Search Results (31)

Addressing the critical challenges of low accuracy, response hysteresis, and insufficient adaptability to complex dynamic tracking conditions in the pressure buildup control strategy of the Electro-Hydraulic Brake system (EHB), this paper proposes a cascaded multi-loop control algorithm based on Active Disturbance Rejection Control (ADRC) and Sliding Mode Control (SMC). Specifically, an ADRC–based integrated position–speed controller is designed to simultaneously analyze the influence of motor speed and piston displacement, thereby mitigating the issue of performance degradation and simplifying the observation of internal system states. Furthermore, the pressure loop utilizes a feedforward-based SMC algorithm tailored to the strong nonlinearity and significant interference characteristics of the hydraulic–mechanical coupling. A joint simulation platform based on Matlab/Simulink and AMESim was established, followed by validation through vehicle tests on a One-box experimental vehicle under step, sinusoidal, and ramp pressure signals. Simulation results indicate that the steady-state pressure error is maintained below 0.1 MPa. Crucially, real vehicle tests demonstrate steady-state errors within ±0.2 MPa (ramp) and ±0.5 MPa (sinusoidal), with maximum dynamic tracking errors kept below 0.8 MPa and 1.2 MPa, respectively. These findings comprehensively verify the advantages of the proposed strategy in terms of response speed, steady-state accuracy, reliability, and robustness. Full article

To address the bottlenecks of conventional valve-controlled marine steering systems—characterized by high throttling losses, low efficiency, and high leakage risk—as well as the insufficient power density and impact resistance of electro-mechanical actuators (EMAs) for high-load steering of large vessels, this paper proposes and validates a high-performance integrated solution for an electro-hydrostatic actuator (EHA) for ship steering. First, a fifth-order electro–hydraulic–mechanical coupled dynamic model comprising a permanent magnet synchronous motor, hydraulic pump, hydraulic cylinder, and load is established. The validity and applicability boundaries of three simplifying assumptions—neglecting leakage, pipeline pressure losses, and steady-state fluid compressibility effects—are quantitatively analysed, with a total introduced error ≤3%. These assumptions are justified under medium-pressure, short-pipeline, and well-sealed conditions typical of marine EHA systems. Second, a composite control architecture combining outer-loop sliding mode control with inner-loop motor PID dual-loop control is proposed. Parameter tuning is performed using pole placement for the sliding surface and the Ziegler–Nichols critical ratio method for the inner loops, effectively suppressing hydraulic system parameter perturbations and random wave-induced load disturbances. Quantitative comparisons show that the proposed method reduces overshoot by 11.63% and improves sinusoidal tracking accuracy by 90.13% compared to conventional single-loop PID control. An integrated drive-control structure is designed, and a three-phase full-bridge inverter main circuit with wide-voltage input capability—including EMI filtering, soft-start, and LC filtering—is developed to accommodate the ±20% voltage fluctuations typical of ship power grids, thereby enhancing system integration and grid adaptability. Phased bench tests demonstrate that the settling time from no-load start-up to 200 r/min is only 0.01 s. When a sudden 20 N·m load is applied, the speed drop is less than 3%, and the recovery time is less than 0.025 s. The steady-state steering angle error does not exceed 0.12°, the maximum average steering rate reaches 3.33°/s, and the steering response time is within 0.3 s. All core performance indicators exceed the general technical standards for marine steering systems, with a 65.7% improvement in steady-state accuracy and a 62.5% improvement in response speed over conventional PID control. The research findings provide an effective general technical solution and experimental data support for the performance optimization and engineering application of marine EHA systems. Full article

