Hyper-spectral imaging (HSI) systems can be divided into two main types as follows: a group of systems that includes a dedicated dispersion/filtering component whose role is to physically separate the different wavelengths and a group of systems that sample all wavelengths in parallel, so that the separation into wavelengths is performed by signal processing (interferometric method). There is a significant advantage to systems of the second type in terms of the integration time required to obtain a signal with a high signal-to-noise ratio since the signal-to-noise ratio of methods based on scanning interferometry (Windowing method) is better compared to methods based on dispersion. The current research deals with the feasibility study of a new concept for an HSI system that is based on scanning interferometry using the “push-broom” method. In this study, we investigated the viability of incorporating a simple birefringent plate into a scanning optical system. By exploiting the motion of the platform on which the system is mounted, we extracted the spectral information of the scanned region. This approach combines the benefits of scanning interferometry with the simplicity of the setup. According to the theory, a chirped cosine-shaped interferogram is obtained for each wavelength due to the nonlinear behavior of the optical path difference of light in the birefringent plate as a function of the angle. An algorithm converts the signal from a superposition of chirped cosine signals to a scaled interferogram such that Fourier transforming (FT) the interferogram retrieves the spectral information. This innovative idea can turn a simple monochrome camera into a hyperspectral camera by adding a relief lens and a birefringent plate. Full article

The current paper recovers dispersive optical solitons in birefringent fibers that are modeled by the Schrödinger–Hirota equation with differential group delay and white noise. Itô Calculus conducts the preliminary analysis. The $\left(G^{\prime }/G\right)$-expansion approach and the enhanced Kudryashov’s scheme gave way to a wide spectrum of soliton solutions with the white noise component reflected in the phase of the soliton. Full article

The pollucite structure is considered as a candidate ceramic crystalline matrix for the ceramic immobilization and long-term storage of ¹³⁵Cs and ¹³⁷Cs fission products, and thus, their structural characteristics have particular importance. However, its local structure has not been fully resolved from reciprocal-space techniques and infrared spectroscopy, and important discrepancies exist in the available literature. Two birefringent and non-stoichiometric pollucite specimens from Tanco pegmatite (Cs_0.83Na_0.20Al_1.13Si_2.56O₆) and from Mt. Mica pegmatite (Cs_0.94Na₀₁₈Al_1.23Si_2.78O₆), with powder X-ray diffraction patterns fully consistent with the cubic Ia-3d space-group symmetry, and with a very different degree of hydrothermal alteration, were used in this work. High-resolution magic-angle spinning multinuclear magnetic resonance (MAS NMR) spectroscopy, including ²⁹Si, ²⁷Al, ²³Na, ¹³³Cs, and ¹H spectra at 9.4 T, as well as ¹H, ²⁷Al, ²⁷Al{¹H} dipolar evolutions and ²⁷Al{²⁹Si} Heteronuclear Multiple Quantum Coherence (HMCQ) spectra at 17.6 T, has been used to investigate the local structure of pollucite and the role of protons. The ²⁹Si spectra suggest a local structure with a disordered Si/Al distribution in only one tetrahedral T site, but with a preference of Si atoms for Q⁴₁ (3Si,1Al) and Q⁴₂ (2Si,2Al) environments, in comparison with random and Loewenstein distributions, due to charge dispersion effects. However, the ²⁷Al{¹H} dipolar evolutions suggest two spectroscopically distinct T sites for Al atoms. The ²³Na and ¹³³Cs spectra indicate broad site distributions for these cavity cations. The anisotropic character of the long-range disordered pollucite structure, with a pseudo-cubic symmetry and lack of strict periodicity, can be explained from an incipient displacive transition to lower symmetry. These pollucite specimens are essentially anhydrous minerals despite the ¹H and the cross-polarization experiments suggesting that some protons exist in the structure as -OH groups, whereas water molecules were only found in relation to the phyllosilicate impurities from alteration in specimen Tanco and perhaps also as liquid water in fluid inclusions. Full article

This study aims to update the existing SG PW laser system and improve the temporal contrast and shape fidelity of a compressed pulse with a 150 fs level for multi-PW (5–10 PW). The design of third-order dispersion (TOD) compensation via a birefringent crystal was studied through numerical simulations and experiments. The dispersions introduced by the birefringent crystal were calculated using the Jones matrix element by changing the in-plane rotation angle ϕ, thickness d, incident angle θ, and temperature T, while also considering the transmission spectral bandwidth. The group-velocity dispersion (GVD), TOD, and fourth-order dispersion (FOD) of the existing SG PW laser system and its influence on the compressed pulse with different pulse durations were analyzed. The results suggest that a TOD of $1.3\times {10}^6$ fs³ needs to compensate for the multi-PW design. The compensation scheme is designed using a quartz crystal of d = 6.5 mm, θ = 90$°$, ϕ = 17$°$, and T = 21 °C, corresponding to the thickness, inclination angle, in-plane rotation angle, and temperature, respectively. Furthermore, we show a principle-proof experiment offline and measure the GVD and TOD by the Wizzler, which is based on theoretical simulations. These results can be applied to independently and continuously control the TOD of short-pulse laser systems. Full article

