In this study, we develop a graphene-trenched silicon Schottky junction for humidity sensing. This novel structure comprises suspended graphene bridging etched trenches on a silicon substrate, creating both free-standing and substrate-contacting regions of graphene that enhance water adsorption sensing. Suspended graphene is intrinsically insensitive to water adsorption, making it difficult for adsorbed H₂O to effectively dope the graphene. In contrast, when graphene is supported on the silicon substrate, water molecules can effectively dope the graphene by modifying the silicon’s impurity bands and their hybridization with graphene. This humidity-induced doping leads to a significant modulation of the Schottky barrier at the graphene–silicon interface, which serves as the core sensing mechanism. We investigate the current–voltage (I–V) characteristics of these devices as a function of trench width and relative humidity. Our analysis shows that humidity influences key device parameters, including the Schottky barrier height, ideality factor, series resistance, and normalized sensitivity. Specifically, larger trench widths reduce the graphene density of states, an effect that is accounted for in our analysis of these parameters. The sensor operates under both forward and reverse bias, enabling tunable sensitivity, high selectivity, and low power consumption. These features make it promising for applications in industrial and home safety, environmental monitoring, and process control. Full article

Monitoring the dynamic behaviors of self-aligning roller bearings (SABs) is vital to guarantee the stability of various mechanical systems. This study presents a novel self-powered, intelligent, and self-aligning roller bearing (I-SAB) with which to monitor rotational speeds and bias angles; it also has an application in fault diagnosis. The designed I-SAB is compactly embedded with a novel sweep-type triboelectric nanogenerator (TENG). The TENG is realized within the proposed I-SAB using a comb–finger electrode pair and a flannelette triboelectric layer. A floating, sweeping, and freestanding mode is utilized, which can prevent collisions and considerably enhance the operational life of the embedded TENG. Experiments are subsequently conducted to optimize the output performance and sensing sensitivity of the proposed I-SAB. The results of a speed-sensing experiment show that the characteristic frequencies of triboelectric current and voltage signals are both perfectly proportional to the rotational speed, indicating that the designed I-SAB has the self-sensing capability for rotational speed. Additionally, as both the bias angle and rotational speed of the SAB increase, the envelope amplitudes of the triboelectric voltage signals generated by the I-SAB rise at a rate of 0.0057 V·deg⁻¹·rpm⁻¹. To further demonstrate the effectiveness of the triboelectric signals emitted from the designed I-SAB in terms of self-powered fault diagnosis, a Multi-Scale Discrimination Network (MSDN), based on the ResNet18 architecture, is proposed in order to classify the various fault conditions of the SAB. Using the triboelectric voltage and current signals emitted from the designed I-SAB as inputs, the proposed MSDN model yields excellent average diagnosis accuracies of 99.8% and 99.1%, respectively, indicating its potential for self-powered fault diagnosis. Full article

ZnO thin films with a thickness of 300 nm were deposited on Si and Al₂O₃ substrates using an electron beam evaporation technique with the aim of testing them as low cost and low power consumption gas sensors for ozone (O₃). Scanning electron microscopy and atomic force microscopy were used to characterize the film surface morphology and quantify the roughness and grain size, recognized as the primary parameters influencing the gas sensitivity due to their direct impact on the effective sensing area. The crystalline structure and elemental composition were studied through Raman spectroscopy and X-ray photoelectron spectroscopy. Gas tests were conducted at room temperature and zero-bias voltage to assess the sensitivity and response as a function of time of the films to O₃ pollutant. The results indicate that the films deposited on Al₂O₃ exhibit promising characteristics, such as high sensitivity and a very short response time (<2 s) to the gas concentration. Additionally, it was observed that the films display pronounced degradation effects after a significant exposure to O₃. Full article

The sensitivity of tunneling magnetoresistance sensors is an important performance parameter. It depends on the derivative of resistance versus magnetic field (transfer curve) and the current and is expressed as the product of the two factors. Previous research has demonstrated that the bias voltage has a significant impact on the sensitivity. However, no research has been conducted into the dependence of current and the derivative on bias voltage magnitude and polarity, and their contribution to the sensitivity. Thus, this paper investigates the dependence of sensitivity, derivative of resistance versus magnetic field curve and current on bias voltage magnitude and polarity in CoFeB/MgO/CoFeB-based tunneling magnetoresistance sensors with weak, strong and no voltage-controlled perpendicular magnetic anisotropy modification. It demonstrates that the sensitivity dependence on bias voltage for sensors with voltage controlled magnetic anisotropy modification showed no saturation up to 1 V. Moreover, the sensitivity asymmetry with respect to bias polarity changed significantly with bias, reaching a ratio of 6.7. Importantly, the contribution of current and the derivative of resistance versus magnetic field curve to the sensitivity showed a crossover. The current dominated the bias dependence of sensitivity below the crossover voltage and the derivative above the voltage. Furthermore, the crossover voltage in sensors without voltage controlled magnetic anisotropy modification did not depend on polarity, whereas in sensors with voltage controlled magnetic anisotropy modification, it appeared at significantly higher voltage under positive than negative polarity. Full article

