Search Results (523)

This paper takes a small three-stage centrifugal pump as the research object. Based on the RNG k-ε turbulence model and the TFM two-phase flow model, the numerical simulation of the internal gas–liquid two-phase flow was carried out, and the influence of the inlet gas content rate of the small multistage centrifugal pump on its internal flow was analyzed. The research results show that the head and efficiency of the multistage centrifugal pump will decrease with the increase in the inlet gas content rate. As the gas content increases from 0% to 5%, the head of the multistage centrifugal pump decreases by 3% and its efficiency drops by 5%. The trend of the continuous increase in the pressure on the blade surface does not change with the increase in the inlet gas content rate. The bubble area on the surface of the first-stage impeller blade increases with the increase in the gas content rate. When the inlet gas content rate condition reaches 5%, the bubbles cover the middle section of the blade suction surface. The flow vortex structure is mainly composed of blade separation vortices and mouth ring clearance leakage vortices. The vortices inside the impeller are concentrated in the blade outlet and rim area, while the vortices inside the guide vanes are located in the flow channel area of the anti-guide vanes. With the increase in the gas content rate, the amplitude of pressure pulsation in the flow channel inside the pump decreases. Full article

Long-distance water conveyance systems require controlled filling after initial operation or maintenance. This process is complex and challenging to manage accurately. It involves transient two-phase flow with rapid velocity and pressure changes, which can risk pipeline damage. Studying the filling process is thus essential to ensure the safe and efficient operation of the system. Combining a specific engineering case, this work investigates gas–liquid two-phase flow in tunnel sections during filling. We employ a coupled Volume of Fluid (VOF) multiphase model and a Realizable k-ε turbulence model for our simulations. Hydraulic parameters (flow patterns, pressure, velocity) are analyzed using the results. Key findings indicate that higher filling flow rates destabilize the process. Gas retention behavior in low-pressure caverns varies, and gas–liquid eruptions occur at shaft water surfaces. Increased flow rates also intensify phase–pattern transitions, elevate peak pressure and velocity values, and amplify pressure pulsations and velocity fluctuations. Furthermore, faster gas transport in low-pressure caverns triggers flow instability, compromising exhaust efficiency. Full article

This study investigates self-pulsation phenomena in a liquid-centered swirl coaxial injector with a recess length of 4 mm, under varying liquid flow conditions, using numerical simulations. The simulations focused on analyzing spray patterns, pressure oscillations, and dominant frequency characteristics, and the results were compared with previous experimental data. Self-pulsation, observed at liquid flow rates of 60%, 90%, and 100% of nominal values, generated distinctive periodic oscillations in the spray pattern, forming “neck” and “shoulder” breakup structures that resemble a Christmas tree. Surface waves induced by Kelvin-Helmholtz and Rayleigh-Taylor instabilities were identified at the gas-liquid interface, contributing to enhanced atomization and reduced spray breakup length. FFT analysis of the pressure oscillations highlighted a match in trends between simulation and experimental data, although variations in dominant frequency magnitudes arose due to the absence of manifold space in simulations, confining oscillations and slightly elevating dominant frequencies. Regional analysis revealed that interactions between the high-speed gas and liquid film in the recess region drive self-pulsation, leading to amplified pressure oscillations throughout the injector’s internal regions, including the gas annular passage, tangential hole, and gas core. These findings provide insights into the internal flow dynamics of swirl coaxial injectors and inform design optimizations to control instabilities in liquid rocket engines. Full article

Large underwater vehicles, designed for multiple cruising speeds, are required to operate under diverse conditions such as full speed, surfacing, diving, and hovering. This demands that the axial flow pumps used in these applications have a broad operational range, typically functioning efficiently from 0.1 times rated flow to 1.5 times rated flow. In the process of adjusting operational conditions, axial flow pumps may experience rotating stall phenomena. Importantly, the presence of tip leakage vortices within the pump markedly influences the internal flow dynamics. To assess the impact of tip leakage vortices on the internal flow field under varied operational states, this study delves into the inherent link between tip leakage vortices and pressure pulsation across three specific scenarios: optimal, critical stall, and deep stall conditions. Analyzing from the perspective of the vorticity transport equation, it is found that the compression–expansion term dictates the core strength of tip leakage vortices, while the viscous dissipation factor determines the frequency of pressure pulsation. With an increase in the core strength of tip leakage vortices, a gradual rise in pressure pulsation is observed; in optimal scenarios, the core of tip leakage vortices progressively shifts toward the interior of the clearance, keeping the pulsation amplitude at each monitoring point within the blade tip clearance at integer multiples of the blade passing frequency. During critical stall and deep stall scenarios, the viscous dissipation effect of tip leakage vortices contributes to the emergence of high-frequency harmonic components within pressure pulsation. Full article

