Fuel vapor can be ignited by lightning through various means, particularly through hot spot formation on fuel tank skins. The wing fuel tank cover and its surrounding outer plates together form part of the aerodynamic shape of an aircraft. The lightning protection design of the fuel system, including wing fuel tank, is of great significance for ensuring the aircraft safety. Based on the Joule heating and implosion effect, the damage response of a composite fuel tank cover subjected to lightning strikes is analyzed in this paper. The adopted method combines electrical–thermal coupling with explicit dynamics analysis. Firstly, a finite element model of the fuel tank cover is established using electrical–thermal coupling elements, and the lightning current impact simulation is carried out under given electrical boundary conditions and thermal boundary conditions. On one hand, the ablation criterion is determined by the Joule heating effect and the sublimation temperature of materials. The thermal damage of composite materials subjected to transient high currents is obtained through transient thermal analysis. On the other hand, special implosion elements are selected according to the temperature distribution obtained from the electrical–thermal coupling analysis. The original composite material model in the implosion region needs to be replaced with a new material model described by the high-explosive material model and the JWL equation of state. The von Mises stress distribution and pressure distribution on the structure after implosion are discussed in detail. The results show that concave pits are formed near the implosion zone. Unlike the thermal damage morphology defined by the ablation criterion, the implosion effect makes the damage distribution deviate from the initial fiber direction of each layer. The implosion dynamic method reveals the internal damage and pit and bulge phenomenon around the lightning attachment area to a certain extent. Full article

The design process of complex systems, such as hybrid aircraft, consists of several stages that depend on each other. The product is virtually validated by simulations in various disciplines. Each of these stages and simulation disciplines is carried out by different experts and they can choose from different tools in their field. The models created during this process are highly interdependent but are typically managed independently by each team. In this paper the first implementation of an open digital platform (ODP) is presented to provide a common data backbone for models from various tools and enable traceability across domains. An open data schema is used to ensure an open interface for the platform. This is implemented with SysML v2. In a proof of concept, two tools from different domains, simulation process and data management (SPDM) and product lifecycle management (PLM) using Teamcenter^® Simulation software and model-based design (MBD) using Simcenter™ Amesim™ software, are connected through this open standard. Full article

Emergency locator transmitters (ELTs) are key safety systems for post-crash aircraft localization and search-and-rescue operations. In more electric aircraft (MEA), however, their design and operation are increasingly influenced by complex electrical architectures, tighter equipment integration, and more demanding electromagnetic environments. This paper presents a narrative literature review of ELT technology from a MEA-oriented perspective. A practice-oriented narrative approach is adopted, examining ELTs through a dual lens: the evolution of the search and rescue (SAR) ecosystem and the progressive electrification of aircraft systems. The review addresses ELT fundamentals, classifications, operating principles, and interaction with the Cospas-Sarsat infrastructure, and examines the transition from legacy analog beacons to modern 406 MHz digital systems incorporating GNSS positioning, MEOSAR capabilities, second-generation beacon functionalities, and distress tracking features. Particular attention is given to integration challenges in MEA platforms, including autonomous energy supply, battery endurance, power quality disturbances, electromagnetic compatibility, installation robustness, antenna survivability, and certification constraints. The analysis highlights that ELT performance in MEA depends not only on the beacon itself, but also on the coupled interaction among device design, installation conditions, and the electrical environment. Finally, the review outlines research priorities for next-generation ELTs, including improved survivability assessment, energy-aware architectures, integration strategies based on electromagnetic compatibility, and certification-ready solutions compatible with future aircraft platforms. Full article