The brake–release stability of electro-hydraulic thrusters (EHTs) significantly affects the safety of hydraulic braking systems, especially under low-temperature conditions with varying fluid viscosity. Most existing studies have focused on macroscopic braking characteristics, while the internal flow field variation and vortex evolution mechanism during the brake–release process remain insufficiently explored. In this work, transient CFD simulations are conducted to investigate vortex formation rules and flow field characteristics inside an EHT. Three typical vortex structures denoted as α, β, and γ are identified, and the independent and coupling influences of fluid dynamic viscosity and motor speed on vortex intensity and piston-bottom pressure are quantitatively analyzed. The results show that vortices α and β trigger flow disorder and additional hydraulic energy loss, while vortex γ optimizes flow uniformity and assists piston extension. Higher fluid viscosity exacerbates vortex development and pressure fluctuation, while increasing motor speed accelerates transient flow field evolution. This study clarifies the internal flow mechanism of EHT brake–release behavior and provides reliable parametric guidance for optimizing the low-temperature performance of electro-hydraulic braking systems. Full article

Crawler cranes suffer from power mismatch in their electro-mechanical–hydraulic main drive system under sudden load variations and multi-action coupling conditions, which results in low energy utilization efficiency. This study establishes an electro-hydraulic closed-loop transfer function model and proposes a synthetic deviation-driven proportional–integral–derivative power matching control strategy to regulate hydraulic pump displacement. Experiments on a 1250 t crawler crane show that the model is reliable, with the coefficient of determination R² between simulation and experimental data exceeding 0.94. The strategy improves power matching by 27.33% for the engine–pump link and 18.9% for the full link in single-action conditions, and 12.67% and 8.7% in compound-action conditions. After control, the engine–pump power matching coefficient stabilizes around 1.04 and the full-link coefficient stabilizes within 1.05 to 1.21 under single-action conditions, while under compound-action conditions, the engine–pump coefficient stabilizes within 1.05 to 1.15 and the full-link coefficient stabilizes within 1.0 to 1.25. The control strategy suppresses power mismatch and optimizes system stability and energy efficiency, which provides a technical reference for the optimization of electro-mechanical–hydraulic drive systems in heavy machinery. Full article

To address the technical challenge where traditional high-pressure, large-flow emulsion pump stations cannot adapt to the drastic flow rate changes in hydraulic supports due to the fixed displacement of their quantitative pumps—leading to frequent system unloading, severe impacts, and damage—this study proposes an intelligent flow control method based on the digital flow distribution principle for actively perceiving and matching support demands. Building on this method, a compact, electro-hydraulically separated prototype with stepless flow regulation was developed. The system integrates high-speed switching solenoid valves, a piston push rod, a plunger pump, sensors, and a controller. By monitoring piston position in real time, the controller employs an optimized combined regulation strategy that integrates adjustable duty cycles across single, dual, and multiple cycles. This dynamically adjusts the switching timing of the pilot solenoid valve, thereby precisely controlling the closure of the inlet valve. As a result, part of the fluid can return to the suction line during the compression phase, fundamentally achieving accurate and smooth matching between the pump output flow and support demand, while significantly reducing system fluctuations and impacts. This research adopts a combined approach of co-simulation and experimental validation to deeply investigate the dynamic coupling relationship between the piston’s extreme position and delayed valve closure. It further establishes a comprehensive dynamic coupling model covering the response of the pilot valve, actuator motion, and backflow control characteristics. By analyzing key parameters such as reset spring stiffness, piston cylinder diameter, and actuator load, the system reliability is optimized. Evaluation of the backflow strategy and delay phase verifies the effectiveness of the multi-mode composite regulation strategy based on digital displacement pump technology, which extends the effective flow range of the pump to 20–100% of its rated flow. Experimental results show that the system achieves a flow regulation range of 83% under load and 57% without load, with energy efficiency improved by 15–20% due to a significant reduction in overflow losses. Compared with traditional unloading methods, this approach demonstrates markedly higher control precision and stability, with substantial reductions in both flow root mean square error (53.4 L/min vs. 357.2 L/min) and fluctuation amplitude (±3.5 L/min vs. ±12.8 L/min). The system can intelligently respond to support conditions, providing high pressure with small flow during the lowering stage and low pressure with large flow during the lifting stage, effectively achieving on-demand and precise supply of dynamic flow and pressure. The proposed “demand feedforward–flow coordination” control architecture, the innovative electro-hydraulically separated structure, and the multi-cycle optimized regulation strategy collectively provide a practical and feasible solution for upgrading the fluid supply system in fully mechanized mining faces toward fast response, high energy efficiency, and intelligent operation. Full article