The multi-wing centrifugal fan is an important part of air conditioning systems, particularly in the automotive domain. Due to the compact structure and short blade passage of the fan, it may reduce the aerodynamic performance and generate noise. As a key part of the multi-wing centrifugal fan, the volute tongue has an important impact on the aerodynamic performance and noise of the multi-wing centrifugal fan. In this paper, the volute tongue of a multi-wing centrifugal fan is modified for air conditioning systems, and a novel gradient-radius volute tongue is designed. Specifically, a simulation calculation model for the multi-wing centrifugal fan is developed based on the Realizable k-ε turbulence model and the Ffowcs Williams–Hawkings (FW-H) equation. The simulation results are analyzed, and the reliability of the proposed method is assessed by comparing the total pressure efficiency and noise levels with the corresponding experimental measurements. Subsequently, the aerodynamic performance and noise characteristics of the gradient-radius volute tongue are investigated, with particular attention given to variations in the flow field, pressure pulsation, and noise before and after the modification. The results indicate that the gradient-radius volute tongue effectively attenuates the pressure pulsations arising from the interaction between the volute and the airflow, thereby reducing the tongue-region noise. Compared with the original fan, a noise reduction of 3.5 dB is achieved through the implementation of the gradient-radius volute tongue. Full article

Multistage pumps serve as the core power source for fluid transportation, and runaway conditions of multistage pumps as turbines (PATs) may lead to severe consequences. This study investigated the pressure pulsation, flow structure, and impeller transient characteristics of an 11-stage petrochemical pump under runaway conditions. Full-flow numerical simulations at varying speeds analyzed head, efficiency, and entropy production via the entropy diagnostic method. The results showed that total entropy production generally increases with rotational speed, while efficiency first rises then declines, peaking at 78.48% at 4000 r/min. Maximum/minimum pressure pulsation peaks consistently occur at identical stages, with dominant peak amplitudes overall increasing with speed. Pressure coefficient amplitudes decrease with frequency growth, with larger pulsation magnitudes observed at monitoring points closer to impeller outlets. Dominant pressure pulsation peaks exhibit upward trends with increasing rotational speed. Both the blade-passing frequency and its harmonics were detected at 5100 r/min, including the impeller inlet/outlet side and the region near the cutwater within the guide vanes. This study identified the critical threshold of 4800 r/min and pinpointed fatigue risk zones, providing a theoretical foundation for designing and manufacturing high-performing multistage PAT systems under runaway conditions. Full article

Hydraulic motors are increasingly pivotal in high-power drive systems for heavy-duty vehicles and industrial machinery due to their high power density. Radial piston hydraulic motors are commonly employed in heavy-load applications, while digital hydraulic motors have surfaced as a potential substitute for traditional hydraulic motors. Yet challenges such as torque pulsation and inefficient flow distribution persist in traditional designs. To improve performance and reliability, this paper proposed a digital radial piston hydraulic motor using several switching valves to distribute hydraulic oil, along with a comprehensive strategy to mitigate flow pulsation and enhance hydraulic transmission efficiency in digital hydraulic motors. The inherent torque pulsation characteristics are systematically investigated, revealing their dependence on valve actuation patterns and load dynamics. A novel torque pulsation mitigation design is introduced. Then, valve modeling and efficiency evaluation are developed; the phase-correction-based flow distribution method is conducted by optimizing valve sequencing; and simulations and experiments are carried out to demonstrate the feasibility. In conclusion, insights have been drawn to direct the design and control of radial piston digital hydraulic motors. This paper presents a potential solution for heavy-duty traction applications. Full article

During the installation and operation of Pelton turbines, deviations of the jet centerline from the runner pitch circle can compromise turbine stability and efficiency. Utilizing design data from a Pelton turbine on China’s Dadu River, this study employs the SST k-ω and VOF models to investigate the flow characteristics, pressure pulsations, and force on the bucket surface under varying offset conditions. The results demonstrate that radial offset causes the jet to enter the bucket later when deflected outward and earlier when deflected inward. All forms of offset exert adverse effects on turbine performance, with axial offsets causing more severe impacts than radial ones. The maximum pressure pulsation amplitude reached 24%. Afterwards, the erosion of Pelton turbines with different grain sizes was investigated by erosion modeling. It was found that the erosion of large grain size is more serious than that of small grain size. This research provides valuable theoretical insights and an important guiding role for improving the operational stability of Pelton turbines. Full article

