Search Results (79)

To address the pressure of space target census posed by low-orbit mega-constellations such as Starlink, this paper proposes an LEO target census constellation design method based on a layered NSGA-II algorithm. Six decision variables—orbital altitude, inclination, number of orbital planes, number of satellites per plane, sensor field of view, and focal length—are considered. Coverage rate, revisit period, and constellation cost are taken as optimization objectives to establish a multi-objective optimization model. To overcome the issues of slow convergence and susceptibility to local optima in high-dimensional decision spaces faced by classical multi-objective optimization algorithms, the decision variables are divided into the orbit layer, configuration layer, and sensor layer. NSGA-II evolution is performed layer by layer, with elite retention and global archive passing of high-quality solutions. Using high-precision 24-h ephemeris of 496 Starlink satellites generated by STK as the simulation object, the proposed layered NSGA-II is compared with classical NSGA-II, MOPSO, MOEA/D, and SPEA2. Results show that the layered NSGA-II achieves a hypervolume (HV) of 13.16, outperforming the other algorithms. Under the condition of maintaining 99.6% coverage, the recommended constellation solution achieves a revisit period as low as 7.6 h and a constellation cost of 0.429, demonstrating significantly better comprehensive performance than other algorithms. Convergence speed is improved by approximately 36% compared to classical NSGA-II. This method provides an efficient and engineering-applicable optimization approach for LEO target census constellation design. Full article

The Research and Observation in Medium Earth Orbit (ROMEO) mission, developed at the University of Stuttgart‘s Institute of Space Systems, seeks to demonstrate a cost-effective exploitation of the medium Earth orbit (MEO) for sustainable access to space. It uses a green propulsion system with water as propellant to reach up to 2500 km altitude starting from a 450 km sun-synchronous orbit (SSO). This paper presents the design and intended use of the ROMEO satellite as well as its two in-house developed camera systems, the public relations (PR) and the near-infrared (NIR) camera system. The PR camera system features two silicon sensors with a Bayer color pattern in a compact, lightweight package and in a cold redundant setup to reduce the impact of radiation-related degradation. Their wide field of view (128 × 96°) allows imaging of the complete visible Earth in the mission‘s final orbit and supports calibration of the Earthshine telescope, which is the primary payload. The NIR camera system uses a commercial InGaAs sensor with a high quantum efficiency up to 1700 nm, coupled to a 100 mm focal length optics assembly that yields a ground sampling distance of 45 m in the initial orbit. Its scientific objectives include monitoring gas flares and wildfires, which are relevant to climate change research, and demonstrating an exoplanet transit detection—an unprecedented capability for a small satellite using a commercial off-the-shelf InGaAs sensor in the NIR spectrum. This paper demonstrates that ROMEO’s compact, low-mass camera systems meet mission constraints while enabling a broad spectrum of scientific and outreach activities. Full article

Compared with the conventional push-broom imaging mode, conical scanning extends the imaging swath through rotational scanning and is suitable for high-resolution, wide-swath remote sensing. To achieve continuous full-coverage imaging, the camera must be mounted at a certain tilt angle and employ an off-axis optical system with a sufficiently large field of view (FOV). However, the tilted installation causes nonuniform irradiance and increased off-axis distortion, while wide-field off-axis imaging also introduces radiometric consistency problems in focal-plane multi-detector stitching. To address these issues, this study investigates the optical design of a tilted off-axis camera for conical-scan imaging. Under the constraints of full coverage and swath requirements, key optical parameters were jointly determined, and a lightweight wide-coverage off-axis three-mirror system was designed, optimized, and evaluated. The final system has a focal length of 1545 mm, an F-number of 8.4, and a full FOV of 23.4° × 11.7°. The modulation transfer function is greater than 0.41 at the Nyquist frequency, and the maximum distortion is less than 2.5446%. In addition, for the focal-plane optical stitching structure, the coupled effects of local structural vignetting and global geometric vignetting induced by the tilted installation were analyzed. The results show that the gray-level difference in the adjacent detector overlap regions is only 0.31–0.53 digital numbers (DN), and the full focal plane shows a smooth gray-level attenuation rate of 5.39–6.77%. These results indicate that vignetting has no significant effect on focal-plane stitching. The proposed camera is well suited for conical-scan imaging. Full article

