Compared to antennas bearing a single port, MIMO antennas with several ports enable higher data throughput by exploiting spatial diversity. This capability is essential for next-generation implantable medical devices, where high channel capacity is a key requirement. A quad-element implantable MIMO antenna is designed and practically validated at 1420 MHz in this paper. It occupies a compact volume of $7\times 8\times 0.1 {\mathrm{mm}}^3$ ($5.6 {\mathrm{mm}}^3$). The compactness is realized by combining high-permittivity substrate (Rogers 3010 with relative permittivity of 10.2) with meandered radiator paths, which increase the effective current length while maintaining a small physical size. All antennas have very small mutual coupling with isolation of more than $31.78$ dB, which is mainly due to the spacing of 1 mm between the elements and the substrate, which is thin. The peak realized gain for each antenna element is $-27.3$ dBi. The simulation is performed within a capsule-like structure, which is embedded in the stomach tissue model. The experimental verification is carried out by embedding antenna within minced meat. The ECC, channel capacity, and link margin are also evaluated and found to be satisfactory. The proposed antenna ensures reliable communication performance, with the transmission range being as high as $2.5$ m, link margin being 15 dB, and the data rate being 120 Mb/s. The proposed antenna ensures a good level of ECC, which is less than $0.1$. The SAR is $52.3$ W/kg at 1420 MHz. This design is favorable for implants because of the small size, good impedance matching, high isolation, low correlation, good level of gain, and good link performance. Full article

This paper presents two broadband four-way power dividers based on a novel T-coil topology, operating in the 22–32 GHz band (covering the K/Ka bands). Type I adopts a cascaded power division structure, while Type II employs a direct-feed integrated architecture. The innovation lies in the introduction of isolating capacitors at the input and output ports, which significantly shortens the critical transmission line lengths in both topologies. This effectively reduces the equivalent inductance and raises the self-resonant frequency, achieving wideband response while maintaining structural simplicity, compact size, and ease of integration. Both circuits were fabricated using a standard 45 nm CMOS process. The measured core chip areas (excluding pads) are only 0.125 mm² for Type I and 0.066 mm² for Type II, demonstrating excellent integration density. Through even-mode and odd-mode theoretical analysis and full-wave electromagnetic simulation verification, both power dividers exhibit good impedance matching and port isolation across the target frequency band. Measurement results further confirm their performance: across the entire 22–32 GHz band, both power dividers achieve a return loss better than 11 dB and isolation exceeding 15 dB; the insertion loss is 1.1–1.4 dB for Type I and 0.8–1.3 dB for Type II; the amplitude imbalance is below ±0.3 dB and ±0.1 dB, respectively; and the phase imbalance is less than ±5° and ±3°, respectively. All measured data show good agreement with simulation results. In summary, Type I offers advantages in layout flexibility and isolation performance, while Type II excels in insertion loss and chip size. Both provide practical circuit solutions for broadband, high-performance, and compact power division systems. Full article

In this article, a new approach to the applicability of the self-complementarity concept in a classical two-port microstrip patch antenna element is presented. This was accomplished through an illustrative design and an electromagnetic analysis of a broadband two-port rectangular printed radiating element in transmission configuration. A calculated ultra-wide matching bandwidth up to approximately 11 GHz was achieved (BW_{sim-RL≥10 dB} ≈ 11 GHz, f_o = 5.5 GHz, i.e., BW_{sim-relative-matching} ≈ 200%). One of the advantages of this topology is that only two degrees of freedom are needed to acquire a very wide impe-dance bandwidth: the length and the width of the slot. Full-wave analysis shows that sui-table combinations of the patch and slot dimensions allow to obtain the broadband mat-ching behavior. It has broadside radiation toward both hemispheres, which is conserved and considerably stable over a wide frequency range. Its linear polarization, radiation patterns, gain values, and radiation efficiency are adequate from 1 to 8 GHz (BW_{sim-radiation} ≈ 7 GHz, f_{o [sim-rad]} = 4.5 GHz, i.e., 63.6% of its BW_sim-matching, and 156% of its f_{o [sim-rad]}). Moreover, the gain and radiation efficiency exhibit very good flatness across wide frequency ranges. Measurements of S-parameters and radiation patterns validate the calculated results. The proposed antenna element is simple, compact, and light-weight. It has a very wide ope-ration bandwidth (7 GHz), its design is easy and flexible, and it is simple to manufacture. It could be used as a radiating element in different linear polarized antenna arrays. Full article