This study investigates the leakage vortex influence on pressure pulsation characteristics within a vertical axial flow pump. Three impeller configurations with blade root clearance (δ) of 2.7–8.0 mm were designed to analyze geometric effects on internal flow dynamics. Unsteady RANS simulations predicted flow structures under multiple operating conditions (0.8–1.2Q_des). Fast Fourier Transform (FFT) extracted frequency–domain and time–frequency characteristics of pressure pulsations in critical flow regions. Key results reveal: (1) δ enlargement expands low-pressure zones within blade channels due to enhanced leakage vortices; (2) leading-edge pulsation shows 8.2–11.7% reduction in peak-to-peak amplitude and fundamental frequency magnitude with increasing δ; (3) trailing-edge response exhibits non-monotonic behavior, with maximum amplitude at δ = 5.0 mm (42.2% increase at design flow). These findings demonstrate that blade root clearance optimization requires condition-dependent thresholds to balance leakage management and pulsation control. Full article

Periphytic algae, as representative aquatic epiphytic communities, play a vital role in the material cycling and energy flow in rivers. Through physiological processes such as photosynthetic carbon fixation and nutrient absorption, they perform essential ecological functions in water self-purification, maintenance of primary productivity, and microhabitat formation. This study investigates the interaction mechanisms between these highly flexible organisms and the hydrodynamic environment, thereby addressing the limitations of traditional hydraulic theories developed for rigid vegetation. By incorporating the coupled effects of biological flexibility and water flow, an innovative nonlinear resistance model with velocity-dependent response is developed. Building upon this model, a coupled governing equation that integrates water flow dynamics, periphytic algae morphology, and layered Reynolds stress is formulated. An analytical solution for the vertical velocity distribution is subsequently derived using analytical methods. Through Particle Image Velocimetry (PIV) measurements conducted under varying flow velocity conditions in an experimental tank, followed by comprehensive error analysis, the accuracy and applicability of the model were verified. The results demonstrate strong agreement between predicted and measured values, with the coefficient of determination R² greater than 0.94, thereby highlighting the model’s predictive capacity in capturing flow velocity distributions influenced by periphytic algae. The findings provide theoretical support for advancing the understanding of ecological hydrodynamics and establish mechanical and theoretical foundations for river water environment management and vegetation restoration. Future research will build upon the established nonlinear resistance model to investigate the dynamic coupling mechanisms between multi-species periphytic algae communities and turbulence-induced pulsations, aiming to enhance the predictive modelling of biotic–hydrodynamic feedback processes in aquatic ecosystems. Full article

Centrifugal pumps as turbines (PATs) are key components in energy micro-grids, playing a significant role in energy conversion and storage. However, vibration and pressure pulsation occur during their operation, impacting the operational stability of the system. To investigate the complex relationship between PAT vibrations, pressure pulsations, and performance characteristics, specialized experiments were conducted in the precision laboratory of the National Research Centre of Pumps in Jiangsu University to gather the vibration data, pressure pulsations, and overall performance parameters of a PAT under varying operating conditions. The resulting data were then analyzed in both the time and frequency domains. The final results indicate that under both pump and turbine operating conditions, the vibration intensity increases with the increase in the flow rate. The vibration energy is predominantly concentrated at f_BEP (blade passing frequency) and its harmonics, while the pressure pulsation intensity is the most significant at f_n (the shaft frequency), f_BEP, and the latter’s harmonics. This study is highly significant for optimizing pump design, enhancing pump performance, and ensuring the safe and stable operation of PAT systems. Full article

Double-suction centrifugal pumps are extensively employed in industrial applications owing to their high efficiency, low vibration, superior cavitation resistance, and operational durability. This study analyzes how impeller oblique cutting angles (0°, 6°, 9°, 12°) affect a double-suction pump at a fixed 4% trimming ratio and constant average post-trim diameter. Numerical simulations and tests reveal that under low-flow (0.7Q_d) and design-flow conditions, the flat-cut (0°) minimizes reflux ratio and maximizes efficiency by aligning blade outlet flow with the mainstream. Increasing oblique cutting angles disrupts this alignment, elevating reflux and reducing efficiency. Conversely, at high flow (1.3Q_d), the 12° bevel optimizes outlet flow, achieving peak efficiency. Pressure pulsation at the volute tongue (P11) peaks at the blade-passing frequency, with amplitudes significantly higher for 9°/12° bevels than for 0°/6°. The flat-cut suppresses wake vortices and static–rotor interaction, but oblique cutting angle choice critically influences shaft-frequency pulsation. Entropy analysis identifies the volute as the primary loss source. Larger oblique cutting angles intensify wall effects, increasing total entropy; pump chamber losses rise most sharply due to worsened outlet velocity non-uniformity and turbulent dissipation. The flat-cut yields minimal entropy at Q_d. These findings provide a basis for tailoring impeller trimming to specific operational requirements. Furthermore, the systematic analysis provides critical guidance for impeller trimming strategies in other double-suction pumps and pumps as turbines in micro hydropower plants. Full article

