Search Results (1,058)

We systematically investigate the combined impact of process variation effects (PVEs), metal gate work function fluctuation (WKF), and random dopant fluctuation (RDF) on the key electrical characteristics of sub-1-nm technology node gate-all-around silicon nanosheet complementary field-effect transistors (GAA Si NS CFETs). Through comprehensive statistical analysis, we reveal that the interplay of these intrinsic and extrinsic sources of variability induces significant fluctuations in the off-state leakage current across both N-/P-FETs in GAA Si NS CFETs. The sensitivity to process-induced variability is found to be particularly pronounced in the P-FETs, primarily due to the enhanced parasitic conduction associated with the bottom nanosheet channel. Given the correlated nature of PVE, WKF, and RDF factors, the statistical sum (RSD) of the fluctuation for each factor is overestimated by less than 50% compared with the simultaneous fluctuations of PVE, WKF, and RDF factors. Furthermore, although the static power dissipation remains relatively small compared to dynamic and short-circuit power components, it exhibits the largest relative fluctuation (approximately 82.1%), posing critical challenges for low-power circuit applications. These findings provide valuable insights into the variability-aware design and optimization of GAA NS CFET device fabrication processes, as well as the development of robust and reliable CFET-based integrated circuits for next-generation technology nodes. Full article

Aiming at the drawback of unstable torque output caused by heat generation due to slip in magnetorheological fluid transmission devices, this paper proposes a new type of non-coaxial conical disk magnetorheological fluid transmission structure and deduces its mathematical model of output torque. The magnetic circuit design was carried out based on the conical disk configuration. The electromagnetic field analysis of the transmission device was conducted by the finite element method, and the influence laws of parameters such as the coil current, magnetic conductive material, the conical angle of the disk, and the working gap on the distribution of the magnetic induction intensity in the working area were obtained. The test system for the non-coaxial conical disk type magnetorheological fluid transmission device was established, and experiments on electromagnetic fields, transmission performance, torque response, etc., were carried out. Research results show that the magnetic induction intensity in the working area increases with the increase of the current in the excitation coil, decreases with the increase of the working gap between the two conical disks, and is positively correlated with the magnetic permeability of the conical disk and the magnetic conducting ring materials. The effective working area range and magnetic induction intensity of the governor both decrease as the conical angle of the disk increases. The magnitude of the magnetic induction intensity on the center line is basically the same, but the effective working area range corresponding to different angles shows significant differences. Full article

The electronics industry has significantly contributed to the development of efficient heat dissipation systems. One widely used technique is pool boiling, a simple method requiring no moving parts or complex structures. It enables the removal of large amounts of heat at relatively low temperature differences. Enhancing pool boiling performance involves increasing the critical heat flux and the heat transfer coefficient, which defines how effectively a surface can transfer heat to a cooling fluid. This method is commonly applied in cooling electronic devices, digital circuits, and power systems. In this study, pool boiling at atmospheric pressure was investigated using copper surfaces. To validate the Rohsenow model used to estimate the maximum bubble departure diameter, a planimetric approach was applied. Measurements included average contact angle (CA), surface tension (σ), and droplet diameter for four working fluids: deionised water, ethanol, Novec-649, and FC-72. For each fluid, at least 15 measurements of CA and σ were conducted using the Young–Laplace model. This study provides a comprehensive analysis of the influence of contact angle and surface tension on nucleate boiling using four different fluids on copper surfaces. The novelty lies in combining high-precision experimental measurements with validation of the Rohsenow model, offering new insights into surface-fluid interactions critical for thermal system performance. Full article