Multi-line-scan camera systems provide high-frequency sampling and wide field-of-view coverage, making them valuable for three-dimensional measurement and dynamic reconstruction. However, their one-dimensional projection property introduces scale ambiguity and strong parameter coupling during calibration, which limits the consistency and stability of local optimization in multi-camera systems. To address this issue, this paper proposes a global calibration method based on physical constraints and hierarchical optimization. A unified imaging and motion model is constructed by incorporating physical scale constraints and structural priors, and geometric scale information is introduced into the joint optimization to reduce scale ambiguity and parameter coupling. Parameter normalization and staged optimization are further adopted to improve numerical stability for variables of different magnitudes and enable consistent estimation of multi-camera parameters within a unified framework. Simulation and experimental results show that the method achieves stable convergence under focal-length initialization perturbation, baseline deviation, and noise interference, with a three-dimensional reconstruction error below 0.67 mm and a convergence probability of at least 99.7%. These results indicate that the proposed method effectively reduces calibration uncertainty in multi-line-scan camera systems and supports high-precision online measurement and dynamic three-dimensional perception. Full article

Three-dimensional seed phenotyping requires imaging systems capable of achieving micron-level resolution across a centimeter-level field of view (FOV), a goal constrained by the resolution–FOV trade-off in conventional light field architectures. This paper presents a hardware–software co-optimized framework that integrates a reconfigurable optical system with computational imaging pipelines to address this limitation. At the hardware level, we develop a tunable-focus lens module that enables flexible adjustment of the effective focal length, combined with a custom-designed microlens array (MLA). A mathematical model is established to analyze the interdependencies among FOV, lateral resolution, depth of field (DOF), and system configuration, guiding the design of individual optical components. On the computational side, we propose a hybrid aberration correction strategy: first, a co-calibration of lens and MLA aberrations based on line-feature detection; second, a conditional generative adversarial network (cGAN) with attention-guided residual learning to enhance sub-aperture images, achieving a PSNR of 34.63 dB and an SSIM of 0.9570 on seed datasets. Experimentally, the system achieves a resolution of 6.2 lp/mm at MTF50 over a 2–3 cm FOV, representing a 307% improvement over the initial configuration (1.52 lp/mm). The reconstruction pipeline combines epipolar plane image (EPI) analysis with multi-view consistency constraints to generate dense 3D point clouds at a density of approximately 1.5 × 10⁴ points/cm² while preserving spectral and textural features. Validation on bitter melon and rice seeds demonstrates accurate 3D reconstruction and accurate extraction of morphological parameters across a large area. By integrating optical and computational design, this work establishes a reconfigurable imaging framework that overcomes the resolution–FOV limitations of conventional light field systems. The proposed architecture is also applicable to robotic vision and biomedical imaging. Full article

This paper presents a systematic investigation into the design and performance of layered polymer gradient refractive index (GRIN) lenses. A material-driven optimization algorithm is proposed, which uses physical volume fractions of the constituent polymers to parameterize the refractive index distribution. By integrating effective medium theory with Sellmeier-based dispersion data, the algorithm ensures that the gradients remain within physically realizable material limits while better aligning with actual refractive index profiles. First, refractive index distribution models for first-order radial GRIN lenses and linear spherical radial GRIN lenses were derived based on material properties, establishing manufacturable lens parameterization expressions. Subsequently, simulation software was employed to model and compare a first-order GRIN doublet, a cemented doublet, a linear spherical radial GRIN lens, and a first-order GRIN aspheric lens. Numerical results demonstrate that the proposed GRIN structures exhibit superior performance in both monochromatic aberration suppression and chromatic control, particularly under large aperture conditions. For a lens system with a 50 mm focal length and a 25 mm entrance pupil diameter, the spherically symmetric GRIN lens achieves diffraction-limited chromatic performance, with its secondary spectrum reduced by over 70% compared to conventional cemented doublets. Furthermore, the first-order GRIN doublet maintains the smallest RMS spot size across multiple fields of view and exhibits the most stable aberration growth rate as the aperture increases. These results validate the feasibility of the material-driven GRIN modeling approach and provide theoretical support for high-performance, short-focal-length optical systems. Full article