Achieving high-precision motion control for hydraulic manipulators presents a challenging task. Addressing the issue of low motion control accuracy caused by the strong electromechanical-hydraulic coupling characteristics of hydraulic manipulator systems, this paper innovatively introduces an RBF neural network and an Actor–Critic reinforcement learning architecture within a performance-based control framework designed using the inverse method. This approach enables dual compensation for both internal uncertainties and external disturbances within the manipulator, thereby enhancing the system’s control performance. First, within the control architecture, the performance function ensures system transient performance while employing an RBF neural network to estimate and compensate for internal unmodeled errors caused by mechanical coupling and hydraulic parameter uncertainties. Stability proofs are used to derive the network weight update rate. Second, a disturbance compensator is designed based on reinforcement learning. Deployed into the controller through offline training and online adaptation, it compensates for external system disturbances, further improving control accuracy. Finally, comparative and ablation experiments conducted on a hydraulic manipulator testbed demonstrate the effectiveness of the disturbance compensator. Compared to PID control, the proposed approach achieves a 60–65% improvement in control accuracy. Full article

The transition to battery electric vehicles (BEVs) is enabling the significant redesign of key subsystems, including braking systems. This work presents a physics-based optimization framework for the preliminary design of a distributed electro-hydraulic brake-by-wire (DEHB) system tailored for electric vehicles. The DEHB system is modeled as a two-phase actuation process captured through a coupled electro-mechanical and hydraulic model: initial pad–disc clearance closure and subsequent pressure buildup. Sensitivity analysis is employed to identify critical design parameters, and a multi-objective genetic algorithm is used to minimize electrical power consumption, peak current, and maximum torque while satisfying performance constraints. The optimized configuration is benchmarked against commercially available solutions and validated against a multiphysics simulation, showing deviations below 8% for current and power. A dynamic analysis incorporating vehicle-level ABS logic demonstrates the improved performance and energy efficiency of the DEHB system during emergency braking, with a reduction of 50% in required power if compared to a non-optimized system. The results confirm the effectiveness of the proposed method for early-stage sizing and highlight the potential of DEHB architectures in future electric vehicle platforms. Full article

Pumped-storage power stations, as a critical resource for supporting secure and stable grid operation, typically adopt a ’single-tunnel-multiple-unit’ configuration, where hydraulic disturbance becomes a key operating condition affecting system security. Existing studies have primarily focused on the impact of the hydro-mechanical subsystem on the normally operating units, while the influence of the electrical subsystem on hydraulic disturbance has been insufficiently addressed. To bridge this gap, this study develops a coupled model of a grid-connected pumped-storage power station incorporating a detailed representation of the power system. The model comprehensively captures the multi-domain interactions among the hydraulic, mechanical, electrical, and grid subsystems, and its accuracy is validated using data from a physical model test platform. On this basis, the hydraulic transient responses under two modeling conditions—detailed grid representation and conventional simplified grid modeling—are systematically compared. Key parameters from the hydraulic, mechanical, and electrical domains are further examined to quantify their impacts on the dynamic characteristics of hydraulic disturbance. The results demonstrate that detailed grid modeling reveals novel characteristics of the hydraulic disturbance that cannot be simulated by the conventional model. Under the detailed model, the normally operating units compensate for the power deficit caused by the tripping unit, leading to reduced hydraulic pressure fluctuations and a significant increase in the maximum output of the operating units. Meanwhile, hydro-mechanical parameters strongly influence the transient behaviors of unit output and net head, whereas the guide vane regulation of the operating unit remains predominantly driven by grid-frequency deviations. Overall, this study enhances the understanding of hydraulic disturbance dynamics in grid-connected pumped-storage systems and provides important insights for ensuring their secure and stable operation. Full article

