Solid–liquid transport pumps are widely used in slurry conveying, deep-sea mining, and sediment-laden water delivery, where suspended particles substantially modify internal flow behavior, energy transfer, and operational stability. This review systematically summarizes recent progress on flow evolution and stability issues in centrifugal pumps and related particle-laden pump systems. The fundamental mechanisms of particle dynamics are first discussed, including single-particle transport and force response, particle collision and agglomeration, turbulence modulation by particle assemblies, and wake-induced local disturbances. On this basis, the review further examines particle-induced changes in global flow topology, local separation and backflow, leakage shear layers, and the evolution of representative vortex structures, with particular attention to the enhancement of flow unsteadiness. In addition, the influences of particle size, concentration, density, and shape on hydraulic performance, wear failure, and operational reliability are summarized, together with recent advances in stability evaluation and fault diagnosis. Although substantial progress has been achieved, current studies still show limitations in cross-scale correlation, unified mechanism interpretation, and life-cycle coupled analysis. This review provides a useful reference for understanding solid–liquid two-phase flow mechanisms and for improving anti-wear design and stable operation control of transport pumps. Full article

A modified Pitot-tube jet (PTJ) separation pump combines centrifugal phase separation with pressure buildup and enables compact oil–water treatment, where a water-rich stream can be discharged at elevated pressure. This work advances an existing laboratory PTJ configuration toward a turbomachinery-oriented rotor concept for systematic design studies and subsequent field-oriented prototypes. Starting from a centrifuge-like reference configuration without blades that prioritizes separation stability, an impeller with trimmed blades is introduced to increase pressure head while limiting blade interaction with the oil–water interface by operating primarily in the outer, water-rich annulus. Comparative experiments with and without the impeller show a pronounced increase in pressure head, up to about a factor of three at the maximum speed investigated. The results also indicate a purity penalty caused by blade-induced mixing and secondary flows. This exposes the central design trade-off of the PTJ machine. Higher specific work input increases pressure head but can reduce discharge quality. Hydraulic optimization, therefore, needs to be coupled to ppm-level purity constraints. Density-based monitoring lacks resolution in the relevant trace range, and chemical-based analyses are too slow for systematic investigations. An imaging-based fluorescence method using Nile Red as a selective tracer is, therefore, implemented as a rapid analysis tool. High-resolution imaging with automated region of interest evaluation provides a robust calibration from 5–500 ppm for safe, non-fluorescent model oils such as sunflower oil. This enables efficient operating-window mapping and comparative screening of rotor concepts under reproducible conditions. Full article

Pumps, as critical equipment in water supply and drainage systems, contribute significantly to energy use and carbon emissions throughout their life cycle. This study quantified the life-cycle carbon footprint (LCF) of water supply and drainage pumps by developing a life-cycle assessment (LCA)-based model covering raw material acquisition, production and processing, transportation, operation, and recycling. Using the 400S-40 single-stage double-suction centrifugal pump as a case, the results showed that: (1) the total LCF of the pump was 5567.56 t CO₂e per unit; and (2) the operational stage accounted for 99.69% of the total life-cycle emissions. The findings indicate that, for the studied case, use-phase electricity consumption dominates the overall carbon footprint under the stated assumptions. Accordingly, for water utilities and pump users, improving operating efficiency and reducing avoidable electricity consumption are critical to carbon reduction. For pump manufacturers, enhancing processing technology, adopting low-carbon materials, improving durability, and promoting component-level maintenance and replacement can reduce embodied carbon and avoid unnecessary emissions associated with premature full-unit replacement. Beyond carbon reduction, these measures are also conducive to resource conservation, sustainable manufacturing, and the low-carbon transition of urban water infrastructure. Therefore, this study provides methodological support for the green design, operation, and management of pump equipment, and contributes to the sustainable development of water supply and drainage systems. Full article

This paper presents a model-free Best Efficiency Point (BEP) tracking method for centrifugal pumps without head measurement or manufacturer-provided characteristic curves. The proposed approach combines a discrete finite-difference extremum-seeking control (ESC) scheme with an efficiency approximation proxy derived from measurable variables—namely, flow rate and electrical power. Under constant head conditions, the proxy function is analytically shown to be proportional to the true pump efficiency, enabling real-time BEP localization using only motor feedback signals. The ESC algorithm employs a sign-based gradient rule with adaptive step-size reduction to achieve rapid and stable convergence without mathematical models. A Python-based simulation using a Schneider SUB 15-0.5cv pump demonstrates that the method can track the BEP with negligible steady-state error (less than 0.1% efficiency deviation). The proposed framework offers a cost-effective solution for efficient optimization for mobile pumping applications in large water resources where installing head sensors is impractical. Full article

