Search Results (335)

Micro air vehicles (MAVs) operating at low Reynolds numbers face aerodynamic and structural challenges that differ significantly from those encountered by conventional aircrafts. Nature provides effective solutions to these constraints, as insects, birds, and bats demonstrate highly efficient flight through integrated interactions between morphology, kinematics, and unsteady aerodynamic mechanisms. This review examines how biological flight principles can inform the design of next-generation MAVs. The study first analyzes biological flight strategies across insects, birds, and bats, with emphasis on scaling laws and physiological adaptations relevant to small-scale flight. It then reviews key unsteady aerodynamic phenomena governing low-Reynolds-number flight, including leading-edge vortex stability, wing–wake interactions, tandem-wing effects, and ground influence, as well as current modeling approaches ranging from quasi-steady methods to high-fidelity Navier–Stokes simulations. Building on these principles, the paper discusses biomimetic design strategies for MAV wings, structural–aerodynamic coupling, and actuation technologies used to replicate flapping flight. Existing MAV demonstrators inspired by biological flyers are analyzed, including concepts relevant to planetary exploration environments. Finally, the review identifies current technological limitations and research gaps in materials, actuation, aerodynamic modeling, and system integration. By synthesizing insights from biology and engineering, this work highlights key directions for the development of efficient, adaptable biomimetic MAV platforms capable of operating in complex environments. Full article

A review of morphing actuation systems in relation to rotary-wing aerial platforms is presented. The research highlights an inadequate maturation of rotary actuation systems, characterised by a scarcity of (1) comprehensive full-scale experimental research relative to non-rotary (fixed-wing) systems, (2) techniques used for rotary actuation systems and (3) implementation of full-chord morphing systems, with existing research only utilising partial-chord actuation techniques. Additionally, another notable shortcoming is presented to be the lack of comprehensive proportional investigation in the proposed five-step development process for rotary actuation designs. A comprehensive critical review is offered, covering the following challenges of progressing through this development process for rotary actuation systems from conceptual design to production: (1) numerical and computational studies, (2) small-scale wind-tunnel testing, (3) full-scale wind-tunnel testing, (4) demonstrator, and ultimately (5) fabrication for industrial implementation. The review examines several existing rotary actuation systems, including (but not limited to) leading-edge, trailing-edge and Gurney flaps; active twist; chord extension; variable span and camber systems. Comparisons are made between rotary morphing actuation systems and their non-morphing counterparts, highlighting the distinct difficulties encountered by rotary-wing systems due to the more complex and challenging operational conditions found in rotorcraft. The review reveals that a significant portion of existing research on rotary-wing systems has focused only on early-stage development, including computational modelling and sub-scale wind-tunnel experiments, underscoring the necessity for more comprehensive full-scale testing and prototype evaluation given that only a small number of studies have progressed to full-scale wind-tunnel testing or actual prototype evaluation, with only one example identified as having been tested on a production helicopter. In addition, a comparative Technology Readiness Level (TRL) assessment is presented for both rotary-wing and fixed-wing morphing actuation systems, enabling a structured evaluation of relative technology maturity, experimental validation depth, and proximity to operational implementation. Building upon this assessment, a morphing Actuation Concept-Transfer Feasibility (ACTF) study is also provided, examining the potential for adapting mature fixed-wing morphing actuation technologies for application in rotary-wing environments, while identifying the key structural, aerodynamic, and operational constraints that currently limit direct technology transfer. This study addresses and proposes opportunities for a novel rotary actuation system design and concludes by suggesting the potential for future research on more effectual systems to include full-chord configuration over larger spanwise blade footprints with innovative actuation mechanisms that could be utilised and progressed through all development stages from numerical studies to full-scale fabrication. Full article

The aerodynamics of avian flight provides critical inspiration for the design of bioinspired aerial vehicles, yet the quantitative characterization of free-flight wing kinematics remains challenging. This study employs a neural-network-based motion tracking approach (DeepLabCut) to analyze wingbeat kinematics in free-flying birds from video data. We automatically digitize key wing points and reconstruct three-dimensional trajectories to quantify asymmetric flapping patterns. Our analysis reveals that while wing oscillations approximate sinusoidal motion, they exhibit statistically significant velocity differences between upstroke and downstroke phases, confirming the stroke asymmetry of avian flapping. Furthermore, using video of a flying frigatebird (Fregata ariel), we quantify the changes in the effective wing area throughout the wingbeat cycle, showing a ~19% variation that significantly impacts lift generation efficiency. These findings provide quantitative benchmarks for avian-inspired wing design and offer insights for optimizing flapping kinematics in bioinspired aerial systems, particularly for enhancing takeoff and landing capabilities in micro air vehicles. Full article

