A linear frequency modulation (LFM) signal and its corresponding de-chirp operation are one of the basic methods for wideband radar signal processing, which can reduce the burden of the radar system sampling rate and is more suitable for large-bandwidth signal processing. More importantly, most existing methods against interrupted sampling repeater jamming (ISRJ) are based on time–frequency (TF) or frequency domain analysis of the de-chirped signal. However, the above anti-ISRJ methods cannot be directly applied to multiple-input multiple-output (MIMO) radar with multiple beams, because the angular waveform (AW) in mainlobe directions does not possess the TF properties of the LFM signal. Consequently, this work focuses on the co-optimization of transmit beampattern and AW similarity in wideband MIMO radar systems. Different from the existing works, which only concern the space–frequency pattern of the transmit waveform, we recast the transmit beampattern and AW expressions for wideband MIMO radar in a more compact form. Based on the compact expressions, a co-optimization model of the transmit beampattern and AWs is formulated where the similarity constraint is added to force the AW to share the TF properties of the LFM signal. An algorithm based on the alternating direction method of multipliers (ADMM) framework is proposed to address the aforementioned problem. Numerical simulations show that the optimized waveform can form the desired transmit beampattern and its AWs have similar TF properties and de-chirp results to the LFM signal. Full article

We propose and demonstrate a tunable femtosecond electro-optic optical frequency comb by shaping a continuous-wave seed laser in an all-fiber configuration. The seed laser, operating at 1.5 μm, is first cascade-phase-modulated and subsequently de-chirped to generate low-contrast pulses of approximately 8 ps at a repetition rate of 5.95 GHz. These pulses are then refined into clean, high-quality picosecond pulses using a Mamyshev regenerator. The generated source is further amplified using an erbium–ytterbium-doped fiber amplifier operating in a highly nonlinear regime, yielding output pulses compressed to around 470 fs. Tunable continuously across a 5.7~6 GHz range with a 1 MHz resolution, the picosecond pulses undergo nonlinear propagation in the final amplification stage, leading to output pulses that can be further compressed to a few hundred femtoseconds. By using a tunable bandpass filter, the center wavelength and spectral bandwidth can be flexibly tuned. This system eliminates the need for mode-locked cavities, simplifying conventional ultrafast electro-optic combs by relying solely on phase modulation, while delivering femtosecond pulses at multiple-gigahertz repetition rates. Full article

A novel photonic-assisted multifunctional radar system was proposed and experimentally investigated. This system can simultaneously achieve frequency-doubled linear frequency modulation (LFM) signal generation, de-chirp reception, self-interference cancellation, and frequency measurement in an integrated transmit-receive radar. First, a high-frequency and broadband LO signal was obtained with photonic frequency doubling, which improved the center frequency and bandwidth of the radar detection system. Then, photonic-assisted interference cancellation was used to reduce the impact of interference signals in radar de-chirp reception. Finally, the microwave frequency measurement was achieved by establishing a mapping relationship between the envelope response time of the intermediate frequency (IF) electrical filter and the microwave frequency to be tested. Both theoretical and experimental investigations were performed. The results showed that an LFM signal with a frequency range of 12–18 GHz was obtained with photonic frequency doubling. Photonic-assisted self-interference cancellation reduced the impact of interference signals in radar de-chirp reception by more than 12.1 dB for an LFM signal bandwidth of 6 GHz. In the frequency measurement module, the difference between the frequency to be tested, generated by the external signal source, and that calculated in the experiment is the measurement error, and a measurement resolution better than 14 MHz was achieved in the range of 12.14 GHz–18.14 GHz. The proposed system is suitable for miniaturized multifunctional radar signal processing systems with continuous operation of transmitting and receiving antennas in unmanned aerial vehicles (UAVs), automotive radar, relatively close spatial locations, and so on. In addition, it can simplify the system structure and reduce space occupation. Full article

The F-SCAN principle is a better alternative to the scan-on-receive technique (SCORE) based on digital beamforming (DBF), which can avoid low gain caused by a conventional broad beam in the case of a wide swath. In F-SCAN SAR, a pencil beam scans the entire target area from far to near, providing high energy independent of the position and ensuring a low range ambiguity-to-signal ratio (RASR). Moreover, echo compression can be achieved via appropriate system parameter configuration, significantly shortening the receive window and reducing the amount of data. A wider range swath can, therefore, be achieved. However, for this novel F-SCAN SAR working mode, signal modeling and imaging processing are key issues that needed to be addressed. In this paper, the far-field synthetic antenna pattern of the space–time coding array (STCA) is first derived and analyzed, based on which the signal modeling of the F-SCAN SAR is carried out. Then, according to the signal model and echo characteristics, a novel imaging processing method based on the hybrid correlation algorithm is presented for the F-SCAN SAR. First, the dechirp operation is performed to compensate for the quadratic phase of the range time. The range compressed result is obtained after a range Fourier transform, where different range targets are successfully separated and range aliasing is avoided. Then, the modified azimuth reference function is correlated with the echo at each range cell to complete range cell migration correction (RCMC) and azimuth compensation. The received signal parameters and the Doppler parameters of each range cell are derived to update the azimuth reference function. Finally, accurate focused results are obtained in the range-frequency, azimuth-time domain. The simulation results indicate that the signal model based on the STCA can satisfy the requirements of the F-SCAN principle, and the proposed imaging algorithm can complete the precise focusing processing of the F-SCAN SAR echo. Full article

