The increasing use of cable-stayed bridges with steel box girders necessitates more sophisticated design approaches, as the diverse environments of bridge locations place higher demands on the design process. Determining a reasonable finished state is a critical aspect of bridge design, yet the current methods are significantly constrained. A new approach to optimizing the finished state is proposed. This method’s practicality and efficiency are verified through a case study, analyzing how constraints on vertical girder deflection, horizontal pylon displacement, cable forces, and cable force uniformity affect the optimization outcome. The results show that convergence of the mixed-constraint quadratic programming model is achieved within 30 iterations, yielding an optimized finished state that meets the design criteria. The chosen constraint ranges are deemed appropriate, and the optimization method for the construction stage is thus demonstrably feasible and efficient. The multiplier path following optimization algorithm is computationally efficient, exhibiting good convergence and insensitivity to the problem size. Being easy to program, it avoids the arbitrariness of manual cable adjustment, enabling straightforward determination of a reasonable finished state for the cable-stayed bridge with a steel box girder. The vertical displacement of the main girder, the positive and negative bending moments, and the normal stresses at the top and bottom edges, as well as the positive and negative bending moments in the towers, are significantly influenced by the constraint ranges. The horizontal displacement of the pylon roof is significantly affected by the constraint ranges of both the main girder’s vertical displacement and the pylon’s horizontal displacement, while the remaining constraint ranges have a limited impact. Full article

The synchronous construction of the pylon and cables of a cable-stayed bridge without backstays has the characteristics of a short construction period and reduced support costs. However, it also increases the difficulty of construction control, making the reasonable completion state of the bridge more complex. To investigate the impact of various load parameters on the structural state of a cable-stayed bridge without backstays during the synchronous construction process, and to ensure a rational final bridge state, this study proposes an assessment framework for evaluating the internal forces of the bridge. The framework initially uses the response surface method to establish explicit equations relating the control indicators of the bridge’s final state to various load parameters. Subsequently, through sensitivity analysis, the degree of influence of each load parameter on the structural response of the cable-stayed bridge without backstays is examined. The most sensitive factors are identified to create a bridge parameter influence library, which helps reduce computational costs. Based on this, a method for controlling construction errors and predicting cable forces is proposed. This method utilizes the pre-established bridge parameter influence library, combined with the internal force state of the bridge at the current construction stage, to accurately predict the tension force of the stay cables in the subsequent stage, thereby ensuring a rational final bridge state. The framework is ultimately validated through a case study of the Longgun River Bridge to assess its rationality and effectiveness. Full article

The reasonable CMF (Color, Material and Finishing) design for automotive interiors could bring positive psychophysical and affective responses of customers, providing an important guideline for automobile enterprises making differentiated products. However, current studies mainly focus on an aspect of CMF design or a single style of the automotive interior, and examined the design mainly through human visual perception. There lack systematic studies on the design and evaluation of automobile interior CMF, and more scientific evaluation of the design through human visual and touching perception was required. Therefore, this study systematically designed the automobile interior CMF based on Kansei engineering and eye-tracking technology. The study consists of five steps: (1) Product positioning: the Chinese young consumers, the new energy vehicles, and bridge and seat are the target users, the automotive model and the key interior components. (2) Kansei physiological measurement: nine groups of Kansei words and thirty-three interior samples were selected, and the interior samples were scored by the Kansei words. (3) Kansei data analysis: three design types were determined, i.e., “hard and stately”, “concise and technological” and “comfortable and safe”. Meanwhile, the CMF design elements of the automotive interiors under the three styles were obtained through mathematical methods. (4) Design practice: four CMF samples under each design style (12 samples) were developed. (5) Kansei evaluation: the design themes were conducted using eye-tracking technology, and the optimal sample that mostly satisfy the user’s Kansei requirements under each style was obtained. The proposed design process of automotive interior CMF may have great implications in the design of automotive interiors. Full article