Ornithopters generate lift and thrust through periodic flapping-wing motion. While control-based optimization has been widely studied to improve the flight efficiency of ornithopters, passive mechanical tuning remains underexplored. This study investigates whether integrating a lightweight torsional spring can passively tune a flapping-wing system toward resonance to reduce input power and enhance aerodynamic performance. We evaluated springs of different stiffness on a 3D-printed, motor-driven flapping rig, recording input voltage and current as well as flapping frequency and thrust. Wing kinematics were analyzed using high-speed video, and free-oscillation tests identified a resonant period of ~0.14 s (~7.1 Hz). Experimental results show that an optimally tuned spring-assisted system achieves up to a threefold improvement in thrust efficiency and up to a twofold improvement in kinematic efficiency, compared to the no-spring baseline. Indoor flight tests using a commercial ornithopter (MetaFly) confirmed the improvement, showing a 12.8% increase in average endurance. The spring-assisted configuration also produced smoother stroke reversals, consistent with reduced energy losses. These results demonstrate that a low-complexity, lightweight torsional spring tuned near resonance can provide an effective passive means to enhance both energy efficiency and aerodynamic output in flapping-wing UAVs, serving as a practical, low-cost complement to control-based optimization methods. Full article

Airframe noise generated at wing trailing edges and high-lift devices, such as flaps, remains a major challenge during landing, with significant contributions in the low-frequency band of 500–1500 Hz. While solid surfaces reflect this acoustic energy, metallic porous materials can effectively absorb it through viscous and thermal dissipation within their internal pore structure. To address this, the present study examines the acoustic absorption characteristics of open-cell AlSi porous cylinders featuring controlled pore diameters between 0.3 mm and 2.25 mm. Measurements were conducted in an acoustic impedance tube according to the ISO 10534-2:2023 standard, using six cylindrical samples (28 mm diameter, 70 mm length). Two sets of measurements were performed for each sample (front and rear faces), and the average values were used. The findings indicate that the normal-incidence sound absorption coefficient α rises as pore size increases, reaching 0.93–0.97 at low frequencies of 500–700 Hz for the samples with the largest pores (1.8–2.25 mm). These results indicate that open-cell AlSi alloys offer strong low-frequencies sound absorption, positioning them as promising options for aeroacoustic noise mitigation, including applications such as porous trailing edge and hybrid flap designs. Full article

This paper investigates the flight kinematics and unsteady aerodynamics of butterfly flight using high-speed schlieren imaging. Butterfly trajectories are reconstructed to examine flight control mechanisms, with particular emphasis on thorax-driven manoeuvring and body reorientation. By reconstructing free-flight trajectories utilizing image recognition algorithms, we isolate the mechanisms of flight control, with particular emphasis on how thoracic oscillation drives manoeuvring and body reorientation. Phase-resolved analysis reveals distinct wingbeat modes, including clap-and-fling motions associated with hovering and low-speed ascent. Schlieren visualization further captures a detailed view of the wake topology, displaying the formation and evolution of wingtip vortices during the downstroke, as well as attached and entrained flow structures during cupped wing configurations. The results demonstrate the strong coupling between body dynamics, wing kinematics, and wake structure, highlighting how butterflies combine aerodynamic and inertial mechanisms to achieve efficient lift generation and control. These findings provide biomimetic insights relevant to the design of flapping wing micro air vehicles, particularly for low-speed flight, hover efficiency, and passive stability and control through body–wing coupling. Full article

Flapping-wing micro air vehicles (FWMAVs) have gained increasing attention due to their manoeuvrability, low acoustic signature, and suitability for confined or cluttered environments. Despite considerable progress, existing reviews treat actuation mechanisms and mechanical transmissions in isolation, leaving a gap in the comparative assessment of pulley-based and alternative flapping systems. This study provides a comprehensive and quantitative synthesis of the literature on FWMAV mechanical architectures, with particular emphasis on pulley-driven transmissions used in platforms such as the Nano Hummingbird and the Robotic Hummingbird. A structured review methodology was applied, incorporating a systematic database search, extraction of performance parameters, and cross-platform comparison of flapping frequency, lift generation, power consumption, lift-to-weight ratio, and material choices. The analysis identifies consistent scaling trends across motor-driven, piezoelectric, and hybrid actuation families and highlights the efficiency and stroke-amplification advantages of pulley-based mechanisms for centimetre-scale hovering MAVs. The review also identifies unresolved challenges, including durability of transmission materials, standardisation of performance metrics, and the need for high-fidelity aerodynamic characterisation. Overall, this work offers an integrated framework for understanding the trade-offs among actuation and transmission strategies and provides a roadmap to guide future research and the practical development of next-generation FWMAVs. Full article