Wide-swath longwave infrared (LWIR) imaging from Low Earth Orbit (LEO) demands fast optics and rectilinear (F-tan) mapping for thermal mapping and multi-frame registration. Achieving an F/1.2 aperture with a 112° diagonal field of view (FOV) and distortion within ±5% is challenging, as mapping constraints and field-dominant off-axis aberrations become strongly coupled at large chief-ray angles. The low-distortion target is not only a geometric specification, but also a practical requirement that reduces peripheral compression, helps maintain edge-detail consistency, and lowers digital de-warping effort in the processing pipeline. While traditional LWIR secondary imaging is predominantly restricted to narrow-field cooled systems for cold-stop constraints, the proposed architecture utilizes a curved intermediate image to effectively decouple mapping formation in the field-dominant front objective from aperture-dominant correction in the rear group. Using chalcogenide glasses, the lens achieves a 5.7 mm effective focal length within a 186.9 mm total track. Analysis over the 8–12 μm band confirms performance approaching the diffraction limit at the 50 lp/mm Nyquist frequency alongside stable geometric fidelity across the full field. Thermal analysis from −40 °C to 80 °C and Monte Carlo tolerance analysis demonstrate stable imaging performance and manufacturing feasibility, confirming the effectiveness of the proposed design approach. Full article

Long-wave infrared (LWIR) airborne optical systems for ground imaging are widely utilized in applications such as ground reconnaissance, agricultural monitoring, counterterrorism, and other fields. Traditional oblique-view ground-imaging optical systems suffer from a critical drawback compared to nadir-view systems: the significant variation in object distances between distant and nearby targets. This disparity leads to inconsistent ground resolution (GR), manifesting in images where distant targets exhibit significantly lower resolution than nearby ones. This characteristic is highly detrimental to information acquisition and three-dimensional modeling of the system. Furthermore, the limited field of view of fixed focal length systems prevents the unmanned aerial vehicle (UAV) from acquiring target information effectively across varying flight altitudes. To address this issue, this paper designs an oblique imaging optical system capable of achieving both constant GR and zoom functionality in the LWIR band. By controlling the ground resolution, a LWIR continuous zoom optical system was designed. The system maintains constant GR over the entire field of view. Its modulation transfer function (MTF) approaches the diffraction limit across the full field of view, and the spot diagram remains within Airy’s disk at each view angle. The radius of the spot diagram is smaller than that of the Airy disk, indicating that the geometric aberrations of the system are well corrected. The imaging performance is primarily determined by the wavelength and the F-number. In the case of LWIR, the longer wavelength results in a larger Airy disk radius. The system meets imaging quality requirements and is suitable for air-to-ground target reconnaissance imaging. Full article

To better meet the wavefront measurement requirements for large-aperture segmented mirrors after in-orbit deployment, this paper designs a measurement system based on an optical camera and targets. This system utilizes photogrammetry principles to measure target positions, fit the wavefront of the segmented mirror, and form a closed-loop control with the calibration mechanism. Based on the wavefront measurement range and accuracy requirements during the coarse calibration phase of the segmented mirror, the optical system was first designed. The measurement camera features a 16° × 12° rectangular field of view with a 100 mm focal length, achieving near-diffraction-limited imaging quality. The structural fundamental frequency of the measurement camera exceeds 400 Hz. Under a 4 °C temperature rise environment, the surface error of the optical lens remains better than 1/80$\lambda$. Based on error theory, a quantitative analysis of error sources and their impact on target position measurement accuracy was conducted, yielding theoretical measurement errors of ±0.0853 mm in the Z-direction and ±0.1525 mm in the X-direction. Through focal length calibration and imaging tests of the prototype, the measurement camera achieved a modulation transfer function greater than 0.11 with excellent imaging quality. With a focal length of 101.356 mm and a measurement range exceeding ±4 mm, it meets design requirements. Finite element simulation and Monte Carlo methods analyzed wavefront fitting accuracy under different operating conditions, yielding peak-to-valley values of 0.397 mm and root mean square values of 0.073 mm. The wavefront measurement system designed in this paper meets the structural rigidity and temperature adaptability requirements for in-orbit measurement systems. The prototype’s field of view satisfies the wavefront measurement range requirements, the camera’s focal length meets design specifications with good imaging quality, and the wavefront measurement deviation meets the accuracy requirements for the coarse calibration phase. Compared to current wavefront measurement systems, the proposed system significantly expands the measurement range, offering a novel wavefront measurement method for coarse calibration of tiled mirrors. Full article