To enhance the development efficiency of medium–deep geothermal resources in cold regions, this study focuses on a coaxial borehole heat exchanger (CBHE) located in Dapuzi Town, Xining City, Qinghai Province. Based on field-scale heat exchange experiments, a three-dimensional numerical model of the CBHE was developed using COMSOL Multiphysics 6.2, incorporating both conductive heat transfer in the surrounding geological formation and convective heat transfer within the wellbore. The model was calibrated and validated against measured data. On this basis, the effects of wellhead injection flow rate, injection temperature, and the thermal conductivity of the inner pipe on heat exchange performance were systematically analyzed. The results show that in cold regions with high altitudes (2000–3000 m) and medium–deep low-temperature geothermal reservoirs (68.8 °C), using a coaxial heat exchange system for space heating delivers good heat extraction performance, with a maximum average power output of 282.37 kW. Among the parameters, the injection flow rate has the most significant impact on heat extraction. When the flow rate increases from 10 m³/h to 30 m³/h, the heat extraction power increases by 57.58%. An increase in injection temperature helps suppress thermal short-circuiting and improves the effluent temperature, but excessively high temperatures lead to a decline in heat extraction. Additionally, increasing the thermal conductivity of the inner pipe significantly intensifies thermal short-circuiting and reduces overall heat exchange capacity. Under constant reservoir conditions, the thermal influence radius expands with both depth and operating time, reaching a maximum of 10.04 m by the end of the heating period. For the CBHE system in Dapuzi, maintaining an injection flow rate of 20–25 m³/h and an injection temperature of approximately 20 °C can achieve an optimal balance between effluent temperature and heat extraction. Full article

2.5D integrated circuits (ICs), which utilize an interposer to stack multiple dies side by side, represent a promising architecture for improving system performance, integration density, and design flexibility. However, the complex interconnect structures present significant challenges for post-fabrication testing, especially when scheduling test paths under constrained test access mechanisms. This paper addresses the test-path scheduling problem in interposer-based 2.5D ICs, aiming to minimize both total test time and cumulative inter-die interconnect length. We propose an efficient orthogonal learning-based differential evolution algorithm, named OLELS-DE. The algorithm combines the global optimization capability of differential evolution with an orthogonal learning-based search strategy and an elites local search strategy to enhance the convergence and solution quality. Comprehensive experiments are conducted on a set of benchmark instances with varying die counts, and the proposed method is compared against five state-of-the-art metaheuristic algorithms and CPLEX. Experimental results demonstrate that OLELS-DE consistently outperforms the competitors in terms of test cost reduction and convergence reliability, confirming its robustness and effectiveness for complex test scheduling in 2.5D ICs. Full article

Discrete Silicon Carbide Metal-Oxide-Semiconductor Field-Effect Transistors (SiC MOSFETs) are characterized by their lower parasitic parameters and single-chip design, enabling them to achieve even faster switching speeds. However, the rapid rate of change in voltage (dv/dt) and current (di/dt) can lead to overshoot and oscillation in both voltage and current, ultimately limiting the performance of high-frequency operations. To address this issue, this paper presents a high-switching-frequency motor controller that utilizes discrete SiC MOSFETs. To achieve a high switching frequency for the controller while minimizing current oscillation and voltage overshoot, a novel electronic system architecture is proposed. Additionally, a passive driving circuit is designed to suppress gate oscillation without the need for additional control circuits. A new printed circuit board (PCB) laminate stack featuring low parasitic inductance, high current conduction capacity, and efficient heat dissipation is also developed using advanced wiring technology and a specialized heat dissipation structure. Compared to traditional methods, the proposed circuit and bus design features a simpler structure, a higher power density, and achieves a 13% reduction in current overshoot, along with a 15.7% decrease in switching loss. The silicon carbide (SiC) controller developed from this research has successfully undergone double-pulse and power testing. The results indicate that the designed controller can operate reliably over extended periods at a switching frequency of 50 kHz, achieving a maximum efficiency of 98.2% and a power density of 9 kW/kg (10 kW/L). The switching frequency and quality density achieved by the controller have not been observed in previous studies. This controller is suitable for use in the development of new energy electrical systems. Full article

