Due to the advantages of easy implementation and fine jamming effect, barrage jamming against synthetic aperture radar (SAR) has received extensive attention in the field of electronic countermeasures. However, most methods of barrage jamming still have limitations, such as uncontrollable jamming position and coverage and high-power requirements. To address these issues, an improved barrage jamming method is proposed in this paper. The proposed method fully combines the prior information of the region of interest (ROI), and the precise jamming with controllable position, coverage, and power is realized. For the proposed method, the ROI is firstly divided into several sub-scenes according to the obtained prior information, and the signal is intercepted. Then the frequency response function of the jammer for each sub-scene is generated. The frequency response function of the jammer, which consists of position modulation function and jamming coverage function, is decomposed into slow-time-dependent parts and slow-time-independent parts. The slow-time-independent parts are generated offline in advance, and the real-time performance of the proposed method is guaranteed through this way. Finally, the intercepted signal is modulated by the frequency response function to generate the two-dimensional controllable jamming effect. Theoretical analysis and simulation results show that the proposed method can produce jamming effects with controllable position and coverage, and the utilization efficiency of jamming power is improved. Full article

Radar jamming waveform design is a vital part of radar jamming. Over seven to eight decades of evolution, the field has transitioned from noise signal design to coherent jamming signal design, resulting in a multitude of complex jamming styles capable of achieving deceptive jamming, suppressive jamming, and smart noise jamming, which combines both deception and suppression. For the first time, this article establishes a general formula for unifying jamming waveform design. Building upon this foundation, we systematically categorize jamming techniques, and provide an in-depth summary of the corresponding principles and conduct comparative analysis of their effectiveness against different targets. Finally, we look forward in terms of future research directions in jamming waveform design, including quantifiable jamming effect evaluation indicators, combined jamming styles, and intelligent jamming waveform generation methods to address the continuous advancement of radar technology and the complexity and variability of the electromagnetic environment. In order to fill the gap in the literature by summarizing the current state of the field and highlighting key challenges and opportunities, this review provides a comprehensive overview of radar jamming waveform design, categorizes and compares different jamming techniques, and identifies future research directions. Full article

The assessment of the jamming effect of Synthetic Aperture Radar (SAR) is the primary means to measure the reliability of the jamming, which can provide important guidance for the use of jamming strategies and patterns. This paper proposes a detection-oriented evaluation of the effect of SAR dexterous barrage jamming. Starting from the detection, it divides the evaluation process into two stages: (1) for the case in which the target can be detected under the jamming scenario, two feature parameters, namely, the target exposion area and target relative magnitude, are extracted; (2) for the case in which the target cannot be detected under the jamming scenario, another three feature parameters, namely, jamming relative magnitude, average edge brightness, and local information entropy, are extracted. On this basis, two hierarchical evaluation candidates, the target exposure degree and jamming concealment degree, respectively, are designed, and a comprehensive evaluation index of the dexterous suppression degree is finally proposed. Jamming experiments are carried out from real and simulated SAR data with different scenarios, and the results demonstrate that the proposed method effectively measures the barrage jamming effects of different jamming-to-signal ratios and patterns. More importantly, it quantifies the relationship between suppression degree and detection rate, wherein the detection rate decreases by about 35% to 45% for every 0.1 increase in the suppression degree. Full article

Due to the modulation of tiny frequency offset on the array elements, a frequency diverse array (FDA) jammer can generate multiple range-dimension point false targets, and many deception jamming methods against SAR using an FDA jammer have been studied. However, the potential of the FDA jammer to generate barrage jamming has rarely been reported. In this paper, a barrage jamming method against SAR using an FDA jammer is proposed. To achieve two-dimensional (2-D) barrage effect, the stepped frequency offset of FDA is introduced to generate range-dimensional barrage patches, and the micro-motion modulation is employed to increase the extent of barrage patches along the azimuth direction. Mathematical derivations and simulation results demonstrate the validity of the proposed method in generating flexible and controllable barrage jamming. Full article

A computationally efficient target parameter estimation algorithm for frequency agile radar (FAR) under jamming environment is developed. First, the barrage noise jamming and the deceptive jamming are suppressed by using adaptive beamforming and frequency agility. Second, the analytical solution of the parameter estimation is obtained by a low-order approximation to the multi-dimensional maximum likelihood (ML) function. Due to that, fine grid-search (FGS) is avoided and the computational complexity is greatly reduced. Full article

Underwater acoustic sensor networks (UASNs) can effectively detect and track targets and therefore play an important role in underwater detection technology. To protect a target from being detected by UASNs, a distributed barrage jamming layout strategy is proposed, which considers the detection performance of UASNs as an indicator of the jamming performance. Since common indices of detection performance often involve specific signal processing methods, the Cramér–Rao bound (CRB) of multiple targets estimated by an UASN for distributed jammers is deduced in this paper, which is universal for all signal processing methods. The optimization model of the distributed jamming layout strategy is designed by maximizing the CRB to achieve the best jamming effect with limited jammers. A heuristic algorithm is used to solve this optimization model, and a numerical simulation shows that the optimal layout strategy for distributed jammers proposed in this paper achieves better performance than traditional jamming layout strategies. Considering the deviation of the position of the jammers from the ideal value due to the movement of water in a real marine environment, this paper also analyzes the jamming effects of strategies when there is error in the position of the jammers. The result proves the effectiveness and superiority of the proposed optimal layout strategy in an actual environment. Full article

Distributed multiple input multiple output (MIMO) radar has attracted much attention for its improved detection and estimation performance as well as enhanced electronic counter-counter measures (ECCM) ability. To protect the target from being detected and tracked by such radar, we consider a barrage jamming strategy towards a distributed MIMO. We first derive the Cramer–Rao bound (CRB) of target parameters estimation using a distributed MIMO under barrage jamming environments. We then set maximizing the CRB as the criterion for jamming resource allocation, aiming at degrading the accuracy of target parameters estimation. Due to the non-convexity of the CRB maximizing problem, particle swarm optimization is used to solve the problem. Simulation results demonstrate the advantages of the proposed strategy over traditional jamming methods. Full article

Radar unconventional active jamming, including unconventional deceptive jamming and barrage jamming, poses a serious threat to wideband radars. This paper proposes an unconventional-active-jamming recognition method for wideband radar. In this method, the visibility algorithm of converting the radar time series into graphs, called visibility graphs, is first given. Then, the visibility graph of the linear-frequency-modulation (LFM) signal is proved to be a regular graph, and the rationality of extracting features on visibility graphs is theoretically explained. Therefore, four features on visibility graphs, average degree, average clustering coefficient, Newman assortativity coefficient, and normalized network-structure entropy, are extracted from visibility graphs. Finally, a random-forests (RF) classifier is chosen for unconventional-active-jamming recognition. Experiment results show that recognition probability was over 90% when the jamming-to-noise ratio (JNR) was above 0 dB. Full article