Multi-channel common-aperture optical systems, which excel at simultaneous multi-spectral information acquisition, are widely used for image fusion. However, complex systems for long-distance multi-band detection suffer from difficulties in assembly and adjustment and light vignetting. To resolve this, the paper proposes a modular design method that splits the optical path into independent modules: the common-aperture optical path adopts an off-axis reflective beam-shrinking structure to extend the focal length and ensure 100% light input, compared with coaxial multi-channel common-aperture systems. The relay optical path of each spectral channel uses a continuous zoom design for smooth detection–recognition switching. Based on the method, a three-channel common-aperture system is developed integrating visible light (VIS), short-wave infrared (SWIR), and mid-wave infrared (MWIR). The modulation transfer function (MTF) and wavefront distribution of the common-aperture optical path approach the diffraction limit. After integration with the relay optical paths, the system, without global optimization, can achieve the following performance: the root mean square (RMS) across the full field of view (FOV) at different focal lengths for each channel is smaller than the detector pixel size (3.45 μm for VIS, 15 μm for SWIR/MWIR); the MTF exceeds 0.2 at the cutoff frequency. Subsequently, the results of the tolerance analysis verify the feasibility of the design for each module and the advantage of the modular layout in the assembly and adjustment of the system. Finally, the paper discusses the influence of parallel plates on the wavefront distortion of the system and proposes optimization thinking using freeform surfaces. The design results of the study validate the feasibility of the modular layout in simplifying the design and assembly of multi-channel common-aperture optical systems. Full article

Freeform optical design is regarded as a key approach to overcoming the performance limits of traditional imaging systems. However, the existing Seed Curve Expansion (SCE) algorithm has two major limitations. First, the initial and ideal image points are selected randomly, causing unstable optical performance and low construction accuracy, especially under finite object distance and non-paraxial incidence. Multiple trials are often needed, reducing efficiency and repeatability. Second, the algorithm cannot constrain aperture, focal length, or geometry; thus, despite good imaging quality, the final system parameters often deviate from design requirements, limiting engineering applicability. To address these issues, this work proposes a Stable Initialization Seed Curve Expansion (SI-SCE) algorithm based on ray tracing and Fermat’s principle. The method accurately calibrates the initial point and the ideal image point, eliminating uncertainties caused by randomness. A virtual auxiliary surface strategy is introduced to achieve high-precision freeform construction under finite object distance. In addition, a parameter constraint mechanism is embedded in the algorithm, enabling the designed off-axis multi-reflective freeform system to directly meet specified requirements on pupil diameter, focal length, and geometric size. The feasibility of the SI-SCE algorithm was demonstrated by designing a freeform off-axis three-mirror imaging system with a rectangular $6°\times 6°$ field of view and a moderate F-number. The final system features an F-number of 3.4 and an entrance pupil diameter of 60 mm. It achieves diffraction-limited performance across the Visible–NIR $\left(0.38-2 \mathrm{\mu }\mathrm{m}\right)$ wavelength range. Full article