Bio-inspired flow-sensing and actuation mechanisms offer a promising path for enhancing the stability of flapping-wing flying robots (FWFRs) operating in dynamic and noisy environments. This study introduces a bio-inspired sensing and actuation feather unit (SAFU) that mimics the covert feathers of falcons and serves simultaneously as a distributed flow sensor and an adaptive actuation element. Each electromechanical feather (EF) passively detects airflow disturbances through deflection and actively modulates its flaps through an embedded actuator, enabling real-time aerodynamic adaptation. A reduced-order bond-graph model capturing the coupled aero-electromechanical dynamics of the FWFR wing and SAFU is developed to provide a physics-based training environment for a proximal policy optimization (PPO) based reinforcement learning controller. Through closed-loop interaction with this environment, the PPO policy autonomously learns control actions that regulate feather displacement, reduce airflow-induced loads, and improve dynamic stability without predefined control laws. Simulation results show that the PPO-driven SAFU achieves fast, well-damped responses with rise times below 0.5 s, settling times under 1.4 s, near-zero steady-state error across varying gust conditions and up to 50% alleviation of airflow-induced disturbance effects. Overall, this work highlights the potential of bio-inspired sensing-actuation architectures, combined with reinforcement learning, to serve as a promising solution for future flapping-wing drone designs, enabling enhanced resilience, autonomous flow adaptation, and intelligent aerodynamic control during operations in gusts. Full article

Unmanned aerial vehicles (UAVs) and birds are typical low-altitude small targets in optical remote sensing, often occupying only a few pixels and exhibiting highly similar appearances, which limits the effectiveness of appearance-based discrimination at long distances and low resolutions. To overcome this, we propose a non-appearance-based classification framework using kinematic and time–frequency features. At the trajectory level, kinematic features—including the coefficient of variation of velocity and acceleration, the Spatiotemporal Box-counting Fractal Dimension (SBFD), and the Local Higuchi Fractal Dimension (LHFD)—quantify multi-scale trajectory complexity. At the scale-variation level, time–frequency features, specifically the Time-Frequency Aware Singular Value Entropy (TF-SVE) derived from bounding-box area sequences, capture non-stationary oscillations from bird wing flapping, reflecting behavioral differences from rigid UAV motion. Experiments on a complex real-world dataset show that stacking these features achieves 99.47% classification accuracy, demonstrating a robust, resolution-invariant, and practically effective approach for non-appearance-based recognition of low-altitude targets. Full article

To improve the pumping performance of biomimetic flapping-wing devices in small river channels, this study introduces high-frequency disturbances in the heave direction based on traditional pitch–heave motion. A systematic investigation of the forces and hydrodynamic performance is conducted using numerical simulations, with vortex contour analysis to explore the evolution mechanism of the wake vortex structure. The results show that high-frequency disturbances cause the instantaneous thrust to exhibit an amplitude modulation feature, with thrust oscillating approximately f_p/f_b times within one base frequency cycle. As the disturbance frequency increases, the average thrust also increases. There is a significant frequency-dependent difference in performance: at low disturbance frequencies (f_p/f_b ≤ 16), changes in thrust, pressure difference, and flow rate are limited, with little improvement in pumping efficiency; at intermediate frequencies (16 < f_p/f_b ≤ 32), wake coherence and jet momentum flux are significantly enhanced, and both thrust and pumping efficiency reach their maximum (up to 47%); at high disturbance frequencies (f_p/f_b > 32), although the vortex structure is further strengthened, input power increases sharply, leading to a decrease in efficiency. Overall, moderate disturbance frequencies can effectively enhance the thrust and pumping performance of the flapping wing, while excessively high frequencies do not offer an advantage due to the high energy cost. Full article

Inspired by the movements of sea turtle forelimbs, this study presents a bio-inspired underwater flapping wing with three degrees of freedom. This flapping wing mechanism can more accurately simulate the rotational motion of a sea turtle’s forelimbs to generate greater propulsive force. The highlight is the gear transmission mechanism arranged along the wingspan, enabling a preset increasing twist angle along the wingspan. Computational fluid dynamics simulations are conducted to evaluate the hydrodynamic performance of the proposed flapping wing system. The effects of different spanwise twist angles along the wingspan on thrust generation are quantitatively analyzed, as well as the influence of key kinematic parameters, including the longitudinal flapping angle, spanwise increasing twist angle, and elevation angle. The results indicate that, compared with a uniform twist angle, the spanwise increasing twist significantly increases the peak thrust during specific phases of the flapping cycle. It is further revealed by flow field analyses that the formation of vortices near the trailing edge enhances the propulsive force in the streamwise direction. To further validate the proposed concept, a prototype of the mechanism is fabricated and experimentally tested under low-frequency actuation, confirming the feasibility of the mechanical design. Overall, these results demonstrate the potential of the proposed approach for bio-inspired underwater propulsion and provide useful guidance for future flapping wing mechanisms and kinematic design. Full article