As a new high-resolution spaceborne SAR observation mode, sliding-spot imaging has the characteristics of a large squint, long aperture time, and azimuth aliasing, and because of the dechirp operation in the imaging algorithm of this mode, it is difficult to construct a direct range–Doppler equation for its geometric processing. In this paper a conformation model based on an antenna pointing vector is presented, which fully considers the influence of the dechirp operation on the range image, starts from the relative position of the dechirped range image points and the satellite, and establishes a strict conversion model between the image coordinates and geographic coordinates using the accurate satellite–ground geometric conditions. Then the forward and reverse formulas for geometric processing of the sliding-spot mode are given based on this model. Finally, geometric calibration and positioning experiments under different conditions and field spaceborne SAR data are executed. Results show that after geometric errors caused by the SAR payload have been calibrated and other factors such as atmospheric delay, platform position, and elevation error have been compensated, the uncontrolled geometric positioning accuracy can reach within 1 m–2 m, which fully proves the effectiveness of this method in the geometric positioning of high-resolution sliding-spot images. Full article

Software risk prediction is the most sensitive and crucial activity of Software Development Life Cycle (SDLC). It may lead to the success or failure of a project. The risk should be predicted earlier to make a software project successful. A model is proposed for the prediction of software requirement risks using requirement risk dataset and machine learning techniques. In addition, a comparison is made between multiple classifiers that are K-Nearest Neighbour (KNN), Average One Dependency Estimator (A1DE), Naïve Bayes (NB), Composite Hypercube on Iterated Random Projection (CHIRP), Decision Table (DT), Decision Table/Naïve Bayes Hybrid Classifier (DTNB), Credal Decision Trees (CDT), Cost-Sensitive Decision Forest (CS-Forest), J48 Decision Tree (J48), and Random Forest (RF) achieve the best suited technique for the model according to the nature of dataset. These techniques are evaluated using various evaluation metrics including CCI (correctly Classified Instances), Mean Absolute Error (MAE), Root Mean Square Error (RMSE), Relative Absolute Error (RAE), Root Relative Squared Error (RRSE), precision, recall, F-measure, Matthew’s Correlation Coefficient (MCC), Receiver Operating Characteristic Area (ROC area), Precision-Recall Curves area (PRC area), and accuracy. The inclusive outcome of this study shows that in terms of reducing error rates, CDT outperforms other techniques achieving 0.013 for MAE, 0.089 for RMSE, 4.498% for RAE, and 23.741% for RRSE. However, in terms of increasing accuracy, DT, DTNB, and CDT achieve better results. Full article

Geosynchronous Synthetic Aperture Radar (GEO SAR) has a very long Coherent Processing Interval (in the order of hundreds of seconds) compared with other SAR platforms. Thus, the current methods of rotation effect matching and ship imaging that operate within a relatively short Coherent Processing Interval (in the order of seconds) are obviously not applicable. To address this problem, a novel ship imaging method with multiple sinusoidal functions matching for rotation effects is proposed for GEO SAR. Firstly, the influence of the rotational motion of a ship on the slant range is analyzed. It can be matched with the sum of multiple sinusoidal functions, and the signal model of a ship with rotational motion is given. Then, multiple sinusoidal functions for the matching-based ship imaging method are proposed, and their procedures are presented as follows: (1) The Generalized Keystone Transform and Generalized Dechirp Process (GKTGDP) is modified to compensate for the range migration and phase caused by the motion of GEO SAR. Then, the signal is focused at the frequencies of sinusoidal functions, and the frequencies can be matched. (2) From the matched frequencies, the other parameters of sinusoidal functions can be matched by parameter searching. (3) Based on the matched results, the Back Projection Algorithm (BPA) is used to take an image of the ship with rotational motion. Finally, the effectiveness of the proposed method is verified by numerical experiments. Full article

In this paper, a fast three-dimensional (3-D) frequency scaling algorithm (FSA) with large depth of focus is presented for near-field planar millimeter-wave (MMW) holographic imaging. Considering the cross-range range coupling term which is neglected in the conventional range migration algorithm (RMA), we propose an algorithm performing the range cell migration correction for de-chirped signals without interpolation by using a 3-D frequency scaling operation. First, to deal with the cross-range range coupling term, a 3-D frequency scaling operator is derived to eliminate the space variation of range cell migration. Then, a range migration correction factor is performed to compensate for the residual range cell migration. Finally, the imaging results are obtained by matched filtering in the cross-range direction. Compared with the conventional RMA, the proposed algorithm is comparable in accuracy but more efficient by using only chirp multiplications and fast Fourier transforms (FFTs). The algorithm has been tested with satisfying results by both simulation and experiment. Full article