A new concept for designing a visual magnification system is introduced. In this concept, apart from the conventional objective and the eyepiece group lenses in the system, an additional Power-Corrector (PC) group of lenses is introduced in the optical design. The Power-Corrector group is located between the objective and the intermediate image and allows an additional degree of freedom to the optical design. This enables improving the system’s performance such as the field of view (FOV) while eliminating the system’s aberrations or reducing them to an insignificant level. Incorporating the PC group achieves this by correcting aberrations that typically limit the performance of conventional eyepiece designs, allowing a wider acceptance angle for incoming light. Recent advances in wide field of view optical systems and compact optical design methodologies have highlighted the ongoing challenges in balancing field of view expansion with aberration control. In this configuration, the PC group unifies the units, the eyepiece and the objective groups, integrates their functionality to one coherent system such that the input focal length of the system is defined jointly by the focal lengths of the objective and the PC while the aberrations are corrected jointly by the PC and the eyepiece. Thus, while the system’s magnification is the ratio of the input focal length to the eyepiece focal length, the PC enables global optimization such that the PC and the eyepiece together have a combined aberration that is less than the characteristic aberration of the eyepiece. This integrated optimization enhances the FOV. Additionally, it maintains image quality, making the system more effective than traditional designs. Contemporary research in freeform optical surface design and optimization techniques demonstrates the growing importance of advanced aberration correction methods in modern optical systems. Using this concept, a compact imaging system with a wider FOV relative to customary designs with the same magnifications, was designed and manufactured. Full article

Far-infrared imaging is a powerful tool in night vision and temperature measurement, with broad applications in military, astronomy, meteorology, industrial, and medical fields. However, conventional imaging lenses face challenges such as large size, heavy weight, and difficulties in miniaturization, which hinder their integration and use in applications with strict requirements for mass and volume, such as drone-based observation and imaging. To address these limitations, we designed a dual-plane diffractive optical lens optimized for the 10.9–11.1 μm wavelength band with a 0.2 μm bandwidth. By optimizing parameters including focal length, spot size, and field of view, we derived the phase distribution of the lens and converted it into the surface sag. To enhance diffraction efficiency and minimize energy loss, the lens was fabricated using a continuous phase surface on single-crystal Germanium. Finally, an imaging system was constructed to achieve clear imaging of various samples, demonstrating the feasibility of both the device and the system. This approach shows great potential for applications requiring lightweight and miniaturized solutions, such as infrared imaging, machine vision, remote sensing, biological imaging, and materials science. Full article

We present a Lobster Eye (LE) X-ray optics module utilizing Multi-Foil Optics (MFO) technology. Designed for CubeSat-class missions, the system is based on the Schmidt arrangement and consists of two orthogonally oriented submodules composed of smooth, gold-coated glass foils. This configuration enables wide-field X-ray imaging with a short focal length of 400 mm and a characteristic cross-shaped focal spot. Key optical parameters, including focal length, full width at half maximum (FWHM), angular resolution, field of view (FOV), and effective area, have been experimentally verified in a vacuum setup using various X-ray sources and detectors. The Lobster Eye (LE) X-ray optics is ready for integration into a CubeSat demonstrator. Full article

To address the issues of insufficient detector target size and high system complexity in infrared bionic compound-eye systems, this paper designs a miniaturized cooled medium-wave infrared curved bionic compound-eye optical system specifically for large target surface detectors and develops a proof-of-concept prototype for verification. The system comprises three components: (1) a curved multi-aperture array, which consists of 61 sub-apertures with an entrance pupil diameter of 5 mm and a focal length of 10 mm; (2) a cooled planar detector; and (3) a relay imaging system, which adopts secondary imaging technology and achieves the matching between the array and detector with only six infrared lenses. The fill factor is introduced to analyze light energy utilization efficiency, providing a theoretical basis for improving the system’s signal-to-noise ratio and spatial information collection capability; meanwhile, the focal length distribution and pupil matching are analyzed to ensure the system’s optical performance. The system operates within the 3.7–4.8 μm wavelength band, with a total focal length of 3.08 mm, F-number of 2, and field of view reaching 108°. Simulations demonstrate that all sub-aperture imaging channels have MTF values greater than 0.47 at 33.3 lp/mm, with distortion less than 3%. Imaging test results verify that the system possesses excellent imaging performance. Full article