This study investigates the wear characteristics and optimization of a centrifugal pump (Q = 25 m³/h, H = 50 m, n = 2900 r/min) applied in sediment-laden waters of Southern Xinjiang irrigation systems. A numerical framework integrating the Realizable $k-\epsilon$ turbulence model, Discrete Phase Model (DPM), and Oka erosion model was established to analyze wear patterns under varying parameters (particle size, density, and mass flow rate). Results indicate that the average erosion rate peaks at 0.92 kg/s mass flow rate. Subsequently, a Response Surface Methodology (RSM)-based optimization was implemented: (1) Plackett–Burman (PB) screening identified the inlet placement angle (A), inlet diameter (C), and outlet width (E) as dominant factors; (2) Full factorial design (FFD) revealed significant interactions (e.g., A × C, C × E); (3) Box–Behnken Design (BBD) generated quadratic regression models for head, efficiency, shaft power, and wear rate (R² > 0.94). Optimization reduced the average erosion rate by 31.35% (from 1.550 × 10⁻⁴ to 1.064 × 10⁻⁴ kg·m⁻²·s⁻¹). Experimental validation confirmed the numerical model’s accuracy in predicting wear localization (e.g., impeller outlet). This work provides a robust methodology for enhancing the wear resistance of centrifugal pumps for agricultural irrigation in water with high fine sediment concentration environments. Full article

Designed to mitigate the significant low-frequency vibration and noise inherent in conventional marine centrifugal pump systems, the magnetic levitation pump constitutes a novel form of centrifugal pump employing active magnetic bearing technology. While this fully levitated design effectively enhances vibration and noise performance, it results in the complete immersion of the rotor within a confined fluid domain, which contains narrow fluid clearances. This poses significant challenges for the accurate computation of rotor wet modes, which is crucial for the structural design of the rotor system to avoid the resonance induced by flow. Despite exerting a substantially greater influence on rotor wet modal characteristics than unconfined domains, the analysis of rotors under confined fluid conditions has received comparatively little research attention. This study focuses on two types of magnetic levitation pump rotors. From the perspective of analytical modeling, an improved analytical method for wet modal computation based on added mass correction is proposed. The validation of this method included examining two distinct computational approaches for the added mass, the thickening treatment for axially elongated disk components, and the methodology for implementing disk equivalent density. Based on this foundation, wet modal analysis was performed on both rotors utilizing the proposed analytical method, alongside acoustic fluid–structure interaction simulations. The results indicate that for the first bending mode, the errors between the analytical and experimental values are 1.2% and 4.1%, respectively, while the discrepancies between the simulated and experimental values are 0.1% and 3.2%. Finally, regularity analysis was conducted on the wet modal characteristics of the rotor under confined water, considering various fluid clearances. The results reveal that the first three bending modes generally exhibit an increasing trend with the enlargement of the fluid clearance, with a triple-size annulus serving as a transition point. However, increasing the annulus size does not always elevate the modal frequencies above their initial values. This study contributes to understanding the influence mechanisms of confined water on the wet modal properties of magnetic levitation pump rotors. Furthermore, the proposed analytical method improved computational efficiency for the early design stages of water-immersed rotors, alongside a model of greater accuracy essential for magnetic bearing control. Full article

Pipeline transportation of petroleum products remains one of the safest and most efficient methods of bulk energy delivery, yet overpressure events continue to pose serious operational and regulatory challenges. Traditional fixed-gain PI controllers, commonly used with centrifugal pump drives, cannot adapt to varying product densities or transient disturbances such as valve closures that generate water hammer. This paper proposes a self-tuning adaptive controller based on Recursive Least Squares (RLS) parameter estimation to improve safety and efficiency in pipeline pump operations. A nonlinear simulation model of a centrifugal pump driven by an induction motor is developed, incorporating pipeline friction losses via the Darcy–Weisbach relation and pressure transients induced by rapid valve closures. The RLS algorithm continuously estimates effective loop dynamics, enabling online adjustment of proportional and integral gains under changing fluid and operating conditions. Simulation results demonstrate that the proposed RLS-based adaptive controller maintains discharge pressure within ±2% of the target setpoint under density variations from 710 to 900 kg/m³ and during severe transient events. Compared to a fixed-gain PI controller, the adaptive strategy reduced pressure overshoot by approximately 31.9% and settling time by 6%. Model validation using SCADA field data yielded an $R^2$ = 0.957, RMSE = 3.95 m³/h, and normalized NRMSE of 12.6% (by range), confirming strong agreement with measured system behavior. The findings indicate that RLS-based self-tuning provides a practical enhancement to existing pipeline control architectures, offering both improved robustness to abnormal transients and greater efficiency during steady-state operation. This work establishes a foundation for higher-level supervisory and game-theoretic coordination strategies to be explored in subsequent studies. Full article