The environmental effects of ship propellers were not even close to fully examined before the current massive ships were introduced to sea trade. Larger ships, result in greater length, beam, draft and propulsion power. Of concern here is the under-keel clearance (UKC) and applied power, the most important parameters causing sea bottom sediment resuspension and, consequently, the transport and deposition of washed sediments. The problems are multifarious: shorelines could be contaminated with heavy metals, petroleum hydrocarbons and other organic chemicals, which are sometimes buried deep in the sediment bed. The effects of resuspension on marine life have been well documented by marine biologists. Further, a ship passing through a flow field may have a significant hydrodynamic effect on the shipping channel: waves generated by moving vessels can accelerate shoreline erosion; erosion around quay piles have a negative impact on sea flora. Waves can also affect other manoeuvring vessels or ships at berth. Available empirical models are applicable for a steady state condition, addressing velocity and, consequently, shears at the sea bottom for defined UKC and states of applied power. The idea here is to calculate material resuspension dynamically in the water column based on realistic manoeuvring conditions, which can be a matter of some complexity. During a manoeuvre, the pilot must bring the ship into or out of the harbour in the safest possible way, operating the telegraph, rudder, thrusters and possibly tugs, and also co-ordinating the work of the linesmen. The jet speed powering the vessel is not only a function of the speed of the propeller, but also of the present speed of the ship, which has an effect on the propeller’s constantly changing torque. Additionally, the bathymetry is constantly changing, and the streamlines hit not only the seabed, but also the bank and other structures of the harbour basin. The resuspended material remains in the column long after the ship has finished manoeuvring, moving slowly through the entire water column and being transported not only by the remaining streamlines of the ship but also by general currents. Realistic manoeuvring parameters can be obtained from real-time simulations with a real crew using state-of-the-art Full Mission Bridge Simulators (FMBS); eddies and the like contribute to the distribution and material resuspension and can be calculated by applying numerical modelling. In this paper, a container ship departure manoeuvre is simulated dynamically using Wartsila FMBS obtained data, which are postprocessed and coupled with the MIKE 3 FM hydrodynamic modelling application to which we add the precise port of Koper bathymetry to gain ship propeller spatial jet velocity distribution in specific time domains. Obtained jet velocity distribution is further coupled with the MIKE 3 MT particle tracking application to visualize total resuspended sediment transport patterns, etc. Container ships were selected to amplify the urgency of this phenomenon; they are the most intrusive in terms of resuspending and scouring the seabed given their powerful engines and larger propellers. Passenger ships could have been used, car carriers, or even tankers; but the fear among scientists is that the issue will not be taken seriously enough by certain stakeholders. Full article

This paper presents a comprehensive study of the Xiangsizhou Bridge, a double-tower double-cable steel–concrete composite girder cable-stayed bridge located in Pingnan, Guangxi, China. A finite element model of the full-bridge spatial truss system was established using a dual main beam simulation of the steel–concrete composite girder. To obtain the initial reasonable bridge state, the minimum bending energy method was employed, followed by optimization of the state using the unknown load coefficient method to attain the final reasonable completion state. This paper proposes an innovative construction scheme for the erection of the main girders, which is designed to address the issue of excessive tensile stresses in the bridge deck slabs that can arise in conventional construction schemes. This scheme can save about 4 months of construction time and shorten the construction cycle of main beam erection by 60%. Furthermore, the study derived and verified a formula for the intermediate cable force during the construction process, which demonstrated its effectiveness. This study provides practical value for the design and construction of similar bridges. Full article

