The transition toward a renewable-based energy structure has significantly accelerated the advancement of energy storage technologies. Compressed air energy storage (CAES) is regarded as a highly promising long-duration energy storage solution due to the advantages of its large scale and long service life. However, the efficiency of conventional compressed air energy storage (CAES) systems remains limited due to the inadequate utilization of thermal energy. Isothermal compressed CAES (ICAES) technology, based on liquid pistons, can overcome the efficiency bottleneck by enabling temperature control during air compression. However, the operation of liquid pistons under high-pressure storage conditions remains a challenge because of the high compression ratio. To enhance the utilization rate of the two-stage liquid piston unit by using the synchronous operations of compression and discharge processes, this paper proposes a coordinated operation scheme. Then, a multi-stage ICAES system under constant-pressure air storage is proposed. Mathematical models and energy efficiency analysis methods of the multi-stage ICAES system are also established. Finally, the operational characteristics are analyzed in combination with the ICAES at 200 kWh. The results show that the proposed system can achieve an overall efficiency of 68.0%, under 85% and 90% efficiencies for low-pressure and linear equipment, respectively. The coordinated operation of the two-stage liquid piston unit can be further extended to multi-stage operations, demonstrating broad application prospects in ICAES systems. Full article

Compressed air energy storage (CAES) systems represent a critical technological solution for addressing power grid load fluctuations by generating electrical power during peak load periods and storing energy during low load periods. As a prominent branch of CAES, isothermal compressed air energy storage (ICAES) systems have attracted significant research attention due to their elimination of requirements for high-temperature storage chambers and high-temperature compressors. Implementing constant-pressure operation in air storage reservoirs not only enhances energy storage density but also improves system safety. However, existing constant-pressure air storage methodologies necessitate supplementary infrastructure, such as high-pressure water reservoirs or elevated hydraulic columns, thereby escalating capital expenditures. This study introduces a novel constant-pressure air storage strategy for ICAES systems utilizing a linear-driven liquid piston mechanism. The proposed approach achieves constant-pressure air storage through the dual-mode operation strategies of buffer tanks (CBA and CBP modes) and hydraulic cylinders (CPP and CPW modes), eliminating the requirement for an auxiliary high-pressure apparatus or extensive civil engineering modifications. A prototype two-stage constant-pressure ICAES architecture was proposed, integrating low-pressure equipment with liquid pistons and providing detailed operational processes for preconditioning, energy storage, and power generation. A comprehensive mathematical model of the system is developed and validated through process simulation and performance characterization of a 100 kWh capacity system. It demonstrates that under operational conditions of 1 MPa of low pressure and 5 MPa of storage pressure, the system achieves an efficiency of 74.0% when the low-pressure equipment and liquid piston exhibit efficiencies of 85% and 90%, respectively. Furthermore, parametric analysis reveals a negative correlation between system efficiency and low-pressure parameters. Full article

The potential energy of compressed air represents a multi-application source of power. Historically employed to drive certain manufacturing or transportation systems, it became a source of vehicle propulsion in the late 19th century. During the second half of the 20th century, significant efforts were directed towards harnessing pressurized air for the storage of electrical energy. Today’s systems, which are based on storing the air at a high pressure, are usually recognized as compressed air energy storage (CAES) installations. This paper aims to provide an overview of different technologies that take advantage of the energy accumulated in the compressed air. Particular attention is paid to the CAES installations that are working as electrical energy storage systems (EESs). These systems, developed originally as large capacity (>100 MW_e) and fuel-based installations, may soon become fully scalable, highly efficient, and fuel-free electrical energy storage systems. To present this opportunity, a thorough review encompassing previous and up-to-date advancements in their development was carried out. In particular, CAES concepts, such as diabatic (D-CAES), adiabatic (A-CAES), and isothermal (I-CAES), are described in detail. This review also provides the detailed characteristics of the crucial elements of these configurations, including compressors, expanders, air storage chambers, and thermal storage tanks. Knowledge of these components and their role allows us to understand the main challenges behind the further development of the mentioned CAES setups. Apart from the CAES systems that are designed as EES systems, this paper describes other prospective technologies that utilize the energy of pressurized air. Accordingly, compressed air cars and their key elements are explained in detail. Moreover, the technology renowned as wave-driven compressed air energy storage (W-CAES) is described as well, indicating that the utilization of pressurized air represents a viable option for converting ocean energy into electrical power. Full article

A promising method of energy storage is the combination of hydrogen and compressed-air energy storage (CAES) systems. CAES systems are divided into diabatic, adiabatic, and isothermal cycles. In the diabatic cycle, thermal energy after air compression is discharged into the environment, and the scheme implies the use of organic fuel. Taking into account the prospects of the decarbonization of the energy industry, it is advisable to replace natural gas in the diabatic CAES scheme with hydrogen obtained by electrolysis using power-to-gas technology. In this article, the SENECA-1A project is considered as a high-power hybrid unit, using hydrogen instead of natural gas. The results show that while keeping the 214 MW turbines powered, the transition to hydrogen reduces carbon dioxide emissions from 8.8 to 0.0 kg/s, while the formation of water vapor will increase from 17.6 to 27.4 kg/s. It is shown that the adiabatic CAES SENECA-1A mode, compared to the diabatic, has 0.0 carbon dioxide and water vapor emission with relatively higher efficiency (71.5 vs. 62.1%). At the same time, the main advantage of the diabatic CAES is the possibility to produce more power in the turbine block (214 vs. 131.6 MW), having fewer capital costs. Thus, choosing the technology is a subject of complex technical, economic, and ecological study. Full article