This study experimentally investigates single-phase forced convection heat transfer and flow characteristics of Al₂O₃-water nanofluids under rotating hypergravity conditions ranging from 1 g to 5.1 g. While nanofluids offer enhanced thermal properties for advanced cooling applications in aerospace and rotating machinery, their performance under hypergravity remains poorly understood. Experiments employed a custom centrifugal test rig with a horizontal test section (D = 2 mm, L = 200 mm) operating at constant heat flux. Alumina nanoparticles (20–30 nm) were dispersed in deionized water at mass fractions of 0.02–0.5 wt%, with stability validated through transmittance measurements over 72 h. Heat transfer coefficients (HTC), Nusselt numbers (Nu), friction factors (f), and pressure drops were measured across Reynolds numbers from 500 to 30,000. Results demonstrate that hypergravity significantly enhances heat transfer, with HTC increasing by up to 40% at 5.1 g compared to 1 g, most pronounced at the transition from 1 g to 1.41 g. This enhancement is attributed to intensified buoyancy-driven secondary flows quantified by increased Grashof numbers and modified particle distribution. Friction factors increased moderately (15–25%) due to Coriolis effects and enhanced viscous dissipation. Optimal performance occurred at 0.5 wt% concentration, effectively balancing thermal enhancement against pumping penalties. Random forest (RF) and eXtreme gradient boosting (XGBoost) achieved R² = 0.9486 and 0.9625 in predicting HTC, respectively, outperforming traditional correlations (Gnielinski: R² = 0.9124). These findings provide crucial design guidelines for thermal management systems in hypergravity environments, particularly for aerospace propulsion and centrifugal heat exchangers, where gravitational variations significantly impact cooling performance. Full article

A novel pumped storage system using centrifugal pumps to transfer water between reservoirs in coastal hydropower plants has significantly mitigated grid instability. However, frequent start–stop operations of large vertical centrifugal pumps, which serve as the core equipment, severely affect the operational stability of these systems. In this study, the intrinsic connection between the cavitating flow field and irreversible losses during the process was analyzed using the entropy production theory. The time–frequency characteristics of pressure pulsation in pump were analyzed by using the continuous wavelet transform. The results indicate that with the reduction in the flow rate and rotational speed, the sheet cavitation at the impeller inlet rapidly weakens until it vanishes. The cavity cavitation within the draft tube commences to emerge in the turbine mode. Separation vortices are formed due to the mismatch in the flow angle at the impeller outlet. These vortices induce local cavitation, causing both a rapid energy loss increase and high-amplitude, low-frequency pressure pulsations. During transient processes, flow instabilities induce high-amplitude, low-frequency pressure pulsations within the stay vane region, with maximum amplitude attained during runaway condition. The research results provide a theoretical foundation for the stable operation of centrifugal pumps. Full article

Prior research has proposed a basic configuration for a deep-sea mining system integrating slurry transport and wastewater discharge, and examined the operational characteristics of water-driven diaphragm pumps. Against the backdrop of commercial deep-sea polymetallic nodule exploitation, this study focuses on the technical design of seabed diaphragm pump groups and hydraulic parameter matching for a coupled slurry transport-wastewater discharge system. The solid–liquid two-phase output characteristics of the water-driven diaphragm pump were analyzed, leading to the proposal of a four-pump staggered configuration to ensure continuous particulate discharge throughout the full operating cycle. To meet commercial mining capacity requirements, the system consists of two sets (each with four pumps) operating with a phase offset to reduce fluctuations in slurry output concentration. A centralized output device was developed for the pump group, and a centralized mixing tank was designed based on analyses of outlet pipe length and positional effects. CFD-DEM simulations show that the combined effects of phased pump operation and centralized mixing tank mixing result in the slurry concentration delivered to the riser pipeline staying within ±1% of the mean for up to 57.8% of the system’s operational time. Considering the characteristics of both diaphragm and centrifugal pumps, the system is designed to output high-concentration slurry from the seabed diaphragm pumps, driven solely by wastewater, while centrifugal pumps provide lower-concentration transport by adding supplementary water from a buffer—thus reducing the risk of clogging. Under the constraints of centrifugal pump capacity, the system’s hydraulic parameters were optimized to maximize overall slurry transport efficiency while minimizing the energy consumption from wastewater discharge. The resulting configuration defines the flow rate and slurry concentration of the diaphragm pump group. Compared with conventional centrifugal pump-based transport schemes, the proposed system increases the slurry pipeline efficiency from 53.14% to 55.43% and reduces wastewater discharge-related pipeline resistance losses from 475.9 mH₂O to 361.7 mH₂O. Full article