In response to the demands for high reliability, excellent dynamic response, and high-precision control of advanced aircraft actuation systems, this study focuses on the control technology for the master-master operating mode of dual-redundancy electro-hydrostatic actuation (EHA) systems. A multi-domain coupling model integrating motor magnetic circuit saturation, hydraulic viscosity-temperature characteristics, and mechanical clearances was established, based on which a current-loop decoupling technique using vector control was developed. Furthermore, the study combined adaptive sliding mode control (ASMC) and an improved active disturbance rejection control (ADRC) to enhance the robustness of the speed loop and the disturbance rejection capability of the position loop, respectively. To address the key challenges of synchronous error accumulation and uneven load distribution in the master-master mode, a dual-redundancy dynamic model accounting for hydraulic coupling effects was developed, and a two-level cooperative control strategy of "position synchronization-dynamic load balancing" was proposed based on the cross-coupling control (CCC) framework. Experimental results demonstrate that the position loop control error is less than ±0.02 mm, and the load distribution accuracy is improved to over 97%, fully meeting the design requirements of advanced aircraft. These findings provide key technical support for the engineering application of power-by-wire flight control systems in advanced aircraft. Full article

The electro-hydraulic hybrid system has emerged as a critical technology in new energy vehicles, owing to the remarkable power density and efficient energy regeneration capabilities of hydraulic technology, coupled with the high energy density of electric power. This system effectively enhances vehicle range and battery life. We developed an energy management strategy (EMS) for the electro-hydraulic hybrid system (EHHS) to ensure smooth energy conversion, while ensuring the full utilization of electrical and hydraulic energy within a reasonable and efficient range. To enhance the system’s overall performance, it is imperative to address pivotal technologies, including power coupling and energy management. In this research, the structure of an electro-hydraulic hybrid vehicle (EHHV) is classified, compared and discussed. The application of existing EHHVs is studied. Subsequently, an analysis and summary are conducted on the current status and development trends of EMSs and collaborative operation control strategies (COCSs), and a novel mechanical-electro-hydraulic power-coupled system (MEHPCS) is put forward that successfully converts mechanical, electrical, and hydraulic energy in performance. Simultaneously, other applications of the system are forecasted. Finally, some suggestions for the electro-hydraulic hybrid systems’ future development are made. This study can promote the development of sustainable transportation technologies. The system integrates mechanical engineering, control theory, and environmental science, enabling interdisciplinary methodological innovation. In addition, relevant studies provide data support for policy makers by quantifying energy consumption indicators. Full article

The strong coupling of the six-degree-of-freedom (6-DoF) electro-hydraulic Stewart parallel mechanism manifests as adjusting the elongation of one actuator potentially inducing motion in multiple degrees of freedom of the platform, i.e., a change in pose; this pose change leads to time-varying and unbalanced load forces (disturbance inputs) on the six hydraulic actuators; unbalanced load forces exacerbate the time-varying nature of the acceleration and velocity of the six hydraulic actuators, causing instantaneous changes in the pressure and flow rate of the electro-hydraulic system, thereby enhancing the pressure–flow nonlinearity of the hydraulic actuators. Considering the advantage of artificial intelligence in learning hidden patterns within complex environments (strong coupling and strong nonlinearity), this paper proposes a reinforcement learning motion control algorithm based on deep deterministic policy gradient (DDPG). Firstly, the static/dynamic coordinate system transformation matrix of the electro-hydraulic Stewart parallel mechanism is established, and the inverse kinematic model and inverse dynamic model are derived. Secondly, a DDPG algorithm framework incorporating an Actor–Critic network structure is constructed, designing the agent’s state observation space, action space, and a position-error-based reward function, while employing experience replay and target network mechanisms to optimize the training process. Finally, a simulation model is built on the MATLAB 2024b platform, applying variable-amplitude variable-frequency sinusoidal input signals to all 6 degrees of freedom for dynamic characteristic analysis and performance evaluation under the strong coupling and strong nonlinear operating conditions of the electro-hydraulic Stewart parallel mechanism; the DDPG agent dynamically adjusts the proportional, integral, and derivative gains of six PID controllers through interactive trial-and-error learning. Simulation results indicate that compared to the traditional PID control algorithm, the DDPG-PID control algorithm significantly improves the tracking accuracy of all six hydraulic cylinders, with the maximum position error reduced by over 40.00%, achieving high-precision tracking control of variable-amplitude variable-frequency trajectories in all 6 degrees of freedom for the electro-hydraulic Stewart parallel mechanism. Full article