To meet the increasingly strict requirements of modern communication, radar detection and electronic measurement systems for wide-bandwidth, low-insertion-loss and high-isolation signal routing, this paper presents a 16 × 16 programmable switch matrix that simultaneously achieves wideband operation (DC-40 GHz), low insertion loss (≤0.9 dB maximum), high isolation (>50 dB typical), and systematic modular scalability, a combination not found in existing implementations. The matrix, constructed with high-quality coaxial switches and optimized RF circuitry and electromagnetic structures, provides flexible and stable single-pole multi-throw (SPMT) signal routing across an ultra-wide frequency range from DC to 40 GHz. The switch matrix features a modular architecture, integrating multiple RF switching units, drive control circuits, and communication interface modules. This architecture achieves minimal signal path depth while maintaining full connectivity between any input and output port, directly minimizing cumulative insertion loss. Through precise impedance matching design and isolation structure optimization, the system still exhibits outstanding transmission characteristics at the 40 GHz high-frequency end: typical insertion loss does not exceed 0.9 dB, and the isolation between channels is better than 50 dB, effectively ensuring the integrity of signals in complex multi-channel environments. To meet the requirements of automated testing and remote control, the equipment integrates dual communication interfaces (serial port/network port), supports the SCPI command set and TCP/IP protocol, and can be conveniently embedded in various test platforms to achieve instrument interconnection and test process automation. Experimental verification shows that this matrix exhibits excellent switching stability and signal consistency across the entire 40 GHz, with a switching action time of less than 10 ms. Furthermore, it is capable of real-time topology reconfiguration via a microcontroller or FPGA. These innovations collectively deliver a switch matrix that meets the demanding requirements of 5G communication, millimeter-wave radar, and aerospace defense systems—applications where bandwidth, signal integrity, and system flexibility are paramount. Full article

The failure of impedance matching between the ultrasonic power supply and the transducer can degrade machining quality, decrease machining efficiency, and reduce tool life. To enhance the detection efficiency of impedance matching status in ultrasonic machining systems, an impedance matching detection method based on the Voltage Standing Wave Ratio (VSWR) is proposed. First, by constructing a fitting model for the forward and reverse voltage and power of ultrasonic power supply, the relationship between VSWR and voltage is determined. Subsequently, a correlation model between the VSWR and tool tip amplitude, which reflects the working state of the ultrasonic system, is established. And the range of VSWR for optimal performance of system impedance matching is obtained by means of the model. Finally, the detection effectiveness of this method is verified through experiments on tool tip output amplitude under varying working conditions, and a comparison is made between this method and the phase method. The results indicate that using VSWR as a detection parameter to characterize impedance matching yields measurement values within 7% of the theoretical values. These results confirm the evaluation interval for a good working state of the system. Furthermore, experiments under varying force loads and temperatures demonstrate the reliability of the VSWR-based characterization. Compared to the traditional phase method, this approach reduces the cost of impedance matching performance detection and meets the requirements for impedance matching status detection during ultrasonic machining. Full article