This paper investigates the rotational lift production of translating and rotating wings within a small insect’s Reynolds number range. Using the Reynolds number 1200 of a bumblebee, three wing section profiles were studied: a circular cylinder model as a reference for a blunt body for which the well-known Magnus effect will occur, a flat plate model as a reference for a sharp body for which the Kramer effect will occur, and finally, an elliptical cylinder model as a transition case. Direct force measurement and particle image velocimetry (PIV) experiments were performed to measure the lift produced and the surrounding flow velocity, and the Kutta–Joukowski theorem was applied to analyze the PIV results. The Kutta–Joukowski theorem gives the relationship between lift and circulation on a body moving at constant speed in a real fluid with some constant density. The experimental results were analyzed and verified by comparing them to the computational results. In general, there is reasonable agreement between the experimental and computational results, confirming that the Magnus effect is observed for the circular cylinder model and no Kramer effect is observed for the flat plate model. The elliptical cylinder model does not appear to be blunt enough for the Magnus effect to occur, and it is not sharp enough for the Kramer effect to occur. Full article

This study employed numerical simulations to investigate the aerodynamic characteristics of a flapping wing by solving the governing incompressible Navier–Stokes equations. Using computational fluid dynamics (CFD), the effect of frequency acceleration on the aerodynamic performance of a two-degrees-of-freedom (DoF) flapping wing in hovering was examined. The results indicate that the pitching frequency acceleration significantly influences the aerodynamic force: positive acceleration enhances lift by up to 2.0 times while maintaining propulsion compared to the case under negative acceleration. This mechanism is attributed to the delayed shedding of the leading-edge vortex (LEV) and the shedding of the trailing-edge vortex (TEV). Moreover, aerodynamic forces are also affected by plunge acceleration, with both negative and positive acceleration contributing to performance improvement. An increase in the acceleration coefficient leads to a notable enhancement in the aerodynamic force; however, the improvement becomes marginal when the coefficient n exceeds 0.4. The underlying flow evolution is illustrated and analyzed through pressure and vorticity contours. These findings on the acceleration effect will be applied to optimize the kinematics and design of flapping wing drones. Full article

The tailless flapping-wing micro aerial vehicle (FW-MAV) exhibits capabilities for hovering and agile six-degree-of-freedom flight, demonstrating potential for missions in complex environments such as forests and indoor spaces. However, limited payload and endurance restrict their practical application. This study presents a novel tailless FW-MAV named X-fly, incorporating a lightweight crank-rocker mechanism with high thrust-to-weight ratio. The optimized flapping-wing mechanism achieves a maximum single-side lift of 28.7 gf, with a lift-to-power ratio of 6.67 gf/W, outperforming conventional direct-drive propellers using the same motor. The X-fly employs servo-controlled stroke planes for tailless attitude stabilization and rapid disturbance recovery. It features a 36 cm wingspan and a net weight of 18.9 g (without battery). Using a commercially available 1100 mAh battery weighing 21.6 g, it demonstrates a peak lift-to-weight ratio of 1.42 at 3.8 V and achieves a maximum flight endurance of 33.2 min. When equipped with a 250 mAh battery weighing 5.5 g, it can carry an additional payload equal to its own net weight. The X-fly attains a maximum speed of 6 m/s and demonstrates high agility during forest flight. Furthermore, it successfully performs a simulated reconnaissance mission with an onboard camera, confirming its potential for practical applications. Full article

Space exploration is a major global focus, advancing knowledge and exploiting new resources beyond Earth. Bioinspired design—drawing principles from nature—offers systematic pathways to increase the capability and intelligence of space robots. Prior reviews have emphasized on-orbit manipulators or lunar rovers, while a comprehensive treatment across application domains has been limited. This review synthesizes bioinspired capability and intelligence for space exploration under varied environmental constraints. We highlight four domains: adhesion and grasping for on-orbit servicing; terrain-adaptive mobility on granular and rocky surfaces; exploration intelligence that couples animal-like sensing with decision strategies; and design methodologies for translating biological functions into robotic implementations. Representative applications include gecko-like dry adhesives for debris capture, beetle-inspired climbers for truss operations, sand-moving quadrupeds and mole-inspired burrowers for granular regolith access, and insect flapping-wing robots for flight under Martian conditions. By linking biological analogues to quantitative performance metrics, this review highlights how bioinspired strategies can significantly improve on-orbit inspection, planetary mobility, subsurface access, and autonomous decision-making. Framed by capability and intelligence, bioinspired approaches reveal how biological analogues translate into tangible performance gains for on-orbit inspection, servicing, and long-range planetary exploration. Full article