Chacao channel bridge is located in a tidal channel with highly-energetic hydrodynamics conditions and significant erodibility potential. Once finished, this 2.5 km long cable-stayed bridge will be the largest in South-America. Here we report an integrated procedure to estimate scour around two of its three towers, both located on a relatively complex but different soil matrices. A high-resolution hydrodynamic model based on the Reynolds-averaged Navier–Stokes equations (RANS), physical tests of in situ soil samples in a Rotating Erosion Testing Apparatus (RETA) and empirical formulas for scour estimation are combined to provide a reliable estimation of scour depth under a periodic tidal ebb-flow regime. The relatively homogeneous soil material at the North Tower shows a high susceptibility to hydrodynamic erosion, which is estimated with SRICOS methodology. The Central Tower, in contrast, needs a combined approach based on the current state of the rock, information collected from underwater explorations and theoretical progress made about rock scour in order to reduce the uncertainty of the soils’ substrate. This study reveals that scour estimation for engineering design purposes in complex soils can be achieved with a joined vision of different disciplines and modelling tools for minimizing the uncertainty. Full article

This article explores technical and socio-political factors that impacted construction of the Gokteik Viaduct railway bridge in Shan State, Burma, and the recurring failure of political powers to complete a continuous railway between Rangoon (Yangon) and Yunnan. Under rather contentious circumstances, the British government awarded an American steel company with the contract to construct what would become the world’s longest railway trestle bridge at the time of its completion in 1900. As an engineering marvel of its era, the Gokteik Viaduct is in the same category as the Eiffel Tower in Paris. Until now, however, scarce research has explored the Gokteik Viaduct in terms of historicity and factors that ultimately prevented this structure from fulfilling its intended purpose of transporting trainloads of marketable goods between Burma and Yunnan. This raises an ironic question: How could engineers construct such a remarkable bridge to service a railway that was never finished? Furthermore, why does the Gokteik Viaduct largely remain unexamined in terms of its noteworthy place in the geopolitics of Southeast Asia? In answering such questions, the authors conclude that the “unseen” story of the Gokteik Viaduct is not only about engineering prowess but of a political and social environment that continues to bedevil massive infrastructure projects in Upper Burma today. Full article

Most existing methods for the determination of the reasonable finished state of self-anchored symmetry suspension bridges were based on the stress state of the stiffening girders used in the construction. A simple and practical control method for the reasonable completion state of stiffened beam based on double control indexes of deformation and stress was proposed. In this paper, the long-term effects of shrinkage and creep were taken into consideration, and a finite element model was built to study the change in the stiffening girder stress during operation. The mid-span deflection of the middle span sustained increasing and the compression stress in the bottom slab of the stiffening girder consistently decreased under the effects of shrinkage and creep. The speed changes from fast to slow and tends to become stable in 50 years. Furthermore, stiffening girders under the action of hanger force, dead weight, cable force, and pre-stress were investigated to study the mechanism of the stress change during operation. Based on the safety stress state of stiffening girders after 50 years, a new control method for the reasonable finished state was proposed. Moreover, the total cross-section of stiffening girders maintained the compression stress state during the developing processes of shrinkage and creep in 50 years. Finally, the utilization in the Hunan Road self-anchored symmetry suspension bridge verified the simplicity and practicality of this new control method and confirms that the method can be implemented to guide the design and construction of the similar bridges. Full article

This paper presents a Light Electric Vehicle (LEV) fast charger with a Lithium-Ion Battery (LIB) and Super-Capacitor (SC). The LEV fast charger consists of an AC/DC rectifier and LLC (Inductor-Inductor-Capacitor) resonant Full bridge converter. The LLC resonant converter has high-efficiency and low switching loss because of Zero Voltage Switching (ZVS). So, it is used widely in the industry. In general, the fast charger algorithm uses the Constant Current (CC) mode and Constant Voltage (CV). The CC mode starts at first and then the CV mode finishes. However, there is a big control value gap between the CC mode and CV mode. Therefore, when changing from CC to CV, the transient state occurs. To compensate for the transient state, we propose a new control algorithm. By means of this algorithm, we can achieve a higher level of safety and stability. The fast charger with LIB of 800 Wh and SC of 50 Wh is analyzed and verified, and we obtain a maximum efficiency of 96.4%. The discussions are validated using the LLC resonant full bridge converter prototype at the laboratory level. Full article