Early fault vibration signals from rolling bearings are typically nonlinear, non-stationary, and heavily obscured by background noise, which severely impedes the accurate extraction of fault features. To overcome the limitations of traditional stochastic resonance (SR)—specifically the small-parameter restriction for high-frequency signals and the subjectivity in parameter selection—this paper proposes an adaptive SR envelope spectroscopy method based on particle swarm optimization (PSO) and local mean decomposition (LMD). First, a variable-scale transformation is introduced to compress the high-frequency fault signals into the effective frequency band required by the adiabatic approximation theory. Second, utilizing the global search capability of PSO, the potential well parameters of the bistable system are adaptively optimized by maximizing the output signal-to-noise ratio (SNR), thereby achieving optimal matching between the nonlinear system and the input signal. Finally, the enhanced signal is decomposed by LMD, and the sensitive components are selected for envelope spectrum analysis to identify fault characteristics. Experimental validation using the Case Western Reserve University bearing dataset demonstrates that the proposed method effectively amplifies weak fault signals under strong noise conditions, exhibiting superior feature extraction accuracy and noise robustness compared to traditional methods. Full article

The design, fabrication, and characterization of a highly transparent and flexible monopole antenna optimized for the 3–6 GHz frequency band are presented in this study. In traditional Transparent Conductive Oxide (TCO) designs, there is always a trade-off between RF efficiency and optical transparency. Therefore, an Aerosol Jet^® 5X system was used to directly print a silver nanoparticle mesh onto a 50 μm colorless polyimide (PI) substrate. Using this fabrication method, a durable structure was obtained that exhibits reliable electrical and mechanical performance, achieving 85% optical transmittance in the visible spectrum and a gain of −2.5 dBi. To evaluate the flexibility and compatibility of the antenna, it was bent over a cylindrical surface and integrated with a commercial solar panel in both simulation and experimental environments. The results demonstrate that the impedance matching and radiation characteristics remain stable under bending conditions, with no critical decrease observed in solar energy harvesting. Consequently, this design has strong potential as a solution for energy-autonomous Internet of Things systems, smart windows, and CubeSat applications. Full article

This study evaluates the application of deep learning techniques to the design of a microwave transmitter–receiver system operating in the 5G mid-band. The proposed architecture consists of four stages—signal generation, amplification, mixing, and filtering—each initially designed using conventional microwave methods and subsequently integrated into a complete transceiver. Simulation data were generated and component-specific convolutional neural networks (CNNs) were implemented in Python using TensorFlow/Keras. Across all models, an average error reduction exceeding 90% was achieved, with most networks converging after the third training cycle. System-level integration shows that the baseline design achieved a transmitted power of −32.637 dBm and a gain of 1.116 dB, while the deep learning-based design yielded −33.912 dBm and 0.738 dB. Additional analysis of S-parameters confirms acceptable impedance matching and a frequency response of around 3.5 GHz. These results illustrate that deep learning provides an effective complementary methodology for multi-component microwave system modeling and optimization in 5G applications. Full article

A dual-band flexible wearable MIMO antenna with two operating modes, namely low-frequency narrowband and high-frequency broadband, is proposed and investigated in this paper. The antenna is based on a polyimide (PI) flexible printed circuit (FPC) substrate and has a compact size (90 mm × 40 mm × 0.1 mm), enabling easy integration into helmet-mounted devices. The antenna elements are fed by a coplanar waveguide (CPW) and integrated with a ground decoupling structure, achieving an isolation of at least 23.4 dB between the two ports across the entire operating frequency band. In addition, the impedance-matching characteristics of the antenna under bending conditions and the Specific Absorption Rate (SAR) of this MIMO antenna in a 1 g human-tissue model at 3.7 GHz and 4.6 GHz were evaluated. The results indicate that the antenna’s key electromagnetic performance remains relatively stable under bending conditions, and the SAR values comply with international limit requirements, verifying its feasibility for application in head-worn terminals. With an impedance bandwidth of −10 dB, this antenna achieves dual-band coverage at 3.42–3.84 GHz (relative bandwidth of 11.6%) and 4.37–7.80 GHz (relative bandwidth of 56.4%), effectively meeting the requirements of 5G/6G communication frequency bands. Full article