In the 21st century, the desire for improved fuel efficiency of engines, lower fuel prices, and the need to reduce greenhouse gas emissions such as ${\mathrm{C}\mathrm{O}}_2$ and ${\mathrm{N}\mathrm{O}}_{\mathrm{x}}$ are leading the aviation industry to seek hybrid-electric jet engines for commercial aircraft. These aircraft will have greater maintenance challenges due to additional components requiring more reliable materials for the engine’s parts, such as turbine blades. Turbine blades must be composed of materials that have enhanced fatigue performance. Resistance to dynamic loads and high strength will be needed to ensure modern gas turbine blades are as reliable as possible. This review paper examines hybrid-electric engine turbine blades and subsequently introduces additive manufacturing (AM) and multi-principal element alloys (MPEAs) with a focus on laser powder bed fusion (LPBF), high-entropy alloys (HEAs), and medium-entropy alloys (MEAs). The tensile properties of LPBF HEAs range from 5 to 47% elongation and a UTS of 572–1640 MPa, while LPBF MEAs range from 8 to 73.9% and a UTS of 573–1382 MPa. This study focused on dynamic and fatigue properties while acknowledging gaps in high-temperature testing. The combination of mechanical properties with the ability to control internal geometry makes these AM alloys an attractive option for the next generation of gas turbine blades. Full article

The growing need to reduce aviation’s carbon footprint and reliance on fossil fuels has prompted the exploration of alternative propulsion technologies. Fuel cell (FC) systems offer a sustainable solution, generating only water vapor as a by-product. This paper presents a conceptual study, focusing on subsystem integration and safety aspects, for an 80-passenger, hydrogen-powered aircraft developed within the European Union (EU) co-funded NEWBORN (NExt generation high poWer fuel cells for airBORNe applications) Project. The designed configuration incorporates wing-mounted pods housing fuel cells, an electric motor, an inverter, a Thermal Management System (TMS), and Balance of Performance (BoP). This configuration is an effort towards environmentally friendly solutions, addressing climate change and paving the way towards greener aviation. Full article

To meet aviation decarbonization goals, novel electric energy storage systems are required. A promising approach combines a Li-ion battery with a hydrogen proton exchange membrane fuel cell system (PEMFCS) into an electrochemical energy storage and conversion (EC-ESC) system. Proper power management ensures efficiency, reliability and durability. The study investigates EC-ESC performance for regional hybrid electric aircraft under varying degrees of hybridization. By systematically adjusting the power split between the battery and FCS, we quantify its impacts on system sizing, energy efficiency and battery degradation. The results show that a well-balanced power distribution enhances overall efficiency and energy density while extending system lifetime. Full article

Hybrid-electric regional aircraft require detailed thermal management digital twins to assess performance and feasibility while reducing physical test effort. The Functional Mock-Up Interface (FMI) enables partners to exchange subsystem models as Functional Mock-Up Units (FMUs) for gate-to-gate simulation while preserving intellectual property. However, FMU integration introduces numerical coupling challenges, interface overhead, and potential loss of accuracy depending on the integration method. Benchmarking against a DLR Thermofluid Stream (TFS) reference model showed that FMU-based co-simulation can significantly increase computational effort, specifically from 8 min up to 2.5 h. Control-based integration further implicates transient deviations due to filtering, although steady-state accuracy generally remains unchanged. Therefore, it is mandatory to evaluate and compare FMU integration strategies to show that digital twin performance targets remain achievable when design, solver settings, and filtering are only applied selectively and systematically. The results show clear design guidance: employ native fluid libraries when possible for speed and accuracy, use FMU paired with adapters and without filters for accuracy, and reserve filtering for numerical stabilization only. Using a control approach to integrate the FMU improves simulation speed compared to adapters but introduces a small error, which in turn reduces simulation accuracy. Full article