This article comprehensively analyzes the new developments and challenges faced by several typical prediction models in the field of radiation effects in recent years. The models discussed include the RPP model, the extended RPP (rectangular parallelepiped) model, and the IRPP (integral rectangular parallelepiped) model. The article conducts a comprehensive analysis of the limitations of the assumption that uses the linear energy transfer (LET) of incident particles and the SEU (single-particle upset) cross-section (without considering the energy and type of ions) to predict the rate of single-particle effects (SEUs). Additionally, the article points out that with the continuous progress of integrated circuit technology, the geometric shape of the target circuit, the energy of the incident particles, the type of particles, and more precise physical models corresponding to the interaction between radiation and matter have become increasingly important in evaluating the sensitivity to single-particle effects (SEEs). Subsequently, based on the probability characteristics of SEE, a series of general estimation equations for the SEE rate are derived, considering particle energy, particle type, and the probability of influence at a specific moment. Then, by introducing the concept of interaction volume, the concept of sensitive volume is further expanded, and using these general equations, the relationship between the SEE rate cross-section and the SEE projected area is derived, simplifying the SEU rate prediction equation to a form that can be directly used in engineering applications. Finally, the article emphasizes a complete method of applying the general prediction equation to engineering to estimate the radiation disturbance performance of two typical verification circuits, and provides the corresponding prediction results. Full article

Background: The primary effect of Botulinum toxin (BoNT) is to cause weakness in the injected muscles by inhibiting the release of acetyl choline from presynaptic nerve terminals. Its effect on sensorimotor integration (SMI) has largely been confined to small studies. The aim of this review is to highlight effect of BoNT on SMI in the context of Parkinson’s disease (PD), Cervical dystonia (CD), and Writer’s cramp (WC). Methods: Using keywords “Botulinum toxin” and “sensorimotor integration” or “Freezing of gait (FOG)” or ‘Tremor”or “Cervical dystonia” or “Parkinson’s disease”, or “Writer’s cramp”, PubMed database was searched for relevant articles supporting our view. The abstracts of all resultant articles (case reports, case series, randomized trials, observational studies) were reviewed to look for evidence of effects of botulinum toxin on SMI. The relevant articles were charted in excel sheet for further full text review. Results: In FOG, chronic BoNT injections may alter central motor patterns with inclusion of alternative striatal systems, cerebellum, and its connections. In tremor, the afferent proprioceptive input may be modified with reduction of intracortical facilitation and increment of intracortical inhibition. In CD, BoNT can restore disorganized cortical somatotrophy, the key pathophysiology behind cervical dystonia. Similarly, in WC, both the deficient sensory system and abnormal reorganization of the sensorimotor cortex may be altered following chronic BoNT injections. Conclusions: There is preliminary evidence that BoNT may modulate SMI in PD, CD, and WC by altering inputs from the muscle spindles in short term and modifying circuits/particular anatomic cerebral cortices in the long term. Properly conducted randomized trials comparing BoNT with placebo or prospective large-scale studies to look for effect on various surrogate markers reflective of changes in SMI should be the next step to confirm these findings. Targeting the system of afferents like spindles and golgi tendon organs in muscles may be a better way of injecting BoNT, with lower amounts of toxin needed and potential for lesser side-effects like weakness and atrophy. However, this needs to be proven in controlled trials. Full article

The treatment of chronic wounds and pressure sores is an important challenge in the context of public health and the effectiveness of patient treatment. Therefore, new methods are being developed to reduce or, in extreme cases, to initiate and conduct the wound healing process. This article presents an innovative smart bandage, programmable using a smartphone, which generates small amplitude impulse vibrations. The communication between the smart bandage and the smartphone is realized using BLE. The possibility of programming the smart bandage allows for personalized therapy. Owing to the built-in MEMS sensor, the smart bandage makes it possible to monitor work during rehabilitation and implement an auto-calibration procedure. The flexible, openwork mechanical structure of the dressing was made in 3D printing technology, thanks to which the solution is easy to implement and can be used together with traditional dressings to create hybrid ones. Miniature electronic circuits and actuators controlled by the PWM signal were designed as replaceable elements; thus, the openwork structure can be treated as single-use. The smart bandage containing six actuators presented in this article generates oscillations in the range from about 40 Hz to 190 Hz. The system generates low-amplitude vibrations, below 1 g. The actuators were operated at a voltage of 1.65 V to reduce energy consumption. For comparison, the actuators were also operated at the nominal voltage of 3.17 V, as specified by the manufacturer. Full article