There is a significant energy transition in progress globally. This is mainly driven by the insertion of variable sources of energy, such as wind and solar power. To guarantee that the supply of energy meets its demand, energy storage technologies will play an important role in integrating these intermittent energy sources. Daily energy storage can be provided by batteries. However, there is still no technology that can provide weekly, monthly and seasonal energy storage services where pumped hydro storage is not a viable solution. Herein, we introduce an innovative energy storage proposal based on isothermal air compression/decompression and storage of the compressed air in the deep sea. Isothermal deep ocean compressed air energy storage (IDO-CAES) is estimated to cost from 1500 to 3000 USD/kW for installed capacity and 1 to 10 USD/kWh for energy storage. IDO-CAES should complement batteries, providing weekly, monthly and seasonal energy storage cycles in future sustainable energy grids, particularly in coastal areas, islands and offshore and floating wind power plants, as well as deep-sea mining activities. Full article

Water-spray-cooled quasi-isothermal compressed air energy storage aims to avoid heat energy losses from advanced adiabatic compressed-air energy storage (AA-CAES). The compression efficiency increases with injection water spray. However, the energy-generated water spray cannot be ignored. As the air pressure increases, the work done by the piston and the work converted into heat rise gradually in the compression process. Accordingly, the flow rate of the water needed for heat transfer is not a constant with respect to time. To match the rising compression heat, a time sequence of water-spray flow rate is constructed, and the algorithm is designed. Real-time water-spray flow rate is calculated according to the difference between the compression power and heat-transfer power. Compared with the uniform flow rate of water spray, energy consumption from the improved flow rate is reduced. Full article

Air is usually compressed adiabatically in the compressor. As the operating speed of compressors can be several thousand rpm, heat generated during compression cannot be sufficiently transmitted to the environment in such a short time. It is for this reason that compressor efficiency is limited. Isothermal compression could be an alternative choice applied on industrial compressor and compressed air energy storage (CAES). This paper proposed a new kind of piston to perform isothermal compression. Surface area of such isothermal piston structure is larger. A certain amount of fluid at the chamber bottom absorbs the heat from the isothermal piston. Heat transfer between piston and fluid during compression is investigated. Air pressure is measured to validate the effectiveness of this proposed piston structure in heat transfer. Compression work of the proposed isothermal piston and conventional one is compared. One issue of this comparison is that air-liquid dissolution can affect the pressure and compression work. The influence of dissolution is quantified with Henry’s Law. Quantitative analysis is performed to determine that heat transfer is the dominant factor affecting the pressure and compression work. Some simple experiments are described in this paper, which shed light on that heat transfer could be significantly improved adopting this proposed isothermal piston. Full article

The integration of renewable energy in the electrical grid is challenging due to the intermittent and non-programmable generated electric power and to the transmission of peak power levels. Several energy storage technologies have been studied to find a solution to these issues. In particular, compressed air energy storage (CAES) plants work by pumping and storing air into a vessel or in an underground cavern; then when energy is needed, the pressurized air is expanded in an expansion turbine. Several CAES configurations have been proposed: diabatic, adiabatic and isothermal. The isothermal process seems to be the most promising to improve the overall efficiency. It differs from conventional CAES approaches as it employs near-isothermal compression and expansion. Currently, there are no commercial isothermal CAES implementations worldwide, but several methods are under investigation. In this paper, the use of phase change materials (PCM) for isothermal air expansion is discussed. Air expansion tests in presence of PCM were carried out in a high-pressure vessel in order to analyze the effect of PCM on the process. Results show that in presence of PCM near isothermal expansion conditions occur and therefore they affect positively the value of the obtainable expansion work. Full article

Energy storage systems are increasingly gaining importance with regard to their role in achieving load levelling, especially for matching intermittent sources of renewable energy with customer demand, as well as for storing excess nuclear or thermal power during the daily cycle. Compressed air energy storage (CAES), with its high reliability, economic feasibility, and low environmental impact, is a promising method for large-scale energy storage. Although there are only two large-scale CAES plants in existence, recently, a number of CAES projects have been initiated around the world, and some innovative concepts of CAES have been proposed. Existing CAES plants have some disadvantages such as energy loss due to dissipation of heat of compression, use of fossil fuels, and dependence on geological formations. This paper reviews the main drawbacks of the existing CAES systems and presents some innovative concepts of CAES, such as adiabatic CAES, isothermal CAES, micro-CAES combined with air-cycle heating and cooling, and constant-pressure CAES combined with pumped hydro storage that can address such problems and widen the scope of CAES applications, by energy and exergy analyses. These analyses greatly help us to understand the characteristics of each CAES system and compare different CAES systems. Full article