The development of More Electric Aircraft (MEA) necessitates that Electro-Hydrostatic Actuator (EHA) controllers achieve exceptional power density within rigorously constrained volumes. However, the compact layout design of these controllers constitutes a challenging NP-hard problem, characterized by strong multi-physics coupling—such as electromagnetic, thermal, and structural fields—and complex nonlinear constraints. Traditional meta-heuristic algorithms frequently suffer from premature convergence and struggle to balance global exploration with local exploitation. To address these challenges, the core contribution of this paper is the proposal of a novel Fractional-Order Anteater Foraging Optimization Algorithm (AFO), which is successfully applied to an established EHA controller layout optimization model. At the algorithmic level, by incorporating the Grünwald–Letnikov fractional derivative, the algorithm exploits the inherent memory property of fractional calculus to dynamically adjust the search step size and direction based on historical evolutionary information, thereby preventing stagnation in local optima. At the engineering application level, a high-fidelity mathematical model of the EHA controller is established, comprising 11 design variables and 10 critical physical constraints, including parasitic inductance minimization, thermal radiation efficiency, and electromagnetic interference (EMI) isolation. Extensive validation against the CEC2005 and CEC2022 benchmark functions demonstrates the superior convergence accuracy and stability of the AFO algorithm. In a specific EHA case study, the proposed method reduced the controller volume by 33.9% while strictly satisfying all multi-physics constraints, compared to traditional methods. Furthermore, a physical prototype was fabricated based on the optimized layout, and experimental tests confirmed its stable operation and excellent thermal performance. The results validate the efficacy of incorporating fractional calculus into bio-inspired algorithms to solve complex, high-dimensional engineering optimization problems. Full article

Liquid hydrogen (LH₂) as an energy source is viewed as a potential path to achieve carbon neutral commercial aviation, albeit accompanied by a plethora of structural, thermal and safety challenges that still need to be resolved. With respect to a LH₂ tank’s structural integration aspect, static, damage tolerance and impact/crashworthiness responses need to be investigated. Ιn the present work, an efficient structural integration concept of LH₂ tanks into a Regional Commercial Aircraft fuselage is proposed, analyzed and preliminary designed, as part of the Clean Aviation project HERFUSE. The main purpose of the work is the feasibility assessment of introducing adhesively bonded solutions in the connection of LH₂ tanks to the aircraft fuselage. The initial design of the potential mounting system configuration was investigated via a finite element parametric simulation model that was developed for this purpose and used to analyze different variations in the proposed concept, under certification relevant load cases. Different variations in the mounting system were assessed, considering their effect on the stress concentrations developed in the fuselage and the tank structure, as well as induced deformations and potential joints debonding. The results indicated that the utilization of adhesive bonding elements in the design of an LH₂ tank integration system is conceptually efficient, although the specific configuration-related shortcomings that were identified need to be tackled. As far as the preliminary design study results are concerned, the minimum required number of joining elements were identified and an initial mass prediction of the mounting system was performed to be used as initial value in the entire hybrid–electric novel aircraft design loop. Future studies on the detailed design and sizing of the mounting system, as well as to incorporate dynamic crash analyses and implementation of energy absorbing elements are needed. Full article

Due to advancements in thermal engineering and nanotechnology, nanofluids—base fluids containing dispersed nanoparticles (1–100 nm)—have emerged as promising high-performance coolants. Their enhanced thermal properties make them attractive for application in hybrid-electric aircraft, which require efficient Thermal Management Systems (TMS) to dissipate significant heat loads. This study employs a dynamic TMS model to assess the influence of key nanofluid features, including nanoparticle type, volume fraction, particle diameter, and base fluid. Metal nanoparticles provided the greatest thermal improvement (up to 19%). Increasing concentration enhanced cooling efficiency, with 0.5%, 1%, and 2% volume fractions reducing mean temperature by 14%, 19%, and 24%, respectively. Smaller particles performed better, as 20 nm nanoparticles achieved a 21.3% temperature reduction compared to 17.5% for 60 nm. Water-based nanofluids exhibited the best overall thermal behaviour, although they remain unsuitable for aeronautical applications. Full article

The weight of battery modules keeps hindering them from being commercially attractive as the sole power supply for short-range electric passenger flights. Furthermore, the challenging requirements for aerospace applications limit the range of options for module elements and complicate the implementation of lightweight solutions. Hence, the objective of this study is to elaborate and evaluate concepts for battery modules to identify promising solutions for electrified aircraft propulsion systems. For that purpose, a house of quality is compiled to assess the relations between options for module elements and module requirements, as well as correlations between options. Potential concepts are elaborated by combining suitable elements. Finally, the concepts are evaluated to highlight the most preferable and compatible ones for aircraft battery modules. Full article