This study presents the simulation of a standalone photovoltaic (PV) water pumping system that is made for use in rural areas and off-grid applications. The system contains a 174 W PV panel, a DC-DC boost converter, a DC motor, and a centrifugal pump. To optimize energy extraction, three maximum power point techniques (MPPT), Perturb and Observe (P&O), incremental conductance (INC), and a Hybrid P&O–INC algorithm, were implemented and evaluated. Unlike most prior studies focusing on large-scale systems, this work targets low-power configurations with load dynamics specific to motor–pump assemblies. The hybrid algorithm is finely tuned using conservative step sizes and adaptive switching thresholds. Simulation results under varying irradiance levels show that the hybrid MPPT achieves the best trade-off, combining high tracking efficiency with reduced power ripple, particularly under challenging low-irradiance conditions. Moreover, the approach offers a favorable balance between performance and implementation cost, positioning it as a viable and scalable solution for sustainable water supply in remote communities. Full article

Centrifugal irrigation pumps in Southern Xinjiang face severe performance degradation due to high fine-sediment loads in canal water. This study combines Eulerian multiphase simulations with experimental validation to investigate the coupled effects of sediment size (0.05~0.8 mm) and concentration (5~20%) on hydraulic performance. Numerical models incorporating Realizable k–ε turbulence closure and discrete phase tracking reveal two critical thresholds: (1) particle sizes ≥ 0.4 mm trigger a phase transition from localized disturbance to global flow disorder, expanding low-pressure zones by 37% at equivalent concentrations; (2) concentrations exceeding 13% accelerate nonlinear pressure decay through collective particle interactions. Velocity field analysis demonstrates size-dependent attenuation mechanisms: fine sediments (≤0.2 mm) cause gradual dissipation via micro-scale drag, while coarse sediments (≥0.6 mm) induce “cliff-like” velocity drops through inertial impact-blockade chains. Experimental wear tests confirm simulation accuracy in predicting erosion hotspots at impeller inlets/outlets. The identified synergistic thresholds provide critical guidelines for anti-wear design in sediment-laden irrigation systems. Full article

This study presents an online evaluation system for the energy efficiency grade of centrifugal pump units using a Browser/Server architecture. The system employs direct calculation and characteristic curve fitting methods to evaluate efficiency, with corrections for viscous fluids. It utilizes Java20, SpringBoot2.7x, HTML5, CSS3, Ajax, and RESTful API technologies for real-time monitoring and evaluation. The system has undergone rigorous testing and full-scale deployment within a petrochemical facility. As demonstrated herein, it delivers exceptional stability and precision, cutting evaluation time substantially while markedly enhancing energy-conservation performance. Full article

Additive Manufacturing is a rapidly developing technology that enables the fabrication of objects with complex geometries and high levels of customization while keeping the prototyping costs relatively low. In recent years, its application has grown to include the fabrication of end-use parts, creating new opportunities in industries such as the automotive, aerospace, mechanical, and hydraulic engineering industries. The present research paper focuses on the fabrication and evaluation of 3D-printed operational end-use parts of a water pump, which were originally made from cast iron. This approach aims to determine whether AM can be an alternative for metal parts in operational systems such as water pumps. In particular, the impeller of a centrifugal pump is remanufactured using material extrusion AM technology with PPS-CF composite polymer as a fabrication material. Subsequently, the surface roughness of the two parts is measured, and the performance of each part is predicted by creating a CFD model. Additionally, the printed part is compared to the original part by conducting a centrifugal pump performance test for each impeller. The results show that the 3D-printed impeller achieves an approximate 15% increase in overall efficiency compared to the original impeller. Full article

Heating, ventilation, and air-conditioning (HVAC); domestic and commercial buildings; district energy; industrial processes and water treatment; municipal wastewater and water supply; and agriculture and irrigation, among others, represent a wide breadth of domains where pumps are used. From this perspective, the number of pumps that will be required to ensure future human demands is expected to increase significantly; accordingly, power consumption is also expected to increase sharply. Therefore, the energy efficiency of pumps will become an even more important topic of concern when designing a pumping installation. The objective of the present study is to introduce a user-friendly Excel workbook that enables the design of pumping systems with centrifugal pumps. It was initially conceived for use in Hydraulic Machines Master’s lectures, but its use might be examined from a wider perspective. The workbook includes 22 worksheets, all linked to each other, addressing different aspects of the design. Special attention is given to the calculation of the major and minor head losses, to the cavitation phenomenon, to the use of dimensionless coefficients to determine the rotation speed to obtain a specific operating point, and to the calculation of the system curve. Today, energy efficiency represents an important goal in every pumping facility; therefore, one of the objectives of this tool is to enable the user to quantify both the shaft power and the efficiency of different operating points, thus allowing a sustained definition of the best solution. Full article