The instability of mine roadways is significantly influenced by the coupled effects of groundwater seepage and non-uniform loading. These interactions often induce localized plastic deformation and progressive failure, particularly in the roof and sidewall regions. Seepage elevates pore water pressure and deteriorates the mechanical properties of the rock mass, while non-uniform loading leads to stress concentration. The combined effect facilitates the propagation of microcracks and the formation of shear zones, ultimately resulting in localized instability. This initial damage disrupts the mechanical equilibrium and can evolve into severe geohazards, including roof collapse, water inrush, and rockburst. Therefore, understanding the damage and failure mechanisms of mine roadways at the mesoscale, under the combined influence of stress heterogeneity and hydraulic weakening, is of critical importance based on laboratory experiments and numerical simulations. However, the large scale of in situ roadway structures imposes significant constraints on full-scale physical modeling due to limitations in laboratory space and loading capacity. To address these challenges, a straight-wall circular arch roadway was adopted as the geometric prototype, with a total height of 4 m (2 m for the straight wall and 2 m for the arch), a base width of 4 m, and an arch radius of 2 m. Scaled physical models were fabricated based on geometric similarity principles, using defect-bearing sandstone specimens with dimensions of 100 mm × 30 mm × 100 mm (length × width × height) and pore-type defects measuring 40 mm × 20 mm × 20 mm (base × wall height × arch radius), to replicate the stress distribution and deformation behavior of the prototype. Uniaxial compression tests on water-saturated sandstone specimens were performed using a TAW-2000 electro-hydraulic servo testing system. The failure process was continuously monitored through acoustic emission (AE) techniques and static strain acquisition systems. Concurrently, FLAC^3D 6.0 numerical simulations were employed to analyze the evolution of internal stress fields and the spatial distribution of plastic zones in saturated sandstone containing pore defects. Experimental results indicate that under non-uniform loading, the stress–strain curves of saturated sandstone with pore-type defects typically exhibit four distinct deformation stages. The extent of crack initiation, propagation, and coalescence is strongly correlated with the magnitude and heterogeneity of localized stress concentrations. AE parameters, including ringing counts and peak frequencies, reveal pronounced spatial partitioning. The internal stress field exhibits an overall banded pattern, with localized variations induced by stress anisotropy. Numerical simulation results further show that shear failure zones tend to cluster regionally, while tensile failure zones are more evenly distributed. Additionally, the stress field configuration at the specimen crown significantly influences the dispersion characteristics of the stress–strain response. These findings offer valuable theoretical insights and practical guidance for surrounding rock control, early warning systems, and reinforcement strategies in water-infiltrated mine roadways subjected to non-uniform loading conditions. Full article