A method which utilizes a Kerr phase-interrogator to measure the group birefringence dispersion (GBD) of a polarization-maintaining fiber (PMF) is systematically studied in this paper. The differential group delay of two sinusoidally modulated optical signals (SMOSs) polarized along the principal axes of the PMF is measured by a Kerr phase-interrogator, which leads to the group birefringence of the PMF. As the laser wavelength of the SMOSs varies, the group birefringence as a function of the laser wavelength is obtained, and the GBD is calculated as the derivative of the group birefringence with respect to the laser wavelength. The proposed method is experimentally demonstrated by characterizations of a Panda PMF with high GBD and an elliptical core PMF with low GBD, and its performance is analyzed. The proposed method eliminates the impact of the laser coherent length and allows for characterizing the GBD of PMFs that are tens of kilometers long. Full article

This paper describes the synthesis and characterization of new “T-type” azo poly(amide imide)s as well as guest-host systems based on the “T-type” matrices. The matrices possessed pyridine rings in a main-chain and azobenzene moieties located either between the amide or imide groups. The non-covalent polymers contained the molecularly dispersed 4-phenylazophenol or 4-[(4-methyl phenyl)diazinyl]phenol chromophores that are capable of forming intermolecular hydrogen bonds with the pyridine rings. The FTIR spectroscopy and the measurements of the thermal, optical and photoinduced optical birefringence were employed for the determination of the influence of H-bonds and the specific elements of polymer architecture on physicochemical properties. Moreover, the obtained results were compared to those described in our previous works to formulate structure-property relations that may be considered general for the class of “T-type” azo poly(amide imide)s. Full article

Silicon nitride photonics is on the rise owing to the broadband nature of the material, allowing applications of biophotonics, tele/datacom, optical signal processing and sensing, from visible, through near to mid-infrared wavelengths. In this paper, a review of the state of the art of silicon nitride strip waveguide platforms is provided, alongside the experimental results on the development of a versatile 300 nm guiding film height silicon nitride platform. Full article

We experimentally characterized a birefringent side-hole microstructured fiber in the visible wavelength region. The spectral dependence of the group and phase modal birefringence was measured using the methods of spectral interferometry. The phase modal birefringence of the investigated fiber increases with wavelength, but its positive sign is opposite to the sign of the group modal birefringence. We also measured the sensing characteristics of the fiber using a method of tandem spectral interferometry. Spectral interferograms corresponding to different values of a physical parameter were processed to retrieve the spectral phase functions and to determine the spectral dependence of polarimetric sensitivity to strain, temperature and hydrostatic pressure. A negative sign of the polarimetric sensitivity was deduced from the simulation results utilizing the known modal birefringence dispersion of the fiber. Our experimental results show that the investigated fiber has a very high polarimetric sensitivity to hydrostatic pressure, reaching –200 rad x MPa^–1 x m^–1 at 750 nm. Full article

Orientation birefringence and its wavelength dispersion are studied for hot-drawn films of cellulose esters such as cellulose triacetate (CTA), cellulose diacetate (CDA), and cellulose acetate propionate (CAP) exposed to three different humidities of environments. Hot-drawn CTA films show negative birefringence that decreases with increasing wavelength. On the other hand, CDA and CAP films show positive birefringence that increases with increasing wavelength, i.e., the so-called extraordinary wavelength dispersion of birefringence. Upon exposure to high humidity environment, the orientation birefringence of CDA and CAP decreases. The decrease is prominent for the samples containing a large amount of water. CTA, however, shows an increase in magnitude of its negative orientation birefringence with increasing moisture content. The results can be explained by the increase of the polarizability anisotropy perpendicular to the stretching direction in the cellulose esters. It is found from ATR-FTIR measurements that hydrogen bonds are formed between carbonyl groups of cellulose esters and water molecules. Considering that orientation birefringence of cellulose esters is determined mainly by ester groups, the formation of hydrogen bonds contributes to the polarizability anisotropy, thus affecting the orientation birefringence. Full article