The gap seal ring is a critical component in high-speed centrifugal pumps. The leakage rate and performance of the pump are sensitive to variation in seal ring parameters. This study investigates the influence of seal ring tooth profile on the leakage flow of pump chambers. Numerical simulation and experimental tests are used to analyze the impact of four different tooth-height labyrinth seal ring structures on the pressure pulsation characteristics of pump leakage chambers. It can be concluded that the use of labyrinth seal rings can significantly reduce the pressure pulsation and leakage rate of pump chambers. For the Case 2 structure with a tooth height of 0.18 mm, the pressure pulsation in the pump chamber can be reduced by a maximum of 22.5%, and the leakage rate can be reduced by 41.1%. For the Case 3 structure with a tooth height of 0.23 mm, the pressure pulsation in the pump chamber can be reduced by a maximum of 30.3%, and the leakage rate can be reduced by 40.6%. The use of labyrinth seal rings significantly reduces the pressure pulsation intensity of the impeller surfaces, which improves the force stability of the high-speed centrifugal pump impeller. This study is helpful in providing theoretical support for the design of labyrinth seal rings in high-speed centrifugal pumps. Full article

As a core component in renewable energy systems for grid regulation, hydropower units are increasingly exposed to flow conditions that elevate the risk of cavitation and erosion, posing significant challenges to the safe operation of flow-passage components. In this study, model testing and computational fluid dynamics (CFD) simulations are employed to investigate the hydraulic performance and cavitation behavior of a bulb turbine operating under rated head conditions and varying cavitation numbers. The analysis focuses on how changes in cavitation intensity affect flow characteristics and efficiency within the runner region. The results show that as the cavitation number approaches its critical value, the generation, growth, and collapse of vapor cavities increasingly disturb the main flow, causing a marked drop in blade hydraulic performance and overall turbine efficiency. Cavitation predominantly occurs on the blade’s suction side near the trailing edge rim and in the clearance zone near the hub, with bubble coverage expanding as the cavitation number decreases. A periodic inverse correlation between surface pressure and the cavitation area is observed, reflecting the strongly unsteady nature of cavitating flows. Furthermore, lower cavitation numbers lead to intensified pressure pulsations, aggravating flow unsteadiness and raising the risk of vibration. Full article

The transient operation of pump turbines generates significant flow-induced instabilities, prompting a comprehensive numerical investigation using the SST $k-\omega$ turbulence model to examine these instability effects throughout the complete operating range in turbine mode. This study specifically analyzes the evolutionary mechanisms of unsteady flow dynamics under ten characteristic off-design conditions while simultaneously characterizing the pressure fluctuation behavior within the vaneless space (VS). The results demonstrate that under both low-speed conditions and near-zero-discharge conditions, the VS and its adjacent flow domains exhibit pronounced flow instabilities with highly turbulent flow structures, while the pressure fluctuation amplitudes remain relatively small due to insufficient rotational speed or flow rate. Across the entire turbine operating range, the blade passing frequency (BPF) dominates the VS pressure fluctuation spectrum. Significant variations are observed in both low-frequency components (LFCs) and high-frequency, low-amplitude components (HF-LACs) with changing operating conditions. The HF-LACs exhibit relatively stable amplitudes but demonstrate significant variation in the frequency spectrum distribution across different operating conditions, with notably broader frequency dispersion under runaway conditions and adjacent operating points. The LFCs demonstrate significantly higher spectral density and amplitude magnitudes under high-speed, low-discharge operating conditions while exhibiting markedly reduced occurrence and diminished amplitudes in the low-speed, high-flow regime. This systematic investigation provides fundamental insights into the flow physics governing pump-turbine performance under off-design conditions while offering practical implications for optimizing transient operational control methodologies in hydroelectric energy storage systems. Full article
