda }_0$ × 0.55${\lambda }_0$ × 0.17${\lambda }_0$ (${\lambda }_0$ is the wavelength at the lowest operating frequency), demonstrating an impedance bandwidth of 66.4% (2.87–5.05 GHz), an AR bandwidth of 31.9% (3.32–4.58 GHz), an average passband gain of 5.5 dBi, and out-of-band suppression levels of 11.5 dB and 26.8 dB at the lower and upper stopbands, respectively, along with good filtering performance characterized by a gain-suppression index (GSI) of 0.93 and radiation skirt index (RSI) of 0.58. The proposed antenna is suitable for satellite communication terminals requiring wide AR bandwidth and strong interference rejection in L/S-bands. Full article