New propulsion technologies not only allow reducing the climate effect of aircraft, but also enable new architectures and integration options. To make use of this increased design space variety, new design methods need to be developed. In this work, an existing design process for CS-23 hydrogen-electric aircraft is expanded with the capability to design various powertrain options. These methods are used to evaluate the designs of two different concepts for small commuter aircraft with centralized and distributed fuel cell (FC) systems, respectively. The results show that the overall mass and performance of both concepts are very similar. However, the concept with distributed FC systems has a lower energy consumption, better FC cooling, and improved maintainability. Thus, the distributed concept is chosen. The final design has the powertrain components distributed among 10 engine pods. To transport nine passengers over 600 km without exceeding the targeted Maximum Take-off Mass (MTOM) of 5700 kg, the propulsion system’s power-to-weight ratio needs to be improved by 1.2% from the current technology level. Full article

Hybrid-electric propulsion and alternative energy carriers are being considered to mitigate the climate impact of short-range regional aviation. Within this framework, the HERA (Hybrid Electric Regional Architecture) project investigates advanced propulsion architectures for a next-generation 72 passenger regional platform. This work presents a cradle-to-grave Life Cycle Assessment of two HERA reference configurations and compares them with a conventional 70 passenger turboprop representative of current service aircraft. The analysis focuses on lithium–sulphur batteries, proton exchange membrane fuel cells, liquid hydrogen storage tanks, and electric motors. The assessment is implemented through a parametric LCA tool supported by a detailed Life Cycle Inventory based on Ecoinvent v3.8 and evaluated using ReCiPe 2016 midpoint indicators. The system boundary includes raw material extraction, manufacturing and assembly, operation under defined mission profiles, maintenance with component replacement, and End-of-Life (EoL) treatment. Results show that the operational phase remains the main driver of climate change impacts, exceeding 95% of total CO₂ equivalent emissions across configurations. The battery-based hybrid reduces fuel consumption but increases manufacturing and maintenance burdens. The fuel cell configuration shows a more balanced life cycle profile, with platinum identified as a critical hotspot. Full article

The design of Hybrid-Electric Regional (HER) aircraft represents a great challenge due to the systems’ complexity and their level of integration and results in a great expense of resources. To overcome these issues, the Open Digital Environment for Hybrid-Electric Regional Architecture (ODE4HERA) project is developing an Open Digital Platform (ODP) to accelerate the design process. The platform is validated using a pilot case which focuses on powertrain systems and covers the entire development process, from requirements definition to Virtual Integrated Verification and Validation (IV&V). At first, the design is performed using state-of-the-art tools; then it is repeated using preliminary ODP modules to evaluate the achieved benefits. Full article

The aviation industry is increasingly prioritizing sustainability, with significant focus on the development of Hybrid-Electric Aircraft (HEA). By integrating electric motors with conventional combustion engines, HEA systems offer substantial environmental benefits and operational efficiency improvements. However, the successful implementation of HEA technologies is contingent upon advancements in power converter systems. This paper addresses the critical need for sustainable aviation solutions by examining the challenges and opportunities associated with High-Efficiency Aviation Power (HEAP) technology. Specifically, the study investigates the role of power converters in Hybrid-Electric Aircraft Propulsion systems, with a particular emphasis on addressing key concerns such as weight reduction, compact design, and system reliability. A comparative analysis of three converter topologies is conducted: two established configurations serve as baseline references, while a third topology, a modular, fault-tolerant DC-DC converter, is proposed for the first time in the context of hybrid-electric aircraft. Its novelty lies in the system-level use of redundancy to offer an inherent architectural advantage against cosmic-ray-induced failures a critical aviation reliability challenge that existing converter topologies do not address through hardware redundancy. This qualitative reliability advantage is presented as an architectural feature, pending quantitative validation through future hardware testing and mean-time-between-failures (MTBF) analysis. This exploration is essential for identifying the most suitable configuration for HEA integration, with the goal of overcoming challenges related to lightweight design, high efficiency, and reliability. The findings contribute to the advancement of more sustainable and efficient aviation solutions by demonstrating the potential of the proposed converter architecture. Full article