Hall-effect in semiconductors has wide applications for magnetic field sensing. Yet, a standard Hall sensor retains two problems: its linearity is affected by the non-uniformity of the current distribution; the sensitivity is bias-dependent, with linearity decreasing with increasing bias current. In order to improve the performance, we here propose a novel structure which realizes bias-free, photo-induced Hall sensors. The system consists of a semi-transparent metal Pt and a semiconductor Si or GaAs to form a Schottky contact. We systematically compared the photo-induced Schottky behaviors and Hall effects without net current flowing, depending on various magnetic fields, light intensities and wavelengths of Pt/GaAs and Pt/Si junctions. The electrical characteristics of the Schottky photo-diodes were fitted to obtain the barrier height as a function of light intensity. We show that the open-circuit Hall voltage of Pt/GaAs junction is orders of magnitude lower than that of Pt/Si, and the barrier height of GaAs is smaller. It should be attributed to the surface states in GaAs which block the carrier drifting. This work not only realizes the physical investigations of photo-induced Hall effects in Pt/GaAs and Pt/Si Schottky junctions, but also opens a new pathway for bias-free magnetic sensing with high linearity and sensitivity comparing to commercial Hall-sensors. Full article

One of the characteristic features of tunneling magnetoresistance (TMR) sensors is a strong influence of bias voltage on tunneling current. Since fundamental sensing characteristics of the sensors are primarily determined by the tunneling current, the bias voltage should impact these characteristics. Previous research has indeed showed the influence of the bias voltage on the magnetic field detection and sensitivity. However, the effect has not been investigated for nonlinearity and hysteresis and the influence of bias voltage polarity has not yet been addressed. Therefore, this paper systematically investigates the dependence of field sensitivity, nonlinearity, hysteresis and magnetic field detection of CoFeB/MgO/CoFeB-based magnetoresistance sensors on bias voltage magnitude and polarity. The sensitivity and field detection of all sensors improved significantly with the bias, whereas the nonlinearity and hysteresis deteriorated. The sensitivity increased considerably (up to 32 times) and linearly with bias up to 0.6 V. The field detection also decreased substantially (up 3.9 times) with bias and exhibited the minimum values for the same magnitude under both polarities. Significant and linear increases with bias were also observed for nonlinearity (up to 26 times) and hysteresis (up to 33 times). Moreover, not only the voltage magnitude but also the polarity had a significant effect on the sensing characteristics. This significant, linear and simultaneous effect of improvement and deterioration of the sensing characteristics with bias indicates that both bias voltage magnitude and polarity are key factors in the control and modification of these characteristics. Full article

Direct ink-jet printing of a zinc-oxide-based thin-film transistor (ZnO-based TFT) with a three-dimensional (3-D) channel structure was demonstrated for ultraviolet light (UV) and visible light photodetection. Here, we demonstrated the channel structures by which temperature-induced Marangoni flow can be used to narrow the channel width from 318.9 ± 44.1 μm to 180.1 ± 13.9 μm via a temperature gradient. Furthermore, a simple and efficient oxygen plasma treatment was used to enhance the electrical characteristics of switching I_ON/I_OFF ratio of approximately 10⁵. Therefore, the stable and excellent gate bias-controlled photo-transistors were fabricated and characterized in detail for ultraviolet (UV) and visible light sensing. The photodetector exhibited a superior photoresponse with a significant increase of more than 2 orders of magnitude larger drain current generated upon UV illumination. The results could be useful for the development of UV photodetectors by the direct-patterning ink-jet printing technique. Additionally, we also have successfully demonstrated that a metal-semiconductor junction structure that enables plasmon energy detection by using the plasmonic effects is an efficient conversion of plasmon energy to an electrical signal. The device showed a significant variations negative shift of threshold voltage under different light power density with exposure of visible light. With the ZnO-based TFTs, only ultraviolet light detection extends to the visible light wavelength. Full article

An automatic mode-matching method for MEMS (Micro-electromechanical Systems) disk resonator gyroscopes (DRGs) based on virtual Coriolis force is presented in this paper. For this mode-matching method, the additional tuning electrodes are not required to be designed, which simplifies the structure design. By using the quadratic relationship between the driving voltage and the electrostatic force, the virtual Coriolis force is obtained by applying an AC voltage whose frequency is half of the driving mode resonant frequency to the sense electrode. The phase difference between the virtual Coriolis force and the sense output signal is used for mode-matching. The structural characteristics and electrode distribution of the DRG are briefly introduced. Moreover, the mode-matching theories of the DRG are studied in detail. The scheme of the mode-matching control system is proposed. Simultaneously, the feasibility and effectiveness of the mode-matching method are verified by system simulation. The experimental results show that under the control of mode-matching at room temperature, the bias instability is reduced from 30.7575 ${}^{°}$ /h to 2.8331 ${}^{°}$ /h, and the Angle Random Walk (ARW) decreases from 1.0208 ${}^{°}/\sqrt{h}$ to 0.0524 ${}^{°}/\sqrt{h}$ . Compared with the mode mismatch condition, the ARW is improved by 19.48 times. Full article

This paper proposes an effective method to calibrate the microelectromechanical systems (MEMS) vibratory gyroscope based on the virtual Coriolis force. This method utilizes a series of voltage signals to simulate the Coriolis force input, and the gyroscope output is monitored to obtain the scale factor characteristics of the gyroscopes. The scale factor and bias parameters of the gyroscope can be calibrated conveniently and efficiently in the sense-mode open loop. The calibration error of the scale factor based on the turntable and the virtual Coriolis force method is only 1.515%, which proves the correction of the method proposed in this paper. Meanwhile, the non-linearity and bias value of the turntable and the virtual Coriolis force method are 742 ppm and 42.04 mV and 3389 ppm and 0.66 mV, respectively. Full article