The electric energy metering box serves as a crucial node in power grid operations, offering essential protection for key components in the distribution network, such as smart meters, data acquisition terminals, and circuit breakers, thereby ensuring their safe and reliable operation. However, the non-metallic housings of these boxes are susceptible to aging under environmental stress, which can result in diminished flame-retardant properties and an increased risk of fire. Currently, there is a lack of rapid and accurate methods for assessing the fire resistance of non-metallic metering box enclosures. In this study, laser-induced breakdown spectroscopy (LIBS), which enables fast, multi-element, and non-contact analysis, was utilized to develop an effective assessment approach. Thermal aging experiments were conducted to systematically investigate the degradation patterns and mechanisms underlying the reduced flame-retardant performance of sheet molding compound (SMC), a representative non-metallic material used in metering box enclosures. The results showed that the intensity ratio of aluminum ionic spectral lines is highly correlated with the flame-retardant grade, serving as an effective performance indicator. On this basis, a one-dimensional convolutional neural network (1D-CNN) model was developed utilizing LIBS data, which achieved over 92% prediction accuracy for different flame-retardant grades on the test set and demonstrated high recognition accuracy for previously unseen samples. This method offers significant potential for rapid, on-site evaluation of flame-retardant grades of non-metallic electric energy metering boxes, thereby supporting the safe and reliable operation of power systems. Full article

This study investigates the integration of LTspice simulations and structured reflective practices within a project-based learning (PBL) framework in a Microelectronic Circuits course. The course was designed to improve students’ conceptual understanding, problem-solving abilities, and engagement by embedding simulation-based assignments and guided reflections within a final design project. A qualitative case study was conducted with 49 third-year undergraduate electrical engineering students. The data sources included structured reflection submissions, researcher observations, and evaluations of project presentations. Thematic analysis identified five recurring themes: linking theory to practice, iterative problem-solving strategies, metacognitive awareness, peer engagement, and reflections on integration challenges and benefits. The results indicate that the LTspice simulations enabled the students to visualize circuit behavior, experiment with design parameters, and observe the effects of design trade-offs. The integration of structured reflection prompted deeper learning by helping the students recognize misconceptions, articulate troubleshooting strategies, and build confidence in circuit analysis. Although some students initially struggled with the complexity of the simulation software, the iterative and collaborative nature of the PBL process increased their motivation and promoted meaningful engagement. This study contributes to the growing body of research on active learning in engineering education and offers practical recommendations for implementing simulation-based learning environments that promote critical thinking, metacognition, and technical competence. Full article

Supercapacitors (SCs) are emerging as a dependable energy storage technology in industrial applications, valued for their high power output and exceptional longevity. In high-power applications, SCs are not used as single cells but are configured in a series–parallel combination to form a bank. Accurate state-of-charge estimation is essential for effective energy management in power systems employing SC banks. This work presents a novel state estimation approach for SC banks. First, a dynamic model of an SC bank is derived by applying a fractional-order Thévenin equivalent circuit to a single-cell SC. Then, an observability analysis is conducted, which reveals that the system is empirically weakly observable. This is the fundamental challenge for state-of-the-art observers to robustly perform state estimation. To address this challenge, an implicitly regularized observer is developed based on generalized parameter estimation techniques. The performance of the proposed observer is benchmarked against a fractional-order extended Kalman filter using experimental data. The results demonstrate that incorporating a regularization law into the observer dynamics effectively mitigates observability limitations, offering a robust solution for the SC bank state estimation. Full article