The electro-hydraulic composite intelligent completion technology is one of the most effective ways to solve the efficient development of oil and gas. The development of an electro-hydraulic composite wet joint tool that is compatible with the electro-hydraulic composite intelligent completion system can achieve intelligent control between the upper and lower pipe columns of deepwater oil and gas wells and the pluggable transmission of monitoring signals. This article proposes a new type of electromagnetic coupling electro-hydraulic composite wet joint designed to address the defects of friction damage and poor contact in current wet joint direct contact power transmission. The joint uses claw docking and wireless energy transmission to achieve the composite transmission of hydraulic and electric power. Firstly, we independently designed a DC power supply inverter circuit, rectification circuit, and wireless power transmission coil assembly to form a wireless power transmission system. We also conducted testing and analysis on the wireless power transmission efficiency, which exceeded 60%. When the input voltage was above 80 V, the output power was greater than 60 W, meeting the design requirements. Secondly, the mechanical structure of the new electro-hydraulic signal wet joint tool was optimized and its strength was verified. The simulation results showed that the maximum stress was 891.8 MPa, and the maximum deformation of the wet joint docking overall structure was 0.123 mm. The strength and deformation met the design requirements. The hydraulic and electrical connectivity indoor tests were conducted on the electromagnetic coupling wet joint, and all aspects of transmission were normal, thus forming a design scheme for the underground electromagnetic coupling electro-hydraulic signal wet joint. The wireless transmission type electro-hydraulic signal wet joint designed in this article is of great significance for accelerating the promotion and application process of deepwater intelligent completion systems. Full article

A two-dimensional (2D) piston electro-hydraulic pump has been proposed further to enhance the power density of the electro-hydraulic pump. The 2D piston pump, characterized by high power density and a slender shape, is embedded within the stator of the motor in a co-rotor configuration where the piston and the motor’s rotor are in tandem. The intimate design of the hydraulic pump and the motor results in a coupling between the two, with intricate relationships and influences existing between the geometric parameters of the piston pump and the dimensions of the motor’s rotor. Based on the operational requirements and structure of the 2D piston pump, a permanent magnet synchronous motor (PMSM) designed for use with a 2D piston electro-hydraulic pump is developed. This study examines the impact of the motor’s stator iron core geometric parameters on both the electromagnetic and mechanical properties of a PMSM and completes the necessary performance validations. The optimization objectives of the motor are determined through an analysis of the influence of the key parameters of the rotor and stator on torque, torque ripple, and motor loss. A surrogate optimization model is constructed using a metamodel of optimal prognosis (MOP) to optimize the torque, torque ripple, and motor loss. Evolutionary genetic algorithms are utilized to achieve the multi-objective optimization design. A finite element simulation is used to compare the electromagnetic performance of the initial motor and optimal motor. Based on the optimal motor parameters, a 2.5 kW motor prototype is manufactured, and the experimental results validate the feasibility and effectiveness of the motor design and optimization. Full article

A high strain rate occurs when the strain rate exceeds 100 s⁻¹. The mechanical behavior of materials at a high strain rate is different from that at middle and low strain rates. In order to study the dynamic compressive mechanical properties of ultra-high-performance steel-fiber-reinforced concrete (UHPSFRC) at high strain rates, an electro-hydraulic servo universal testing machine and a separate Hopkinson pressure bar (SHPB) with a diameter of 120 mm were used, respectively. A quasi-static compression test (strain rate 0.001 s⁻¹) and impact compression test with a strain rate range of 90~200 s⁻¹ were carried out to study the failure process, failure mode, and stress–strain curve characteristics of UHPSFRC at different strain rates and quantify the strain rate strengthening effect and fiber toughening effect. Based on the statistical damage theory and energy conversion principle, a dynamic damage constitutive model considering the effects of strain rate and fiber content was constructed. The results showed that the rate correlation of UHPSFRC and the fiber toughening properties showed a certain coupling competition mechanism. When the fiber content was less than 1.5%, with an increase in the steel fiber content, the crack initiation and propagation time of the specimen was extended, and the strain rate sensitivity gradually decreased. When the fiber content was 2%, the impact compressive strength of the specimen was optimal. Compared with UHPC, the dynamic increase factor (DIF) of UHPSFRC was significantly lower. The dynamic damage constitutive model established in this paper, considering the influence of strain rate and fiber content, has a good applicability and can describe the mechanical behavior of UHPSFRC at a high strain rate. Full article
