Electric ducted fans (EDFs) have emerged as promising propulsion systems due to their compact design, high thrust density, and enhanced operational safety. Accurate prediction of aerodynamic thrust is essential for EDF design and performance evaluation; however, existing numerical studies have not yet provided a systematic comparison of the thrust-prediction capability of different k−ω-based turbulence models in micro-EDF applications. In this study, a dedicated thrust-measurement platform was developed for a 120 mm EDF, and experimental thrust data were obtained under three representative hover operating conditions. Based on these measurements, six turbulence models, including SST, SK$\omega$, BSL, GEKO, EARSM, and SST-$\gamma$(alg.), were evaluated using three-dimensional CFD simulations. The numerical model was assessed through thrust validation, centerline velocity comparison, power-consistency analysis, grid independence verification, and qualitative flow-field interpretation. A two-factor full-factorial analysis was further conducted to quantify the effects of rotational speed and turbulence model on prediction accuracy and computational cost. The results show that the turbulence model has a stronger influence on the normalized thrust-prediction error than the rotational speed factor over the investigated operating range. The SST-$\gamma$(alg.) model achieves the highest thrust-prediction accuracy, with an average relative deviation of 0.47%, but requires the highest computational cost. In comparison, the SST model provides a favorable balance between accuracy and efficiency, with an average relative deviation of 1.79% and an average computation time of 184.33 min, approximately 33% lower than that of the SST-$\gamma$(alg.) model. The centerline velocity and power-consistency results further support the comparative model assessment. Overall, this study provides an experimentally validated comparative reference for turbulence model selection in simulations of similar 120 mm EDF under hover conditions. Considering both prediction accuracy and computational efficiency, the SST model can serve as a practical turbulence model choice for engineering parameter optimization of similar micro-EDF configurations. Full article

The deployment of wall-climbing robotic systems plays an important role for executing inspection and maintenance tasks in high-risk environments and minimizing the risk to operators tasked with the inspection. Conventional adhesion techniques, such as magnetic, suction, and dry adhesives, encounter significant challenges when applied to diverse surface types. This study presents a four-wheeled robotic platform utilizing dual electric ducted fans (EDFs) to produce adjustable adhesion forces, facilitating uninterrupted movement from horizontal to vertical planes. A comprehensive multibody dynamics model constructed using MSC Adams analyzed wheel–surface interaction, thrust forces, and system stability during transitional phases, revealing essential force parameters for stable vertical operation and determining minimum thrust levels required to sustain four-point contact during orthogonal transitions. These findings informed thrust distribution optimization between the two EDF units to reduce rotational effects while ensuring sufficient safety margins during the ground to vertical wall transition. The findings also allowed for appropriate thrust application ensuring the generation of the required normal force distribution at wheel contact interfaces during vertical movement. A physical prototype was developed and experimentally validated, demonstrating dependable adhesion and maneuverability across a spectrum of orientations and highlighting the efficacy of simulation-driven design for thrust-based adhesion systems. Full article

Few studies have examined Hybrid Aquatic–Aerial Vehicles (HAAVs), autonomous vehicles designed to operate in both air and water, especially those that are aircraft-launched and recovered, with a variable-sweep design to free dive into a body of water and breach under buoyant and propulsive force to re-achieve flight. The novel design research examines the viability of a recoverable sonar-search child aircraft for maritime patrol, one which can overcome the prohibitive sea state limitations of all current HAAV designs in the research literature. This paper reports on the analysis from computational fluid dynamic (CFD) simulations of such an HAAV diving into static seawater at low speeds due to the reverse thrust of two retractable electric-ducted fans (EDFs) and its subsequent breach back into flight initially using a fast buoyancy engine developed for deep-sea research vessels. The HAAV model entered the water column at speeds around 10 ms⁻¹ and exited at 5 ms⁻¹ under various buoyancy cases, normal to the surface. Results revealed that impact force magnitudes varied with entry speed and were more acute according to vehicle mass, while a sufficient portion of the fuselage was able to clear typical wave heights during its breach for its EDF propulsors and wings to protract unhindered. Examining the medium transition dynamics of such a novel HAAV has provided insight into the structural, propulsive, buoyancy, and control requirements for future conceptual design iterations. Research is now focused on validating these unperturbed CFD dive and breach cases with pool experiments before then parametrically and numerically examining the effects of realistic ocean sea states. Full article