Aquifer Thermal Energy Storage (ATES) is a promising technology for the seasonal storage of heat, thereby bridging the temporal gap between summer surpluses and peak winter demand. However, the efficiency of conventional ATES systems is severely compromised in aquifers with high groundwater flow velocities, as advective heat transport leads to significant storage losses. This study explores a novel three-well concept that implements an active hydraulic barrier, created by an additional extraction well upstream of the ATES doublet. This well effectively disrupts the regional groundwater flow, thereby creating a localized zone of stagnant or significantly reduced flow velocity, to protect the stored heat. A comprehensive parametric study was conducted using numerical simulations in FEFLOW. The experiment systematically varied three key parameters: groundwater flow velocity, the distance of the third well and its pumping rate. The performance of the system was evaluated based on its thermal recovery efficiency and a techno-economic analysis. The findings indicate that the hydraulic barrier effectively enhances heat recovery, surpassing twice the efficiency observed in a conventional two-well configuration (100 m/a). The analysis reveals a critical trade-off between hydraulic containment and thermal interference through hydraulic short-circuiting. The techno-economic assessment indicates that the three-well concept has the potential to generate significant cost and CO₂e savings. These savings greatly exceed the additional capital and operational costs in comparison to a traditional doublet system in the same conditions. In conclusion, the three-well ATES system can be considered a robust technical and economic solution for expanding HT-ATES to sites with high groundwater velocities; however, its success depends on careful, model-based design to optimize these competing effects. Full article

Solar photovoltaic (PV) power is an important force in promoting the transformation of the energy structure. An increase in PV panel temperature reduces open-circuit voltage and fill factor, thereby increasing the recombination of internal charge carriers and leading to a decrease in the output power of PV systems. When PV panels operate in the environment, high solar intensity may rapidly heat PV panels to very high temperature levels, converting a significant proportion of solar energy into waste heat. Waste heat further reduces the efficiency of PV panels. Therefore, effective cooling methods are important in improving the electrical performance and reliability of PV systems. For different types of PV panel cooling methods, many research works have been conducted. Aiming at providing a relatively valuable reference for future work on PV panel cooling methods, this paper presents a comprehensive review of existing research on cooling methods for PV panels. Relevant issues of eight types of PV panel cooling methods are introduced, including working principles, typical research, advantages, disadvantages, existing problems, and future research directions. Full article

With advancements in remote sensing technology and very-large-scale integration (VLSI) circuit technology, the Earth observation capabilities of spaceborne synthetic aperture radar (SAR) have continuously improved, leading to significantly increased performance demands for on-board SAR real-time imaging processors. Currently, the low data access efficiency of traditional direct memory access (DMA) engines remains a critical technical bottleneck limiting the real-time processing performance of SAR imaging systems. To address this limitation, this paper proposes a dedicated instruction set for spaceborne SAR data transfer control, leveraging the memory access characteristics of DDR4 SDRAM and common data read/write address jump patterns during on-board SAR real-time imaging processing. This instruction set can significantly reduce the number of instructions required in DMA engine data access operations and optimize data access logic patterns. While effectively reducing memory resource usage, it also substantially enhances the data access efficiency of DMA engines. Based on the proposed dedicated instruction set, we designed a DMA engine optimized for efficient data access in on-board SAR real-time imaging processing scenarios. Module-level performance tests were conducted on this engine, and full-process imaging experiments were performed using an FPGA-based SAR imaging system. Experimental results demonstrate that, under spaceborne SAR imaging processing conditions, the proposed DMA engine achieves a receive data bandwidth of 2.385 GB/s and a transmit data bandwidth of 2.649 GB/s at a 200 MHz clock frequency, indicating excellent memory access bandwidth and efficiency. Furthermore, tests show that the complete SAR imaging system incorporating this DMA engine processes a 16 k × 16 k SAR image using the Chirp Scaling (CS) algorithm in 1.2325 s, representing a significant improvement in timeliness compared to existing solutions. Full article