Flexible wearable electronics have shown strong potential for medical and health monitoring; however, conventional materials often fail to simultaneously satisfy the requirements of signal stability, wear comfort, and environmental adaptability under dynamic use conditions. To address this issue, this study proposes a data-driven material selection framework for flexible wearable sensors based on the extreme gradient boosting (XGBoost) algorithm. The model integrates user perception, material physical parameters, and environmental coupling performance indicators to enable intelligent material matching and recommendation. Experimental results show that the proposed model achieves a recommendation accuracy of 94.5%, outperforming conventional comparison methods. Among the candidate materials, silver nanowires (AgNWs) exhibit superior overall performance, including a higher signal-to-noise ratio, lower skin-contact impedance, and stronger sweat resistance. In physiological monitoring experiments, the maximum deviation of the sensor response was below 3% under both static and motion conditions. In environmental coupling tests, the recommended material improved the system signal-to-noise ratio by 68% and reduced 24-h sensitivity decay by 75%. These results indicate that the proposed XGBoost-based framework can effectively support material selection for flexible wearable sensors and improve signal reliability and environmental adaptability in complex application scenarios. Full article

The translation of nucleic acid amplification into practical point-of-care and biosensor-integrated diagnostics is still significantly impeded by the necessity for rapid sample preparation. For this reason, a broad comparison of seven commercially available kits for DNA/RNA extraction containing their temperature-related adjustments was performed. Extracts isolated from SARS-CoV-2-positive nasopharyngeal swabs, viral stocks, as well as laboratory-prepared suspensions of clinically relevant Gram-positive and Gram-negative bacteria were evaluated by recombinase polymerase amplification (RPA) and real-time PCR. In addition, the impact of transport media for SARS-CoV-2 samples was investigated. Extraction performance varied markedly according to the kit, pathogen, sample background. For SARS-CoV-2, rapid extraction was more effective for samples collected in viral transport medium than in inactivation buffer. Across bacterial targets, performance was species dependent, highlighting substantial differences in compatibility between simplified extraction workflows and downstream amplification. Among the rapid methods tested, a simplified QuickExtract protocol (95 °C, 5 min) provided the most consistent overall results, although it did not uniformly match the reference silica-based method for all targets. In conclusion, these results demonstrate that rapid nucleic acid extraction must be thoroughly evaluated as an essential element of the entire sample-to-answer workflow, rather than being chosen as a standalone preprocessing step for point-of-care molecular diagnostics. Full article

In this work, a flexible and sustainable radar-absorbing material (RAM) based on porous carbon derived from raw Kraft black liquor was developed. The porous carbon filler was synthesized through a simple, eco-friendly one-pot polymerization route, thereby avoiding lignin extraction, purification, and chemical activation steps. Macroporosity was introduced by using poly(methyl methacrylate) microspheres as a hard template, yielding a lightweight carbon material with a foam-like morphology, low density, and high porosity. The carbon filler was incorporated into a silicone rubber matrix at different loadings (5–25 wt.%) to produce flexible composites. The structural, morphological, and textural properties of porous carbon were investigated by SEM, EDX, Raman spectroscopy, nitrogen adsorption, and mercury porosimetry. The electromagnetic properties of composites were measured in the X-band (8.2–12.4 GHz) using a vector network analyzer. The mechanical behavior was evaluated through Young’s modulus. The results show that increasing filler content enhances dielectric losses and attenuation capability. Among all composites, the sample containing 20 wt.% of porous carbon exhibited the best electromagnetic performance, achieving a reflection loss of −42.3 dB at 10.97 GHz with a thickness of 2.43 mm, corresponding to an absorption efficiency of 99.99%. This performance is attributed to a favorable combination of impedance matching and quarter-wavelength cancellation effects. The developed sustainable, lightweight, and flexible composites demonstrate potential as low-cost RAM for aerospace and electromagnetic interference mitigation applications. Full article