Most of the developed and studied service robots for vertical locomotion, as visual inspection, are made up by a rigid body with legs, wheels, or both. Thus, the robot can only displace over regular and/or flat surfaces since it is not able to adapt to the irregularities and projections of the wall. Therefore, this paper presents the design and analysis of an adaptable robot for vertical locomotion service tasks, which has a body made up of four wheeled legs that can easily adapt to the different irregularities and projections of building facades. The robot uses an Electric Ducted Fan (EDF) as the vortex adhesion system. Each leg has a rubber cover, which allows a higher mechanical adaptability of the robot over different irregularities of the wall. Theoretical backgrounds and open issues are addressed by considering some challenging problems such as mechanical adaptability modeling as well as kinematic and static analysis. Laser sensors are mounted over the robot to measure the adaptability of the robot, between the legs and body, at each time of the experimental tests for vertical locomotion. Full article

The field of unmanned aerial vehicles (UAVs) has experienced substantial growth, with applications expanding across diverse domains. Missions increasingly demand higher autonomy, reducing human intervention and relying more on advanced onboard systems. However, integrating hybrid power sources, especially micro-turboprop engines, into UAVs poses significant challenges due to their complexity, hindering the development of effective power management control systems. This research aims to design a control algorithm for dynamic power allocation based on UAV operational needs. A fuzzy logic-based control algorithm was implemented on the Single-Board Computer (SBC) of a micro-turbogenerator test bench, which was previously developed in an earlier study. After implementing and testing the algorithm, voltage stabilization was achieved at improved levels by tightening the membership function constraints of the fuzzy logic controller. Automating the throttle control of the Electric Ducted Fan (EDF), the test platform’s primary power consumer, enabled the electric generator’s maximum capacity to be reached. This result indicates the necessity of replacing the current electric motor with one that is capable of higher power outputs to support the system’s enhanced performance. Full article

A study on aerodynamic design studies of a blended wing–body (BWB) unmanned aerial vehicle (UAV) operating at low Mach numbers is presented. First, a parametric investigation based on analytical equations is carried out to identify the range of the necessary wetted area for the UAV to maximize endurance at a Mach number close to 0.1. A base-of-reference configuration is designed, and its aerodynamic performance is evaluated by utilizing a panel method in Xflr5. An optimization algorithm is then incorporated to trim the UAV and produce the ‘clean’ configuration. Computational fluid dynamics (CFD) simulations are performed within the OpenFoam environment to produce first the updated drag polars, and then, to analyze the integration of the nacelle and the pair of electric ducted fans (EDFs) used for the propulsion system. In particular, when examining the integration of the nacelle with a spinning electric ducted fan (EDF) standing as the propulsion system of the vehicle, a rotating, sliding mesh computational approach is adopted. Results indicate that the clean configuration is characterized by strong longitudinal stability so that the UAV has the potential to fly trimmed at very low speeds. Mounting EDFs on the back of the fuselage is conducive to higher loading with minimal drag penalty. An increased lift-to-drag ratio is achieved. Reduced wake mixing due to the EDF’s jet flow is observed. The spanwise flow that is conducive to pitch brake and loss of stability is also weak, as the suction produced by the EDF diverts the flow inboard. Full article

This paper aims to conduct an acoustic analysis through noise measurements of a hybrid propulsion system intended for implementation on a drone, from which the main noise sources can be identified for further research on noise reduction techniques. Additionally, the noise was characterized by performing spectral analysis and identifying the tonal components that contribute to the overall noise. The propelling force system consists of a micro-turboshaft coupled with a gearbox connected to an electric generator. The propulsion system consists of a micro-turboshaft coupled with a gearbox connected to an electric generator. The electric current produced by the generator powers an electric ducted fan (EDF). The engineturbo-engine was tested in free-field conditions for noise generation at different speeds, and for this, an array of microphones was installed, positioned polarly around the system and near the intake and exhaust. Consequently, based on the test results, the acoustic directivity was plotted, revealing that the highest noise levels are at the front and rear of the engine. The noise level at a distance of 1.5 m from the turboengine exceeds 90 dBA at all tested speeds. Spectral analyses of both the far-field acoustic signals (measured with a polar microphone array) and the near-field signals (microphones positioned near the intake and exhaust) revealed that the primary contributors to the overall noise are the micromotor’s compressor, specifically the gas dynamic phenomena in the fan (BPF and 2× BPF). Thus, it was determined that at the intake level, the main noise contribution comes from the high-frequency components of the compressor, while at the exhaust level, the noise mainly originates from the combustion chamber, characterized by low-frequency components (up to 2 kHz). The findings from this study have practical applications in the design and development of quieter drone propulsion systems. By identifying and targeting the primary noise sources, engineers can implement effective noise reduction strategies, leading to drones that are less disruptive in urban environments and other noise-sensitive areas. This can enhance the acceptance and deployment of drone technology in various sectors, including logistics, surveillance, and environmental monitoring. Full article