One of the strongest electromagnetic engineering approaches for enhancing antenna performance is the use of photonic crystal (PhC) substrates. This technique can be efficiently applied to antenna design and offers notable advantages, such as gain improvement, increased bandwidth, and frequency-dependent beam scanning. In this paper, a bow-tie dipole antenna has been developed for terahertz operation over the 0.39–1.3 THz band, presenting a novel structure capable of producing strong ultra-wideband (UWB) field enhancement within its feed gap. The feed gap between the two metallic arms has a slot width of 1.24 λ0 (λ0 is the wavelength in free space at a center range of 0.8 THz), which facilitates the generation of an enhanced electric field. The PhC substrate enables surface-wave control through dispersion engineering, thereby enhancing the radiation efficiency of the antenna. The proposed antenna exhibits a radiation efficiency of approximately 73–93% over the entire UWB frequency band. Furthermore, the PhC substrate antenna achieves a maximum gain of 21 dB, exceeding that of a homogeneous-substrate THz bow-tie antenna by at least 3.3 dB. The results indicate that the antenna achieves |S₁₁| < −10 dB impedance matching over the bandwidth of 105.9%, ranging from 0.4 to 1.3 THz. The proposed bow-tie dipole antenna integrated with a PhC substrate demonstrates a wide beam-scanning capability from −54° to +74° across the 0.39–1.16 THz band, while maintaining a compact footprint of 14.9 λ₀ × 22.4 λ₀. This combination of wide scanning, broad bandwidth, and ultra-low profile represents a notable advancement in the development of compact THz radiating structures. Full article

Crop fungal and viral diseases cause annual economic losses exceeding USD 150 billion globally, demanding rapid, sensitive, and field-deployable diagnostic technologies. This review critically evaluates recent advances in electrochemical biosensing platforms for early crop pathogen detection, focusing on immunosensors, genosensors, aptasensors, and VOC-based systems. Reported analytical performances demonstrate ultralow detection capabilities, including 0.3 fg mL⁻¹ for viral coat proteins, 15 DNA copies for bacterial pathogens, 0.5 fg µL⁻¹ RNA detection for viroids, and nanomolar-level VOC sensing (35–62 nM), with response times ranging from 2 to 60 min. Comparative analysis reveals that genosensors and aptasensors generally achieve the lowest LODs due to nucleic acid amplification or high-affinity recognition, while immunosensors provide robust protein-level specificity validated against ELISA. Volatile organic compound (VOC) sensors enable non-invasive, pre-symptomatic monitoring but face specificity challenges. Despite strong laboratory performance, practical adoption is limited by matrix-derived electrochemical interference, environmental instability of biorecognition elements, workflow complexity, and insufficient standardization across studies. Emerging innovations, including magnetic bead enrichment, nanoporous and graphene-based electrodes, microfluidic integration, AI-assisted impedance interpretation, and biodegradable substrates, are progressively addressing these bottlenecks. This review emphasizes that successful field translation requires holistic workflow engineering, matrix-matched validation, and harmonized performance metrics rather than incremental sensitivity improvements alone. By integrating analytical chemistry, nanomaterials engineering, and agricultural decision-support frameworks, electrochemical biosensing platforms hold significant potential to enable decentralized, rapid, and sustainable crop disease management. Full article

The design and implementation of a dynamic frequency sweeping algorithm for a 3 kW RF power source are underpinned by theoretical principles aimed at optimizing impedance matching under pulse-mode operation. The algorithm dynamically adjusts the output frequency within a predefined range to align the source impedance Z_source with the conjugate of the load impedance Z*_load, maximizing the power transfer efficiency and minimizing the reflection coefficient Γ. This is achieved by leveraging the maximum power transfer theorem and adapting to dynamic load variations, such as those induced by the plasma state transitions. The algorithm incorporates adaptive step size adjustments based on the rate of change of Γ, predictive frequency initialization using historical data, and real-time impedance monitoring to ensure efficient convergence within the constrained pulse “ON” time (TON). Integration with pulse mode requires synchronization with the pulse signal, fast convergence, and optimized search strategies. Experimental validation on a 13.56 MHz, 3 kW Automatic Sweep Generator testbed operating at 20 kHz pulse modulation with a 50% duty cycle demonstrates a linear and stable sweep, achieving impedance matching and low reflected power within 5.0172 ms. These findings highlight the algorithm’s potential for high-precision applications, such as RF plasma excitation, and underscore the importance of adaptive techniques in dynamic RF systems. Full article