New innovative green concepts in electrified vertical take-off and landing vehicles are currently emerging as a revolution in urban mobility going into the third dimension (vertically). The high population density of cities makes the market share highly attractive while posing an extraordinary challenge in terms of community acceptance due to the increasing and possibly noisier commuter traffic. In addition to passenger transport, package deliveries to customers by drones may enter the market. The new challenges associated with this increasing transportation need in urban, rural, and populated areas pose challenges for established companies and startups to deliver low-noise emission products. The article’s objective is to revisit the benefits and drawbacks of an affordable acoustic measurement campaign focused on early prototyping. In the very early phase of product development, available resources are often considerably limited. With this in mind, this article discusses the sound power results using the enveloping surface method in a typically available low-reflection room with a reflecting floor according to DIN EN ISO 3744:2011-02. The method is applied to a subsonic electric ducted fan (EDF) unit of a 1:2 scaled electrified vertical take-off and landing vehicle. The results show that considerable information at low costs can be gained for the early prototyping stage, despite this easy-to-use, easy-to-realize, and non-fine-tuned measurement setup. Furthermore, the limitations and improvements to a possible experimental setup are presented to discuss a potentially more ideal measurement environment. Measurements at discrete operating points and transient measurements across the total operating range were conducted to provide complete information on the EDF’s acoustic behavior. The rotor-self noise and the rotor–stator interaction were identified as primary tonal sound sources, along with the highest broadband noise sources located on the rotor. Based on engineering experience, a first acoustic improvement treatment was also quantified with a sound power level reduction of 4 dB(A). In conclusion, the presented method is a beneficial first measurement campaign to quantify the acoustic properties of an electric ducted fan unit under minimal resources in a reasonable time of several weeks when starting from scratch. Full article

With the expanding electrification in all sectors of transport, it is necessary to look for new efficient solutions for propulsion systems for use in air transport. One of the approaches can be the use of electric ducted fans (EDFs), especially in, but not limited to, the case of unmanned aerial vehicles with vertical takeoff and landing. This concept has been known for several decades but has been used very little and therefore has been almost unexplored. This opens up opportunities for investigating the performance characteristics, electrical consumption or efficient thrust vectoring of EDFs with respect to their design and operational use. The presented study therefore deals with the influence of the EDF design change on its performance characteristics. These design changes mainly concerned the geometry of the cowling, i.e., reduction and increase of outlet cross section, and arrangement of fans, i.e., one- and two-rotor specification. The comparison was based on measuring of vertical thrust and power consumption during static testing. The results showed that the increasing outlet is the most suitable construction for the generation of vertical thrust during static testing, considering the specifically used EDF construction arrangement. Based on the findings, it can also be concluded that EDFs are a suitable option for use in unmanned aircraft as a competition to other propulsion systems. Full article

Unmanned aerial vehicles (UAVs) have drawn significant attention from researchers over the last decade due to their wide range of possible uses. Carrying massive payloads concurrent with light UAVs has broadened the aeronautics context, which is feasible using powerful engines; however, it faces several practical control dilemmas. This paper introduces a medium-scale hexacopter, called the Fan Hopper, alimenting Electric Ducted Fan (EDF) engines to investigate the optimum control possibilities for a fully autonomous mission carrying a heavy payload, even of liquid materials, considering calculations of higher orders. Conducting proper aerodynamic simulations, the model is designed, developed, and tested through robotic Gazebo simulation software to ensure proper functionality. Correspondingly, an Ardupilot open source autopilot is employed and enhanced by a model reference adaptive controller (MRAC) for the attitude loop to stabilize the system in case of an EDF failure and adapt the system coefficients when the fluid payload is released. Obtained results reveal less than a 5% error in comparison to desired values. This research reveals that tuned EDFs function dramatically for large payloads; meanwhile, thermal engines could be substituted to maintain much more flight endurance. Full article

Water ingression is a critical issue in honeycomb composite structures, which could result in catastrophic structural failure. In the aviation industry, they are widely used to manufacture critical aircraft structural components including fuselage, wings, and flight control surfaces. Catastrophic failure of these structures would be disastrous, thus identifying water accumulation in earlier stages of the defect is necessary. The conventional non-destructive testing method is thermography which is performed using handheld thermography cameras by manually accessing the specific areas. This method of inspection has been identified to be a risky, costly, time-consuming, and inspector-dependent technique. This paper describes using a wall-climbing robotic platform that can be controlled remotely to access and perform the inspection on a targeted structural area replacing the manual process. The designed wall-climbing inspection robot onboard a heat pump to stimulate the composite surface to an adequate temperature and, an infrared sensor to feed the real-time temperature data via Bluetooth serial communication to a remote computer system to be processed into a thermal image and evaluated to determine the presence of water. The results obtained from the thermographic sensor are validated with the comparison of the Fluke thermography camera. Full article
